Bumpers (avant) Audi A4 B8

Scheme 120

1. Bolt 3 Nm
2. Bolt 1.5 Nm
3. Bumper Cover End Plate Removing and installing. Refer to «FRONT BUMPER COVER END PLATE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__front-bumper-cover-end-plate) .
4. Cover For the towing hook
5. Bumper Cover Removing and installing. Refer to «FRONT BUMPER COVER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__front-bumper-cover) .
6. Right Front Parking Aid Sensor -G252- Removing and installing. Refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant) .
7. Radiator Grille Removing and installing, refer to «RADIATOR GRILLE»(/audi/a4/b8-2007-2012/remont/mirrors/#exterior-equipment-avant) .
8. Bolt Tightening specification. Refer to item 7 «RADIATOR GRILLE OVERVIEW»(/audi/a4/b8-2007-2012/remont/mirrors/#exterior-equipment-avant) .
9. Lock Carrier Cover Removing and installing, refer to «LOCK CARRIER COVER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__lock-carrier-cover) .
10. Expanding Rivet Remove the clamping pin when removing. Only press the clamping pin in when installing.
11. Shock Absorber Removing and installing, refer to «IMPACT ABSORBER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__impact-absorber) .
12. Left Front Parking Aid Sensor -G255- Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant) .
13. Front Bumper Cover Mount Removing and installing, refer to «FRONT BUMPER COVER MOUNT»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__front-bumper-cover-mount) .
14. Bolt 4 Nm
15. Nut 4 Nm
16. Fog Lamps Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/exterior-lights/#exterior-lights-switches-avant) .
17. Air Intake Grille Removing and installing, refer to «AIR INTAKE GRILLE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__air-intake-grille) .
18. Bolt 3 Nm
19. Bolt 1.5 Nm

BUMPER COVER OVERVIEW, ALLROAD

Note. Only the differences from the standard bumper are described Removing and installing the bumper cover is same as on standard bumpers.

Scheme 121

1. Right Bumper Cover Removal, refer to «REMOVING THE LEFT AND RIGHT BUMPER COVERS»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .
2. Radiator Grille Removing and istalling, refer to «RADIATOR GRILLE»(/audi/a4/b8-2007-2012/remont/mirrors/#exterior-equipment-avant) . Loosen the threaded connectors. Refer to «REMOVING THE RADIATOR GRILLE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .
3. Bolt 1.5 Nm
4. Bolt 4 Nm
5. Left Bumper Cover Removal, refer to «REMOVING THE LEFT AND RIGHT BUMPER COVERS»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .
6. Left Air Intake Grille Removing, refer to «REMOVING THE LEFT AND RIGHT AIR INTAKE GRILLE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .
7. Front Spoiler First remove the left and right expanding clips before removing the front spoiler. This differs from the standard bumper «FRONT SPOILER EXPANDING CLIP»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__front-spoiler-expanding-clip) .
8. End Plate Remove the bumper cover. Refer to «FRONT BUMPER COVER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__front-bumper-cover) . -- Remove the screws -12- and then remove the end panel from the impact guard.
9. Bolt 1.5 Nm
10. Underbody Impact Guard Bumper cover removed. Remove the screws -12- and the screw -11- and remove the impact guard forward from the front spoiler and the end panel.
11. Bolt 1.5 Nm
12. Bolt 1.5 Nm
13. Right Air Intake Grille Removing, refer to «REMOVING THE LEFT AND RIGHT AIR INTAKE GRILLE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

FRONT SPOILER EXPANDING CLIP

Press the left and right clamping pin -3- upward through the expanding clip on the front spoiler -2-.

Scheme 122

Remove the expanding clip from the front spoiler -2- and then remove the bumper cover -1-.

Secure the expanding clip with the clamping pin.

Scheme 123

Insert a small screwdriver into the opening on the air intake grille as illustrated.

Release the catches on the air intake grille and pull it forward.

Scheme 124

Bumper cover removed.

Remove the screws -arrow -a-.

Release the catches from the outside toward the inside and remove the spoiler or the radiator grille.

Scheme 125

Bumper removed.

Remove the screws -arrows- on the radiator grille and pull the grilled out of the spoiler and the side panels.

Scheme 126

Removing the lock carrier cover, refer to LOCK CARRIER COVER .

If the gap dimension is not even, position the wrench on the adjusting bolt -1- and adjust the gap dimension for the front bumper cover -2-.

