Seat Upholstery, Covers (coupe) Audi A5 I

Scheme 360

1. Retaining Strip Sewn into cover To engage the cover in the backrest frame side trim
2. Cover Separating cover from upholstery, refer to «BACKREST COVER AND PADDING, SUPER SPORT SEAT, SEPARATING AND CONNECTING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-padding-super-sport)
3. Pocket For side airbag Sewn into cover
4. Side Airbag Removing and installing, refer to «SIDE AIRBAG IGNITERS -N199- / -N200»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
5. Entry Assistance Trim Entry assistance trim, removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Cover With padding Removing and installing, refer to «BACKREST COVER AND PADDING, SUPER SPORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-padding-super-sport) Cover, separating from upholstery and connecting, refer to «BACKREST COVER AND PADDING, SUPER SPORT SEAT, SEPARATING AND CONNECTING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-padding-super-sport)
7. Backrest Frame
8. Retaining Channel Sewn into cover For engaging the cover in the top of the backrest frame
9. Backrest Cover Version without or with storage net Removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The storage net can only be replaced with the backrest cover
10. Backrest Frame Trim Clipped to the backrest frame
11. Retaining Channel Sewn into cover To engage the cover in the backrest frame lower trim

BACKREST COVER AND UPHOLSTERY OVERVIEW

Note. The assembly overview is based on a manual or power standard or sport front seat and comfort seat.

Scheme 361

1. Retaining Strip Sewn into cover To engage the cover in the backrest frame side trim
2. Cover
3. Pocket For side airbag Sewn into cover
4. Side Airbag Removing and installing, refer to «SIDE AIRBAG IGNITERS -N199- / -N200»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
5. Cover With padding Removing and installing, refer to «BACKREST COVER AND UPHOLSTERY»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-upholstery) Cover, separating from upholstery and connecting, refer to «BACKREST COVER AND UPHOLSTERY, SEPARATING AND CONNECTING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-upholstery-separating-and)
6. Entry Assistance Trim Standard front seat and sport front seat (manual) Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-trim) Standard front seat and sport front seat (power) and comfort front seat. Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Headrest Manual Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) Power Removing and installing, refer to «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Backrest Cover Version without or with storage net Removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
9. Backrest Frame Trim Clipped to the backrest frame
10. Retaining Channel Sewn into cover To engage the cover in the backrest frame lower trim

Scheme 362

1. Wiring Connected to the backrest heating element
2. Backrest Bolster Heating Element Bonded Removing and installing, refer to «BACKREST HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Cushion For backrest
4. Upper Backrest Heating Element Only bonded at the edges with the spacer fabric Removing and installing, refer to «BACKREST HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
5. Lower Backrest Heating Element Only bonded at the edges with the spacer fabric Removing and installing, refer to «BACKREST HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)

BACKREST HEATING ELEMENT OVERVIEW, SPORT SEAT

The assembly overview is based on a standard front seat. The backrest heating element on the front sport seat is similar. Refer to

Scheme 363

1. Cushion For backrest
2. Backrest Heating Element Bonded with upholstery Removing and installing, refer to «BACKREST HEATING ELEMENT, SUPER SPORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Wiring Connected to the backrest heating element

Scheme 364

1. Cushion For backrest
2. Backrest Heating Element Bonded with upholstery Removing and installing, refer to «BACKREST HEATING ELEMENT, STANDARD SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Wiring Connected to the backrest heating element

Scheme 365

1. Seat Heating Element Bonded with upholstery Removing and installing, refer to «BUCKET SEAT HEATING ELEMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
2. Bolster Heating Element Firmly connected to seat heating element
3. Backrest Heating Element Bonded with upholstery Removing and installing, refer to «BUCKET SEAT BACKREST HEATING ELEMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
4. Electric Wire Connected to the backrest heating element
5. Electric Wire Connected to the seat heating element

Scheme 366

1. Backrest Cover Removing and installing, refer to «BUCKET SEAT BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
2. Outer Belt Guide Part Removing and installing, refer to «SEAT BELT GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-belt-guide)
3. Retaining Clips Quantity: 8 For grip channel of backrest cover Install in bend in backrest
4. Backrest Padding Removing and installing, refer to «BUCKET SEAT BACKREST PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
5. Module Carrier With Air Cushions For Lumbar Support Removing and installing, refer to «MODULE CARRIER WITH AIR CUSHIONS FOR LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Backrest Removing and installing, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-backrest)
7. Backrest Bolster Inflation Adjuster Disengage, refer to «BUCKET SEAT BACKREST PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)

Scheme 367

1. Seat Pan Removing and installing, refer to «SEAT PAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-pan)
2. Right Seat Bolster Inflation Adjuster Disengage, refer to «BUCKET SEAT PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Seat Pan Cushion Removing and installing, refer to «BUCKET SEAT PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
4. Seat Pan Cover Removing and installing, refer to «BUCKET SEAT COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
5. Y-Connector Connects both pneumatic hoses to seat bolster inflation adjustment
6. Left Seat Bolster Inflation Adjuster Disengage «BUCKET SEAT PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)

Scheme 368

1. Headrest Support Manual headrests
2. Headrest Support Power headrests Only available as a replacement with upholstery, refer to item 3
3. Cushion Removing and installing, refer to «HEADREST COVER AND UPHOLSTERY, WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__headrest-cover-and-upholstery-with-locking) The release button opening is only with the manual headrests
4. Cover Removing and installing, refer to «HEADREST COVER AND UPHOLSTERY, WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__headrest-cover-and-upholstery-with-locking) The release button opening is only with the manual headrests
5. Release Button For height adjustment Clipped to the headrest support Only installed with manual headrests

LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER OVERVIEW

Note. The assembly overview is based on a manual or power sport front seat and super sport front seat.

