Front Doors, Central Locking System (coupe) Audi A5 I

Scheme 148

1. Bolt 32 Nm
2. Bolt 8 Nm
3. Cover For the door arrester
4. Door arrester Removing and Installing, refer to «FRONT DOOR»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
5. Bolt 25 Nm
6. Cover Install on the threaded pin.
7. Threaded pin 30 Nm
8. Upper door hinge
9. Bolt 32 Nm
10. Bolt NOTE: The bolt is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category. 45 Nm
11. Bolt 8 Nm
12. Seal For the door arrester
13. Bolt 32 Nm
14. Bolt NOTE: The bolt is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category. 45 Nm
15. Bolt 32 Nm
16. Bottom door hinge
17. Threaded pin 25 Nm
18. Cover Install on the threaded pin.

Scheme 149

1. Clip for the door seal and inner window shaft strip Cannot be replaced separately.
2. Outer door seal with inside window shaft strip and exterior mirror seal Removing and Installing, refer to «DOOR SEALS»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-seals) .
3. Door
4. Outer window shaft strip Removing and Installing, refer to «OUTER WINDOW SHAFT STRIP»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__outer-window-shaft-strip) .
5. Exterior rearview mirror

DOOR, ADJUSTING

Special tools and workshop equipment required

Scheme 150

1. Adjustment gauge 3371

Preliminary work for adjusting lengthwise and toward the vehicle center

Driver side

Remove the instrument panel cover on the driver side. Refer to REMOVAL AND INSTALLATION .

Remove the lower A-pillar trim. Refer to REMOVAL AND INSTALLATION .

Remove the driver side relay carrier mount REMOVAL AND INSTALLATION .

Passenger side

Remove the glove compartment. Refer to REMOVAL AND INSTALLATION .

Procedure for both sides

Remove the A-pillar connector station REMOVAL AND INSTALLATION .

1. Gap dimensions, refer to «DOOR, ADJUSTING»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-adjusting) .

1. Adjustment in longitudinal direction

Scheme 151

Loosen the bolts -B arrows- on the top and bottom of the hinge and on the A-pillar -item 1-.

Adjust the door -2- lengthwise.

Tighten the bolts -B arrows-.

1. Tightening specifications, refer to «FRONT DOOR ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

2. Adjustment to center of vehicle

Note. The bolt -A- is a fitting bolt so it is generally not necessary to adjust the door using it. If it is necessary to make an adjustment using these bolts, the bolt can be replaced with one of the same length and strength category.

Loosen the bolts -A arrows- on the top and bottom of the hinge.

Adjust the door -2- lengthwise.

Tighten the bolts -A arrows-.

1. Tightening specifications, refer to «FRONT DOOR ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Scheme 152

Note. The striker pin backing must be position with the pins -arrows- exactly in the hole. The striker pins must be sheared off cleanly after sliding the striker pin.

Loosen the bolts -2-.

Slide the striker pin -1- until the door is flush with the body contours.

Note. When adjusting the striker pin, move it only toward the center of the vehicle. Do not adjust the door height using the striker pin because the door lock will be damaged.

Striker pin must align in door lock center for correct adjustment.

Tighten the bolts -2-.

1. Tightening specifications, refer to «DOOR LOCK AND STRIKER PIN ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Scheme 153

1. Door window to the side window Flush -a - = +/- 1.0 mm Parallel dimension = 1.0 mm -1- Door window -2- Side window Adjusting, refer to «DOOR WINDOW, ADJUSTING»(/audi/a5/i-2007-2011/remont/windows/#glass-window-regulators-coupe__door-window-adjusting)
2. Door to the rear side panel Gap dimension -b- = 3.4 +/- 0, 5 mm Flush = +/- 0.5mm Parallel dimension = 1.0 mm -3- Door -4- Side panel Adjusting, refer to «DOOR, ADJUSTING»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-adjusting)
3. Door to the sill panel trim Gap dimension -c- = 5.0 +/- 0.5 mm Flush = +/- 1.0 mm -3- Door -5- Sill Panel Trim Adjusting, refer to «DOOR, ADJUSTING»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-adjusting)
4. Door to the front side panel Gap dimension -d- = 3.5 +/- 0.5 mm Flush = +/- 0.5mm Parallel dimension = 1.0 mm -3- Door -6- Front side panel Adjusting, refer to «DOOR, ADJUSTING»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-adjusting)