Check the gap dimension again and repeat the adjustment if necessary.

Scheme 127

1. Side Impact Bar Removing and installing, refer to «IMPACT MEMBER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__impact-member) .
2. Low Tone Horn -H7- Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/gauges-instrument-panels/#instruments-avant) .
3. Right Spacer For the bumper cover.
4. Right Impact Bar Bracket Removing and installing, refer to «RIGHT IMPACT BAR BRACKET»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__right-impact-bar-bracket) .
5. High Tone Horn -H2- Removing and installing, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/gauges-instrument-panels/#instruments-avant) .
6. Bolt 30 Nm
7. Left Spacer For the bumper cover.
8. Bolt 4 Nm Secures the lock carrier.
9. Bolt 30 Nm
10. Left Impact Bar Bracket Removing and installing, refer to «LEFT IMPACT BAR BRACKET»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__left-impact-bar-bracket) .
11. Bolt 20 Nm
12. Nut Tightening specification, refer to «Removal and Installation»(/audi/a4/b8-2007-2012/remont/gauges-instrument-panels/#instruments-avant) .

REAR BUMPER COVER OVERVIEW

Scheme 128

1. Rear Bumper Cover Removing and installing, refer to «REAR BUMPER COVER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__rear-bumper-cover).
2. Bolt 17 Nm
3. Bolt 1.5 Nm
4. Upper Guide Piece Insert into the guide piece and lock. Removing and installing, refer to «UPPER GUIDE PIECE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__upper-guide-piece).
5. Clip
6. Bolts Remove the bumper cover upward (Scheme 150)
7. Left Guide Piece Removing and installing, refer to «GUIDE PIECE»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__guide-piece).
8. Bolt 1.5 Nm Tightening sequence (Scheme 129)
9. Nut 17 Nm
10. Bumper Carrier
11. Right Guide Piece
12. Upper Guide Piece Insert into the guide piece and lock.
13. Spoiler Removing and installing, refer to «SPOILER»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant).
14. Bolt 1.5 Nm

Scheme 129

Tighten the bolts in a -1 to 5- sequence to 1.5 Nm.

REAR BUMPER COVER OVERVIEW, ALLROAD

Note. Only the differences from the standard bumper are described Removing and installing the bumper cover is same as on standard bumpers.

Scheme 130

1. Spoiler First remove the left and right expanding clips before removing the spoiler. This differs from the standard bumper, refer to «Removing the expanding clips»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__removing-the-expanding-clips). Bumper cover removed. -- Release the hooks all the way around in steps and remove the cover toward the rear. -- Make sure the hooks engage completely into the cover when installing.
2. Bumper Cover When installing the old bumper cover, the old support -7- remains installed. -- A new support must be installed when replacing the bumper cover (Scheme 133) Removal is the same as for the spoiler.
3. Clip
4. Securing Strip
5. Bolt 2.5 Nm
6. Bolt 1.5 Nm
7. Support Piece NOTE: Support piece must be installed only with a new bumper cover. Release (Scheme 133)
8. Underbody Impact Guard Bumper cover removed. Remove the screws -6- and -9- and remove the impact guard toward the rear.
9. Bolt 1.5 Nm

REMOVING THE EXPANDING CLIPS

Press the left and right clamping pin -3- upward through the expanding clip on the spoiler -2-.

Remove the expanding clip from the spoiler -2- and then remove the bumper cover -1-.

Secure the expanding clip with the clamping pin.

Removing Hooks

Release the hooks, including the ones under the end panel -2- to remove the cover -1- or the spoiler -5-.

Scheme 131

Remove the screws -3-, release the hooks -arrows- and remove the impact guard -2- from the spoiler.

Scheme 132

Note. Support piece must be installed only with a new bumper cover.

To remove, press catch -arrow- to the side and pull support piece downward out of cover -1-.

Insert support piece -2- into cover as shown and let engage inside.

Disengaging cord must be removed only when the cover is installed completely.

Scheme 133

When re-installing the old bumper cover, the old support piece remains installed.

When replacing the bumper cover, a new support piece must be clipped into the bumper cover from below.

After completely installing bumper cover, disengage support piece by pulling on disengaging cord -arrow-.

Note. By pulling disengaging cord, tension is released from support piece and reinforces the bumper cover against the crossmember.

