Seat Frames (coupe) Audi A5 I

AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING

Special tools and workshop equipment required

1. Airbag adapter VAS 6281

DISCONNECTING

Bring seat into service position. Refer to FRONT SEATS SERVICE POSITION, SETTING .

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Release side airbag connector -1- and disconnect it.

Scheme 62

Connect Airbag Adapter VAS 6281 to side airbag connector on seat side -1-.

Scheme 63

Note. Ensure airbag adapter engages correctly.

CONNECTING

Airbag connectors are connected in the following sequence, note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

BACKREST RELEASE CABLE, ADJUSTING

The following prerequisites must be met to adjust

1. The backrest cover must be removed.
2. The upholstery must be removed from the backrest.

Note. The pins (release pins) -2- on both sides must be locked (delivery position, i.e. basic position).

Tilt the bracket -1- up so there is a distance -a- = 2 to 4 mm between the backrest frame stop surface -arrow A- and the bracket stop ridge -arrow B-.

Scheme 64

Hold the bracket -1- in this position.

Note. The illustration does not show the side cable adjuster.

Adjust the left and right release cables -1- and -2- at the cable adjusters -arrows-.

Scheme 65

To adjust, rotate the upper section -arrow A- and lower section -arrow B- against each other.

Adjust the cables so they are free of play and tension.

Note. The illustration only shows one side of the retainer. When adjusting cables -1-, they must not be tensioned at release pins -2-.

After adjusting release cables, check function of backrest lock.

If it does not release or only releases partially, check the release cable routing or repeat the adjustment.

CONNECTOR STATION CONNECTORS

Connector routing. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.

Scheme 66

1. Side Airbag
2. Seat Heater
3. Seat Adjustment Power Supply
4. Belt Latch

Note. The number of harness connectors may vary depending on the equipment. The description shows the version with the most equipment.

FRONT SEAT, INSTALLING ON THE FIXTURE FOR SEAT REPAIRVAS 6136

Special tools and workshop equipment required

1. Engine and transmission holder VAS 6095
2. Fixture for seat repair VAS 6136

Installing the Front Seat on the Fixture for Seat Repair VAS 6136

1. Front seat removed from the vehicle.

Mount the fixture for seat repair VAS 6136 on the engine and transmission holder VAS 6095.

Attach the front seat to the fixture for seat repair VAS 6136.

FRONT SEATS SERVICE POSITION, SETTING

Special tools and workshop equipment required

1. Trim removal wedge 3409

Service Position, Implementing

Bring headrest into lowest lock position.

Move seat as far back and up as possible.

Note. For the sake of clarity, the figure does not show the surrounding area.

Standard Seat (Manual)

Pry the caps -1- from off the seat rail -2- using the trim removal wedge 3409.

Standard Seat (Power)

Pry the caps -1- off the seat forward/back adjustment spindle using the trim removal wedge 3409.

Procedure for All Seat Versions

Scheme 67

Unclip rear cover -1- with the trim removal wedge 3409 and pull the cover in the direction of the -arrow- off of connector station -2-.

Note. Do not disconnect electrical wires.

Service Position, Resetting

Install in reverse order of removal. Note the following

Make sure the cover tab slides into connector station correctly.

Engage the cover correctly with the connector station.

HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

Note. The connector coupling station is located in the vehicle floor under the front seat area.

Bring seat into service position. Refer to FRONT SEATS SERVICE POSITION, SETTING .

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove wiring bracket -3- upward from the connector station.

Note. The number of harness connectors may vary depending on the equipment. The description shows the version with the most equipment.

Remove side airbag connector -1-.

Connect the airbag adapter VAS 6281 to the side airbag connector on the front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Vehicles with seat heating: Disconnect the connector for the seat heating -2-.

Vehicles with power seats: Disconnect the connector for the power supply for seat adjuster -4-.

Disconnect the seat belt latch connector -5-.

Vehicles Equipped with a DVD Player

Scheme 68

Push the grommet -3- to the side.

Disconnect and free up the electrical connectors -1- and -2- and free up the wiring harness.

Connectors are connected in the following sequence, note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Scheme 69

1. Sill Side Trim
2. Screws Quantity: 2 0.5 Nm
3. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch-overview) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch) Switch and operating knob cannot be separated

Scheme 70

1. Front Seat
2. Wiring Bracket Note location. Refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
3. Corrugated Pipe Lower shell Note location. Refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
4. Wiring Harness Observe notes for routing wiring harness in corrugated pipe. Refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
5. Corrugated Pipe Upper shell Note location. Refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)

MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT

Note. The wires between the seat pan and the connector station are inside a double-shell corrugated tube in the modulate wiring routing.

Special tools and workshop equipment required

1. Trim removal wedge 3409

Opening Corrugated Pipe and Removing Individual Wire

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual), refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat, refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136 FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Open the wiring bracket -1- using the trim removal wedge 3409.

Scheme 71

Remove the wiring bracket -1- from the corrugated tube -2-.

Free up the corrugated tube -2- on the seat frame and open it.

Note. Replacing a faulty wire or opening the corrugated tube for the side airbag, refer to [For engine(s) CAUA,CAEB,CALA] General Information or SIDE AIRBAG IGNITERS -N199- / -N200 .

Install Individual Wires And Close Corrugated Pipe

Install in reverse order of removal. Note the following

When bundling and placing individual wires in the corrugated tube, make sure the wires are not twisted.

Note. Note the installation position of the two-part corrugated tube to the wiring harness and the position of the wiring bracket to the corrugated tube.

The beginning of the corrugated tube -4- should be placed immediately after the clip -2- or cable tie.

Scheme 72

Wiring harness to the connector station -3

Make sure the two-part corrugated tube -4- locks cleanly over entire length.

After connecting both halves of the corrugated tube, position the wiring bracket -1- and clip it into place according to the illustration.

Make sure the side -arrow A- of the wiring bracket -1- connects to the last rib -arrow B- on the corrugated tube -4-.

Install the cable ties, wiring bracket and clips in the same positions as before removal.

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SEAT VERSIONS OVERVIEW

Note. The illustration shows manual standard front seats.

Scheme 73

1. Driver Seat Standard Seat (Manual) Assembly overview, refer to «MANUAL FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-front-seat-overview) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) Optional equipment: Seat and backrest heating Four-way lumbar support Storage compartment Power Standard Seat Assembly overview, refer to «POWER STANDARD FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat-overview) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) Optional equipment: Memory function Seat and backrest heating Storage compartment Comfort Seats (Power) Assembly overview, refer to «POWER STANDARD FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat-overview) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) Optional equipment: Memory function Manual Sport Seat with Seat Depth Adjuster Assembly overview, refer to «MANUAL FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-front-seat-overview) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) Optional equipment: Seat and backrest heating Four-way lumbar support Seat angle adjustment Power Sport Seat With Seat Depth Adjuster Assembly overview, refer to «MANUAL FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-front-seat-overview) Removing and installing, refer to «MANUAL SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-sport-front-seat) Optional equipment: Memory function Seat and backrest heating Super Sport Seats (Power) Assembly overview, refer to «SUPER SPORT FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat-overview) Removing and installing, refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) Optional equipment: Memory function Seat and backrest heating Bucket Seats Assembly overview, refer to «FRONT BUCKET SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-bucket-seat-overview) Removing and installing, refer to «FRONT BUCKET SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-bucket-seat)
2. Front Passenger Seat Standard Seat (Manual) Assembly overview, refer to «MANUAL FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-front-seat-overview) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) Optional equipment: Seat and backrest heating Four-way lumbar support Storage compartment LATCH child seat anchor Power Standard Seat Assembly overview, refer to «POWER STANDARD FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat-overview) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) Optional equipment: Memory function Seat and backrest heating Storage compartment LATCH child seat anchor Comfort Seats (Power) Assembly overview, refer to «POWER STANDARD FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat-overview) Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) Optional equipment: Memory function LATCH child seat anchor Manual Sport Seat With Seat Depth Adjuster Assembly overview, refer to «MANUAL FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-front-seat-overview) Removing and installing, refer to «MANUAL SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-sport-front-seat) Optional equipment: Seat and backrest heating Seat angle adjustment Four-way lumbar support LATCH child seat anchor Power Sport Seat With Seat Depth Adjuster Assembly overview, refer to «MANUAL FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-front-seat-overview) Removing and installing, refer to «MANUAL SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-sport-front-seat) Optional equipment: Memory function Seat and backrest heating LATCH child seat anchor Super Sport Seats (Power) Assembly overview, refer to «SUPER SPORT FRONT SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat-overview) Removing and installing, refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) Optional equipment: Memory function Seat and backrest heating LATCH child seat anchor Bucket Seats Assembly overview, refer to «FRONT BUCKET SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-bucket-seat-overview) Removing and installing, refer to «FRONT BUCKET SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-bucket-seat)
3. Right Side Airbag Not for bucket seat Assembly overview, refer to «FRONT SIDE AIRBAG OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Removing and installing, refer to «SIDE AIRBAG IGNITERS -N199- / -N200»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
4. 2/3 Right Backrest Assembly overview, refer to «DIVIDED BACKREST OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__divided-backrest-overview) Removing and installing, refer to «BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest) Optional equipment: with center armrest and without storage compartment (backrest cover and trim) with center armrest and storage compartment (lockable backrest cover) with center armrest and pass-through cover
5. Center Armrest With backrest cover and trim Vehicles with special equipment There is no pass-through in the right 2/3 backrest Assembly overview, refer to «CENTER ARMREST WITH COVER AND TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The center armrest as well as the backrest cover and trim can only be removed and installed separated. Center Armrest, removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-armrest) Trim, removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Backrest Trim, removing and installing, refer to «BACKREST TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Center Armrest With storage compartment (armrest with lockable cover) Vehicles with special equipment There is no pass-through in the right 2/3 backrest Assembly overview, refer to «CENTER ARMREST AND LOCKABLE STORAGE COMPARTMENT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The center armrest and storage compartment can only be removed and installed separately Center Armrest, removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-armrest) Storage compartment (armrest with lockable cover), removing and installing, refer to «LOCKABLE ARMREST STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lockable-armrest-storage-compartment)
7. Center Armrest With pass-through cover Vehicles with special equipment Assembly overview, refer to «CENTER ARMREST WITH PASS-THROUGH COVER OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «CENTER ARMREST WITH PASS-THROUGH COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Left 1/3 Backrest Assembly overview, refer to «DIVIDED BACKREST OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__divided-backrest-overview) Removing and installing, refer to «BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest)
9. One-Part Bench Seat Assembly overview, refer to «ONE PIECE BENCH SEAT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «BENCH SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. Bench Seat With center storage compartment Assembly overview, refer to «ONE PIECE BENCH SEAT, WITH CENTER STORAGE COMPARTMENT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__one-piece-bench-seat-with-center) Removing and installing, refer to «BENCH SEAT WITH CENTER STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__bench-seat-with-center-storage-compartment)
11. Left Side Airbag Not for bucket seat Assembly overview, refer to «FRONT SIDE AIRBAG OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Removing and installing, refer to «SIDE AIRBAG IGNITERS -N199- / -N200»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)

Scheme 74

1. Seat Pan
2. Torsion Bar Lubricated; for grease. Removing and installing, refer to «TORSION BAR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__torsion-bar)
3. Mount For the torsion bar Slide into the guide Removing and installing, refer to «TORSION BAR BEARING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__torsion-bar-bearing)

Scheme 75

1. Right Backrest Cover Removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-cover)
2. Left Backrest Cover Removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-cover)
3. Retaining Clip
4. Bolt For the correct tightening specifications, refer to «BACKREST RELEASE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Belt Guide Removing and installing, refer to «SEAT BELT GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-belt-guide)
6. Cover For release lever
7. Backrest Frame

Scheme 76

1. Backrest Release Cable Removing and installing, refer to «BACKREST RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Adjuster Left for release cable
3. Bolt 2.5 Nm Insert with locking compound. For locking compound.
4. Cover For left release lever
5. Edge Protection
6. Bolt 2.5 Nm Insert with locking compound. For locking compound.
7. Cover For right release lever
8. Edge Protection
9. Right Release Lever For the backrest Removing and Installing, refer to «BACKREST RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. Plastic Disc For release lever
11. Mount For right release lever
12. Mount For left release lever
13. Backrest Frame
14. Backrest Frame Mount
15. Bolt 22 Nm Insert with locking compound. For locking compound.
16. Pop Rivet 6 mm (steel)
17. Plastic Washer For release lever
18. Left Release Lever For the backrest Removing and installing, refer to «BACKREST RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
19. Adjuster Right for release cable

Procedure

Scheme 77

1. Backrest cover removed.

When operating one of the two release levers, the release pins on the left and right of the seat frame must be operated at the same time.

Operate the release lever

1. Left and right release pins must be operated at the same time.

Release the release lever

1. The release cables must engage the release pins on the backrest hinge to the stop.
2. The release cables must then be relieved.

If necessary, rotate -arrows- adjusters -1- and -2- on the release cables accordingly.

The connector station connectors are described fro the manual standard front seat. They are similar for the bucket front seat. Refer to CONNECTOR STATION CONNECTORS .

FRONT BUCKET SEAT OVERVIEW

The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right.

Scheme 78

1. Bucket Seats Removing and installing, refer to «FRONT BUCKET SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-bucket-seat)
2. Seat Rail Covers Right front and left rear are identical Left front and right rear are identical Removing and installing, refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Screws 50 Nm
4. Screws 50 Nm

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the bucket front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Scheme 79

1. Screws 24 Nm Insert with locking compound. For locking compound.
2. Bolt 4 Nm
3. Handle For seat forward/back adjustment Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-forwardback-adjuster-release-cable)
4. Bolt 24 Nm Insert with locking compound. For locking compound.
5. Seat Pan Removing and Installing, refer to «SEAT PAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-pan)
6. Bolt 20 Nm Insert with locking compound. For locking compound.
7. Front Backrest Removing and installing, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-backrest)
8. Bolt 20 Nm Insert with locking compound. For locking compound.
9. Pneumatic Hose From the module carrier with air cushions for lumbar support
10. Electrical Wiring Harness
11. Bolt 24 Nm Insert with locking compound. For locking compound.
12. Seat Frame

MODULAR WIRE ROUTING OVERVIEW

The assembly overview shows a manual Standard front seat. The modular wiring for the bucket front seat is similar. Refer to MODULAR WIRE ROUTING OVERVIEW .

The modular wiring is described for a manual standard front seat. It is similar for the bucket front seat. Refer to

Scheme 80

1. Connector For driver's lumbar support pump -V152- For front passenger's lumbar support pump -V153
2. Connector For driver's lumbar support pressure switch -F224- For front passenger's lumbar support pressure switch -F225
3. Hard Foam Block For pneumatic components Removing and installing, refer to «MODULE CARRIER WITH AIR CUSHIONS FOR LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Module Carrier With Air Cushions For Lumbar Support Secured to hard foam block -3- using plastic plug To remove, remove backrest cushion. Refer to «BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Pry off plastic plug using pry lever - rmv outside mirror 80-200
5. Lumbar Support Adjustment Switch Driver lumbar support adjustment pressure switch -F224- Front passenger lumbar support adjustment pressure switch -F225- To remove, remove backrest cushion. Refer to «BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
6. Y-Connector For pneumatic hoses to valve blocks
7. Lumbar Support Valve Block Driver lumbar support adjustment valve block -N209- Front passenger lumbar support adjustment valve block -N210- To remove, remove backrest cushion. Refer to «BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
8. Backrest Inflation Adjustment Valve Block Driver seat/backrest inflation adjustment valve block -V378- Front passenger seat/backrest inflation adjustment valve block -V379- To remove, remove backrest cushion. Refer to «BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe)
9. Lumbar Support Pump Driver lumbar support adjustment pump -V152- Front passenger lumbar support adjustment pump -V153- To remove, remove backrest cushion. Refer to «BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe) Secured using rubber strap -11- and plastic plugs -10
10. Plastic Plug Pry off using pry lever - rmv outside mirror 80-200
11. Rubber Strap

Scheme 81

1. Bolt 22 Nm Insert with locking compound. For locking compound.
2. Retaining Clip Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-height-adjustment-handle)
3. Lever For seat height adjustment Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-height-adjuster)
4. Seat Frame
5. Bolt 8 Nm
6. Bolt 8 Nm
7. Bolt 8 Nm
8. Retaining Plate Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
9. Seat Height Adjuster Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. Bolt 8 Nm

Scheme 82

1. Bolt 1.2 Nm
2. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-sill-side)
3. Bolt 0.4 Nm
4. Button For Seat Bolster Inflation Adjustment Driver side: driver seat bolster inflation adjustment button -E587- Front passenger side: front passenger seat bolster inflation adjustment button -E588- Removing and installing, refer to «SEAT BOLSTER AND BACKREST BOLSTER ADJUSTMENT BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Bolt 0.4 Nm
6. Button For Backrest Bolster Inflation Adjustment Driver side: driver backrest bolster inflation adjustment button -E589- Front passenger side: front passenger backrest bolster inflation adjustment button -E590- Removing and installing, refer to «SEAT BOLSTER AND BACKREST BOLSTER ADJUSTMENT BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Bolt 0.4 Nm
8. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Removing and installing, refer to «SEAT BOLSTER AND BACKREST BOLSTER ADJUSTMENT BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
9. Tunnel Side Trim Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. Expanding Clip
11. Cover
12. Backrest Adjusting Wheel Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
13. Seat Height Adjustment Handle Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-height-adjustment-handle)
14. Bolt For the correct tightening specifications, refer to «SEAT HEIGHT ADJUSTER OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
15. Outer Trim Removing and Installing, refer to «OUTER TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
16. Expanding Clip

Scheme 83

Tighten the bolts -arrow- to 1.5 Nm.

BACKREST COVER AND BACKREST FRAME TRIM OVERVIEW

Note. The assembly overview shows a standard front seat. The backrest cover and backrest frame trim for the other seat versions are similar.

Scheme 84

1. Front Seat
2. Backrest Frame Trim Removing and installing, refer to «BACKREST FRAME TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-frame-trim)
3. Backrest Cover Removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Backrest Frame

Scheme 85

1. Backrest, Front Seat
2. Upper Hooks (quantity: 2)
3. Left Side Retaining Tabs (quantity: 3)
4. Lower Hooks (quantity: 2)
5. Right Side Retaining Tabs (quantity: 3)

Scheme 86

1. Lumbar Support Height Adjustment Motor Driver side: driver seat lumbar support height adjustment motor -V129- Front passenger side: front passenger seat lumbar support height adjustment motor -V130- Assembly overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-curvature-and-height-adjustment) Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Lumbar Support Curvature Adjustment Motor Driver side: driver seat lumbar support curvature adjustment motor -V125- Front passenger side: front passenger seat lumbar support curvature adjustment motor -V126- Assembly overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-curvature-and-height-adjustment) Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch-overview) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch)
4. Seat Position Sensor Diver side: driver seat position sensor -G553- Front passenger side: front passenger seat position sensor -G554- Assembly overview, refer to «SEAT POSITION SENSOR OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Versions with seat occupied sensor for belt fastening detection, removing and installing «SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__seat-position-sensor-with-seat-occupied) Versions with seat occupied sensor for passenger airbag deactivation, removing and installing «SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__seat-position-sensor-with-seat-occupied)

ENTRY ASSISTANCE OVERVIEW

Backrest Release Assembly Overview

Note. The illustration does not show the spring mat, the four-way lumbar support and the seat frame.

Scheme 87

1. Backrest Frame
2. Bolts For the backrest release Both sides Component of the backrest hinge
3. Release Cable For the backrest release One piece Removing and installing, refer to «BACKREST RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-cable) Adjusting, refer to «BACKREST RELEASE CABLE, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-cable-adjusting)
4. Bracket For the backrest release cable Quantity: 2 Component of the release cable Riveted to backrest frame
5. Mount For the backrest release cable Component of the release cable Clipped to the backrest frame
6. Connecting Cable For the backrest release Between the handle and bracket Engaged in the handle and bracket Removing and installing, refer to «CONNECTING CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connecting-cable)
7. Handle With backrest release bracket Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
8. Screws Quantity: 2 3.5 Nm
9. Entry Assistance Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-trim)
10. Bolt 3.5 Nm
11. Bracket For the backrest release Riveted to backrest frame Removing and installing, refer to «BACKREST RELEASE BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-bracket)
12. Support Plate Riveted to backrest frame Different versions for different equipment Standard seat Comfort seat Sport seat Super sport seat For the correct allocation. Removing and installing, refer to «SUPPORT PLATE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__support-plate)
13. Rivet Quantity: 2

Entry Assistance Assembly Overview

Note. The illustration does not show the spring mat, the four-way lumbar support and the seat frame upholstery.