Scheme 154

1. Inner door panel cover Removing and Installing, refer to «INNER DOOR PANEL COVER»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
2. Door opener actuating link Removing and Installing, refer to «INTERIOR DOOR MECHANISM OPERATING CABLE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
3. Grommet Cannot be replaced separately.
4. Bolt 25 Nm
5. Hood catch Removing and Installing, refer to «STRIKER PIN»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
6. Bolt 19 Nm
7. Door lock CAUTION: There is a risk of malfunctions. The door lock must be removed and installed together with the bracket to prevent overbending the cable when disengaging and engaging it. The cable must be disconnected from/attached to lever on the door lock outside of the door. Removing and Installing, refer to «DOOR LOCK»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-lock) .
8. Door lock cable

Scheme 155

Remove the door trim panel. Refer to. Refer to REMOVAL AND INSTALLATION .

Remove the wiring harness -5- from the bracket -4-.

Remove the inner door panel cover -3- beginning at the top -arrow-.

Disengage the rubber grommet -1- for the inside door release mechanism cable -2- from the inner door panel cover.

Installing

Install in reverse order of removal. Note the following

Remove the inner door panel cover.

1. The inner door panel cover must be flush.

Scheme 156

1. Outside door handle sensor for vehicles with the "keyless entry system". Removing and Installing, refer to. Refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe) .
2. Outer door handle trim For vehicles without the "keyless entry system" Removing and Installing, refer to «OUTER DOOR HANDLE TRIM»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__outer-door-handle-trim) .
3. Bolt 2.5 Nm
4. Front backing Removing and Installing, refer to «OUTER DOOR HANDLE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
5. Actuating link for the door lock Removing and Installing, refer to «DOOR LOCK ACTUATING LINK»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__door-lock-actuating-link) .
6. Door lock
7. Bolt Tightening specifications, refer to item 6
8. Guide For lock cylinder Removing and Installing, refer to «LOCK CYLINDER GUIDE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
9. Bracket Removing and Installing, refer to «BRACKET»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe__bracket) .
10. Bracket For lock cylinder with clamping screw Tightening specification 2.5 Nm.
11. Rear backing Removing and Installing, refer to «OUTER DOOR HANDLE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
12. Lock cylinder for the driver door Removing and Installing, refer to «LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
13. Cover Driver side: For lock cylinder Passenger side: Closed version Removing and Installing, refer to «LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
14. Housing instead of the lock cylinder for the passenger door Removing and Installing, refer to «LOCK CYLINDER»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
15. Outside door handle Removing and Installing, refer to «OUTER DOOR HANDLE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Scheme 157

1. Sealing plugs
2. Nut 9 Nm
3. Lower double-bolt for adjusting the window regulator
4. Window Regulator Removing and Installing, refer to «WINDOW REGULATOR»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) . Adjusting, refer to «DOOR WINDOW, ADJUSTING»(/audi/a5/i-2007-2011/remont/windows/#glass-window-regulators-coupe__door-window-adjusting) .
5. Upper double bolt for adjusting the window regulator
6. Clip
7. Door window Removing and Installing, refer to «DOOR WINDOW»(/audi/a5/i-2007-2011/remont/windows/#glass-window-regulators-coupe) . Adjusting, refer to «DOOR WINDOW, ADJUSTING»(/audi/a5/i-2007-2011/remont/windows/#glass-window-regulators-coupe__door-window-adjusting)
8. Door
9. Nut 9 Nm
10. Sealing plugs
11. Window regulator motor Removing and Installing, refer to «WINDOW REGULATOR MOTOR»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
12. Bolt Quantity: 3 3.5 Nm
13. Inside door release mechanism cable
14. Cover Clipped into the door Removing and Installing, refer to «INNER DOOR PANEL COVER»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .
15. Nut 9 Nm
16. Sealing plugs
17. Nut 9 Nm

CENTRAL LOCKING, SERVICING

Note. Central locking functions electronically. The adjusters in the doors are integrated inside the door lock and have 2 motors. The adjusters cannot be replaced separately. The first motor locks the door and the second motor locks the interior door mechanism (Safe function). The door can no longer be opened from the inside. The central locking control module will unlock any locked doors if there is a crash and the air bag deploys. The central locking control module is located inside the right rear side panel.

