5-speed Automatic Transmission 01v Audi A4 B6

Transmission Identification

The 5-speed automatic transmission 01V is installed in the Audi A4 2002 and up in conjunction with the 4 and 6-cylinder engines. Allocation --> Code letters, allocation, ratios, equipment .

Code letter allocation at transmission

Scheme 835

Transmission code letters are located on the data plate under the transmission (arrow).

There is another identical data plate on side of transmission which is not accessible with the transmission installed.

Scheme 836

Transmission code number and transmission serial number.

Transmission serial number (arrow 1)

Transmission identification (arrow 2)

Code letter (arrow 3)

The transmission code letters are also listed on the vehicle data plates.

Self-study program number. 180 informs extensively about the function of this transmission.

Torque converter

The torque converter is equipped with a lock-up clutch. The lock-up clutch is closed load- and speed-dependant with minimum pulsations and mechanically drives all forward gears independent of slip.

Transmission

5-speed automatic transmission 01V is equipped with 5 hydraulically activated forward gears. By passing the torque converter slip, these forward gears become mechanically driven gears if the lock-up clutch is closed.

On Board Diagnostic (OBD)

Before performing service work on the automatic transmission, cause of damage must be exactly determined via "Guided Fault Finding".

"Guided Fault Finding" is performed using the tester VAS5051.

Transmission Control Module (TCM) J217 with driving situation shifting (fuzzy logic)

Driving situation- and driving resistance dependent shift point determination is performed automatically.

Advantages

1. It is shifted depending on consumption
2. Highest engine performance is always available
3. Individual adaptation of shift points in all driving situations
4. Arbitrarily changed shift points

Shift point change when driving up- or downhill ranges

At uphill or downhill ranges, the shifts are automatically selected dependent on the accelerator pedal position and vehicle speed via additional shift characteristics maps.

1. Shift characteristics map for extreme uphill driving is adapted to the engine performance.
2. Shift characteristics map for extreme downhill driving is adapted to the braking effect of the engine.

All Wheel Drive (AWD)

*11 mm intermediate plate is installed between engine and transmission.

Rear final drive, identification

Vehicles with all wheel drive automatic transmission 01V are equipped with rear final drive 01R.

Allocation

>

1. «00 GENERAL, TECHNICAL DATA»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE
2. «00 - GENERAL, TECHNICAL DATA»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

Scheme 837

Location on rear final drive

Code letters and date of manufacture (arrow 1)

Rear final drive 01R (arrow 2)

Scheme 838

Rear final drive 01R (arrow 2)

Scheme 839

Code letters and date of manufacture of final drive.

Additional information depends on manufacturing.

Code letters, allocation, ratios

Capacity

Planet gear

*Filled for life: Replacement only after repair, when oil pan is removed, up to 3 liters.

ATF is available as a replacement part (is also referred to as VW ATF).

Container size 0.5 L -part number G 052 162 A1

Container size 1.0 L -part number G 052 162 A2

Container size 20 L -part number G 052 162 A6

Only ATF available as a replacement part must be used in the planetary gear of the automatic transmission 01V.

Checking ATF level or replacing ATF --> Automatic Transmission Fluid (ATF), checking and changing .

Final drive-front

Gear oil SAE 75 W 90 (synthetic oil) is available as a replacement part in the following container sizes

Container size 0.5 L -part number G 052 145 A1

Container size 1.0 L -part number G 052 145 A2

Checking oil level in front final drive --> Gear oil in front final drive, checking .

Center differential

Gear oil SAE 75 W 90 (synthetic oil) is available as a replacement part in the following container sizes

Container size 0.5 L -part number G 052 145 A1

Container size 1.0 L -part number G 052 145 A2

Filling transfer housing with gear oil and checking oil level --> Gear oil in center differential, checking and topping off .

Rear final drive

Capacity

>

1. «00 GENERAL, TECHNICAL DATA»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE
2. «00 - GENERAL, TECHNICAL DATA»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

Roll starting and towing notes

Note. Tow starting for starting engine, e.g. if the battery is too weak or the starter does not work is not possible.

Servicing notes

The maximum possible care, cleanliness and proper tools are essential to ensure satisfactory and successful transmission repairs. The usual basic safety precautions also apply when carrying out vehicle repairs.

A number of generally applicable instructions for individual repair procedures, which are otherwise mentioned at various points in the article, are summarized here. They apply to this article.

Special tools and workshop equipment

For a complete list of special tools used in this article: see "Special tools and equipment" or "Special tools".

Transmission

1. Rules of cleanliness for working on automatic transmissions --> «Rules of cleanliness for working on automatic transmissions»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__rules-of-cleanliness-for-working-on) .
2. Do not run engine with the oil pan removed or without ATF filling and do not tow vehicle.
3. Clean ATF lines and ATF cooler when replacing automatic transmission --> «ATF lines and ATF cooler, cleaning»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-lines-and-atf-cooler-cleaning) .
4. Secure torque converter on removed transmission to keep it from falling out.

1. Thoroughly clean all connections and the surrounding area before disconnecting.
2. Check installation dimension of torque converter before installing transmission --> «Torque converter, installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__torque-converter-installing)
3. When installing transmission, make sure centering sleeves are correctly seated in engine.
4. Place parts that have been removed on a clean surface and cover. Use foils and paper. Use lint-free cloths only!

1. Carefully cover over opened components or seal, if repairs are not carried out immediately.
2. Only install clean components: Only unpack replacement parts immediately prior to installation.
3. Check, and if necessary correct amount of the following fluids when replacing the automatic transmission. ATF in planetary gear --> «ATF level, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) , gear oil in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) , gear oil in center differential --> «Gear oil in center differential, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) . Capacities and specifications --> «Capacity»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) onward.
4. When replacing the rear final drive, check and if necessary, correct oil level in rear final drive. Capacities and specifications --> «Capacity»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) . --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

O-rings, gaskets, seals

1. Always replace O-rings, gaskets and sealing rings.
2. After removing gaskets and seals, always inspect the contact surfaces at housing or shaft for burrs resulting from removal or for other signs of damage.
3. Thoroughly clean housing sealing surfaces before assembling.
4. Lightly lubricate O-rings before installing, this prevents the rings from being pinched when inserting.

Scheme 840

1. Before installing, fill gap between sealing lips (arrow) of radial-shaft seals half way with sealing grease 052 128 A1.
2. The open side of the seals face toward the fluid to be sealed in.
3. For installation, lightly coat outer circumference and sealing lip with ATF or transmission oil, depending on the installation location.
4. Use only ATF in areas near ATF. Other lubricating substances cause functional problems in the hydraulic transmission control.

1. When pressing in new seals, make sure the sealing lip does not run on the same point as the sealing lip of the old seal (use insertion depth tolerances).
2. After installing, check and if necessary correct fluid levels in the affected area. ATF in planetary gear --> «ATF level, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) , gear oil in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) , gear oil in center differential --> «Gear oil in center differential, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) , gear oil in rear final drive --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

Capacities and specifications --> Capacity onward.

Nuts, bolts

1. Loosen bolts in reverse order of tightening sequence.
2. Tighten and loosen bolts or nuts for securing covers and housings without tightening sequence in diagonal sequence in stages.
3. Do not cant, and loosen and tighten especially sensitive parts - e.g. valve body - in diagonal manner in stages.
4. The tightening torques stated apply to non-oiled nuts and bolts.

1. Always replace self-locking nuts and bolts.
2. Using a wire brush, clean threads of bolts which are secured with locking compound. Next, insert bolts using AMV 185 101 A1.
3. Threaded bores into which self-locking bolts or bolts with locking compound are threaded in, must be cleaned (e.g. using threaded tap). Otherwise there is danger that the bolts may shear when removed again.

Circlips

1. Do not over-stretch circlips.
2. Always replace damaged or over-stretched circlips.
3. Circlips must be fully seated in groove.

Mount

1. Install needle bearings with the lettering on the bearing (the side with thicker metal) facing the drift.
2. Insert bearing with transmission oil or ATF, depending on installation location.

Valve body

1. Replace transmission if shift members are burnt.

Guided Troubleshooting, Vehicle On Board Diagnostic (OBD) and Test Instruments

Scheme 841

1. Before performing repairs on the automatic transmission, the malfunction cause must be determined as exact as possible via the tester VAS5051 in the operating modes "Guided Fault Finding ", " Vehicle Self-Diagnosis " and " Test Instruments."

Torque converter

Note. Rules of cleanliness for working on automatic transmissions --> Rules of cleanliness for working on automatic transmissions . General repair notes --> Servicing notes . Lightly coat sealing ring with ATF. Other lubricating substances lead to functional problems in the hydraulic transmission control.

Scheme 842

1 - Torque converter

1. Secure on removed transmission to keep it from falling out.
2. Identification --> «Torque converter, identification»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
3. Installing --> «Torque converter, installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__torque-converter-installing)

2 - Seal

1. Always replace --> «Torque converter oil seal, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__torque-converter-oil-seal-replacing)

3 - Contact ring

1. Behind sealing ring
2. Replace if damaged

Scheme 843

Different types of torque converters exist. Identification is performed via code letters (arrow).

Allocation of torque converter/transmission --> Code letters, allocation, ratios, equipment .

Scheme 844

1. Checking converter hub for wear grooves (arrow).

Note. The torque converter is welded in and must be completely replaced if damaged or in case of malfunctions.

Torque converter, draining

Special tools, testers and auxiliary items required

Scheme 845

1. Oil siphoning unit VAG1358A
2. Oil siphoning probe VAG1358 A/1

In case of soiling of the ATF via shavings, torque converter must be drained

Scheme 846

1. Drain ATF from torque converter using oil siphoning unit VAG1358A and Oil siphoning probe VAG1358 A/1.

Torque converter oil seal, replacing

Special tools, testers and auxiliary items required

Scheme 847

1. Extractor lever VW681

Scheme 848

1. Thrust piece 3295

Removing

1. Removing transmission --> «Transmission, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Secure transmission to assembly stand --> «Transmission, attaching to assembly stand»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 849

1. Insert extractor lever VW681 directly behind the sealing lip of the sealing ring, so that the contact ring which is behind it is not damaged.

Installing

1. Insert contact ring.
2. Coat outer circumference and sealing lips of sealing ring with ATF.

1. Installation position: The open side of the sealing ring faces the transmission.

Scheme 850

1. Using thrust piece 3295 , drive in sealing ring for torque converter up to thrust piece stop.

Torque converter, installing

Special tools, testers and auxiliary items required

1. Depth gauge

1. Slide in converter hub through the sealing ring up to the first stop.
2. Rotate torque converter inward with light pressure, until the groove of the torque converter hub engages in the coupling plate of the pump wheel and the torque converter slides inward noticeably.

Scheme 851

When torque converter is installed correctly, distance between lower contact surface of threaded holes at torque converter and contact surface of converter housing on Automatic Transmission 01V is approx. 23 mm.

If the torque converter is not inserted completely, this distance will be approx. 11 mm.

Pay particular attention to the following when installing the transmission.

Scheme 852

1 - Transmission Control Module J217

1. Component location and removing and installing --> «Component location of Transmission Control Module (TCM) J217»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. Disconnecting multi-pin connector --> «Disconnecting Transmission Control Module (TCM) J217 from multi-pin harness connector»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
3. May be checked using tester VAS5051 in "Guided Fault Finding"

2 - Data Link Connector (DLC)

1. Installation location «Data Link Connector (DLC)»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

3 - Multi-Function Transmission Range (TR) Switch F125

1. Component location and removing and installing --> «Multi-Function Transmission Range (TR) Switch F125»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

4 - Internal transmission wiring harness with integrated Transmission Fluid Temperature Sensor G93 (ATF)

1. Component location and removing and installing --> «Internal transmission wiring harness with integrated Transmission Fluid Temperature Sensor G93 (ATF)»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

5 - Valve body

1. Component location and removing and installing «Valve body»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

6 - Sensor for transmission RPM G182

1. Calculates transmission RPM
2. Component location and removing and installing --> «Sensor for transmission RPM G182»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
3. May be checked using tester VAS5051 in "Guided Fault Finding"

7 - Transmission Vehicle Speed Sensor (VSS) G38 (also designated as Sender for transmission output RPM G195 )

1. Calculates transmission output RPM
2. Component location and removing and installing --> «Transmission Vehicle Speed Sensor (VSS) G38»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
3. May be checked using tester VAS5051 in "Guided Fault Finding"

8 - Tiptronic Switch F189

1. Component location and removing and installing --> «Tiptronic Switch F189»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

9 - Shift Lock Solenoid N110

1. Component location and removing and installing --> «Shift lock solenoid N110»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

10 - Throttle Position (TP) Sensor G79 and G185

1. Component location and removing and installing and under «Throttle Position (TP) sensor G79 and G185»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

11 - Starting Interlock Relay J207

1. Installation location --> «Starting Interlock Relay J207»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

12 - Transmission Range (TR) Selector Lever Display Y6

1. Component location and removing and installing --> «Transmission Range (TR) Selector Lever Display Y6»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. Unlit selected gear display indicates emergency mode with inactive Transmission Control Module (TCM).
3. Completely lit selected gear display indicates emergency mode with active Transmission Control Module (TCM).

13 - Brake light switch F

1. Component location and removing and installing --> «Brake light switch F»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. May be checked using tester VAS5051 in "Guided Fault Finding"

Scheme 853

Control module is located in left plenum chamber in e-box under Engine Control Module (ECM).

Removing and installing the control module

>

1. «97 WIRING»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment)
2. «97 WIRING»(ref-278931-S14478958282008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

If control module for engine or transmission is replaced, the system must be put into basic setting.