Scheme 88

1. Seat Frame
2. Entry Assistance Release Cable A From the backrest hinge to the seat rail release Removing and installing, refer to «ENTRY ASSISTANCE RELEASE CABLE A»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-release-cable-a) Adjusting, refer to «ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Backrest Hinge Engaging Tag To engage the entry assistance release cable A. See item 2 (Scheme 91).
4. Release Bracket For securing the release cable on the backrest frame Clipped to the backrest frame Component of the release cable
5. Entry Assistance Release Cable B From the backrest hinge to the seat rail release Removing and installing, refer to «ENTRY ASSISTANCE RELEASE CABLE B»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-release-cable-b) Adjusting, refer to «ENTRY ASSISTANCE RELEASE CABLE B, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Memory Stop Removing and installing, refer to «MEMORY STOP»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__memory-stop)
7. Seat Rail Release Pins To engage the entry assistance release cable B. See item 5 (Scheme 91).
8. Seat Rail Release With a control cable bracket for the entry assistance release cable A. See item 2 in (Scheme 91).
9. Release Cable Hook For engaging the entry assistance release cable A in the seat rail release
10. Backrest Hinge Pin To engage the entry assistance release cable B. See item 5 in (Scheme 91).
11. Entry Assistance Release Cable B Eyelet To engage the entry assistance release cable B in the backrest hinge pin. See item 10 in (Scheme 91).
12. Clips Only secure after checking and adjusting the entry assistance release cable A «ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 89

1. Seat Pan
2. Screws Self-Locking Always replace if removed Threaded holes for screws must be cleaned, for example, with thread cutter 33 Nm
3. Backrest Removing and installing, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Headrest Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism)
5. Handle With bracket (entry assistance) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
6. Entry Assistance Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-trim)
7. Wiring Harness Running from the side airbag to the connector station. Depending on optional equipment, there may be more wiring harnesses, such as for backrest heating, lumbar support
8. Cables With entry assist Quantity: 2 Entry assistance release cable A, removing and installing «ENTRY ASSISTANCE RELEASE CABLE A»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-release-cable-a) Entry assistance release Cable A, adjusting «ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Entry assistance release Cable B, removing and installing «ENTRY ASSISTANCE RELEASE CABLE B»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-release-cable-b) Entry assistance release cable B, adjusting «ENTRY ASSISTANCE RELEASE CABLE B, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 90

Tighten the retaining plate screws -2- to 6 Nm.

Scheme 91

Tighten nut -2- to 0.4 Nm.

Scheme 92

1. Backrest Frame
2. Rivet
3. Plastic Washer Insert in front of the four-way lumber support riveted connection between the lumbar support bracket and the backrest frame
4. Lumbar Support Curvature Adjustment Motor Driver side: driver seat lumbar support curvature adjustment motor -V125- Front passenger side: front passenger seat lumbar support curvature adjustment motor -V126- Assembly overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-curvature-and-height-adjustment) Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Four-Way Lumbar Support Removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__four-way-lumbar-support)
6. Lumbar Support Height Adjustment Motor Driver side: driver seat lumbar support height adjustment motor -V129- Front passenger side: front passenger seat lumbar support height adjustment motor -V130- Assembly overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-curvature-and-height-adjustment) Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. System Engaged in the four-way lumbar support The upholstery is secured tot he system by Velcro™ fasteners

HEADRESTS OVERVIEW

Note. The assembly overview is based on a standard front seat. The headrest on the manual front sport seat is similar. The illustration does not show the backrest cover and upholstery.

Scheme 93

1. Front Backrest
2. Headrest Guide Without release button Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrest-guide) Always installed on right side of backrest
3. Headrest Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) For the correct allocation.
4. Headrest Guide With release button Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrest-guide) Always installed on left side of backrest

LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS OVERVIEW

The assembly overview shows the power Standard front seat. The forward/backward and height adjustment motors for the lumbar curvature support for the front standard seat are similar. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS .

MANUAL FRONT SEAT OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering.

Scheme 94

1. Connector Station Connector routing, refer to «CONNECTOR STATION CONNECTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connector-station-connectors)
2. Cover For connector station Removing and installing, refer to «FRONT SEATS SERVICE POSITION, SETTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-seats-service-position-setting)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview, refer to «MODULAR WIRE ROUTING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-overview) Modular wiring with corrugated tube on front seat, refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
4. Storage Compartment Vehicles with special equipment Removing and installing, refer to «STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Seat Forward/Back Adjuster Seat forward/back adjustment handle, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-forwardback-adjustment-handle) Seat forward/back adjuster release cable, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. LATCH Child Seat Anchor Vehicles with special equipment For the front passenger seat only Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Check after accident «CHILD SEAT ANCHORS LATCH AND TOP TETHER, CHECKING AFTER A CRASH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__child-seat-anchors-latch-and-top)
8. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
9. Tunnel Side Trim Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
10. Standard Front Seat (Manual) Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) Optional equipment: Seat and backrest heating
11. Headrest Manual Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism)
12. Entry Assistance Backrest Release Assembly overview, refer to «ENTRY ASSISTANCE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-overview) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
13. Backrest Adjusting Wheel Removing and installing, refer to «BACKREST ADJUSTING WHEEL»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
14. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cap)
15. Screws Quantity: 4 50 Nm
16. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover)
17. Seat Height Adjuster Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
18. Actuator For the lumbar support Lumbar support adjustment switch, removing and installing «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
19. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 95

1. Handle For seat inclination adjustment Removing and installing, refer to «SEAT ANGLE ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-angle-adjustment-handle)
2. Retaining Clip Replace the seat angle adjustment handle each time it is removed Installation position «SEAT ANGLE ADJUSTMENT HANDLE =>»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-angle-adjustment-handle)
3. Bolt Self-Locking Replace Threaded holes for screws must always be cleaned, for example, with thread cutter 6.5 Nm
4. Shoulder Pin Self-Locking Replace Threaded holes for screws must always be cleaned, for example, with thread cutter 6 Nm
5. Seat Angle Adjustment Removing and installing, refer to «SEAT ANGLE ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

SEAT FORWARD/BACK ADJUSTER OVERVIEW

Note. There is no separation between the seat pan lower frame with a seat forward/back adjuster and the seat pan upper frame on the standard front seat (manual).

Scheme 96

1. Front Seat
2. Seat Forward/Back Adjuster Part of seat pan lower frame Not replaced separately
3. Seat Forward/Back Adjuster Release Cable Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) It is not possible to adjust the release cable
4. Clip Or Cable Tie
5. Handle For seat forward/back adjustment Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-forwardback-adjustment-handle)
6. Retaining Clip Replace the seat forward/back adjustment handle each time it is removed Note location «SEAT FORWARD/BACK ADJUSTMENT HANDLE =>»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-forwardback-adjustment-handle)
7. Actuator For seat forward/back adjustment
8. Spring For lever for seat forward/back adjuster release cable retainer Different components for driver and front passenger side Removing and installing, refer to «RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-mount-lever-and-seat)
9. Lever For seat forward/back adjuster release cable retainer Same part for driver and front passenger seat Removing and installing, refer to «RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-mount-lever-and-seat)

Scheme 97

1. Seat Height Adjustment Handle Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) With a tab -A- for engaging with the tab -B- on the lever -item 7-.
2. Screws Quantity: 2 Note the different bolt length -item 4- 6.5 Nm
3. Seat Height Adjuster Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Bolt Note the different bolt lengths -item 2- 10 Nm
5. Locking Washer Always replace if removed
6. Screws Quantity: 2 8 Nm
7. Lever For seat height adjustment handle With the tab -B- for locking the seat height adjustment handle -item 1

SEAT POSITION SENSOR OVERVIEW

The assembly overview is based on a power standard front seat. The seat position sensor for the manual standard front seat is similar. Refer to SEAT POSITION SENSOR OVERVIEW

Scheme 98

1. Front Seat Manual
2. Retaining Bracket For sill side trim Removing and installing, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__sill-side-retaining-bracket-trim)
3. Screws Quantity: 3 3.5 Nm

Scheme 99

1. Front Seat
2. Expanding Rivet
3. Tunnel Side Trim Can only be replaced with seat removed Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
4. Expanding Rivet Quantity: 2
5. Backrest Adjusting Wheel Removing and installing, refer to «BACKREST ADJUSTING WHEEL»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Seat Height Adjustment Handle Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Lumbar Support Adjustment Switch Vehicles with special equipment Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch-overview) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch)
8. Sill Side Trim Can be replaced with seat installed Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 100

1. Bottom Spring Not available separately
2. Center Pull-Spring Not available separately
3. Upper Pull-Spring Not available separately
4. Spring Mat Removing and installing, refer to «SPRING MAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__spring-mat) Can be removed and installed with and without the pull-springs
5. Backrest Frame

STORAGE COMPARTMENT OVERVIEW

The assembly overview is based on a power standard front seat. The storage compartment on the manual standard front seat is similar. Refer to STORAGE COMPARTMENT OVERVIEW

AIRBAG ADAPTER, CONNECTING

Connecting the airbag adapter on the manual standard front seat is described here. The procedure is similar for the manual sport front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING

The assembly overview shows a manual Standard front seat. The backrest cover and backrest frame trim of the manual sport front seat are similar. Refer to BACKREST COVER AND BACKREST FRAME TRIM OVERVIEW

The adjusting procedure is described for the manual standard front seat. The procedure is similar on the manual sport front seat. Refer to BACKREST RELEASE CABLE, ADJUSTING

The connector station connectors are described fro the manual standard front seat. They are similar for the manual sport front seat. Refer to CONNECTOR STATION CONNECTORS

ELECTRICAL AND ELECTRONIC COMPONENTS OVERVIEW

The assembly overview shows a manual Standard front seat. The electrical and electronic components of the manual sport front seat are similar. Refer to ELECTRICAL AND ELECTRONIC COMPONENTS OVERVIEW

The assembly overview shows a manual Standard front seat. The entry assistance is similar for the manual sport front seat. Refer to ENTRY ASSISTANCE OVERVIEW

ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING

The adjusting procedure is described for the manual standard front seat. The procedure is similar on the manual sport front seat. Refer to ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING

ENTRY ASSISTANCE RELEASE CABLE B, ADJUSTING

The adjusting procedure is described for the manual standard front seat. The procedure is similar on the manual sport front seat. Refer to ENTRY ASSISTANCE RELEASE CABLE B, ADJUSTING

FOUR-WAY LUMBAR SUPPORT OVERVIEW

The assembly overview shows a manual Standard front seat. The four-way lumbar support of the manual sport front seat is similar. Refer to FOUR-WAY LUMBAR SUPPORT OVERVIEW

FRONT BACKREST OVERVIEW

The assembly overview shows a manual Standard front seat. The front backrest is similar for the manual sport front seat. Refer to FRONT BACKREST OVERVIEW

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the manual sport front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

The assembly overview shows a manual Standard front seat. The headrests are similar for the manual Sport front seat. Refer to HEADRESTS OVERVIEW

LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW

The assembly overview shows a manual Standard front seat. The lumbar support adjustment switches of the manual sport front seat are similar. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW

The assembly overview shows the power Standard front seat. The lumbar support curvature and backward-and-forward and height adjustment motors for the manual sport front seat (manually adjustable) are similar. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS

The assembly overview shows a manual Standard front seat. The modular wiring for the manual sport front seat is similar. Refer to MODULAR WIRE ROUTING OVERVIEW

The modular wiring is described on the basis of a manual standard front seat. It is similar for the manual sport front seat. Refer to MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT

SEAT ANGLE ADJUSTER OVERVIEW

The overview shows a manual standard front seat. The seat angle adjuster is similar on the Manual Sport front seat. Refer to SEAT ANGLE ADJUSTER OVERVIEW

Scheme 101

1. Nut Quantity: 4 Replace
2. Sport Seat With a seat depth adjuster
3. Trim For seat depth adjustment Removing and installing, refer to «SEAT DEPTH ADJUSTER TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-depth-adjuster-trim) Press on until it engages audibly
4. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-depth-adjuster)
5. Bushing
6. Bolt Replace Use locking fluid when installing the bolt. 4 Nm
7. Screws Replace Use locking fluid when installing the bolt. 4 Nm
8. Bolt Replace Use locking fluid when installing the bolt. 4 Nm
9. Bushing

The assembly overview shows a manual Standard front seat. The seat forward/back adjuster is similar for the manual sport front seat. Refer to SEAT FORWARD/BACK ADJUSTER OVERVIEW

SEAT HEIGHT ADJUSTER AND SEAT HEIGHT ADJUSTMENT HANDLE OVERVIEW

The assembly overview shows a manual Standard front seat. The seat height adjustment unit and handle of the manual sport front seat are similar. Refer to SEAT HEIGHT ADJUSTER AND SEAT HEIGHT ADJUSTMENT HANDLE OVERVIEW

The assembly overview shows the power Standard front seat. The seat position sensor the for the manual front sport seat is similar. Refer to SEAT POSITION SENSOR OVERVIEW

SILL SIDE TRIM RETAINING BRACKET OVERVIEW

The assembly overview shows a manual Standard front seat. The trim retaining bracket on the sill side of the manual sport front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET OVERVIEW

SILL AND TUNNEL SIDE TRIM OVERVIEW

The assembly overview shows a manual Standard front seat. The trims on the sill and tunnel side of the manual sport front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM OVERVIEW

SPORT FRONT SEAT OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering.

Scheme 102

1. Connector Station Connector routing «CONNECTOR STATION CONNECTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connector-station-connectors)
2. Cover For connector station Removing and installing, refer to «FRONT SEATS SERVICE POSITION, SETTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-seats-service-position-setting)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-overview) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
4. Seat Angle Adjustment Removing and installing, refer to «SEAT ANGLE ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Storage Compartment Vehicles with special equipment Removing and installing, refer to «STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Seat Forward/Back Adjuster Seat forward/back adjustment handle, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-forwardback-adjustment-handle) Seat forward/back adjuster release cable, removing and installing, refer to «SEAT FORWARD/BACK ADJUSTER RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Seat Depth Adjuster Removing and Installing, refer to «SEAT DEPTH ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-depth-adjuster)
9. LATCH Child Seat Anchor Vehicles with special equipment For the front passenger seat only Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Check after accident «CHILD SEAT ANCHORS LATCH AND TOP TETHER, CHECKING AFTER A CRASH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__child-seat-anchors-latch-and-top)
10. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
11. Tunnel Side Trim Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
12. Manual Sport Front Seat There is no separation between the upper and lower seat pan frame on the manual sport front seat Removing and installing, refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) Optional equipment: Seat and backrest heating
13. Headrest Manual Removing and installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism)
14. Entry Assistance Assembly overview, refer to «ENTRY ASSISTANCE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-overview) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
15. Backrest Adjusting Wheel Removing and installing, refer to «BACKREST ADJUSTING WHEEL»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
16. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
17. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cap)
18. Bolt Quantity: 4 50 Nm
19. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover)
20. Seat Height Adjustment And Seat Height Adjustment Handle Removing and installing, refer to «SEAT HEIGHT ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
21. Actuator For the lumbar support Lumbar support adjustment switch, removing and installing «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

SPRING MAT OVERVIEW

The assembly overview shows a manual Standard front seat. The spring mat is similar for the manual sport front seat. Refer to SPRING MAT OVERVIEW

The assembly overview shows the power Standard front seat. The storage compartment is similar for the manual sport front seat. Refer to STORAGE COMPARTMENT OVERVIEW

TORSION BAR OVERVIEW

The assembly overview shows a manual standard front seat. The torsion bar is similar for the manual sport front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW

The following describes connecting the airbag adapter for the manual standard front seat. The procedure is similar for the power comfort front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING

BACKREST ADJUSTMENT MOTOR, SWITCH UNIT AND BACKREST OVERVIEW

The assembly overview shows the power Standard front seat. The comfort front seat is similar. Refer to BACKREST ADJUSTMENT MOTOR, SWITCH UNIT AND BACKREST OVERVIEW

The adjustment on the manual standard front seat is described. It is similar for the comfort front seat. Refer to BACKREST RELEASE CABLE, ADJUSTING

COMFORT FRONT SEAT OVERVIEW

The assembly overview shows the power Standard front seat. The comfort front seat is similar. Refer to POWER STANDARD FRONT SEAT OVERVIEW

The assembly overview relates to the power standard front seat. The electrical and electronic components of the comfort front seat are similar. Refer to ELECTRICAL AND ELECTRONIC COMPONENTS OVERVIEW

The assembly overview relates to the power standard front seat. The front backrest is similar for the comfort front seat. Refer to ENTRY ASSISTANCE OVERVIEW

ENTRY ASSISTANCE BUTTON OVERVIEW

The assembly overview shows the power Standard front seat. The entry assistance button is similar on the comfort front seat. Refer to ENTRY ASSISTANCE BUTTON OVERVIEW

Scheme 103

1. Plastic Washer Insert in front of the four-way lumber support riveted connection between the lumbar support bracket and the backrest frame
2. Four-Way Lumbar Support Driver side: driver seat lumbar support curvature adjustment motor -V125- Front passenger side: front passenger seat lumbar support curvature adjustment motor -V126- Driver side: driver seat lumbar support height adjustment motor -V129- Front passenger side: front passenger seat lumbar support height adjustment motor -V130- Removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Backrest Frame
4. Rivet

The assembly overview relates to the power standard front seat. The front backrest is similar for the comfort front seat. Refer to FRONT BACKREST OVERVIEW

FUNCTION TEST, PERFORMING

The function test is performed the same way on all seat versions. Refer to FUNCTION TEST, PERFORMING

The following describes disconnecting and connecting the connectors for the manual standard front seat. The procedure is similar for the comfort front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING

The assembly overview shows a manual Standard front seat. The lumbar support adjustment switches of the comfort front seat are similar. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW

MEMORY SEAT ADJUSTMENT CONTROL MODULE WITH INTEGRATED SEAT VENTILATION FUNCTION OVERVIEW

The assembly overview is based on a power standard front seat with a memory seat adjustment control module. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE OVERVIEW

The assembly overview relates to the manual standard front seat. It is similar for the comfort front seat. Refer to MODULAR WIRE ROUTING OVERVIEW

POWER HEADRESTS OVERVIEW

The assembly overview relates to the power standard front seat. The electrically adjustable headrest is similar for the comfort front seat. Refer to POWER HEADRESTS OVERVIEW

SEAT ADJUSTMENT CONTROL HEAD OVERVIEW

The assembly overview shows the power Standard front seat. The driver or front passenger seat adjustment control head is similar on the comfort front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD OVERVIEW

SEAT ANGLE ADJUSTMENT MOTOR OVERVIEW

The assembly overview shows the power Standard front seat. The seat angle adjustment motor is similar on the comfort front seat. Refer to SEAT ANGLE ADJUSTMENT MOTOR OVERVIEW

SEAT BACKREST AND HEADREST ADJUSTMENT CONTROL HEAD OVERVIEW

The assembly overview relates to the power standard front seat. The seat and backrest adjustment control of the comfort front seat is similar. Refer to SEAT BACKREST AND HEADREST ADJUSTMENT CONTROL HEAD OVERVIEW

Scheme 104

1. Seat Cushion Fan Driver side: driver seat cushion blower fan -V390- Front passenger side: front passenger seat cushion blower fan -V391- Removing and installing, refer to «SEAT CUSHION FAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Seat Cushion Fan 2 Driver side: driver seat cushion blower fan 2 -V419- Front passenger side: front passenger seat cushion blower fan 2 -V420- Removing and installing, refer to «SEAT CUSHION FAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Backrest Fan 2 Driver side: driver seat backrest blower fan 2 -V417- Front passenger side: front passenger seat backrest blower fan 2 -V418- Removing and Installing, refer to «UPPER BACKREST FAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Backrest Fan Driver side: driver seat backrest blower fan -V388- Front passenger side: front passenger seat backrest blower fan -V389- Removing and installing, refer to «UPPER BACKREST FAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 105

1. Bolt - 1.5 Nm
2. Cover Grille
3. Seal
4. Seat Cushion Fan

SEAT PAN OVERVIEW

The assembly overview relates to the power standard front seat. The seat pan is similar for the comfort front seat. Refer to SEAT PAN OVERVIEW

SEAT FORWARD/BACK ADJUSTMENT MOTOR OVERVIEW

The assembly overview relates to the power standard front seat. The seat forward/back adjustment motor of the comfort front seat is similar. Refer to SEAT FORWARD/BACK ADJUSTMENT MOTOR OVERVIEW

SEAT HEIGHT ADJUSTMENT MOTOR OVERVIEW

The assembly overview shows the power Standard front seat. The seat height adjustment motor is similar on the comfort front seat. Refer to SEAT HEIGHT ADJUSTMENT MOTOR OVERVIEW

The assembly overview shows the power Standard front seat. The seat position sensor for the front comfort seat is similar. Refer to SEAT POSITION SENSOR OVERVIEW

The assembly overview relates to the power standard front seat. The trim retaining bracket on the sill side of the comfort front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET OVERVIEW

The assembly overview relates to the power standard front seat. The trims on the sill and tunnel side of the comfort front seat are similar. refer to SILL AND TUNNEL SIDE TRIM OVERVIEW

The assembly overview relates to the power standard front seat. The storage compartment is similar for the comfort front seat. Refer to STORAGE COMPARTMENT OVERVIEW

SWITCH UNIT MICRO-SWITCH, CALIBRATING

The switch unit micro-switches are calibrated the same way on all seat versions. Refer to SWITCH UNIT, CALIBRATING

SWITCH UNIT OVERVIEW

The assembly overview shows the power Standard front seat. The comfort front seat is similar. Refer to SWITCH UNIT OVERVIEW .