Scheme 369

1. Cover With seat depth adjustment cushion Removing and installing, refer to «LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__lower-seat-frame-with-seat-depth) Cover, separating from upholstery and connecting, refer to «LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__lower-seat-frame-with-seat-depth)
2. Cover With the seat cushion Removing and installing, refer to «LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__lower-seat-frame-with-seat-depth) Cover, separating from upholstery and connecting, refer to «LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__lower-seat-frame-with-seat-depth)
3. Retaining Channel Clipped in -Item 4- Sewn into cover Cushion clamp Only with leather covers For securing cover to upholstery Always replace if removed Install in same location as before removal
4. Clip In foam in upholstery
5. Clip In foam in upholstery Only with fabric covers
6. Contour Wire Pushed into the cover Clipped in -Item 5
7. Retaining Channel Sewn into cover For engaging the cover on the rear of the seat pan upper frame
8. LATCH Child Seat Anchorage Assembly overview, refer to «FRONT SEAT CHILD SEAT ANCHORS OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__front-seat-child-seat-anchors-overview) Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
9. Tab With clamping profile Sewn into cover For engaging the cover on side of the seat pan upper frame
10. Retaining Channel Sewn into cover For engaging the cover on the front and side of the seat pan upper frame, except the seat cushion extension area.
11. Retaining Bracket For sill side trim Manual sport front seat Removing and installing, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__sill-side-retaining-bracket-trim) (retaining bracket not shown in the illustration) Power sport front seat and super sport front seat Removing and installing, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
12. Seat Depth Adjuster

LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER OVERVIEW

Note. The assembly overview is based on a manual or power standard front seat and comfort seat.

Scheme 370

1. Cover
2. Contour Wire Pushed into the cover Clipped in -3- (only with fabric covers)
3. Clip Positioned in the foam upholstery (only with fabric covers)
4. Retaining Channel Clipped in -5- Sewn into cover
5. Clip In foam in upholstery
6. Retaining Channel Sewn into cover For engaging the cover on the rear of the seat pan upper frame
7. LATCH Child Seat Anchorage Vehicles equipped with: front passenger seat only Assembly overview, refer to «FRONT SEAT CHILD SEAT ANCHORS OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__front-seat-child-seat-anchors-overview) Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
8. Cover Strap With clamping profile or hook Retaining channel or hook sewn to the cover For engaging the cover on side of the seat pan upper frame
9. Retaining Bracket For sill side trim Standard front seat (manual) Removing and installing «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__sill-side-retaining-bracket-trim) (retaining bracket not shown in the illustration) Power standard front seat Removing and installing, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. Cushion With wire placed in foam upholstery (only with leather covers)
11. Cushion Clamp Only with leather covers For securing cover to upholstery Always replace if removed Install in same location as before removal
12. Retaining Channel Sewn into cover For engaging the cover on the front and side of the seat pan upper frame.
13. Cover With padding Removing and installing, refer to «LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__lower-seat-frame-without-seat-depth) Cover, separating from upholstery and connecting «LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__lower-seat-frame-without-seat-depth)

Scheme 371

1. Front Seat Heating Element Connected to the bolster heating elements Removing and installing, refer to «SEAT HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
2. Cushion For seat pan
3. Bolster Heating Element Connected to the front and rear seat heating elements Removing and installing, refer to «SEAT HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
4. Wiring Connected securely to the seat heating element
5. Rear Seat Heating Element Connected to the bolster heating elements Removing and installing, refer to «SEAT HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
6. Center Rear Seat Heating Element Connected to the rear seat heating element Only bonded at the edges with the spacer fabric Removing and installing, refer to «SEAT HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
7. Center Front Seat Heating Element Connected to the center rear seat heating element Only bonded at the edges with the spacer fabric Removing and installing, refer to «SEAT HEATING ELEMENT, COMFORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)

Scheme 372

1. Cushion For seat pan
2. Seat Heating Element Bonded with upholstery Removing and installing, refer to «SEAT HEATING ELEMENT, SPORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Wiring Connected to the seat heating element
4. Bolster Heating Element Connected to the seat heating element
5. Seat Depth Adjuster Heating Element Connected to the seat heating element

Scheme 373

1. Cushion For seat pan
2. Seat Heating Element Bonded with upholstery Removing and installing, refer to «SEAT HEATING ELEMENT, STANDARD SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Wiring Connected to the seat heating element
4. Seat Bolster Heating On all cover versions except the fabric standard seat Connected to the seat heating element

Scheme 374

1. Cushion For seat pan
2. Seat Heating Element Bonded with upholstery Removing and installing, refer to «SEAT HEATING ELEMENT, SUPER SPORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
3. Wiring Connected to the seat heating element
4. Bolster Heating Element Bonded to the seat heating element
5. Seat Depth Adjuster Heating Element Connected to the seat heating element

Scheme 375

1. Backrest Heating Element Bonded with upholstery Removing and installing, refer to «BACKREST HEATING ELEMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
2. Cushion For backrest
3. Electric Wire Connected to the backrest heating element

BACKREST WITH COVER OR STORAGE COMPARTMENT OVERVIEW

Note. The illustration only shows the structure of the right 2/3 section of the backrest. The structure of the left 1/3 section of the backrest is similar.

Scheme 376

1. Trim For locking Lock cylinder without trim, removing and installing, refer to «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder) . Lock cylinder with trim, removing and installing, refer to «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder) .
2. Headrest Guide Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Backrest Shell
4. Outer Bracket
5. Release Cable Lock - connector station
6. Inner Bracket
7. Upper Upholstery Removing and installing, refer to «BACKREST WITH COVER OR STORAGE COMPARTMENT, CUSHION»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
8. Cushion Removing and installing, refer to «COVER AND PADDING, BACKREST WITH COVER OR STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Separating cover from upholstery, refer to «BACKREST WITH COVER OR STORAGE COMPARTMENT, PADDING COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-with-cover-or-storage-compartment)
9. Clip In foam in upholstery
10. Clip In foam in upholstery Only with fabric covers
11. Cover Removing and installing, refer to «COVER AND PADDING, BACKREST WITH COVER OR STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Separating cover from upholstery, refer to «BACKREST WITH COVER OR STORAGE COMPARTMENT, PADDING COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-with-cover-or-storage-compartment)
12. Cushion Clamp Only with leather covers For securing cover to upholstery Always replace if removed Install in same location as before removal
13. Retaining Channel Sewn into cover For engaging the cover in the backrest shell
14. Molding Only on backrest with storage compartment or backrest back cover, 2/3 right side Sewn into cover For attaching the cover into the storage compartment cut-out or the backrest cover
15. Molding Sewn into cover For engaging the cover in the backrest shell
16. Plugs For securing the cover Quantity: 2
17. Lower Upholstery Removing and installing, refer to «BACKREST WITH COVER OR STORAGE COMPARTMENT, CUSHION»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)

BACKREST WITH PASS-THROUGH OVERVIEW

Note. The illustration only shows the structure of the right 2/3 section of the backrest. The structure of the left 1/3 section of the backrest is similar.

