Continuously Variable Transmission (cvt) 01j Audi A4 B6

Transmission identification

The "Continuously Variable Transmission (CVT) 01J" is installed in conjunction with various engines in the Audi A4 2002 -->. Allocation --> Code letters, assembly allocation, ratios, equipment .

Location of code letters on transmission

Scheme 1245

Code letters and serial number of transmission are stamped on underside of transmission housing - arrow -.

Note. The code letters of the transmission are also listed on the vehicle data stickers.

Extensive information about the construction and function of this transmission 951103 Continuously Variable Transmission (CVT) 01J.

Note. The continuously variable automatic transmission multitronic 01J is also called "Continuously Variable Transmission" , short "CVT".

Guided Fault Finding

Always perform Guided Fault Finding using Diagnostic Operation System VAS 5051 A before starting disassembly and assembly work.

Code letters, assembly allocation, ratios, equipment

*Only country version Mexico.

* Version dependent .

*Only country version Belgium.

* Version dependent .

* Version dependent .

* Version dependent .

* Version dependent .

* Version dependent .

* Version dependent .

Capacities

Planetary transmission

* ATF change interval for planetary gear -->

1. «01 - MAINTENANCE»(/audi/a4/b6-2000-2006/remont/procedures/#maintenance-procedures)
2. «01 - MAINTENANCE»(/audi/a4/b6-2000-2006/remont/procedures/#maintenance-procedures-cabriolet) for MAINTENANCE PROCEDURES - CABRIOLET

ATF for CVT transmission can be obtained as replacement part, container size

1. 1.0 L - ATF (Automatic Transmission Fluid) G 052 180 A2

Checking ATF level or replacing ATF --> ATF level, checking and topping off .

Front final drive

Multitronic gear oil is available as a replacement part and comes in the following container size

1. 1.0 L - Axle oil G 052 190 A2

Oil level in front final drive, checking --> Gear oil level in front final drive, checking .

Towing instructions

Note. Tow-starting the engine, e.g. when the battery is too weak or the starter is faulty, is not possible.

Repair instructions

The maximum possible care and cleanliness and proper tools are essential to ensure satisfactory and successful transmission repairs. The usual basic safety precautions also apply when carrying out vehicle repairs.

A number of generally applicable instructions for individual repair procedures, which are otherwise mentioned at various points in the article, are summarized here. They apply to this article.

Contact corrosion!

1. Transmission housing of continuously variable automatic transmission Multitronic 01J consists of a magnesium alloy.
2. Bolts and other components which have direct contact with transmission have a surface coating which is matched to magnesium transmission housing.
3. On magnesium transmissions, bolts must always be replaced on following bolted connections: transmission cover to transmission housing and final drive cover to transmission housing.
4. Contact corrosion occurs when incorrect components (bolts, nuts, washers, etc.) are used. The transmission housing will be damaged.

1. Transmission housing, transmission cover and differential cover must all be of same material.
2. If you are not sure whether used parts can be re-installed, always install new parts.

General Repair Notes

Transmission

1. Observe rules of cleanliness for working on the transmission --> «Rules for cleanliness when working on transmission»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__rules-for-cleanliness-when-working-on) .
2. Do not run engine with end cover removed or without ATF filling and do not tow vehicle.
3. Only install clean parts: Remove packing from replacement parts immediately prior to installation and not before.
4. After installing, the following fluid levels must be checked and topped off if necessary: ATF in planetary gear --> «ATF level, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-level-checking-and-topping-off) and axle oil in front final drive --> «Gear oil level in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__gear-oil-level-in-front-final) . Capacities and specifications --> «Capacities»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

O-rings, seals, gaskets

1. Always replace O-rings, gaskets and seals.
2. After removing gaskets, examine contact surface on housing/shaft for burr resulting from removal or for other signs of damage.
3. Thoroughly clean housing joint surfaces before assembling.
4. To install, thinly coat gaskets along outer circumference and on sealing lip with ATF.

1. Lightly lubricate O-rings with ATF when installing to prevent the rings from being pinched when components are assembled.
2. Only use ATF for automatic transmission components. Other types of lubrication cause faults to occur in the transmission hydraulics.
3. Open sides of oil seals face fluid side.
4. When pressing in new gaskets, make sure the sealing lip does not run on the same point as the sealing lip of the old seal (use insertion depth tolerances).

1. After installing, the following fluid levels must be checked and topped off if necessary: ATF in planetary gear --> «ATF level, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-level-checking-and-topping-off) or axle oil in front final drive --> «Gear oil level in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__gear-oil-level-in-front-final) . Capacities and specifications --> «Capacities»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

Bolts and nuts

1. Loosen bolts in reverse of tightening sequence.
2. Nuts and bolts which secure covers and housings should be tightened in stages according to specified sequence and tightening method.
3. Loosen and tighten bolts and nuts for securing covers and housings in a diagonal sequence and in stages, when no tightening sequence is specified.
4. The tightening torques stated apply to unoiled bolts and nuts.

1. Replace self-locking bolts and nuts.
2. Clean threads of bolts that were applied with locking fluid using a wire brush. Then insert bolts with locking fluid AMV 185 101 A1 .
3. Threaded holes into which self-locking bolts or bolts coated with locking fluid are installed, must be cleaned (e.g. tap). Otherwise there is a risk that the bolts will shear the next time they are removed.

Locking elements

1. Do not over-stretch circlips.
2. Always replace circlips which have been damaged or over-tensioned.
3. Circlips must be properly seated in the base of the groove.

Bearings

1. Install needle bearings with the lettering on the bearing (the side with thicker metal) facing towards the drift.
2. Insert bearing with axle oil or ATF, depending on installation location.
3. Do not interchange outer or inner races of bearings of the same size.
4. Always replace taper roller bearings on one shaft together and use new bearings from a single manufacturer.

Adjustment shims

1. Use a micrometer to measure shims at several points. Varying tolerances make it possible to measure the required shim thickness exactly.
2. Inspect for burrs and signs of damage. Install only shims that are in perfect condition.

Guided Fault Finding

Always perform Guided Fault Finding using Diagnostic Operation System VAS 5051 A before starting disassembly and assembly work.

Rules for cleanliness when working on transmission

1. Carefully clean all joints and adjacent areas before disconnecting.
2. Place removed parts on a clean surface and cover them. Use sheeting or paper. Do not use fluffy cloths!
3. Carefully cover or plug unpacked components if repairs cannot be performed immediately.
4. Only install clean parts: Remove packing from replacement parts immediately prior to installation and not before.

Scheme 1246

Note. If ATF leak is determined from check hole behind ATF breather pipe - A - at level of bolt - B - , transmission is malfunctioning and must be replaced.

Scheme 1247

1 - Transmission Control Module (TCM) J217

1. Installed location --> «Transmission Control Module (TCM) J217»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. Control module is checked with On Board Diagnostics (OBD)
3. Removing and installing --> «Transmission Control Module (TCM) J217 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-control-module-tcm-j217)

2 - Hydraulic control module

1. Installed location «Hydraulic control module»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. Valves are checked with On Board Diagnostics (OBD)
3. Removing and installing --> «Hydraulic control module, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__hydraulic-control-module-removing-and-installing)

3 - Shift mechanism cover

1. > «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499)
2. > «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500)

4 - Tiptronic Switch F189

1. Location: Integrated into circuit board in cover of shift mechanism
2. Consists of 3 Hall sensors that are controlled by a magnet on the cover strip transverse slide.
3. If malfunctions at Tiptronic Switch F189 occur, check first whether magnet at control slide masking panel is properly secured and replace masking panel if necessary. Before replacing the printed circuit, check wiring.
4. > «Tiptronic Switch F189 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-through-vin-8e_6a156499)

1. > «Tiptronic Switch F189 (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-from-vin-8e_6a156500)

5 - Shift lock solenoid N110

1. Installed location --> «Shift lock solenoid N110»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. > «Shift Lock Solenoid N110 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-lock-solenoid-n110-through-vin)
3. > «Shift Lock Solenoid N110 (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)

6 - Data Link Connector (DLC)

1. Installed location «Data Link Connector (DLC)»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)

7 - Cruise Control Switch E45

1. Installed location --> «Cruise Control Switch E45»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. Removing and installing --> «94 LIGHTS, SWITCHES - EXTERIOR»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment) 94 LIGHTS, SWITCHES - EXTERIOR for ELECTRICAL EQUIPMENT, CABRIOLET

8 - Park/Neutral Position (PNP) Relay J226 (up to 10.04) or Starting Interlock Relay J207 (as of 11.04)

1. Installed location --> «Power supply relay terminal 87/Starter Interlock Alarm System Relay J60 and Park/Neutral Position (PNP) Relay J226 (up to 10.04) or Starting Interlock Relay J207 (as of 11.04)»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)

9 - Power supply relay terminal 87/ Starter Interlock Alarm System Relay J60

1. Installed location --> «Power supply relay terminal 87/Starter Interlock Alarm System Relay J60 and Park/Neutral Position (PNP) Relay J226 (up to 10.04) or Starting Interlock Relay J207 (as of 11.04)»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)

10 - Transmission Range (TR) Display Y6

1. Installed location --> «Transmission Range (TR) Display Y6»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. A fully illuminated gear selection indicator indicates a simple malfunction
3. A blinking gear selection indicator indicates a critical malfunction
4. No indication on display points to a fault in wiring or a faulty Transmission Range (TR) Display Y6

11 - Kick Down Switch F8

1. Not a separate component, it adopts functions of Throttle Position (TP) Sensor G79 and Accelerator Pedal Position Sensor 2 G185 in vehicles with gasoline engine, both are integrated in accelerator pedal module; component location --> «Kick Down Switch F8»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. Installed as one unit with Throttle Position (TP) Sensor G79 in vehicles with Diesel engine, this is integrated in the accelerator pedal module; component location --> «Kick Down Switch F8»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
3. Signal received in Engine Control Module (ECM), signal transferred from ECM to Transmission Control Module (TCM) via CAN-Bus
4. Removing and installing accelerator pedal module --> «20 - FUEL SUPPLY SYSTEM»(/audi/a4/b6-2000-2006/remont/fuel-system/#fuel-supply-system)

12 - Brake Light Switch F

1. Installed location --> «Brake Light Switch F»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. Signal received in Engine Control Module (ECM), signal transferred from ECM to Transmission Control Module (TCM) via CAN-Bus
3. Removing and installing --> «46 - BRAKES - MECHANICAL COMPONENTS»(/audi/a4/b6-2000-2006/remont/anti-locktraction-control/#brake-system)

Scheme 1248

1. Location: Transmission Control Module (TCM) J217 is on the back end of transmission, secured directly to hydraulic control module.

The following components are integrated in the control module

A - Transmission Output Speed (RPM) Sensor G195 and Transmission Output Speed (RPM) Sensor 2 G196

B - Transmission Fluid Temperature Sensor G93

C - Multi-Function Transmission Range (TR) Switch F125

D - Transmission Input Speed (RPM) Sensor G182

E - Automatic Transmission Hydraulic Pressure Sensor 1 G193

F - Automatic Transmission Hydraulic Pressure Sensor 2 G194

Removing and installing Transmission Control Module (TCM) J217 --> Transmission Control Module (TCM) J217 , removing and installing .

Scheme 1249

1. Location: Hydraulic control module is bolted to back end of transmission. Transmission Control Module (TCM) J217 is fastened directly to hydraulic control module.

A - Harness connector for Automatic Transmission Pressure Regulating Valve 1 N215

B - Harness connector for Automatic Transmission Pressure Regulating Valve 2 N216

C - Harness connector for Solenoid Valve 1 N88

Following valves are integrated into hydraulic control module (not depicted here).

1. Automatic Transmission Pressure Regulating Valve 1 N215 (clutch solenoid valve)
2. Automatic Transmission Pressure Regulating Valve 2 N216 (solenoid valve gear)
3. Solenoid Valve 1 N88 (clutch cooling/safety shut-off)
4. Clutch cooling valve

1. Minimum pressure valve
2. Pressure relief valve
3. Clutch control valve
4. Pressure control valve

Note. Valves are monitored via On Board Diagnostic (OBD). Description and functions of individual valves 951103Continuously Variable Automatic Transmission Multitronic 01J.

Removing and installing hydraulic control module --> Hydraulic control module, removing and installing .

Scheme 1250

1. Location: Shift Lock Solenoid N110 is located in shift mechanism - arrow -.

Scheme 1251

1. Location: Diagnostic connection is located beneath knee bolster on left of steering wheel.

Scheme 1252

1. Location: Cruise control switch is located on steering column switch.

Scheme 1253

1. Location: Integrated in instrument cluster.

Note. Transmission Range (TR) Display Y6 can only be replaced as a set with the instrument cluster.

Scheme 1254

1. Location: On relay carrier in E-box, plenum chamber.

Voltage is supplied differently via terminal 87

1 - Starter Interlock Alarm System Relay J60 - only in vehicles with 2.4 L gasoline engine

3 - Motronic Engine Control Module (ECM) Power Supply Relay J271 - in all other vehicles with gasoline engine

3 - Power Supply Relay (terminal 30, B+) J317 - in vehicles with Diesel engine

4 - Park/Neutral Position (PNP) Relay J226 (up to 10.04) or Starting Interlock Relay J207 (as of 11.04)

Note. In vehicles as of 11.04, activation of reverse driving lights occurs via CAN-Bus.

Scheme 1255

1. Location: Brake light switch - arrow - is located in brake pedal assembly.

Note. Switch is only to be installed once so as to ensure a firm fit.

Scheme 1256

1. Location: In accelerator pedal module - arrow -.

Note. In vehicles with gasoline engine, Kick Down Switch F8 adopts the functions of Throttle Position (TP) Sensor G79 and Accelerator Pedal Position Sensor 2 G185.

Shift mechanism (through VIN 8E_6A156499), servicing

Shift mechanism (through VIN 8E_6A156499), checking

Overview

1. 1. Selector mechanism function test --> «Selector mechanism function test»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-mechanism-function-test)
2. 2. Checking ignition key removal lock --> «Check ignition key withdrawal lock»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__check-ignition-key-withdrawal-lock)
3. 3. Locking button on selector lever handle, checking --> «Check locking button on selector lever handle»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__check-locking-button-on-selector-lever)

1. If shift mechanism does not function as described, perform "Guided Fault Finding" with Vehicle Diagnosis, Testing and Information System VAS 5051B.

Selector mechanism function test

1. In selector lever positions "S" , "D" , "R" and "Tiptronic gate" the starter motor will not operate.
2. If selector lever position "N" is selected at speeds greater than 5 km/h, the selector lever lock solenoid must not engage and block selector lever. Selector lever can be shifted into driving gear.
3. For speeds below 2 km/h (almost standstill) and shifting into selector lever position "N" , the shift lock solenoid must only engage after approx. 1 second. Selector lever can only be shifted out of position "N" with brake pedal operated.