SWITCH UNIT MICRO-SWITCH, ADJUSTING

The switch unit micro-switches are adjusted the same way on all seat versions. Refer to SWITCH UNIT MICRO-SWITCH, ADJUSTING .

SWITCH UNIT MICRO-SWITCH, CHECKING

The switch unit micro-switches are checked the same way on all seat versions. Refer to SWITCH UNIT MICRO-SWITCH, CHECKING .

The assembly overview relates to the manual standard front seat. The torsion bar is similar for the comfort front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW .

The following describes connecting the airbag adapter for the manual standard front seat. The procedure is similar for the power standard front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Backrest adjustment motor

Note. The backrest is shown without the upholstery, cover and seat pan.

Scheme 106

1. Backrest Frame
2. Nut Replace 6 Nm
3. Washer
4. Shaft The threads must be cleaned before installing the nut -2- (for example, using a thread tap). Apply locking compound fluid to the threaded section of the shaft before installing the nut.
5. Bolt Replace Use locking compound fluid when installing the bolt. 7.5 Nm
6. Backrest Adjustment Motor Driver side: driver backrest adjustment motor -V45- Front passenger side: front passenger backrest adjustment motor -V46- Removing and installing, refer to «BACKREST ADJUSTMENT MOTOR AND SWITCH UNIT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Switch Unit (Micro-Switch with Bracket)

Note. The 6-pin connector with backrest lock switch and backrest forward stop switch are not separate from the bracket. They are delivered as a micro switch with bracket switch unit -7-. See item 7 in (Scheme 109). The locking bushing -6- (See item 6 in (Scheme 109) ) and the screws for securing the switch unit -2- (See item 2 in (Scheme 109) ) are delivered as a replacement part. The backrest is shown without the upholstery, cover and seat pan.

Scheme 107

1. Backrest Frame
2. Bolt Quantity: 2 1.5 Nm
3. Washer
4. Nut For the correct tightening specifications, refer to -2-. See item 2 in (Scheme 109). Replacing
5. Shaft The threads must always be cleaned before installing the nut -4- (for example, using a thread tap). See item 4 in (Scheme 109). Coat the threads on the shaft with locking fluid before installing the nut.
6. Locking Bushing Clipped to the spindle Clip to the spindle after adjusting the switch unit
7. Switch Unit (Micro-Switch with Bracket) Removing and installing, refer to «BACKREST ADJUSTMENT MOTOR AND SWITCH UNIT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Adjusting, refer to «SWITCH UNIT MICRO-SWITCH, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Checking «SWITCH UNIT MICRO-SWITCH, CHECKING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST RELEASE CABLE, ADJUSTING

The following describes the connector station connectors for the manual standard front seat. They are similar for the power standard front seat. Refer to CONNECTOR STATION CONNECTORS

Scheme 108

1. Memory Seat/Steering Column Adjustment Control Head Driver side: memory seat/steering column adjustment control module -J136- Front passenger side: front passenger memory seat control module -J521- Vehicles with seat heating or a comfort seat on the driver side: left front seat ventilation control module -J800- (integrated seat heater function) Vehicles with seat heating or a comfort seat on the driver side: right front seat ventilation control module -J799- (integrated seat heater function) Assembly overview, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__memory-seatsteering-column-adjustment-control-module)
2. Seat Forward/Back Adjustment Motor Driver side: driver seat forward/back adjustment motor -V28- Front passenger side: front passenger seat forward/back adjustment motor -V31- Assembly overview, refer to «SEAT FORWARD/BACK ADJUSTMENT MOTOR OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and Installing, refer to «SEAT FORWARD/BACK ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Backrest Adjustment Motor Driver side: driver backrest adjustment motor -V45- Front passenger side: front passenger backrest adjustment motor -V46- Assembly overview, refer to «BACKREST ADJUSTMENT MOTOR, SWITCH UNIT AND BACKREST OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «BACKREST ADJUSTMENT MOTOR AND SWITCH UNIT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Lumbar Support Height Adjustment Motor Driver side: driver seat lumbar support height adjustment motor -V129- Front passenger side: front passenger seat lumbar support height adjustment motor -V130- Assembly overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-curvature-and-height-adjustment) Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Headrest Adjustment Motor Driver side: driver headrest adjustment motor -V103- Front passenger side: front passenger headrest adjustment motor -V104- Fixed component of the headrest base plate and cannot be replaced. If the headrest adjustment motor is faulty, replace the entire headrest base plate.
6. Entry Assistance Button Driver side: driver entry assistance button -E358- Front passenger side: front passenger entry assistance button -E359- Assembly overview, refer to «ENTRY ASSISTANCE BUTTON OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Lumbar Support Curvature Adjustment Motor Driver side: driver seat lumbar support curvature adjustment motor -V125- Front passenger side: front passenger seat lumbar support curvature adjustment motor -V126- Assembly overview, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-curvature-and-height-adjustment) Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Rear Footwell Lights Removing and installing, refer to «[For engine(s) CAUA,CAEB,CALA] Removal and Installation»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
9. Seat Height Adjustment Motor Driver side: driver seat height adjustment motor -V245- Front passenger side: front passenger seat height adjustment motor -V246- Assembly overview, refer to «SEAT HEIGHT ADJUSTMENT MOTOR OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. 6-Pin Connector For the switch unit
11. Backrest Lock Switch Driver side: driver backrest lock switch -F211- Front passenger side: front passenger backrest lock switch -F212- The backrest lock switch and the backrest forward stop switch -12- are installed on the same bracket. See item 12 in (Scheme 111) Checking, refer to «SWITCH UNIT MICRO-SWITCH, CHECKING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Adjusting, refer to «SWITCH UNIT MICRO-SWITCH, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
12. Backrest Forward Stop Switch Driver side: driver seat backrest forward stop switch -F381- Front passenger side: front passenger seat backrest forward stop switch -F383- The backrest lock switch -11- and the backrest forward stop switch are installed on the same bracket. See item 11 in (Scheme 111) Checking, refer to «SWITCH UNIT MICRO-SWITCH, CHECKING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Adjusting, refer to «SWITCH UNIT MICRO-SWITCH, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
13. Seat Adjustment Control Head Driver side: driver seat adjustment control head -E470- with: Driver backrest adjustment switch -E96- Driver headrest adjustment button -E155- Driver seat angle adjustment switch -E222- Driver seat forward/back adjustment switch -E363- Driver seat height adjustment switch -E364- Front passenger side: front passenger seat adjustment control head -E471- with: Front passenger seat forward/back adjustment switch -E64- Front passenger backrest adjustment switch -E98- Front passenger headrest adjustment switch -E170- Front passenger seat angle adjustment motor -E334- Front passenger seat height adjustment switch -E365- Assembly overview, refer to «SEAT ADJUSTMENT CONTROL HEAD OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
14. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch-overview) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch)
15. Seat Angle Adjustment Motor Driver side: driver seat angle adjustment motor -V243- Front passenger side: front passenger seat angle adjustment motor -V244- Assembly overview, refer to «SEAT ANGLE ADJUSTMENT MOTOR OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «SEAT ANGLE ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
16. Seat Position Sensor Diver side: driver seat position sensor -G553- Front passenger side: front passenger seat position sensor -G554- Assembly overview, refer to «SEAT POSITION SENSOR OVERVIEW»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Versions with seat occupied sensor for belt fastening detection, removing and installing «SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__seat-position-sensor-with-seat-occupied) Versions with seat occupied sensor for passenger airbag deactivation, removing and installing «SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__seat-position-sensor-with-seat-occupied)

Note. The illustration does not show the seat frame and the four-way lumbar support.

Scheme 109

1. Backrest Frame
2. Bolts For the backrest release Both sides Component of the backrest hinge
3. Release Cable For the backrest release One piece Removing and installing, refer to «BACKREST RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-cable) Adjusting, refer to «BACKREST RELEASE CABLE, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-cable-adjusting)
4. Bracket For the backrest release cable Quantity: 2 Component of the release cable Riveted to backrest frame
5. Mount For the backrest release cable Component of the release cable Clipped to the backrest frame
6. Connecting Cable For the backrest release Between the handle and bracket Engaged in the handle and bracket Removing and installing, refer to «CONNECTING CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connecting-cable)
7. Handle With backrest release bracket Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
8. Screws Quantity: 2 3.5 Nm
9. Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-trim)
10. Button With entry assist Assembly overview, refer to «ENTRY ASSISTANCE BUTTON OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
11. Bolt 3.5 Nm
12. Bracket For the backrest release Riveted to backrest frame Removing and installing, refer to «BACKREST RELEASE BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-bracket)
13. Support Plate Riveted to backrest frame Different versions, for allocation. Removing and installing, refer to «SUPPORT PLATE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__support-plate)
14. Rivet Quantity: 2

Scheme 110

1. Entry Assistance Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Wiring With connector
3. Entry Assistance Button Driver side: driver entry assistance button -E358- Front passenger side: front passenger entry assistance button -E359- Removing and Installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 111

1. Seat Pan
2. Screws Self-Locking Always replace if removed Threaded holes for screws must be cleaned, for example, with thread cutter 33 Nm
3. Backrest Removing and installing, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Entry Assistance Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Handle With bracket (entry assistance) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Button With entry assist Assembly overview, refer to «ENTRY ASSISTANCE BUTTON OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Wiring Harness From the side airbag to the connector station Depending on optional equipment, there may be more wiring harnesses, such as for seat heating, lumbar support

1. Front seat installed

Release the backrest using the entry assistance function.

1. The headrest must move into the lowest position by itself.

Move the seat forward using the entry assistance function.

1. The headrest must remain in the lowest position.

Move the front seat back and fold the backrest back.

1. The headrest must move back to the original position.

The following describes disconnecting and connecting the connectors for the manual standard front seat. The procedure is similar for the power standard front seat.

The assembly overview is based on a manual standard front seat. The lumbar support adjustment switches for the power standard front seat are similar. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW

Scheme 112

1. Lumbar Support Curvature Adjustment Motor Driver side: driver seat lumbar support curvature adjustment motor -V125- Front passenger side: front passenger seat lumbar support curvature adjustment motor -V126- Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Lumbar Support Height Adjustment Motor Driver side: driver seat lumbar support height adjustment motor -V129- Front passenger side: front passenger seat lumbar support height adjustment motor -V130- Removing and installing, refer to «LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Retaining Bracket For the lumbar support height adjustment motor -2-. See item 2 in (Scheme 115).
4. Retaining Bracket For the lumbar support curvature adjustment motor -1-. See item 1 in (Scheme 115).

Scheme 113

1. Front Seat
2. Pin For securing the bracket to the seat pan To remove the bracket -3-, press the pin toward the upholstery. See item 3 in (Scheme 116).
3. Bracket Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe). Engaged and clipped in the seat pan
4. Memory Seat/Steering Column Adjustment Control Head Driver side: memory seat/steering column adjustment control module -J136- Front passenger side: passenger memory seat control module -J521- Vehicles with seat heating or a comfort seat on the driver side: left front seat ventilation control module -J800- (integrated seat heater function) Vehicles with seat heating or a comfort seat on the driver side: right front seat ventilation control module -J799- (integrated seat heater function) Clipped with the bracket Removing and installing, refer to «MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__memory-seatsteering-column-adjustment-control-module)

The assembly overview relates to the manual standard front seat. The modular wiring for the power standard front seat is similar. Refer to MODULAR WIRE ROUTING OVERVIEW

The following describes the modular wiring for a manual standard front seat. It is similar for a power standard front seat.

POWER STANDARD FRONT SEAT OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 114

1. Connector Station Connector routing, refer to «CONNECTOR STATION CONNECTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connector-station-connectors)
2. Cover For connector station Removing and installing, refer to «FRONT SEATS SERVICE POSITION, SETTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-seats-service-position-setting)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview, refer to «MODULAR WIRE ROUTING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-overview) Modular wiring with corrugated tube on front seat, refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
4. Storage Compartment Vehicles with special equipment Removing and installing, refer to «STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. LATCH Child Seat Anchor Vehicles with special equipment For the front passenger seat only Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Check after accident «CHILD SEAT ANCHORS LATCH AND TOP TETHER, CHECKING AFTER A CRASH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__child-seat-anchors-latch-and-top)
7. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
8. Tunnel Side Trim Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
9. Power Standard Front Seat Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) Optional equipment: Seat and backrest heating
10. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
11. Entry Assistance Backrest Release Assembly overview, refer to «ENTRY ASSISTANCE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-overview) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
12. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
13. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
14. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cap)
15. Screws Quantity: 4 50 Nm
16. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover)
17. Actuator For backrest and headrest adjustment Actuator, removing and installing, refer to «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
18. Actuator For seat adjustment Actuator, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
19. Actuator For the lumbar support Lumbar support adjustment switch, removing and installing «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Note. The illustration does not show the backrest cover and upholstery.

Scheme 115

1. Front Backrest
2. Headrest Guide Without release button Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrest-guide) Always installed on right side of backrest
3. Wiring With connector Connected firmly to the headrest
4. Headrest Driver side: driver head adjustment motor -V103- / driver headrest height adjustment sensor -G217- Front passenger side: with front passenger headrest adjustment motor -V104- / front passenger headrest height adjustment sensor -G282- Removing and installing, refer to «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) In the case of the headrest, the cover and upholstery can only be replaced with the entire base plate (including the adjuster) It is not possible to disassemble the base plate or replace the electrical and electronic components installed inside.
5. Headrest Guide With release button Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrest-guide) Always installed on left side of backrest

Scheme 116

1. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Actuator For backrest and headrest adjustment Clipped to the control head Removing and installing, refer to «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Actuator For seat adjustment Clipped to the control head Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Screws Quantity: 3 0.4 Nm
5. Seat Adjustment Control Head Driver side: driver seat adjustment control head -E470- with: Driver backrest adjustment switch -E96- Driver headrest adjustment button -E155- Driver seat angle adjustment switch -E222- Driver seat forward/back adjustment switch -E363- Driver seat height adjustment switch -E364- Front passenger side: Front passenger seat adjustment control head -E471- with: Front passenger seat forward/back adjustment switch -E64- Front passenger backrest adjustment switch -E98- Front passenger headrest adjustment switch -E170- Front passenger seat angle adjustment button -E334- Front passenger seat height adjustment switch -E365- Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 117

1. Seat Angle Adjustment Motor Driver side: driver seat angle adjustment motor -V243- Front passenger side: front passenger seat angle adjustment motor -V244- Removing and installing, refer to «SEAT ANGLE ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Screws Self-Locking Quantity: 2 10 Nm Replace Threaded holes for screws must always be cleaned, for example, with thread cutter
3. Bolt Self-Locking 20 Nm Replace Threaded holes for screws must always be cleaned, for example, with thread cutter
4. Connector

Scheme 118

1. Lumbar Support Adjustment Switch Driver side: driver seat lumbar support adjustment switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Do not disconnect actuator and switch, they can only be replaced as a complete assembly unit. Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch)
2. Control for Seat Forward/Back, Tilt, and Height Adjustment Driver side: for driver seat forward/back adjustment switch -E363-, driver seat angle adjustment switch -E222-, driver seat height adjustment switch -E364- Front passenger side: for front passenger seat forward/back adjustment switch -E64-, front passenger seat angle adjustment button -E334-, front passenger seat height adjustment switch -E365- Actuator, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Switch and button, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The switch and button including the switches and buttons listed under are integrated in the driver seat adjustment control head -E470- or front passenger seat adjustment control head -E471- and cannot be replaced separately. See item 3 in (Scheme 121).
3. Backrest and Headrest Adjustment Driver side: for driver backrest adjustment switch -E96-, driver headrest adjustment button -E155- Front passenger side: for front passenger backrest adjustment switch -E98-, front passenger headrest adjustment switch -E170- Actuator, removing and installing «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Switch and button, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The switch and button including the switches listed under -2- are integrated in the driver seat adjustment control head -E470- or front passenger seat adjustment control head -E471- and cannot be replaced separately. See item 2 in (Scheme 121)

Scheme 119

1. Seat Pan
2. Screws Quantity: 2 10 Nm Self-Locking Replace Threaded holes for screws must always be cleaned, for example, with thread cutter
3. Bracket Bolted with the seat pan
4. Seat Height Adjustment Motor Driver side: driver seat height adjustment motor -V245- Front passenger side: front passenger seat height adjustment motor -V246- Removing and installing, refer to «SEAT HEIGHT ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Bolt CAUTION: The bolt has a left-hand thread. Quantity: 2 18 Nm Self-Locking Replace Follow the information given when removing and installing «SEAT HEIGHT ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Threaded holes for screws must always be cleaned, for example, with thread cutter
6. Adjusting Spindle Preadjusted by the manufacturer Component of the seat height adjustment motor
7. Screws Quantity: 2 28 Nm Self-Locking Replace Threaded holes for screws must always be cleaned, for example, with thread cutter

Note. If the motor is faulty, the seat pan lower frame must be replaced. The seat pan is shown without the upholstery and cover.

Scheme 120

1. Upper Seat Pan Frame Separate the seat pan upper and lower frames and assemble. Refer to «SEAT PAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Lower Seat Pan Frame Separate the seat pan upper and lower frames and assemble. Refer to «SEAT PAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Seat Forward/Back Adjustment Motor Driver side: driver seat forward/back adjustment motor -V28- Front passenger side: front passenger seat forward/back adjustment motor -V31- Removing and installing, refer to «SEAT FORWARD/BACK ADJUSTMENT MOTOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 121

1. Seat Depth Adjuster Only for sport seats Removing and installing, refer to «SEAT DEPTH ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-depth-adjuster) For the correct allocation.
2. Upper Seat Pan Frame Removing and installing, refer to «SEAT PAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) For the correct allocation. Install all electrical and electronic components and wires in the new upper frame.
3. Window
4. Bolt Quantity: 4 Self-Locking Replace Threaded holes for screws must be cleaned, for example, with thread cutter 22 Nm
5. Lower Seat Pan Frame Driver side: with driver seat forward/back adjustment motor -V28- Front passenger side: with front passenger seat forward/back adjustment motor -V31- Cannot be disassembled Removing and installing, refer to «SEAT PAN»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) When replacing, install the seat belt latch in the new lower frame
6. Bushing Inserted in all bracket locations Cannot be replaced with workshop materials The assembly component must be replaced if the bushing is damaged For the correct allocation.

The assembly overview relates to the manual standard front seat. It is similar for the power standard front seat. Refer to SEAT POSITION SENSOR OVERVIEW

Scheme 122

1. Front Seat
2. Expanding Rivet
3. Tunnel Side Trim Can only be replaced with seat removed Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
4. Expanding Rivet
5. Expanding Rivet
6. Driver Seat Adjustment Control Head -E470- Front passenger side: front passenger seat adjustment control head -E471- Assembly overview, refer to «SEAT ADJUSTMENT CONTROL HEAD OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Actuator For seat adjustment Assembly overview, refer to «SEAT BACKREST AND HEADREST ADJUSTMENT CONTROL HEAD OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Driver Seat Lumbar Support Adjustment Switch -E176- Front passenger side: front passenger seat lumbar support adjustment switch -E177- Assembly overview, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch-overview) Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch)
9. Sill Side Trim Can be replaced with seat installed Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Attach to the bracket and storage compartment

Scheme 123

1. Front Seat Power standard seat Power sport seat Comfort seat Super sport seat
2. Screws Quantity: 4 8 Nm
3. Retaining Bracket For sill side trim Removing and Installing, refer to «SILL SIDE RETAINING BRACKET TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Scheme 124

1. Front Seat
2. Sill Side Trim
3. Threaded Clip Quantity: 2
4. Storage Compartment Various versions For manual standard and sport front seats For the power standard and sport front seats and comfort and super sport front seats Removing and installing, refer to «STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Cannot be disassembled, only available as a complete replacement part For the correct allocation.
5. Bolt Quantity: 2 8 Nm
6. Upper Seat Pan Frame

SWITCH UNIT, CALIBRATING

Special tools and workshop equipment required

1. Vehicle Diagnostic Tester

Procedure

1. Front seat installed
2. Vehicle Diagnostic Tester connected
3. Ignition turned on.

Choose "Guided Functions" under Vehicle Diagnostic Tester.

Select the "Control Module Address" (06 front passenger seat or 36 driver seat)

Perform the "Seat Axis Designation".

