Engine compartment covers Audi A4 B6

Body Exterior - Cabriolet 1 illustration

Engine compartment covers

Model variations

Scheme 305

Scheme 305: Engine compartment covers
Scheme 305: Engine compartment covers

1 - Right engine compartment cover

2 - Toggle bolt

3 - Brake line bracket

4 - Left engine compartment cover

5 - Ball stud

6 - Coolant reservoir

7 - Grommet

8 - Bolt

  1. 3 Nm

9 - Bolt

  1. 9 Nm

10 - Grommet