Selector lever in "P" position and ignition switched on

1. Do not operate brake pedal.

1. Selector lever is locked and also cannot be shifted out of position "P" while locking button on selector lever handle is pressed. Shift Lock Solenoid N110 blocks selector lever.

1. Press brake pedal and hold.

1. Shift Lock Solenoid N110 releases selector lever. It must be possible to select a driving mode without "hitching" while locking button on selector lever handle is pressed.
2. Slowly shift selector lever from "P" through "R, N, D, S" , checking whether Transmission Range (TR) Display Y6 in instrument cluster matches selector lever position.

Selector lever in "N" position and ignition switched on

1. Do not operate brake pedal.

1. Up to approx. 08.01: Selector lever is locked and cannot be shifted out of position "N" without pressing button on selector lever handle. Shift Lock Solenoid N110 blocks selector lever.
2. As of approx. 08.01: Selector lever is not locked immediately when rapidly shifting through position "N" (e.g. from "R" to "D"). This enables e.g. "forward and reverse maneuvers" when vehicle is stuck. Shift lock engages when selector lever is located in "N" for longer than approx. 1 s with brake not being pressed.

1. Operate brake pedal.

1. Shift Lock Solenoid N110 releases selector lever. It must be possible to select a driving mode without "hitching" while locking button on selector lever handle is pressed.

Selector lever in position "D" , ignition switched on

1. Shift selector lever into "Tiptronic gate".

1. Brightening of "D" symbol must go out in selector mechanism cover and "+" and "-" symbols must light up.
2. The Transmission Range (TR) Display Y6 in instrument cluster must change from "PRND" to "654321" or (from VIN 8E_5400001) from "PRNDS" to "7654321" when selector lever is shifted into "Tiptronic Gate".

If specified values are not obtained

1. Adjust selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .
2. Check ignition key removal lock.

Check ignition key withdrawal lock

1. Switch ignition key to driving position ("ignition on").
2. Press brake pedal and hold.

1. It must be possible to shift selector lever out of position "P" without "hitching" while locking button on selector lever handle is pressed.

1. Switch ignition off.

1. It should not be possible to remove ignition key when selector lever is in any other position than "P".

1. Place selector lever in position "P".

1. It must be possible to move ignition key into removal position without "sticking".

1. Remove ignition key.

1. It must be possible to remove ignition key only in position "P".
2. Selector lever cannot be shifted out of position "P" with locking button pressed and foot brake operated.

Check locking button on selector lever handle

Check locking button for ease of movement

1. It must be possible to press locking button without great force.
2. After releasing, the locking button must come all the way back out by itself

If specified values are not obtained

1. Check whether selector lever handle is installed correctly.
2. Check whether selector rod or selector lever is bent.

Function test

1. Ignition switched on

Locking button on selector lever handle must be pressed for the following shifts. If it is not pressed, the selector lever cannot be shifted into specified position.

1. "P" to "R" and also press brake pedal
2. "D" to "S"
3. "N" to "R" ; in standstill, also press brake pedal after long wait
4. "R" to "P"

If specified values are not obtained

1. Check whether selector lever handle is installed correctly.
2. Adjust selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .

Shift mechanism, through VIN 8E_6A156499, removing and installing

Removing

1. Remove selector lever handle --> «Selector lever handle (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-through-vin-8e_6a156499) .

Scheme 1257

1. Open ashtray in center console and remove trim panel - arrows -.
2. Remove air conditioning operating unit --> «87 AIR CONDITIONING»(/audi/a4/b6-2000-2006/remont/ac-compressor/#heating-air-conditioning) .
3. Remove ashtray in center console --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Scheme 1258

1. Release all 4 clips - arrows - and pull cover - 1 - with guide upwards to remove.
2. Disconnect connector from side of guide plate.
3. Disconnect electrical harness connector on Shift Lock Solenoid N110.

Scheme 1259

1. Disengage locking cable - arrows -.

Scheme 1260

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

Vehicles with 4-cyl. engine

Scheme 1261

1. Remove vehicle floor plates at inside left - 2 - and inside right - 1 -.

Scheme 1262

1. Remove rear cross member for vehicle floor, to do so remove bolts - 1 through 4 -.

All

Scheme 1263

1. Remove bolts - 1 to 6 - to remove front cross member for vehicle floor.

Note. Depicted in illustration for a vehicle with 4-cyl. engine.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

Scheme 1264

1. Disconnect exhaust system at double clamp - arrows -.

Note. Depicted in illustration for a vehicle with 4-cyl. engine.

1. Remove heat shield below shift mechanism.

Scheme 1265

1. Remove lower cover from shift mechanism - arrows -.
2. Detach selector lever cable sleeve from shift mechanism bottom cover and slide back.

Scheme 1266

1. Remove retaining clip - 1 - for selector lever cable on shift mechanism downward.
2. Pull plastic securing spring - 2 - slightly to front and push pin - 3 - upward only as far as necessary - arrow -.
3. Remove selector lever cable - 4 - from shift mechanism.

Note. Do not bend or kink the selector lever cable.

Scheme 1267

1. Remove nuts - arrows -.

Note. A second technician is required when detaching shift mechanism below vehicle.

1. Press holder clips - 1 - and - 2 - inward, at the same time pushing shift mechanism downward.

Installing

Installation is in reverse order of removal, note the following

1. Install selector lever cable --> «Selector lever cable, (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .
2. Install locking cable --> «Locking lever (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .
3. Adjust locking cable --> «Locking lever (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-lever-through-vin-8e_6a156499-adjusting) .
4. Install exhaust system and align it free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

1. Check shift mechanism --> «Shift mechanism (through VIN 8E_6A156499), checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-through-vin-8e_6a156499-checking) .

Torque specifications

Selector lever handle, shift mechanism cover (through VIN 8E_6A156499), assembly overview

Note. Lubricate bearing areas and slide surfaces with polycarbamide grease G 052 142 A2 .

Scheme 1268

1 - Selector lever

2 - Selector lever shaft piece

1. Removing and installing --> «Selector lever handle (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-through-vin-8e_6a156499)

3 - Selector lever handle

1. Removing and installing --> «Selector lever handle (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-through-vin-8e_6a156499)

4 - Cover

1. With selector scale and Tiptronic gate
2. Removing and installing --> «Tiptronic Switch F189 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-through-vin-8e_6a156499) and also unclipping symbol inserts

5 - Symbol panel

1. Clipped into cover

6 - Printed circuit board

1. With integrated Tiptronic Switch F189
2. Removing and installing --> «Tiptronic Switch F189 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-through-vin-8e_6a156499)
3. Switch consists of 3 Hall sensors, which are activated by a magnet on transverse slide of cover strip.
4. Before replacing circuit board when DTC "18161" is entered in DTC memory, first check adjustment of selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499)

7 - Cover strip

1. With solenoid for Tiptronic Switch F189 on transverse slide
2. Removing and installing --> «Tiptronic Switch F189 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-through-vin-8e_6a156499)

8 - Masking panel guide

Selector lever handle (through VIN 8E_6A156499), removing and installing

Removing

1. Place selector lever in position "D".

Scheme 1269

1. Rotate sleeve - 1 - to left and push downward as far as stop.
2. Carefully pull switch - 2 - just enough out of selector lever handle - 3 - until a cable tie can be inserted between button and selector lever handle.

Note. Do not pull out the button any further, otherwise the selector lever handle will be damaged.

1. Secure button in pulled-out position using cable tie - arrow - as shown in illustration.
2. Pull selector lever handle upward and off.

Installing

Installation is in reverse order of removal, note the following

1. Place selector lever in position "D".

Note. To install new selector lever handle - 3 - , button - 2 - must be pulled out as far as stop and secured with a cable tie - arrow - or using assembly aid included with new handle. If the button was not secured, it must not be pulled out from the handle using mechanical aids. Apply compressed air gun to bottom of handle and press button out with compressed air.

1. Place selector lever handle - 3 - completely onto selector lever - button - 2 - faces toward driver. When doing this, handle must engage into ring groove of selector lever.
2. Remove cable tie - arrow - or assembly aid, thereby button mechanism engages in vertical groove of selector lever. If necessary press button into selector lever handle.
3. Pull sleeve - 1 - upward and engage by rotating clockwise.

Shift mechanism cover (through VIN 8E_6A156499), removing and installing

Removing

1. Remove selector lever handle --> «Selector lever handle (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-through-vin-8e_6a156499) .

1. Open ashtray in center console and remove trim panel - arrows -.
2. Remove 2 retaining bolts for ashtray and lift ashtray at rear.

1. Release all 4 clips - arrows - and pull cover - 1 - with guide upwards to remove.
2. Disconnect connector from side of guide plate.

Installing

Installation is in reverse order of removal, note the following

1. Install selector lever handle --> «Selector lever handle (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-through-vin-8e_6a156499) .

Tiptronic Switch F189 (through VIN 8E_6A156499), removing and installing

1. If malfunctions at Tiptronic Switch F189 occur, check first whether magnet at control slide masking panel is properly secured and replace masking panel if necessary. Before replacing the printed circuit, check the wiring.

Removing

1. Remove cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .

Scheme 1270

1. Press down retaining hooks - arrows - and pull off cover - 2 - from guide - 1 -.
2. Remove circuit board with integrated Tiptronic Switch F189.

Scheme 1271

1. Check magnets - arrows - on cover strip for secure seating.

1. Cover strip must be replaced if a magnet is missing.

Installing

Installation is in reverse order of removal, note the following

1. Install cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .

Shift mechanism (through VIN 8E_6A156499,), assembly overview

Note. Lubricate bearing areas and slide surfaces with polycarbamide grease G 052 142 A2 .

Scheme 1272

1 - Shift mechanism bottom cover

2 - Bracket

1. For selector lever

3 - Bushing

4 - Tiptronic locking lever

5 - Pivot pin

6 - Selector lever

7 - Shift lock solenoid N110

1. > «Shift Lock Solenoid N110 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-lock-solenoid-n110-through-vin)

8 - Operating lever for locking cable

9 - Lock for locking cable

10 - Lever for locking cable

11 - Locking lever

12 - Shift lever guide

Note. If selector lever guide or shift unit is faulty, entire shift mechanism must be replaced. It is not possible to adjust both components using shop equipment.

13 - Nut

1. 10 Nm

14 - Shift unit

15 - Bushing

16 - Retaining bracket for selector lever

17 - Retaining clip

18 - Tiptronic locking lever

19 - Pivot pin

20 - Nut

1. 10 Nm

Shift mechanism (through VIN 8E_6A156499), disassembling and assembling

Disassembling

Note. Securing spring for locking cable, removing and installing Retaining spring for locking cable, removing and installing

6 - Selector lever

1. Place selector lever in position "D".
2. Remove shift lock solenoid - 7 - --> «Shift Lock Solenoid N110 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-lock-solenoid-n110-through-vin) .
3. Unclip selector lever guide - 12 -.
4. Release pivot pins - 5 - and - 19 - and pull them out from side.

1. Unclip retaining brackets - 2 - and - 16 -.
2. Pull off retaining clip - 17 -.
3. Swing locking lever - 11 - fully upwards.
4. Pull selector lever - 6 - with bushings - 3 - and - 15 - as well as Tiptronic locking levers - 4 - and - 18 - downward out of shift unit - 14 -.

Assembling

6 - Selector lever

1. Check whether selector lever is in position "D".
2. Swing locking lever - 11 - fully upwards.
3. Insert selector lever - 6 - from below into shift unit - 14 -.
4. Connect locking levers for Tiptronic - 4 - and - 18 - as well as bushings - 3 - and - 15 - on selector lever.

1. Press selector lever - 6 - with bushes into shift unit and position it with retaining clip - 17 -.
2. Engage retaining brackets - 2 - and - 16 - on shift unit.
3. Push pivot pins - 5 - and - 19 - into selector lever - 6 - until they engage.
4. Check whether mounting pins in Tiptronic locking lever engage.

1. Install shift lock solenoid - 7 - --> «Shift Lock Solenoid N110 (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-lock-solenoid-n110-through-vin) .
2. Clip in selector lever guide - 12 -.

Scheme 1273

Removing

1. To remove locking cable, slightly lift spring at top - arrow B -.
2. Unhook spring at retaining tab - arrow C - and remove toward top.

Installing

1. Insert spring - arrow B - from top and hook in at retaining clip - arrow C -.
2. Align spring so that it is seated evenly in groove - arrow A -.

Shift Lock Solenoid N110 (through VIN 8E_6A156499), removing and installing

Removing

1. Remove cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .
2. Disconnect electrical harness connector on Shift Lock Solenoid N110.

Scheme 1274

1. Release lugs and remove shift lock solenoid forward - arrows -.

Installing

Installation is in reverse order of removal, note the following

Scheme 1275

1. Press shift lock solenoid into guide until it engages; operating lever - 2 - of solenoid must engage in locking lever - 1 - on shift mechanism.
2. Install cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .

Selector lever cable and locking cable (through VIN 8E_6A156499), assembly overview

Note. Do not bend or kink the selector lever cable. Lightly grease eyelet and ball socket with polycarbamide grease G 052 142 A2 before installing.

Scheme 1276

1 - Nut

1. 23 Nm

2 - Selector lever cable

1. Do not bend or kink, lightly grease cable eye and ball socket before installing.
2. Removing and installing --> «Selector lever cable, (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499)
3. Adjusting --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499)
4. In case of damaged rubber boots, selector lever cable must be replaced

1. When installing, make sure that rubber sleeve on transmission side is not twisted

3 - Lock nuts

1. 13 Nm

4 - Boot for selector lever cable

1. To be buttoned into selector mechanism bottom cover

5 - Retaining clip

6 - Ignition/starter switch

1. with ignition key removal lock

7 - Locking cable

1. For ignition key removal lock
2. Not to be kinked
3. Removing and installing --> «Locking lever (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
4. Adjusting --> «Locking lever (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-lever-through-vin-8e_6a156499-adjusting)

8 - Bolt

1. 9 Nm

9 - Clamping screw

1. 13 Nm
2. For selector lever cable
3. Loosen 1 turn for adjusting, do NOT remove completely

10 - Pin

1. For selector lever cable
2. To remove selector lever cable, move plastic retaining spring at selector mechanism forward slightly and put screws upward, only as far as necessary.

11 - Retaining clip for selector lever cable

12 - Bracket for selector lever cable

13 - Bolt

1. 23 Nm

14 - Bracket for selector lever cable

Selector lever cable, (through VIN 8E_6A156499), removing and installing

Special tools, testers and auxiliary items required

Scheme 1277

1. Pry lever 80-200

Removing

1. Place selector lever in position "P".

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

Vehicles with 4-cyl. engine

1. Remove vehicle floor plates at inside left - 2 - and inside right - 1 -.

1. Remove rear cross member for vehicle floor, remove bolts - 1 through 4 - to do so.

All

1. Remove bolts - 1 through 6 - and remove front cross member for vehicle floor.

Note. Depicted in illustration for a vehicle with 4-cyl. engine.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at double clamp - arrows -.