Hood Switch, Safe Indicator Lamp, Driver And Front Passenger Door Control Module, Comfort System Central Control Module

Scheme 158

1. Driver door control module -J386- Removing and Installing, refer to «DRIVER DOOR AND FRONT PASSENGER DOOR CONTROL MODULES J386/ J387»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe)
2. Front passenger door control module -J387- Removing and Installing, refer to «DRIVER DOOR AND FRONT PASSENGER DOOR CONTROL MODULES J386/ J387»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe)
3. Vehicle positioning system interface control module -J843- Only for Sportback
4. Cover For comfort system central control module -J393- 5-door vehicles
5. Comfort system central control module -J393- 5-door vehicles Removing and installing, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring-coupe)
6. Mounting bracket For control modules 5-door vehicles
7. Comfort system central control module -J393- 2-door vehicles Removing and installing, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/wiring-system-data-link-connectors-pwr-dist-grnd-dist/#wiring-coupe)
8. Mounting bracket For control modules 2-door vehicles
9. Mounting bracket For control modules 2-door vehicles
10. Vehicle positioning system interface control module -J843- 2-door vehicles Removing and Installing, refer to «VEHICLE POSITIONING SYSTEM INTERFACE CONTROL MODULE J843, COUPE»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe)
11. Central Locking -SAFE- Indicator Lamp -K133- Removing and Installing, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)

Contact Switch In The Lock Cylinder For The Rear Lid, Rear Lid Central Locking System Motor, Anti-Theft Alarm System Sensor, Fuel Tank Lid Unlock Motor

Scheme 159

1. Engine hood contact switch -F266- Hood Latch, Removing and Installing. Refer to «HOOD ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/exterior-body-panels/#hood-lids-coupe)
2. Fuel filler door unlock motor -V155- Removing and Installing, refer to «FUEL FILLER DOOR UNLOCK MOTOR V155»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe)
3. Rear lid lock With the rear lid central locking system motor -V53- /rear lid alarm switch -F123-, and cannot be replaced separately. Assembly Overview, refer to «REAR LID»(/audi/a5/i-2007-2011/remont/exterior-body-panels/#hood-lids-coupe)
4. Rear lid lock cylinder unlock button -F248- Integrated inside the handle strip, cannot be replaced separately
5. Anti-Theft Alarm System Sensor -G578- Removing and installing, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#interior-lights-switches-coupe)
6. Front interior monitoring individual sensor Can only be removed and installed together with the anti-theft alarm system sensor -G578
7. Interior light/front reading light

Scheme 160

Tighten the bolts -arrow- to 2 Nm.

Scheme 161

Proceed as follows

Disconnect the door connector on the A-pillar. Refer to REMOVAL AND INSTALLATION .

Remove the door arrester bolt -2-.

Remove the cover caps -1- and -3- from the stud bolts.

Remove the stud bolts -4- on the upper and lower door hinge.

Carefully remove the door upward out of the door hinges.

INSTALLING

1. Tightening specifications, refer to «FRONT DOOR ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Note. Do not make any adjustments after installing the door.

Scheme 162

Move the door window into the "closed" position.

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the lower speaker REMOVAL AND INSTALLATION .

Remove the door arrester bolt -arrow-.

Remove the door arrester seal -1- on the door opening.

Scheme 163

Remove the bolt -arrows- and remove the door arrester -2- inward.

Pull the rubber grommet -1- on the door arrester to the side slightly -A arrows-.

