Seat Frames: Other Audi A3 8P facelift

FRONT SEAT, INSTALLING ON FIXTURE FOR SEAT REPAIR VAS 6136

Special tools and workshop equipment required

Scheme 30

Scheme 31

1. Engine And Transmission Holder VAS 6095
2. Fixture for Seat Repair VAS 6136

1. Front seat removed from the vehicle.

Mount the VAS 6136 on the VAS 6095.

Attach the seat to the VAS 6136.

CONNECTORS, DISCONNECTING AND CONNECTING

Disconnecting

Scheme 32

Disconnect the battery ground wire with the ignition off. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Release cover cap -1- in -direction of arrow-.

Remove the wiring bracket -3- upward from the connector station.

Scheme 33

Note. The number of connectors may vary depending on equipment.

Disconnect seat operating electrical connector -2-.

Release clip in -direction of arrow- with a small screwdriver and disconnect side airbag electrical connector -1-.

Connect the VAS 6235 to the side airbag electrical connector on the seat. Refer to AIRBAG ADAPTER, CONNECTING .

Note. Ensure airbag adapter engages correctly.

Connectors, connecting

The electrical connectors are connected in the following sequence, note the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

AIRBAG ADAPTER, CONNECTING

Special tools and workshop equipment required

Scheme 34

1. Airbag Adapter VAS 6235

Airbag connector, disconnecting

Disconnect the battery ground wire with the ignition off. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Connect the airbag connector -3- to the airbag adapter connector -4-.

Scheme 35

If equipped, connect voltage supply connector for airbag adapter -2- to voltage supply connector for seat connector -2-.

Note. Ensure airbag adapter engages correctly.

Airbag connector, connecting

Airbag connectors are connected in the following sequence, note the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Scheme 36

1. Backrest Adjusting Wheel Removing and Installing, refer to «BACKREST ADJUSTING WHEEL»(ref-496057-S40051701552012082100000)
2. Sill Side Trim Removing and Installing, refer to «SILL SIDE TRIM»(ref-496057-S20128003842012082100000)
3. Bolt 3.5 Nm
4. Spreader Clip
5. Tunnel Side Trim Removing and Installing, refer to «TUNNEL SIDE TRIM»(ref-496057-S05357237262012082100000)
6. Bolt 2 Nm
7. Bolt 3.5 Nm
8. Retaining Bracket For side trim, door sill side Removing and Installing, refer to «SILL SIDE TRIM RETAINING BRACKET»(ref-496057-S15357477112012082100000)
9. Seat Height Adjustment Handle Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(ref-496057-S18414418432012082100000)

Scheme 37

1. Seat Pan
2. Bolt Self-locking Replace 34 Nm Threaded holes for screws must always be cleaned (for example, with thread cutter)
3. Backrest Cover Removing and Installing, refer to «BACKREST COVER»(ref-496057-S03918534072012082100000)
4. Spring Clamp With hooks
5. Backrest Removing and Installing, refer to «BACKREST»(ref-496057-S38070773612012082100000)
6. Bolt Self-locking Replace 34 Nm Threaded holes for screws must always be cleaned (for example, with thread cutter)

Scheme 38

1. Lower Center Pull-spring Different number of coils
2. Upper Center Pull-spring Different number of coils
3. Upper Pull-spring Different number of coils
4. Right Clip For the spring mat
5. Right Spacer
6. Left Spacer
7. Backrest Frame
8. Left Clip For the spring mat
9. Spring Mat Removing and Installing, refer to «SPRING MAT»(ref-496057-S00688902332012082100000) Can be removed and installed with and without the pull-springs
10. Lower Pull-spring Different number of coils

Scheme 39

1. Four-way Lumbar Support With the lumbar support guide Removing and Installing, refer to «FOUR-WAY LUMBAR SUPPORT, VERSION 1»(ref-496057-S36229580612012082100000)
2. Lumbar Support Height Adjustment Motor Driver Seat Lumbar Support Height Adjustment Motor -V129- Passenger Seat Lumbar Support Height Adjustment Motor -V130- Cannot be replaced separately
3. Clip
4. Clip
5. Rivet Rivet with VAS 5072
6. Backrest Frame
7. Rivet Rivet using V.A.G 1753A
8. Rivet Rivet with VAS 5072
9. Plastic Washer Insert between four-way lumbar support and backrest frame
10. Lumbar Support Curvature Adjustment Motor Driver Seat Lumbar Support Curvature Adjustment Motor -V125- Passenger Seat Lumbar Support Curvature Adjustment Motor -V126- Cannot be replaced separately

Scheme 40

1. Backrest Padding
2. Four-way Lumbar Support Removing and Installing, refer to «FOUR-WAY LUMBAR SUPPORT, VERSION 2»(ref-496057-S27118485302012082100000)
3. Springs For attaching the four-way lumbar support in the backrest frame
4. Four-way Lumbar Support Frame Removing and Installing, refer to «FOUR-WAY LUMBAR SUPPORT, VERSION 2»(ref-496057-S27118485302012082100000)
5. Lumbar Support Curvature Adjustment Motor Driver Seat Lumbar Support Curvature Adjustment Motor -V125- Passenger Seat Lumbar Support Curvature Adjustment Motor -V126- Removing and Installing, refer to «LUMBAR SUPPORT ADJUSTMENT MOTOR, VERSION 2»(ref-496057-S39349515262012082100000)
6. Assembly Safety Guard For centering four-way lumbar support with frame
7. Rivet Rivet using V.A.G 1753 A
8. Plastic Washer Insert between four-way lumbar support and backrest frame
9. Lumbar Support Height Adjustment Motor Driver Seat Lumbar Support Height Adjustment Motor -V129- Passenger Seat Lumbar Support Height Adjustment Motor -V130- Removing and Installing, refer to «LUMBAR SUPPORT ADJUSTMENT MOTOR, VERSION 2»(ref-496057-S39349515262012082100000)
10. Fastening Strips On backrest cover