Scheme 134

1. Washer
2. Bolt 57 Nm
3. Bolt
4. Left Impact Member Mount For vehicles without a trailer hitch. Removing and installing, refer to «IMPACT MEMBER MOUNT WITHOUT TRAILER HITCH»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__impact-member-mount-without-trailer-hitch) .
5. Washer
6. Bolt 57 Nm
7. Nut 17 Nm
8. Right Impact Bar Mount For vehicles without a trailer hitch. Removing and installing, refer to «IMPACT MEMBER MOUNT WITHOUT TRAILER HITCH»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__impact-member-mount-without-trailer-hitch) .
9. Bolt 57 Nm
10. Washer
11. Nut 17 Nm
12. Side Impact Bar For vehicles without a trailer hitch. Removing and installing, refer to «IMPACT MEMBER WITHOUT TRAILER HITCH»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__impact-member-without-trailer-hitch) .
13. Bolt
14. Bolt 57 Nm
15. Washer
16. Side Impact Bar For vehicles with a trailer hitch. Removing and installing, refer to «IMPACT MEMBER WITH TRAILER HITCH»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__impact-member-with-trailer-hitch) .
17. Type Plate

AIR INTAKE GRILLE

Removing

Scheme 135

Release the retaining hooks -A arrows- using a screwdriver.

Remove the air intake grille -1- from the lower part of the bumper cover -arrow B-.

Installation

To install, perform the steps used in removal in reverse order.

FRONT BUMPER COVER

Removing

Scheme 136

Removing the lock carrier cover, refer to LOCK CARRIER COVER .

Disconnect the electrical connector -2- for the outside air temperature sensor -G17- and the electrical connector -1- for the front parking aid sensor.

Remove the bolt -3-.

Scheme 137

Remove the bolt -2- and the quick-release coupling -1- on the front bumper noise insulation.

Remove wheel housing liner. Refer to FRONT WHEEL HOUSING LINER .

Scheme 138

Disconnect the electrical connector -1- on the fog lamp.

Remove the bolts -arrows-.

Disengage the side walls on the front side panel and remove the bumper cover forward.

Installation

1. Tightening specifications, refer to «BUMPER COVER OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Install wheel housing liner. Refer to FRONT WHEEL HOUSING LINER .

Install the lock carrier cover. Refer to LOCK CARRIER COVER .

FRONT BUMPER COVER END PLATE

Removing

Scheme 139

Remove the bolts -1- and -2-.

Pull the front bumper cover end plate back.

Installation

1. Tightening specifications, refer to «BUMPER COVER OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

To install, perform the steps used in removal in reverse order.

FRONT BUMPER COVER MOUNT

Removing

Scheme 140

Remove front bumper cover. Refer to FRONT BUMPER COVER .

Remove the nuts -arrows- and the front bumper cover mount -1-.

Installation

1. Tightening specifications, refer to «BUMPER COVER OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Install the front bumper cover, refer to FRONT BUMPER COVER .

HEADLAMP WASHER SYSTEM SPRAY NOZZLE COVER

Removing

Scheme 141

Fold the washer nozzle cover -1- upward -arrow A-.

Using a screwdriver on the inner side, pry the spray nozzle cover -1- off the mount -2- -arrow B- and disengage it at the opposite side.

Installation

Installation is reverse of removal, but note the following

Press the spray nozzle cover on until it engages audibly.

IMPACT ABSORBER

Removing

Scheme 142

Remove front bumper cover. Refer to FRONT BUMPER COVER .

Disconnect the front parking aid sensor electrical wiring harness -1- -arrow- if applicable.

Guide the impact absorber -2- out of the brackets -A- and remove it.

Installation

Installation is reverse of removal, but note the following

Install the front bumper cover, refer to FRONT BUMPER COVER .

IMPACT MEMBER

Removing

Scheme 143

Note. When installing, position cable ties in same place.

Remove front bumper cover. Refer to FRONT BUMPER COVER .

Disconnect the electrical connector -4- on the horns and free up the electrical wiring harness -3- on the horn bracket.

Free up the washer nozzle water drain hose by disconnecting the cable tie -1-.

Remove the bolts -arrows- and the bumper cover spacer -2-.

Remove the impact bar -5- from the mounts.

Note. Pry the impact bar out of the mounts if it is not easy to remove.

Installation

1. Tightening specifications, refer to «IMPACT BAR OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Install the front bumper cover. Refer to FRONT BUMPER COVER .

LEFT IMPACT BAR BRACKET

Removing

Scheme 144

Remove front bumper cover. Refer to FRONT BUMPER COVER .