Scheme 164

Remove the rubber grommet from the door arrester -2- -arrow B-.

DOOR ARRESTER, INSTALLING

1. Tightening specifications, refer to «FRONT DOOR ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Install the lower speaker. Refer to REMOVAL AND INSTALLATION .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

OUTER WINDOW SHAFT STRIP

Special tools and workshop equipment required

Scheme 165

1. Removal hook T40219

REMOVING

Remove the exterior mirror. Refer to EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009 .

Open the door window completely.

Before the window shaft strip -1- can be removed, first disconnect it from the door hooks (quantity: 5) -arrows- -2-.

Scheme 166

Insert the removal hook T40219 between the door window and the window shaft strip near the B-pillar.

Scheme 167

Slide the removal hook T40219 forward on the B-pillar starting at the specified dimensions up to the first catch and release the window shaft strip on the side in direction of arrow.

Scheme 168

Move the removal hook T40219 to the next catch and release the window shaft strip.

Note. The measurements refer from the end of the window shaft strip to the B-pillar.

1. Dimension -a- = 40 mm
2. Dimension -b- = 260 mm
3. Dimension -c- = 500 mm
4. Dimension -d- = 740 mm
5. Dimension -e- = 960 mm

Release the window shaft strip -2- completely in steps and then pull it upward off the door flange -1-.

Scheme 169

Install in reverse order of removal. Note the following

Beginning at the A-pillar, press the window shaft strip completely into the retaining hooks in the door.

Install exterior mirror. Refer to EXTERIOR MIRROR - VEHICLES THROUGH MAY 2009 .

DOOR SEALS

Special tools and workshop equipment required

Scheme 170

Scheme 171

1. Roller 3356
2. Adhesive strip remover VAS 6349
3. Adjustment gauge 3371
4. Template T40038 /8

Scheme 172

1. Lower door seal Before removing, remove sill panel trim and A-pillar trim panel. Refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) . Remove the rear side trim panel near the door seal, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) -- Remove the lower door seal from the body flange and under the upper door seal. -- When installing the front and rear door seal, first slide it under the upper door seal and then press it onto the body flange.
2. Upper door seal Loosen the rear side trim panel and B-pillar trim near the door seal, i.e. unclip. Refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) . Remove the top of the A-pillar. Refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) . -- Remove the upper door seal on the A-pillar and B-pillar, then pull it off the body flange.
3. Sill panel cover Removed, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) .
4. Headliner Pull downward around the upper door seal
5. Upper B-pillar Removed, refer to «REMOVAL AND INSTALLATION»(/audi/a5/i-2007-2011/remont/exteriorinterior-trim/#interior-trim-coupe) .

Scheme 173

Proceed as follows

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the door window. Refer to DOOR WINDOW .

Remove the exterior mirror. Refer to EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009 .

Remove the outer window shaft strip -3- OUTER WINDOW SHAFT STRIP .

Remove the door shell cover INNER DOOR PANEL COVER .

Remove the bass speaker REMOVAL AND INSTALLATION .

Remove the retaining studs -1, 2 and 4- from the door shell.

Reach through the openings and carefully press the retaining springs -arrows- in the door seal and inner window shaft strip clips -5- from inside to outside.

Remove the door seal and inner window shaft strip -1- all around -arrow A-.

Scheme 174

Remove the retaining studs from the door shell in the exterior mirror area.

Remove the window guide wires -4- from the window guide.

Remove the exterior mirror housing -2- upward from the door shell -3- -arrow B-.

Scheme 175

Install in reverse order of removal. Note the following

Install the door seal and inner window shaft seal in the sequence -A to D- as shown in the illustration while following the procedure below

Position the molded piece on the B-pillar while sliding the rubber tabs -2- and -3- into the door shell -arrows- and pressing the retaining studs -1- and -4- on completely.

Slide window guide wires -8- in the window guide.

In order to remove front exterior mirror housing from the door shell, position the slot -5- on the inside of the outer door panel -7- -arrow-. Press the retaining studs -6- on completely.

Slide the inner window shaft strip onto the door fold.