Scheme 377

1. Trim For locking Lock cylinder without trim, removing and installing, refer to «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder) . Lock cylinder with trim, removing and installing, refer to «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder) .
2. Headrest Guide Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Cover Frame Only with the right 2/3 section of the backrest with pass-through Removing and installing, refer to «COVER FRAME»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__cover-frame)
4. Backrest Shell
5. Outer Bracket
6. Release Cable Lock - connector station
7. Inner Bracket
8. Cushion Removing and installing, refer to «BACKREST COVER AND PADDING WITH PASS-THROUGH»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Separating cover from upholstery, refer to «COVER AND PADDING, BACKREST WITH PASS-THROUGH, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__cover-and-padding-backrest-with-pass-through)
9. Clip In foam in upholstery
10. Clip In foam in upholstery Only with fabric covers
11. Cover Removing and installing, refer to «BACKREST COVER AND PADDING WITH PASS-THROUGH»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Separating cover from upholstery, refer to «COVER AND PADDING, BACKREST WITH PASS-THROUGH, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__cover-and-padding-backrest-with-pass-through)
12. Cushion Clamp Only with leather covers For securing cover to upholstery Always replace if removed Install in same location as before removal
13. Retaining Channel Sewn into cover For engaging the cover in the backrest shell
14. Molding Only with the right 2/3 section of the backrest with pass-through Sewn into cover For engaging the cover in the pass-through opening
15. Molding Sewn into cover For engaging the cover in the backrest shell
16. Plugs For securing the cover Quantity: 2

Scheme 378

1. Cover Removing and installing, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment) Separating cover from upholstery, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment)
2. Molding Sewn into cover For engaging the cover in the rear and side channel at the center armrest
3. Contour Wire Pushed into the cover
4. Molding Sewn into cover For engaging the cover in the seat frame
5. Left/Right Upholstery Removing and installing, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment) Separating cover from upholstery, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment)
6. Center Storage Compartment Separating the cover from the center storage compartment: Right cover, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment) Left cover, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment) Removing and installing, refer to «CENTER STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Clip In foam in upholstery Only with fabric covers
8. Clip In foam in upholstery
9. Seat Frame
10. Cushion Clamp Only with leather covers For securing cover to upholstery Always replace if removed Install in same location as before removal

Scheme 379

1. Cover Removing and installing, refer to «BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Separating cover from upholstery «BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-without-center-storage-compartment)
2. Contour Wire Pushed into the cover
3. Cushion Removing and installing, refer to «BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Separating cover from upholstery «BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-without-center-storage-compartment)
4. Molding Sewn into cover For engaging the cover in the seat frame
5. Clip In foam in upholstery Only with fabric covers
6. Seat Frame
7. Cushion Clamp Only with leather covers For securing cover to upholstery Always replace if removed Install in same location as before removal
8. Clip In foam in upholstery

HEADREST OVERVIEW

Note. A leather headrest is shown in the illustration. Because headrests with a fabric cover are not disassembled, that version is not shown in the assembly overview.

Scheme 380

1. Cover Equipment level: leather cover Removing and installing, refer to «HEADREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__headrest-cover) CAUTION: It is only possible to replace the cover on the headrest with a leather cover. It is not possible to replace a fabric headrest cover because the cover is filled with foam and also serves as the casing for the upholstery.
2. Carrier Piece With padding Equipment level: leather cover The headrest support is in the upholstery and cannot be separated
3. Leg Spring Removing and installing, refer to «LEG SPRING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
4. Trim Removing and installing, refer to «TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)

SEAT HEATING ELEMENT OVERVIEW

Note. The figure shows the location of the seat heating elements on a bench seat without a center storage compartment. The location of the seat heating elements is similar on a bench seat with a center storage compartment.

Scheme 381

1. Seat Heating Element Bonded with upholstery Removing and installing, refer to «SEAT HEATING ELEMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
2. Electric Wire Connected to the seat heating element
3. Cushion For the bench seat

BACKREST COVER AND PADDING, SUPER SPORT SEAT

Special tools and workshop equipment required

1. Drill for vehicles equipped with a DVD player
2. Eye protection for vehicles equipped with a DVD player
3. 12 mm drill for vehicles equipped with a DVD player

REMOVING

Remove the front seat. Refer to SUPER SPORT FRONT SEAT .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Vehicles Equipped with a Mount for a DVD Player

Scheme 382

1. DVD player removed.

Unclip the trim -2- for the connector -arrow-.

Drill out the guides -1- and -3- for the DVD player using a 12 mm drill.

Scheme 383

All Vehicles

Remove backrest cover panel. Refer to BACKREST COVER .

Remove front backrest. Refer to FRONT BACKREST .

Remove the entry assistance trim. Refer to ENTRY ASSISTANCE TRIM .

Disengage the lower retaining channels -5- and -6-.

Scheme 384

Disengage the upper retaining channel -3-.

1 - Cover

2 - Backrest frame

3 - Upper retaining channel

4 - Backrest frame trim

Disengage the side retaining strips -3- at the backrest frame trim catches -2-.

Scheme 385

Pull the cover as far forward as possible in the side airbag area in order to be able to remove side airbag.

Remove side airbag. Refer to SIDE AIRBAG IGNITERS -N199- / -N200

Remove the airbag from the pocket sewn into the cover and engage the airbag in the backrest frame.

Reach from the rear side of the backrest under the upholstery and find the release button -5-.

Scheme 386

Press the release button in the direction of the -arrow-.

Hold release button -5- down in this position.

Remove the upholstery with the headrest -1- upward from the backrest frame -3-.