1. Perform basic setting in "Vehicle Self-Diagnosis" using the tester VAS5051.

Scheme 854

1. Disengage harness connector (arrow) and disconnect it from Transmission Control Module (TCM).

Installation is the reverse of removal.

Scheme 855

Installation location: Data Link Connector (DLC) is located under driverside storage compartment.

1. Connect tester VAS5051 to Data Link Connector (DLC) using diagnostic cable VAS5051/1 and adapter VAS6017 with ignition switched off.

Scheme 856

Installation location: Valve body is bolted on to transmission housing below and covered by transmission oil pan.

Solenoid valves N88 , N89 , N90 , and pressure control valves N215 , N216 , N217 , N218 are fastened to valve body.

Removing and installing valve body

> Valve body, removing and installing

Scheme 857

Installation location: Transmission Fluid Temperature Sensor (arrow) is located in the wiring harness on valve body.

Wiring harness may be replaced with transmission installed and valve body removed.

Wiring harness in transmission, removing and installing

> Wiring harness inside transmission, removing and installing

Scheme 858

Installation location: Transmission Vehicle Speed Sensor is located on rear right of transmission. Also referred to as the sender for transmission output RPM G195.

Removing and installing Transmission Vehicle Speed Sensor (VSS)

> Transmission Vehicle Speed Sensor (VSS) G38 , removing and installing

Scheme 859

Sensor for transmission RPM - A - is fastened to transmission housing behind valve body. This sensor is a Hall sensor.

Removing and installing Sensor for transmission RPM G182

> Sensor for transmission RPM G182 , removing and installing

Scheme 860

Installation location: Multi-Function Transmission Range (TR) Switch - 1 - is located at left on transmission; multi-pin connector for Multi-Function Transmission Range (TR) Switch - 2 -.

Removing and installing Multi-Function Transmission Range (TR) Switch

> Multi-Function Transmission Range (TR) Switch F125 , removing and installing

Scheme 861

Installation location: Tiptronic switch is integrated into circuit board of symbol insert, which is located in shift mechanism cover.

Tiptronic Switch F189 , removing and installing

> Tiptronic Switch F189 , removing and installing

Scheme 862

Installation location: Shift lock solenoid is located in the shift mechanism - arrow -.

Shift lock solenoid, removing and installing

> Shift Lock Solenoid N110 , removing and installing

Scheme 863

Installation location: Relay is located in central electronics.

Assignment

> Electrical Wiring Diagrams, Troubleshooting and Component Locations

Scheme 864

Throttle Position (TP) sensor G79 and G185 (arrow), component of electronic engine power control (E-Gas), is located at pedal assembly.

The kick down function is performed (controlled) via Throttle Position (TP) sensor G79 and G185.

Checking, removing and installing Throttle Position (TP) sensor

> 20 - FUEL SUPPLY SYSTEM

Scheme 865

Installation location: Brake light switch (arrow) is located in foot pedal assembly.

Brake light switch, removing and installing

> 46 - BRAKES - MECHANICAL COMPONENTS

Scheme 866

Installation location: in instrument cluster

Removing and installing Transmission Range (TR) Selector Lever Display

>

1. «90 INSTRUMENTS»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment)
2. «90 INSTRUMENTS»(ref-278931-S12002884242008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

Selector lever mechanism, servicing

Ignition key removal lock, checking

1. Switch ignition key to driving position (ignition on).
2. Depress brake pedal and hold.

1. Shifting selector lever out of position "P" must be possible with the button at shift lever depressed without "sticking".
2. It must not be possible to remove ignition key with selector lever in any position other than "P".

1. Shift selector lever into position "P".

1. It must be possible to move ignition key into removal position without "sticking".

1. Remove ignition key.

1. It must only be possible to remove ignition key in "P" position.
2. Selector lever cannot be shifted out of position "P" with the button pressed and foot brake operated.

Shift mechanism, checking

Selector lever in position "P" and ignition switched on

1. Brake pedal is not being operated

Selector lever is locked and cannot be shifted out of position "P" with the button at selector lever pressed. Shift lock solenoid is locking the selector lever.

1. Brake pedal is being operated

Shift lock solenoid enables the selector lever. Selecting a driving mode must be possible with the button at shift handle pressed without "sticking".

Slowly shift selector lever from "P" through "R, N, D, S" checking whether selector lever position in dash panel insert agrees with selector lever position.

Selector lever in position "N" and ignition switched on

1. Brake pedal is not being operated

Selector lever is locked and cannot be shifted out of position "N" with the button at selector lever handle pressed. Shift lock solenoid is locking the selector lever.

1. Brake pedal is being operated

Shift lock solenoid enables the selector lever. Selecting a driving mode must be possible with the button at shift handle pressed without "sticking".

Selector lever in position "D" , ignition and lights switched on

Move selector lever in Tiptronic gate. The "D" symbol must no longer be illuminated and "+" and "-" symbols must illuminate.

1. Start engine and let run at idle
2. Engage parking brake and operate brake pedal

The selector lever display in dash panel insert must change from "PRNDS" to "54321" when selector lever is moved in Tiptronic gate.

Note. The starter must not operate in the selector lever positions "D" , "S" and "R". For speeds exceeding 5 km/h and shifting into selector lever position "N" , the shift lock solenoid must not engage to lock the selector lever. Selector lever can be shifted into a driving mode. For speeds below 2 km/h (almost standstill) and shifting into selector lever position "N" , the shift lock solenoid must only engage after approx. 1 second. Selector lever can only be shifted out of position "N" with the brake pedal operated.

Shift mechanism cover and selector lever knob, exploded view

Note. Lubricate bearing areas and slide surfaces with polycarbamide grease G 052 142 A2.

Scheme 867

1 - Selector lever

2 - Shaft piece for selector lever

1. Removing and installing selector lever knob --> «Selector lever handle, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

3 - Selector lever handle

1. Removing and installing --> «Selector lever handle, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

4 - Cover

1. With selector scale and Tiptronic gate and selector lever lock indicator
2. Removing and installing Tiptronic switch F189 --> «Tiptronic Switch F189 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__tiptronic-switch-f189-removing-and) and additionally unclipping cover

5 - Symbol insert

1. Clipped in cover

6 - Printed circuit board

1. with integrated Tiptronic Switch F189
2. Removing and installing --> «Tiptronic Switch F189 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__tiptronic-switch-f189-removing-and)

7 - Masking panel

1. With solenoid for Tiptronic switch F189 on reverse slide
2. Removing and installing Tiptronic Switch F189 --> «Tiptronic Switch F189 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__tiptronic-switch-f189-removing-and)

8 - Guide

1. For masking panel
2. Separate both halves by applying careful levering movements

1. Shift selector lever into position "D".

Scheme 868

1. Turn sleeve - 1 - to left and push downward as far as stop.
2. Carefully pull switch - 2 - just enough out of selector lever knob - 3 - until a cable tie can be inserted between button and selector lever.

Note. Do not remove button further under any circumstances, otherwise the selector lever knob will be damaged.

1. Secure button in pulled-out position using cable tie - arrow - as shown in illustration.
2. Remove selector lever knob upward.

Installation is reverse of removal, noting the following

1. Shift selector lever into position "D".

Note. To install new selector lever knob - 3 - , button 2 must be pulled out as far as stop and secured with a cable tie - arrow - or using assembly aid included with new knob. If the button was accidentally not secured, then it must not be pulled from selector lever knob using mechanical tools. Apply compressed air gun to bottom of knob and carefully press button out with compressed air.

1. Position complete selector lever knob - 3 - on selector lever - button 2 faces driver. During this, the knob must engage into ring groove of the selector lever.
2. Remove cable tie - arrow - or assembly aid, then button actuation engages in vertical groove of selector lever. If necessary press button into selector lever knob.
3. Pull sleeve - 1 - upward and engage by turning clockwise.

1. Selector lever handle, removing --> «Selector lever handle, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 869

1. Open ashtray in center console and remove trim (arrows).
2. Remove ashtray in center console: --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET

Scheme 870

1. Release all 4 clips (arrows) and pull cover - 1 - with guide upward to remove.
2. Disconnect electrical harness connector on side of guide.

Installation is reverse of removal, noting the following

1. Remove selector lever handle.

Tiptronic Switch F189 , removing and installing

Tiptronic switch is integrated into circuit board ( ), which is located in shift mechanism cover.

It consists of 3 camshaft position sensors, which are activated by a magnet on the cross slide masking panel.

To replace Tiptronic switch, circuit board ( ) must be replaced.

Check also whether solenoid is correctly fixed on transverse slide of masking panel, replace masking panel with guide if necessary.

1. Remove shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 871

1. Press the 4 lugs (arrows) inward and remove cover - 2 - from guide - 1 -.
2. Remove circuit board with integrated Tiptronic Switch F189 from cover - 2 -.

Note. If necessary, masking panel with solenoid for Tiptronic Switch F189 can be removed as described below. As replacement part the masking panel is only available together with guide.

Scheme 872

1. Separate both guide parts by applying careful levering movements (arrows).
2. Remove masking panel with solenoid for Tiptronic Switch F189.

Installation is reverse of removal, noting the following

1. Install shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Remove selector lever handle.

Shift mechanism, overview

Note. Lubricate bearing areas and slide surfaces with polycarbamide grease G 052 142 A2.

Scheme 873

1 - Shift mechanism bottom cover

2 - Retaining bracket

1. For selector lever

3 - Bearing bushing

4 - Tiptronic locking lever

5 - Pivot pin

6 - Selector lever

7 - Shift lock solenoid N110

1. Removing and installing --> «Shift Lock Solenoid N110 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

8 - Actuating lever

1. For locking cable

9 - Lock

1. For locking cable

10 - Lever

1. For locking cable

11 - Catch lever

12 - Gate

13 - 10 Nm

14 - Selector housing

15 - Bearing bushing

16 - Retaining bracket

1. For selector lever

17 - Retaining clip

1. Always replace

18 - Tiptronic locking lever

19 - Pivot pin

20 - 10 Nm

Additional information

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)
2. «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Selector lever handle, removing --> «Selector lever handle, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Open ashtray in center console and remove trim (arrows).
2. Remove air conditioning operating unit: --> «87 AIR CONDITIONING»(/audi/a4/b6-2000-2006/remont/ac-compressor/#heating-air-conditioning)
3. Remove ashtray in center console: --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET

1. Release all 4 clips (arrows) and pull cover - 1 - with guide upward to remove.
2. Disconnect electrical harness connector on side of guide.
3. Disconnect electrical harness connector on Shift Lock Solenoid N110.

Scheme 874

1. Disengage locking cable (arrows).
2. Shift selector lever into position "S".
3. Remove front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
4. Remove heat shield for driveshaft from body of the vehicle.

Scheme 875

1. Remove heat shield for driveshaft from cover for Torsen differential (arrows).
2. Unbolt driveshaft from transmission and hang or support. --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
3. Unbolt front heat shield, if installed, from below shift mechanism housing.

Scheme 876

1. Remove lower cover from shift mechanism (arrows).
2. Remove boot of selector lever cable from lower shift mechanism cover and slide back.

Scheme 877

1. Remove retaining clip - 1 - for selector lever cable on shift mechanism downward.
2. Pull plastic securing spring - 2 - slightly to front and push pin - 3 - up only as far as necessary (arrow).
3. Pull selector lever cable - 4 - out of shift mechanism at the same time, and do not bend.

Note. Do not bend or kink selector lever cable.

Scheme 878

1. Unscrew nuts (arrows).

Note. A second mechanic is required when detaching shift mechanism below vehicle.

1. Press holder clips - 1 - and - 2 - inward, at the same time pushing shift mechanism downward.

Installation is reverse of removal, noting the following

1. Install selector lever cable.

Scheme 879

1. Fit new retaining clip - 1 - for selector lever cable on shift mechanism.

Installation position

Angled end of retaining clip faces to inside of shift mechanism.

1. Install locking cable «Installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Adjust locking cable --> «Locking cable, adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__locking-cable-adjusting) .
3. Fit driveshaft to transmission. --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
4. Install front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Tightening torques

Shift mechanism, disassembling and assembling (sequence)

Note. Removing and installing securing spring for locking cable Securing spring for locking cable, removing and installing .

Disassembly of suspension strut

1. Move selector lever into position "S".
2. Remove selector lever lock solenoid - 7 - --> «Shift Lock Solenoid N110 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Carefully unbolt gate - 12 -.

Note. If gate - 12 - or selector housing - 14 - is damaged, complete selector housing with gate must be replaced.

1. Release pivot pins - 5 - and - 19 - and pull them out from the side.
2. Unclip retainers - 2 - and - 16 -.
3. Remove retaining clip - 17 -.
4. Swing locking lever - 11 - fully upward.

1. Pull selector lever - 6 - with bushes - 3 - and - 15 - together with locking levers for Tiptronic - 4 - and - 18 - downward out of selector housing - 14 -.

Assembly of suspension strut

1. Check whether selector lever is still in position "S".
2. Swing locking lever - 11 - fully upward.
3. Insert selector lever - 6 - into selector housing - 14 - from below.
4. Push locking levers for Tiptronic - 4 - and - 18 - along with bushes - 3 - and - 15 - onto selector lever.

1. Press selector lever - 6 - with bushes into selector housing and position it with retaining clip - 17 -.
2. Engage retainers - 2 - and - 16 - to selector housing.
3. Press pivot pins - 5 - and - 19 - into mounting bracket until they engage.
4. Check whether pivot pins engage in locking lever for Tiptronic.

1. Install selector lever lock solenoid - 7 - --> «Shift Lock Solenoid N110 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Tighten gate - 12 - to selector housing - 14 - with the 3 securing bolts to 0.4 Nm.

