Side window, adjusting Audi A4 B6

Body Exterior - Cabriolet 21 illustrations ~764 words

Side window, adjusting

Special tools, testers and auxiliary items required

Scheme 376

Scheme 376: Side window, adjusting
Scheme 376: Side window, adjusting
  1. Side Window Installation Tool V.A.G 1739

Distinctive features can be

  1. Low window tension.
  2. Wind noise.
  3. Window rattles with convertible top open.
  4. Window runs poorly into roof frame seal.

Scheme 377

Scheme 377
Scheme 377

Check window to see if it is parallel

  1. Close convertible top.
  1. Raise all windows.
  2. Close both doors.
  3. Using a steel ruler, measure gap dimension between door window and side window.
  1. Gap must be parallel, dimension - a - and dimension - b - = 9-10 mm.
  2. Deviation from parallel: 0.5 mm.

Scheme 378

Scheme 378
Scheme 378

Side window height and parallelism, adjusting

  1. Open convertible top.
  2. Remove side panel trim --> «70 - INTERIOR TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «70 - INTERIOR TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
  3. Remove rear seat bench --> «72 - SEAT - FRAMES»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «72 - SEAT - FRAMES»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
  4. Remove speaker cover and speaker.
  1. Raise all windows.
  2. Loosen nuts - arrows -.
  3. Adjust parallelism or side window height to door window by moving side window.
  4. Tighten nuts.

Scheme 379

Scheme 379
Scheme 379

Side window distance, checking

  1. Open convertible top.
  2. Raise side windows.
  3. Open both doors.
  4. Using a tape measure on inner edge of side windows - arrow - , measure distance of side windows to each other.
  1. Distance - a - = 1169 -1171 mm.

Note. Because this measurement cannot determine symmetry to both windows, the window that is still noticeable after all pre-adjustments is adjusted in case of a deviation from the dimension.

Scheme 380

Scheme 380
Scheme 380

Side window distance, adjusting

  1. Remove side panel trim --> «70 - INTERIOR TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «70 - INTERIOR TRIM»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
  2. Remove rear seat bench --> «72 - SEAT - FRAMES»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior) «72 - SEAT - FRAMES»(/audi/a4/b6-2000-2006/remont/gauges-instrument-panels/#body-interior-cabriolet) for BODY INTERIOR - CABRIOLET .
  3. Remove speaker cover and speaker.
  4. Loosen nut - arrow -.
  1. Adjust window angle with Side Window Installation Tool V.A.G 1739 «Angle, adjusting»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

Scheme 381

Scheme 381
Scheme 381

Note. The window regulator - 4 - can be adjusted in the respective - direction of arrow - by turning adjusting screw - 2 - in or out. Turning right: distance is increased. 1 turn corresponds to approx. 2 mm.

  1. Tighten nuts and bolts.

Tightening torques --> Side windows - assembly overview .

Scheme 382

Scheme 382: Component locations
Scheme 382: Component locations

1 - Front Passengers Door Control Module J387

  1. Installation location --> «Front Passengers Door Control Module J387»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

2 - Radar Interior Monitoring Control Module 2 G305

  1. Installation location --> «Radar Interior Monitoring Control Module 2 G305»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

3 - Right Rear Window Regulator Motor V27

  1. Installation location --> «Right Rear Window Regulator Motor V27»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

4 - Alarm Horn H12

  1. Installation location --> «Alarm Horn H12»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

5 - Motor for fuel tank lid unlock V155

  1. Installation location --> «Motor for fuel tank lid unlock V155»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

6 - Motor for rear lid release V139

  1. Installation location --> «Motor for rear lid release V139»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

7 - Left Rear Window Regulator Motor V26

  1. Installation location --> «Left Rear Window Regulator Motor V26»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

8 - Radar Interior Monitoring Control Module 1 G303

  1. Installation location --> «Radar Interior Monitoring Control Module 1 G303»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

9 - Driver s Door Control Module J386

  1. Installation location --> «Drivers Door Control Module J386»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

10 - Central control module for comfort system J393

  1. Installation location --> «Central control module for comfort system J393»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

11 - Front hood switch F266

  1. Installation location --> «Front hood switch F266»(/audi/a4/b6-2000-2006/remont/door-locks-anti-theft-systems/#body-exterior-cabriolet) .

Scheme 383

Scheme 383: Front Passengers Door Control Module J387
Scheme 383: Front Passengers Door Control Module J387
  1. Integrated in window regulator.

Scheme 384

Scheme 384: Radar Interior Monitoring Control Module 2 G305
Scheme 384: Radar Interior Monitoring Control Module 2 G305
  1. Between front seats in center console below parking brake lever handle recess.

Scheme 385

Scheme 385: Right Rear Window Regulator Motor V27
Scheme 385: Right Rear Window Regulator Motor V27
  1. Right rear behind side trim.

Scheme 386

Scheme 386: Alarm Horn H12
Scheme 386: Alarm Horn H12
  1. In convertible top compartment at right behind side trim.

Scheme 387

Scheme 387: Motor for fuel tank lid unlock V155
Scheme 387: Motor for fuel tank lid unlock V155
  1. In luggage compartment at right behind side trim.

Scheme 388

Scheme 388: Motor for rear lid release V139
Scheme 388: Motor for rear lid release V139
  1. in luggage compartment on rear lid lock.

Scheme 389

Scheme 389: Left Rear Window Regulator Motor V26
Scheme 389: Left Rear Window Regulator Motor V26
  1. Left rear behind side trim.

Scheme 390

Scheme 390: Radar Interior Monitoring Control Module 1 G303
Scheme 390: Radar Interior Monitoring Control Module 1 G303
  1. Below rear seat bench.

Scheme 391

Scheme 391: Drivers Door Control Module J386
Scheme 391: Drivers Door Control Module J386
  1. Integrated in window regulator.

Scheme 392

Scheme 392: Central control module for comfort system J393
Scheme 392: Central control module for comfort system J393
  1. On left front sill.

Scheme 393

Scheme 393: Front hood switch F266
Scheme 393: Front hood switch F266
  1. In lock carrier.

Scheme 394

Scheme 394: Fuel filler flap
Scheme 394: Fuel filler flap

5 - Tightening torque: 1.5 Nm

Scheme 395

Scheme 395: Fuel Tank Lid Unlock Motor V155, removing and installing
Scheme 395: Fuel Tank Lid Unlock Motor V155, removing and installing
  1. Motor for fuel tank lid unlock V155
  2. Locking pin
  3. Fuel filler flap

Scheme 396

Scheme 396
Scheme 396

Removing

  1. Disconnect electrical connector.
  2. Loosen bolts - arrows - using Socket Wrench T10010 , slide actuator - 1 - up and remove.

Installing

  1. Before installing actuator, emergency release - 2 - must be slid over the locking pin.
  2. Locking pin of actuator must move cleanly into closed fuel filler flap - 2 -.
  3. Clip in grommets - 1 -.

Note. To remove fuel filler flap, remove bolts - 5 -. Panel gap dimensions Panel gap dimensions .

Tightening torques --> Component locations .