Note. Depicted in illustration for a vehicle with 4-cyl. engine.

1. Remove heat shield below shift mechanism.

Scheme 1278

1. Remove bracket - 3 - for selector lever cable by first removing bolts - 2 -.

Scheme 1279

1. Using pry lever 80-200 , press selector lever cable - A - from lever for selector shaft - arrow -.

1. Remove lower cover from shift mechanism - arrows -.
2. Detach selector lever cable sleeve from shift mechanism bottom cover and slide back.

1. Remove retaining clip - 1 - for selector lever cable on shift mechanism downward.
2. Pull plastic securing spring - 2 - slightly to front and push pin - 3 - upward only as far as necessary - arrow -.

Note. Make sure that pin is not pushed fully out.

1. Remove selector lever cable - 4 - from shift mechanism.

Note. Do not bend or kink selector lever cable.

1. Loosen lock nuts - 6 - and remove selector lever cable - 5 - from support bracket - 4 -.

Note. Do not bend or kink selector lever cable.

Installing

Installation is in reverse order of removal, note the following

Note. Do not bend or kink selector lever cable. Lightly grease eyelet and ball socket of selector lever cable with polycarbamide grease G 052 142 A2 before installing.

Scheme 1280

1. Slide selector lever cable into shift mechanism and secure it with retaining clip - 1 -.

1. Installation position: Angled end of retaining clip points toward rear.

1. Insert end of selector lever cable - 4 - into selector lever joint.
2. Press pin - 3 - downward - arrow -.
3. Check whether plastic securing spring - 2 - has locked the pin.
4. Button selector lever cable boot into lower cover.

1. Bolt lower cover securely to shift mechanism - arrows -.

Scheme 1281

1. Tightly bolt selector lever cable - 5 - to support bracket - 4 - , tighten lock nuts - 6 - to 12 Nm.

Scheme 1282

1. Press selector shaft lever - A - on transmission completely toward rear - arrow - until parking lock engages.

1. Check whether selector lever is in position "P" , then press ball socket of selector lever cable - 5 - carefully onto lever for selector shaft - 7 -.

Note. Take care not to bend selector shaft lever when pressing it on; support it if necessary, as otherwise selector mechanism can no longer be adjusted properly.

1. Adjust selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .
2. Install exhaust system and align it free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

Torque specifications

Selector lever cable (through VIN 8E_6A156499), adjusting

Special tools, testers and auxiliary items required

Scheme 1283

1. Socket and key T40031

1. Remove cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .

Note. There is a distinction between vehicles with "PRND" shift mechanisms (up to model year 2004) and vehicles with "PRNDS" shift mechanisms (as of model year 2005). In vehicles with "PRND" shift mechanisms (through model year 2004), selector lever cable adjustment is performed in selector lever position "D". In vehicles with "PRNDS" shift mechanisms (from model year 2005), selector lever cable adjustment is performed in selector lever position "S".

Vehicles with "PRND" shift mechanisms

1. Place selector lever in position "D".

Scheme 1284

1. Loosen rear clamping screw on selector lever cable through hole in shift mechanism approx. one turn using socket and key T40031.

Note. Loosen clamping screw only approx. 1 turn. Do not remove. Clamping screw is only accessible in selector lever position "D". Selector lever must remain in position "D" while clamping screw is loose.

1. Carefully move selector lever lightly toward front and rear without shifting into another selector lever position, this releases the tension on selector lever cable.
2. Check exact position of selector lever in position "D" by pushing selector lever lightly towards drivers seat - arrow A -.

Note. Do not touch selector lever during the adjustment.

1. Without touching selector lever, tighten clamping screw in this position using socket and key T40031.

Vehicles with "PRNDS" shift mechanisms

1. Place selector lever in position "S".

Scheme 1285

1. Loosen rear clamping screw on selector lever cable through the hole in shift mechanism approx. one turn using socket and key T40031.

Note. Loosen clamping screw only 1 turn. Do not remove. Clamping screw is only accessible in selector lever position "S". The selector lever must remain in position "S" with clamping bolt loosened, otherwise the setting is not correct.

1. Carefully move selector lever forwards and backwards slightly without shifting to a different selector lever position.
2. Pull selector lever completely toward rear once more until it stops in position "S" and release selector lever.

Note. Do not touch selector lever during the adjustment.

1. Without touching selector lever, tighten clamping screw in this position using socket and key T40031.

Vehicles with "PRND" and "PRNDS" shift mechanisms

1. Install cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .
2. Check shift mechanism --> «Shift mechanism (through VIN 8E_6A156499), checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-through-vin-8e_6a156499-checking) .

Scheme 1286

Note. Using Vehicle Diagnosis, Testing and Information System VAS 5051 A , the position of Multi-Function Transmission Range (TR) Switch F125 can be compared to position on selector lever via On Board Diagnostic (OBD), 02 - Transmission electronics, 08 - Read measured value block, display group 2 in display field - 1 -.

If shift mechanism does not function properly after adjusting selector lever cable

1. Bring selector lever cable into basic setting --> «Selector lever cable (VIN through 8E_6A156499), bringing into basic setting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-vin-through-8e_6a156499) .

Torque specifications

Selector lever cable (VIN through 8E_6A156499), bringing into basic setting

Special tools, testers and auxiliary items required

1. Socket and key T40031

Work procedure

1. Remove cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .

Note. There is a distinction between vehicles with "PRND" shift mechanisms (up to model year 2004) and vehicles with "PRNDS" shift mechanisms (as of model year 2005).

Vehicles with "PRND" shift mechanisms

1. Place selector lever in position "D".

Note. Before performing basic setting, make sure that the clamping screw is tightened. It is accessible through the hole in shift mechanism in position "D" using socket and key T40031.

1. Tighten clamping screw in this position using socket and key T40031 (13 Nm).

Vehicles with "PRNDS" shift mechanisms

1. Place selector lever in position "S".

Note. Before performing basic setting, make sure that the clamping screw is tightened. It is accessible through the hole in shift mechanism in position "S" using socket and key T40031.

1. Tighten clamping screw in this position using socket and key T40031 (13 Nm).

Vehicles with "PRND" and "PRNDS" shift mechanisms

1. Place selector lever in position "P".

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

Scheme 1287

1. Remove support bracket for selector lever cable - 1 -.

Note. Make sure selector lever is in position "P".

1. Push lever for selector shaft - 2 - at transmission completely toward rear until parking lock engages.

Note. When parking lock is engaged, it must not be possible to turn both front wheels in one direction at the same time.

1. Make sure that selector lever cable has been routed free of kinks and tension.

1. Make sure that selector lever cable - 5 - is secured with nuts - 6 - to support bracket - 4 - (13 Nm).

1. Install support bracket for selector lever cable tightly to bracket - 1 -.
2. Adjust selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .

Torque specification

Scheme 1288

1 - Locking cable

Removing

Note. Do not kink locking cable.

1. Disconnect Ground (GND) wire at battery.
2. Remove storage compartment on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
3. Remove steering column trim --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
4. Remove A/C system operating unit --> «87 AIR CONDITIONING»(/audi/a4/b6-2000-2006/remont/ac-compressor/#heating-air-conditioning) .

1. Remove ashtray in center console --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
2. Remove cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .
3. Turn ignition key into driving position ("ignition on").
4. Place selector lever in position "P".

1. Lift retaining clip - 2 - from interlock lever and pull locking cable - 1 - out of ignition/starter switch.
2. Lift securing spring - 4 - for locking cable and pull locking cable support bracket - 5 - on shift mechanism sideways and disengage locking cable eye.

1 - Locking cable

Installing

Installation is in reverse order of removal, note the following

1. Route locking cable kink-free behind instrument panel strut - arrow -.
2. Turn ignition key into driving position ("ignition on").
3. Insert locking cable - 1 - into ignition/starter switch.
4. Check interlock lever - 2 -.

1. Bring ignition/starter switch into locking position ("ignition off").
2. Check whether selector lever is in position "P".
3. Engage locking cable eye into pin - 3 -.
4. Lift securing spring - 4 - slightly.

1. Slide locking cable support bracket - 5 - from right into shift mechanism until securing spring - 4 - engages.
2. Adjust locking cable --> «Locking lever (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-lever-through-vin-8e_6a156499-adjusting) .
3. Observe procedures for connecting battery --> «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment) 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET .

Locking lever (through VIN 8E_6A156499), adjusting

Special tools, testers and auxiliary items required

Scheme 1289

1. Adjustment pin for shift lock 3 3352 A
2. Safety glasses

Work preparations

Note. The procedure described below will save you the effort of removing the center console.

Scheme 1290

1. Cut through adjustment pin for shift lock 3 3352 A at rear end of flat area - arrow - using a cutting grinder.

1. Order a new adjustment pin for shift lock as a replacement for other use.

Work procedure

1. Position steering wheel column adjustment all the way and back toward drivers seat.
2. Remove cover for shift mechanism --> «Shift mechanism cover (through VIN 8E_6A156499), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-through-vin-8e_6a156499) .
3. Remove ashtray in center console --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

Scheme 1291

1. Loosen bolt - 1 -.

1. Support bracket - 2 - of locking cable must be movable by hand

1. Insert adjustment pin for shift lock 3 3352 A between pin on locking cable lever and locking cable eye.
2. Pull locking cable in direction of - arrow - and tighten bolt to 9 Nm.
3. Remove adjustment pin.
4. Check ignition key removal lock after every adjustment of locking cable --> «Shift mechanism (through VIN 8E_6A156499), checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-through-vin-8e_6a156499-checking) .

Torque specification

Shift mechanism (from VIN 8E_6A156500), servicing

Shift mechanism (from VIN 8E_6A156500), checking

Overview

1. 1. Selector mechanism function test «Selector mechanism function test»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. 2. Checking ignition key removal lock «Check ignition key withdrawal lock»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
3. 3. Locking button on selector lever handle, checking «Check locking button on selector lever handle»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)

1. If shift mechanism does not function as described, perform "Guided Fault Finding" with Vehicle Diagnosis, Testing and Information System VAS 5051B.

1. In selector lever positions "S" , "D" , "R" and "Tiptronic gate" starter motor will not operate.
2. If selector lever position "N" is selected at speeds greater than 5 km/h, selector lever lock solenoid must not engage and block selector lever. Selector lever can be shifted into driving gear.
3. For speeds below 2 km/h (almost standstill) and shifting into selector lever position "N" , the shift lock solenoid must only engage after approx. 1 second. Selector lever can only be shifted out of position "N" with brake pedal operated.

Selector lever in "P" position and ignition switched on

1. Do not operate brake pedal.

1. Selector lever is locked and also cannot be shifted out of position "P" while locking button on selector lever handle is pressed. Shift Lock Solenoid N110 blocks selector lever.

1. Press brake pedal and hold.

1. Shift Lock Solenoid N110 releases selector lever. It must be possible to select a driving mode without "hitching" while locking button on selector lever handle is pressed.
2. Slowly shift selector lever from "P" through "R, N, D, S" , checking whether Transmission Range (TR) Display Y6 in instrument cluster matches selector lever position.

Selector lever in "N" position and ignition switched on

1. Do not operate brake pedal.

1. Selector lever is not locked immediately when rapidly shifting through position "N" (e.g. from "R" to "D"). This enables e.g. "forward and reverse maneuvers" when vehicle is stuck. Shift lock engages when selector lever is located in "N" for longer than approx. 1 s with brake not being pressed.

1. Operate brake pedal.

1. Shift Lock Solenoid N110 releases selector lever. It must be possible to select a driving mode without "hitching" while locking button on selector lever handle is pressed.

Selector lever in position "D" , ignition switched on

1. Shift selector lever into "Tiptronic gate".

1. Brightening of "D" symbol must go out in selector mechanism cover and "+" and "-" symbols must light up.
2. The Transmission Range (TR) Display Y6 in instrument cluster should switch from "PRNDS" to "7654321" when selector lever is shifted into "Tiptronic gate".

If specified values are not obtained

1. Adjust selector lever cable --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500) .
2. Check ignition key removal lock.

1. Switch ignition key to driving position ("ignition on").
2. Press brake pedal and hold.

1. It must be possible to shift selector lever out of position "P" without "hitching" while locking button on selector lever handle is pressed.

1. Switch ignition off.

1. It should not be possible to remove ignition key when selector lever is in any other position than "P".

1. Place selector lever in position "P".

1. It must be possible to move ignition key into removal position without "sticking".

1. Remove ignition key.

1. It must be possible to remove ignition key only in position "P".
2. Selector lever cannot be shifted out of position "P" with locking button pressed and parking brake operated.

Check locking button for ease of movement

1. It must be possible to press locking button without great force.
2. After releasing, locking button must come all the way back out by itself

If specified values are not obtained

1. Check whether selector lever handle is installed correctly.
2. Check whether selector rod or selector lever is bent.

Function test

1. Ignition switched on

Locking button on selector lever handle must be pressed for the following shifts. If it is not pressed, selector lever cannot be shifted into specified position.

1. "P" to "R" and also press brake pedal
2. "D" to "S"
3. "N" to "R" ; in standstill, also press brake pedal after long wait
4. "R" to "P"

If specified values are not obtained

1. Check whether selector lever handle is installed correctly.
2. Adjust selector lever cable --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500) .

Selector lever handle, shift mechanism cover (from VIN 8E_6A156500), assembly overview

Note. Lubricate bearing areas and slide surfaces with polycarbamide grease G 052 142 A2 .

1 - Selector lever

2 - Selector lever shaft piece

1. Removing and installing --> «Selector lever handle (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-from-vin-8e_6a156500)

3 - Selector lever handle

1. Removing and installing --> «Selector lever handle (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-from-vin-8e_6a156500)

4 - Cover

1. With selector scale and Tiptronic gate
2. Removing and installing --> «Tiptronic Switch F189 (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-from-vin-8e_6a156500) and also unclipping symbol inserts

5 - Symbol panel

1. Clipped into cover

6 - Printed circuit board

1. With integrated Tiptronic Switch F189
2. Removing and installing --> «Tiptronic Switch F189 (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-from-vin-8e_6a156500)
3. Switch consists of 3 Hall sensors, which are activated by a magnet on transverse slide of cover strip.
4. Before replacing circuit board when DTC "18161" is entered in DTC memory, first check adjustment of selector lever cable --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500)

7 - Cover strip

1. With solenoid for Tiptronic Switch F189 on transverse slide
2. Removing and installing --> «Tiptronic Switch F189 (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__tiptronic-switch-f189-from-vin-8e_6a156500)

8 - Masking panel guide

Selector lever handle (from VIN 8E_6A156500), removing and installing

Removing

1. Place selector lever in position "D".

1. Rotate sleeve - 1 - to left and push downward as far as stop.
2. Carefully pull switch - 2 - just enough out of selector lever handle - 3 - until a cable tie can be inserted between button and selector lever handle.