1 -Headrest

2 - Headrest guide without release button

3 - Seat backrest frame

4 - Side Airbag

5 - Release Button

6 - Headrest guide with release button

Note. A second technician is needed to remove the upholstery with the headrest from the backrest frame.

Equipment Versions with Lumbar Support

Scheme 387

Separate the upholstery from the Velcro™ fastener -3- on the lumbar support -2- otherwise the lumbar support will be damaged when removing the hooks -arrows-.

All Vehicles

Remove cover with upholstery from backrest frame.

INSTALLING

Install in reverse order of removal. Note the following

Make sure the headrest is engaged correctly in headrest guides after positioning upholstery on backrest.

Make sure the retaining channels -3-, -5- and -6- and the side retaining strips engage correctly and the cover is not wrinkled.

Vehicles Equipped with a Mount for a DVD Player

1. The guide mounts -1- and -3- on the backrest must free of contaminants.

Align the backrest cover and install the guides into the mounts.

1. The guides -1- and -3- can be installed in only one position.
2. The release buttons must face outside.

Install the trim -2-.

1. The trim can be installed in only one position.

Note. Ignore the -arrow- in this reference.

All Vehicles

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

BACKREST COVER AND PADDING, SUPER SPORT SEAT, SEPARATING AND CONNECTING

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Scheme 388

Remove the cover and upholstery from the backrest. Refer to BACKREST COVER AND PADDING, SUPER SPORT SEAT .

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Versions with Fabric Covers

Scheme 389

Remove contour wire -3- that is inserted into pocket -2- in cover -1- from clips -4-.

Remove the cover from the cushion -5-.

Versions with Leather Covers

Scheme 390

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Install in reverse order of removal. Note the following

When installing new upholstery clips, use Upholstery Clip Pliers V.A.G 1634.

BACKREST COVER AND UPHOLSTERY

Note. The work description is based on a manual or power standard or sport front seat and comfort seat.

Special tools and workshop equipment required

1. Drill for vehicles equipped with a DVD player
2. Eye protection for vehicles equipped with a DVD player
3. 12 mm drill for vehicles equipped with a DVD player

Remove the front seat

1. Standard seat and Sport seat (manual), refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Vehicles Equipped with a Mount for a DVD Player

1. DVD player removed.

Unclip the trim -2- for the connector -arrow-.

Drill out the guides -1- and -3- for the DVD player using a 12 mm drill.

All vehicles

Remove backrest cover panel. Refer to BACKREST COVER .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the front backrest

1. Standard seat and Sport seat (manual), refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the entry assistance trim

1. Standard seat and Sport seat (manual), refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-trim) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Disengage the lower clamping profile -5- and -6- on the backrest frame trim -4-.

Scheme 391

Disengage the upper clamping profile -3- for the cover -1- on the backrest frame -2-.

Disconnect the electrical connectors and free them up.

Disengage the side retaining strips -3- at the backrest frame trim catches -2-.

Scheme 392

Remove the upholstery on the backrest until it is possible to remove the side airbag.

Remove side airbag. Refer to SIDE AIRBAG IGNITERS -N199- / -N200 .

Vehicles Equipped with a Manual Adjustable Seat

Disengage the side airbag from the backrest frame using the hook and out of the pocket sewn in the cover and install it again in the backrest frame.

Versions with Power Seats

Disengage the side airbag from the backrest frame using the hook and leave it in the pocket sewn in the cover.

Equipment Versions with Lumbar Support (not Comfort Seat)

Separate the upholstery from the Velcro fastener -3- on the lumbar support -2- otherwise the lumbar support will be damaged when removing the hooks -arrows-.

All Vehicles

Remove the cover and cushion from the backrest frame while guiding the side airbag wiring harness.

Install in reverse order of removal. Note the following

Make sure the retaining channels -3, 5 and 6- and the side retaining strips engage correctly and the cover is not wrinkled.

Vehicles Equipped with a Mount for a DVD Player

1. The guide mounts -1- and -3- on the backrest must free of contaminants.

Align the backrest cover and install the guides into the mounts.

1. The guides -1- and -3- can be installed in only one position.
2. The release buttons must face outside.

Install the trim -2-.

1. The trim can be installed in only one position.

Note. Ignore the -arrow-.

All Vehicles

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

BACKREST COVER AND UPHOLSTERY, SEPARATING AND CONNECTING

Note. The work description is based on a manual or power standard or sport front seat and comfort seat.

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Scheme 393

Remove the cover and upholstery from the backrest BACKREST COVER AND UPHOLSTERY .

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Remove cover from cushion.

Versions with fabric covers

Scheme 394

Remove contour wire -3- that is inserted into pocket -2- in cover -1- from clips -4-.

Remove the cover from the cushion -5-.

Versions with leather covers

Scheme 395

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

Scheme 396

Remove cover and cushion from backrest, refer to BACKREST COVER AND UPHOLSTERY .

Disconnect cover from upholstery BACKREST COVER AND UPHOLSTERY, SEPARATING AND CONNECTING .

Cut the wire -1- off directly at the old lower backrest heating element -2-.

Cut through the connecting bars and wires -arrows-.

Carefully loosen the top and bottom of the backrest heating element -C- and -D- and remove.

Note. The spacer fabric must not be damaged. The heating elements -A- and -B- remain on the backrest bolsters and the new backrest heating element is bonded over them.

Align the new backrest heating element on the upholstery -1-.

Bond the individual areas of the heating element in the sequence -A-, -B-, -C- and -D-.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrows-.

Pull the wire -3- through the slit in the upholstery.

Further installation is performed in the reverse order of removal.

BACKREST HEATING ELEMENT, SPORT SEAT

Removing and installing a standard front seat is described. The procedure is similar for a sport front seat.

Scheme 397

Remove cover and cushion from backrest, refer to BACKREST COVER AND UPHOLSTERY .

Disconnect cover from upholstery BACKREST COVER AND UPHOLSTERY, SEPARATING AND CONNECTING .

Cut the wire -3- off directly at the old backrest heating element -2-.

Note. The old backrest heating element remains on the upholstery -1- and the new backrest heating element is bonded over it.

Align the new backrest heating element on the upholstery.

Bond the individual areas of the heating element in the sequence -A-, -B- and -C-.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrow-.