Remove the side impact bar. Refer to IMPACT MEMBER .

Remove the headlamp washer system spray nozzle. Refer to Removal and Installation .

Mark the installation position of the bracket to the lock carrier for installation later.

Remove the bolts -arrows-.

Remove the locating bolt -1-.

Tip the impact bar bracket -2- on the lock carrier out and remove it.

Installation

1. Tightening specifications, refer to «IMPACT BAR OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Tighten the impact bar bracket according to the marking made during removal.

Install the headlamp washer system spray nozzle. Refer to Removal and Installation .

Install the impact member. Refer to IMPACT MEMBER .

Install the front bumper cover. Refer to FRONT BUMPER COVER .

LOCK CARRIER COVER

Removing

Scheme 145

Remove the expanding clip bolts -1, 2, 3 and 5-.

Lift the lock carrier cover -4- -arrow- and disengage it from the radiator grille.

Installation

Installation is reverse of removal, but note the following

Insert the lock carrier cover with the guide into the mounts on the radiator grille and into the bumper cover.

Insert the expanding clips and install the bolts as far as the stop.

RIGHT IMPACT BAR BRACKET

Removing

Remove front bumper cover. Refer to FRONT BUMPER COVER .

Remove the side impact bar. Refer to IMPACT MEMBER .

Mark the installation position of the bracket to the lock carrier for installation later.

Remove the bolts -arrows-.

Scheme 146

Remove the locating bolt -1-.

Remove the impact bar bracket -2- on the lock carrier.

Installation

1. Tightening specifications, refer to «IMPACT BAR OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Tighten the impact bar bracket according to the marking made during removal.

Install the impact member. Refer to IMPACT MEMBER .

Install the front bumper cover. Refer to FRONT BUMPER COVER .

REAR BUMPER COVER

Removing

Remove the tail lamp assembly. Refer to Removal and Installation .

Scheme 147

Disconnect the electrical connector -1- on the parking aid control module -J446- if applicable.

Free up the electrical wiring harness on the control module bracket -arrow- by disconnect the cable tie -2-.

Press the grommet -3- outward.

Remove the nut -3- from the threaded pin on the cover -1-.

Scheme 148

Remove the bolts -1- on the lower bumper cover section.

Scheme 149

Scheme 150

Before the bumper cover can be pulled to the rear, remove the bolt -1- from the left and right guide piece -3-.

When installing, fold the hinge -2- on the guide piece forward -arrow- before inserting the bolt.

Remove the left and right bolts -1- on the front side of the bumper.

Release the catch for the bumper cover by removing the bolts -3- from the guide piece.

Scheme 151

Disengage the left and right bumper cover on the side panel -arrow-.

Remove the bumper cover -2-. The parking aid sensor electrical wire must be guided out through the body opening.

Installation

1. Tightening specifications, refer to «REAR BUMPER COVER OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__rear-bumper-cover-overview) .
2. Installation is reverse of removal, but note the following

When installing, the side catches on the guide piece -2- must engage completely into the bumper cover -1-.

Scheme 152

Fold the hinge on the guide piece forward and insert the bolt. (Scheme 150)

Connect the electrical connector on the parking aid control module -J446- if applicable. Refer to Removal and Installation .

Install the tail lamp assembly. Refer to Removal and Installation .

Scheme 153

1. Spoiler The clips -arrow- must engage completely into the bumper cover when installing.
2. Bumper Cover Installed
3. Bolt 1.5 Nm

Removing

Scheme 154

Remove the bolts -1- and -3- on the spoiler -2- for the bumper cover.

Unclip the bumper cover spoiler -2- from the bumper cover -1- in the sequence -A to C arrows- beginning above the tail pipe.

Scheme 155

Installation

1. Tightening specifications, refer to «REAR BUMPER COVER OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__rear-bumper-cover-overview) .

Installation is reverse of removal, but note the following

When pressing on, make sure the end points are guided into the bumper cover before pressing on for the final time.

UPPER GUIDE PIECE

Removing

Scheme 156

Remove the rear bumper cover. Refer to REAR BUMPER COVER .

Remove the bumper cover side mount. Refer to GUIDE PIECE .

Remove the bolts -arrows- and the bumper cover locking mechanism -1-.

Installation

1. Tightening specifications, refer to «REAR BUMPER COVER OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant__rear-bumper-cover-overview) .