Note. Do not pull out the button any further, otherwise the selector lever handle will be damaged.

1. Secure button in pulled-out position using cable tie - arrow - as shown in illustration.
2. Pull selector lever handle upward and off.

Installing

Installation is in reverse order of removal, note the following

1. Place selector lever in position "D".

Note. To install new selector lever handle - 3 - , button - 2 - must be pulled out as far as stop and secured with a cable tie - arrow - or using assembly aid included with new handle. If the button was not secured, it must not be pulled out from the handle using mechanical aids. Apply compressed air gun to bottom of handle and press button out with compressed air.

1. Place selector lever handle - 3 - completely onto selector lever - button - 2 - faces toward driver. When doing this, handle must engage into ring groove of selector lever.
2. Remove cable tie - arrow - or assembly aid, thereby the button mechanism engages in the vertical groove of the selector lever. If necessary press button into selector lever handle.
3. Pull sleeve - 1 - upward and engage by rotating clockwise.

Shift mechanism cover (from VIN 8E_6A156500), removing and installing

Removing

1. Remove selector lever handle --> «Selector lever handle (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-from-vin-8e_6a156500) .

1. Open ashtray in center console and remove trim panel - arrows -.
2. Remove 2 retaining bolts for ashtray and lift ashtray at rear.

1. Release all 4 clips - arrows - and pull cover - 1 - with guide upwards to remove.
2. Disconnect connector from the side of the guide plate.

Installing

Installation is in reverse order of removal, note the following

1. Install selector lever handle --> «Selector lever handle (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-from-vin-8e_6a156500) .

Tiptronic Switch F189 (from VIN 8E_6A156500), removing and installing

1. If malfunctions at Tiptronic Switch F189 occur, first check whether magnet at control slide masking panel is properly secured and replace masking panel if necessary. Before replacing the printed circuit, check the wiring.

To replace Tiptronic switch, circuit board must be replaced.

Removing

1. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .

1. Press down retaining hooks - arrows - and pull off cover - 2 - from guide - 1 -.
2. Remove circuit board with integrated Tiptronic Switch F189.

1. Check magnets - arrows - on cover strip for secure seating.

1. Cover strip must be replaced if a magnet is missing.

Installing

Installation is in reverse order of removal, note the following

1. Install cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .

Shift mechanism (from VIN 8E_6A156500), assembly overview

Note. Lubricate bearing areas and slide surfaces with polycarbamide grease G 052 142 A2 .

Scheme 1292

1 - Rubber seal

2 - Press tube

3 - Bolt, 2 Nm

1. Qty. 4

4 - Selector mechanism function unit

5 - Shift lock solenoid N110

1. > «Shift Lock Solenoid N110 (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)

6 - Noise insulation

1. Not installed on all vehicles

7 - Lock washers

1. Qty. 4, always replace
2. For securing sound insulation on selector mechanism function unit

8 - Retaining clip

1. Secures selector lever cable on selector mechanism function unit

9 - Selector lever cable

1. > «Selector lever cable (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500)
2. Adjusting --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500)

10 - O-Ring

1. Always replace

Shift mechanism (from VIN 8E_6A156500), removing and installing

Special tools, testers and auxiliary items required

1. Socket and key T40031

Removing

1. Remove selector lever handle --> «Selector lever handle (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-from-vin-8e_6a156500) .
2. Remove air conditioning operating unit --> «87 AIR CONDITIONING»(/audi/a4/b6-2000-2006/remont/ac-compressor/#heating-air-conditioning) .
3. Remove ashtray in center console --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .

1. Release all 4 clips - arrows - and pull cover - 1 - with guide upwards to remove.
2. Disconnect connector from side of guide plate.
3. Disconnect electrical harness connector on Shift Lock Solenoid N110.

Scheme 1293

1. Raise retaining tab - A - and remove locking lever in direction of - arrow -.
2. Place selector lever in position "D".

1. Loosen rear clamping screw on selector lever cable through hole in shift mechanism approx. one turn using socket and key T40031.

Note. Loosen clamping screw only approx. 1 turn. Do not remove. Clamping screw is only accessible in selector lever position "D". Selector lever must remain in position "D" while clamping screw is loose.

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

Scheme 1294

1. Remove tunnel braces --> «66 EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior) «66 - EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) for BODY EXTERIOR - CABRIOLET

Scheme 1295

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at double clamps - arrows -.
2. Remove heat shield under shift mechanism --> «66 EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior) «66 - EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) for BODY EXTERIOR - CABRIOLET

For vehicles with noise insulation - A - under shift mechanism

1. Remove lock washers - arrows -.

Note. Always replace lock washers

1. Remove sound insulation - A - and slide forward.

All

Scheme 1296

1. Remove selector lever cable retaining clip - 1 - sideways.
2. Remove selector lever cable - 2 - from shift mechanism.

Note. Do not bend or kink the selector lever cable.

1. Remove nuts - arrows -.

Note. A second technician is required when detaching shift mechanism below vehicle.

1. Press holder clips - 1 - and - 2 - inward, at the same time pushing shift mechanism downward.

Installing

Installation is in reverse order of removal, note the following

1. Install selector lever cable --> «Selector lever cable (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500) .
2. Install locking cable --> «Locking lever (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-lever-from-vin-8e_6a156500-removing) .
3. Adjust locking cable --> «Locking cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-cable-from-vin-8e_6a156500-adjusting) .
4. Install exhaust system and align it free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

1. Check shift mechanism --> «Shift mechanism (from VIN 8E_6A156500), checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-from-vin-8e_6a156500-checking) .

Torque specifications

Scheme 1297

Removing

1. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
2. Disconnect electrical harness connector on Shift Lock Solenoid N110.
3. Press retaining hooks - A - into shift mechanism - arrow - and hold it down.

Note. If retaining hook - A - is broken off, selector mechanism function unit must be replaced.

Scheme 1298

1. Tip Shift Lock Solenoid N110 down and out in direction of - arrow - so that ball head - 1 - disengages from operating lever on shift mechanism.
2. Remove Shift Lock Solenoid N110.

Installing

Installation is in reverse order of removal, note the following

1. Rotate ball head - 1 - to correct installation position.
2. Guide Shift Lock Solenoid N110 diagonally from above into shift mechanism.
3. Tip Shift Lock Solenoid N110 down in opposite direction of - arrow -.

1. Ball head - 1 - must be completely engaged in operating lever on shift mechanism.
2. Secure Shift Lock Solenoid N110 on retaining hook - A -.
3. Install cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .

Selector lever cable and locking cable (from VIN 8E_6A156500), assembly overview

Note. Do not bend or kink selector lever cable. Lightly grease eyelet and ball socket with polycarbamide grease G 052 142 A2 before installing.

Scheme 1299

1 - Selector lever cable

1. Do not bend or kink, lightly grease cable eye and ball socket before installing.
2. Removing and installing --> «Selector lever cable (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500)
3. Adjusting --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500)
4. In case of damaged rubber boots, selector lever cable must be replaced

1. When installing, make sure that rubber sleeve on transmission side is not twisted

2 - Lock nuts

1. 13 Nm

3 - Retaining clip

4 - Ignition/starter switch

1. With ignition key removal lock

5 - Locking cable

1. For ignition key removal lock
2. Not to be kinked
3. Removing and installing --> «Locking lever (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-lever-from-vin-8e_6a156500-removing)
4. Adjusting --> «Locking cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-cable-from-vin-8e_6a156500-adjusting)

6 - Bolt

1. 9 Nm

7 - Clamping screw

1. 13 Nm
2. For selector lever cable
3. Loosen 1 turn for adjusting, do NOT remove completely

8 - O-Ring

1. Always replace

9 - Retaining clip for selector lever cable

10 - Bolt

1. 20 Nm
2. For securing bracket to selector lever cable bracket

11 - Bracket for selector lever cable

1. Different equipment depending on version

12 - Bolt

1. 20 Nm
2. Qty. 3
3. For securing selector lever cable bracket to transmission

13 - Bracket for selector lever cable

1. Different equipment depending on version

Selector lever cable (from VIN 8E_6A156500), removing and installing

Special tools, testers and auxiliary items required

1. Pry lever 80-200

1. Socket and key T40031

Removing

1. Remove selector lever handle --> «Selector lever handle (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-handle-from-vin-8e_6a156500) .
2. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
3. Place selector lever in position "D".

1. Loosen rear clamping screw on selector lever cable through hole in shift mechanism approx. one turn using socket and key T40031.

Note. Loosen clamping screw only approx. 1 turn. Do not remove. Clamping screw is only accessible in selector lever position "D". Selector lever must remain in position "D" while clamping screw is loose.

Removing

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

1. Remove tunnel braces --> «66 EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior) «66 - EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) for BODY EXTERIOR - CABRIOLET

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at double clamps - arrows -.
2. Remove heat shield under shift mechanism --> «66 EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior) «66 - EXTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) for BODY EXTERIOR - CABRIOLET

For vehicles with noise insulation - A - under shift mechanism

Scheme 1300

1. Remove lock washers - arrows -.

Note. Always replace lock washers

1. Remove sound insulation - A - and slide forward.

All

1. Remove selector lever cable retaining clip - 1 - sideways.
2. Remove selector lever cable - 2 - from shift mechanism.

Note. Do not bend or kink selector lever cable.

Installing

Installation is in reverse order of removal, note the following

Torque specifications --> Selector lever cable and locking cable (from VIN 8E_6A156500), assembly overview

Note. Do not bend or kink selector lever cable. Lightly grease eyelet and ball socket of selector lever cable with polycarbamide grease G 052 142 A2 before installing.

For vehicles with noise insulation - A - under shift mechanism

1. Slide noise insulation - A - over opening on selector lever cable.

All

Scheme 1301

1. Replace O-ring - 1 - on selector lever cable.
2. Slide selector lever cable into shift mechanism - arrow -.

1. Secure selector lever cable - 2 - to shift mechanism with retaining clip - 1 -.

1. Installation position: Angled end of retaining clip faces toward shift mechanism.

For vehicles with noise insulation - A - under shift mechanism

1. Secure sound insulation to shift mechanism with four new lock washers - arrows -.

All

1. Tightly bolt selector lever cable - 5 - to support bracket - 4 - , tighten lock nuts - 6 -.

1. Press selector shaft lever - A - on transmission completely toward rear - arrow - until parking lock engages.

Note. When parking lock is engaged, it must not be possible to turn both front wheels in one direction at the same time.

1. Then press selector shaft forward 3 detents, so transmission is in "D" position.
2. Ensure selector lever in vehicle is also in "D" position.

1. Carefully press selector lever cable ball socket - 5 - onto selector shaft lever - 7 - in this position.

Note. Take care not to bend selector shaft lever when pressing it on; support it if necessary, as otherwise selector mechanism can no longer be adjusted properly.

1. Check exact position of selector lever in position "D" by pushing selector lever lightly towards drivers seat - arrow A -.

Note. Do not touch selector lever during the adjustment.

1. Tighten clamping screw with Socket T40031 through hole in shift mechanism while in this position, without touching selector lever.
2. Adjust selector lever cable --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500) .
3. Install exhaust system and align it free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

Selector lever cable (from VIN 8E_6A156500), adjusting

Special tools, testers and auxiliary items required

1. Socket and key T40031

1. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
2. Place selector lever in position "D".

1. Loosen rear clamping screw on selector lever cable through hole in shift mechanism approx. one turn using socket and key T40031.

Note. Loosen clamping screw only approx. 1 turn. Do not remove. Clamping screw is only accessible in selector lever position "D". Selector lever must remain in position "D" while clamping screw is loose.

1. Carefully move selector lever lightly toward front and rear without shifting into another selector lever position, this releases the tension on selector lever cable.
2. Check exact position of selector lever in position "D" by pushing selector lever lightly towards drivers seat - arrow A -.

Note. Do not touch selector lever during the adjustment.

1. Without touching selector lever, tighten clamping screw in this position using socket and key T40031.
2. Install cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
3. Check shift mechanism --> «Shift mechanism (from VIN 8E_6A156500), checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-from-vin-8e_6a156500-checking) .

Note. Using Vehicle Diagnosis, Testing and Information System VAS 5051 A , the position of Multi-Function Transmission Range (TR) Switch F125 can be compared to position on selector lever via On Board Diagnostic (OBD), 02 - Transmission electronics, 08 - Read measured value block, display group 2 in display field - 1 -.

If shift mechanism does not function properly after adjusting selector lever cable

1. Bring selector lever cable into basic setting --> «Selector lever cable, from VIN 8E_6A156500), bringing into basic setting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500) .

Torque specifications

Selector lever cable, from VIN 8E_6A156500), bringing into basic setting

Special tools, testers and auxiliary items required

1. Socket and key T40031

Work procedure

1. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
2. Place selector lever in position "D".

Note. Before performing basic setting, make sure that the clamping screw is tightened. It is accessible through hole in shift mechanism in position "D" using socket and key T40031.

1. Tighten clamping screw in this position using socket and key T40031 (13 Nm).
2. Place selector lever in position "P".

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

1. Remove support bracket for selector lever cable - 1 -.

Note. Make sure selector lever is in position "P".

1. Push lever for selector shaft - 2 - at transmission completely toward rear until parking lock engages.

Note. When parking lock is engaged, it must not be possible to turn both front wheels in one direction at the same time.

1. Make sure that selector lever cable has been routed free of kinks and tension.

1. Make sure that selector lever cable - 5 - is secured with nuts - 6 - to support bracket - 4 - (13 Nm).

1. Install support bracket for selector lever cable tightly to bracket - 1 -.
2. Adjust selector lever cable --> «Selector lever cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-from-vin-8e_6a156500) .

Torque specification

Locking lever (from VIN 8E_6A156500), removing and installing

Overview

Scheme 1302

1 - Locking cable

2 - Retaining clip

3 - Locking cable eye pins

4 - Locking cable bracket

5 - Bolt, 10 Nm

1. For adjusting locking cable

Removing

Note. Do not kink locking cable.

1. Disconnect Ground (GND) wire at battery.
2. Remove storage compartment on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
3. Remove steering column trim --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
4. Remove A/C system operating unit --> «87 AIR CONDITIONING»(/audi/a4/b6-2000-2006/remont/ac-compressor/#heating-air-conditioning) .

1. Remove ashtray in center console --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
2. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
3. Turn ignition key into driving position "ignition on".
4. Place selector lever in position "P".