Scheme 41

1. Backrest Frame
2. Headrest Guide without Release Button Always installed on right side of backrest Removing and Installing, refer to «HEADREST GUIDE»(ref-496130-S29917127772012082100000)
3. Headrest Removing and Installing, refer to «HEADRESTS WITH LOCKING MECHANISM»(ref-496057-S42119695822012082100000)
4. Headrest Guide with Release Button Always installed on left side of backrest Removing and Installing, refer to «HEADREST GUIDE»(ref-496130-S29917127772012082100000)

CONNECTORS, DISCONNECTING

Loosen seat mounting bolts. Refer to SEAT .

Tip front seat back.

Release cover cap -1- in -direction of arrow-.

Remove wiring bracket -3-.

Release clip in -direction of arrow- with a small screwdriver and disconnect electrical connector -1- with side airbag terminal resistance.

Note. The terminal resistance for the side airbag is a component of the wiring harness.

Press in tab on connector for heated seat -2- on tunnel side and disconnect connector for heated seat.

Country versions of seat belt fasten sensor: Press the tab on the seat belt fasten sensor connector on the tunnel side and disconnect the seat belt fasten sensor connector.

Scheme 42

1. Backrest Lock Actuating Link Removing and Installing, refer to «BACKREST LOCK ACTUATING LINK»(ref-496057-S10112843602012082100000)
2. Actuating Link Adjuster Left
3. Bolt 2.5 Nm Insert with locking compound; locking compound
4. Left Release Lever Cover
5. Edge Protection
6. Bolt 2.5 Nm Insert with locking compound; locking compound
7. Right Release Lever Cover
8. Edge Protection
9. Right Backrest Lock Release Lever Removing and Installing, refer to «BACKREST LOCK ACTUATING LINK»(ref-496057-S10112843602012082100000)
10. Plastic Disc For release lever
11. Right Release Lever Mount
12. Left Release Lever Mount
13. Backrest Frame
14. Backrest Frame Mount
15. Bolt 22 Nm Insert with locking compound; locking compound.
16. Pop Rivet ø 6 mm (steel)
17. Plastic Washer for release lever
18. Left Backrest Lock Release Lever Removing and Installing, refer to «BACKREST LOCK ACTUATING LINK»(ref-496057-S10112843602012082100000)
19. Actuating Link Adjuster Right

Scheme 43

1. Backrest cover removed.

When operating one of the two backrest lock release levers, release pins on left and right of seat frame must be operated at the same time.

Operate backrest lock release lever

1. Left and right release pins must be operated at the same time.

Release backrest lock release lever

1. The actuating links must engage the release pins on the backrest hinge as far as stop.
2. The actuating links must then be relieved.

If necessary, rotate -arrows- adjusters -1 and 2- on actuating links accordingly.

Scheme 44

1. Right Mount
2. Right Latch Removing and Installing, refer to «LOCK»(ref-496057-S15361643182012082100000)
3. Center Bracket
4. Clamp
5. Cover
6. Bolt 15 Nm
7. Left Mount
8. Left Pivot Pin
9. Left Latch Removing and Installing, refer to «LOCK»(ref-496057-S15361643182012082100000)
10. Left 1/3 Backrest Removing and Installing, refer to «LEFT 1/3 OR RIGHT 2/3 BACKREST»(ref-496057-S12470658852012082100000)
11. 2/3 Right Backrest Without center armrest Removing and Installing, refer to «LEFT 1/3 OR RIGHT 2/3 BACKREST»(ref-496057-S12470658852012082100000)
12. Right Pivot Pin

Scheme 45

1. Cup Holder In the center armrest Removing and Installing, refer to «CUPHOLDER»(ref-496057-S42185389532012082100000)
2. Center Armrest Removing and Installing, refer to «CENTER ARMREST»(ref-496057-S31118807942012082100000)
3. Belt Latch
4. Mount For backrest
5. Bolt 55 Nm
6. Rear Three-Point Seat Belt
7. Backrest Latch Removing and Installing, refer to «LOCK»(ref-496057-S15361643182012082100000)
8. Bolt 12 Nm
9. Latch Trim For backrest latch Removing and Installing, refer to «LATCH TRIM»(ref-496057-S07835590852012082100000)
10. Headrest Guide
11. Headrest Guide With release button
12. Belt Webbing Guide For three-point seat belt Removing and Installing, refer to «SEAT BELT GUIDE»(ref-496057-S18683036292012082100000)
13. Cover Frame cannot be removed without destroying
14. 2/3 Right Backrest Removing and Installing, refer to «LEFT 1/3 OR RIGHT 2/3 BACKREST»(ref-496057-S12470658852012082100000)
15. Foam Wedge
16. Cover and Upholstery
17. Pass-through Removing and Installing, refer to «PASS-THROUGH»(ref-496057-S22345619192012082100000)
18. 10 Nm With plastic ring Cannot be replaced separately
19. Internal Upholstery For center armrest Removing and Installing, refer to «CENTER ARMREST INTERNAL UPHOLSTERY»(ref-496057-S22617263102012082100000)

FRONT SEAT, INSTALLING ON VAS 6136

Special tools and workshop equipment required

1. Engine and Transmission Holder VAS 6095
2. Fixture for Seat Repair VAS 6136

1. Front seat removed from the vehicle.

Mount the VAS 6136 on the VAS 6095.