Pull the wire -3- through the slit in the upholstery -1-.

Further installation is performed in the reverse order of removal.

Scheme 398

Remove cover and cushion from backrest, refer to BACKREST COVER AND PADDING, SUPER SPORT SEAT .

Disconnect cover from upholstery BACKREST COVER AND PADDING, SUPER SPORT SEAT, SEPARATING AND CONNECTING .

Cut the wire -3- off directly at the old backrest heating element -2-.

Note. The old backrest heating element remains on the upholstery -1- and the new backrest heating element is bonded over it.

Align the new backrest heating element on the upholstery.

Bond the individual areas of the heating element in the sequence -B, A, C and D-.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrow-.

Pull the wire -3- through the slit in the upholstery -1-.

Further installation is performed in the reverse order of removal.

Scheme 399

Remove the seat pan SEAT PAN .

Detach Velcro™ fastener -2-.

Pry the retaining strip at the edge of seat cover -3- out from around the guide on the seat pan.

Detach rear retaining strip -1- at the seat pan.

Detach retaining strip -1- from the holders -arrow- at the seat pan cushion and detach Velcro™ fastener -3- at seat pan cushion -2-.

Scheme 400

Remove the seat pan cover.

Install in reverse order of removal.

Scheme 401

Remove the backrest FRONT BACKREST .

Remove the outer belt guide parts SEAT BELT GUIDE .

Starting at the bottom, pry the grip channel for the backrest cover out of the guide at the backrest, using for example, an awl -arrow- ; lightly press together the backrest upholstery in order to release the strain on the backrest cover.

Pry the retaining strip at the edge of the backrest cover out from around the guide on the backrest.

1. In the bends, the grip channel is also secured by clips. Carefully remove the clips.

Pull out lower retaining strip -2- on module carrier -1-.

Scheme 402

Detach retaining strip -1- from the holders -arrow- at the backrest cushion and detach Velcro™ fastener -3- at backrest cushion -2-.

Remove the backrest cover.

Install in reverse order of removal.

Scheme 403

Remove the backrest cushion and place on a soft surface BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW .

Note. The electrical wiring harness for the module carrier must not be disconnected from the seat pan.

Disconnect the electrical harness connector for the backrest heating element.

Cut electrical wire -6- off directly at the old seat heating element -arrow-.

Note. The old seat heating element remains on the upholstery and the new seat heating element is bonded over it.

Remove the old electrical connection wire.

Disconnect electrical connecting wires -5- and -7- to the heating elements at the backrest bolsters.

Align the new heating elements on the backrest surface.

Remove the protective film and adhere new heating elements -1, 2, 3, 4- to the same positions as the old heating elements.

Run connecting wires -A- loosely to the upper backrest heating element along the bottom of the gaps.

Run the connecting wires loosely to the backrest bolsters along the bottom of the gaps.

Scheme 404

Remove the backrest cover BUCKET SEAT BACKREST COVER .

Tilt the backrest bolster inward -arrow A- and detach backrest bolster inflation adjuster -1- at retaining bracket -3- of the backrest -arrow B-.

Expose pneumatic hose -2- for backrest bolster inflation adjustment at the backrest shell. Remove adhesive tape -1- for this purpose.

Scheme 405

Disconnect the pneumatic hose at Y-Connector -3- and expose it on the left side. Remove adhesive tape -4- for this purpose.

Remove the backrest cushion with the backrest bolster inflation adjuster from the backrest shell.

Install in reverse order of removal.

Scheme 406

Remove the seat pan cushion BUCKET SEAT COVER .

Cut electrical wire -5- off directly at the old seat heating element -arrow-.

Note. The old seat heating element remains on the upholstery and the new seat heating element is bonded over it.

Remove the old electrical connection wire.

Align the new heating elements on the seat surface.

Conduct the electrical connection wire down through the opening provided in the seat cushion.

Remove the protective film and adhere new heating elements -1, 2, 3, 4, 6- to the same positions as the old heating elements.

Run connecting wires -A- loosely to the seat bolsters along the bottom of the gaps.

Scheme 407

Remove the seat pan cover. Refer to BUCKET SEAT COVER .

Remove seat bolster inflation adjuster -2- from retaining bracket -3- of the seat pan -arrow-.

Disconnect pneumatic hose -1- for seat bolster inflation adjustment at the Y-Connector.

Remove the seat pan cushion with the seat bolster inflation adjuster.

Install in reverse order of removal.

HEADREST COVER AND UPHOLSTERY, WITH LOCKING MECHANISM

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Remove headrests.

1. Manual headrests, removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism)
2. Power headrests, removing and installing, refer to «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Side Locks, Opening

Scheme 408

Open the side locks -arrows- on the cover -1-.

Slide the trim removal wedge 3409 or a flat-head screwdriver in the direction of -arrow A- between the cover lock -1-.

Scheme 409

Bend the lower U-Channel -3- in the direction of -arrow B-.

Pull the upper side of the cover with the flat channel -2- out of the U-Channel -3-.

Main Lock, Opening

Scheme 410

Slide the trim removal wedge 3409 or a flat-head screwdriver between the cover lock.

Bend the lower U-Channel -1- in the direction of -arrow A-.

Pull the upper side of the cover with the flat channel -2- out of the U-Channel -1-.

Note. The cover must be completely open to remove the upholstery.

Remove the padding -1- from the cover -2-.

Scheme 411

Insert cushion -1- into cover -2- and make sure it fits properly.

Insert headrest mount in upholstery with cover.

Main Lock, Closing

Scheme 412

Fold the upper flat channel -1- down.

Slide the edge of the fabric with the flat channel -1- into the U-Channel -5-.

2 - Cover

3 - Cushion

4 - Headrest support

Side Locks, Closing

Closing the side locks is similar to the closing the main lock.

After Closing the Main and Side Locks

Using a needle or a tool with a point, align the cover and the channels.

Make sure the cover lies on the upholstery without any wrinkles and without seam markings.

With manual headrests, install the height adjustment release button.

Insert the release button through the cover and the upholstery into the headrest support.

Be careful of the release button/headrest support locking device.

The tab -arrow A- on the release button -1- must align with the slit -arrow B- in the button mount on the headrest support -2-.