Scheme 1303

1. Lift retaining clip - 2 - from interlock lever and pull locking cable - 1 - out of ignition/starter switch.

1. Raise retaining tab - A - and remove locking lever in direction of - arrow - from locking cable eye pins.

Installing

Installation is in reverse order of removal, note the following

Scheme 1304

1. Route locking cable without kinks under wiring harness - arrow A - and behind instrument panel brace - arrow B -.
2. Turn ignition key into driving position "ignition on".

1. Insert locking cable - 1 - into ignition/starter switch.
2. Check interlock lever - 2 -.
3. Bring ignition/starter switch into locking position "ignition off".
4. Check whether selector lever is in position "P".

1. Slide locking cable in opposite in direction of - arrow - onto locking cable eye pins.

1. The retaining tab - A - must engage over locking cable

1. Adjust locking cable --> «Locking cable (from VIN 8E_6A156500), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__locking-cable-from-vin-8e_6a156500-adjusting) .
2. Observe procedures for connecting battery --> «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment) 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET .

Locking cable (from VIN 8E_6A156500), adjusting

Special tools, testers and auxiliary items required

1. Adjustment pin for shift lock 3 3352 A
2. Safety glasses

Work preparations

Note. The procedure described below will save you the effort of removing the center console.

1. Cut through adjustment pin for shift lock 3 3352 A at rear end of flat area - arrow - using a cutting grinder.

1. Order a new adjustment pin for shift lock as a replacement for other use.

Work procedure

1. Position steering wheel column adjustment all the way and back toward drivers seat.
2. Remove cover for shift mechanism --> «Shift mechanism cover (from VIN 8E_6A156500), removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-cover-from-vin-8e_6a156500) .
3. Remove ashtray in center console --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
4. Place selector lever in position "P".

1. Loosen bolt - 1 -.

1. Support bracket - 2 - of locking cable must be movable by hand

1. Insert adjustment pin for shift lock 3 3352 A between pin on locking cable lever and locking cable eye.
2. Pull locking cable in direction of - arrow - and tighten bolt to 10 Nm.
3. Remove adjustment pin.
4. Check ignition key removal lock after every adjustment of locking cable --> «Shift mechanism (from VIN 8E_6A156500), checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__shift-mechanism-from-vin-8e_6a156500-checking) .

Torque specification

Transmission, removing and installing

Overview

1. > «Transmission (vehicles with 1.8 L turbo engine, also Audi Cabriolet), removing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j)
2. > «Transmission (vehicles with 2.0 L normally-aspirated engine, also Audi Cabriolet), removing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-vehicles-with-20-l-normally-aspirated)
3. > «Transmission (vehicles with 2.0 L TFSI engine, also Audi Cabriolet), removing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-vehicles-with-20-l-tfsi)
4. > «Transmission (vehicles with 6-cyl. 3.0 L gasoline engine, also Audi Cabriolet), removing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-vehicles-with-6-cyl-30-l)

1. > «Transmission (vehicles with 6-cyl. 3.2 L FSI gasoline engine, also Audi Cabriolet), removing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-vehicles-with-6-cyl-32-l)
2. > «Installing transmission»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__installing-transmission)

Scheme 1305

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222 A
2. Pry lever 80-200
3. Transmission support 3282
4. Adjustment plate 3282/30

1. Engine/Gearbox Jack V.A.G 1383 A

Special tools, testers and auxiliary items required

Scheme 1306

1. Fender insert pads T40045

Work procedure

1. Place selector lever in position "P".

Scheme 1307

1. Slide cover over battery to right - arrow 1 - and pull it off upwards - arrow 2 -.

Scheme 1308

1. With ignition switched off, disconnect Battery Ground (GND) wire - arrow -.

Scheme 1309

1. Remove engine cover - arrows -.

Scheme 1310

1. Pull off sealing rubber at bolted flanges of fender.
2. To prevent damage to bolted flanges of fender when using engine support bridge 10-222 A , insert fender insert pads T40045 on both sides between bolted flange of fender and web plate lying beneath.

Scheme 1311

1. Position engine support bridge 10-222 A onto bolted flange of fenders; spindle stands at rear.
2. Expose rear lifting eye on engine.
3. Connect hook on spindle with lifting eye on back of engine.
4. Take up some of the engine weight by tightening spindle of support bar, but do not lift.

1. Remove both front wheels.

Scheme 1312

1. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Remove bolts or quick-release screws - 1 to 3 - and remove noise insulation at front and rear.

Scheme 1313

1. Remove noise insulation bracket - arrows -.

1. Remove vehicle floor plates at inside left - 2 - and inside right - 1 -.

1. Remove bolts - 1 through 4 - and remove rear cross member for vehicle floor

1. Remove bolts - 1 to 6 - and remove front cross member for vehicle floor.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at double clamp - arrows -.
2. Remove heat shield for exhaust system.

Scheme 1314

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood inserted in between - 1 - on transmission at bottom.
2. Support tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

Scheme 1315

1. First remove bolts - 1 - and - 2 - , then bolts - 3 - and - 4 -.
2. Slowly lower tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

Scheme 1316

1. Remove nuts - arrows - and remove tunnel cross member.

Scheme 1317

1. Remove heat shield - 1 - for right drive axle.
2. Remove drive axle from transmission flange on left and right sides --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .
3. Remove front exhaust pipe bracket - 1 -.

Scheme 1318

1. Remove bolts - arrows - for front exhaust pipe/catalytic converter.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Remove front exhaust pipe.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Place an oil receptacle underneath transmission.

Scheme 1319

1. Remove union nuts - 1 - and - 2 - and disconnect ATF lines.
2. Remove bracket for ATF-lines - arrows -.

Scheme 1320

1. Remove ATF filter on transmission - arrows -.

Scheme 1321

1. Remove union nuts - 1 - and - 2 - and disconnect ATF lines.
2. Remove bracket for ATF-lines - arrows -.

Scheme 1322

1. Remove bolt - arrow - and remove ATF lines from transmission.
2. Disconnect ATF lines.

For transmission with right-angled connector

Scheme 1323

1. Disengage harness connector - A - in direction of - arrow - and disconnect it from transmission.
2. Free up wiring harness.

For transmission with round connector

Scheme 1324

1. Disengage electrical harness connector - 1 - and disconnect from transmission.
2. Move wiring harness clear - arrows -.

All

1. Remove bracket - 3 - for selector lever cable by first removing bolts - 2 -.

1. Using pry lever 80-200 , press selector lever cable - A - from lever for selector shaft - arrow -.

Scheme 1325

1. Remove bolts - 2 - and remove transmission support - 1 - from transmission.

Scheme 1326

1. Remove bolts - 1 to 5 - and - 11 - on engine/transmission flange.
2. Loosen bolt - 6 - only and then tighten by hand.

Note. Starter must not be removed.

1. Mount transmission support 3282 on Engine/Transmission Jack V.A.G 1383 A.

Scheme 1327

1. Set Template 3282/30 on to transmission support 3282 (template only installs in one position).
2. Align arms of transmission support to correspond with holes in adjustment plate.
3. Attach support elements on adjustment plate, as illustrated.

Scheme 1328

1. Move engine/transmission jack V.A.G 1383 A with transmission mount 3282 under transmission and support transmission.

Note. The arrow symbol on the adjusting plate points in direction of travel.

1. Align template parallel to transmission and secure to transmission using a bolt M10 x 20 - arrow -.

Audi Cabriolet

Note. So that the 4 engine/transmission connecting bolts at bottom can be removed on the Audi Cabriolet, the following work steps must also be performed

1. Raise transmission slightly using Engine/Transmission Jack V.A.G 1383 A.

Scheme 1329

1. Remove torque support - arrows -.

Scheme 1330

1. Remove left and right nuts - 1 - and swing stabilizer bar - 2 - downward.
2. Remove nuts - 3 - at engine mount on left and right far enough until lower edge of nut is flush with threaded pin - arrow -.
3. Raise engine using engine support bridge 10-222 A far enough until both nuts - 3 - (on left and right sides) make contact on plate from below.

All

1. Remove bolts - 7 to 10 - at engine/transmission flange.

Audi Cabriolet

1. Lower engine again.
2. Lower transmission again slowly.

All

1. Tie up drive axles.
2. Remove last engine/transmission mounting bolt.
3. Press off transmission from bushings and let it down carefully.

Transmission (vehicles with 2.0 L normally-aspirated engine, also Audi Cabriolet), removing

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222 A
2. Pry lever 80-200
3. Transmission support 3282
4. Adjustment plate 3282/30

1. Engine/Transmission Jack V.A.G 1383 A

Special tools, testers and auxiliary items required

1. Fender insert pads T40045

Work procedure

1. Place selector lever in position "P".

1. Slide cover over battery to right - arrow 1 - and pull it off upwards - arrow 2 -.

1. With ignition switched off, disconnect Battery Ground (GND) wire - arrow -.

Scheme 1331

1. Remove engine cover - arrows -.

Scheme 1332

1. Disconnect air guide hose between Mass Air Flow (MAF) sensor and intake manifold - arrows -.

1. Pull off sealing rubber at bolted flanges of fender.
2. To prevent damage to bolted flanges of fender when using engine support bridge 10-222 A , insert fender insert pads T40045 on both sides between bolted flange of fender and web plate lying beneath.

1. Position engine support bridge 10-222 A onto bolted flange of fenders; spindle stands at rear.
2. Expose rear lifting eye on engine.
3. Connect hook on spindle with lifting eye on back of engine.
4. Take up some of the engine weight by tightening spindle of support bar, but do not lift.

1. Remove both front wheels.
2. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Remove bolts or quick-release screws - 1 to 3 - and remove noise insulation at front and rear.

1. Remove noise insulation bracket - arrows -.

1. Remove vehicle floor plates at inside left - 2 - and inside right - 1 -.

1. Remove bolts - 1 through 4 - and remove rear cross member for vehicle floor.

1. Remove bolts - 1 to 6 - to remove front cross member for vehicle floor.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at double clamp - arrows -.
2. Remove heat shield for exhaust system.

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood inserted in between - 1 - on transmission at bottom.
2. Support tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. First remove bolts - 1 - and - 2 - , then bolts - 3 - and - 4 -.
2. Slowly lower tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. Remove nuts - arrows - and remove tunnel cross member.

1. Remove heat shield - 1 - for right drive axle.
2. Remove drive axle from transmission flange on left and right sides --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .

1. Remove front exhaust pipe bracket - 1 -.
2. Remove bolts front exhaust pipe/catalytic converter - arrows -.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Remove front exhaust pipe.

Scheme 1333

1. Remove bracket for ATF-lines - arrow -.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Place an oil receptacle underneath transmission.
2. Remove bolt - arrow - and remove ATF lines from transmission.
3. Move ATF lines clear to one side and secure in place.

For transmission with right-angled connector

1. Disengage harness connector - A - in direction of - arrow - and disconnect it from transmission.
2. Free up wiring harness.

For transmission with round connector

1. Disengage electrical harness connector - 1 - and disconnect from transmission.
2. Move wiring harness clear - arrows -.

All

1. Remove bracket - 3 - for selector lever cable by first removing bolts - 2 -.

1. Using pry lever 80-200 , press selector lever cable - A - from lever for selector shaft - arrow -.

1. Remove bolts - 2 - and remove transmission support - 1 - from transmission.

1. Remove bolts - 1 to 5 - and - 11 - on engine/transmission flange.
2. Loosen bolt - 6 - only and then tighten by hand.

Note. Starter must not be removed.

1. Mount transmission support 3282 on Engine/Transmission Jack V.A.G 1383 A.

1. Set Template 3282/30 on to transmission support 3282 (template only fits in one position).
2. Align arms of transmission support to correspond with holes in adjustment plate.
3. Attach support elements on adjustment plate, as illustrated.

1. Move engine/transmission jack V.A.G 1383 A with transmission mount 3282 under transmission and support transmission.

Note. The arrow symbol on the adjusting plate points in the direction of travel.

1. Align template parallel to transmission and secure to transmission using a bolt M10 x 20 - arrow -.
2. Raise transmission slightly using Engine/Transmission Jack V.A.G 1383 A.

1. Remove bolts - 7 to 10 - at engine/transmission flange.
2. Lower transmission again slowly.
3. Tie up drive axles.
4. Remove last bolt securing transmission to engine.

1. Press off transmission from bushings and let it down carefully.

Transmission (vehicles with 2.0 L TFSI engine, also Audi Cabriolet), removing

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222 A
2. Pry lever 80-200
3. Transmission support 3282
4. Adjustment plate 3282/30

1. Engine/Transmission Jack V.A.G 1383 A

Special tools, testers and auxiliary items required

1. Fender insert pads T40045

Work procedure

1. Place selector lever in position "P".

1. Slide cover over battery to right - arrow 1 - and pull it off upwards - arrow 2 -.

1. With ignition switched off, disconnect Battery Ground (GND) wire - arrow -.

Scheme 1334

1. Remove engine cover - arrows -.
2. Pull off sealing rubber at bolted flanges of fender.

1. To prevent damage to bolted flanges of fender when using engine support bridge 10-222 A , insert fender insert pads T40045 on both sides between bolted flange of fender and web plate lying beneath.

Scheme 1335

1. Position engine support bridge 10-222 A with adapters 10-222/3 on to bolted flanges of fender.
2. Position engine support bridge 10-222 A with adapters 10-222 A/3 on to bolted flanges of fender.
3. Engage spindles onto engine lifting eyes as shown.
4. Pre-tension engine slightly using spindles on engine support bridge.

1. Remove both front wheels.
2. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Loosen quick-release screws - 1 to 3 - and remove front and rear noise insulation.

1. Remove noise insulation bracket - arrows -.

1. Remove vehicle floor plates at inside left - 2 - and inside right - 1 -.

1. Remove bolts - 1 through 4 - and remove rear cross member for vehicle floor.

1. Remove bolts - 1 to 6 - to remove front cross member for vehicle floor.

Scheme 1336

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Loosen bolts of front double clamp - arrows -.
2. To disconnect exhaust system, slide clamping sleeve toward rear.
3. Remove heat shield for exhaust system.

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood inserted in between - 1 - on transmission at bottom.
2. Support tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. First remove bolts - 1 - and - 2 - , then bolts - 3 - and - 4 -.
2. Slowly lower tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. Remove nuts - arrows - and remove tunnel cross member.

1. Remove heat shield - 1 - for right drive axle.
2. Remove drive axle from transmission flange on left and right sides --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Loosen bolts of front double clamp - arrows -.
2. To disconnect exhaust system, slide clamping sleeve toward rear.

Scheme 1337

1. Remove bolts - arrows - for front exhaust pipe/catalytic converter connection.
2. Remove nut - 1 - on front exhaust pipe bar and remove front exhaust pipe.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Place an oil receptacle underneath transmission.
2. Remove union nuts - 1 - and - 2 - and disconnect ATF lines.
3. Remove bracket for ATF-lines - arrows -.