Scheme 125

1. 6-Pin Connector Clipped with the bracket
2. Backrest Lock Switch Driver side: driver backrest lock switch -F211- Front passenger side: front passenger backrest lock switch -F212- Also called a micro switch Adjusting, refer to «SWITCH UNIT MICRO-SWITCH, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Checking, refer to «SWITCH UNIT MICRO-SWITCH, CHECKING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Slide Moveable mount for the driver backrest lock switch -F211- or Front passenger backrest lock switch -F212
4. Slide Retainer Unclip to adjust the backrest lock switch
5. Bracket
6. Locking Bushing Clipped to the spindle
7. Spindle
8. Spindle Nut
9. Backrest Forward Stop Switch Driver side: driver seat backrest forward stop switch -F381- Front passenger side: front passenger backrest forward stop switch -F383- Adjusting, refer to «SWITCH UNIT MICRO-SWITCH, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Checking, refer to «SWITCH UNIT MICRO-SWITCH, CHECKING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

Backrest lock switch, adjusting see scheme 69.

Backrest forward stop switch, adjusting see scheme 73.

Special tools and workshop equipment required

1. Gauge T40179 for 8T0 959 760
2. Spacer sleeve T40180
3. Gauge T40181 for 8T0 959 760 B and others

Note. Check the part number of the front passenger memory seat control module -J521- and the memory seat/steering column adjustment control module -J136-. Use the gauge T40179 for 8T0 959 760, from the 8T0 959 760 B and following the gaugeT40181.

Scheme 126

Slide the spacer sleeve T40180 onto the pins -3- as far as the stop.

1. The spacer sleeve T40180 and tab -4- must touch each other but must not activate the backrest lock switch -2-.

Unclip the slide retainer -1-.

Scheme 127

Release the locking tab -4- in the direction of the -arrow-.

Scheme 128

Move the slide -3- with the backrest lock switch -1- in the direction of -arrow A- or -arrow B-.

Note. Leave the spacer sleeve T40180 installed on the pins when adjusting the backrest lock switch.

Clip the slide retainer -1- in.

Scheme 129

1. The locking bushing -4- must not engage with the spindle -3-. It must be able to move on the shaft -5-.

Position the gauge T40179 or gauge T40181 on the anchor -2-.

Scheme 130

The front edge of the gauge -arrow B- must lie on the moving anchor -1-.

Connect an external power source (12 Volt) to the backrest adjustment motor.

Move the backrest forward until the anchor -1- lies on the gauge T40179 or gauge T40181 and the motor switches off.

Note. Depending on the switch adjusting, the backrest adjustment motor may stop before it runs into the block. Run the motor up to the block again. The gauge must be clamped in.

Rotate the spindle -2- until the spindle nut -1- operates the button -arrow-.

Scheme 131

Engage the locking bushing -4- with the spindle -3-.

Remove the gauge.

Checking the Adjustment

Move the backrest back slightly using the adjusting motor.

Move the backrest forward again until the adjustment motor switches off.

1. There should be a gap at the location where the gauge was inserted for the adjustment.
2. The anchors must not be lined up on the block.

Connector routing (Scheme 134)

BACKREST LOCK SWITCH, CHECKING \.

BACKREST FORWARD STOP SWITCH, CHECKING .

Special tools and workshop equipment required

1. Multimeter V.A.G 1526E
2. Connector Test Set V.A.G 1594C

Scheme 132

Connector

1. 1 - 6- Pin connectors -A- Black 6-Pin connector housing -B- Bracket

Note. Contacts not listed are not used in this application.

BACKREST LOCK SWITCH, CHECKING

Check the driver backrest lock switch -F211- or front passenger backrest lock switch -F212- using the multimeterV.A.G 1526E and connector lines from the connector test setV.A.G 1594C.

BACKREST FORWARD STOP SWITCH, CHECKING

Check the driver seat backrest forward stop switch -F381- or front passenger seat backrest forward stop switch -F383- using the multimeterV.A.G 1526E and connector lines from the connector test set V.A.G 1594C.

The assembly overview relates to the manual standard front seat. The torsion bar on the power standard front seat is similar. Refer to TORSION BAR ASSEMBLY OVERVIEW

Connecting the airbag adapter on the manual Standard front seat is described here. It is similar on the power sport front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

The assembly overview shows the power Standard front seat. The backrest adjustment motor on a power Sport front seat is identical. Refer to BACKREST ADJUSTMENT MOTOR, SWITCH UNIT AND BACKREST OVERVIEW .

The adjusting procedure is described for the manual standard front seat. It is similar on the power sport front seat. Refer to BACKREST RELEASE CABLE, ADJUSTING .

The connector station connectors are described fro the manual standard front seat. They are similar for the power sport front seat. Refer to CONNECTOR STATION CONNECTORS .

The assembly overview shows the power Standard front seat. The electrical and electronic components in a power Sport front seat are identical. Refer to ELECTRICAL AND ELECTRONIC COMPONENTS OVERVIEW .

The assembly overview shows the power Standard front seat. The front backrest is similar for the power sport front seat. Refer to ENTRY ASSISTANCE OVERVIEW .

The assembly overview shows the power Standard front seat. The entry assistance button is similar on the power sport front seat. Refer to ENTRY ASSISTANCE BUTTON OVERVIEW .

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the manual sport front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

The function test is performed the same way on all seat versions. Refer to FUNCTION TEST, PERFORMING .

The assembly overview shows the power Standard front seat. The front backrest is similar for the power sport front seat. Refer to FRONT BACKREST OVERVIEW .

The assembly overview shows a manual Standard front seat. The lumbar support adjustment switches of the power sport front seat are similar. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW .

LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS

The assembly overview shows the power Standard front seat. The lumbar support curvature and height adjustment motors for the power sport front seat are similar. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS .

MEMORY SEAT ADJUSTMENT CONTROL MODULE

The assembly overview shows the power Standard front seat. The memory seat adjustment control module on a power Sport front seat is identical. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .

The modular wiring on a manual Standard front seat is described here. It is similar on a power sport front seat. Refer to MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT .

The assembly overview shows a manual Standard front seat. It is similar on a power sport front seat. Refer to MODULAR WIRE ROUTING OVERVIEW .

The assembly overview shows the power Standard front seat. The power headrest of the power sport front seat is similar. Refer to POWER HEADRESTS OVERVIEW .

The assembly overview shows the power Standard front seat. The driver or front passenger seat adjustment control head is similar on the power sport front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD OVERVIEW .

The assembly overview shows the power Standard front seat. The seat angle adjustment motor on a power Sport front seat is identical. Refer to SEAT ANGLE ADJUSTMENT MOTOR OVERVIEW .

The assembly overview shows the power Standard front seat. The seat adjustment controls and switches on a power Sport front seat are identical. Refer to SEAT BACKREST AND HEADREST ADJUSTMENT CONTROL HEAD OVERVIEW .

SEAT DEPTH ADJUSTER OVERVIEW

The assembly overview shows a manual Sport front seat. The seat depth adjustment on a power Sport front seat is identical. Refer to SEAT DEPTH ADJUSTER OVERVIEW .

The assembly overview shows the power Standard front seat. The seat forward/back adjustment motor on a power Sport front seat is identical. Refer to SEAT FORWARD/BACK ADJUSTMENT MOTOR OVERVIEW .

SEAT HEIGHT ADJUSTMENT MOTOR ASSEMBLY OVERVIEW

The assembly overview shows the power Standard front seat. The seat height adjustment motor on a power Sport front seat is identical. Refer to .

The assembly overview shows the power Standard front seat. The seat frame on the power Sport front seat is identical. Refer to SEAT PAN OVERVIEW .

SEAT POSITION SENSOR ASSEMBLY OVERVIEW

The assembly overview shows the power Standard front seat. The seat position sensor the for the electric front sport seat is similar. Refer to SEAT POSITION SENSOR OVERVIEW .

The assembly overview shows the power Standard front seat. The trims on the sill and tunnel side of the power sport front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM OVERVIEW .

The assembly overview shows the power Standard front seat. The trim retaining bracket on the sill side of the power sport front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET OVERVIEW .

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 133

1. Connector Station Connector routing, refer to «CONNECTOR STATION CONNECTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connector-station-connectors)
2. Cover For connector station Removing and installing, refer to «FRONT SEATS SERVICE POSITION, SETTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-seats-service-position-setting)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview, refer to «MODULAR WIRE ROUTING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-overview) Modular wiring with corrugated tube on front seat, refer to «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
4. Storage Compartment Vehicles with special equipment Removing and installing, refer to «STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-depth-adjuster)
6. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. LATCH Child Seat Anchor Vehicles with special equipment For the front passenger seat only Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Check after accident «CHILD SEAT ANCHORS LATCH AND TOP TETHER, CHECKING AFTER A CRASH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__child-seat-anchors-latch-and-top)
8. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
9. Tunnel Side Trim Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
10. Power Sport Front Seat Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) Optional equipment: Seat and backrest heating
11. Headrest Power Removing and installing, refer to «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
12. Entry Assistance Assembly overview, refer to «ENTRY ASSISTANCE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
13. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
14. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
15. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cap)
16. Bolt Quantity: 4 50 Nm
17. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover)
18. Actuator For backrest and headrest adjustment Actuator, removing and installing, refer to «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
19. Actuator For seat adjustment Actuator, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
20. Actuator For the lumbar support Lumbar Support Adjustment Switch, Removing and installing, refer to «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch) Four-way lumbar support, removing and installing, refer to «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

The assembly overview shows the power Standard front seat. The storage compartment on a power Sport front seat is identical. Refer to STORAGE COMPARTMENT OVERVIEW .

The assembly overview shows the power Standard front seat. The backrest adjustment motor on a power Sport front seat is identical. Refer to SWITCH UNIT OVERVIEW .

The switch unit micro-switches are calibrated the same way on all seat versions. Refer to SWITCH UNIT, CALIBRATING .

The switch unit micro-switches are adjusted the same way on all seat versions. Refer to SWITCH UNIT MICRO-SWITCH, ADJUSTING .

The switch unit micro-switches are checked the same way on all seat versions. Refer to SWITCH UNIT MICRO-SWITCH, CHECKING .

The assembly overview shows a manual Standard front seat. The torsion bar is similar for the power sport front seat. Refer to TORSION BAR ASSEMBLY OVERVIEW .

Connecting the airbag adapter on the manual standard front seat is described here. The procedure is similar for the super sport front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

The assembly overview shows the power Standard front seat. The super sport front seat is similar. Refer to BACKREST ADJUSTMENT MOTOR, SWITCH UNIT AND BACKREST OVERVIEW .

The adjusting procedure is described for the manual standard front seat. The procedure is similar for the super sport front seat. Refer to BACKREST RELEASE CABLE, ADJUSTING .

The connector station connectors are described fro the manual standard front seat. They are similar for the super sport front seat. Refer to CONNECTOR STATION CONNECTORS .

The assembly overview shows the power Standard front seat. The electrical and electronic components of the super sport front seat are similar. Refer to ELECTRICAL AND ELECTRONIC COMPONENTS OVERVIEW .

Two different versions of the backrest may be installed.

1. Backrest frame with bracket
2. Backrest frame with support plate
3. Note the allocation of the handle with bracket and the entry assistance trim.

Note. The four-way lumbar support and seat frame are not shown in the illustration.

Scheme 134

1. Backrest Frame With bracket The bracket cannot be removed
2. Release Cable For the backrest release One piece Removing and Installing, refer to «BACKREST RELEASE CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-cable) Adjusting, refer to «BACKREST RELEASE CABLE, ADJUSTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-cable-adjusting)
3. Mount For the backrest release cable Component of the release cable Clipped to the backrest frame
4. Rivet Quantity: 2
5. Support Plate Riveted to backrest frame Different versions, for allocation. Removing and installing, refer to «SUPPORT PLATE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__support-plate)
6. Backrest Frame For versions with the support plate
7. Button With entry assist Assembly overview, refer to «ENTRY ASSISTANCE BUTTON OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Entry Assistance Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
9. Bolt Quantity: 2 3.5 Nm
10. Bolt 3.5 Nm
11. Connecting Cable For the backrest release Between the handle and bracket Engaged in the handle and bracket Removing and installing, refer to «CONNECTING CABLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connecting-cable)
12. Handle With bracket (entry assistance) For the backrest release Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
13. Bracket For the backrest release cable Quantity: 2 Component of the release cable Riveted to backrest frame
14. Bracket For the backrest release Riveted to backrest frame Removing and installing, refer to «BACKREST RELEASE BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest-release-bracket)
15. Bolts For the backrest release Both sides Component of the backrest hinge

The assembly overview shows the power Standard front seat. The entry assistance button is similar for the super sport front seat. Refer to ENTRY ASSISTANCE BUTTON OVERVIEW .

Scheme 135

1. Seat Pan
2. Bolt Self-Locking Always replace if removed Threaded holes for screws must be cleaned, for example, with thread cutter 33 Nm
3. Backrest Removing and installing, refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Entry Assistance Button Driver side: driver entry assistance button -E358- Front passenger side: front passenger entry assistance button -E359- Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Handle With bracket (entry assistance) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. Entry Assistance Trim Removing and installing, refer to «ENTRY ASSISTANCE TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Wiring Harness From the side airbag to the connector station Depending on optional equipment, there may be more wiring harnesses, such as for seat heating, lumbar support

The function test is performed the same way on all seat versions. Refer to FUNCTION TEST, PERFORMING .

Disconnecting and connecting the connectors on the manual standard front seat is described here. The procedure is similar for the super sport front seat. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Note. The headrest is a fixed component of the backrest upholstery and can only be removed together with the backrest upholstery. It is not possible to separate the headrest from the backrest upholstery. The backrest cover was not shown in the illustration for clarity purposes.

Scheme 136

1. Backrest Frame With bracket The bracket cannot be removed
2. Headrest Guide Without release button Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Always installed on right side of backrest
3. Headrest With padding Headrest laid in foam in upholstery Removing and installing, refer to «BACKREST COVER AND PADDING, SUPER SPORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-padding-super-sport)
4. Headrest Guide With release button Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Always installed on left side of backrest
5. Backrest Frame With support plate Support plate riveted to the backrest frame Support plate, removing and installing, refer to «SUPPORT PLATE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__support-plate)

The assembly overview shows a manual Standard front seat. The lumbar support adjustment switches of the super sport front seat are similar. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH OVERVIEW .

The assembly overview shows the power Standard front seat. The lumbar support curvature and forward/backward and height adjustment motors for the super sport front seat are similar. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS .

MEMORY SEAT ADJUSTMENT CONTROL MODULE OVERVIEW

The assembly overview shows the power Standard front seat. The memory seat adjustment control module of the super sport front seat is similar. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE OVERVIEW .

The assembly overview shows a manual Standard front seat. The modular wiring for the super sport front seat is similar. Refer to MODULAR WIRE ROUTING OVERVIEW .

The modular wiring is described for a manual standard front seat. It is similar for the super sport front seat. Refer to MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT .

The assembly overview shows the power Standard front seat. The seat and backrest adjustment control head for the super sport front seat is similar. Refer to SEAT BACKREST AND HEADREST ADJUSTMENT CONTROL HEAD OVERVIEW .

The assembly overview shows a manual Sport front seat. The seat depth adjuster is similar for the super sport front seat. Refer to SEAT DEPTH ADJUSTER OVERVIEW .

The assembly overview shows the power Standard front seat. The seat forward/back adjustment motor is similar for the super sport front seat. Refer to SEAT FORWARD/BACK ADJUSTMENT MOTOR OVERVIEW .

The assembly overview shows the power Standard front seat. The driver or front passenger seat adjustment control head is similar on the super sport front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD OVERVIEW .

The assembly overview shows the power Standard front seat. The seat angle adjustment motor is similar for the super sport front seat. Refer to SEAT ANGLE ADJUSTMENT MOTOR OVERVIEW .

The assembly overview shows the power Standard front seat. The seat height adjustment motor is similar for the super sport front seat. Refer to SEAT HEIGHT ADJUSTMENT MOTOR OVERVIEW .

The assembly overview shows the power Standard front seat. The lower seat frame is similar for the super sport front seat. Refer to SEAT PAN OVERVIEW .

The assembly overview shows the power Standard front seat. The seat position sensor for the front super sport seat is similar. Refer to SEAT POSITION SENSOR OVERVIEW .

The assembly overview shows the power Standard front seat. The trims on the sill and tunnel side of the super sport front seat are similar. Refer to SILL AND TUNNEL SIDE TRIM OVERVIEW .

The assembly overview shows the power Standard front seat. The trim retaining bracket on the sill side of the super sport front seat is similar. Refer to SILL SIDE TRIM RETAINING BRACKET OVERVIEW .

The assembly overview shows the power Standard front seat. The storage compartment is similar for the super sport front seat. Refer to STORAGE COMPARTMENT OVERVIEW .

SUPER SPORT FRONT SEAT OVERVIEW

Note. The overview is based on the driver seat. The passenger seat is similar and the components are installed reversed from left to right. The illustration does not show the floor covering and the four-way lumbar support.

Scheme 137

1. Connector Station Connector routing «CONNECTOR STATION CONNECTORS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__connector-station-connectors)
2. Cover For connector station Removing and installing, refer to «FRONT SEATS SERVICE POSITION, SETTING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__front-seats-service-position-setting)
3. Connector With a corrugated tube for the modular wiring routing Modular wiring routing, assembly overview «MODULAR WIRE ROUTING OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-overview) Modular wiring with corrugated tube on front seat «MODULAR WIRE ROUTING WITH RIDGED TUBE ON FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__modular-wire-routing-with-ridged-tube)
4. Seat Depth Adjuster Removing and installing, refer to «SEAT DEPTH ADJUSTER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-depth-adjuster)
5. Spindle Cover Quantity: 2 Clipped to the seat forward/back adjustment spindle Removing and installing, refer to «SEAT RAIL SPINDLE COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
6. LATCH Child Seat Anchor Vehicles with special equipment For the front passenger seat only Removing and installing, refer to «LATCH AND TOP TETHER CHILD SEAT ANCHORS»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe) Check after accident «CHILD SEAT ANCHORS LATCH AND TOP TETHER, CHECKING AFTER A CRASH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__child-seat-anchors-latch-and-top)
7. Belt Latch Removing and installing, refer to «FRONT BELT LATCH»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe)
8. Tunnel Side Trim Removing and installing, refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__trim-tunnel-side)
9. Super Sport Front Seat Removing and installing, refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat)
10. Button With entry assist Removing and installing, refer to «ENTRY ASSISTANCE BUTTON»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
11. Entry Assistance Assembly overview, refer to «ENTRY ASSISTANCE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «ENTRY ASSISTANCE HANDLE WITH BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__entry-assistance-handle-with-bracket)
12. Sill Side Trim Removing and installing, refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
13. Cover Only behind on the seat rail, sill side Removing and installing, refer to «SEAT RAIL CAP»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cap)
14. Screws Quantity: 4 50 Nm
15. Cover For the seat rail Quantity: 4 Removing and installing, refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover)
16. Actuator For backrest adjustment Actuator, removing and installing «BACKREST AND HEADREST ADJUSTMENT ACTUATOR»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
17. Actuator For seat adjustment Actuator, removing and installing «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Control head, removing and installing, refer to «SEAT ADJUSTMENT CONTROL HEAD»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
18. Actuator For the lumbar support Vehicles with special equipment Lumbar support adjustment switch, removing and installing «LUMBAR SUPPORT ADJUSTMENT SWITCH»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lumbar-support-adjustment-switch) Four-way lumbar support, removing and installing «FOUR-WAY LUMBAR SUPPORT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

The assembly overview shows the power Standard front seat. The super sport front seat is similar. Refer to

The switch unit micro-switches are calibrated the same way on all seat versions. Refer to

The switch unit micro-switches are adjusted the same way on all seat versions. Refer to

The switch unit micro-switches are checked the same way on all seat versions. Refer to

The assembly overview shows a manual Standard front seat. The torsion bar is similar for the super sport front seat. Refer to

Scheme 138

1. 2/3 Right Backrest Without pass-through Vehicles with special equipment Versions with center armrest with storage compartment (lockable backrest cover)
2. Bracket With hinges Removing and installing, refer to «BACKREST TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Cover Removing and installing, refer to «COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__cover)
4. Screws Self-Locking Quantity: 4 Always replace if removed 11 Nm
5. Storage Compartment (backrest cover) Removing and installing, refer to «LOCKABLE ARMREST STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lockable-armrest-storage-compartment)
6. Bolt 4 Nm
7. Cover For storage compartment (cover for armrest) Can be removed only with the storage compartment (cover for armrest) Is not possible to separate from the storage compartment (cover for armrest)
8. Center Armrest Removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-armrest)
9. Bolt 4 Nm
10. Rivet Rivet using special pop rivet pliersV.A.G 1753A
11. Nuts Quantity: 2 8 Nm

Scheme 139

1. 2/3 Right Backrest Without pass-through Vehicles with special equipment Center armrest with cover and trim assembly overview
2. Bracket With hinges Removing and installing, refer to «BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__bracket)
3. Cover Removing and installing, refer to «COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__cover)
4. Screws Quantity: 4 Self-Locking Always replace if removed 11 Nm
5. Bolt 4 Nm
6. Cover For backrest Removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Trim For backrest Removing and installing, refer to «BACKREST TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
8. Center Armrest Removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-armrest)
9. Bolt 1.8 Nm
10. Bolt 4 Nm
11. Rivet Rivet using special pop rivet pliersV.A.G 1753A
12. Nuts Quantity: 2 8 Nm

Scheme 140

1. 2/3 Right Backrest With pass-through Vehicles with special equipment
2. Cover Frame Clipped into the rear seat backrest Removing and installing, refer to «COVER FRAME»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__cover-frame)
3. Hood For pass-through Removing and installing, refer to «PASS-THROUGH COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Lock Washers Quantity: 2 For bolts -6
5. Bracket Part of the center armrest and pass-through cover Is not removed individually
6. Screws Quantity: 2 8 Nm
7. Bolt Quantity: 4 Self-Locking Always replace if removed 11 Nm
8. Internal Upholstery Removing and installing, refer to «INTERNAL PADDING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
9. Center Armrest Removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
10. Trim For the cupholder Removing and installing, refer to «CUPHOLDER TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__cupholder-trim)
11. Cupholder Removing and installing, refer to «CUPHOLDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
12. Key
13. Lock Cylinder For the pass-through cover Removing and installing, refer to «PASS-THROUGH COVER LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) CAUTION: Only remove and install the lock cylinder with the key inserted correctly. If that is not done, the tumblers and compression springs can fall out and the lock cylinder will be ruined. Check the installation position when installing the lock cylinder. It is not possible to lock the backrest correctly if the installation position is not correct.
14. Protective Cap For lock cylinder Remove before installing the lock cylinder CAUTION: The key must be inserted in the lock cylinder correctly before the protective cap is removed. If that is not done, the tumblers and compression springs can fall out and the lock cylinder will be ruined.