Attach the seat to the VAS 6136.

FRONT MANUAL SEAT

Removing

Disconnect the battery ground wire with the ignition off. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Bring headrest into lowest lock position.

Pull the handle for the forward/back adjustment -2- and move the seat -4- all the way back.

Scheme 46

Remove the front screws -1- and -3-.

Pull the handle for the seat forward/back adjustment and move the seat all the way forward.

Remove the rear screws -5- and -6-.

Tip seat backward.

Disconnect the electrical connectors at the connector station in the floor. Refer to CONNECTORS, DISCONNECTING AND CONNECTING .

Connect the VAS 6235 to the side airbag electrical connector on the seat. Refer to AIRBAG ADAPTER, CONNECTING .

Raise the seat with a 2nd technician and remove it from the vehicle.

Installation

Installation is reverse of removal, but note the following

Remove VAS 6235 only after installing seat. Refer to AIRBAG ADAPTER, CONNECTING .

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Connect the connector to the couplings on the connector station in the floor. Refer to CONNECTORS, DISCONNECTING AND CONNECTING .

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SEAT RAIL COVERS

Removing

Remove the front seat bolts

1. Front seat (mechanically adjustable), refer to «FRONT MANUAL SEAT»(ref-496057-S35256894542012082100000)
2. Power front seat, refer to «POWER SEAT»(ref-496057-S40242894112012082100000)

Note. The electrical connectors for the front seat must not be loosened.

Front Seat Rail Cover

Scheme 47

Tilt the seat as far as possible to the back.

Carefully lift the securing clip -2- -arrow A-.

Remove the seat rail cover -3- from the seat rail guide -1- -arrow B-.

Rear Seat Rail Cover

Scheme 48

Tilt the seat as far as possible forward.

Carefully press the safety clip -1- down.

Remove the seat rail cover -3- from the seat rail guide -2- -arrow-.

Installation

To install, perform the steps used in removal in reverse order.

BACKREST ADJUSTING WHEEL

Special tools and workshop equipment required

Scheme 49

1. Assembly tool 3399

Removing

Scheme 50

Turn the backrest adjustment wheel -1- until a locking mechanism is visible from behind -arrow A-. It may be necessary to use a flashlight.

Hook in 3399 -item 2- and pry in -direction of arrow B-.

Turn backrest adjustment wheel -1- about 120° more.

Hook in 3399 -item 2- again and pry in -direction of arrow B-.

Remove backrest adjustment wheel -1-.

Installation

Installation is reverse of removal, but note the following

Hand wheel must be pressed on until it audibly engages.

Note. If the hand wheel for backrest adjustment sits loosely on the adjustment shaft, the hand wheel for backrest adjustment must be replaced.

SILL SIDE TRIM

Removing

Scheme 51

Remove backrest adjustment wheel. Refer to BACKREST ADJUSTING WHEEL .

Remove seat height adjustment handle. Refer to SEAT HEIGHT ADJUSTMENT HANDLE .

Open the storage compartment -1-.

Push the stop for the opening -3- to the side and move the storage compartment all the way down.

Disconnect the storage compartment pivot, while doing this, carefully push the bracket -2- slightly to the side -arrow A-.

Pull the storage compartment forward and out -arrow B-.

Remove the bolts -2- and -3- on the side trim on the door sill side.

Scheme 52

Note. Ignore -item 1- and the -arrows-.

Remove the backrest cover -1- on the trim -2- -arrow-.

Scheme 53

Remove expanding clip -1-, press clamping pin through to the inside.

Scheme 54

Open the clips -3- -arrow A-.

Remove the trim -2- -arrows B-.

If applicable, disconnect the lumbar support electrical connector.

Installation

To install, perform the steps used in removal in reverse order.

SILL SIDE TRIM RETAINING BRACKET

Removing

Disconnect the battery ground wire with the ignition off. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Remove front seat. Refer to FRONT MANUAL SEAT .

Remove the storage compartment bracket. Refer to STORAGE COMPARTMENT WITH BRACKET .

Remove side trim on sill side. Refer to SILL SIDE TRIM .

Remove bolts -1- and -2-.

Scheme 55

Remove retaining bracket -3-.

Installation

Installation is reverse of removal, but note the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

TUNNEL SIDE TRIM

Note. Removal and Installation can only be done with the seat removed.

Removing

Bring seat as far up as possible.

Disconnect the battery ground wire with the ignition switched off. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Remove front seat

1. Manual seat, refer to «FRONT MANUAL SEAT»(ref-496057-S35256894542012082100000)
2. Power seat, refer to «POWER SEAT»(ref-496057-S40242894112012082100000)

Secure the seat on the VAS 6136. Refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Move the seat rail all the way to the front so that the bolt for the seat belt latch is accessible.