1. Remove ATF filter on transmission - arrows -.

1. Remove union nuts - 1 - and - 2 - and disconnect ATF lines.
2. Remove bracket for ATF-lines - arrows -.

1. Remove bolt - arrow - and remove ATF lines from transmission.
2. Disconnect ATF lines.

1. Disengage electrical harness connector - 1 - and disconnect it from transmission.
2. Move wiring harness - arrows - to clear engine.

Note. For the sake of illustration, shown with transmission removed.

1. Remove bracket - 3 - for selector lever cable by first removing bolts - 2 -.

1. Using pry lever 80-200 , press selector lever cable - A - from lever for selector shaft - arrow -.

1. Remove bolts - 2 - and remove transmission support - 1 - from transmission.

1. Remove bolts - 1 to 5 - and - 11 - on engine/transmission flange.
2. Loosen bolt - 6 - only and then tighten by hand.

Note. Starter must not be removed.

1. Mount transmission support 3282 on Engine/Transmission Jack V.A.G 1383 A.
2. Set Template 3282/30 on to transmission support 3282 (template only fits in one position).
3. Align arms of transmission support to correspond with holes in adjustment plate.
4. Attach support elements on adjustment plate, as illustrated.

1. Move engine/transmission jack V.A.G 1383 A with transmission mount 3282 under transmission and support transmission.

Note. The arrow symbol on the adjusting plate points in direction of travel.

1. Align template parallel to transmission and secure to transmission using a bolt M10 x 20 - arrow -.

Audi Cabriolet

Note. So that the 4 engine/transmission connecting bolts at bottom can be removed on the Audi Cabriolet, the following work steps must also be performed

1. Raise transmission slightly using Engine/Transmission Jack V.A.G 1383 A.

Scheme 1338

1. Remove bolts - arrows - and remove torque support.

Note. Disregard - 1 -.

1. Remove left and right nuts - 1 - and swing stabilizer bar - 2 - downward.
2. Remove nuts - 3 - at engine mount on left and right far enough until lower edge of nut is flush with threaded pin - arrow -.
3. Raise engine using engine support bridge 10-222 A far enough until both nuts - 3 - (on left and right sides) make contact on plate from below.

All

1. Remove bolts - 7 to 10 - at engine/transmission flange.

Audi Cabriolet

1. Lower engine again.
2. Lower transmission again slowly.

All

1. Tie up drive axles.
2. Remove last engine/transmission mounting bolt.
3. Press off transmission from bushings and let it down carefully.

Transmission (vehicles with 6-cyl. 3.0 L gasoline engine, also Audi Cabriolet), removing

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222 A
2. Pry lever 80-200
3. Transmission support 3282
4. Adjustment plate 3282/30

1. Engine/Transmission Jack V.A.G 1383 A

Special tools, testers and auxiliary items required

1. Fender insert pads T40045

Work procedure

Note. Reinstall cable ties that were loosened or cut off during removal at same locations during installation.

1. Place selector lever in position "P".

1. Slide cover over battery to right - arrow 1 - and pull it off upwards - arrow 2 -.

1. With ignition switched off, disconnect Battery Ground (GND) wire - arrow -.

Scheme 1339

1. Remove rear engine cover - arrows -.

Scheme 1340

1. Remove front engine cover - arrows -.

Scheme 1341

1. Remove left cover - 1 - in engine compartment.

Scheme 1342

1. Remove coolant reservoir - arrow -.
2. Disconnect electrical wiring to Engine Coolant Level (ECL) Warning Switch F66 at bottom of coolant expansion tank.
3. Tie coolant expansion tank with connected coolant hoses - 1 to 3 - to side.
4. If present, remove connector heat shield at left of bulkhead.

Scheme 1343

1. Remove electrical connectors - 1 through 4 - from bracket at left of bulkhead.
2. Disconnect electrical connectors - 1 - and - 4 -.
3. Guide out wiring for lambda probes from below.

Scheme 1344

1. Remove nut - 2 - which is accessible from top for left exhaust pipe/exhaust manifold.

Note. For the sake of illustration, shown with engine removed.

Scheme 1345

1. Remove right cover - 1 - in engine compartment.

Scheme 1346

1. Remove bolts - arrows -.
2. Disengage Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 - 1 - at air duct.
3. Remove air duct - 2 -.

Scheme 1347

1. Remove air filter housing - arrows -.

Scheme 1348

1. Remove bolts for holding plate - 3 - for solenoid valves - arrows -.
2. Disconnect electrical harness connector at Mass Air Flow (MAF) Sensor G70.
3. Disconnect crankcase ventilation hose - 4 - from air guide - 2 -.

Scheme 1349

1. Remove bolt - arrow - and disconnect air guide - 2 - from throttle valve control module.
2. Disconnect hose - 1 - from air guide.

Note. For sake of illustration, air guide is shown from rear with engine removed.

Scheme 1350

1. Remove electrical connectors - 1 through 4 - from bracket at right of bulkhead.
2. Disconnect electrical connectors - 1 - and - 4 -.
3. Guide out wiring for lambda probes from below.

Scheme 1351

1. Remove nut - 2 - which is accessible from top for right exhaust pipe/exhaust manifold.

Note. For the sake of illustration, shown with engine removed.

1. Pull off sealing rubber at bolted flanges of fender.
2. To prevent damage to bolted flanges of fender when using engine support bridge 10-222 A , insert fender insert pads T40045 on both sides between bolted flange of fender and web plate lying beneath.

Scheme 1352

1. Position engine support bridge 10-222 A onto bolted flange of fenders; spindle stands at front.
2. Take up some of the engine weight by tightening spindle of support bar, but do not lift.
3. Remove both front wheels.

1. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Remove bolts or quick-release screws - 1 to 3 - and remove noise insulation at front and rear.

1. Remove noise insulation bracket - arrows -.

Scheme 1353

1. Remove bolts - 1 through 4 - and remove front cross member for vehicle floor.

Scheme 1354

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at both double clamps - arrows -.

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood inserted in between - 1 - on transmission at bottom.
2. Support tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. First remove bolts - 1 - and - 2 - , then bolts - 3 - and - 4 -.
2. Slowly lower tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. Remove nuts - arrows - and remove tunnel cross member.

Scheme 1355

1. Remove bolt - 1 - for noise insulation cover over left and right drive axle.
2. Disengage hook - 2 - and remove noise insulation cover.

1. Remove left and right heat shields for drive axles - 1 -.
2. Remove drive axle from transmission flange on left and right sides --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .

Scheme 1356

1. Remove bracket for left front exhaust pipe - arrow -.

1. Free up oxygen sensor wiring.
2. Remove nuts - 1 - and - 3 - which are accessible from bottom for front exhaust pipe/left exhaust manifold.

Note. For the sake of illustration, shown with engine removed.

1. Remove front exhaust pipe complete with primary and main catalytic converter.

Scheme 1357

1. Remove bracket for right front exhaust pipe - arrow -.

1. Free up oxygen sensor wiring.
2. Remove nuts - 1 - and - 3 - which are accessible from bottom for front exhaust pipe/right exhaust manifold.
3. Remove front exhaust pipe complete with primary and main catalytic converter.

Note. For the sake of illustration, shown with engine removed.

Scheme 1358

1. Remove Engine Speed (RPM) Sensor G28 on left of transmission - arrow - and lay to side.

Scheme 1359

1. Remove bracket for ATF-lines - arrow -.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Remove bolt - arrow - and remove ATF lines from transmission.
2. Move ATF lines clear to one side and secure in place.

For transmission with right-angled connector

1. Disengage harness connector - A - in direction of - arrow - and disconnect it from transmission.
2. Free up wiring harness.

For transmission with round connector

1. Disengage electrical harness connector - 1 - and disconnect from transmission.
2. Move wiring harness clear - arrows -.

All

1. Remove bracket - 3 - for selector lever cable by first removing bolts - 2 -.

1. Using pry lever 80-200 , press selector lever cable - A - from lever for selector shaft - arrow -.

1. Remove bolts - 2 - and remove transmission support - 1 - from transmission.

Scheme 1360

1. Remove bolts - 2 to 7 - at engine/transmission flange.
2. Loosen bolt - 8 - only and then tighten by hand.

Note. Starter must not be removed.

1. Mount transmission support 3282 on the Engine/Transmission Jack V.A.G 1383 A.

1. Set Template 3282/30 on to transmission support 3282 (template only fits in one position).
2. Align arms of transmission support to correspond with holes in adjustment plate.
3. Attach support elements on adjustment plate, as illustrated.

1. Move engine/transmission jack V.A.G 1383 A with transmission mount 3282 under transmission and support transmission.

Note. The arrow symbol on the adjusting plate points in the direction of travel.

1. Align template parallel to transmission and secure to transmission using a bolt M10 x 20 - arrow -.

Audi Cabriolet

Note. So that the 4 engine/transmission connecting bolts at bottom can be removed on the Audi Cabriolet, the following work steps must also be performed

1. Raise transmission slightly using Engine/Transmission Jack V.A.G 1383 A.

Scheme 1361

1. Remove torque support - arrows -.

1. Remove left and right nuts - 1 - and swing stabilizer bar - 2 - downward.
2. Remove nuts - 3 - at engine mount on left and right far enough until lower edge of nut is flush with threaded pin - arrow -.
3. Raise engine using engine support bridge 10-222 A far enough until both nuts - 3 - (on left and right sides) make contact on from below.

All

1. Remove bolts - 1 - and - 9 through 11 - on engine/transmission flange.

Audi Cabriolet

1. Lower engine again.
2. Lower transmission again slowly.

All

1. Move drive shafts towards rear.
2. Remove last bolt securing transmission to engine.
3. Press off transmission from bushings and let it down carefully.

Transmission (vehicles with 6-cyl. 3.2 L FSI gasoline engine, also Audi Cabriolet), removing

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222 A
2. Pry lever 80-200
3. Transmission support 3282
4. Adjustment plate 3282/30

1. Engine/Transmission Jack V.A.G 1383 A

Special tools, testers and auxiliary items required

1. Fender insert pads T40045
2. Drip tray for VAS 6100 VAS 6208

Work procedure

Note. Reinstall cable ties that were loosened or cut off during removal at same locations during installation.

1. Place selector lever in position "P".

1. Slide cover over battery to right - arrow 1 - and pull it off upwards - arrow 2 -.

1. With ignition switched off, disconnect Battery Ground (GND) wire - arrow -.

1. Remove rear engine cover - arrows -.

Scheme 1362

1. Remove front engine cover - arrows -.
2. Pull off sealing rubber at bolted flanges of fender.

1. To prevent damage to bolted flanges of fender when using engine support bridge 10-222 A , insert fender insert pads T40045 on both sides between bolted flange of fender and web plate lying beneath.

Scheme 1363

1. Position engine support bridge 10-222 A with two adapters 10 - 222 A/3 on to bolted flanges of fender.
2. Engage spindles onto engine lifting eyes as shown.
3. Take up some of the engine weight by tightening spindle of support bar, but do not lift.
4. Remove both front wheels.

1. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Remove bolts or quick-release screws - 1 to 3 - and remove noise insulation at front and rear.

1. Remove noise insulation bracket - arrows -.

1. Remove bolts - 1 through 4 - and remove front cross member for vehicle floor.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at both double clamps - arrows -.

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood inserted in between - 1 - on transmission at bottom.
2. Support tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. First remove bolts - 1 - and - 2 - , then bolts - 3 - and - 4 -.
2. Slowly lower tunnel cross member using Engine/Transmission Jack V.A.G 1383 A.

1. Remove nuts - arrows - and remove tunnel cross member.

1. If installed, remove bolt - 1 - for noise insulation cover over left and right drive axle.
2. Disengage hook - 2 - and remove noise insulation cover.

1. Remove left and right heat shields for drive axles - 1 -.
2. Remove drive axle from transmission flange on left and right sides --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .
3. Remove left and right front exhaust pipe with catalytic converter --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

1. Remove Engine Speed (RPM) Sensor G28 on left of transmission - arrow - and lay to side.

1. Remove bracket for ATF-lines - arrow -.
2. Place drip tray for workshop crane VAS 6208 under transmission.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Remove bolt - arrow - and remove ATF lines from transmission.
2. Seal openings with clean cover caps.
3. Move ATF lines clear to one side and secure in place.

Scheme 1364

1. Loosen bolts - arrows - at torque support stop approx. two rotations each.

Scheme 1365

1. Remove left and right stabilizer mounts - 1 - and - 2 -.
2. Swing stabilizer downward.

1. Remove nuts - 3 - at engine mount on left and right far enough until lower edge of nut is flush with threaded pin - arrow -.
2. Raise engine using spindles of engine support bridge 10-222 A far enough until both nuts - 3 - (on left and right sides) make contact on from below.

Scheme 1366

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood - 1 - inserted in between transmission at bottom.
2. Raise transmission slightly using Engine/Transmission Jack V.A.G 1383 A.

Note. Lower connecting bolts on engine/transmission flange are accessible by doing this.

Scheme 1367

1. Remove bolts - 8, 9 and 10 - on engine/transmission flange.
2. Lower engine again using spindles of engine support bridge 10-222 A.

1. Disengage electrical harness connector - 1 - and disconnect from transmission.
2. Move wiring harness clear - arrows -.

1. Remove bolts - 2 - and remove transmission support - 1 - from transmission.

1. Remove bolts - 2 to 6 - at engine/transmission flange.
2. Loosen bolts - 1 - and - 7 - only and then tighten by hand.

Note. Starter must not be removed.

1. Mount transmission support 3282 on Engine/Transmission Jack V.A.G 1383 A.
2. Set Template 3282/30 on to transmission support 3282 (template only fits in one position).
3. Align arms of transmission support to correspond with holes in adjustment plate.
4. Attach support elements on adjustment plate, as illustrated.

1. Move engine/transmission jack V.A.G 1383 A with transmission mount 3282 under transmission and support transmission.

Note. The arrow symbol on the adjusting plate points in the direction of travel.

1. Align template parallel to transmission and secure to transmission using a bolt M10 x 20 - arrow -.
2. Move drive shafts towards rear.

1. Remove last mounting bolts - 1 - and - 7 - on engine/transmission flange.
2. Press transmission off bushings - A - and carefully lower it far enough until selector lever cable is accessible.

1. Mark installation position of support bracket for selector lever cable.
2. Remove bolt - 1 - support bracket for selector lever cable.
3. Press selector lever cable ball joint - 2 - off from selector shaft lever.

Note. Do not bend or kink the selector lever cable.