Scheme 413

Clip the release button -1- into the headrest support -2-.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING

Note. The work description is based on a manual or power sport front seat and super sport front seat.

Remove the front seat

1. Manual Sport seat, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Power Sport seat, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super sport seat, refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove the front backrest

1. Manual Sport seat, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
2. Power Sport seat, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
3. Super sport seat, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the sill side trim retaining bracket.

1. Manual Sport seat, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__sill-side-retaining-bracket-trim) .
2. Power sport seat and super sport seat, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Versions with LATCH (passenger seat only), remove the LATCH, refer to LATCH AND TOP TETHER CHILD SEAT ANCHORS .

Remove the seat depth adjuster as far as the stop.

Unclip the catches -2-.

Scheme 414

Tilt the support with the cushion and cover -1- for the seat depth adjustment upward in the direction of the -arrow- so that the catches remain disengaged.

Remove support -1- with seat depth adjustment cushion and cover -2- up and forward at an angle.

Scheme 415

Note. The illustration does not show the seat pan lower frame.

Disengage tabs -3- from openings -5- on seat depth adjustment lower section -4-.

Unclip the clamping profile -1- and -2- for the cover and cushion -4- across and at the sides from the catches -3-.

Scheme 416

Disengage the cover retaining channels -3- is the side areas -A- of the seat pan upper frame.

Scheme 417

When disengaging the retaining channels, be careful of the exposed retaining hooks -1- on the edge -2-.

Disengage tab retaining channels -1- at both sides of the seat pan -3-.

Scheme 418

1. LATCH child seat anchor -2- removed.

Disengage the cover retaining channels -6- in the area -A-.

When disengaging the cover, be careful of the exposed retaining hooks -4- on the edge -5-.

Remove the cover with upholstery from the seat pan and seat depth adjuster.

The seat depth adjuster support (plastic) remains on the upholstery.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING

Note. The work description is based on a manual or power sport front seat and super sport front seat.

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Scheme 419

Remove the cover and upholstery from the seat pan and seat depth adjuster. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING .

Unclip the retaining channels -2- from the catches -5-.

Disengage the cover from the tabs -4- on both sides.

Remove the support with seat depth adjuster cushion -3- from cover -1-.

Cover and Upholstery, Sport Seat, Separating

Scheme 420

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Remove cover from cushion.

Versions with Fabric Covers

Scheme 421

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Scheme 422

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Cover and Upholstery, Super Sport Seat, Separating

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Versions with Fabric Covers

Scheme 423

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Scheme 424

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING

Note. The work description is based on a manual or power standard front seat and comfort seat.

Remove the front seat

1. Manual standard seat, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Power standard seat and Comfort seat, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136 FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove the front backrest

1. Manual standard seat, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
2. Power standard seat and Comfort seat, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the sill side trim retaining bracket.

1. Manual standard seat, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__sill-side-retaining-bracket-trim) .
2. Power standard seat and Comfort seat, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Versions with LATCH (passenger seat only), remove the LATCH, refer to LATCH AND TOP TETHER CHILD SEAT ANCHORS .

Storage compartment, removing, refer to STORAGE COMPARTMENT .

Disconnect the electrical connectors and free them up.

Disengage the front and side areas -A- and -B- of the cover retaining channel -3-.

Scheme 425

When disengaging the cover, be careful of the exposed retaining hooks -1- on the edge -2-.

Disengage the retaining channel or hooks on the tabs -1- at both sides of the seat pan -3-.

1. LATCH child seat anchor -2- removed.

Disengage the cover retaining channel -6- in the area -A-.

When disengaging the cover, be careful of the exposed retaining hooks -4- on the edge -5-.

Remove the cover with upholstery from the seat pan.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA, CAEB, CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING

Note. The work description is based on a manual or power standard front seat and comfort seat.

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Scheme 426

Remove the cover and upholstery from the seat pan. Refer to LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING .

Remove the rear and sides of the cover -1- from the upholstery -2-.

On vehicles with comfort seats, unclip retaining channel -3- on the front side of the upholstery from clips -4-.

Unclip retaining channel -4- for cover -1- on upholstery -3- from clips -2-.

Scheme 427

Remove cover from cushion.

Versions with Fabric Covers

Scheme 428

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Scheme 429

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

Scheme 430

Remove cover and upholstery from seat pan. Refer to LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING .

Disconnect cover from upholstery. Refer to LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING .

Cut the wire -3- off directly at the old heating element -2-.

Note. The old seat heating element remains on the upholstery -1- and the new seat heating element is bonded over it. Ignore items -A through E- and -arrows- in this reference.

Align the new heating element on upholstery.

Bond the individual areas of the heating element in the sequence -A, B, C and D-.

Bond the bolster area -E- last on all cover versions except the basic fabric.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrows-.

Pull the wire -3- through the slit in the upholstery -1-.

Further installation is performed in the reverse order of removal.

Remove cover and upholstery from seat pan. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING .

Disconnect cover from upholstery. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING .

Cut electrical wire -3- off directly at old seat heating element -2-.

Scheme 431

Cut through the connecting bars -arrows-.

Carefully loosen the seat heating elements -D- and -E- from the bonded connection and remove them.

Note. The spacer fabric must not be damaged. The old seat heating elements -A, B and C- remain on the upholstery and the new seat heating element is bonded over them.

Align the new heating element on upholstery.

Bond the individual areas of the heating element in the sequence -A, B, C, D and E-.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrows-.

Pull the wire -3- through the slit in the upholstery -1-.

Further installation is performed in the reverse order of removal.

Scheme 432

Remove cover and upholstery from seat pan. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING .

Disconnect cover from upholstery. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING .

Cut the wire -3- off directly at the old heating element -2-.

Note. The old seat heating element remains on the upholstery -1- and the new seat heating element is bonded over it.

Align the new heating element on upholstery.

Bond the individual areas of the heating element in the sequence -A-, -C-, -D- and -E-.

Bond the bolster area -B- last on all cover versions except the basic fabric.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrows-.

Pull the wire -3- through the slit in the upholstery -1-.

Further installation is performed in the reverse order of removal.

Scheme 433

Remove cover and upholstery from seat pan. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING .

Disconnect cover from upholstery. Refer to LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING, SEPARATING AND CONNECTING .

Cut the wire -3- off directly at the old heating element -2-.

Note. The old seat heating element remains on the upholstery -1- and the new seat heating element is bonded over it.

Align the new heating element on upholstery.

Bond the individual areas of the heating element in the sequence -A-, -B-, -D-, -E- and -C-.

Route the connecting wires to the individual heating surfaces in the base of the gaps -arrows-.

Pull the wire -3- through the slit in the upholstery -1-.

Further installation is performed in the reverse order of removal.

Remove the seat bench. Refer to BENCH SEAT .

Remove the backrest. Refer to BACKREST .

Remove the headrests. Refer to HEADREST .

Right 2/3 Section of Backrest with Pass-Through

Remove the center armrest with the pass-through cover. Refer to CENTER ARMREST WITH PASS-THROUGH COVER .

Remove the cover frame. Refer to COVER FRAME .

Continuation for Left and Right Backrest

Scheme 434

Remove the retainer trim. Refer to

1. «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder) .
2. «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder) .

Remove headrest guide. Refer to HEADREST GUIDE .

Unclip the plugs -2-.

1 - Cover

2 - Plugs

3 -Inner bracket

Pry the upper retaining channel -1- out of the backrest shell -3-.

Scheme 435

Remove the molding -2- from the sides and bottom of the backrest shell -3-.

Right 2/3 Section of Backrest with Pass-Through

Scheme 436

Pry off molding -1- and -3- in backrest pass-through -2-.

Continuation for Left and Right Backrest

Pry the cover over the inner bracket.

Pry the cover over the outer bracket.

Guide the release cable with the connector station through the slit in the cover.

Remove the cover with upholstery from the backrest shell.

Scheme 437

Install in reverse order of removal. Note the following

Install headrest guide with button at left.

Make sure the button -2- moves easily after installing the trim.

REMOVE THE UPPER UPHOLSTERY.

Disengage the top and bottom of the cover at the backrest shell.

Fold the cover back until the upper section of the upholstery can be removed from the backrest shell.

UPPER UPHOLSTERY, INSTALLING

Install in reverse order of removal.

REMOVE THE LOWER UPHOLSTERY.

Disengage the bottom and sides of the cover at the backrest shell.

Fold the cover back until the lower section of the upholstery can be removed from the backrest shell.

LOWER UPHOLSTERY, INSTALLING

Install in reverse order of removal.

BACKREST WITH COVER OR STORAGE COMPARTMENT, PADDING COVER

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Scheme 438

Remove cover with upholstery. Refer to COVER AND PADDING, BACKREST WITH COVER OR STORAGE COMPARTMENT .

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Remove cover from cushion.

Versions with Fabric Covers

Scheme 439

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Scheme 440

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

Remove the backrest cover and upholstery. Refer to

1. «BACKREST COVER AND PADDING WITH PASS-THROUGH»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) .
2. «COVER AND PADDING, BACKREST WITH COVER OR STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) .

Separate the cover from the upholstery. Refer to

1. «COVER AND PADDING, BACKREST WITH PASS-THROUGH, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__cover-and-padding-backrest-with-pass-through) .
2. «BACKREST WITH COVER OR STORAGE COMPARTMENT, PADDING COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-with-cover-or-storage-compartment) .

Cut the electrical wire -3- off directly at the old backrest heating element -2-.

Scheme 441

Note. The old backrest heating element remains on the upholstery -1- and the new backrest heating element is bonded over it. Ignore -arrows A through E- in this reference.

Align the new backrest heating element on the upholstery.

Begin bonding the center are of the backrest heating element -arrow C-.

Then bond the top area -arrow A-.

Route the connecting wires from the top to the bottom heating surface in the base of the gaps -B arrows-.

Bond the bottom area of the heating surface -arrow D-.

Pull the wire -3- through the slit in the upholstery -arrow E-.

Further installation is performed in the reverse order of removal.

BACKREST WITH PASS-THROUGH, INTERNAL PADDING

The internal upholstery can only be removed and installed when the center armrest with pass-through cover is removed. It is not possible to separate the upholstery or cover. These components can only be replaced together. Refer to

BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 442

Remove the seat bench. Refer to BENCH SEAT .

Disengage the rear and side molding -2- from the channel -arrow- in the center storage compartment -1-.

Disengage the molding -1- all around the seat frame -2-.

Scheme 443

Remove the cover with upholstery -3- and -4- from the seat frame -2-.

Install in reverse order of removal. Note the following

When engaging the cover in the center storage compartment channel, begin at the center of the rear.

Align the cover molding to the center storage compartment and then clip the cover into the center storage compartment channel.

Do the same on the other sides of the cover.

Make sure the covers are secured on the center storage compartment without wrinkles.

BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Scheme 444

Remove cover with upholstery. Refer to BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING .

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Remove cover from cushion.

Versions with Fabric Covers

Scheme 445

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Scheme 446

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -2- from cushion -1-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

Remove the seat bench. Refer to BENCH SEAT .

Disengage the molding -1- all around the seat frame -2-.

Remove the cover with upholstery -3- and -4- from the seat frame -2-.

Install in reverse order of removal.

BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Remove cover with upholstery. Refer to BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING .

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Versions with Fabric Covers

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -2- from cushion -1-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

CENTER STORAGE COMPARTMENT

The following article describes the removal and installation. Refer to CENTER STORAGE COMPARTMENT .

Remove the seat bench. Refer to BENCH SEAT .

Remove the backrest. Refer to BACKREST .

Remove the headrests. Refer to HEADREST .

Split backrest right 2/3 with storage compartment or cover

Remove the center armrest. Refer to CENTER ARMREST .

Remove the storage compartment (backrest cover with lock) or backrest cover. Refer to

1. «LOCKABLE ARMREST STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lockable-armrest-storage-compartment) .
2. «BACKREST TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
3. «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Continuation for Left and Right Backrest

Remove the retainer trim. Refer to

1. «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder) .
2. «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder) .

Remove headrest guide. Refer to HEADREST GUIDE .

Unclip the plugs -2-.