Installation is reverse of removal, but note the following

Install the bumper cover side mount. Refer to GUIDE PIECE .

Install the rear bumper cover. Refer to REAR BUMPER COVER .

GUIDE PIECE

Removing

Scheme 157

Remove the rear bumper cover. Refer to REAR BUMPER COVER .

Remove the bolts -1 through 3-.

Release the retaining spring on the bumper cover locking mechanism -arrow- and remove the bumper cover side mount -4- downward.

Installation

1. Tightening specifications (Scheme 129)

Installation is reverse of removal, but note the following

Install the rear bumper cover. Refer to REAR BUMPER COVER .

IMPACT MEMBER WITHOUT TRAILER HITCH

Removing

Remove the rear bumper cover. Refer to REAR BUMPER COVER .

Disconnect the electrical connector on the radio frequency controlled clock receiver -J489-.

Note. If the impact bar is replaced -3-, remove the radio frequency controlled clock receiver -J489-. Refer to Removal and Installation .

Remove the bolts -1- by counterholding the nuts -2-.

Remove the impact bar -3-.

Installation

1. Tightening specifications, refer to «IMPACT BAR OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Install the rear bumper cover. Refer to REAR BUMPER COVER .

IMPACT MEMBER MOUNT WITHOUT TRAILER HITCH

Removing

Remove the rear bumper cover. Refer to REAR BUMPER COVER .

Remove the side impact bar. Refer to IMPACT MEMBER WITHOUT TRAILER HITCH .

Remove the tie-downs. Refer to Removal and Installation .

Loosen the left and right luggage compartment side trim in the rear area. Refer to Removal and Installation .

Remove the bolts -arrows- and the impact bar mount -1-.

Scheme 158

Installation

1. Tightening specifications, refer to «IMPACT BAR OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Install the left and right luggage compartment side trim. Refer to Removal and Installation .

Install the tie-downs. Refer to Removal and Installation .

Install the impact member. Refer to IMPACT MEMBER WITHOUT TRAILER HITCH .

Install the rear bumper cover. Refer to REAR BUMPER COVER .

IMPACT MEMBER WITH TRAILER HITCH

Removing

Remove the rear bumper cover. Refer to REAR BUMPER COVER .

Remove the trailer hitch outlet. Refer to Removal and Installation .

Free up the electrical wire spiral clip -1-.

Scheme 159

Note. Use a soapy solution if necessary make removal easier.

Disconnect the electrical connector on the radio frequency controlled clock receiver -J489- -item 2-, if applicable.

Note. If the impact bar is replaced -3-, remove the radio frequency controlled clock receiver -J489-. Refer to Removal and Installation .

Remove the tie-downs. Refer to Removal and Installation .

Loosen the left and right luggage compartment side trim in the rear area. Refer to Removal and Installation .

Remove the bolts -arrows- and the impact bar -3-.

Installation

1. Tightening specifications, refer to «IMPACT BAR OVERVIEW»(/audi/a4/b8-2007-2012/remont/exterior-body-panels/#bumpers-avant) .

Installation is reverse of removal, but note the following

Install the left and right luggage compartment side trim. Refer to Removal and Installation .

Install the tie-downs. Refer to Removal and Installation .

Install the trailer hitch outlet. Refer to Removal and Installation .

Install the rear bumper cover. Refer to REAR BUMPER COVER .

See also:
• Removal and Installation
• RADIATOR GRILLE
• Removal and Installation
• Removal and Installation
• FRONT WHEEL HOUSING LINER
• Removal and Installation
• Removal and Installation
• FRONT BUMPER COVER END PLATE
• FRONT BUMPER COVER
• LOCK CARRIER COVER
• IMPACT ABSORBER
• FRONT BUMPER COVER MOUNT
• AIR INTAKE GRILLE
• REMOVING THE LEFT AND RIGHT BUMPER COVERS
• FRONT SPOILER EXPANDING CLIP
• IMPACT MEMBER
• RIGHT IMPACT BAR BRACKET
• LEFT IMPACT BAR BRACKET
• REAR BUMPER COVER
• UPPER GUIDE PIECE
• GUIDE PIECE
• Removing the expanding clips
• IMPACT MEMBER MOUNT WITHOUT TRAILER HITCH
• IMPACT MEMBER WITHOUT TRAILER HITCH
• IMPACT MEMBER WITH TRAILER HITCH
• REAR BUMPER COVER OVERVIEW