Note. If gate - 12 - or selector housing - 14 - is damaged by tightening too much, complete selector housing with gate must be replaced. Gate is matched to selector housing and cannot be replaced separately.

Scheme 880

Removing

1. Slightly lift spring at top (arrow B) and remove locking cable from shift mechanism.
2. Unhook spring (arrow A) at retaining clip (arrow C) and remove toward top.

Installing

1. Insert spring (arrow B) from top and hook in at retaining clip (arrow C).
2. Align spring so that it is seated evenly in groove (arrow A).
3. Slightly lift spring at top (arrow B) and insert locking cable into shift mechanism.

1. Remove shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Disconnect electrical harness connector on Shift Lock Solenoid N110.

Scheme 881

1. Release lugs and remove selector lever lock solenoid forward (arrows).

Installation is reverse of removal, noting the following

Scheme 882

1. Press selector lever lock solenoid into guide until it engages; actuating lever - 2 - of solenoid must engage in locking lever - 1 - on shift mechanism.
2. Install shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Selector lever cable and locking cable, assembly overview

Note. Do not bend or kink selector lever cable. Lubricate pull ring and ball socket with polycarbamide grease, part no. G 052 142 A2.

Scheme 883

1 - Selector lever cable

1. Must not be kinked
2. Removing and installing --> «Selector lever cable, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__selector-lever-cable-removing-and-installing)
3. Adjusting --> «Selector lever cable, checking and adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__selector-lever-cable-checking-and-adjusting)

2 - Lock nuts - 12 Nm

3 - Boot

1. For selector lever cable
2. Fasten into bottom cover of shift mechanism

4 - Locking clamp

5 - Ignition/Starter Switch

1. With ignition key removal lock

6 - Locking cable

1. For ignition key removal lock
2. Must not be kinked
3. Removing and installing --> «Locking cable, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
4. Adjusting --> «Locking cable, adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__locking-cable-adjusting)

7 - Hex-bolt - 9 Nm

8 - Clamping screw - 13 Nm

1. For selector lever cable
2. To adjust, loosen by approx. 1 turn, do not fully remove

9 - Pin

1. For selector lever cable
2. To remove selector lever cable, pull plastic securing spring on shift mechanism slightly forward and push pin up only as far as necessary

10 - Retaining clip

1. For selector lever cable
2. Always replace

11 - Pivot

1. For selector lever cable to transmission

12 - Hex-bolt, 23 Nm

Selector lever cable, removing and installing

Special tools, testers and auxiliary items required

Scheme 884

1. Pry lever 80-200

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)
2. «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Shift selector lever into position "S".
2. Raise vehicle.
3. Remove front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
4. Remove heat shield for driveshaft from body of the vehicle.

1. Remove heat shield for driveshaft from cover for Torsen differential (arrows).
2. Unbolt driveshaft from transmission and hang or support. --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
3. Remove shielding plate/selector lever cable, if installed.

Scheme 885

1. Remove mounting bracket for selector lever cable (arrow).
2. Removing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 886

1. Pry off selector lever cable from lever/shift rod using prying lever 80-200 (arrows).
2. Unbolt front heat shield, if installed, from below shift mechanism housing.

1. Remove lower cover from shift mechanism (arrows).
2. Remove boot of selector lever cable from lower shift mechanism cover and slide back.

1. Remove retaining clip - 1 - for selector lever cable on shift mechanism downward.
2. Pull plastic securing spring - 2 - slightly to front and push pin - 3 - up only as far as necessary (arrow).

Note. Make sure that pin is not pushed fully out.

1. Remove selector lever cable - 4 - from shift mechanism.

Note. Do not bend or kink selector lever cable.

Installation is reverse of removal, noting the following

1. Fit new retaining clip - 1 - for selector lever cable on shift mechanism.

Installation position

Angled end of retaining clip faces to inside of shift mechanism.

1. Insert end of selector lever cable - 4 - into selector lever joint.
2. Press pin - 3 - downward (arrow)
3. Check whether plastic securing spring - 2 - has locked pin.
4. Fasten selector lever cable boot into lower cover of shift mechanism.

1. Bolt lower cover to shift mechanism (arrows).

Note. Do not bend or kink selector lever cable.

1. Install front heat shield, if present, under shift mechanism housing.

Scheme 887

1. Push lever/selector shaft - 2 - on transmission fully forward into position "S" - arrow -.
2. Shift selector lever into "S" and carefully press up ball head of selector lever cable - 1 - on lever/shift rod - 2 - using a pair of pliers.

Note. Do not deform lever/shift rod when pressing up or else shifting cannot be precisely adjusted any more.

1. Bolt on mounting bracket for selector lever cable in this position (arrow).
2. Install shielding plate/selector lever cable, if present.
3. Install left transmission support with transmission mount --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
4. Fit driveshaft to transmission. --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Bolt heat shield for driveshaft onto transfer box (arrows).
2. Install front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
3. Adjust selector lever cable --> «Selector lever cable, checking and adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__selector-lever-cable-checking-and-adjusting) .

Selector lever cable, checking and adjusting

Special tools, testers and auxiliary items required

1. Special tool T40031

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)

Procedure

1. Shift selector lever into position "S".

For 6 cylinder gasoline engines

1. Remove left front exhaust pipe. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
2. Remove shielding plate/selector lever cable.

All

1. Remove mounting bracket for selector lever cable (arrow).
2. Removing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Grasp selector lever cable - 1 - and push lever/selector shaft - 2 - fully forward into position "S" - arrow -.

1. Bolt on mounting bracket for selector lever cable in this position (arrow).
2. Remove shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 888

1. Loosen rear clamping screw on selector lever cable approx. 1 turn through the hole in shift mechanism using special tool T40031.

Note. Loosen clamping screw approx. 1 turn. Do not remove. Clamping screw is only accessible in selector lever position "S". Selector lever must remain in position "S" while clamping screw is loose.

1. Check exact position of selector lever in position "S" by pushing selector lever lightly toward drivers seat (arrow - A - ).

Note. When adjusting, do not move selector lever backward or forward, or adjustment will be falsified.

1. Tighten clamping screw to 13 Nm in this position using special tool T40031.
2. Install shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Installing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

For 6 cylinder gasoline engines

1. Install shielding plate/selector lever cable.
2. Install left front exhaust pipe. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Note. Locking cable must not be kinked.

1. Shift selector lever into position "S".
2. Note radio code (for vehicles equipped with coded anti-theft radio/radio navigation system).

See Caution before beginning repairs on electrical system --> Selector lever mechanism, servicing

1. Disconnect Ground (GND) strap from battery.
2. Remove storage compartment on drivers side --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET
3. Remove steering column cover: --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET
4. Remove air conditioning operating unit: --> «87 AIR CONDITIONING»(/audi/a4/b6-2000-2006/remont/ac-compressor/#heating-air-conditioning)

1. Remove ashtray in center console: --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET
2. Remove shift mechanism cover --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Switch ignition key to driving position (ignition on).
4. Shift selector lever into position "P".

1. Lift retaining clip - 2 - from interlock lever and pull locking cable - 1 - out of ignition/starter switch.
2. Lift securing spring - 4 - for locking cable and pull locking cable support bracket - 5 - on shift mechanism sideways and disengage locking cable eye.

Installation is reverse of removal, noting the following

1. Route locking cable kink-free behind dash panel strut (arrow).
2. Switch ignition key to driving position (ignition on).
3. Insert locking cable - 1 - into ignition/starter switch.
4. Check that interlock lever - 2 - is locked.

1. Bring ignition/starter switch into locking position (ignition off).
2. Check whether selector lever is still in position "P".
3. Engage locking cable eye in pin - 3 -.
4. Slightly lift securing spring - 4 -.

1. Push locking cable support bracket - 5 - into shift mechanism from the right until securing spring - 4 - engages.
2. Adjusting locking cable --> «Locking cable, adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__locking-cable-adjusting) .

See Caution for connecting Telematics battery --> Selector lever mechanism, servicing

Note. Be sure to activate vehicle features (radio/radio-navigation system, clock, electric window regulators) according to owners manual when the battery is reconnected. Further measures after re-connecting power supply: --> 24 MULTIPORT FUEL INJECTION (MFI) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB 24 - MULTIPORT FUEL INJECTION (MFI) for 2.0 LITER 4-CYL. 4V TURBO FUEL INJECTION IGNITION, ENGINE CODE(S): BPG, BWT 24 MULTIPORT FUEL INJECTION (MFI) for 3.0 LITER 6-CYL. 5V FUEL INJECTION & IGNITION, ENGINE CODE(S): AVK, BGN 24 - FUEL INJECTION SYSTEM for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH 24 - MULTIPORT FUEL INJECTION (MFI) for 4.2 LITER V8 4V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BNS 24 MULTIPORT FUEL INJECTION (MFI) for 4.2 LITER V8 5V FUEL INJECTION AND IGNITION, ENGINE CODE(S): BHF

Scheme 889

Locking cable, adjusting

Special tools, testers and auxiliary items required

Scheme 890

1. Adjusting gauge 3352A for locking cable
2. Protective glasses

Preliminary work

Note. The following described procedure saves the work of removing center console.

Scheme 891

1. Cut through adjusting gauge 3352A at rear end of flat area - arrow - using a parting grinder.

1. Order a new adjusting gauge 3352A for locking cable as replacement for later use.

1. Remove center console trim --> «Shift mechanism cover, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Note. Selector lever knob and cover can remain installed.

1. Remove ashtray in center console: --> «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «68 - INTERIOR EQUIPMENT»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET

Adjustment requirements

1. Locking cable in installation position
2. Selector lever in position "P".
3. Ignition key in removal position.

Scheme 892

1. Loosen bolt - 1 -.

1. Support bracket - 2 - of locking cable must be movable by hand

1. Push modified adjusting gauge 3352A between pin on lever for locking cable and locking cable eye.
2. Move locking cable in direction of arrow to stop and tighten bolt - 1 - to 9 Nm.
3. It must be possible to easily remove and insert adjusting gauge 3352A in this position.
4. Remove adjusting gauge.

1. Check ignition key removal lock after every adjustment of the locking cable --> «Ignition key removal lock, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__ignition-key-removal-lock-checking) .

Tightening torque

Transmission, removing and installing

Special tools, testers and auxiliary items required

1. Engine support bridge 10-222A
2. Support 10-222A/1
3. Adapter 10-222A/3
4. Shackle 10-222A/12

1. Pry lever 80-200 for removing outside mirror
2. Transmission support 3282

Scheme 893

Special tools, testers and auxiliary items required

1. Adjustment plate 3282/19
2. Testing Mandrels 3393
3. Transport device 3457
4. Drip tray VAG1306

1. Engine/transmission support VAG1383A engine/gearbox jack
2. Ladder VAS5085

Note. All cable ties opened or cut during engine removal must be reinstalled at the same locations.

1. First determine whether a coded radio is installed. If so, determine the correct coding.

See Caution before beginning repairs on the electrical system --> Transmission, removing and installing

1. Switch ignition off and disconnect battery Ground (GND) strap.

Scheme 894

1. Remove cover - 1 - in engine compartment (left side).

Scheme 895

1. Remove cover - 1 - in engine compartment (right side).

Scheme 896

1. Remove engine cover (arrows).
2. Remove intake air duct from intake manifold.

Scheme 897

1. Disengage Evaporative Emission (EVAP) Canister Purge Regulator Valve N80 - 1 -.
2. Remove bolts (arrows) and remove intake air guide - 2 -.

Scheme 898

1. Fit support bar 10-222A together with supports 10-222A/1 and fit adapters 10-222A/3.
2. Secure spindles to engine. To do so, additionally use a shackle 10-222A/12 at the front side of the engine to avoid damage.
3. Take up weight of engine/transmission assembly on spindles.
4. Loosen wheel bolts.

1. Raise vehicle.
2. Remove front wheels.

Scheme 899

1. Remove noise insulation panel (arrows).
2. Remove front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Scheme 900

1. Remove heat shields for left, if installed, and right drive axles (arrows).

Third bolt is not visible in the illustration.

1. Unbolt left and right drive axles - 1 - from transmission flanges and tie up. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

Scheme 901

1. Remove noise insulation bracket - 1 -.
2. Disconnect connector - 2 - of wire for multi-function switch.
3. Swing securing lever - 3 - , disconnect connector for transmission wiring harness.
4. Cut cable ties - 4 -.

Make sure the wire for multi-function switch is not damaged when doing this.

Scheme 902

1. Disconnect connector from Speedometer Vehicle Speed Sensor (arrow - A - ).
2. Unbolt Engine Speed (RPM) Sensor G28 (arrow - B - ) from transmission.

Scheme 903

1. Unscrew nut - 2 - for clamp for ATF lines.
2. Place drip tray VAG1306 underneath.
3. Always clean area of ATF line/transmission connection.
4. Mark ATF lines if no color markings are present.

Scheme 904

1. Disconnect ATF lines - 1 -.
2. Plug ATF lines with clean plug.
3. Remove starter. --> «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment) «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(ref-278931-S05223151852008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

Scheme 905

1. Unbolt 3 torque converter bolts from drive plate (turn crank shaft an additional 1/3 turn every time).

1. Remove heat shield for driveshaft at transmission (arrows).

Scheme 906

1. Unbolt driveshaft - 1 - on transmission and secure to panel - 2 - with wire (arrow). --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
2. Remove shielding plate/selector lever cable, if installed.

1. Mark position of mounting bracket for selector lever cable to transmission housing for re-installation, unbolt mounting bracket (arrow).
2. Remove left transmission support with transmission mount --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Pry off selector lever cable from lever/shift rod using prying lever 80-200 (arrows).