If applicable, free up the electrical wire -2-.

Scheme 56

Remove bolt -arrow-.

Remove the seat belt latch -1-.

Note. The electrical wire remains connected.

Unclip backrest cover -4-.

Scheme 57

Remove expanding clip -3-, press clamping pin through to the inside.

Remove the bolt -2-.

Remove the trim -1- in -direction of arrow-.

Installation

Installation is reverse of removal, but note the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Install the seat belt latch.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again..

BACKREST COVER

Special tools and workshop equipment required

Scheme 58

1. Pry Lever 80 - 200

Removing

Scheme 59

Release the spring clamps for the backrest cover -1- using the 80 - 200 up to the first retainer -arrows A-.

Note. The spring clamps (with hooks) can be removed only up to the first retainer.

In order to remove the spring clamps (with hooks) -2-, push the backrest cover in -direction of arrow B-.

Pull the backrest cover -1- upward slightly and then swivel it to the rear -arrows-.

Scheme 60

1. When doing this, the guide tabs -2- and -3- are disconnected from the backrest frame.

Remove backrest cover.

Installation

Scheme 61

Installation is reverse of removal, but note the following

Note. Replace damaged spring clamps.

Guide the spring clamps (with hooks) -3- into the guides -1- on the backrest cover -2- in -direction of arrow-.

BACKREST

Special tools and workshop equipment required

Scheme 62

1. Airbag Adapter VAS 6281

Removing

Remove front seat. Refer to FRONT MANUAL SEAT .

Secure the seat on the VAS 6136. Refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Remove side trim on sill side. Refer to SILL SIDE TRIM .

Remove side trim on tunnel side. Refer to TUNNEL SIDE TRIM .

Remove backrest cover panel. Refer to BACKREST COVER .

Scheme 63

Disconnect the rubber strap -2- on the cloth strip -1- on the seat pan.

Disconnect the left and right rubber straps -1- and -2-.

Scheme 64

Where applicable, disconnect the electrical connector for the seat heating.

If applicable, connect the VAS 6281 -item 2- to the side airbag electrical connector -1-.

Scheme 65

Free up the electrical wiring harness on the seat pan.

Remove the left and right bolts -arrows-.

Scheme 66

Tip backrest -1- forward onto seat pan -2-.

Press the upholstery to the side and carefully remove the side airbag wire and, if necessary, all additional wires (depending on optional equipment) on the seat pan.

Remove backrest.

Installation

Installation is reverse of removal, but note the following

Threaded bolt holes -arrows- must always be cleaned (for example, with thread cutter).

Replace the bolts each time they are removed.

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

SPRING MAT

Note. Removal and installation is the same on the driver and passenger seat.

Removing

Remove front seat. Refer to FRONT MANUAL SEAT .

Secure the seat on the VAS 6136. Refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Remove backrest cover panel. Refer to BACKREST COVER .

Remove cover with upholstery. Refer to BACKREST COVER AND UPHOLSTERY .

Disengage the pull-springs -3- on the backrest frame -1-.

Scheme 67

Note. The pull-springs -3- can also stay engaged in the backrest frame -1- and the spring mat -2- can be disengaged directly at the pull-springs.

Remove the left and right spacers on the back side.

Scheme 68

Swivel the spring mat -1- upward -arrow-, when doing this, the spring mat will be pushed out of the clips -2-.

Remove the spring mat form the backrest frame -1-.

Installation

Make sure the correct pull-spring (number of coils) is engaged at the location determined.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

FOUR-WAY LUMBAR SUPPORT, VERSION 1

Note. Removal and installation is the same on the driver and passenger seat.

Special tools and workshop equipment required

Scheme 69

Scheme 70

1. Special Pop Rivet Pliers V.A.G 1753A
2. Pop Rivet Pliers VAS 5072
3. Drill
4. Drill bit ø 7 mm
5. Protective eyewear

Removing

Remove front seat

1. Manual seat, refer to «FRONT MANUAL SEAT»(ref-496057-S35256894542012082100000)
2. Power seat, refer to «POWER SEAT»(ref-496057-S40242894112012082100000)

Secure the seat on the VAS 6136, refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Remove backrest cover panel, refer to BACKREST COVER .

Remove cover with upholstery, refer to BACKREST COVER AND UPHOLSTERY .

Remove the rear rivet -2- on the backrest frame -1-.

Scheme 71

Remove the side rivets -6- on the backrest frame.

Scheme 72

Disconnect the bracket -3- for the four-way lumbar support -4- with the upper clips -2- from the backrest frame.

Disconnect the electrical connectors to the motors -1- and -5- for the lumbar support adjustment.

Remove the four-way lumbar support.

Installation

Before securing rivet -4-, a plastic washer -2- must be placed between four-way lumbar support -1- and backrest frame -3-.

Scheme 73

Further installation is performed in reverse sequence of removal, but observe the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on, refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

FOUR-WAY LUMBAR SUPPORT, VERSION 2

Special tools and workshop equipment required

1. Special Pop Rivet Pliers V.A.G 1753A
2. Drill
3. Drill bit ø 7 mm
4. Protective eyewear

Removing

Scheme 74

Remove backrest cover panel. Refer to BACKREST COVER .

Pry out peripheral fastening strips with a screwdriver.

Insert foil between upholstery and backrest frame to protect against metal particles.

Drill out rivet -1-.