Position the door seal on the door shell and press the clips on until they engage audibly.

Install the bass speaker. Refer to REMOVAL AND INSTALLATION .

Install the door shell cover INNER DOOR PANEL COVER .

Install the outer window shaft strip OUTER WINDOW SHAFT STRIP .

Install exterior mirror. Refer to EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009 .

Install the door window DOOR WINDOW .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

Scheme 176

Proceed as follows

Note. The window regulator motor can be removed or installed with the motor or door window in any position.

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Disconnect the electrical connector -2- on the door control module.

Remove the bolts -arrows- and remove the window regulator motor -2- from the window regulator.

Scheme 177

1. Tightening specifications, refer to «WINDOW REGULATOR MOTOR AND WINDOW REGULATOR ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

1. The clips -3- for the window regulator motor threaded pins -2- must be engaged in the inner door panel.

Slide the window regulator motor -1- onto the threaded pins and tighten the bolts -4-.

Note. With the window regulator motor switches connected, switch the ignition on and run the door windows up to the stop. Continue holding the window regulator switch for approximately 2 seconds so the basic setting and one-touch up/down function are activated.

Proceed as follows

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the wiring harness -5- from the bracket -4-.

Remove the door shell cover -3- beginning at the top -arrow-.

Disengage the rubber grommet -1- for the inside door release mechanism cable -2- from the door shell cover.

Install in reverse order of removal. Note the following

Press the door shell cover on.

1. The door shell cover must be flush.

Scheme 178

Proceed as follows

Window regulator motor, removing, refer to WINDOW REGULATOR MOTOR .

Remove the door window. Refer to DOOR WINDOW .

Remove the bass speaker. Refer to REMOVAL AND INSTALLATION .

Release the clips -5- on the window regulator threaded pins -6- using an 11 mm socket by sliding the socking onto the threaded pins.

Disengage the cable -2- upward from the cable guide -1- on the inside.

Unclip the cable -3- from the cable guide -1- and the bracket -4- on the inside.

Remove the sealing plugs -1, 2 and 4-.

Scheme 179

Remove the nuts -3- on the window regulator cable guide.

Remove the nuts -5- while counterholding at the door window adjustment threaded pin -6-.

Guide the window regulator back out of the opening.

1. Tightening specifications, refer to «WINDOW REGULATOR MOTOR AND WINDOW REGULATOR ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

1. The clips -5- for the window regulator motor threaded pins -6- must be engaged in the inner door panel.

Install the bass speaker. Refer to REMOVAL AND INSTALLATION .

Install the door window. Refer to DOOR WINDOW .

Install the window regulator motor. Refer to WINDOW REGULATOR MOTOR .

Adjust the door window: side adjustment. Refer to DOOR WINDOW, ADJUSTING .

Height adjustment, refer to DOOR WINDOW, ADJUSTING .

Scheme 180

Proceed as follows

Press the door seal to the side and remove the protective film over the hole -arrow A-.

Remove the locking bolt -4- as far as the stop using a screwdriver -1-.

Press the lock cylinder retaining bracket -3- inward.

Remove the lock cylinder -2- from the mounting bracket -arrow B-.

Note. If the lock cylinder cannot be pressed out, slide the key into it and remove it with the key turned slightly.

1. Tightening specifications, refer to «DOOR HANDLE, MOUNTING BRACKET AND DOOR LOCK ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Slide the lock cylinder into the mounting bracket and then check if the door lock closing and opening position is activated.

Scheme 181

Remove lock cylinder. Refer to LOCK CYLINDER .

Spread the clips -arrows- and remove the cover cap -1- from the lock cylinder -2- using an awl if necessary.

Install in reverse order of removal. Note the following

Press the lock cylinder cover cap on until it engages audibly.

Install the lock cylinder. Refer to LOCK CYLINDER .

Proceed as follows

Press the door seal to the side and remove the protective film over the hole -arrow A-.

Remove the locking bolt -4- as far as the stop using a screwdriver -1-.

Pull the outer door handle outward and hold it in the "opened" position.