DIVIDED BACKREST OVERVIEW

Note. The backrest is divided into 2/3 on the right and 1/3 on the left.

Scheme 141

1. 2/3 Right Backrest Optional equipment: Without the center armrest and storage compartment and without the center armrest and pass-through cover With the center armrest and storage compartment With center armrest and pass-through cover Removing and installing, refer to «BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest)
2. Trim For the right lock Optional equipment: With lock cylinder Without lock cylinder (not shown in the illustration) Assembly overview, refer to «LOCK TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Lock cylinder without trim, removing and installing, refer to «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder) . Lock cylinder with trim, removing and installing, refer to «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder) . The trim with lock cylinder is destroyed when removed
3. Headrest Assembly overview, refer to «HEADREST AND HEADREST GUIDE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «HEADREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Center Armrest With pass-through cover Vehicles with special equipment Assembly overview, refer to «CENTER ARMREST WITH PASS-THROUGH COVER OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Removing and installing, refer to «CENTER ARMREST WITH PASS-THROUGH COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Center Armrest With storage compartment (armrest with lockable cover) Vehicles with special equipment Assembly overview, refer to «CENTER ARMREST AND LOCKABLE STORAGE COMPARTMENT OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The center armrest and storage compartment can only be removed and installed separately Center armrest, removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-armrest) Storage compartment (armrest with lockable cover), removing and installing, refer to «LOCKABLE ARMREST STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lockable-armrest-storage-compartment)
6. Center Armrest Without storage compartment with backrest cover and backrest trim Vehicles with special equipment Assembly overview, refer to «CENTER ARMREST WITH COVER AND TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) The center armrest as well as the backrest cover and trim can only be removed and installed separated. Center armrest, removing and installing, refer to «CENTER ARMREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-armrest) Backrest cover, removing and installing, refer to «BACKREST TRIM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Backrest trim, removing and installing, refer to «BACKREST COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
7. Left 1/3 Backrest Removing and installing, refer to «BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__backrest)
8. Right Locking Mechanism Assembly overview, refer to «LOCK OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-overview) Removing and installing, refer to «LOCK, REMOVING AND INSTALLING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-removing-and-installing)
9. Right Release Cable From the locking mechanism to the connector station Assembly overview, refer to «LOCK OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-overview) Removing and installing, refer to «RELEASE CABLE, SEPARATING FROM CONNECTOR STATION RETAINER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-separating-from-connector-station)
10. Release Cable With handle for the right remote release Assembly overview, refer to «REMOTE RELEASE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__remote-release-overview) Removing and installing, refer to «RELEASE CABLE WITH REMOTE CONTROL UNLOCK HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-with-remote-control-unlock)
11. Left Release Cable From the locking mechanism to the connector station Assembly overview, refer to «LOCK OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-overview) Removing and installing, refer to «RELEASE CABLE, SEPARATING FROM CONNECTOR STATION RETAINER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-separating-from-connector-station)
12. Release Cable With hand for the left remote release Assembly overview, refer to «REMOTE RELEASE OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__remote-release-overview) Removing and installing, refer to «RELEASE CABLE WITH REMOTE CONTROL UNLOCK HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-with-remote-control-unlock)
13. Trim For the left lock Optional equipment: With lock cylinder Without lock cylinder (not shown in the illustration) Assembly overview, refer to «LOCK TRIM OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Lock cylinder without trim, removing and installing, refer to «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder) . Lock cylinder with trim, removing and installing, refer to «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder) . The trim with lock cylinder is destroyed when removed
14. Left Locking Mechanism Assembly overview, refer to «LOCK OVERVIEW»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-overview) Removing and installing, refer to «LOCK, REMOVING AND INSTALLING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-removing-and-installing)
15. Outer Bracket Quantity: 2 Clipped into the backrest shell Removing and installing, refer to «OUTER BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__outer-bracket)
16. Cover For the center bracket Removing and installing, refer to «CENTER STORAGE COMPARTMENT COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__center-storage-compartment-cover)
17. Bolt 9 Nm
18. Securing Bracket For the center bracket Removing and installing, refer to «SECURING BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
19. Center Bracket Removing and installing, refer to «CENTER BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
20. Inner Bracket Quantity: 2 Removing and installing, refer to «INNER BRACKET»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
21. Screws Quantity: 4 16.5 Nm

Scheme 142

1 - Backrest shell

2 - Grommet

3 - Bolt

4 - Cover disc

FLOOR PANEL FOR BENCH SEAT MOUNTING GROMMETS AND WIRE FRAME, CHECKING AND ALIGNING

Check And Adjust The Floor Panel.

Scheme 143

Check body openings -1- for deformations.

In the case of deformation, readjust the panel with a plastic hammer.

Note. Remaining minor deformation is permissible.

Check And Adjust The Bench Seat Wire Frame.

Scheme 144

Note. The illustration of the seat foam can deviate from the real bench seat. Regardless of the shape of the seat foam, dimension -a- must be measured between the upper edge of the seat foam and the upper edge of the wire frame.

Place the bench seat with the cover on a clean stable surface.

Check dimension -a- on both sides of the seat frame, from the padding to the upper edge of the wire frame. Dimension -a- must be 16 to 22 mm.

If dimension -a- does not meet the specification, the wire frame must be adjusted to meet the specification. For this purpose evenly adjust the wire frame in the area of the -b motion arrows-.

Scheme 145

1. Headrest Guide With securing spring -arrow A- Always installed on the right Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
2. Headrest Guide With headrest height adjustment button -arrow B- Always installed on the left Removing and installing, refer to «HEADREST GUIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
3. Headrest Removing and installing, refer to «HEADREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Left 1/3 Backrest
5. 2/3 Right Backrest

LOCK OVERVIEW

Note. The illustration only shows the left 1/3 section of the backrest. The backrest lock on the right 2/3 section of the backrest is similar.

Scheme 146

1. Backrest Shell
2. Trim For locking
3. Locking Tab For the correct allocation. Removing and installing, refer to «LOCK, REMOVING AND INSTALLING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-removing-and-installing)
4. Release Cable With handle for remote release To the connector station Removing and installing, refer to «RELEASE CABLE WITH REMOTE CONTROL UNLOCK HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-with-remote-control-unlock)
5. Screws 2 per retainer 25 Nm
6. Release Cable From the backrest lock to the connector station With retaining clip Removing and installing, refer to «RELEASE CABLE, SEPARATING FROM CONNECTOR STATION RETAINER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-separating-from-connector-station)
7. Connector Station For the cable with handle for the remote release For the cable from the lock to the backrest
8. Cable Tie Replace
9. Retaining Clip Release cable delivery package

Scheme 147

1. 2/3 Right Backrest
2. Right Trim For locking with locking cylinder Vehicles with special equipment Removing and installing, refer to «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder)
3. Protective Cap For lock cylinder Remove before installing the lock cylinder CAUTION: The key must be inserted in the lock cylinder correctly before the protective cap is removed. If that is not done, the tumblers and compression springs can fall out and the lock will be ruined.
4. Lock Cylinder Removing and installing, refer to «LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) CAUTION: Only remove and install the lock cylinder with the key inserted correctly. If that is not done, the tumblers and compression springs can fall out and the lock cylinder will be ruined. Check the installation position when installing the lock cylinder. It is not possible to lock the backrest correctly if the installation position is not correct.
5. Key
6. Right Trim For lock with a lock cylinder Vehicles with special equipment Removing and installing, refer to «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder)
7. Left Trim For lock with a lock cylinder Vehicles with special equipment Removing and installing, refer to «LOCK TRIM, WITHOUT LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-without-lock-cylinder)
8. Left Trim For locking with locking cylinder Vehicles with special equipment Removing and installing, refer to «LOCK TRIM, WITH LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__lock-trim-with-lock-cylinder)
9. Left 1/3 Backrest

Scheme 148

1. Bench Seat NOTE: The wire frame of the bench seat must be checked after every disassembly of the bench seat and be readjusted in the case of deformation. One piece Removing and installing, refer to «BENCH SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Check and readjust the wire frame, refer to «FLOOR PANEL FOR BENCH SEAT MOUNTING GROMMETS AND WIRE FRAME, CHECKING AND ALIGNING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__floor-panel-for-bench-seat-mounting)
2. Cover For LATCH Vehicles with special equipment Quantity: 4 Clipped to the LATCH child seat anchorage brackets that are welded to the floor
3. Mounting Grommet NOTE: Replace the mounting grommets each time the bench seat is removed. Quantity: 2 For securing bench seat Clipped into the vehicle floor Removing and installing, refer to «BENCH SEAT =>»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Vehicle Floor NOTE: The floor panel into which the mounting grommets are inserted must be checked after every disassembly of the bench seat and be readjusted in the case of deformation. Check and readjust the floor panel, refer to «FLOOR PANEL FOR BENCH SEAT MOUNTING GROMMETS AND WIRE FRAME, CHECKING AND ALIGNING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__floor-panel-for-bench-seat-mounting)

ONE PIECE BENCH SEAT, WITH CENTER STORAGE COMPARTMENT OVERVIEW

Note. The one piece bench seat with center storage compartment is special equipment and is only installed on vehicles with super sport front seats.

Scheme 149

1. Bench Seat NOTE: The wire frame of the bench seat must be checked after every disassembly of the bench seat and be readjusted in the case of deformation. One piece Removing and installing, refer to «BENCH SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) Check and readjust the wire frame, refer to «FLOOR PANEL FOR BENCH SEAT MOUNTING GROMMETS AND WIRE FRAME, CHECKING AND ALIGNING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__floor-panel-for-bench-seat-mounting)
2. LATCH Child Seat Anchorage Cover Vehicles with special equipment Quantity: 4 Clipped to the LATCH child seat anchorage brackets that are welded to the floor
3. Center Storage Compartment Removing and installing, refer to «CENTER STORAGE COMPARTMENT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
4. Mounting Grommet NOTE: Replace the mounting grommets each time the bench seat is removed. Quantity: 2 For securing bench seat Clipped into the vehicle floor Removing and installing, refer to «BENCH SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)
5. Vehicle Floor NOTE: The floor panel into which the mounting grommets are inserted must be checked after every disassembly of the bench seat and be readjusted in the case of deformation. Check and readjust the floor panel, refer to «FLOOR PANEL FOR BENCH SEAT MOUNTING GROMMETS AND WIRE FRAME, CHECKING AND ALIGNING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__floor-panel-for-bench-seat-mounting)

REMOTE RELEASE OVERVIEW

Note. The illustration does not show the backrest and luggage compartment trim.

Scheme 150

1. Body Side Rear Shelf
2. Handle For remote release with handle shell Removing and installing, refer to «REMOTE CONTROL UNLOCK HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__remote-control-unlock-handle)
3. Expanding Nut Inserted in the body
4. Bolt 1.5 Nm
5. Clip
6. Release Cable From the remote release handle to the connector station Removing and installing, refer to «RELEASE CABLE WITH REMOTE CONTROL UNLOCK HANDLE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-with-remote-control-unlock)
7. Tab Quantity: 2
8. Retainer For the vehicle wiring For positioning the release cable Quantity: 2
9. Stud Bolt To secure the connector station
10. Connector Station For the cable with handle for the remote release For the cable from the lock to the backrest
11. Release Cable From the backrest lock to the connector station Removing and installing, refer to «RELEASE CABLE, SEPARATING FROM CONNECTOR STATION RETAINER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__release-cable-separating-from-connector-station)

BACKREST RELEASE BRACKET

Special tools and workshop equipment required

1. Special Pop Rivet Pliers V.A.G 1753A
2. Drill
3. Protective Eyewear

REMOVING

Turn on the ignition.

Disconnect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest frame trim. Refer to BACKREST FRAME TRIM .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the entry assistance trim. Refer to ENTRY ASSISTANCE TRIM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Push the bracket -2- up as far as the stop.

Scheme 151

Disengage the connecting cable -1- at the bracket -2-.

Drill the rivets -1- on the backrest frame -2-.

Scheme 152

Press the end of the release cable -1- out of the bracket -2-.

Remove the bracket from the backrest frame.

INSTALLING

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

BACKREST RELEASE CABLE

Note. The left and right release cables cannot be replaced separately.

Special tools and workshop equipment required

1. Special Pop Rivet Pliers V.A.G 1753A
2. Drill
3. Protective Eyewear

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest frame trim. Refer to BACKREST FRAME TRIM .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the entry assistance trim. Refer to ENTRY ASSISTANCE TRIM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Remove side airbag. Refer to SIDE AIRBAG IGNITERS -N199- / -N200 .

Note. The spring mat or lumbar support does not need to be removed when removing and installing the release cables.

Using pliers, disengage the eyes -3- (quantity: 2) from the pins -4- (quantity: 2) on both sides.

Scheme 153

Drill out rivets -2- on left and right brackets -1-.

5 - Backrest frame

Unclip the end of the release cable -2-.

Scheme 154

Press the end of the release cable out of the bracket -1- in the direction of the -arrow-.

Unclip the mount -1- from the backrest frame -2-.

Scheme 155

Guide the end of the release cable through the mount opening in the backrest frame.

Remove the left and right release cables from the backrest frame.

Install in reverse order of removal. Note the following

Adjust the left and right release cable. Refer to BACKREST RELEASE CABLE, ADJUSTING .

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest frame trim. Refer to BACKREST FRAME TRIM .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the entry assistance trim. Refer to ENTRY ASSISTANCE TRIM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Tilt the bracket -arrow- up as far as the stop and hold it in that position.

Disengage the connecting cable -1- at the bracket.

Push the handle -1- forward as far as the stop.

Scheme 156

Disengage the connecting cable -2- at the handle.

Remove the connecting cable.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Scheme 157

Remove front backrest cover and upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Remove the bolts -1-.

Remove the retaining plate -2- for the screen console.

Remove the nut -2-.

Guide socket -4- and washer -3- out of mount -1-.

Installation is reverse of removal, noting the following

Pull washer -3- up and slide socket -4- from the side into mount -1-.

1. The socket must fit in the center of the mount.

Hold the socket in this position and tighten the nut.

Install the retaining plate hooks into the backrest frame -3- -arrows-.

Tighten the bolts.

TIGHTENING SPECIFICATIONS

(Scheme 93)

(Scheme 94).

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest frame trim. Refer to BACKREST FRAME TRIM .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the entry assistance trim. Refer to ENTRY ASSISTANCE TRIM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Remove the connecting cable. Refer to CONNECTING CABLE .

Press the handle -arrow- forward as far as the stop and hold it in that position.

Scheme 158

Remove the bolts -1-.

Remove the handle with bracket -2- from the backrest frame entry assistance support plate.

Disengage the tabs -A arrows- (quantity: 2) on the entry assistance support plate.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Remove tunnel side trim panel. Refer to TRIM, SILL SIDE .

Disconnect the connector -4-.

Scheme 159

Remove the bolts -2-.

Remove the driver seat lumbar support adjustment switch -E176- or -E177- -1- from the trim -3-.

Install in reverse order of removal. Note the following

Route the wires as close to the connector -4- as possible.

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SEAT POSITION SENSOR

The following describes the removal and installation of a power standard front seat. The procedure is similar for a manual standard front seat. Refer to SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION .

SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION

SEAT RAIL COVER

Note. The procedure for removing and installing is described on the driver seat sill side seat rail cover. The procedure is similar for the tunnel side seat rail cover.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Unclip the retaining tabs -3, 4 and 5- on the cover -2- from the seat rail.

Scheme 160

Remove the cover -1- forward parallel to the seat rail.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SUPPORT PLATE

Special tools and workshop equipment required

1. Special Pop Rivet Pliers V.A.G 1753A
2. Drill
3. Protective Eyewear

Remove the handle with bracket. Refer to ENTRY ASSISTANCE HANDLE WITH BRACKET .

Drill out rivets -1-.

Scheme 161

Remove the support plate -2- from the backrest frame -3-.

Install in reverse order of removal.

TORSION BAR

Special tools and workshop equipment required

1. Bracket 2024 A /1
2. Handle-Hold Dr. Shaft Flange 3145
3. Shackles 8 mm diameter (available commercially)
4. M10x30 bolt and nut

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove tunnel side trim panel

1. Standard seat and Sport seat (manual). Refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
2. Standard seat and Sport seat (power), Comfort seat and Super Sport seat. Refer to «TRIM, SILL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove tunnel side trim panel. Refer to TRIM, TUNNEL SIDE .

Remove the front backrest

1. Standard seat and Sport seat (manual). Refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .
3. Super Sport seat. Refer to «FRONT BACKREST»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Secure the counter-holder 3145 with the bracket 2024 A /1 and shackle -2- on the torsion bar -3- as illustrated.

Scheme 162

1 - M10x30 bolt with nut

2 - Shackle

3 - Torsion bar

4 - Seat pan

Carefully rotate the torsion bar -1- until it disengages from the oblong hole -arrow- on the seat pan.

Scheme 163

Remove the torsion bar -1- and extension 2024 A /1 from the seat pan -2-.

Slide the torsion bar -1- into the mount until the end -arrow- comes into contact with the seat pan -2-.

Scheme 164

Make sure the torsion bar -2- is seated in the mounting bracket -arrow- on the seat pan -1- correctly.

Scheme 165

Mount the handle 3145 with the bracket 2024 A /1 and threaded connection -3-, but without the shackle, to the torsion bar -1-.

Scheme 166

1 - Torsion bar

2 - Seat pan

Carefully rotate the torsion bar -1- until it engages in the oblong hole -arrow- on the seat pan.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Remove the torsion bar. Refer to TORSION BAR .

Remove the bearing -1- out of the guide -2-.

Scheme 167

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

TRIM, TUNNEL SIDE

Note. Removal and installation can only be performed with the front seat removed.

Turn on the ignition.

Move the front seat to the highest position.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the expanding rivets -3- and -4-.

Scheme 168

Remove tunnel side trim panel -2- upward.

Note. Make sure the tab -1- is not damaged when removing the trim.

Install in reverse order of removal. Note the following

Note. Make sure the tab -1- is seated correctly. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

BACKREST ADJUSTING WHEEL

Removal and installation is described for a manual standard front seat. The procedure is similar for the bucket front seat. Refer to BACKREST ADJUSTING WHEEL .

BACKREST COVER

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Scheme 169

Apply adhesive tape -2- to the backrest shell all around trim -1-.

Using the pry lever80-200, pry off the upper backrest cover on the inner side, starting from the backrest shell.

Disengage the clip at the front edge of the backrest cover extremely carefully.

Install in reverse order of removal.

Special tools and workshop equipment required

1. Pop Rivet Pliers VAS 5072
2. Drill
3. 6.0 mm drill bit
4. Protective Eyewear

Scheme 170

Remove the backrest. Refer to FRONT BACKREST .

Remove the backrest cover. Refer to BUCKET SEAT BACKREST COVER AND PADDING OVERVIEW .

Unscrew the screws. Refer to -arrows- at the cover.

Remove cover -1-.

Turn the cover and release the retaining tabs -arrows-.

Scheme 171

Remove cover -1-.

Remove control cable bracket -3- for the release cables for releasing the backrest at the cover.

Scheme 172

Remove release lever -2-.

Detach release cables -1- in the direction of the -arrow-.

Repeat work steps on opposite side.

Remove backrest cover and backrest frame. Refer to BACKREST COVER .

Scheme 173

Remove the bolts -3- and -4-.

Drill out the blind rivet -2- with a 6 mm drill in backrest frame mount -1-.

Tip the backrest frame mount to the side and remove control cable bracket -2- for the release cables at backrest frame mount -3-.