Disconnect the frame for the upper left and right four-way lumbar support -5- on the springs -arrows-.

Disconnect the electrical connectors -2- and -6- on the motors for the lumbar support adjustment.

Disconnect Velcro connector between four-way lumber support -3- and backrest upholstery -4-.

Remove four-way lumbar support.

Installation

Scheme 75

Installation is performed in reverse order of removal, noting the following

Lay plastic film -1- over Velcro strips -2- on four-way lumbar support. Secure the plastic sheet on the four-way lumbar support.

Make sure the four-way lumbar support is attached to four-way lumbar support frame with assembly fastener -3- or a suitable pin.

Position lumbar support frame behind backrest and engage lumbar support frame at top left and right in mounts on frame.

Rivet the lower frame for the four-way lumbar support to the backrest frame.

Scheme 76

Before securing rivet -4-, a plastic washer -1- must be placed between four-way lumbar support -2- and backrest frame -3-.

Remove plastic film between backrest padding and four-way lumbar support.

Press four-way lumbar support Velcro fastener onto backrest padding to secure.

Connect electrical connectors to lumbar support adjustment motors.

HEADRESTS WITH LOCKING MECHANISM

Removing

Scheme 77

Push release button -2- in -direction of arrow A- and pull headrest -1- upward as far as possible -arrow B-, keep release button pushed while doing so.

Press release button -2- on headrest -1- until stop -arrow-.

Scheme 78

Slide headrest down completely on rods, release button on headrest must be kept pressed while doing so.

Remove headrest completely from headrest guides.

Installation

To install, perform the steps used in removal in reverse order.

SEAT PAN

Note. Removal and installation is the same on the driver and passenger seat.

Removing

Remove the seat. Refer to FRONT MANUAL SEAT .

Secure the seat on the VAS 6136. Refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Remove the backrest. Refer to BACKREST .

Remove cover with upholstery from seat pan. Refer to SEAT PAN COVER AND UPHOLSTERY .

Remove the seat height adjustment unit. Refer to SEAT HEIGHT ADJUSTMENT UNIT .

Installation

Install removed cover with upholstery in new seat pan.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

STORAGE COMPARTMENT WITH BRACKET

Removing

Remove the seat. Refer to FRONT MANUAL SEAT .

Secure the seat on the VAS 6136.

Open the storage compartment -1-.

Push the opening stop -3- to the side and open the storage compartment all the way.

Disconnect the storage compartment pivot, while doing this, carefully push the bracket -2- slightly to the side -arrow A-.

Pull the storage compartment forward and out -arrow B-.

Remove the bolts -2- and -3- on the side trim on the door sill side.

Remove the bolts -arrows- and the bracket -1-.

Installation

Installation is reverse of removal, but note the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

POWER SEAT

Removing

Bring headrest into lowest lock position.

Operate the seat forward/back adjustment and move the seat -4- all the way to the rear.

Remove the front screws -1- and -3-.

Operate seat fore and aft adjustment and guide seat as far forward as possible.

Remove the rear screws -5- and -6-.

Note. Ignore -2-.

Disconnect the battery ground wire with the ignition switched off. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Disconnect the electrical connectors at the connector station in the floor. Refer to CONNECTORS, DISCONNECTING AND CONNECTING .

Connect the VAS 6235 to the side airbag electrical connector on the seat. Refer to AIRBAG ADAPTER, CONNECTING .

Raise the seat with a 2nd technician and remove it from the vehicle.

Installation

Installation is reverse of removal, but note the following

Remove VAS 6235 only after installing seat. Refer to AIRBAG ADAPTER, CONNECTING .

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Connect the connector to the couplings on the connector station in the floor. Refer to CONNECTORS, DISCONNECTING AND CONNECTING .

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Removing and installing for the mechanically adjustable front seat. Removing and installing a power front seat is identical.

Note. The sill side trim panel can only be removed and installed with the seat installed. Removal and installation is the same on the driver and passenger seat.

Removing

Bring seat as far up as possible.

Remove the backrest cover -1- on the trim -2- -arrow-.

Remove expanding clip -3-, press clamping pin through to the inside.

Scheme 79

Open the clips -1- -arrow A-.

Pull the trim -2- as far up from the retaining bracket -arrows B-, as the electrical wires allow.

Disconnect the electrical connector -3- on the lumbar support adjustment switch -2-.

Scheme 80

Disconnect the electrical connectors -4- and -5- from the seat fore/aft, inclination, height and backrest adjustment switch housing -1-.

Remove the sill side trim.

Installation

Installation is reverse of removal, but note the following

Make sure the sill side trim is engaged correctly on retaining bracket and lock clips are closed.

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Removing

Scheme 81

Remove the sill side trim. Refer to SILL SIDE TRIM .

Disconnect the rubber cable -4- for the backrest cover.

Disconnect the cable ties -1-.

Remove the screws -2, 3 and 5-.

Remove the retaining bracket -6- for the sill side trim.

Installation

To install, perform the steps used in removal in reverse order.

Removing and installing for the mechanically adjustable front seat. Removing and installing a power front seat is identical.

Removing and installing for the mechanically adjustable front seat. Removing and installing a power front seat is identical.

Note. Removal and installation is described for the driver seat. Removing and installing the passenger seat is identical.

Special tools and workshop equipment required

1. Airbag Adapter VAS 6281

Removing

Remove front seat. Refer to POWER SEAT .