Press the lock cylinder retaining bracket -3- inward. The outer door handle is secured in the "opened" position.

Remove the lock cylinder -2- from the mounting bracket -arrow B-.

Note. If the lock cylinder cannot be pressed out, slide the key into it and remove it with the key turned slightly.

Pull the outer door handle -1- in the -direction of the arrow-. This disengages the handle from the operating lever in the mounting bracket.

Scheme 182

Tilt the outer door handle -1- outward -arrow- and remove it from the mount on the mounting bracket.

Scheme 183

In vehicles with the "keyless entry system", disconnect the electrical connector -2- on the outer door handle.

Scheme 184

Install in reverse order of removal. Note the following

Replace the outer door handle washers -1- and -2- if damaged or brittle.

Insert the outer door handle -1- -arrow A-. It must engage in the mount -2- on the mounting bracket -3-.

Scheme 185

Tilt the outer door handle -1- in the -direction of arrow B- and slide the >>coupling plate<< -5- into the mounting bracket in front of the operating lever -4-.

Press lock cylinder retaining bracket onto the outer door handle.

Install the lock cylinder. Refer to LOCK CYLINDER .

OUTER DOOR HANDLE TRIM

In vehicles without "keyless entry", trim installed instead of the outer door handle touch sensor.

Scheme 186

Proceed as follows

Remove the outside door handle. Refer to OUTER DOOR HANDLE .

Pry the outer door handle trim -2- out using an awl -1- at the location shown in the illustration -arrow-.

Remove the outer door handle trim from the handle -3-.

Install in reverse order of removal. Note the following

Slide the outer door handle trim in until it engages audibly.

Install the outer door handle. Refer to OUTER DOOR HANDLE .

Install the lock cylinder. Refer to LOCK CYLINDER .

LEFT AND RIGHT FRONT OUTSIDE DOOR HANDLE TOUCH SENSOR

Remove the door handle -2- and sensor -1-. Refer to OUTER DOOR HANDLE .

Scheme 187

Using a small screwdriver, carefully release the latches at the arrows - A and B- and push the connector -3- and the wiring guide to the side.

Scheme 188

Insert a screwdriver in front of the sensor as illustrated.

With light force on the screwdriver, pry out the sensor form the door handle.

Remove the sensor from the door handle.

Proceed as follows

Remove the bolts -2- and the striker pin -1-.

1. Tightening specifications, refer to «DOOR LOCK AND STRIKER PIN ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Striker Pin, Adjusting, refer to DOOR, ADJUSTING .

Scheme 189

Remove lock cylinder. Refer to LOCK CYLINDER .

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the door shell cover. Refer to INNER DOOR PANEL COVER .

Tilt the lock cylinder guide -1- up as far as the stop -arrow-.

Remove the lock cylinder guide.

Scheme 190

Install in reverse order of removal. Note the following

When inserting the lock cylinder guide -1-, make sure the anti-twist mechanism -3- engages in the mount -2- on the door shell -arrow-.

Install the door shell cover. Refer to INNER DOOR PANEL COVER .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

Install the lock cylinder. Refer to LOCK CYLINDER .

DOOR LOCK

Remove lock cylinder. Refer to LOCK CYLINDER .

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the inner door panel cover. Refer to INNER DOOR PANEL COVER .

Remove the lock cylinder guide. Refer to LOCK CYLINDER GUIDE .

Remove mounting bracket. Refer to BRACKET

Remove the bolts -arrows- from the door lock.

Scheme 191

Disconnect the connector -2- and remove the door lock -1- and bracket.

Scheme 192

Turn the actuating link on the lever -1- 90° in the -direction of arrow A- and remove it from the cable bracket -2-.

Rotate the actuating link on the door lock operating lever -3- in the -direction of arrow B-.

1. The actuating link must be aligned with the opening on the operating lever.

Disengage the actuating link from the operating lever.

Scheme 193

1. Tightening specifications, refer to «DOOR LOCK AND STRIKER PIN ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Engage the actuating link -3- in the door lock operating lever -2-.