Scheme 174

Disengage release cable eye -1- at release lever -4- by sliding the eye forward -arrow- and removing.

Remove the release cables upward out of the backrest frame.

Install in reverse order of removal. Note the following

Insert the bolts with locking compound.

Adjust the backrest lock release cables. Refer to BACKREST RELEASE CABLE, ADJUSTING .

FRONT BACKREST

Special tools and workshop equipment required

1. Pop Rivet Pliers VAS 5072
2. Drill
3. 4.0 mm drill bit
4. Protective Eyewear

Scheme 175

Remove the seat pan. Refer to SEAT PAN .

Remove the seat adjustment control module. Refer to SEAT ADJUSTMENT CONTROL MODULE .

Remove the bolt -1-.

Drill out the blind rivet -2- with a 4 mm drill and remove retaining bracket -3-.

Remove the left and right bolts -arrows-.

Scheme 176

Remove the backrest -3- and cut the cable ties -2- for the electrical wiring harness.

Remove the backrest with the electrical wiring harness.

Install in reverse order of removal. Note the following

Insert the bolts with locking compound.

For the correct tightening specifications, refer to LOWER SEAT FRAME AND FRONT BACKREST OVERVIEW, see item 10 in (Scheme 84).

FRONT BUCKET SEAT

Scheme 177

Move bucket seat -1- all the way up and back.

Remove the bolts -2-.

Move the bucket seat all the way forward.

Remove the bolts -3-.

Tilt the bucket seat back and disconnect the electrical harness connectors. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Remove the bucket seat from the vehicle with a second technician.

Install in reverse order of removal.

Scheme 178

Remove the bucket seat. Refer to FRONT BUCKET SEAT .

Secure the bucket front seat on the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the trim on the sill side. Refer to TRIM, SILL SIDE .

Remove the bolts -arrows-.

Remove lumbar support adjustment switch -1-.

Install in reverse order of removal.

Scheme 179

Remove the backrest padding. Refer to BUCKET SEAT BACKREST PADDING .

Cut through cable tie -3-.

Expose the wiring harness and pneumatic hose at retaining clip -4-.

Carefully detach the adhesive of module carrier -2- from the backrest.

Tilt the upper edge of the module carrier forward -arrow- and guide out at backrest adjustment shaft -1-.

Remove the module carrier.

Install in reverse order of removal.

Coat adhesive material on the reverse side of the module support. Adhesive material

Component assignment of the module carrier, refer to MODULE CARRIER WITH AIR CUSHIONS FOR LUMBAR SUPPORT COMPONENT ASSIGNMENT .

Scheme 180

Move the seat all the way forward to the highest position.

Release the clips -arrows- and remove trim -2-.

Note. Ignore -1-.

Install in reverse order of removal. Note the following

Press the outer trim on until it engages audibly.

Move the bucket seat all the way up and forward.

Remove the bolts -arrows-.

Disconnect the connector -2-.

Disconnect the connector -3-.

To disconnect electrical connector, press catch -1-, rotate retaining bracket in the direction of the -arrow- and remove connector.

Scheme 181

Remove control module.

Install in reverse order of removal.

For the correct tightening specifications (Scheme 86)

SEAT BELT GUIDE

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Scheme 182

Carefully guide the pry lever80 - 200 between the backrest cover and belt guide.

Release and remove the belt guide from the cover by pressing carefully.

Install in reverse order of removal.

Scheme 183

Remove the bucket seat. Refer to FRONT BUCKET SEAT .

Secure the bucket front seat on the fixture for seat repair VAS 6136 FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the trim on the sill side. Refer to TRIM, SILL SIDE .

Remove the bolts -2- and -3-.

Disengage retaining clips -5- and -6- and remove seat bolster inflation adjustment button -1- or backrest bolster inflation adjustment button -4-.

Install in reverse order of removal.

SEAT FORWARD/BACK ADJUSTER RELEASE CABLE

Special tools and workshop equipment required

1. Pop Rivet Pliers VAS 5072
2. Drill
3. 4.0 mm drill bit
4. Protective Eyewear

Scheme 184

Remove the trim on the sill side. Refer to TRIM, SILL SIDE .

Remove the screw.

Remove the seat forward/back adjustment handle.

Press the control cable sleeve in the direction of -arrow A- out of the control cable bracket.

Detach release cable -1- for seat forward/back adjustment from the release lever -arrow B-.

Scheme 185

Drill out blind rivets -arrows- with a 4 mm drill and remove the retaining plate -1- for the relay socket and wiring harness.

Release retaining clip -4- on the release cable in the direction of -arrow A- and remove the retaining clamp in an upward direction -arrow B-.

Scheme 186

Release retaining spring -2- with a narrow screwdriver -3-.

Remove seat rail release lever -1- up out of the axis of rotation.

Remove the seat forward/back adjustment release cable.

Install in reverse order of removal.

Scheme 187

Remove the outer trim. Refer to OUTER TRIM .

Remove the bolt -2-.

Remove seat height adjustment lever -1- -arrow-.

Install in reverse order of removal. Note the following

Insert the bolt with locking compound; locking compound.

Scheme 188

Remove the seat pan. Refer to SEAT PAN .

Remove the bolt -3-.

Remove the bolts -2- and -4-.

Remove seat height adjuster -5- and retaining plate -1-.

Install in reverse order of removal.

Scheme 189

Pull seat height adjustment handle -2- up as far as the stop and hold it in that position.

Use a narrow screwdriver to press retaining clip -1- toward the inside -arrow A- and remove the seat height adjustment handle from the lever -arrow B-.

Scheme 190

Install in reverse order of removal. Note the following

1. Springs -2- of retaining clip -3- must be on the outside of lever -1-.

Remove the trim on the sill side. Refer to TRIM, SILL SIDE .

Remove the trim on the tunnel side. Refer to TRIM, TUNNEL SIDE .

Remove the screw.

Remove the seat forward/back adjustment handle.

Press the control cable sleeve in the direction of -arrow A- out of the control cable bracket.

Detach release cable -1- for seat forward/back adjustment from the release lever -arrow B-.

Release retaining clip -4- on the release cable in the direction of -arrow A- and remove the retaining clamp in an upward direction -arrow B-.

Release retaining spring -2- with a narrow screwdriver -3-.

Remove seat rail release lever -1- up out of the axis of rotation.

Remove the bolt -1- and cut the cable ties -arrows-.

Scheme 191

Free up the electrical wiring harness on the retaining plate.

Disconnect the electrical connectors -2- and -4-.

Disconnect the pneumatic hose -3-.

Remove the bolts -arrows-.

Scheme 192

Remove the seat pan from the seat frame.

Install in reverse order of removal. Note the following

Insert the bolts with locking compound; locking compound.

Scheme 193

Remove the bucket seat. Refer to FRONT BUCKET SEAT .

Carefully release retaining tabs -1- and -2-.

Remove the seat rail cover.

Install in reverse order of removal. Note the following

Seat rail cover must be removed until it audibly engages.

Remove the bucket seat. Refer to FRONT BUCKET SEAT .

Secure the bucket front seat on the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the outer trim. Refer to OUTER TRIM .

Remove the seat height adjustment lever. Refer to SEAT HEIGHT ADJUSTER .

Remove the backrest adjustment wheel. Refer to SEAT HEIGHT ADJUSTMENT HANDLE .

Remove the left backrest cover BACKREST COVER .

Remove the bolt -1-.

Scheme 194

Separate the cable ties.

Press the retaining tab and pull the electrical connectors out of the brackets.

Mark electrical connectors -2- and -3- and remove them.

Press the locking pin inward and remove the expanding clip -3-.

Scheme 195

Release retaining tab -1- -arrow A- and remove sill trim -2- upward and toward the front -B arrows

Disconnect the lumbar support electrical harness connector.

Scheme 196

Install in reverse order of removal. Note the following

Make sure trim -1- on the sill side engages correctly in the seat pan and on the backrest -arrows-.

For the correct tightening specifications, refer to

Scheme 197

Remove the bucket seat. Refer to FRONT BUCKET SEAT .

Secure the bucket front seat on the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the right backrest cover. Refer to BACKREST COVER .

Remove the belt latch. Refer to FRONT BELT LATCH .

Note. Do not disconnect the electrical harness connectors.

Press the locking pin inward and remove the expanding clip -1-.

Release clip -3- -arrow A- and remove trim -2- on the tunnel side upward and toward the front -arrow B-.

Install in reverse order of removal. Note the following

Make sure the trim on the tunnel side engages correctly in the backrest.

Special tools and workshop equipment required

1. Assembly Tool 3399

Scheme 198

Turn the backrest adjustment wheel -1- until a locking mechanism is visible from behind -arrow A-. It may be necessary to use a flashlight.

Engage Assembly Tool 3399 and pry it in the direction of -arrow B-.

Turn backrest adjustment wheel about 120° more.

Engage Assembly Tool 3399 and pry it in the direction of -arrow B-.

Remove backrest adjustment wheel.

Install in reverse order of removal. Note the following

If backrest adjustment wheel is too loose after installation, replace wheel.

Note. Removal and installation can be done with seat installed. Removing and installing a standard front seat is described. Removal and installation on the other seat versions is similar. The illustration shows a backrest cover without a storage net. The storage net cannot be removed from the backrest cover and can only be replaced together with the backrest cover.

Scheme 199

Disengage the lower side hooks -3- (quantity: 2) on the backrest cover -2-.

1 - Backrest frame trim

Press the backrest cover -1- toward the center of the seat in the direction of -arrow A-.

Scheme 200

Remove the backrest cover back in the direction of -arrow B-.

Do the same on the opposite side.

Disengage the sides of the backrest cover -2- -arrows A, B, E and F-.

Scheme 201

Reach behind the backrest cover -1- and remove the right side from the backrest -2-.

Scheme 202

Do the same to the opposite side of the backrest cover -1-.

Loosen the side retaining hooks -3- or -5- (Scheme 88).

Remove the backrest cover -1- further and bend it until the upper hooks -2- (Scheme 88) disengage from the backrest frame.

Scheme 203

Note. The illustration does not show the upper hooks.

Tip the backrest cover -1- back slightly.

Press the backrest cover -1- down in the direction of -arrow A-.

Scheme 204

Lift the backrest cover in the direction of -arrow B- and remove it from the backrest frame.

Install in reverse order of removal. Note the following

First slide the upper hooks -2- (Scheme 88) under the top backrest frame cross panel.

Tilt the backrest cover down and engage the side retaining tabs -3- and -5- and the lower hooks -4-.

Make sure the side retaining tabs -3- and -5- engage with the backrest frame trim correctly and the lower hooks -4- slide over the backrest frame trim seats.

Press the backrest cover -1- firmly into the areas marked with circles in the direction of the backrest.

Scheme 205

Check the retainers for secure seating and try to pull the lower part of the backrest cover off.

The backrest cover is engaged properly if it cannot be pulled off.

BACKREST FRAME TRIM

Note. Removal and installation are described for the standard front seat. Removal and installation on the other seat versions is similar.

Scheme 206

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest upholstery until the 2 retaining tabs -arrow A- and -arrow B- on the backrest frame trim -2- can be seen from behind.

Disengage the retaining tabs -arrow A- and -arrow B- on the backrest frame trim -2- at the backrest frame.

Scheme 207

Remove the backrest frame trim -2- upward from the backrest frame -1-.

Scheme 208

Disengage the lower seats -arrows- (quantity: 2) on the backrest frame.

Remove the backrest frame trim from the backrest frame.

Install in reverse order of removal.

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove tunnel side trim panel. Refer to TRIM, TUNNEL SIDE .

Move the backrest forward as far as the stop using the handwheel.

Disengage the entry assistance release cable A -1- at the backrest hinge.

Scheme 209

Remove the entry assistance release cable A guide -2- from the seat frame.

Unclip the control cable bracket of the entry assistance release cable A -1- at the seat forward/back adjuster -2-.

Scheme 210

Disengage the entry assistance release cable A -1- at the seat forward/back adjuster -2- and remove it.

Scheme 211

Engage the entry assistance release cable B -1- in at the seat forward/back adjuster -2-.

Clip the control cable bracket of the entry assistance release cable A -1- into seat forward/back adjuster -2-.

Engage the entry assistance release cable A -1- at the backrest hinge.

Install the entry assistance release cable A guide -2- on the seat frame.

Adjust the entry assistance release cable A. Refer to ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING .

Lock the entry assistance release cable A -1- with the clip -2-.

Scheme 212

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

The following conditions must be met to adjust the entry assistance release cable

1. The upholstery must be removed from the seat and backrest and they must be bolted to each other.
2. To adjust the entry assistance function, the backrest must be positioned at the front stop.
3. The entry assistance release cable B must be engaged at the backrest and on the seat pan lower frame.

Checking and Correcting

Scheme 213

Press the entry assistance lever -4- in the direction of the -arrow- as far as the stop.

1 - Backrest

2 - Bolts

3 - Tab

4 - Entry assistance lever

5 - Backrest frame

Check if the self-adjuster -1- is locked and if the spring in the self-adjuster responds.

Scheme 214

To check, press the self-adjuster -1- together and release it twice.

1 - Self adjuster

2 - Clips

If the test is successful

Engage the clip -2- on the self-adjuster -1-.

If the test is not successful

Replace the release cable and perform the checking and adjusting procedure again.

Turn on the ignition.

Disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Move the backrest forward as far as the stop using the handwheel.

Disengage the eyelet on the entry assistance release cable B -3- from the pin -arrow- on the seat rail.

Unclip the entry assistance release cable B -3- at the seat forward/back adjuster -2-.

Push the upholstery to the side.

Disengage the eyelet on the entry assistance release cable B -1- from the pin -arrow- on the backrest hinge.

Scheme 215

Disengage the retainer on the entry assistance release cable B at the backrest hinge and remove the cable.

Engage the eyelet on the entry assistance release cable B -1- from the pin -arrow- on the backrest hinge.

Secure the entry assistance release cable B on the backrest hinge.

Clip the entry assistance release cable B -3- in at the seat forward/back adjuster -2-.

Engage the eyelet on the entry assistance release cable B -3- from the pin -arrow- on the seat rail.

Adjust the entry assistance release cable B. Refer to ENTRY ASSISTANCE RELEASE CABLE B, ADJUSTING .

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Note. The function of the entry assistance release cable B is checked and corrected when adjusting the cable.

The following conditions must be met to check and correct the function

1. The upholstery must be removed from the seat and backrest and they must be bolted to each other.
2. To adjust the function, the backrest must be positioned at the front stop.
3. The entry assistance release cable B must be engaged at the backrest and on the seat pan lower frame.

Note. The knurled nut -1- on the entry assistance release cable B -2- is delivered in the position shown in the illustration and must not be changed. This ensures the entry assistance release cable B is preadjusted.

CHECKING AND CORRECTING

Fold the backrest over the entry assistance release unit.

If the function still does not work, it must be corrected.

Unclip the release cable -3- with the knurled nut from the seat forward/back adjuster -2-.

Rotate the knurled wheel approximately 10 mm forward.

Correct the position of the knurled nut if the adjustment is incorrect.

Clip the release cable -3- with the knurled nut into the seat forward/back adjuster -2-.

Repeat the checking and correcting procedure until the function is correct.

ENTRY ASSISTANCE TRIM

Note. Removal and installation can be performed with the front seat installed.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 216

Press the handle -arrow B- forward as far as the stop and hold it in that position.

Press the tab -arrow A- off the catch -arrow C- in the direction of the -arrow- using a trim removal wedge3409.

Perform the same step on the opposite side of the trim -1-.

Tilt the trim -1- upward diagonally and remove from the handle with the bracket -2-.

Disengage the rear trim catch from the handle with bracket.

Remove the trim from the bracket with handle.

Install in reverse order of removal. Note the following

First engage the rear trim catch in the handle with bracket.

Make sure the trim engages correctly in the handle with bracket.

FOUR-WAY LUMBAR SUPPORT

Special tools and workshop equipment required

1. Special Pop Rivet Pliers V.A.G 1753A
2. Drill
3. Protective Eyewear

Turn on the ignition.

Disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest frame trim. Refer to BACKREST FRAME TRIM .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove the cover with the upholstery

1. Standard seat and Sport seat (manual or power) and Comfort seat. Refer to «BACKREST COVER AND UPHOLSTERY»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-upholstery) .
2. Super Sport seat. Refer to «BACKREST COVER AND PADDING, SUPER SPORT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-upholstery-covers-coupe__backrest-cover-and-padding-super-sport) .

Separate the Velcro fastener -3- between the system -2- and the upholstery.

Scheme 217

Note. It requires relatively high amount of force to separate the Velcro fastener.

Note. Lay plastic film between the seat pan cover and the backrest frame to protect against metal shavings.

Drill out rivet -3-.

Disconnect the electrical connectors -1- and -2- at lumbar support curvature and height adjustment motors.

Disengage the four-way lumbar support -2- on the backrest frame -1-.

Scheme 218

Remove the four-way lumbar support from the backrest frame.

Disengage system -2- at four-way lumbar support -1- if necessary -arrows-.

Engage system -2- at four-way lumbar support -1- if necessary -arrows-.

Lay plastic film -1- over the Velcro strips -2- on the system -2-.

Scheme 219

Secure plastic film to the system -2-.

Make sure the lumbar support is attached to the system -2- using an assembly fastener -4- or a suitable pin.

Engage four-way lumbar support -2- on the backrest frame -1-.

Before securing rivet -4-, a plastic washer -1- must be placed between lumbar support -2- and backrest frame -3-.

Scheme 220

Rivet the four-way lumbar support frame -2- with the backrest frame -3-.

Stretch the upholstery with cover over the backrest frame.

Remove the plastic film between the system and the upholstery.

Press the system Velcro™ fastener onto the upholstery.

Connect the electrical connectors on the lumbar support curvature and height adjustment motors.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SEAT RAIL CAP

Note. The cap is installed only on the back of the seat rail, on the sill side.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 221

Bring headrest into lowest lock position.

Move the seat all they way forward and in the highest position.

Release the hook -3- on the seat rail -2- and pry the cap off the seat rail screw -1- using the trim removal wedge3409 -arrow-.

Make sure the cap is engaged correctly.

Note. Removal and installation is described for the driver seat. Removal and installation of the passenger seat is similar.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the tunnel side trim. Refer to TRIM, TUNNEL SIDE

Remove the sill side trim. Refer to TRIM, SILL SIDE

Press the entry assistance release cables -1- and -3- out of the retaining plate -2- at the seat rail release.

Disengage the release cable -3- from the seat rail release -arrow-.

Disengage the release cable -1- at the seat rail release idler pulley -2-.

Using the trim removal wedge3409, unclip the wiring harness -1- in the corrugated tube -2- at the bottom side of the seat pan and remove the wiring bracket.

Disconnect all the wiring harness connectors to the backrest and free up the disconnected wiring harnesses.

Note. The wiring harness between the connection point and the side airbag is continuous.

Remove the bolts -2-.

Scheme 222

Tip backrest -3- forward onto seat pan -1-.

Press the seat pan upholstery to the side and carefully remove side airbag wiring harness -4- and, if necessary, all additional wiring harnesses (depending on equipment) from the seat pan.

Remove backrest.

Install in reverse order of removal. Note the following

Adjust the entry assistance release cables. Refer to

ENTRY ASSISTANCE RELEASE CABLE B, ADJUSTING

ENTRY ASSISTANCE RELEASE CABLE A, ADJUSTING

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the headrests. Refer to HEADRESTS WITH LOCKING MECHANISM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Headrest Guide Without Release Button

Scheme 223

Press the retaining tabs -arrows- on the headrest guide -1- toward the center of the headrest guide.

Hold the retaining tabs -arrows- down.

Pull headrest guide -1- upward out of backrest frame -2-.

Headrest Guide With Release Button

Scheme 224

Press the retaining tabs -arrows- on the headrest guide -1- toward the center of the headrest guide.

Hold the retaining tabs -arrows- down.

Pull headrest guide -1- upward out of backrest frame -2-.

Install in reverse order of removal. Note the following

Headrest Guide Without Release Button

Note. When sliding the headrest guide -1- in, make sure the tab -3- engages correctly on the backrest frame -2-. Make sure the retaining tabs -arrows- are engaged in the backrest frame -2- correctly.

Headrest Guide With Release Button

Note. When sliding the headrest guide -1- in, make sure the tab -3- engages correctly on the backrest frame -2-. Make sure the retaining tabs -arrows- are engaged in the backrest frame -2- correctly.

Continuation for Headrest Guide Without and With Release Button

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

HEADRESTS WITH LOCKING MECHANISM

Note. The headrests can be removed with the front seats installed. The release button is located on the outer left of the driver seat and inner left of the passenger seat.

Scheme 225

Find release button pressure point -3-. It is located under the backrest cover.

Press the release button forward in the direction of the -arrow-.

Hold the release button down in this position.

Pull headrest -2- up out of guides -1- and -4-.

Note. If the release button does not work as described, remove the backrest cover. Refer to BACKREST COVER . Reach under the backrest cover and find the release button pressure point.