1. Slowly lower transmission.
2. Pay attention to clearance of drive axles when lowering transmission.

Installing transmission

Installation is in reverse order of removal, note the following

Note. Before installing a replacement transmission, clean ATF lines and ATF cooler --> ATF lines and ATF cooler, cleaning . When performing repairs, replace self-locking nuts and bolts. Always replace bolts that are secured with tightening torque as well as seals, gaskets and O-rings. Clean input shaft splines of transmission and damper unit splines on flywheel, remove corrosion and apply only a very thin coating of lubricant G 000 100 on splines. Excess grease must be removed. Secure all hose connections with hose clamps of the same type as those equipped by the factory . When installing, bring all cable ties back to same positions.

1. Check if alignment sleeves for centering engine/transmission are in cylinder block, and install if necessary.
2. Before installing transmission, tie electrical wiring to one side so that it cannot be trapped between engine and transmission.
3. Raise engine far enough until selector lever cable can be installed.

1. Press selector shaft lever - A - on transmission completely toward rear - arrow - until parking lock engages.

1. Carefully press ball socket of selector lever cable - 2 - onto lever for selector rod.

Note. Take care not to bend selector shaft lever when pressing it on; support it if necessary, as otherwise selector mechanism can no longer be adjusted properly.

If bracket for selector lever cable - 3 - was removed from transmission

1. Tighten bolts - 2 - on bracket - 3 - for selector lever cable to 23 Nm on transmission.

Note. Do not bend or kink the selector lever cable. Lightly grease ball socket of selector lever cable with polycarbamide grease G 052 142 A2 before installing.

1. Install support bracket for selector lever cable - 1 - according to marking on bracket.
2. Place intermediate panel or intermediate plate onto bushings.

1. Carefully raise transmission and bring into installation position using transmission support 3282.

Note. Tightening torques are valid only for nuts and bolts that are lightly greased, oiled, covered with a thin coat of phosphate or blackened, tightening torques Securing engine/transmission (transmission flange pattern) . Additional lubricant such as engine or transmission oil may be used, but do not use graphite lubricant. Do not use degreased parts. Tolerance for torque specification ± 15%.

1. Tighten connecting bolts on engine/transmission flange to tightening torque (tables «Securing engine/transmission (transmission flange pattern)»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__securing-enginetransmission-transmission-flange-pattern) ).

1. Tighten nuts for left and right engine mounts - 3 - --> 10 - ENGINE - ASSEMBLY for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «10 - ENGINE - ASSEMBLY»(ref-278881-S23313549852008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 10 ENGINE - ASSEMBLY for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «10 - ENGINE - ASSEMBLY»(ref-278883-S24046934652008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «10 - ENGINE - ASSEMBLY»(ref-278885-S28123014792008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «10 - ENGINE - ASSEMBLY»(ref-278884-S30565723472008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .
2. Tighten stabilizer bolts - 2 - --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .
3. Tighten bolts of torque support or torque support stop to engine --> 10 - ENGINE - ASSEMBLY for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «10 - ENGINE - ASSEMBLY»(ref-278881-S23313549852008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 10 ENGINE - ASSEMBLY for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «10 - ENGINE - ASSEMBLY»(ref-278883-S24046934652008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «10 - ENGINE - ASSEMBLY»(ref-278885-S28123014792008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «10 - ENGINE - ASSEMBLY»(ref-278884-S30565723472008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

1. Bolt transmission mount - 1 - onto transmission with bolts - 2 - --> «Transmission mount, transmission support and tunnel cross member, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-mount-transmission-support-and-tunnel)
2. Install ATF lines with new sealing rings --> «ATF lines, ATF cooler and auxiliary ATF filter, servicing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .
3. Install exhaust system --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .
4. Install drive axles --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering) .

1. Install heat shield for left and right drive axle.
2. Install tunnel cross member --> «Transmission mount, transmission support and tunnel cross member, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-mount-transmission-support-and-tunnel) .
3. Align exhaust system so it is free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .
4. Electrical connections and routing --> Electrical Wiring Diagrams, Troubleshooting and Component Locations.

1. Observe procedures for connecting battery --> «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment) 27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL for ELECTRICAL EQUIPMENT, CABRIOLET .
2. Check adjustment of selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .
3. Check oil level in front final drive --> «Gear oil level in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__gear-oil-level-in-front-final) .
4. Check ATF level and top off --> «ATF level, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-level-checking-and-topping-off) .

Securing engine/transmission (transmission flange pattern)

Vehicles with 1.8 L turbo engine

*Replace bolts.

Vehicles with 2.0 L normally aspirated engine

*Replace bolts.

Vehicles with 2.0 L TFSI engine

*Replace bolts.

Vehicles with 3.0 L 6-cyl. gasoline engine

*Replace bolts.

*Bolt strength rating 10.9

Vehicles with 3.2 L FSI 6-cyl. gasoline engine

*Bolt strength rating 10.9.

Torque specifications

Automatic transmission, transporting

Special tools, testers and auxiliary items required

Scheme 1368

1. Lifting tackle T40013

Scheme 1369

Work procedure

The transmission lift hook T40013 can be used when transporting the transmission and for aligning transmission support 3282.

1. Mount and secure transmission lift hook T40013 on upper rib of transmission housing as shown in the illustration.

Scheme 1370

Special tools, testers and auxiliary items required

1. Holding plate VW 309
2. Holding fixture VW 313
3. Transmission support VW 353
4. Engine and Transmission Holder VW 540

1. Workshop crane VAS 6100
2. Lifting tackle T40013

Scheme 1371

1. Secure transmission to assembly stand with bolts - 1 - and - 2 -.
2. Install transmission support VW 353 onto holding plate VW 309.

Scheme 1372

1. Using workshop crane VAS 6100 , insert transmission into holding fixture VW 313.

Scheme 1373

1. Bolt transmission onto engine/transmission holder VW 540 - arrows -.
2. Using workshop crane VAS 6100 , insert transmission into holding fixture VW 313.

Transmission mount, transmission support and tunnel cross member, removing and installing

Special tools, testers and auxiliary items required

Scheme 1374

1. Engine/Transmission Jack V.A.G 1383 A
2. Wooden block

Removing

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

Note. Flex joint in front exhaust pipe must not be bent more than 10°, otherwise it may be damaged.

1. Disconnect exhaust system at both double clamps - arrows -.

1. Place plunger of Engine/Transmission Jack V.A.G 1383 A with a block of wood inserted in between - 1 - on transmission at bottom.
2. Raise transmission slightly using Engine/Transmission Jack V.A.G 1383 A.

1. First remove bolts - 1 - and - 2 - , then bolts - 3 - and - 4 -.

1. Remove nuts - arrows - and slide tunnel cross member slightly toward rear.

1. Remove bolts - 2 - and remove transmission mount - 1 - from transmission.

Installing

Installation is in reverse order of removal.

Torque specifications

Transmission mount - 1 - to transmission

1. Bolts M8 - 2 - , tightening torque: 23 Nm

Transmission mount to tunnel cross member

1. Nuts M8 - arrows - , tightening torque: 23 Nm

Tunnel cross member to chassis

1. Always replace bolts M12 - 3 - and - 4 - , tightening torque: 110 Nm plus an additional 90° (corresponds to one-quarter turn)
2. Bolts M10 - 1 - and - 2 - , tightening torque: 65 Nm

1. Align exhaust system so it is free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

ATF in planetary gearing

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions .

ATF level, checking and topping off

Special tools, testers and auxiliary items required

Scheme 1375

1. Vehicle Diagnosis, Testing and Information System VAS 5051 A with Diagnostic cable VAS 5051/5A

Scheme 1376

1. ATF filler system F/CVT transmission VAS 5162
2. Safety glasses
3. Oil receptacle

Scheme 1377

Note. The illustration on the reservoir for Atf Filler System F/CVT Transmission VAS5162 in upper left graphic refers to the use of special ATF for CVT transmissions. The illustration also shows pictures of the steps required to fill the transmission. These steps will be explained in the following.

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions .

Test conditions

1. Transmission not in emergency operating mode.
2. Move vehicle onto a lifting platform or over a work pit so that it stands absolutely horizontal.
3. Engine idling.
4. Air conditioner and heating must be switched off.

Scheme 1378

1. Vehicle Diagnostic, Testing and Information System VAS 5051 A connected, Vehicle Self-Diagnosis and vehicle system "02 - Transmission electronics" selected.
2. ATF temperature must not be higher than 30°C at start of test, allow transmission to cool down if necessary.

Note. The ATF level will vary according to the temperature of the ATF. Checking ATF level at too low ATF temperature leads to overfilling. If the ATF level is checked when the ATF temperature is too high, this will result in under filling. Over and under filling lead to impaired functioning of transmission. ATF temperature is read off on the Vehicle Diagnosis, Testing and Information System VAS 5051 A.

Checking ATF temperature

Scheme 1379

Display on VAS 5051 A

1. In selection - 1 - , click on diagnostic function "08 - Read measuring value block".

Scheme 1380

Display on VAS 5051 A

1 - Enter display group, max. input value = 255

1. In button field - 2 - , enter "10" for "Display group 10" and confirm input by pressing Q button.

Scheme 1381

Display on VAS 5051 A

1. Read off ATF temperature indicated in display field - 3 -.

Checking ATF level and topping off

Note. Engine keeps running at idle speed. The ATF level is checked at the ATF inspection plug. ATF level is correct if a little bit of fluid still escapes at the ATF check plug between 35°and 45°C (50°C for hot countries) ATF temperature (dependent on the fluid level when warming up).

1. Fill ATF filler system F/CVT transmission VAS 5162 with ATF for CVT transmissions.

1. ATF specification --> «Capacities»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

Scheme 1382

1. Secure filled reservoir of ATF filler system F/CVT transmission VAS 5162 as high as possible on vehicle.

Note. The shut-off valve on ATF filler system F/CVT transmission VAS 5162 must be closed.

1. While brake pedal is depressed, shift through all selector lever positions ("P" , "R" , "N" , "D" , "S") let each position remain shifted at idle for approx. 2 seconds.

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.
2. Place an oil receptacle underneath transmission.

Scheme 1383

1. If an ATF temperature of 35°C is reached, remove ATF check plug - B -.

Note. Approx. 5 cl of ATF will always drain initially from the internal oil level pipe when the plug is removed.

If ATF continues to flow out of the ATF filler plug hole over the overflow tube before the ATF reaches 40°C, the ATF level is OK.

1. Replace and tighten ATF check plug.

1. Tightening torque: 20 Nm.

Note. At the latest at 45°C (50°C for hot countries) the ATF check plug must be installed again. At an ATF temperature above 45°C, too much ATF flows out due to heat up and the transmission is not filled sufficiently!

The ATF check is now completed.

1. Press <-- button to end function "08 - Read measured value block".
2. Select "06 - End output".
3. Switch off ignition and disconnect Data Link Connector (DLC).

Add ATF if no ATF has escaped from the ATF check plug hole by 40°C Filling ATF .

Filling ATF

Note. Engine keeps running at idle speed.

1. Thread connection on shut-off valve of ATF filler system F/CVT transmission VAS 5162 into opening of ATF check plug - B -.

Scheme 1384

1. Rotate shut-off valve in direction of filler hose - lower arrow -. ATF flows into transmission.
2. Hold a suitable container beneath outlet of ATF filler system F/CVT transmission VAS 5162.

Scheme 1385

1. Check ATF level by rotating shut-off valve in direction of outlet - lower arrow -.

ATF level is correct when ATF drips out only lightly from outlet before 45°C is reached.

Note. Approx. 5 cl of ATF will initially drain from the internal oil level pipe. This is normal.

1. If no additional ATF flows out, rotate shut-off valve back in direction of filler hose and fill with more ATF; repeat check of ATF level.
2. After reaching correct ATF level, remove shut-off valve again.

Note. After removing shut-off valve, ATF drips out lightly.

1. Replace and tighten ATF check plug.

1. Tightening torque: 20 Nm.

Note. At the latest at 45°C (50°C for hot countries) the ATF check plug - B - must be installed again. At an ATF temperature above 45°C, too much ATF flows out due to heat up and the transmission is not filled sufficiently!

1. Press <-- button to end function "08 - Read measured value block".
2. Select "06 - End output".
3. Switch off ignition and disconnect Data Link Connector (DLC).

ATF, changing or filling after repairs

Special tools, testers and auxiliary items required

Scheme 1386

1. Triple square socket driver 3357

1. ATF filler system F/CVT transmission VAS 5162
2. Old oil collecting and extracting device V.A.G 1782
3. Safety glasses

Work procedure

1. Move vehicle onto a lifting platform or over a work pit so that it stands absolutely horizontal.

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions . Observe disposal regulations! Always blow compressed air through ATF cooler and ATF lines (max. 10 mbar) and replace auxiliary ATF filter before installing a replacement transmission --> Additional ATF filter .

1. Fill ATF filler system F/CVT transmission VAS 5162 with ATF for CVT transmissions.

1. ATF specification --> «Capacities»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

1. Secure filled reservoir of ATF filler system F/CVT transmission VAS 5162 as high as possible on the vehicle.

Note. The shut-off valve on the ATF filler system F/CVT transmission VAS 5162 must be closed.

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.
2. Place old oil collecting and extracting device V.A.G 1782 beneath transmission.

1. Remove ATF drain plug - A - using triple square socket driver 3357 and drain ATF.
2. Tighten ATF drain plug again.

1. Tightening torque: 24 Nm.

1. Remove ATF check plug - B -.
2. Thread connection on shut-off valve of ATF filler system F/CVT transmission VAS 5162 into opening of ATF check plug - B -.

1. Rotate shut-off valve in direction of filler hose - lower arrow -. ATF flows into transmission.
2. Fill at least 4.5 to liters ATF into transmission.
3. Selector lever in "P" , start engine and let it run at idle.

For vehicles as of model year 2005

1. Selector lever in position "P"

1. Let engine run at high speed at a minimum of 2500 RPM by depressing accelerator pedal.

All model years

1. Check ATF level and top off --> «ATF level, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-level-checking-and-topping-off) .

Note. Observe all notes and test requirements for "Checking ATF level and topping off".

ATF lines, ATF cooler and auxiliary ATF filter, servicing

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions . Always blow compressed air through ATF cooler and ATF lines (max. 10 mbar) and replace auxiliary ATF filter before installing a replacement transmission --> ATF lines and ATF cooler, cleaning . If extremely dirty ATF flows out when blowing with compressed air, ATF cooler and ATF lines must also be flushed with clean ATF. To install, first insert ATF lines into transmission or cooler by hand as far as they will go, then bolt on. Check ATF level --> ATF level, checking and topping off after replacing ATF lines.