Scheme 907

1. Unbolt multi-function Transmission Range (TR) switch F125 for protection against damage (arrows) and expose wiring harness.

Scheme 908

1. Prepare transmission support 3282 for Automatic Transmission 01V with adjustment plate 3282/10 and place it on the engine/transmission hoist VAG1383A.

Note. The symbols on the adjustment plate indicate the necessary mounts for Automatic Transmission 01V and the arrow points toward front of vehicle.

Scheme 909

1. Roll engine/transmission hoist VAG1383A with transmission support 3282 under transmission, align adjustment plate parallel to transmission and support transmission.
2. Secure transmission on transmission support 3282 using bolt - A -.
3. Fill space between gearbox support and sump with washers.

Automatic Transmission 01V with All Wheel Drive is supported at the same positions as the Front Wheel Drive version.

1. Remove right transmission support with transmission mount --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 910

1. Unclip retaining clip for coupling rods - 1 - of Left Front Level Control System Sensor G78 from left front control arm - 2 -.

Vehicles with six-cylinder engine

Scheme 911

1. Unbolt bolts (arrows) for stop/torque support - 1 -.

All

Scheme 912

1. Mark installation positions for threaded assemblies - 1 - and positioning sleeves - 2 -.
2. Remove nuts - 1 - on left and right engine mounts.

Note. When installing, make sure that locating sleeves - 2 - engage again.

Scheme 913

1. Before loosening subframe, check on both sides of vehicle, using testing Mandrels 3393 , that at least holes - 1 - and - 2 - align.

If this is not the case, axle alignment must be carried out after tightening of subframe.

Hole - 3 - is not applicable here.

Scheme 914

1. Remove bolts - 1 - and - 2 - at rear of subframe on both sides of vehicle.
2. Remove bolts - 3 - at front of subframe on both sides of vehicle.
3. Remove bolts - 4 - (2 bolts at each vehicle side).
4. Remove lower connecting bolts for engine/transmission.

1. Lower engine-transmission-subframe using the spindles approx. 4 turns. To do this use Support VAS5058.
2. To do this lower engine/gearbox assembly using spindles in turn, 2 turns at a time.
3. At the same time lower engine-transmission-subframe using lifter VAG1383A (second mechanic).

Note. When lowering transmission, ensure that no components are damaged.

1. Remove upper connecting bolts for engine/transmission.
2. Press transmission off engine, while pressing torque converter out of drive plate.

Scheme 915

1. Press torque converter against the ATF pump (arrow).
2. Lower transmission.

Scheme 916

1. Secure converter so it does not fall out.

For disassembly and assembly, secure transmission to assembly stand using Transport device 3457 and Holding plate VW309 --> Transmission, attaching to assembly stand .

Installation of transmission is the reverse of removal. The following points must also be observed

Before installing

1. Clean threads in output flange/driveshaft flange using a tap.
2. Clean ATF lines --> «ATF lines and ATF cooler, cleaning»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-lines-and-atf-cooler-cleaning) .
3. Insert torque converter correctly into transmission

Installation dimension for torque converter, checking

When torque converter is installed correctly, distance between lower contact surface of threaded holes at torque converter and contact surface of converter housing on Automatic Transmission 01V is approx. 23 mm.

If the torque converter is not inserted completely, this distance will be approx. 11 mm.

1. Make sure bushings are correctly seated.

Note. If the bushings get stuck in the transmission housing, they must be removed and new bushings must be installed on the engine.

Scheme 917

For 4 cylinder engines

Item A = bushings

Scheme 918

For 6 cylinder engines

Item A = bushings

1. Prepare transmission support 3282 for Automatic Transmission 01V with adjustment plate 3282/10 and place it on the engine/transmission hoist VAG1383A.

Note. The symbols on the adjustment plate indicate the necessary mounts for Automatic Transmission 01V and the arrow points toward front of vehicle.

1. Place transmission onto transmission support.

1. Secure transmission on transmission support 3282 using bolt - A -.
2. Move transmission into position between the lowered subframe and vehicle floor.
3. Align transmission properly to engine.
4. Tighten one engine/transmission connecting bolt at either side by hand.

1. Make sure that wires do not get pinched as transmission is docked at engine.

1. Bolt together torque converter and drive plate.
2. To do this insert bolts by hand and tighten to tightening torque.
3. Insert top engine/transmission connecting bolts and tighten to tightening torque.

Note. Some bolts also have a bracket or a Ground (GND) connection attached refer to tightening torque tables starting on --> --> Tightening torques .

1. Raise engine-transmission-subframe using the spindles approx. 4 turns. To do this use Support VAS5058.
2. To do this raise engine/gearbox assembly using spindles in turn, 2 turns at a time.
3. At the same time raise engine-transmission-subframe using lifter VAG1383A (second mechanic).
4. Insert remaining engine/transmission connecting bolts and tighten to tightening torque

1. Install subframe, observe tightening sequence and alignment with master bore hole. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Only perform vehicle alignment if necessary. --> «44 - WHEELS, TIRES, VEHICLE ALIGNMENT»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
3. Install right transmission support with transmission mount --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

Scheme 919

1. Screw on lower nuts - A - on left and right engine mounts. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Vehicles with six-cylinder engine

1. Bolt on torque support stop - 1 - (arrows). --> «10 - ENGINE - ASSEMBLY»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «10 - ENGINE - ASSEMBLY»(ref-278881-S23313549852008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «10 ENGINE - ASSEMBLY»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «10 - ENGINE - ASSEMBLY»(ref-278883-S24046934652008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «10 - ENGINE - ASSEMBLY»(ref-278885-S28123014792008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «10 - ENGINE - ASSEMBLY»(ref-278884-S30565723472008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

All

1. Attach retaining clip for coupling rods of Left Front Level Control System Sensor G78 to left front control arm, if present. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

1. After subframe is installed, remove bolt - A - and remove transmission jack VAG1383A.
2. Apply corrosion protection to contact surface between bolt - A - and oil pan.

1. Push lever/selector shaft - 2 - on transmission fully forward (on illustration fully left).
2. Shift selector lever into "S" and carefully press up ball head of selector lever cable - 1 - on lever/shift rod - 2 - using a pair of pliers.

Note. Do not deform lever/shift rod when pressing up or else shifting cannot be precisely adjusted any more.

1. Bolt on mounting bracket for selector lever cable to transmission corresponding to marking for re-installation of transmission.
2. Install shielding plate/selector lever cable, if present.

1. Install Multi-Function Transmission Range (TR) Switch F125 --> «Multi-Function Transmission Range (TR) Switch F125 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) ; removing and installing Multi-Function Transmission Range (TR) Switch F125
2. Install left transmission support with transmission mount --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Bolt driveshaft to transmission. --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Install heat shield for driveshaft at transmission (arrows).
2. Install starter. --> «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(/audi/a4/b6-2000-2006/remont/cruise-control-systems/#electrical-equipment) «27 BATTERY, STARTER, GENERATOR, CRUISE CONTROL»(ref-278931-S05223151852008020700000) for ELECTRICAL EQUIPMENT, CABRIOLET

1. Connect ATF lines - 1 - according to the respective color markings.

1. Engage clamp for ATF lines and tighten nut - 2 -.

1. Connect connector of Speedometer Vehicle Speed Sensor (arrow A-).
2. Bolt Engine Speed (RPM) Sensor G28 (arrow - B - ) to transmission.

1. Install noise insulation bracket - 1 -.
2. Connect connector - 2 - of wire for multi-function switch.
3. Connect connector for transmission wiring harness and swivel securing lever - 3 -.
4. Replace cable ties - 4 -.

1. Bolt on left and right driveshafts - 1 - to transmission flanges. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Install heat shields for left, if present, and right drive axles (arrows).

Third bolt is not visible in the illustration.

1. Install front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

1. Install noise insulation panel (arrows).
2. Install front wheels. --> «44 - WHEELS, TIRES, VEHICLE ALIGNMENT»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
3. Remove engine support bridge 10-222A.
4. Fit intake air duct to intake manifold.

1. Install intake air guides.
2. Install engine cover.
3. Install left and right covers in engine compartment.

See Caution for connecting Telematics battery --> Transmission, removing and installing

1. After connecting battery, enter anti-theft code for radio operating manual.
2. Check adjustment of selector lever cable --> «Selector lever cable, checking and adjusting»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__selector-lever-cable-checking-and-adjusting) .
3. Check gear oil in front final drive with transmission installed --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .
4. Then check ATF level and top off onward --> «Automatic Transmission Fluid (ATF), checking and changing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Fully close power windows to stop.
2. Then activate all power window switches ( "up" ) for at least one second to activate automatic window raising/lowering.
3. Set clock to correct time.

Note. Tightening torques are valid only for nuts and bolts that are lightly greased, oiled, covered with a thin coat of phosphate or blackened. Other lubricants are permitted, e.g. engine oil or transmission fluid, however they may not contain graphite. Do not use any degreased parts.

Engine/transmission mount for 4-cylinder gasoline engines

*with nut

*with bracket for wiring harness

*with cable bracket

Item A = bushings

Engine/transmission mount for 6-cylinder gasoline engines

*with nut

Item A = bushings

Scheme 920

Valid for all engine/transmission types

Transmission, transporting

Special tools, testers and auxiliary items required

Scheme 921

1. Attachment and holding rig 3457

The attachment and holding rig 3457 can be used when transporting the transmission and for setting up the transmission support 3282.

1. Remove ATF lines from transmission (only for vehicles with 6-cylinder engine).
2. Plug ATF connections with plugs.
3. Unbolt left and right transmission supports.

Scheme 922

1. Attach the attachment and holding rig 3457 at the transmission housing mounts and secure.

Scheme 923

Special tools, testers and auxiliary items required

1. Attachment and holding rig 3457
2. Holding fixture VW540 (only for FWD transmissions) (Not for US/Canada)
3. Holding fixture VW313
4. Holding plate VW309

1. Engine Hoist VAG1202A

1. Attach the attachment and holding rig 3457 at the transmission housing mounts and secure.
2. Bolt the attachment and holding rig to the holding plate VW309 and place this into the holding fixture VW313 using a workshop crane.

For transmissions with Front Wheel Drive (FWD), the holding fixture VW540 can also be used to secure the transmission to the holding fixture VW313 (Not for US/Canada).

Scheme 924

1. Secure transmission to holding fixture VW540 (arrows) and insert in holding fixture VW313.

Note. Vents for the transmission housing and final drive must be closed before turning a filled transmission on the assembly stand so that the oil pan faces upward.

Scheme 925

Special tools, testers and auxiliary items required

1. Transmission support 3282
2. Adjustment plate 3282/19
3. Engine/transmission support VAG1383A engine/gearbox jack

Note. Transmission must be supported as indicated when both transmission supports are removed. Transmission does not need to be supported this way when only one of the transmission supports is being removed.

1. Prepare transmission support 3282 for Automatic Transmission 01V with adjustment plate 3282/10 and place it on the engine/transmission hoist VAG1383A.

Note. The symbols on the adjustment plate indicate the necessary mounts for Automatic Transmission 01V and the arrow points toward front of vehicle.

1. Roll engine/transmission hoist VAG1383A with transmission support 3282 under transmission, align adjustment plate parallel to transmission and support transmission.
2. Secure transmission on transmission support 3282 using bolt - A -.

Note. If transmission support 3282 is not available, transmission can be supported using the transmission lift VAG1383A and the 1359/2 universal mount.

Right transmission support

Scheme 926

1. Remove bolts - B -.
2. Remove heat shield - C -.
3. Remove right heat shield -D- by removing bolts - A - from transmission.

Left transmission support

Scheme 927

1. Remove bolts - B -.
2. Remove heat shield - C -.

Note. The left heat shield is not installed on 4 cylinder gasoline engines.

1. Remove left heat shield -D- by removing bolts - A - from transmission.

Left and right transmission supports

1. Unscrew nuts - A - on subframe.

Scheme 928

1. Remove transmission supports -E-.

Note. Items - C - and - B - are not installed on vehicles with hydraulic transmission bearing H, because bolt G is threaded directly into the transmission bearing.

Installation is the reverse of removal.

Tightening torques for left and right transmission supports

Tightening torques for left transmission support

Tightening torques for right transmission support

Scheme 929

Special tools, testers and auxiliary items required

1. Tester VAS5051
2. Diagnostic cable VAS5051/1 or VAS5051/3
3. Drip tray VAG1306
4. ATF filler tool VAG1924

1. Protective glasses

Test requirements

1. Transmission must not be in emergency running mode.
2. Vehicle on level ground.
3. Selector lever in "P" , let engine run at idle.
4. A/C system and heating switched off.

Note. ATF level changes with ATF temperature. Performing ATF level check when ATF temperature is too low causes overfilling. Performing ATF level check when ATF temperature is too high causes insufficient filling. Excess filling and insufficient filling both affect the function of the transmission. ATF temperature is read off using the tester VAS5051.

Scheme 930

1. Secure container of ATF filler tool VAG1924 as high up on vehicle as possible.

1. Remove noise insulation panel (arrows).

Connect tester VAS5051

All functions previously performed with the VAG1551 can also be performed using the new tester VAS5051 in operating mode "Vehicle On Board Diagnostic (OBD)"

Scheme 931

1. Connect tester VAS5051 to Data Link Connector (DLC) using diagnostic cable VAS5051/1 with ignition switched off.

Scheme 932

1. Switch on tester (arrow).

The tester now requires up to 3 minutes to finish booting.

1. Switch on ignition.
2. Select operating mode: Press "Vehicle Self-Diagnosis" selection on display.
3. Press "02 - Transmission electronics" on display.
4. Perform dialog to confirm control module number belonging to selected system.