1 - Cover

3 - Inner bracket

Pry the upper retaining channel -1- out of the backrest shell -3-.

Remove the molding -2- from the sides and bottom of the backrest shell -3-.

Split Backrest Right 2/3 with Storage Compartment or Cover

Scheme 447

Pry the molding -2- out of the tabs -arrow- on the backrest shell -1-.

Continuation for Left and Right Backrest

Pry the cover over the inner bracket.

Pry the cover over the outer bracket.

Guide the release cable with the connector station through the slit in the cover.

Remove the cover with upholstery from the backrest shell.

Remove the upper and lower upholstery from the backrest shell.

Install in reverse order of removal. Note the following

Install headrest guide with button at left.

Make sure the button -2- moves easily after installing the trim.

COVER AND PADDING, BACKREST WITH PASS-THROUGH, SEPARATING

Special tools and workshop equipment required

1. Upholstery Clip Pliers V.A.G 1634

Remove cover with upholstery. Refer to BACKREST COVER AND PADDING WITH PASS-THROUGH .

Remove the cover -1- from the upholstery -3- as far as possible.

Unclip retaining channel -4- from clips -2-.

Remove cover from cushion.

Versions with Fabric Covers

Remove contour wire -3- that is inserted into pocket -4- in cover -5- from clips -2-.

Remove the cover from the cushion -1-.

Versions with Leather Covers

Cut through the upholstery clips -3- using pliers -4-.

Remove the cover -1- from cushion -2-.

Install in reverse order of removal. Note the following

When installing new upholstery clips with leather covers, use upholstery clip pliers V.A.G 1634.

HEADREST COVER

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 448

Remove the headrests. Refer to HEADREST .

Press the sides of the upholstery away from the trim -1- in the direction of the -arrow-.

Bend the leg spring -2- up slightly using a wide screwdriver.

Pull the trim -1- up at one side at the same time until it disengages on one side.

Perform the same step on the other side.

Remove the trim -1- while bending the leg spring -2- up.

Open the locking channel -1- and -2-.

Scheme 449

Remove the cover -3- from the support with the upholstery.

Scheme 450

Install cover -1-.

Position the cover -1- and slide it over the support with upholstery -2-.

Pull the left and right corners of the cover -arrow- over the support with upholstery -2-.

Pull the cover so it is smooth.

Engage the locking channel -1-.

Scheme 451

Bend the leg spring -2- up while sliding the trim -1- on.

Scheme 452

Hold the leg spring -2- open until the trim -1- slides over the notches into the locked position.

Press the trim -1- on firmly until it engages.

Align the cover -3- and pull it so it is smooth.

Make sure the cover lies on the upholstery without any wrinkles and without seam markings.

Further installation is performed in the reverse order of removal.

Remove the headrests. Refer to HEADREST .

Remove trim. Refer to TRIM .

Remove the leg spring -2- from the trim support -1-.

Install in reverse order of removal.

Remove the cover and upholstery from the bench seat. Refer to

1. «BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) .
2. «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment) .

Separate the cover from the upholstery. Refer to

1. «BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-without-center-storage-compartment) .
2. «BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__bench-seat-with-center-storage-compartment) .

Cut electrical wire -3- off directly at old seat heating element -2-.

Scheme 453

Note. The old seat heating element remains on the upholstery -1- and the new seat heating element is bonded over it. Ignore -arrows A through E- in this reference.

Align the new heating element on upholstery.

Begin bonding the center are of the seat heating element -arrow C-.

Then bond the front area -arrow A-.

Route the connecting wires from the front to the rear heating surface in the base of the gaps -arrow B-.

Bond the rear area of the heating surface -arrow D-.

Pull the wire -3- through the slit in the upholstery -arrow E-.

Further installation is performed in the reverse order of removal.

Remove the headrests. Refer to HEADREST .

Press the sides of the upholstery away from the trim -1- in the direction of the -arrow-.

Bend the leg spring -2- up slightly using a wide screwdriver.

Pull the trim -1- up at one side at the same time until it disengages on one side.

Perform the same step on the other side.

Remove the trim -1- while bending the leg spring -2- up.

Install in reverse order of removal.

SPECIAL TOOLS

Upholstery Clip Pliers V.A.G 1634

Scheme 454

Trim Removal Wedge 3409

Scheme 455

See also:
• SIDE AIRBAG IGNITERS -N199- / -N200
• ENTRY ASSISTANCE TRIM
• ENTRY ASSISTANCE TRIM
• HEADRESTS WITH LOCKING MECHANISM
• SEAT BELT GUIDE
• FRONT BACKREST
• SEAT PAN
• FRONT SEAT CHILD SEAT ANCHORS OVERVIEW
• SILL SIDE RETAINING BRACKET TRIM
• LOCK TRIM, WITHOUT LOCK CYLINDER
• LOCK TRIM, WITH LOCK CYLINDER
• COVER FRAME
• SUPER SPORT FRONT SEAT
• FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136
• [For engine(s) CAUA, CAEB, CALA] Removal and Installation
• MANUAL STANDARD FRONT SEAT
• POWER STANDARD FRONT SEAT
• STORAGE COMPARTMENT
• BACKREST
• CENTER ARMREST
• LOCKABLE ARMREST STORAGE COMPARTMENT
• BACKREST COVER AND PADDING, SUPER SPORT SEAT, SEPARATING AND CONNECTING
• BACKREST COVER AND UPHOLSTERY
• BACKREST COVER AND UPHOLSTERY, SEPARATING AND CONNECTING
• BACKREST HEATING ELEMENT, COMFORT SEAT
• HEADREST COVER AND UPHOLSTERY, WITH LOCKING MECHANISM
• LOWER SEAT FRAME WITH SEAT DEPTH ADJUSTER, COVER AND PADDING
• LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING
• BACKREST WITH COVER OR STORAGE COMPARTMENT, PADDING COVER
• COVER AND PADDING, BACKREST WITH PASS-THROUGH, SEPARATING
• BENCH SEAT WITH CENTER STORAGE COMPARTMENT, COVER AND PADDING
• BENCH SEAT WITHOUT CENTER STORAGE COMPARTMENT, COVER AND PADDING, SEPARATING
• HEADREST COVER