Secure the seat on the VAS 6136. Refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Remove side trim on sill side. Refer to SILL SIDE TRIM .

Remove side trim on tunnel side. Refer to TUNNEL SIDE TRIM .

Disconnect the rubber strap -2- on the cloth strip -1- on the seat pan.

Disconnect the left and right rubber straps -1- and -2-.

Where applicable, disconnect the electrical connector for the seat heating.

If applicable, connect the VAS 6281 -item 2- to the side airbag electrical connector -1-.

Free up the electrical wiring harness on the seat pan.

Remove the left and right bolts -arrows-.

Scheme 82

Remove the bracket -3- on the outer side of the backrest.

Tip backrest -2- forward onto seat pan -1-.

Press the upholstery to the side and carefully remove the side airbag wire and, if necessary, all additional wires (depending on optional equipment) on the seat pan.

Remove backrest.

Installation

Installation is reverse of removal, but note the following

Threaded bolt holes -arrows- must always be cleaned (for example, with thread cutter).

Replace the bolts each time they are removed.

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

The removing and installing is described for the mechanically adjustable front power seat. It is identical for the adjustable front power seat.

The removing and installing is described for the mechanically adjustable front power seat. It is identical for the adjustable front power seat.

SEAT HEIGHT ADJUSTER TOOTHED SEGMENT

Special tools and workshop equipment required

Scheme 83

1. Trim removal wedge 3409

Removing

Remove the seat height adjustment motor. Refer to SEAT HEIGHT ADJUSTMENT MOTOR .

Using 3409, unclip plastic toothed segment -2- from fitting -1-.

Installation

Clip plastic toothed segment -2- into fitting -1-.

Make sure the clip -arrow A- and plastic toothed segment collar and the locking pins -B arrows- are inserted correctly in the holes on the fitting -1-.

Make sure the plastic toothed segment is clipped to the fitting correctly.

1. The plastic toothed segment collar -arrow C- must lie evenly on the fitting.

Make sure the locking pins -A arrows- are inserted correctly in the holes -B arrows- on the link plate -1-.

Further installation is performed in reverse sequence of removal, but observe the following

Note. Ensure that electrical connections are pushed in as far as stop and engage with a click.

Disconnect the battery ground wire with the ignition switched on. Refer to [For engine(s) CBRA, BPY, CCTA, CBFA] Removal and Installation .

Note. If Airbag Malfunction Indicator Lamp (MIL) -K75- indicates a fault after installation, DTC memory must be checked, deleted and checked again.

Mounting the seat on the Fixture for Seat Repair VAS 6136 is described for the mechanically adjustable front seat.

Note. The S3 bucket seat does not have a side airbag. Therefore the electrical connector for the side airbag is provided in the vehicle wiring harness with a terminal resistance. The terminal resistance is a component of the wiring harness.

Scheme 84

1. Front Seat Removing -- Push front seat -1- fully upward and to the rear. -- Remove front bolts -3- (quantity: 2). -- Move seat forward. -- Remove rear bolts -4- (quantity: 2). -- Tip front seat -1- back. -- Disconnect electrical harness connectors. Refer to «CONNECTORS, DISCONNECTING»(ref-496057-S31525316932012082100000) . -- Remove seat. Installation To install, perform the steps used in removal in reverse order.
2. Seat Rail Covers Removing and Installing, refer to «SEAT RAIL COVERS»(ref-496057-S03781382262012082100000)
3. Front Bolts Quantity: 2 50 Nm
4. Rear Bolts Quantity: 2 50 Nm

Removing

Remove the seat, refer to SEAT .

Front Seat Rail Cover

Scheme 85

Carefully release retaining bracket in -direction of arrow A- and remove seat rail cover -1- -arrow B-.

Rear Seat Rail Cover

Scheme 86

Carefully release retaining tab -1-.

Then remove seat rail cover -2- in -direction of arrow-.

Installation

Seat rail cover must be removed until it audibly engages.

SIDE TRIM

Scheme 87

1. Bolt 1.2 Nm
2. Sill Side Trim Removing -- Remove the seat. Refer to «SEAT»(ref-496057-S28709605442012082100000) . -- Secure the seat on the VAS 6136. Refer to «FRONT SEAT, INSTALLING ON VAS 6136»(ref-496057-S16205627172012082100000) . -- Remove backrest adjustment hand wheel -5-. -- Remove seat height adjustment handle -7-. Refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(ref-496057-S37568993632012082100000) . -- Remove expanding clip -6-, press clamping pin through to the inside. -- Remove mounting bolt -1-. -- Remove side panel -2- at lower edge from retaining bracket on seat. -- Swing side panel upward at front edge. -- Remove side panel to side. -- Pull tab at rear of side panel out under backrest trim. Installation To install, perform the steps used in removal in reverse order.
3. Tunnel Side Trim Removing -- Remove the seat. Refer to «SEAT»(ref-496057-S28709605442012082100000) . -- Secure the seat on the VAS 6136. Refer to «FRONT SEAT, INSTALLING ON VAS 6136»(ref-496057-S16205627172012082100000) . -- Remove expanding clip -4-, press clamping pin through to the inside. -- Disengage retaining detent at rear side of side panel on tunnel side. -- Remove the trim. Installation To install, perform the steps used in removal in reverse order.
4. Spreader Clip
5. Hand Wheel for Backrest Adjustment Removing and Installing, refer to «BACKREST ADJUSTMENT HAND WHEEL»(ref-496057-S37632237522012082100000)
6. Spreader Clip
7. Seat Height Adjustment Handle Removing and Installing, refer to «SEAT HEIGHT ADJUSTMENT HANDLE»(ref-496057-S37568993632012082100000)