1. Select "08 - Read Measuring Value Block" on display.
2. Choose Display Group 4 via the "Read Measuring Value Block" and "Change Display Group" touch screen displays.

Scheme 933

Display on VAS5051

The first line of display field - 1 - displays ATF temperature.

Checking and correcting ATF level

Note. ATF level is checked at the ATF check plug. ATF level is correct if a little bit of fluid still escapes at the ATF check plug between 35 ° and 45 ° C * See note (dependent on the fluid level when warming up).

* For warm countries 50 ° C

1. Start engine.
2. Raise vehicle.
3. Place drip tray VAG1306 under transmission.

Scheme 934

1. Once an ATF temperature of 35 ° C is reached, remove ATF check plug (arrow) and drain excess ATF if necessary.

Scheme 935

1. If ATF flows out from the ATF filler plug hole before the ATF reaches 40 ° C, the ATF level (arrow) is OK.

Note. ATF check plug must be closed again by 45 ° C * See note at the latest.

* For warm countries 50 ° C

1. Add ATF if no ATF has escaped from the ATF check plug hole by 40 ° C.
2. ATF specification --> «Capacity»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

Scheme 936

1. Insert ATF filler tool VAG1924 into an opening (arrow) in the protective cap, but do not knock cap upward.

Scheme 937

1. Fill with ATF using ATF filler tool VAG1924 until ATF exits from the check hole.

Scheme 938

1. Always replace seal (arrow) for ATF check plug.
2. Tighten ATF check plug to 80 Nm.
3. Switch off motor.
4. Select diagnostic function "06 - end output" in selection.

Scheme 939

Display on VAS5051

1. Switch off ignition and disconnect diagnostic connector after this indication is displayed.
2. Install noise insulation.

ATF, changing or topping off after repairs

Special tools, testers and auxiliary items required

Scheme 940

1. Drip tray VAG1306

Scheme 941

1. ATF filler tool VAG1924
2. Engine switched off.

1. Secure container of ATF filler tool VAG1924 as high up on vehicle as possible.
2. Raise vehicle.

1. Remove noise insulation panel (arrows).

Note. Observe disposal regulations. Engine must not be started without ATF and vehicle must not be towed!

1. Place Drip tray VAG1306 under transmission.

Scheme 942

1. Remove drain plug (arrow - 1 - ).
2. Let ATF drain.
3. Tighten new drain plug (arrow - 1 - ) to 40 Nm.

Note. Drain plug and oil seal must both be replaced.

1. Remove ATF check plug (arrow - 2 - ).

1. Insert ATF filler tool VAG1924 into an opening (arrow) in the protective cap, but do not knock cap upward.

1. ATF specification --> «Capacity»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

1. Fill with ATF using ATF filler tool VAG1924 until ATF exits from the check hole.
2. Shift selector lever into position "P".
3. Start engine.
4. Keeping the brake pedal depressed, shift into all selector lever positions at idle speed. Each position must remain selected for at least 10 seconds.

1. Shift selector lever into position "P".
2. Check ATF level and top off --> «ATF level, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) onward.
3. Install noise insulation.

Note. Observe all notes and test requirements for "Checking ATF level".

Scheme 943

A - Clutch A

B - Clutch B

E - Clutch E

F - Clutch F

C - Brake C

D - Brake D

G - Brake G

F1 - Freewheel 1

1 - Engine

2 - Torque converter with lock-up clutch

3 - Front differential

4 - Automatic transmission

5 - Drive pinion

6 - Output shaft

7 - Center differential

8 - Driveshaft

9 - Rear differential

Z1, Z2 and Z3 = spur gears of front intermediate drive; ratio --> Code letters, allocation, ratios, equipment

Z4, Z5 = front gear set; ratio --> Code letters, allocation, ratios, equipment

Z6, Z7 = spur gears of rear intermediate drive; ratio All Wheel Drive (AWD)

Z8, Z9 = rear ring gear, ratio All Wheel Drive (AWD)

Note. Arrows point in direction of travel.

Shift element positions

1. When dealing with problems relating to poor acceleration and performance or general malfunctions, the following chart indicates which selector elements are actuated in the various gears. This should help to identify the selector elements that are not working properly.

x = Component is actuated

= Component is not actuated

(x) = Component actuation is dependent on driving condition

Transmission, disassembling and assembling

1. Observe general repair instructions --> «Servicing notes»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Rules of cleanliness for working on automatic transmissions

1. Thoroughly clean all connections and the surrounding area before disconnecting.
2. Place parts that have been removed on a clean surface and cover. Use foils and paper. Use lint-free cloths only!
3. Carefully cover over opened components or seal, if repairs are not carried out immediately.
4. Only install clean components: Only unpack replacement parts immediately prior to installation.

1. Always replace O-rings, gaskets and sealing rings.
2. Lightly lubricate O-rings before installing, this prevents the rings from being pinched when inserting.
3. Use only ATF in areas near ATF. Other lubricating substances cause functional problems in the hydraulic transmission control.
4. Check the following fluid levels after installing, top off if necessary. ATF in planetary gear --> «ATF level, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) , gear oil in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) , gear oil in center differential --> «Gear oil in center differential, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) . Capacities and specifications --> «Capacity»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) onward.

ATF lines, removing and installing (overview)

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

Removing and installing ATF lines for 4 cylinder gasoline engines --> ATF lines, removing and installing, (vehicles with 4 cyl. engine)

Removing and installing ATF lines for 6 cylinder gasoline engines --> ATF lines, removing and installing, (vehicles with 6 cyl. engine)

ATF lines, removing and installing, (vehicles with 4 cyl. engine)

Note. Place drip tray VAG1306 underneath.

Scheme 944

1 - Bolt (21Nm)

1. Insert line until impact by hand before tightening

2 - Oil line to cooler

1. Note marking on transmission housing

3 - Oil line from cooler

1. Note marking on transmission housing

4 - O-ring

1. Apply ATF when inserting
2. Always replace

5 - O-ring

1. Apply ATF when inserting
2. Always replace

6 - Bolt (5Nm)

1. Insert line until impact by hand before tightening

7 - O-ring

1. Apply ATF when inserting
2. Always replace

8 - Bolt (5Nm)

1. Insert line until impact by hand before tightening

9 - Union nut - 29 Nm

10 - Bracket

11 - Hex bolt

1. Does not need to be removed when removing and installing ATF lines.

12 - Nut - 5 Nm

13 - Clamp

14 - Bracket

1. On engine/transmission support

ATF lines, removing and installing, (vehicles with 6 cyl. engine)

Note. Place drip tray VAG1306 underneath.

Scheme 945

1 - Bolt (21Nm)

1. Insert line until impact by hand before tightening

2 - Oil line to cooler

1. Note marking on transmission housing
2. Note color identification (arrow)

3 - Oil line from cooler

1. Note marking on transmission housing
2. Note color identification (arrow)

4 - O-ring

1. Apply ATF when inserting
2. Always replace

5 - O-ring

1. Apply ATF when inserting
2. Always replace

6 - Bolt (5Nm)

1. Insert line until impact by hand before tightening

7 - O-ring

1. Apply ATF when inserting
2. Always replace

8 - Union nut - 29 Nm

9 - Bracket

10 - Bolt (5Nm)

11 - Double bolt - 10 Nm

12 - Bracket

13 - Combination nut - 10 Nm

14 - Clamp

15 - Combination nut - 5 Nm

ATF lines and ATF cooler, cleaning

Special tools, testers and auxiliary items required

1. Drip tray VAG1306
2. Hose, approx. 18 mm
3. Compressed air gun, standard
4. Protective glasses

Note. Always blow compressed air through oil cooler and ATF lines (max. 10 mbar) before installing a replacement transmission. When installing ATF lines, insert into transmission or cooler by hand until impact first and then tighten bolts.

1. Place drip tray VAG1306 underneath.

Scheme 946

1. Remove bolt - 2 -.
2. Disconnect ATF lines from transmission.
3. Slide a hose with approx. 18 mm diameter onto ATF line - A - and secure with hose clamp. Place the other end of the hose into an appropriate container.
4. Blow through ATF line - B - with compressed air gun.

1. Change hose from ATF line - A - to ATF line - B - and repeat procedure.
2. Replace O-ring - 1 -.
3. Coat O-ring with ATF.
4. Insert ATF lines completely into transmission by hand until stop.

1. Re-secure ATF lines.
2. Then check ATF level and top off --> «ATF level, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) onward.

Oil pan, oil strainer and valve body, removing and installing

Note. Always replace a soiled or faulty valve body. Rules of cleanliness for working on automatic transmissions --> Rules of cleanliness for working on automatic transmissions . General repair notes --> Servicing notes . Coat O-rings and sealing rings with ATF. Other lubricating substances lead to functional problems in the hydraulic transmission control.

Scheme 947

1 - Drain plug - 40 Nm

1. With seal
2. Always replace
3. 5 mm socket-head bolt
4. Remove to drain ATF

2 - Bolt - 10 Nm

1. Tighten bolts for oil pan in several stages in diagonal sequence

3 - Oil pan

1. Removing and installing --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing)

4 - Gasket

1. Always replace

5 - Oil strainer

1. Removing and installing --> «Oil strainer, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

6 - Bolt - 8 Nm

1. For mounting valve body: 16 bolts M6 x 60
2. Observe tightening sequence --> (Scheme 955)

7 - Valve body

1. Removing and installing --> «Valve body, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__valve-body-removing-and-installing)

8 - Bolt - 8 Nm

9 - Bracket

1. For wiring harness
2. Hook in wiring harness
3. Mounted with valve body bolts

10 - Bolt - 6 Nm

11 - Transmission Vehicle Speed Sensor (VSS) G38 (also designated as Sender for transmission output RPM G195 )

1. Removing and installing --> «Transmission Vehicle Speed Sensor (VSS) G38 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__transmission-vehicle-speed-sensor-vss-g38)

12 - Spacer sleeve

1. Height: 8 mm

13 - Inner oil line

1. Always replace
2. Removing and installing --> «Oil line inside transmission, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-line-inside-transmission-removing-and)

14 - O-ring

1. Always replace

15 - Speedometer Vehicle Speed Sensor (VSS) G22

1. Removing and installing --> «Speedometer Vehicle Speed Sensor (VSS) G22 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

16 - O-ring

1. Always replace
2. Coat with gear oil and insert

17 - Multi-Function Transmission Range (TR) Switch F125

1. Removing and installing --> «Multi-Function Transmission Range (TR) Switch F125 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. Replacing shift rod sealing ring --> «Shift rod seal, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__shift-rod-seal-replacing)

18 - Bolt - 8 Nm

19 - O-ring

1. Always replace
2. Coat with ATF and insert

20 - Locking clamp

1. Always replace

21 - Wiring harness in transmission

1. Always replace --> «Wiring harness inside transmission, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. Transmission Fluid Temperature Sensor G93 is integrated into the wiring harness
3. Remove and install valve body to replace --> «Valve body, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__valve-body-removing-and-installing)
4. Unhook from bracket for wiring harness, item 10

1. Installation position wiring harness connector: Flat part of rear collar points toward oil pan, the tabs at collar are horizontal

22 - Bolt - 9 Nm

23 - Sensor for transmission RPM G182

1. Removing and installing --> «Sensor for transmission RPM G182 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

24 - Connector

1. Is connected at wiring harness in transmission
2. Must be disconnected before removing the valve body

25 - Bolt - 6 Nm

26 - Bracket

1. For solenoid valve

27 - Pressure Control Valve 1 for Auto. Transmission N215

1. With O-ring
2. Remove and install valve body to replace --> «Valve body, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__valve-body-removing-and-installing)

28 - Solenoid valve 3 N90

1. Without O-ring
2. Remove and install oil pan to replace --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing)

29 - Solenoid valve 2 N89

1. Without O-ring
2. Remove and install oil pan to replace --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing)

30 - Bolt - 6 Nm

31 - Bracket

1. For solenoid valves

32 - Pressure Control Valve 3 for Auto. Transmission N217

1. With O-ring
2. Remove and install oil pan to replace --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing)

33 - Pressure Control Valve 4 for Auto. Transmission N218

1. With O-ring
2. Remove and install oil pan to replace --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing)

34 - Pressure Control Valve 2 for Auto. Transmission N216

1. With O-ring
2. Remove and install oil pan to replace --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing)

35 - Solenoid valve 1 N88

1. Without O-ring
2. Remove and install oil pan to replace --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing) and unbolt guide plate for park locking mechanism
3. When installing, do not tighten bolts for guide plate (23 Nm) in selector lever position "P".

36 - Bolt - 6 Nm

37 - Magnet

1. 4 pieces in the oil pan recesses
2. Clean after every removal of oil pan
3. Ensure full surface contact in oil pan

38 - O-ring

1. Always replace

39 - ATF check plug - 80 Nm

1. 17 mm socket-head bolt

Oil pan, removing and installing

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

1. Remove noise insulation panel (arrows).
2. Place drip tray VAG1306 under transmission.

Scheme 948

1. Remove ATF drain plug (arrow) and drain ATF.
2. Loosen oil pan bolts diagonally and remove oil pan.

Installation is reverse of removal, noting the following

1. Clean all 4 magnets in oil pan recesses. Ensure full surface contact of the magnets on the oil pan.
2. Replace gaskets.

Note. Drain plug and oil seal must both be replaced.

1. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .

1. Removing oil pan --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing) .

Scheme 949

1. Removing oil strainer bolts (arrows).
2. Pull oil strainer off of valve body.

1. Lightly coat seal on suction collar of oil strainer with ATF.
2. Carefully press suction collar of oil strainer into the opening at valve body up to stop.
3. Bolt on oil strainer.
4. Installing oil pan.

1. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .

Valve body, removing and installing

Note. Always replace a soiled or faulty valve body. General repair notes --> Servicing notes . Rules of cleanliness for working on automatic transmissions --> Rules of cleanliness for working on automatic transmissions .

1. Removing oil pan --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing) .
2. Removing oil strainer --> «Oil strainer, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 950

1. Disconnect clip for wiring harness connectors (arrow).

Scheme 951

1. Disconnect harness connector from Transmission Vehicle Speed Sensor (VSS) G38 ( - A - ).
2. Disconnect harness connector from Sensor for transmission RPM G182 ( - B - ).

Scheme 952

1. Loosen mounting bolts (arrows) of valve body and remove valve body with wiring harness.

Note. Only the marked mounting bolts (arrows) must be loosened. When loosening other bolts, the function of the valve body can be influenced or the valve body splits up. The bolt (arrow A) is not installed on transmissions with hydraulic control E18/2 and can therefore be disregarded.

1. Remove valve body from transmission while advancing the wiring harness connector.

1. Lightly coat O-rings of wiring harness connector with ATF.
2. Insert wiring harness connector into transmission housing.

1. Installation position: Flat part of rear collar points downward, the tabs at collar are horizontal

1. Route wire with connector - C - according to illustration, so that the wire is not pinched when installing the valve body.

Scheme 953

1. Insert connector with flat part (arrow - A - ) facing toward oil pan into transmission housing.
2. Align valve body to hole in transmission housing (arrow - C - ) using alignment pin (arrow - B - ).

Scheme 954

1. Set valve body in place without force while placing bolt of notched disc - 1 - into the groove of the selector register - 2 -.

1. Next, tighten valve body bolts (arrows) by hand.

Note. The bolt (arrow A) is not installed on transmissions with hydraulic control E18/2 and can therefore be disregarded.

1. Then tighten valve body bolts from inside out to final tension.

Scheme 955

1. Pull wiring with connector - B - of Sensor for transmission RPM G182 between valve body and wiring harness upward.
2. Connect connector - B - to connector - A - at wiring harness.
3. Connect connector - C - to Transmission Vehicle Speed Sensor (VSS) G38.

1. Connect clip to wiring harness connector (arrow).
2. Installing oil strainer --> «Oil strainer, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Installing oil pan.
4. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .

Oil line inside transmission, removing and installing

Special tools, testers and auxiliary items required

Scheme 956

1. 3381oil line installer

Note. Faulty O-rings at inner oil line allow ATF to enter the differential, which becomes over-filled and oil escapes at differential vent. A removed oil line generally must be replaced. The oil line must only be inserted using 3381oil line installer. Otherwise there is a risk of leaks because of bending of the oil line.

1. Removing valve body --> «Valve body, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__valve-body-removing-and-installing) .

Scheme 957

1. Lever off inner oil line evenly from transmission housing.

Installation is reverse of removal, noting the following

1. Replace O-rings.

Scheme 958

1. Insert oil line into oil line installer 3381.
2. Drive oil line into transmission housing by lightly tapping on the oil line installer 3381 up to stop using a plastic mallet.

Note. The open side of oil line installer 3381 faces toward the outer wall of the transmission. Do not cant oil line. Drive in both line ends uniformly.

1. Installing valve body.
2. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .
3. Check oil level in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .

Shift rod seal, replacing

Special tools, testers and auxiliary items required

Scheme 959

1. Sealing ring installer 3385

1. Pry lever 80-200

1. Removing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Removing Multi-Function Transmission Range (TR) Switch F125 --> «Multi-Function Transmission Range (TR) Switch F125 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Pry off selector lever cable from lever/shift rod (arrow).

Scheme 960

1. Drive out spring dowel sleeve - 1 - at lever/shift rod - 2 - in direction of travel toward the front (arrow), until the lever/shift rod can be pulled off the shift rod.

Scheme 961

1. Pierce sealing ring using a small screwdriver and pull out.

1. Coat outer circumference and gap between sealing lips with ATF.

1. Installation position: The open side of the sealing ring faces the transmission.

Scheme 962

1. Slide new sealing ring onto sealing ring installer 3385 without canting and drive in up to stop of pressure piece.
2. Installing Multi-function switch --> «Multi-Function Transmission Range (TR) Switch F125 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Drive back spring dowel sleeve with transmission not yet removed in opposite direction through the lever.
4. Slide transmission shift lever onto shift rod and drive in spring dowel sleeve.

1. Push lever/selector shaft - 2 - on transmission fully forward (on illustration fully left).
2. Shift selector lever into "S" and carefully press up ball head of selector lever cable - 1 - on lever/shift rod - 2 - using a pair of pliers.

Note. Do not deform lever/shift rod when pressing up or else shifting cannot be precisely adjusted any more.

Scheme 963

1. Rotate multi-function switch - 3 - until the alignment bore - 4 - at switch housing can be fitted on the alignment pin - 2 - at transmission housing.
2. Installing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Removing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Unbolt Multi-Function Transmission Range (TR) Switch F125 from transmission and pull off from shift rod.

1. Connect Multi-Function Transmission Range (TR) Switch F125 to shift rod. Flap part at splines in switch - 3 - must align with flat part of shift rod - 1 -.

Note. Set Multi-Function Transmission Range (TR) Switch F125 onto shift rod in centered manner. Do not cant and do not set with force. Risk of damage at switch terminals.

1. Rotate switch until the alignment bore - 4 - at switch housing can be fitted on the alignment pin - 2 - at transmission housing.
2. Installing left transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Remove heat shield - 1 - for left drive axle (arrows), if installed.

Third bolt is not visible in the illustration.

Scheme 964

1. Disconnect harness connector from Speedometer Vehicle Speed Sensor (VSS) G22 (arrow - A - ).
2. Push retaining bracket of sensor downward, and turn (arrow).
3. Remove sensor.

Scheme 965

1. Replace sealing rings (arrows).
2. Insert O-rings with gear oil.
3. Insert sensor.
4. Engage retaining bracket at mounting bracket for flange shaft.

1. Install heat shield - 1 - for left drive axle (arrows), if present.

Third bolt is not visible in the illustration.

1. Removing valve body --> «Valve body, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__valve-body-removing-and-installing) .

1. Unbolt Sensor for transmission RPM - A - from transmission.

1. Bolt on Sensor for transmission RPM - A - at transmission via bolt - B -. Tightening torque is 9 Nm.
2. Route wire with connector - C - according to illustration, so that the wire is not pinched when installing the valve body.
3. Installing valve body.
4. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .

Transmission Vehicle Speed Sensor (VSS) G38 , removing and installing

Also referred to as Sender for transmission output RPM G195.

1. Removing oil pan --> «Oil pan, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__oil-pan-removing-and-installing) .

Scheme 966

1. Disconnect harness connector from Transmission Vehicle Speed Sensor (VSS) G38 (arrow).

Scheme 967

1. Remove Transmission Vehicle Speed Sensor (VSS) - 2 -.

1. Install and tighten Transmission Vehicle Speed Sensor (VSS) - 2 - using spacer sleeve - 1 - (height: 8 mm) to 6 Nm.

1. Connect connector at Transmission Vehicle Speed Sensor (VSS) G38.
2. Installing oil pan.
3. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .

1. Removing valve body --> «Valve body, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__valve-body-removing-and-installing) .

Scheme 968

1. Lever out retainer straps of connectors at solenoid valves and pressure control valves using a small screwdriver and disconnect connectors - A - in sequence.
2. Unhook wiring harness at side retainer straps - B - of valve body.

Scheme 969

1. Turn valve body on its back side and loosen connector - 1 - at Pressure Control Valve 1 for Auto. Transmission N215.
2. Remove retaining clip (arrow A) and unclip wiring harness from retaining clip (arrow B).

Installation is reverse of removal, noting the following

1. When installing, connect connectors of wiring harness to the corresponding solenoid valves and pressure control valves.
2. Clip wiring harness into the respective retaining clips. In case of deviations, the wiring harness can be pinched during installation of the valve body.
3. Installing valve body.
4. Fill up ATF --> «ATF, changing or topping off after repairs»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__atf-changing-or-topping-off-after) .

Transmission Fluid Temperature Sensor G93 , replacing

Note. Transmission Fluid Temperature Sensor G93 is integrated in the transmission wiring harness.

Removal

1. Remove wiring harness in transmission --> «Wiring harness inside transmission, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Installation is the reverse of removal. Also carry out the following procedure.

1. Replace wiring harness with a new one.
2. Install new wiring harness in transmission --> «Wiring harness inside transmission, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Gear oil in front final drive, checking

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

Scheme 970

1. Plug insert 3247 (8mm)

Procedure

1. Warm up gear oil in front final drive to approx. 60 ° C by performing a short road test.
2. Drive vehicle onto a 4-column lift or over a work pit.

Note. The vehicle must be on a level surface.

1. Place drip tray VAG1306 underneath.

Scheme 971

1. Remove locking screw (arrow).

Note. Loosen locking bolt using an angled socket-head wrench, but do not use hex ball socket 3247. For improved accessibility it may be necessary to remove the heat shield and drive axle and to set them aside. If hex ball socket 3247 is used for loosening the bolt, it could be destroyed.

1. With engine switched off, allow gear oil to drip out for approx. 2 minutes.

Oil level is correct when the front final drive is filled up to lower edge of oil filler hole.

1. Let excessive gear oil drain or top up gear oil --> «Gear oil in front final drive, filling up after servicing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Note. Replace locking screw with seal.

1. When the oil level is correct, tighten locking bolt using hex ball socket 3247 (8mm socket) to 30 Nm.

Gear oil in front final drive, filling up after servicing

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

1. Plug insert 3247 (8mm)

Procedure

1. Drive vehicle onto a 4-column lift or over a work pit.

Note. The vehicle must be on a level surface.

1. Place drip tray VAG1306 underneath.

1. Remove locking screw (arrow).

Note. Loosen locking bolt using an angled socket-head wrench, but do not use hex ball socket 3247. For improved accessibility it may be necessary to remove the heat shield and drive axle and to set them aside. If hex ball socket 3247 is used for loosening the bolt, it could be destroyed.

1. Slowly and uniformly fill front final drive over a time period of at least 5 minutes until gear oil escapes at lower edge of oil filler hole.

1. Specification --> «Capacity»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

Note. Filling time of at least 5 minutes is essential, so that the internal oil level compensation between differential and retaining area can occur.

1. Screw in old locking screw (arrow).
2. Perform a short test drive to warm gear oil to approx. 60 ° C.
3. Check front final drive oil level --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .

Note. Replace locking screw with seal.

1. When the oil level is correct, tighten locking bolt using hex ball socket 3247 (8 mm socket) to 30 Nm.

Front final drive, servicing

1. Transmission installed

Note. General repair notes --> Servicing notes . Rules of cleanliness for working on automatic transmissions --> Rules of cleanliness for working on automatic transmissions .

Scheme 972

1 - Seal

1. Between final drive and transmission housing
2. Always replace --> «Final drive sealing ring/transmission housing, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

2 - Adjustment shim

1. Behind tapered roller bearing outer race

3 - Tapered roller bearing outer race

4 - Locking screw - 30 Nm

1. With seal
2. Always replace

5 - Bolt - 23 Nm

6 - Right drive flange

7 - Right drive flange seal

1. Always replace --> «Sealing ring for right drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

8 - Bolt - 23 Nm

1. Observe tightening sequence

9 - Cover for final drive

10 - Adjustment shim

1. Behind tapered roller bearing outer race

11 - Tapered roller bearing outer race

12 - O-ring

1. Always replace --> «O-ring at cover for final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__o-ring-at-cover-for-final-drive)

13 - Differential

14 - Bolt - 23 Nm

1. Observe tightening sequence «Tightening sequence»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__tightening-sequence)

15 - Cover for front final drive

1. Front wheel drive version shown

16 - Bushing

17 - Gasket

1. Always replace --> «Seal for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__seal-for-front-final-drive-replacing)

18 - Spring dowel sleeve

19 - Lever

1. For shift rod

20 - Seal

1. For shift rod
2. Always replace --> «Shift rod seal, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__shift-rod-seal-replacing)

21 - Bolt - 23 Nm

22 - Left drive flange seal

1. Always replace --> «Sealing ring and grooved ball bearing for left drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

23 - Drive gear

1. For speedometer Vehicle Speed Sensor (VSS) G22
2. Installation position --> (Scheme 988)

24 - Left drive flange

1. Removing and installing --> «Sealing ring and grooved ball bearing for left drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) onward

25 - Mounting bracket for drive flange

26 - Grooved ball bearing for drive flange

1. Always replace --> «Sealing ring and grooved ball bearing for left drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

27 - Snap ring

28 - O-ring

1. Square cross section
2. Remove and install left drive flange to replace --> «Sealing ring and grooved ball bearing for left drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

Scheme 973

Special tools, testers and auxiliary items required

1. Extractor lever VW681
2. Right sealing ring installer 3382
3. Drip tray VAG1306

1. «SUSPENSION, WHEELS, STEERING»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

Scheme 974

1. Loosen bolt drive axle/wheel hub while the vehicle is still standing on its wheels. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Remove wheel.

1. Remove heat shield for right drive axle (arrows).

Third bolt is not visible in the illustration.

1. Unbolt right drive axle - 1 - from transmission flange and remove. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

Scheme 975

1. Remove bolt for flange shaft (arrow) while securing against turning using a drift.
2. Place drip tray VAG1306 underneath.
3. Remove right drive flange.