Insert the actuating link in the cable bracket -1- and rotate the lever -4- 90° -arrow-.

1. The lever must engage audibly with the locking tab on the cable bracket.

Install the lock cylinder guide. Refer to LOCK CYLINDER GUIDE .

Install the door shell cover. Refer to INNER DOOR PANEL COVER .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

Install the lock cylinder. Refer to LOCK CYLINDER .

BRACKET

Special tools and workshop equipment required

Scheme 194

1. Pry lever 80 - 200

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the door shell cover INNER DOOR PANEL COVER .

Turn the actuating link on the lever -1- 90° in the -direction of arrow A- and remove it from the cable bracket -2-.

Rotate the actuating link on the door lock operating lever -3- in the -direction of arrow B-.

1. The actuating link must be aligned with the opening on the operating lever.

Disengage the actuating link from the operating lever.

Remove the outside door handle. Refer to OUTER DOOR HANDLE .

Remove the lock cylinder guide. Refer to LOCK CYLINDER GUIDE .

Disengage the electrical wire on the mounting bracket -arrow- if applicable.

Scheme 195

Free up the electrical wire spiral clip -1- using the pry lever 80 - 200.

Note. Use a soapy solution if necessary make removal easier.

Remove the bolt -3- and the mounting bracket -2-.

Install in reverse order of removal. Note the following

Engage the actuating link -3- in the door lock operating lever -2-.

Insert the actuating link in the cable bracket -1- and rotate the lever -4- 90° -arrow-.

1. The lever must engage audibly with the locking tab on the cable bracket.

Install the lock cylinder guide. Refer to LOCK CYLINDER GUIDE .

Install the door shell cover. Refer to INNER DOOR PANEL COVER .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

Install the outer door handle. Refer to OUTER DOOR HANDLE .

DOOR LOCK ACTUATING LINK

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the inner door panel cover. Refer to INNER DOOR PANEL COVER .

Turn the actuating link on the lever -1- 90° in the -direction of arrow A- and remove it from the cable bracket -2-.

Rotate the actuating link on the door lock operating lever -3- in the -direction of arrow B-.

1. The actuating link must be aligned with the opening on the operating lever.

Disengage the actuating link -1- on the operating lever by pressing the cable bracket -3- out of the mount on the mounting bracket -2- -arrow-.

Scheme 196

Remove the operating shaft.

Install in reverse order of removal. Note the following

Engage the actuating link -3- in the door lock operating lever -2-.

Insert the actuating link in the cable bracket -1- and rotate the lever -4- 90° -arrow-.

1. The lever must engage audibly with the locking tab on the cable bracket.

Install the door shell cover. Refer to INNER DOOR PANEL COVER .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

Proceed as follows

Remove lock cylinder. Refer to LOCK CYLINDER .

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Remove the door shell cover. Refer to INNER DOOR PANEL COVER .

Remove the lock cylinder guide. Refer to LOCK CYLINDER GUIDE .

Remove the bolts -arrows-.

Press the door lock -1- to the side and disconnect the electrical connector -2- if necessary.

Disengage the actuating link -3- at the door lock cable bracket -2- -arrow A-.

Scheme 197

Turn the nipple -1- 90° in the -direction of arrow B- and remove it from the door opener release lever -4-.

Scheme 198

1. Tightening specifications, refer to «DOOR LOCK AND STRIKER PIN ASSEMBLY OVERVIEW»(/audi/a5/i-2007-2011/remont/door-locks-anti-theft-systems/#front-doors-central-locking-system-coupe) .

Install in reverse order of removal. Note the following

Insert the nipple -2- in the door opener release lever -3- -bottom arrow-.

Rotate the nipple 90° -top arrow- and press the actuating link into the cable bracket on the door lock -1- until it engages audibly.

Install the lock cylinder guide. Refer to LOCK CYLINDER GUIDE .

Install the door shell cover. Refer to INNER DOOR PANEL COVER .

Install the door trim panel. Refer to REMOVAL AND INSTALLATION .

Install the lock cylinder. Refer to LOCK CYLINDER .