FRONT BACKREST AND SEAT PAN

Scheme 88

1. Bolt 24 Nm Insert with locking compound; locking compound.
2. Seat Forward/Back Adjustment Handle remove to remove from operating rod.
3. Bolt 24 Nm Insert with locking compound; locking compound
4. Electrical Wiring For seat heating
5. Seat Pan Removing -- Remove the seat. Refer to «SEAT»(ref-496057-S28709605442012082100000). -- Secure the seat on the VAS 6136. Refer to «FRONT SEAT, INSTALLING ON VAS 6136»(ref-496057-S16205627172012082100000). -- Remove side trim on sill side. Refer to «SIDE TRIM»(ref-496057-S39663278982012082100000). -- Remove side trim on tunnel side. Refer to «SIDE TRIM»(ref-496057-S39663278982012082100000). -- Disconnect seat heater connector. (Scheme 89) -- Drill out pop rivets on connector retaining plate using a ø 4.0 mm drill and guide seat heating wiring harness out under retaining plate (Scheme 89). -- Free up electrical wires on seat pan. -- Remove bolts -1, 3, 10-. -- Remove bolts -6 and 8- and set backrest aside behind seat pan. -- Remove seat pan. Installation Installation is reverse of removal, but note the following: -- Replace seat pan if threads are damaged or stripped. -- Insert the bolts with locking compound; locking compound.
6. Bolt 20 Nm Insert with locking compound; locking compound
7. Backrest Removing -- Remove the seat. Refer to «SEAT»(ref-496057-S28709605442012082100000). -- Secure the seat on the VAS 6136. Refer to «FRONT SEAT, INSTALLING ON VAS 6136»(ref-496057-S16205627172012082100000). -- Remove side trim on sill side. Refer to «SIDE TRIM»(ref-496057-S39663278982012082100000). -- Remove side trim on tunnel side. Refer to «SIDE TRIM»(ref-496057-S39663278982012082100000). -- Disconnect backrest heating electrical connector (Scheme 89). -- Drill out pop rivets on connector retaining plate using a ø 4.0 mm drill and guide backrest heating wiring harness out under retaining plate (Scheme 89). -- Remove bolts -1, 3, 10-. -- Remove bolts -6 and 8- and set backrest aside behind seat pan. -- Remove seat pan -5-. -- Remove backrest and guide electrical wiring harness out of seat frame. Installation Installation is reverse of removal, but note the following: -- Insert the bolts with locking compound; locking compound.
8. Bolt 20 Nm Insert with locking compound; locking compound
9. Electrical Wiring For backrest heating
10. Bolt 24 Nm Insert with locking compound; locking compound
11. Seat Frame

Scheme 89

Drill out pop rivets -arrows- using a ø 4.0 mm drill.

Disconnect electrical connectors

1. Seat heating connector.
2. Backrest heating connector.
3. Belt latch detection connector.

Special tools and workshop equipment required

1. Pry Lever 80 - 200

Scheme 90

1. Right Backrest Cover Removing and Installing (Scheme 91)
2. Left Backrest Cover Removing and Installing (Scheme 91)
3. Retaining Clip
4. Bolt 2.5 Nm
5. Outer Part of Belt Guide Removing and Installing (Scheme 92)
6. Inner Part of Belt Guide With release lever The version without the backrest release is shown in the illustration To remove, remove backrest cover. Refer to «BACKREST COVER AND UPHOLSTERY»(ref-496130-S28666320622012082100000) Disassembling. Refer to «BACKREST LOCK ACTUATING LINK»(ref-496057-S10112843602012082100000)
7. Backrest Frame

Scheme 91

Affix backrest panel all around trim -1- using adhesive tape -2-.

Using 80 - 200, pry off upper backrest cover at inner side, starting from backrest panel.

Disengage clip at front corner of backrest panel extremely carefully.

Scheme 92

Carefully guide 80 - 200 between backrest cover and outer part of belt guide.

Carefully press to disengage outer part of belt guide from inner part.

BACKREST LOCK ACTUATING LINK

Special tools and workshop equipment required

1. Pop Rivet Pliers VAS 5072
2. Drill
3. Drill bit ø 6.0 mm

Removing

Remove the seat. Refer to SEAT .

Secure the seat on the VAS 6136. Refer to FRONT SEAT, INSTALLING ON VAS 6136 .

Remove backrest and front seat pan. Refer to FRONT BACKREST AND SEAT PAN .

Remove backrest cover. Refer to BACKREST COVER AND UPHOLSTERY .

Remove bolts -arrows- on inner part of belt guide.

Scheme 93

Remove inner part of belt guide -1-.

Rotate inner part of belt guide and release retaining tabs -arrows-.

Scheme 94

Remove cover -1-.

Remove bracket -3- for backrest lock actuating link on inner part of belt guide.

Scheme 95

Remove backrest lock release lever -2-.

Disengage actuating link -1- in -direction of arrow-.

Repeat work steps on opposite side.

Remove backrest cover and backrest frame. Refer to BACKREST COVER .