Scheme 976

1. Pull out drive flange seal.

1. Coat outer edge of oil seal with gear oil.

Scheme 977

1. Drive in new seal to stop, without canting seal.

1. Installation position: The open side of the sealing ring faces the transmission.

1. Fill area between sealing lip and dust lip halfway with sealing grease G 052 128 A1.
2. Install right drive flange.

1. Install bolt for drive flange (arrow, 23 Nm) while securing drive flange against turning, using a drift.

1. Install right drive axle - 1 -. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Install heat shield for right drive axle (arrows).

Third bolt is not visible in the illustration.

1. Install front wheel. --> «44 - WHEELS, TIRES, VEHICLE ALIGNMENT»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Check oil level in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .

Scheme 978

Special tools, testers and auxiliary items required

1. Thrust plate VW401
2. Thrust plate VW402
3. Punch VW407
4. Punch VW412

1. Extractor lever VW681
2. Driving sleeve 32-109

Scheme 979

Special tools, testers and auxiliary items required

1. Press tube 2040
2. Assembly mandrel 3384
3. Drip tray VAG1306
4. Oil siphoning unit VAG1358A

1. «SUSPENSION, WHEELS, STEERING»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

Remove left drive flange

1. Loosen bolt drive axle/wheel hub while the vehicle is still standing on its wheels. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Remove wheel.

1. Remove heat shield for left drive axle (arrows), if installed.

Third bolt is not visible in the illustration.

1. Unbolt left drive axle - 1 - from transmission flange and remove. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Place drip tray VAG1306 underneath.

Scheme 980

1. Remove oil filler plug (arrow) and siphon off at least 0.5 L gear oil from front final drive using oil siphoning unit VAG1358A

Note. Oil must be siphoned from final drive, otherwise there is a risk that the gear oil could mix with the ATF.

1. Remove Speedometer Vehicle Speed Sensor (VSS) --> «Speedometer Vehicle Speed Sensor (VSS) G22 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Remove harness connector bracket from mounting bracket for drive flange.

Scheme 981

1. Remove drive flange mounting bracket (arrows).
2. Pull out drive flange.

Note. The left drive flange can be pulled out between body and subframe with the transmission installed if the mounting bracket for drive flange is turned approx. 60 ° to the right against the installation position.

Scheme 982

1. Remove circlip (arrow A) for grooved ball bearing.

Scheme 983

1. Press drive flange out of drive flange mounting bracket.
2. Remove drive flange seal using extractor lever VW681.

Scheme 984

1. Press grooved ball bearing out of mounting bracket.

Scheme 985

1. Press new grooved ball bearing into mounting bracket.

Installing sealing ring

1. Coat outer edge and sealing lip of oil seal with gear oil.

Scheme 986

1. Drive in new sealing ring to stop, without canting.

1. Installation position: The open side of the sealing ring faces the transmission.

1. Fill area between sealing lip and dust lip halfway with sealing grease G 052 128 A1.

Scheme 987

1. Set drive gear for Speedometer Vehicle Speed Sensor (VSS) G22 on drive flange (arrow).

1. Installation position: The carriers at drive wheel must engage in grooves of drive flange

Note. If necessary, coat contact surface with grease to affix drive wheel in installation position.

Scheme 988

1. Press mounting bracket with grooved ball bearing onto drive flange.

1. Insert circlip (arrow - A - ).

Installing left drive flange

1. Replace sealing ring (arrow B) in mounting bracket for drive flange.

Scheme 989

1. Check drive flange for sharp edges on transmission side of flange end (arrow) and if necessary, deburr.
2. Insert left drive flange into transmission.

Note. When sliding in, left drive flange must be carefully guided by hand to prevent damage to the double sealing ring in transmission.

1. Secure mounting bracket for drive flange.
2. Bolt on harness connector bracket to mounting bracket for drive flange.
3. Install speedometer Vehicle Speed Sensor (VSS) G22 --> «Speedometer Vehicle Speed Sensor (VSS) G22 , removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Install left drive axle - 1 -. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Install heat shield for left drive axle (arrows).

Third bolt is not visible in the illustration.

1. Install left front wheel. --> «44 - WHEELS, TIRES, VEHICLE ALIGNMENT»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Check oil level in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .

O-ring at cover for final drive, replacing

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

1. «SUSPENSION, WHEELS, STEERING»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)

1. Loosen bolt drive axle/wheel hub while the vehicle is still standing on its wheels. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
2. Remove right wheel.
3. Remove heat shield for right drive axle.
4. Remove right drive axle: --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

1. Remove right front exhaust pipe. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
2. Remove right transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Remove bolt for flange shaft (arrow) while securing against turning using a drift.
2. Place drip tray VAG1306 underneath.
3. Remove right drive flange.

Scheme 990

1. Remove bolts for final drive cover opposite of shown tightening sequence and remove cover.

Scheme 991

1. Replace sealing ring (arrow).

1. Install cover for final drive.

Tightening sequence

1. 1. Stage: Tighten bolts - 1 - to - 3 - by hand
2. 2. Stage: Tighten bolts - 1 - to - 12 - in specified sequence to tightening torque

1. Install right drive flange.
2. Install transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Install right front exhaust pipe. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
4. Install drive axle. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)

1. Top-up and check gear oil in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .

Scheme 992

Special tools, testers and auxiliary items required

1. Extractor lever VW681
2. Double sealing ring installer 3383
3. Drip tray VAG1306
4. Oil siphoning unit VAG1358A

Note. A faulty sealing ring lets ATF or gear oil escape into the converter housing via the center vent of the shaft seal (between the two sealing lips). In addition, a faulty sealing ring can let ATF escape into the center differential. It over-fills and oil escapes at the differential vent.

1. Remove cover for front final drive --> «O-ring at cover for final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__o-ring-at-cover-for-final-drive) .
2. Pull out differential and remove.

Scheme 993

1. Remove tapered roller bearing outer race of differential - 1 - and shim - 2 - which is behind it from transmission housing by hand.

Note. Shim is pre-determined and must not be exchanged for a shim with another thickness.

1. Remove left drive flange --> «Sealing ring and grooved ball bearing for left drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 994

1. Pull out seal.

Note. Extractor lever must be positioned behind both sealing lips of the sealing ring. Do not position at outer circumference of sealing ring, otherwise the contact surface in transmission housing will be damaged. When levering out, carefully guide extractor lever.

1. Check seal seat in transmission housing for damage; rework if necessary.
2. Coat outer circumference and sealing lip of sealing ring with ATF.

Scheme 995

1. Slide seal onto double sealing ring installer 3383 so that the projecting sealing lip (arrow) of sealing ring faces tool.

Scheme 996

1. Drive in new sealing ring to stop.
2. Install left drive flange --> «Sealing ring and grooved ball bearing for left drive flange, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

1. Insert adjustment shim - 2 - and tapered roller bearing outer race for differential - 1 - into transmission housing up to stop by hand.
2. Insert differential into transmission housing.
3. Install cover for front final drive.
4. Install right drive flange.

1. Install transmission support --> «Right and left transmission mounts, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Install right front exhaust pipe. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
3. Install drive axle. --> «40 - FRONT SUSPENSION»(/audi/a4/b6-2000-2006/remont/axle-shafts/#suspension-wheels-steering)
4. Top-up and check gear oil in front final drive --> «Gear oil in front final drive, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__gear-oil-in-front-final-drive) .

Seal for front final drive, replacing

Special tools, testers and auxiliary items required

Scheme 997

1. Engine/transmission jack VAG1383 with plate VAG1359/2

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)

1. Remove front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
2. Remove heat shield for selector lever cable, if installed.
3. Remove center differential --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing) .

Scheme 998

1. Remove bolts (arrows) at intermediate flange for front final drive.

1. Lift off cover i.e. intermediate flange for front final drive.

Note. Do not remove spur gears for front final drive. Secure spur gears so they do not fall out. If the spur gears for front final drive were removed, the wheel marking must face outward (away from transmission) for re installation.

Installation is reverse of removal, noting the following

Scheme 999

1. Make sure centering sleeve - A - is correctly seated before installing.
2. Install gasket
3. Set on cover i.e. intermediate flange for front final drive.

Note. If installing the intermediate flange to the output shaft carelessly, the sealing lips of the sealing ring can be damaged.

Tightening sequence

1. 1. Stage: Tighten bolts - 1 - to - 3 - by hand

Note. When tightening bolts by hand, make sure the housing gap between cover and transmission housing decreases evenly around circumference. 2. Stage: Tighten bolts - 1 - to - 14 - in specified sequence to tightening torque

1. Check ATF level and top off --> «ATF level, checking»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) onward.
2. Install center differential.

Gear oil in center differential, checking and topping off

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

Additional information

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)

Procedure

1. Drive vehicle onto a 4-column lift or over a work pit.

Note. The vehicle must be on a level surface.

Scheme 1000

1. If necessary, loosen or remove relevant parts of the exhaust system to gain access to oil filler plug (arrow B). --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
2. Place drip tray VAG1306 underneath.
3. Remove oil filler plug (arrow B).

Oil level is correct when the final drive is filled up to lower edge of oil filler hole.

1. Let excessive gear oil drain or top up gear oil --> «Gear oil in center differential, changing or topping up after repair»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
2. Always replace oil filler plug.
3. Thread in new oil filler plug and tighten to 35 Nm.
4. Secure or reinstall exhaust system free of stress. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Gear oil in center differential, changing or topping up after repair

Special tools, testers and auxiliary items required

1. Drip tray VAG1306

Additional information

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)

Procedure

1. Drive vehicle onto a 4-column lift or over a work pit.

Note. The vehicle must be on a level surface.

Drain gear oil

1. Place drip tray VAG1306 underneath.

1. Removing drain plug (arrow A) and draining gear oil.
2. Always replace drain plug.
3. Thread in new drain plug (arrow A) again and tighten to 20 Nm.

Filling up gear oil

1. If necessary, loosen or remove relevant parts of the exhaust system to gain access to oil filler plug (arrow B). --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Note. There is a distinction made between two cases: A - Center differential was not removed. B - Center differential was removed

A - Center differential was not removed (e.g. after removing and installing drive flange/drive shaft)

1. Remove oil filler plug (arrow B).
2. Top up transmission fluid to lower edge of oil filler hole. Specification and capacity «Center differential»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .
3. Thread in old oil filler plug and tighten to 35 Nm.

Note. If it was necessary to loosen or remove the exhaust system, this must be re-secured or reinstalled for the road test. It must be removed and installed again for the final oil level check.

1. Road test vehicle (15 minutes pure driving).

Note. During road test, gear oil enters output cover and Torsen differential; oil level in center differential housing will drop.

1. Fill transfer housing with gear oil and check oil level --> «Gear oil in center differential, checking and topping off»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

B - Center differential was removed and disassembled

1. Add 200 ml. gear oil to output cover.
2. Center differential, assembling and installing.

1. Remove oil filler plug (arrow B).
2. Add 600 ml. gear oil to center differential housing.
3. Always replace oil filler plug.
4. Thread in new oil filler plug and tighten to 35 Nm.

Note. Oil level does not need to be re-checked.

All

1. Secure or re-install exhaust system free of stress. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

Center differential, servicing

Transmission installed

Scheme 1001

Special tools, testers and auxiliary items required

1. Thrust plate VW401
2. Punch VW412
3. Thrust plate VW402
4. Thrust tube VW454

1. Punch VW407
2. Sleeve 3021

Special tools, testers and auxiliary items required

1. Sleeve 40-20
2. Press support 3118
3. Item 3 Kukko 17/2 separating tool

Note. Rules of cleanliness for working on automatic transmissions --> Rules of cleanliness for working on automatic transmissions . General repair notes --> Servicing notes .

The parts listed in the following illustration can be removed with the transmission installed.

Scheme 1002

1 - Socket head bolt- 25 Nm

2 - Output flange/driveshaft

3 - Seal

1. Always replace --> «O-ring for output flange/driveshaft, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__o-ring-for-output-flangedriveshaft-replacing)

4 - Bolt - 23 Nm

1. 4x

5 - Housing cover

1. With dampener

6 - O-ring

1. Coat with transmission fluid

7 - Snap ring

8 - Grooved ball bearing

1. Pressing off «Press off grooved ball bearing for spur gear 1»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. Pressing on «Press on grooved ball bearing for spur gear 1»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

9 - Spur gear 1

1. For rear gear set

10 - Snap ring

11 - Needle bearing

1. Only remove for replacement
2. To replace, heat up transfer gear housing to approx. 100 ° C and drive out needle bearing toward rear using drift (Warning! Wear protective gloves)
3. Drive in to stop using 30-21 sleeve

12 - Bolt - 23 Nm

1. Loosen or tighten in stages and in diagonal sequence

13 - Center differential housing

14 - Tension nut

15 - Needle bearing

1. Only remove for replacement
2. Always replace --> «Needle bearing for spur gear 2, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

16 - Snap ring

17 - Spur gear 2

1. For rear gear set

18 - Grooved ball bearing

1. Pressing off «Press off grooved ball bearing for spur gear 2»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)
2. Pressing on «Press on grooved ball bearing for spur gear 2»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v)

19 - Snap ring

20 - Washer

21 - Alignment plate

22 - Bolt - 10 Nm

23 - Snap ring

24 - Gasket

1. Always replace --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing)

25 - Torsen differential

1. If damaged replace as complete unit
2. Removing and installing --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing)

26 - Seal

1. Always replace --> «Sealing ring in intermediate flange for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__sealing-ring-in-intermediate-flange-for)

27 - Magnet

1. Removing and installing --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing)

28 - Bushing

1. 2x

29 - Breather

1. For transfer gear
2. With cap installed
3. Installation position: Without cover, breather must project 10 - 11 mm out of housing

30 - Bolt - 23 Nm

1. Observe tightening sequence «Tightening sequence»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__tightening-sequence)

31 - Intermediate flange for front final drive

32 - Gasket

1. Always replace --> «Seal for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__seal-for-front-final-drive-replacing)

33 - Bushing

34 - Drive pinion

1. For front final drive
2. Removing and installing --> «Sealing ring in drive pinion, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__sealing-ring-in-drive-pinion-replacing)

35 - Intermediate pinion

1. For front final drive
2. Installation position: gear identification faces toward transfer gear

36 - Output pinion

1. For front final drive
2. Installation position: gear identification faces toward transfer gear

37 - Seal

1. Always replace --> «Sealing ring in drive pinion, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__sealing-ring-in-drive-pinion-replacing)

Scheme 1003

A - Separating device 22-115 mm, e.g. Kukko 17/2 separating tool

Scheme 1004

Scheme 1005

A - Separating device 22-115 mm, e.g. Kukko 17/2 separating tool

Scheme 1006

Center differential, removing and installing

(Transmission installed)

Special tools, testers and auxiliary items required

1. Engine/transmission lifter VAG1383A with universal transmission holder VAG1359/2

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)
2. «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Remove front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

1. Remove heat shield for driveshaft from cover for Torsen differential (arrows).

Scheme 1007

1. Unbolt driveshaft - 1 - from transmission and let rest on heat shield - 2 - --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
2. Secure driveshaft using wire (arrow) to bracket - 3 - of fuel lines or support driveshaft using engine/transmission hoist VAG1383A.
3. Drain center differential gear oil --> «Gear oil in center differential, changing or topping up after repair»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 1008

1. Loosen mounting bolts - A - and - C - for transfer housing - 2 - in diagonal sequence and remove.
2. Do not remove bolts - B -.