Scheme 199

Remove the door trim panel. Refer to REMOVAL AND INSTALLATION .

Open the release and the disconnect the connectors -1- and -2-.

Disconnect the connector -3-.

Disconnect the connector -2- on the door control module.

Press the retaining detent -5- in -direction of arrow- and disengage the door control module -6- on the door shell.

Scheme 200

Clamp off ground wire at battery with ignition switched off REMOVAL AND INSTALLATION .

Open the right luggage compartment side trim panel cover.

Remove the nuts -arrows- and frame -1- with comfort system central control module -J393- and set it aside.

If equipped, release the retaining clips -arrows- and remove the electronic damping control module -J250- -1- from the frame.

Scheme 201

Remove bolts -1- and -2- and nut -4-.

Scheme 202

Move frame -3- with control module to the side.

Disconnect the connector for the control module in the frame.

Remove the frame and control module.

Remove the bolts -arrows-.

Remove the vehicle positioning system interface control module -J843- -1-.

Disconnect the connectors -2, 3, 4-.

1. Tightening specifications (Scheme 160)

Install in reverse order of removal. Note the following

Install the frame for the control module. Refer to REMOVAL AND INSTALLATION .

Connect battery. Necessary measures REMOVAL AND INSTALLATION .

Scheme 203

1. Cable for emergency release
2. Fuel filler door unlock motor -V 155- Removal: -- Removed fuel filler door: refer to Audi A5 «FUEL FILLER DOOR»(/audi/a5/i-2007-2011/remont/exterior-body-panels/#hood-lids-coupe__fuel-filler-door) , Audi RS 5 «FUEL FILLER DOOR INSERT»(/audi/a5/i-2007-2011/remont/exterior-body-panels/#hood-lids-coupe__fuel-filler-door-insert) -- Pull the comfort system central control module -J393- into the luggage compartment and pull it forward. -- Remove the fuel tank lid unlock motor -V 155- forward off the body flange and disconnect the electrical connector. Installing: -- Slide the fuel tank lid unlock motor -V 155- onto the flange and slide the emergency release into the luggage compartment.
3. Fuel filler door Removal: -- Open the door and remove the bolt. -- Pull the bolted side of the door out of the side panel slightly. -- Completely remove the door from the side panel diagonally toward the rear. Installing: -- Guide cable through opening in fuel filler door cup. -- Insert fuel filler door diagonally until catches on protruding flange engage in side panel. -- Bolt the door and the door release motor together using the bolt -4-.
4. Bolt 1.7 Nm
5. Fuel filler door cup
6. Drain hose

Fuel Filler Door Emergency Release

Scheme 204

1. Fuel filler door unlock motor -V 155
2. Cable for emergency release Insert the fuel tank lid unlock motor -V 155- with the cable over the tank opening as shown. Pull the cable back into the vehicle interior and connect it with the tab on the flange on the comfort system central control module -J393-.
3. Side panel

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 205

1. Pry Lever - Rmv Outside Mirror 80 - 200
2. Roller 3356
3. Special Hook 3370
4. Adjustment Gauge 3371
5. Disassembly Tool T40219
6. Adhesive Strip Remover VAS 6349
7. Not illustrated
8. Template T40038/8

See also:
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• REMOVAL AND INSTALLATION
• DOOR WINDOW, ADJUSTING
• REMOVAL AND INSTALLATION
• DOOR WINDOW
• HOOD ASSEMBLY OVERVIEW
• REMOVAL AND INSTALLATION
• EXTERIOR REARVIEW MIRROR ASSEMBLY OVERVIEW - VEHICLES THROUGH MAY 2009
• REMOVAL AND INSTALLATION
• FUEL FILLER DOOR
• FUEL FILLER DOOR INSERT
• FRONT DOOR
• DOOR SEALS
• OUTER WINDOW SHAFT STRIP
• DOOR, ADJUSTING
• DOOR LOCK
• OUTER DOOR HANDLE TRIM
• DOOR LOCK ACTUATING LINK
• BRACKET