Scheme 96

Remove screws -3 and 4-.

Drill out pop rivet -2- with a ø 6.0 mm drill in backrest frame mount -1-.

Tip backrest frame mount to side, remove actuating link bracket -2- at backrest frame mount -3-.

Scheme 97

Disengage actuating link eye -1- at backrest lock release lever -4- by sliding eye forward -arrow- and removing.

Remove actuating link upward from backrest frame.

Installation

Installation is reverse of removal, but note the following

Insert the bolts with locking compound; locking compound.

Adjust backrest lock actuating link. Refer to BACKREST LOCK ACTUATING LINK, ADJUSTING .

REAR BENCH SEAT

Removing

Scheme 98

Lift the rear bench seat -1- at the front and pull it forward.

Installation

Installation is in reverse order of removal, noting the following

Engage anchoring eyes -2- (quantity: 2) in plastic sleeves -3- (quantity: 2).

Push the rear bench seat -1- down.

Scheme 99

Remove used mounting from chassis cut-out.

Insert the new mounting grommet -2- into the body opening until it engages -1-.

LEFT 1/3 OR RIGHT 2/3 BACKREST

Removing

Scheme 100

Remove the luggage compartment floor covering.

Release clips -arrows- on cover cap.

Remove bolt -1- and remove securing bracket -2- in -direction of arrow-.

Scheme 101

Raise backrest out of center mount.

Remove backrest toward center of vehicle out of outer pivot pin.

Installation

To install, perform the steps used in removal in reverse order.

Tightening Specifications

CENTER ARMREST

Removing

Scheme 102

Fold up center armrest -1- to 2 / 3 .

Remove bolts -arrows-.

Remove center armrest on pass-through -2-.

Installation

Installation is reverse of removal, but note the following

Ensure plastic ring is on mounting bolt.

Tightening Specifications

CENTER ARMREST INTERNAL UPHOLSTERY

Removing

Scheme 103

Fold center armrest up.

Open pass-through -1-.

Remove bolts -arrows-.

Remove pass-through.

Release clips -A- and -B- on rear side of hinge -1- and pass-through -3-.

Scheme 104

Remove internal upholstery -2- in -direction of arrow-.

Installation

Scheme 105

Installation is reverse of removal, but note the following

Position internal upholstery -2- at top of pass-through.

Press internal upholstery on bottom side onto clips -3- on hinge -1- and pass-through -4-.

If the internal upholstery cannot be pressed on, carefully press in clips -3- with a screwdriver until upholstery engages in retainer.

Tightening Specifications

CUPHOLDER

Removing

Scheme 106

Fold center armrest up.

Open cupholder cover -2-.

Release retaining springs -1- and -3- and remove cupholder in -direction of arrow- from center armrest.

Installation

To install, perform the steps used in removal in reverse order.

PASS-THROUGH

Removing

Fold center armrest up.

Open pass-through -1-.

Remove bolts -arrows-.

Remove pass-through.

Installation

To install, perform the steps used in removal in reverse order.

Tightening Specifications

OUTER HEADRESTS

Removing

Scheme 107

Press button -2-.

Remove headrest -1-.

Installation

To install, perform the steps used in removal in reverse order.

CENTER HEADREST

Removing

Press button -1- and press in slit -arrow- with a small screwdriver at the same time. Press headrest up.

Scheme 108

Remove headrest -2-.

Installation

To install, perform the steps used in removal in reverse order.

LATCH TRIM

Removing

Scheme 109

Lift latch trim -2- off.

Installation

Installation is reverse of removal, but note the following

Note. After installing latch trim -2-, ensure red lever -1- moves easily.

LOCK

Removing

Remove backrest

1. Left 1/3 backrest, refer to «LEFT 1/3 AND RIGHT 2/3 BACKREST WITHOUT CENTER ARMREST COMPONENT OVERVIEW»(ref-496057-S11006744592012082100000) .
2. Right 2/3 backrest, refer to «LEFT 1/3 OR RIGHT 2/3 BACKREST»(ref-496057-S12470658852012082100000) .

Remove backrest cover and upholstery in latch area.

1. Left 1/3 backrest, refer to «COVER AND UPHOLSTERY FOR DIVIDED BACKREST, LEFT 1/3 BACKREST»(ref-496130-S20849404642012082100000) .
2. Right 2/3 backrest: vehicles without a center armrest, refer to «DIVIDED BACKREST COVER AND UPHOLSTERY, RIGHT 2/3 BACKREST WITHOUT CENTER ARMREST»(ref-496130-S40937360752012082100000) , vehicles with a center armrest, refer to «RIGHT 2/3 BACKREST COVER WITH CENTER ARMREST»(ref-496130-S41189021782012082100000) .

Remove bolts -2- (quantity: 2).

Scheme 110

Remove latch -1- in -direction of arrow-.

Installation

To install, perform the steps used in removal in reverse order.

Tightening Specifications

SEAT BELT GUIDE

Removing

Scheme 111

Remove seat belt guide -3- upward.

Thread belt webbing -2- through opening -1- out of seat belt guide -3-.

Installation

To install, perform the steps used in removal in reverse order.

LATCH BRACKET COVER CAPS

Removing

Scheme 112

Unclip cover caps -1- (quantity: 2) from LATCH brackets -2- (quantity: 2).

Installation

To install, perform the steps used in removal in reverse order.