ATF lines, ATF cooler and auxiliary ATF filter (vehicles with 1.8 L turbo engine)

Part 1

Scheme 1387

1 - Combi bolt, 5 Nm

2 - O-Ring

1. Replace
2. Insert with ATF

3 - O-Ring

1. Replace
2. Insert with ATF

4 - Combi bolt, 5 Nm

5 - Union nut, 29 Nm

6 - Union nut, 29 Nm

Part 2

Scheme 1388

1 - Bracket

2 - Combi bolt, 40 Nm

3 - Additional ATF filter

1. Must be replaced when transmission is malfunctioning
2. Removing and installing --> «Additional ATF filter»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__additional-atf-filter)

4 - Combi bolt, 20 Nm

5 - Combi bolt, 46 Nm

6 - Combi bolt, 5 Nm

7 - Clamp

8 - Union nut, 29 Nm

9 - Union nut, 29 Nm

10 - Combi bolt, 5 Nm

11 - Clamp

12 - Combi bolt, 46 Nm

13 - Bracket

14 - Clamp

15 - Combi bolt, 5 Nm

16 - Double bolt, 10 Nm

17 - Clamp

18 - Combi nut, 10 Nm

19 - O-Ring

1. Replace
2. Insert with ATF

20 - ATF line

21 - ATF line

22 - Combi bolt, 21 Nm

Scheme 1389

1 - Bolt, 20 Nm

2 - ATF lines

3 - O-Ring

1. Replace
2. Insert with ATF

4 - ATF line

5 - O-Ring

1. Replace
2. Insert with ATF

6 - Combi bolt, 5 Nm

7 - Combi bolt, 10 Nm

8 - Additional ATF filter

1. Must be replaced when transmission is malfunctioning
2. Removing and installing --> «Additional ATF filter»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__additional-atf-filter)

9 - Combi bolt, 10 Nm

10 - O-Ring

1. Replace
2. Insert with ATF

11 - ATF line

12 - Combi bolt, 5 Nm

13 - Union nut, 29 Nm

14 - Combi bolt, 46 Nm

15 - Bracket

16 - Combi nut, 5 Nm

17 - Clamp

Scheme 1390

1 - Socket head cap screw, 21 Nm

2 - ATF lines

1. To auxiliary ATF filter and to ATF cooler

3 - O-Ring

1. Replace
2. Insert with ATF

4 - Combi bolt, 21 Nm

5 - Bracket

6 - Combi bolt, 40 Nm

7 - Additional ATF filter

1. Must be replaced when transmission is malfunctioning
2. Removing and installing --> «Additional ATF filter»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__additional-atf-filter)

8 - Combi bolt, 20 Nm

9 - Combi bolt, 46 Nm

10 - Combi bolt, 5 Nm

11 - Clamp

12 - Union nut, 29 Nm

13 - Union nut, 29 Nm

14 - Combi bolt, 5 Nm

15 - Clamp

16 - Combi bolt, 5 Nm

17 - O-Ring

1. Replace
2. Insert with ATF

18 - ATF line

19 - ATF lines

20 - O-Ring

1. Replace
2. Insert with ATF

21 - Combi bolt, 5 Nm

22 - Combi nut, 10 Nm

23 - Clamp

24 - Combi bolt, 10 Nm

25 - ATF lines

26 - Union nuts, 29 Nm

Scheme 1391

1 - Combi bolt, 21 Nm

2 - ATF lines

3 - O-Ring

1. Replace
2. Insert with ATF

4 - ATF line

5 - O-Ring

1. Replace
2. Insert with ATF

6 - Combi bolt, 5 Nm

7 - Combi bolt, 10 Nm

8 - Additional ATF filter

1. Must be replaced when transmission is malfunctioning
2. Removing and installing --> «Additional ATF filter»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__additional-atf-filter)

9 - Combi bolt, 10 Nm

10 - O-Ring

1. Replace
2. Insert with ATF

11 - ATF line

12 - Combi bolt, 5 Nm

13 - Union nut, 29 Nm

14 - Double bolt, 10 Nm

1. Not installed on 3.2 L FSI engine

15 - Bracket

16 - 10 Nm

1. Combination nut for 3.0 L engines
2. Bolt for 3.2 L FSI engines

17 - Combi nut, 5 Nm

18 - Clamp

ATF lines and ATF cooler, cleaning

Special tools, testers and auxiliary items required

1. Old oil collecting and extracting device V.A.G 1782
2. Hose diameter approx. 18 mm
3. Compressed air gun, commercially available
4. Safety glasses

Work procedure

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Before installing a replacement transmission, always blow into ATF cooler and ATF lines with compressed air (max. 10 bar).
2. Before installing a replacement transmission, always replace auxiliary ATF filter.

Note. If extremely dirty ATF flows out when blowing with compressed air, ATF cooler and ATF lines must also be flushed with clean ATF. ATF lines, removing and installing --> ATF lines, ATF cooler and auxiliary ATF filter, servicing .

Additional ATF filter

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions . Always blow compressed air through ATF cooler and ATF lines (max. 10 mbar) and replace auxiliary ATF filter before installing a replacement transmission. If extremely dirty ATF flows out when blowing with compressed air, ATF cooler and ATF lines must also be flushed with clean ATF. To install, first insert ATF lines into transmission or cooler by hand as far as they will go, then bolt on.

Auxiliary ATF filter, removing and installing (vehicles with 1.8 turbo and 2.0 L TFSI)

Special tools, testers and auxiliary items required

1. Oil receptacle

Removing

1. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Remove bolts or quick-release screws - 1 to 3 - and remove noise insulation at front and rear.

1. Remove noise insulation bracket - arrows -.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Place an oil receptacle underneath transmission.

Scheme 1392

1. Remove union nuts - 1 - and - 2 - and disconnect ATF lines.
2. Remove clamp for ATF-lines - arrow -.

1. Remove auxiliary ATF filter on transmission - arrows -.

Installing

Installation is in reverse order of removal, note the following

1. Check ATF level and top off --> «ATF level, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-level-checking-and-topping-off) .

Torque specifications

Auxiliary ATF filter, removing and installing (vehicles with 2.0 L normally aspirated- and 6-cyl. gasoline engine)

Special tools, testers and auxiliary items required

1. Oil receptacle

Removing

Note. Removal and installation is here described for vehicles with 6-cyl. gasoline engine in the following. On vehicles installed with 2.0l engines components inside the vehicle possibly look different from the ones shown in the illustrations.

1. On vehicles equipped with auxiliary heater, remove bolts - arrows - for exhaust pipe of auxiliary/additional heater to noise insulation.

1. Loosen bolts or quick-release screws - 1 - and - 2 - and remove front noise insulation.

Note. Observe the rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

1. Place an oil receptacle underneath transmission.

Scheme 1393

1. Remove union nut - arrow - and disconnect ATF-line to auxiliary ATF filter.

Scheme 1394

1. Disconnect air hoses - 1 - and - 2 - at Secondary Air Injection (AIR) pump.

Note. Electrical harness connector - 3 - remains connected.

Scheme 1395

1. Remove bolts - 1 - at auxiliary ATF filter bracket - 2 -.

1. Remove right cover - 1 - in engine compartment.

1. Remove bolts - arrows -.
2. Disengage Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 - 1 - at air duct.
3. Remove air duct - 2 -.

1. Remove air filter housing - arrows -.

Scheme 1396

1. Disconnect upper ATF line - arrow - from cooler.
2. Remove auxiliary ATF filter.

Installing

Installation is in reverse order of removal, note the following

Note. Replace O-rings.

1. Check ATF level and top off --> «ATF level, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-level-checking-and-topping-off) .

Torque specifications

ATF breather pipe

1. If ATF flows out at underside of transmission bell housing, input shaft seal and/or ATF breather pipe may be leaking. Before replacing any parts, be sure to find actual cause of malfunction.
2. Input shaft seal must be replaced if leaking --> «Input shaft seal, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__input-shaft-seal-replacing) .
3. ATF breather pipe must be replaced if leaking.

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions .

ATF breather pipe, removing and installing

Removing

1. Transmission removed.

1. Remove bolt - B -.
2. Pull ATF breather pipe - A - out of mount.

Note. If ATF leak is determined from check hole behind ATF breather pipe - A - , slightly below bolt - B - , transmission is malfunctioning and must be replaced.

Installing

Installation is in reverse order of removal, note the following

1. Insert new ATF breather pipe - A - until it reaches stop.
2. Tighten ATF breather pipe with strap and bolt - B - on transmission housing.

Torque specification

Scheme 1397

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222 A
2. Pry lever 80-200
3. Triple square socket driver 3357
4. Engine/Transmission Jack V.A.G 1383 A

1. Oil receptacle

Removing

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions .

1. Place selector lever in position "P".

1. Remove tunnel cross member --> «Transmission mount, transmission support and tunnel cross member, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-mount-transmission-support-and-tunnel) .

Vehicles with oval connector

1. Disengage harness connector - A - in direction of - arrow - and disconnect it from transmission.

Vehicles with round connector

1. Disengage electrical harness connector - 1 - and disconnect it from transmission.

All

1. Remove bracket - 3 - for selector lever cable by first removing bolts - 2 -.

1. Using pry lever 80-200 , press selector lever cable - A - from lever for selector shaft - arrow -.

1. Remove bolts - 2 - and remove transmission mount - 1 - from transmission.

Scheme 1398

1. Remove bolts - arrows - and remove end cover.

Installing

Installation is in reverse order of removal, note the following

Note. Replace sealing rings, seals and bolts for end cover.

Vehicles with round connector

Scheme 1399

1. Slide new twin lip oil seal - A - with twin lips facing outward onto connector at Transmission Control Module (TCM) J217.

Vehicles with oval connector

Scheme 1400

1. Slide new twin lip oil seal - A - with twin lips facing outward onto connector at Transmission Control Module (TCM) J217.

All

1. Clean sealing surfaces on transmission housing and on end cover.
2. If bushings were installed in transmission housing or in cover, they must be remounted in same location.

Scheme 1401

1. Slide new twin lip oil seal - A - with twin lips facing outward onto connector at Transmission Control Module (TCM) J217.

Note. There are metal and paper seals. The new seal must be made of the same material as the old one . Make sure bushings are seated properly.

1. Put on end cover and make sure seal does not slip.

Scheme 1402

1. Tighten new bolts - arrows - first hand-tight and in diagonal sequence, and then to tightening torque (table «Torque specifications»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__torque-specifications) ).
2. Check installation position of twin lip oil seal - A

1. Twin lip oil seal must fit flush (sealing lips must not be twisted).

1. Check installation position of twin lip oil seal - A - : It must fit flush (sealing lips must not be twisted).

1. Tighten bolts - 2 - of bracket for selector lever cable - 3 - on transmission.

Note. Do not bend or kink the selector lever cable. Lightly grease eyelet and ball socket of selector lever cable with polycarbamide grease G 052 142 A2 before installing.

1. Press selector shaft lever - A - on transmission completely toward rear - arrow - until parking lock engages.

1. Check whether selector lever is in position "P" , then press ball socket of selector lever cable - 2 - carefully onto lever for selector shaft.

Note. Take care not to bend selector shaft lever when pressing it on; support it if necessary, as otherwise selector mechanism can no longer be adjusted properly.

1. Bolt transmission mount - 1 - onto transmission - 2 - --> «Transmission mount, transmission support and tunnel cross member, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-mount-transmission-support-and-tunnel) .
2. Install tunnel cross member --> «Transmission mount, transmission support and tunnel cross member, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-mount-transmission-support-and-tunnel) .
3. Adjust selector lever cable --> «Selector lever cable (through VIN 8E_6A156499), adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__selector-lever-cable-through-vin-8e_6a156499) .
4. Install exhaust system and align it free of tension --> 26 - EXHAUST SYSTEM, EMISSION CONTROLS for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT 26 EXHAUST SYSTEM, EMISSION CONTROLS for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF .

1. Fill with ATF --> «ATF, changing or filling after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__atf-changing-or-filling-after-repairs) .

Torque specifications

* 90° is a quarter turn.

Transmission Control Module (TCM) J217 , removing and installing

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions .

1. Remove end cover --> «End cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

The corresponding description for Transmission Control Module (TCM) J217 , removing and installing can be found in --> 38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS .

Selector shaft, cleaning

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions . Transmission Control Module (TCM) J217 removed

Work procedure

Scheme 1403

1. Clean catch - arrow - of selector shaft. Do not use fluffy materials for cleaning. Clean contact surfaces of magnet especially thoroughly of metal shavings and the like.

Note. Make sure that spring - A - and roller - B - are secured properly.

1. If necessary, clean sensors - A - , - C - and - D - of soiling and metal shavings.
2. Install Transmission Control Module (TCM) J217 --> «Transmission Control Module (TCM) J217 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j__transmission-control-module-tcm-j217) .

Hydraulic control module, removing and installing

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions . Always replace hydraulic control assembly if it has collected dirt or if it is defective.

1. Remove end cover --> «End cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

The corresponding description for removal and installation of the hydraulic control unit can be found in --> 38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS .

Input shaft, removing and installing

Note. Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission . General repair notes --> Repair instructions . Transmission removed and secured vertically to assembly stand Suspending transmission vertically .

The corresponding description for removal and installation of the input shaft can be found in --> 38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS .

Input shaft, servicing

The corresponding description, along with disassembling and assembling input shaft, can be found in --> 38 - AUTOMATIC TRANSMISSION - GEARS, HYDRAULIC CONTROLS .

Gear oil in front final drive

Note. General repair notes --> Repair instructions . Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

Gear oil level in front final drive, checking

Note. The specified oil level must be maintained exactly; the transmission reacts very sensitively to over-filling.

Test sequence

1. Take vehicle for a short test drive to heat gear oil to approx. 60°C.
2. Move vehicle onto a lifting platform or over a work pit so that it is absolutely level.
3. Switch off engine and allow 5 minutes for gear oil to settle back into transmission case.

1. Loosen quick-release screws - 2 - and - 3 - and remove rear noise insulation.

1. If installed, remove bolt - 1 - for noise insulation cover over left drive axle.
2. Disengage hook - 2 - and remove noise insulation cover.

Scheme 1404

1. Remove inspection plug - arrow -.
2. Check oil level using a tool created in the workshop, e.g. an angled section of wire.

1. Specified value: Oil level 8.5 mm below bottom of filler hole.

1. If necessary, top off gear oil level.

1. Axle oil specification --> «Capacities»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#continuously-variable-transmission-cvt-01j) .

Note. When servicing at the workshop the oil can also be filled up to the lower edge of the oil filler hole. In this case it is necessary to draw off 0.2 ltr. to attain the correct oil level.

1. Tighten new screw plug.

Torque specification

*Replace screw plug.

Front final drive, servicing

Note. General repair notes --> Repair instructions . Rules of cleanliness for working on automatic transmissions --> Rules for cleanliness when working on transmission .

Left flange shaft, removing and installing

Special tools, testers and auxiliary items required

Scheme 1405

1. Drift VW 295

Scheme 1406

1. Puller T10037
2. Oil receptacle

Removing

1. Transmission installed.