Scheme 1009

1. Pull Torsen differential off output shaft toward rear.

Installation is reverse of removal, noting the following

Scheme 1010

1. Check for presence of dowel sleeves (arrows - A - and - B - ).
2. Install gasket

Note. Lightly coat sealing surface -D- with gear oil to prevent the seal from slipping.

1. Slide cleaned magnets into cast holding pocket - 1 - in intermediate flange.
2. Add 200 ml. gear oil to output housing (comparable to gear oil, topping up on removed and disassembled center differential).

1. Install Torsen differential onto splines of output shaft and bottom spur gear while turning slowly.
2. Check whether installed Torsen differential can be turned by hand.

1. Install fully assembled transfer housing with installed spur gears and drive flange/drive shaft onto transmission flange.
2. Insert bolts - A - and - C - for transfer housing - 2 - and tighten to final tightening torque in diagonal sequence in several stages.
3. Bolt driveshaft to output flange/driveshaft --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
4. Install front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

1. Fill transfer housing with gear oil and check oil level --> «Gear oil in center differential, changing or topping up after repair»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

O-ring for output flange/driveshaft, replacing

(Transmission installed)

Special tools, testers and auxiliary items required

Scheme 1011

1. Pressure piece 3402

1. Engine/transmission lifter VAG1383A with Universal transmission holder VAG1359/2

1. «1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) «2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT»(ref-278881) «3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) «3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH»(ref-278883) «4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS»(ref-278885) «4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF»(ref-278884)
2. «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Remove front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF

1. Remove heat shield for driveshaft from cover for Torsen differential (arrows).

1. Unbolt driveshaft - 1 - from transmission and let rest on heat shield - 2 - --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR
2. Secure driveshaft using wire (arrow) to bracket - 3 - of fuel lines or support driveshaft using engine/transmission hoist VAG1383A.
3. Drain center differential gear oil --> «Gear oil in center differential, changing or topping up after repair»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Scheme 1012

1. Unbolt output flange driveshaft while securing output flange/driveshaft against turning using a drift.
2. Pull out output flange/driveshaft.

Scheme 1013

1. Remove O-ring using appropriate screwdriver.

Installation is reverse of removal, noting the following

1. Coat outer edge and sealing lip of oil seal with gear oil.

Scheme 1014

1. Drive O-ring in to stop using pressure piece 3402.
2. Fill area between sealing lip and dust lip halfway with sealing grease G 052 128 A1.
3. Secure output flange/driveshaft with socket-head bolt.
4. Bolt driveshaft to output flange/driveshaft --> «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

1. Install front exhaust system with catalytic converter. --> «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/blowers-superchargers-turbochargers/#18l-4-cyl-5v-turbo-engine-mechanical-engine-codes-amb) for 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278881-S12387190922008020700000) for 2.0 LITER 4-CYL. 4V TURBO ENGINE MECHANICAL, ENGINE CODE(S): BPG, BWT «26 EXHAUST SYSTEM, EMISSION CONTROLS»(/audi/a4/b6-2000-2006/remont/cooling-fan/#30l-6-cyl-5v-engine-mechanical-engine-codes-avk-bgn) for 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278883-S25168432662008020700000) for 3.2 V6 4V ENGINE MECHANICAL, ENGINE CODE(S): BKH «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278885-S34607538342008020700000) for 4.2 LITER V8 4V ENGINE MECHANICAL, ENGINE CODE(S): BNS «26 - EXHAUST SYSTEM, EMISSION CONTROLS»(ref-278884-S01497083522008020700000) for 4.2 LITER V8 5V ENGINE MECHANICAL, ENGINE CODE(S): BHF
2. Fill transfer housing with gear oil and check oil level --> «Gear oil in center differential, changing or topping up after repair»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v) .

Sealing ring in intermediate flange for front final drive, replacing

(Transmission installed)

Special tools, testers and auxiliary items required

Scheme 1015

1. Thrust piece 3404

Scheme 1016

Note. An inspection opening is provided on the left side of the intermediate flange to check for oil leaks (arrow) for the sealing ring in drive pinion and the sealing ring in intermediate flange. If oil escapes at this oil leak inspection opening, this double sealing ring must be replaced.

1. Remove center differential --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing) .
2. Removing intermediate flange for front final drive --> «Seal for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__seal-for-front-final-drive-replacing) .

Scheme 1017

1. Drive out sealing ring (arrow) in direction of transfer gear using a mandrel.

Installation is reverse of removal, noting the following

1. Check seal seat in intermediate flange for damage; rework if necessary.
2. Coat outer edge and sealing lip of oil seal with gear oil.

Scheme 1018

1. Slide sealing ring onto thrust piece 3404 so that the larger and projecting outer ring (arrow) of sealing ring faces tool.
2. Drive in sealing ring up to thrust piece 3404 stop.

Note. If installing the intermediate flange to the output shaft carelessly, the sealing lip of the sealing ring can be damaged.

1. Fill area between sealing lip and dust lip halfway with sealing grease G 052 128 A1.
2. Installing intermediate flange for front final drive --> «Seal for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__seal-for-front-final-drive-replacing) .
3. Install center differential.

Sealing ring in drive pinion, replacing

(Transmission installed)

Special tools, testers and auxiliary items required

Scheme 1019

1. Thrust piece 3403

Note. An inspection opening is provided on the left side of the intermediate flange to check for oil leaks (arrow) for the sealing ring in drive pinion and the sealing ring in intermediate flange. If oil escapes at this inspection opening, this sealing ring must be replaced.

1. Remove center differential --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing) .
2. Removing intermediate flange for front final drive --> «Seal for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__seal-for-front-final-drive-replacing) .

Scheme 1020

1. Remove intermediate pinion - 2 - for front final drive from transfer housing.
2. Pull drive pinion - 3 - from output shaft.

Output pinion - 1 - remains on the drive pinion.

1. Drive out sealing ring using drift.

Installation is reverse of removal, noting the following

1. Coat outer edge and sealing lip of oil seal with gear oil.

Scheme 1021

1. Slide sealing ring onto thrust piece 3403.
2. Drive sealing ring in up to thrust piece 3403 stop.

Contact surface - A - of thrust piece must lie against drive pinion - B -.

1. Fill area between sealing lip and dust lip halfway with sealing grease G 052 128 A1.

Scheme 1022

1. Completely cover splines on end of shaft (arrow) with insulating tape without creasing or overlapping the tape, to prevent damage to sealing ring when sliding on drive pinion.
2. Install drive pinion on center of output shaft. (Installation position )

Note. If installing the intermediate flange on the output shaft carelessly, the sealing lips of the sealing ring can be damaged.

1. Slide drive pinion - 3 - together with the intermediate pinion - 2 - into final drive housing up to stop (tapered roller bearing).

Observe installation position of spur gears (pinion)

Wheel identification (arrows) point outward, away from final drive.

1. Installing intermediate flange for front final drive --> «Seal for front final drive, replacing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__seal-for-front-final-drive-replacing) .
2. Install center differential.

Scheme 1023

Special tools, testers and auxiliary items required

1. Thrust plate VW402
2. Punch VW408A
3. Press sleeve for sleeve 2080A
4. Item 1 Kukko 21/4 extractor

1. Item 3 Kukko 22/1 support
2. Hot air blower VAG1416

1. Remove center differential --> «Center differential, removing and installing»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#5-speed-automatic-transmission-01v__center-differential-removing-and-installing) .

Scheme 1024

1. Unbolt rear output flange/driveshaft while securing output flange/driveshaft against turning.

Scheme 1025

1. Pull tension nut - A - out of spur gear shaft.
2. Remove bolts (arrows).
3. Remove guide plate - B - and shim - C -.
4. Remove securing ring for securing grooved ball bearing in center differential housing

Scheme 1026

1. Attach support - A - at internal extractor - B - as shown and insert spur gear shaft - 2 -.

A - Support, e.g. 22/1 Kukko

B- extractor, e.g. 21/2 Kukko

1. Support retainer - A - using thrust plate VW402 and pre-tension at nut - 1 - of retainer.
2. Pull out spur gear and carefully remove upward.
3. Remove needle bearing securing ring.

Scheme 1027

Note. The upper part of the illustration shows how the pulling hooks of extractor - B - must be inserted into needle bearing.

1. Slide centering sleeve - 2 - of extractor - B - approx. 4 mm into direction of arrow in order to be able to open pulling hooks of extractor far enough.

A - Support, e.g. 22/1 Kukko

B- extractor, e.g. 21/2 Kukko

1. Spread extractor - B - into upper lip of needle bearing - 1 - and secure extractor at nut.
2. Install retainer - A - on extractor - B - as illustrated.
3. Support retainer - A - using thrust plate VW402 and pre-tension at nut - 3 - of retainer.
4. Using hot air blower, e.g. VAG141, quickly heat up outside of transfer housing in vicinity of needle bearing seat to approx. 80 to 100 ° C.

1. Quickly pull out needle bearing.

Installation is the reverse of removal. Also carry out the following procedure.

1. Check needle bearing seat in transfer housing for damage, rework if necessary.
2. Using hot air blower, e.g. VAG141, quickly heat up outside of transfer housing in vicinity of needle bearing seat to approx. 80 to 100 ° C.

Scheme 1028

1. Insert new needle bearing and set sleeve 2080A onto new needle bearing - 1 -.

Sleeve 2080A must be centered when set onto sleeve.

1. Drive needle bearing into transfer housing up to stop using punch VW408A.

Driveshaft, servicing

>

1. «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE
2. «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

Driveshaft, removing and installing

>

1. «39 FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive) for REAR FINAL DRIVE
2. «39 - FINAL DRIVE, DIFFERENTIAL»(/audi/a4/b6-2000-2006/remont/differentials-drive-axles/#rear-final-drive-0ar) for REAR FINAL DRIVE 0AR

See also:
• 00 GENERAL, TECHNICAL DATA
• 00 - GENERAL, TECHNICAL DATA
• 97 WIRING
• 20 - FUEL SUPPLY SYSTEM
• 46 - BRAKES - MECHANICAL COMPONENTS
• 91 - COMMUNICATION
• 91 RADIO, TELEPHONE, NAVIGATION, TRIP COMPUTER
• 68 - INTERIOR EQUIPMENT
• 68 - INTERIOR EQUIPMENT
• 1.8 LITER 4-CYL. 5V TURBO ENGINE MECHANICAL, ENGINE CODE(S): AMB
• 3.0 LITER 6-CYL. 5V ENGINE MECHANICAL, ENGINE CODE(S): AVK, BGN
• 87 AIR CONDITIONING
• 24 MULTIPORT FUEL INJECTION (MFI)
• 24 MULTIPORT FUEL INJECTION (MFI)
• 40 - FRONT SUSPENSION
• Code letters, allocation, ratios, equipment
• Gear oil in front final drive, checking
• Rules of cleanliness for working on automatic transmissions
• ATF lines and ATF cooler, cleaning
• Torque converter, installing
• Torque converter oil seal, replacing
• Valve body, removing and installing
• Transmission Vehicle Speed Sensor (VSS) G38 , removing and installing
• Tiptronic Switch F189 , removing and installing
• Locking cable, adjusting
• Selector lever cable, removing and installing
• Selector lever cable, checking and adjusting
• Ignition key removal lock, checking
• ATF lines, removing and installing (overview)
• All Wheel Drive (AWD)
• ATF lines, removing and installing, (vehicles with 4 cyl. engine)
• Oil pan, removing and installing
• Oil line inside transmission, removing and installing
• Shift rod seal, replacing
• ATF, changing or topping off after repairs
• O-ring at cover for final drive, replacing
• Tightening sequence
• Seal for front final drive, replacing
• Center differential, removing and installing
• O-ring for output flange/driveshaft, replacing
• Sealing ring in intermediate flange for front final drive, replacing
• Sealing ring in drive pinion, replacing