Install in reverse order of removal. Note the following

Make sure the headrest is engaged correctly in headrest guides.

The following describes the removal and installation of a power standard front seat. The procedure is similar for a manual standard front seat. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS .

MANUAL STANDARD FRONT SEAT

Note. The following describes removing and installing the driver side. The procedure for the front passenger seat is similar.

Bring seat into service position. Refer to FRONT SEATS SERVICE POSITION, SETTING .

Turn on the ignition.

Disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Disconnect the harness connectors> Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING on the connector station in the floor.

Connect Airbag Adapter VAS 6281. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Remove front bolts -1- (quantity: 2).

Scheme 226

3 - Rear console

4 - Front console

Press the seat forward/back adjustment handle and move the seat -2- as far forward as possible.

Remove rear bolts -1- (quantity: 2).

With help from a second technician, lift the seat -2- out of the vehicle.

Install in reverse order of removal. Note the following

Remove Airbag AdapterVAS 6281 only after installing seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Note. Make sure the connectors are installed all the way in and are secure.

Connect the connectors to the connectors of the connector station in the floor. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Release the seat forward/back adjuster.

Slide the front seat all the way back.

Unlatch the front seat using the entry assistance handle.

Fold the backrest forward and move the seat all the way forward at the same time.

Remove the rear seat bolt on the tunnel side. See item 15 in (Scheme 97).

Press the rocker -arrow A- on the memory stop in the direction of the -arrow- and release it.

Scheme 227

Remove the memory stop -1- from the seat rail -2- toward the rear by tipping it slightly toward the tunnel.

Scheme 228

If the memory stop has been replaced, clean this area of the seat rail to remove any residue of the previous memory stone.

Install the memory stop into the seat rail -1- by slightly tipping it toward the tunnel.

Engage the memory stop in the back catch -arrow-.

Tighten the rear seat bolt on the tunnel side. See item 15 in (Scheme 97).

Tilt the backrest back while sliding the seat all the way back (entry assistance).

Release the seat forward/back adjuster and slide the front seat into the desired position.

Note. It is not necessary to adjust the memory seat separately.

Note. The work can be performed with the seat installed.

Move the seat as far as possible up and back.

Disengage the control cable bracket of release cable -1- at seat forward/back adjuster -2-.

Scheme 229

Disengage the end of the release cable -arrow- at release cable retainer lever -3- of the seat forward/back adjuster.

Turn the release cable retainer lever forward and remove it.

Remove the spring if necessary.

Install in reverse order of removal. Note the following

Note. The release cable retainer lever is the same for the driver and front passenger seat. The spring is different for the driver and front passenger seat.

Install the spring correctly.

Release Cable Retainer with Installed Spring for The Left Seat

Scheme 230

Attach the spring at points -1- and -2-.

Turn the spring at lever -3- in a clockwise direction.

Place the spring around tab -4- so that it is touching -5-.

Release Cable Retainer With Installed Spring for The Right Seat

Scheme 231

Attach the spring at points -1- and -2-.

Turn the spring at lever -3- in a counterclockwise direction.

Place the spring around tab -4- so that it is touching -5-.

SEAT PAN LOWER FRAME OR SEAT PAN

Note. There is no separation between the seat pan lower frame with a seat forward/back adjuster and the seat pan upper frame on the standard front seat (manual). Refer to .

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove tunnel side trim panel. Refer to TRIM, SILL SIDE .

Remove the seat angle adjustment handle. Refer to SEAT ANGLE ADJUSTMENT HANDLE .

Remove the shoulder pin -2-.

Scheme 232

Remove the bolt -3-.

Remove the seat angle adjuster -1-.

Install in reverse order of removal. Note the following

Replace the shoulder pin -2- and the bolt -3-.

Clean the threaded holes before installing, for example using a thread tap.

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Open the cable ties for the release cable or unclip the clip on the seat pan.

Disengage the control cable bracket of release cable -1- at seat forward/back adjuster -2-.

Disengage the end of the release cable -arrow- at the seat forward/back adjuster lever -3-.

Disengage the control cable bracket of release cable -2- at seat forward/back adjuster -1-.

Scheme 233

Disengage the release cable -1- that seat forward/back release cable mount -arrow A-.

Scheme 234

Disengage the ball-shaped end of the release cable -arrow B- at the seat forward/back adjuster groove.

Remove the release cable.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SEAT FORWARD/BACK ADJUSTMENT HANDLE

Note. Removal and Installation can be done with the seat installed.

Scheme 235

Bring headrest into lowest lock position.

Press the seat forward/backward handle and move the seat as far back as possible.

Pry handle -1- off of seat forward/back adjuster -2- by using a screwdriver to press down the clip locking spring.

Scheme 236

Install in reverse order of removal. Note the following

Replace the clip on the seat forward/back adjustment handle. Note the installation position.

1. The springs -arrows- (quantity: 2) on the clip -2- must be on the inner side of the lever -1-.

Make sure the seat height adjustment handle engages correctly with the clips.

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove tunnel side trim panel. Refer to TRIM, SILL SIDE .

Remove bolts -2- (quantity: 2).

Scheme 237

Remove the seat height adjustment handle -1-.

Remove the lock washer -1-.

Scheme 238

Note. The bolts -1- and the bolt -3- are different lengths.

Remove the bolts -1- (quantity: 2) and -3- (quantity: 5).

Remove seat height adjuster -2-.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SEAT HEIGHT ADJUSTMENT HANDLE

Note. The seat height adjustment handle can be replaced with the front seat installed.

Special tools and workshop equipment required

1. Hook 3438

Scheme 239

Note. Remove the seat height adjustment handle -1- as described. Do not drive it off the lever -2-. If the tab -arrow- is damaged when removing the seat height adjustment handle, the handle cannot be reinstalled. It must be replaced.

Pull the seat height adjustment handle -1- as far up as possible and hold it in that position.

Scheme 240

Carefully pull the seat height adjustment handle slightly away from the front seat.

Place thehook3438 between the seat height adjustment handle and the trim -2-.

Unlock the release -3- using the hook3438 and at the same time, pull the seat height adjustment handle in the direction of the -arrow- from the lever.

Install in reverse order of removal. Note the following

Inspect the tab -arrow- visually.

If damage can be seen on the tab, installed a new seat height adjustment handle -1-.

Make sure the tab in the seat height adjustment handle fits correctly into the notch on the lever.

Scheme 241

Remove tunnel side trim panel. Refer to TRIM, SILL SIDE .

Remove bolts -2- (quantity: 3).

Remove bracket -1- from front seat -3-. Remove any cable ties from the retaining bracket.

Install in reverse order of removal.

Turn on the ignition.

Disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the headrests. Refer to HEADRESTS WITH LOCKING MECHANISM .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Remove the springs -A through D- from the backrest frame -1-.

Scheme 242

Note. The pull-springs -A through D- can also stay engaged in the backrest frame -1- and the spring mat -2- can be disengaged directly from the pull-springs.

Tip spring mat -2- forward.

Scheme 243

Remove the spring mat -2- from the openings -arrow- in the backrest frame -1-.

Install in reverse order of removal. Note the following

Label the springs -A through D- as shown in the illustration.

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

STORAGE COMPARTMENT

The following describes the removal and installation of a power standard front seat. The procedure is similar for a manual standard front seat. Refer to STORAGE COMPARTMENT .

TRIM, SILL SIDE

Note. Removal and installation can be performed with the front seat installed.

Scheme 244

Bring seat as far up as possible.

Remove backrest adjustment wheel. Refer to BACKREST ADJUSTING WHEEL .

Remove seat height adjustment handle. Refer to SEAT HEIGHT ADJUSTMENT HANDLE .

Remove the expanding rivet -2- for the sill side trim -1-.

Open the clips -4- (quantity: 2).

Scheme 245

Unclip trim -1- on retaining bracket -3-.

Disengage trim in area of backrest adjustment wheel and seat anchor.

Remove the trim forward and up from the retaining bracket -3-.

Note. Make sure the bracket -2- and the tab -2- are not damaged when removing the trim.

Seat With Four-Way Lumbar Support

Remove the electrical connector -4- from the driver seat lumbar support adjustment switch -E176- -1-.

3 - Sill side trim

Procedure For All Manual Seat Versions

Remove sill side trim.

Install in reverse order of removal. Note the following

Note. Make sure the tab -2- is seated correctly. Make sure the sill side trim -1- is engaged correctly on the retaining bracket -3- and the locking clips -4- are closed.

Note. Make sure the wire is as close to the connector -4- as possible.

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST ADJUSTING WHEEL .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST COVER .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST FRAME TRIM .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST RELEASE BRACKET .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST RELEASE CABLE .

CONNECTING CABLE

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to CONNECTING CABLE .

DVD PLAYER RETAINING PLATE

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to DVD PLAYER RETAINING PLATE .

ENTRY ASSISTANCE RELEASE CABLE A

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to ENTRY ASSISTANCE RELEASE CABLE A .

ENTRY ASSISTANCE RELEASE CABLE B

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to ENTRY ASSISTANCE RELEASE CABLE B .

ENTRY ASSISTANCE HANDLE WITH BRACKET

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to ENTRY ASSISTANCE HANDLE WITH BRACKET .

For the correct tightening specifications, refer to ENTRY ASSISTANCE OVERVIEW .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to ENTRY ASSISTANCE TRIM .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to FOUR-WAY LUMBAR SUPPORT OVERVIEW .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to FRONT BACKREST .

For the correct tightening specifications, refer to FRONT BACKREST OVERVIEW .

HEADREST GUIDE

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to HEADREST GUIDE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to HEADRESTS WITH LOCKING MECHANISM .

LUMBAR SUPPORT ADJUSTMENT SWITCH

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH .

Removal and installation on a power Standard front seat is described here. Removal and installation of the manual Sport front seat is identical. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS .

MANUAL SPORT FRONT SEAT

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to MANUAL STANDARD FRONT SEAT .

MEMORY STOP

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to MEMORY STOP .

RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to RELEASE CABLE MOUNT LEVER AND SEAT FORWARD/BACK ADJUSTMENT SPRING .

SEAT ANGLE ADJUSTMENT HANDLE

Note. Removal and installation can be performed with the front seat installed.

Scheme 246

Remove tunnel side trim panel. Refer to TRIM, SILL SIDE .

Pry the handle -2- off the seat angle adjuster -1-.

Scheme 247

Install in reverse order of removal. Note the following

Replace the clip on the seat height adjustment handle. Note the installation position.

Make sure the seat height adjustment handle engages correctly with the clips.

1. The springs -arrows- (quantity: 2) on the clip -2- must be on the inner side of the lever -1-.

SEAT DEPTH ADJUSTER

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Remove the front seat

1. Manual Sport seat. Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Power sport seat and super sport seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Equipment level with storage compartment: remove the storage compartment. Refer to STORAGE COMPARTMENT .

Remove trim. Refer to SEAT DEPTH ADJUSTER TRIM .

Move the seat depth adjuster all the way forward -arrow-.

Scheme 248

Unclip the tabs -2- using a trim removal wedge3409.

Swivel the support with the seat cushion and seat cover -1- for the seat depth adjuster upward so that the tabs -arrow A- and -arrow B- remain unlocked.

Scheme 249

Note. The illustration shows the upholstery disengaged.

Remove the support with the seat cushion and seat cover for the seat depth adjuster upward and toward the front.

Disengage the tabs -arrow C- on the seat depth adjuster -2- and move the support with the seat cushion and seat cover upward.

Lay the support -2-, seat cushion and seat cover for the seat depth adjustment on the front seat.

Scheme 250

Note. The illustration does not show the seat pan lower frame.

Remove the cushion retaining channels -1, 3, 4- across and at the sides from the seat depth adjustor.

To do this, unclip the retaining channels -1- and -2- in the direction of the -arrow- out from the tabs -3-.

Scheme 251

Remove the bolts -1-, -2- and nuts -3- from the seat depth adjuster.

Scheme 252

Unclip the tabs -1- and -3- using a trim removal wedge3409.

Scheme 253

Remove the seat depth adjuster -2- from the lower seat frame upward and forward -arrows-.

Disengage the tabs -4- from the lower seat frame while doing this.

Remove the seat depth adjuster from the front seat.

Install in reverse order of removal. Note the following

Install a nut -3- on the seat pan side of each bolt -1, 2- to secure the bolts after installing them.

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

SEAT DEPTH ADJUSTER TRIM

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Remove the front seat

1. Manual Sport seat. Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Power sport seat and super sport seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Equipment level with storage compartment: remove the storage compartment. Refer to STORAGE COMPARTMENT .

Move the seat depth adjuster all the way forward.

Scheme 254

Unclip the tabs -arrows- on the trim -1- using a trim removal wedge3409.

Remove the trim from the seat depth adjuster.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SEAT FORWARD/BACK ADJUSTMENT HANDLE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SEAT FORWARD/BACK ADJUSTER RELEASE CABLE .

SEAT HEIGHT ADJUSTER

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SEAT HEIGHT ADJUSTER .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SEAT HEIGHT ADJUSTMENT HANDLE .

The seat position sensor removal and installation procedure is similar on all seat versions. Refer to SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION .

SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION

1. The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat.
2. The removal and installation procedure for the seat rail covers is described on the driver seat sill side seat rail. The tunnel side cover is removed and installed in a similar way. Refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover) .

SILL SIDE RETAINING BRACKET TRIM

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SILL SIDE RETAINING BRACKET TRIM .

SPRING MAT

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SPRING MAT .

Removal and installation on a power Standard front seat is described here. Removal and installation of the manual Sport front seat is identical. Refer to STORAGE COMPARTMENT .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SUPPORT PLATE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to TORSION BAR .

TORSION BAR BEARING

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to TORSION BAR BEARING .

Removal and installation is described for a manual standard front seat. Removal and installation are similar for a manual sport front seat. Refer to TRIM, SILL SIDE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to TRIM, TUNNEL SIDE .

BACKREST AND HEADREST ADJUSTMENT ACTUATOR

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to BACKREST AND HEADREST ADJUSTMENT ACTUATOR .

BACKREST ADJUSTMENT MOTOR AND SWITCH UNIT

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to BACKREST ADJUSTMENT MOTOR AND SWITCH UNIT .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to BACKREST RELEASE BRACKET .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to BACKREST RELEASE CABLE .

BRACKET FOR MEMORY SEAT ADJUSTMENT CONTROL MODULE WITH INTEGRATED SEAT VENTILATION FUNCTION

Removal and installation on a power Standard front seat is described here. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE BRACKET .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to CONNECTING CABLE .

The following describes the connector station connectors for the manual standard front seat. They are similar for the comfort front seat. Refer to CONNECTOR STATION CONNECTORS .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to DVD PLAYER RETAINING PLATE .

ENTRY ASSISTANCE BUTTON

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to ENTRY ASSISTANCE BUTTON .

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to ENTRY ASSISTANCE HANDLE WITH BRACKET .

For the correct tightening specifications, refer to ENTRY ASSISTANCE OVERVIEW .

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to ENTRY ASSISTANCE TRIM .

Special tools and workshop equipment required

1. Special Pop Rivet Pliers V.A.G 1753A
2. Drill
3. Protective Eyewear

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat. Refer to POWER STANDARD FRONT SEAT .

Attach the front seat to the fixture for seat repairVAS 6136 FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove the backrest frame trim. Refer to BACKREST FRAME TRIM .

Remove headrests. Refer to

1. «HEADRESTS WITH LOCKING MECHANISM»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__headrests-with-locking-mechanism) .
2. «POWER HEADRESTS»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Note. Lay plastic film between the seat pan cover and the backrest frame to protect against metal shavings.

Drill out rivet -2-.

Disconnect the electrical connectors -1- and -3- at lumbar support curvature and height adjustment motors.

Free up the electrical wiring harness at the four-way lumbar support -1-.

Scheme 255

Disengage the four-way lumbar support on the backrest frame -2-.

Remove the four-way lumbar support from the backrest frame.

Engage four-way lumbar support -1- on the backrest frame -2-.

Before securing rivet -4-, a plastic washer -1- must be placed between lumbar support -2- and backrest frame -3-.

Scheme 256

Rivet the four-way lumbar support frame -2- with the backrest frame -3-.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

FRONT SEAT WITH FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE

The following describes the removal on a standard power front seat. The procedure is similar for a comfort front seat. Refer to FRONT SEAT WITH FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE .

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to FRONT BACKREST .

For the correct tightening specifications, refer to FRONT BACKREST OVERVIEW .

Scheme 257

Remove backrest cover panel. Refer to BACKREST COVER .

Adjust the lumbar support to the highest curve while moving the slider -1- all the way down -arrow A-.

Note. Ignore -2-.

Disconnect the connector -1-.

Scheme 258

Carefully tilt the backrest fan -2- out of the backrest upholstery -arrow-.

Scheme 259

Install in reverse order of removal. Note the following

1. The mounting eyelets on the fan housing -1- face up and down.
2. Place the wire -2- into the gap in the backrest cushions -arrow- facing outward.

Make sure the backrest lumber support spring plate is seated correctly.

The following describes the removal and installation of a manual sport front seat. The procedure is similar for a comfort front seat. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH .

MEMORY SEAT ADJUSTMENT CONTROL MODULE WITH INTEGRATED SEAT VENTILATION FUNCTION

Removal and installation are described for the power standard front seat with a memory seat adjustment control module. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE OVERVIEW .

POWER COMFORT FRONT SEAT

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to POWER STANDARD FRONT SEAT .

POWER HEADRESTS

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to POWER HEADRESTS .

SEAT ADJUSTMENT CONTROL HEAD

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD .

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD .

SEAT ANGLE ADJUSTMENT MOTOR

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SEAT ANGLE ADJUSTMENT MOTOR .

Scheme 260

Remove the seat pan upholstery. Refer to LOWER SEAT FRAME WITHOUT SEAT DEPTH ADJUSTER, COVER AND PADDING .

Disconnect and free up the electrical connectors -2-.

Remove the bolts -1- and -3-.

Rotate the cover grille -4- in the direction of the -arrow- and remove the fan.

Install in reverse order of removal.

For the correct tightening specifications (Scheme 108)

SEAT FORWARD/BACK ADJUSTMENT MOTOR

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SEAT FORWARD/BACK ADJUSTMENT MOTOR .

SEAT HEIGHT ADJUSTMENT MOTOR

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SEAT HEIGHT ADJUSTMENT MOTOR .

The seat position sensor removal and installation procedure is similar on all seat versions. Refer to SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION .

SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION

1. The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat.
2. The removal and installation procedure for the seat rail covers is described on the driver seat sill side seat rail. Removing and installing the cover on the tunnel side is similar. Refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover) .

SEAT RAIL SPINDLE COVER

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SEAT RAIL SPINDLE COVER .

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to SILL SIDE RETAINING BRACKET TRIM .

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to STORAGE COMPARTMENT .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to SUPPORT PLATE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to TORSION BAR .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to TORSION BAR BEARING .

TRIM

The following describes the removal and installation of a manual sport front seat. The procedure is similar for a comfort front seat. Refer to SEAT DEPTH ADJUSTER .

The following describes the removal and installation of a power standard front seat. The procedure is similar for a comfort front seat. Refer to TRIM, SILL SIDE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a comfort front seat. Refer to TRIM, TUNNEL SIDE .

Remove backrest cover panel. Refer to BACKREST COVER .

Disconnect and free up the electrical connector -1-.

Scheme 261

Carefully tilt fan -2- out of the backrest upholstery -arrow-.

Install in reverse order of removal. Note the following

Upper fan installation position

1. The electrical wire faces down.
2. The securing eyes on the fan housing face to the side.

Special tools and workshop equipment required

1. Locking compound

Remove the front seat

1. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
2. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Remove the tunnel side trim TRIM, TUNNEL SIDE .

Remove the sill side trim TRIM, SILL SIDE .

Remove backrest cover panel. Refer to BACKREST COVER .

Make a permanent mark (a line) on the left and right side -arrow A- on the backrest frame -2- on the front edge -arrow B- of the anchor -1-.

Scheme 262

Remove the nut -5- from the shaft -3-.

Remove the upholstery on the backrest. Refer to BACKREST COVER AND UPHOLSTERY .

Scheme 263

Note. The switch unit must be removed to remove the backrest adjustment motor -7- but it does not need to be replaced.

Remove the switch unit. see scheme 248

Remove the shaft -3- in the direction of the -arrow- from the backrest frame -1-.

Disconnect the electrical connector -6- on the backrest adjustment motor -7-.

Remove the bolt -2-.

Remove the bracket adjustment motor -7- from the bracket -5-.

Remove the shaft -5- in the direction of the -arrow- from the switch unit -2-.

Disconnect the multi-pin connector -5-.

Scheme 264

Remove the bolts -2-.

Remove the switch unit -4- from the backrest frame -1-.

Unclip the locking bushing -2- at the spindle -1-.

Scheme 265

3 - Switch unit

Clean the shaft threads -3- before installing, for example using a thread tap.

Check the position of the backrest frame -2- and the anchor -1- on the left and right side.

1. The left and right backrest frames must be in the position marked before removal -A and B arrows -.

If the left and right backrest frames are not in the position marked before removal, correct their position accordingly.

Scheme 266

Position the backrest adjustment motor -1- on the bracket -3-.

Replace the bolt -4-. Coat it with locking compound fluid and tighten it by hand.

1. It must still be possible to move the backrest adjustment motor.

First slide the shaft through the anchor (tunnel side) as far as the stop -2- in the backrest adjustment motor.

Check whether the profile of the inserted shaft and mount -2- in the backrest adjustment motor align.

1. If the shaft profile and the mount in the backrest adjustment motor align

Slide the shaft through the mount in the backrest adjustment motor up to approximately the middle of the seat.

1. If the shaft profile and the mount in the backrest adjustment motor do not align

Connect an external power source (12 Volt) to the backrest adjustment motor -1-.

Rotate mount -2- until it aligns with the shaft profile.

Slide the shaft through the mount in the backrest adjustment motor up to approximately the middle of the seat.

Install the switch unit. see scheme 253

Insert the switch unit -4- so the guide -arrow- covers the backrest frame -1- correctly.

Tighten the switch unit -4- to the tightening specification.

Connect the socket -5- to the switch unit multi-pin connector.

Position the locking bushing -4- on the shaft -3-.

Scheme 267

Note. The catches -arrow- (quantity: 4) on the locking bushing must face toward the switch unit -1-. When sliding the shaft in, do not engage the locking bushing -4- with the spindle -2-. Only engage the locking bushing -4- after adjusting the switch unit with the spindle -2-.

Backrest Adjustment Motor and Switch Unit, Installing

Slide the shaft -3- through the spindle -2- and the anchor (sill side) as far as the stop.

Apply locking compound to the threaded section of the shaft.

Install the new nut -5- on the shaft -3-.

Tighten the bolt -5- to the specified torque.

Bolt the backrest adjustment motor on the bracket -3- and tighten it to the tightening specification.

Adjust the switch unit micro switch -2-. Refer to SWITCH UNIT MICRO-SWITCH, ADJUSTING .

After adjusting the switch unit, slide the locking bushing -4- onto the spindle -3-.

Engage the locking bushing -4- with the spindle -3-.

Check the switch unit. Refer to SWITCH UNIT MICRO-SWITCH, CHECKING .

Installation is in reverse order of removal, noting the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Perform the following tests after removing and installing the backrest adjustment motor and the switch unit

1. Calibration, performing, refer to «SWITCH UNIT, CALIBRATING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__switch-unit-calibrating) .
2. Function test, performing, refer to «FUNCTION TEST, PERFORMING»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe)

The backrest and headrest adjustment actuator consists of

1. Driver backrest adjustment switch -E96- or front passenger backrest adjustment switch -E98
2. Driver headrest adjustment button -E155- or front passenger headrest adjustment switch -E170-.

Note. The backrest and headrest adjustment actuator can be removed and installed with the front seat installed.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 268

Pry the actuator -1- out of the retainer using the trim removal wedge3409.

Install in reverse order of removal.

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST RELEASE BRACKET .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to BACKREST RELEASE CABLE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to CONNECTING CABLE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to DVD PLAYER RETAINING PLATE .

Scheme 269

Remove the entry assistance trim. Refer to ENTRY ASSISTANCE TRIM .

Disconnect the electrical connector -1- on the entry assistance button -2-.

Unclip the catches -arrows- at the tabs.

Scheme 270

Tilt the entry assistance button -2- out of the tabs in the direction of the -arrows- and disengage it -arrow-.

Remove the entry assistance button from the trim -1-.

Note. The entry assistance button is not designed to be disassembled further.

Install in reverse order of removal.

Note. Removal and installation can be performed with the front seat installed.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 271

Press the handle -arrow B- forward as far as the stop and hold it in that position.

Press the tab -arrow A- off the catch -arrow C- in the direction of the -arrow- using a trim removal wedge 3409.

Perform the same step on the opposite side of the trim -1-.

Tilt the trim -1- upward diagonally and remove from the handle with the bracket -2-.

Disengage the rear trim catch from the handle with bracket.

Remove the trim -1- from the handle with bracket -2- as far as the length of the entry assistance button wire allows.

Disconnect the electrical connector -1- on the entry assistance button -2-.

Remove the trim -3- with the entry assistance button.

Remove the entry assistance button. Refer to ENTRY ASSISTANCE BUTTON .

Install the entry assistance button.

Connect the connector to the entry assistance button.

Note. Make sure the connectors are installed all the way in and are secure.

First engage the rear trim retaining tab in the handle with bracket.

Make sure the trim engages correctly in the handle with bracket.

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to ENTRY ASSISTANCE HANDLE WITH BRACKET .

For the correct tightening specifications, refer to ENTRY ASSISTANCE OVERVIEW .

Note. The following describes removing and installing the driver side. The procedure for the front passenger seat is similar.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Turn on the ignition.

Disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
2. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat Repair VAS 6136 .

Remove the tunnel side trim. Refer to TRIM, TUNNEL SIDE

Remove the sill side trim. Refer to TRIM, SILL SIDE .

Using the trim removal wedge 3409, unclip the wiring harness -1- in the corrugated tube -2- at the bottom side of the seat and remove the wiring bracket.

Disconnect all the wiring harness connectors to the backrest and free up the disconnected wiring harnesses.

Note. The wiring harness between the connection point and the side airbag is continuous.

Remove the bolts -2-.

Scheme 272

Tip backrest -3- forward onto seat pan -1-.

Press the seat pan upholstery to the side and carefully remove side airbag wiring harness -4- and, if necessary, all additional wiring harnesses -5- to the backrest (depending on equipment) from the seat pan.

Remove backrest.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Test The Seat Forward/Back Adjustment Motor -V28- / -V31- or Control Module(s) -J136- / -J521

Move the seat as far up as possible.

Remove tunnel side trim panel. Refer to TRIM, SILL SIDE .

Note. Check electrical and electronic components and wires before removing seat further to avoid unnecessary repair costs.

Perform the following tests

1. Check the fuse. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.
2. Check the voltage at the connector station and perform fault finding if necessary. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.
3. Check the voltage to the control module. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.
4. Check the voltage to the seat forward/back adjustment motor -V288-. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.

Replace the fuse if faulty. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.

If there is no voltage at the connector station, repair or replace the wire. Refer the appriopriate SYSTEM WIRING DUAGRAMS information.

Replace the seat pan lower frame together with seat forward/back adjustment motor. Refer to SEAT PAN .

Replace the memory seat/steering column adjustment control module -J136- /front passenger memory seat control module -J521- if faulty. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .

Removing A Faulty Seat Forward/Back Adjustment Motor -V28- / -V31

Scheme 273

Turn on the ignition.

Turn on the ignition and disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the bolts -3- (quantity: 4) on both sides.

I - Seat forward/back adjustment motor, threaded connection on sill side.

II - Seat forward/back adjustment motor, threaded connection on tunnel side.

Note. To remove the tunnel side bolts, reach under the seat from the front.

Disconnect the connector on the seat forward/back adjustment motor.

Move seat until bolts -1- (quantity: 4) are visible.

Scheme 274

Remove the bolts -1-.

Disconnect the harness connectors at the connector station. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Connect Airbag Adapter VAS 6281. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Raise the front seat with a 2nd technician and remove it from the vehicle.

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Separate the lower frame -2- from the upper frame -1-. Refer to SEAT PAN .

Replace the lower seat pan frame -2- with seat forward/back adjustment motor SEAT PAN .

Removing A Faulty Control Module -J136- / -J521

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Disconnect the connector on the seat forward/back adjustment motor.

Connect the seat forward/back adjustment motor to an external power source and move the seat forward or back until the bolts -1- (quantity: 4) are visible.

Remove the bolts -1-.

Disconnect the harness connectors at the connector station. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Connect Airbag Adapter VAS 6281. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Raise the front seat with a 2nd technician and remove it from the vehicle.

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Replace control module -J136- / -J521-. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .

Install in reverse order of removal. Note the following

Remove the airbag adapterVAS 6281 only after installing the front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Connect the connectors to the connectors of the connector station in the floor. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnosis tester.

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH .

Lumbar Support Height Adjustment Motor, Removing

Scheme 275

Remove backrest cover panel. Refer to BACKREST COVER .

Disconnect the connector -1-.

Release the bracket -2- with a screwdriver -arrow-.

Remove the lumbar support height adjustment motor -3-.

Install in reverse order of removal.

Lumbar Support Curvature Adjustment Motor, Removing and Installing

The lumbar support curvature adjustment motor is removed in a similar way as the lumbar support height adjustment motor.

MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
2. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Disconnect the connectors -2 through 5- on the control module -1-.

Scheme 276

Note. The number of connectors may vary depending on the equipment. The description shows the version with the most equipment.

Unclip the tabs -arrows- using the trim removal wedge3409.

Carefully tilt the control module -1- in the direction of -arrow A- out of the retainers -2-.

Scheme 277

Slide the control module in the direction of -arrow B-.

Disengage the control module hooks -arrow- from the bracket.

Remove the control module from the bracket.

Install in reverse order of removal. Note the following

Note. Make sure the memory seat adjustment control module engages audibly in the retainer. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Remove the memory seat adjustment/steering column adjustment control module. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .

Press the pin -2- toward the upholster and out of the clip -arrow A- on the bracket -1-, for example, using an upholstery needle.

Scheme 278

Remove the pin -2- from the seat pan.

Remove the bracket support base -2- from the seat pan upper frame.

Scheme 279

Unclip the clip -arrow A- at the seat pan upper frame -1-.

Disengage the retaining tabs -arrow B- (quantity: 2).

Carefully remove the bracket in the direction of the -arrow- from the seat pan.

Remove the bracket from the seat pan.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Note. The headrests can be removed with the front seats installed. The release button is located on the outer left of the driver seat and inner left of the passenger seat.

Scheme 280

Remove backrest cover panel. Refer to BACKREST COVER .

Unclip the cable tie clip -3- on the backrest frame -1-.

Disconnect the connector -2-.

Reach under the backrest cover and find the release button pressure point -3-.

Press the release button forward in the direction of the -arrow-.

Hold release button -3- down in this position.

Pull headrest -2- up out of guides -1- and -4-.

When removing the headrest -1-, guide the wire with the connector -4- through the headrest guide -3-.

Scheme 281

2 - Backrest frame

Install in reverse order of removal. Note the following

When installing the headrest, the release button -3- must not be pressed in.

POWER STANDARD FRONT SEAT

Note. The following describes removing and installing the driver side. The procedure for the front passenger seat is similar.

Bring seat into service position. Refer to FRONT SEATS SERVICE POSITION, SETTING .

Remove front bolts -1- (quantity: 2).

Operate seat forward/back adjuster and move the seat -2- as far forward as possible.

Remove rear bolts -1- (quantity: 2).

3 - Rear console

4 - Front console

Turn on the ignition.

Disconnect the battery ground (GND) cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Disconnect the harness connectors. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING on the connector station in the floor.

Connect Airbag AdapterVAS 6281. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Raise the front seat with a 2nd technician and remove it from the vehicle.

Install in reverse order of removal. Note the following

Remove the airbag adapter VAS 6281 only after installing the front seat. Refer to AIRBAG ADAPTER VAS 6281, CONNECTING AND DISCONNECTING .

Note. Make sure the connectors are installed all the way in and are secure.

Connect the connectors to the connectors of the connector station in the floor. Refer to HARNESS CONNECTORS, DISCONNECTING AND CONNECTING .

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Scheme 282

Remove the sill side trim. Refer to TRIM, SILL SIDE .

Disengage the wire from the bracket -6-.

Disconnect the connector -7-.

Remove the backrest and headrest adjustment control head -5-. Refer to BACKREST AND HEADREST ADJUSTMENT ACTUATOR .

Remove the seat adjustment control head -4-. Refer to SEAT ADJUSTMENT CONTROL HEAD .

Remove the bolts -3-.

Remove the control head -1- from the sill side trim -2-.

Install in reverse order of removal.

The seat adjustment controls consist of

1. Driver seat forward/back adjustment switch -E363- or front passenger seat forward/back adjustment switch -E64
2. Driver seat angle adjustment switch -E222- or front passenger seat angle adjustment button -E334
3. Driver seat height adjustment switch -E364- or front passenger seat height adjustment switch -E365

Note. The seat adjustment actuator can be removed and installed with the front seat installed.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 283

Pry the seat adjustment actuator -1- from the retainer using a trim removal wedge 3409.

Install in reverse order of removal.

Turn on the ignition.

Turn on the ignition and disconnect the ground cable from the battery. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Remove the front seat

1. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
2. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Disconnect electrical harness connector -3- on seat angle adjustment motor -4-.

Scheme 284

Remove the bolt -2-.

5 - Adjusting spindle, preadjusted by the manufacturer

Do not damage the bushing -1- inserted in the bearing area -2- when removing the bolt.

Scheme 285

Remove the bolts -1-.

Remove the seat angle adjustment motor from the front seat.

Clean the threaded bolt holes for self-locking nuts, for example using a thread tap.

Replace all self-locking bolts.

Do not damage bushing -1- when inserting the bolt.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Note. The seat forward/back adjustment motor can only be replaced together with the seat pan lower frame.

Remove the front seat

1. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
2. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repair VAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Note. The upper and lower seat pan frames can only be separated and connected when the upholstery is removed. The seat position sensor must be installed in the new seat pan lower frame.

Remove the seat position sensor. Refer to

1. «SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__seat-position-sensor-with-seat-occupied) .
2. «SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION»(/audi/a5/i-2007-2011/remont/airbag/#passenger-protection-airbags-seat-belts-coupe__seat-position-sensor-with-seat-occupied) .

Separate the seat pan upper frame from the lower frame. Refer to UPPER AND LOWER FRAMES, SEPARATING .

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

Remove the tunnel side trim. Refer to TRIM, TUNNEL SIDE

Remove the sill side trim. Refer to TRIM, SILL SIDE .

Disconnect electrical harness connector -1- on seat height adjustment motor -2-.

Scheme 286

Release the tension in the torsion bar. Refer to TORSION BAR .

Scheme 287

Remove bolt -2- on the seat height adjustment motor adjusting spindle -1-.

Remove the bolt -2-.

Scheme 288

1 - Seat angle adjustment motor adjusting spindle (preadjusted by the manufacturer)

Do not damage the bushing -1- inserted in the bearing area -2- when removing the bolt.

Tilt the seat pan upper frame -1- up as far as possible.

Scheme 289

Support the seat pan upper frame with a suitable wood block -6- on the fixture for seat repair VAS 6136 -item 2-.

Remove bolts -3- (quantity: 2).

Remove bracket -5- with seat height adjustment motor -4- from the seat pan.

Remove the bolts -1-.

Scheme 290

Separate bracket -2- and seat height adjustment motor -3-.

Clean the threaded bolt holes for self-locking nuts, for example using a thread tap.

Replace all self-locking bolts.

Insert the bolt -2-.

Do not damage bushing -1- when inserting the bolt.

Do not damage the bushing -3- when inserting the bolt -2-.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. Refer to [For engine(s) CAUA,CAEB,CALA] Removal and Installation .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

The seat position sensor removal and installation procedure is similar on all seat versions. Refer to SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR BELT FASTENING DETECTION .

SEAT POSITION SENSOR, WITH SEAT OCCUPIED SENSOR FOR PASSENGER AIRBAG DEACTIVATION

1. The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat.
2. The removal and installation procedure for the seat rail covers is described on the driver seat sill side seat rail. Removing and installing the cover on the tunnel side is similar. Refer to «SEAT RAIL COVER»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__seat-rail-cover) .

Note. The removal and installation procedure is described on the basis of the driver seat sill side seat rail. For the sake of clarity, the figure does not show the surrounding area.

Special tools and workshop equipment required

1. Trim Removal Wedge 3409

Scheme 291

Proceed as follows

Bring headrest into lowest lock position.

Move seat as far back and up as possible.

Pry the spindle cover -1- from the seat rail cover -2- and seat forward/back adjustment spindle using the trim removal wedge3409.

Install in reverse order of removal. Note the following

Make sure the spindle cover is engaged correctly.

Scheme 292

Remove tunnel side trim panel TRIM, SILL SIDE .

Remove bolts -3- (quantity: 4).

Remove bracket -1- from front seat -2-. Remove any cable ties from the retaining bracket.

Install in reverse order of removal.

Remove the front seat

1. Standard seat and Sport seat (manual). Refer to «MANUAL STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__manual-standard-front-seat) .
2. Standard seat, Sport seat (power) and Comfort seat. Refer to «POWER STANDARD FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__power-standard-front-seat) .
3. Super Sport seat. Refer to «SUPER SPORT FRONT SEAT»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe__super-sport-front-seat) .

Attach the front seat to the fixture for seat repairVAS 6136. Refer to FRONT SEAT, INSTALLING ON THE Fixture for Seat RepairVAS 6136 .

Open the storage compartment -1- and remove the bolts -2-.

Scheme 293

Release the tab -arrow- on the storage compartment -2- and remove the storage compartment downward from the sill side trim -1-.

Scheme 294

Push the storage compartment -1- in the direction of the -arrow- and disengage the retainer -lower arrow- from the upper seat frame -2-.

Scheme 295

Remove the storage compartment from the seat pan upper frame.

Installation is performed in the reverse of removal, but note the following

Note. Make sure the connectors are installed all the way in and are secure.

Connect the battery ground (GND) cable with the ignition turned on. .

Note. If the airbag indicator lamp -K75- indicates a fault after installation, the DTC memory must be checked, deleted and checked again using the vehicle diagnostic tester.

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to SUPPORT PLATE .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to TORSION BAR .

The following describes the removal and installation of a manual standard front seat. The procedure is similar for a power standard front seat. Refer to TORSION BAR BEARING .

Note. Removal and installation can be performed with the front seat installed.

Scheme 296

Bring seat as far up as possible.

Remove the expanding rivet -2- from the sill side trim -1-.

Open the clip -3-.

Scheme 297

Unclip trim -1- on retaining bracket -2-.

Disengage trim in seat/backrest stop area.

Note. Ensure bracket -4- is not damaged when removing trim.

Release the catch -arrow- on the storage compartment -2- and remove the sill side trim -1- upward.

Pull the sill side trim slightly forward off the bracket and remove it upward.

Pull the trim as far up from the retaining bracket as the electrical wires allow.

Disconnect the connectors

Scheme 298

1. Seat adjustment control head assembly, driver seat adjustment control head -E470- /front passenger seat adjustment control head -E471
2. Lumbar support adjustment switch -E176- / -E177

Free up electrical wire on the bracket -3-.

Remove sill side trim.

Install in reverse order of removal. Note the following

Note. Make sure the connectors are installed all the way in and are secure. Make sure the side member trim is engaged correctly on the retaining bracket and the lock clip is closed. Make sure that the wires are as close as possible to the connectors.

1. Removal and installation can only be performed with the front seat removed.
2. The following describes the removal and installation of a manual standard front seat. The procedure is similar for the power standard front seat. Refer to «TRIM, TUNNEL SIDE»(/audi/a5/i-2007-2011/remont/seats/#seat-frames-coupe) .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to BACKREST ADJUSTMENT MOTOR AND SWITCH UNIT .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to BACKREST AND HEADREST ADJUSTMENT ACTUATOR .

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to BACKREST RELEASE CABLE .

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to BACKREST RELEASE BRACKET .

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to CONNECTING CABLE .

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to DVD PLAYER RETAINING PLATE .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to ENTRY ASSISTANCE BUTTON .

Removal and installation is described for a manual standard front seat. It is identical on a power sport front seat. Refer to ENTRY ASSISTANCE HANDLE WITH BRACKET .

For the correct tightening specifications, refer to ENTRY ASSISTANCE OVERVIEW .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to ENTRY ASSISTANCE TRIM .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to FRONT BACKREST .

For the correct tightening specifications, refer to FRONT BACKREST OVERVIEW .

The following describes the removal of a power standard front seat. The procedure is similar for a comfort front seat. Refer to FRONT SEAT WITH FAULTY SEAT FORWARD/BACK ADJUSTMENT MOTOR OR CONTROL MODULE .

Removal and installation is described for a manual sport front seat is described here. It is identical on a power sport front seat. Refer to LUMBAR SUPPORT ADJUSTMENT SWITCH .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to LUMBAR SUPPORT CURVATURE AND HEIGHT ADJUSTMENT MOTORS .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE BRACKET .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to POWER HEADRESTS .

POWER SPORT FRONT SEAT

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to POWER STANDARD FRONT SEAT .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to SEAT ADJUSTMENT CONTROL HEAD .

Removal and installation on a power Standard front seat is described here. It is identical on a power sport front seat. Refer to SEAT ANGLE ADJUSTMENT MOTOR .

Removal and installation is described for a manual sport front seat is described here. It is identical on a power sport front seat. Refer to SEAT DEPTH ADJUSTER .
