ENGINE OVERVIEW

Code letters		CBFA	CCTA	BPY
Displacement	L	1.984	1.984	1.984
Output	KW at 1/rpm	147/5100	147/5100	147/5700
Torque	Nm at rpm	280/1700	280/1700	280/2000
Bore	Dia. mm	82.5	82.5	82.5
Stroke	Mm	92.8	92.8	92.8
Compression ratio		10.5	10.5	10.5
RON		98 (1)	98 (1)	98 (1)
Fuel injection and ignition system		FSI			FSI
Ignition sequence		1-3-4-2	1-3-4-2	1-3-4-2
Knock sensor		Yes	Yes	Yes
Charging		Yes	Yes	Yes
Exhaust gas recirculation		No	No	No
Variable intake manifold		No	No	No
Variable valve timing		Yes	Yes	Yes
Secondary air injection (AIR)		No	No	No
(1) Unleaded RON 95 is also permissible, although with reduced power.
(1) 98 (2) 98 (3) Super unleaded RON 95 is permissible, although with reduced power.

(1)

(2)

(3)	Super unleaded RON 95 is permissible, although with reduced power.

Code Letters		BUB	CBRA
Displacement	Liter	3.189	3.189
Output	KW at RPM	184/6300	184/6300
Torque	Nm at RPM	320/2500 to 3000	320/2500 to 3000
Bore	Dia. mm	84	84
Stroke	Mm	95.9	95.9
Compression ratio		10.85	10.85
RON	At least
Fuel injection and ignition system		Motronic	Motronic
Ignition sequence		1-5-3-6-2-4	1-5-3-6-2-4
Emissions values		EU4	LEV2
Exhaust gas recirculation		No	No
Turbocharger, G-Charger		No	No
Oxygen sensor regulation		4 sensors	4 sensors
Variable valve timing		Yes	Yes
Variable intake manifold		Yes	Yes
Secondary Air Injection System		Yes	Yes
Valve per cylinder		4	4

Diesel Engine

Engine code		CBEA
Emissions category		ULEV II
Number of cylinders/valves per cylinder		4/4
Displacement	L	2.0
Output	KW at RPM	103/4200
Torque	Nm at RPM	320 1750...2500
Bore	Diameter mm	81.0
Stroke	Mm	95.5
Compression ratio		16.5 +/- 1
Fuel injection/Ignition		TDI CR
CZ	Minimum.	51
Diesel particulate filter		X

GENERAL INFORMATION

WARNING

Brake fluid must never come into contact with fluids containing mineral oils (oil, gas, cleaning solutions). Mineral oils damage brake system seals. Brake fluid is poisonous and must not be extracted by mouth using a hose under any circumstances. In addition, it must not come into contact with paint due to is corrosive effects. Brake fluid is hygroscopic, meaning that it absorbs moisture from the surrounding air, and must therefore always be stored in air-tight containers. Observe waste disposal regulations!

Note. If the air filter insert is heavily soiled or soaked, dirt particles or moisture can reach the mass airflow sensor -G70- and cause an incorrect airflow reading. This causes lack of performance because a lower injection amount is calculated. Always use an original air filter insert. Use a lubricant (silicone-free) when installing intake hose. Check drain hose in bottom side of air filter or dirt and adhesion (clean, if necessary). Secure all hose connections with hose clamps that match current standard production. Clean air filter housing (upper and lower parts) of salt residue, dirt or leaves (clean with vacuum, if necessary). Check mass airflow sensor and intake hose (clean air side) for salt residue, dirt and leaves. Check the intake canal up to the filter insert for dirt. When installing air filter insert, ensure it is centered in mount on bottom of air filter. Carefully and gently place upper part of air filter on lower part. When doing so, ensure upper part of air filter is not crooked on air filter insert. Pay attention to the seal lip on the air filter insert (air leak). Finally, screw upper part of air filter onto lower part.

WARNING

Oil extraction not permitted with various engine types! See maintenance table.

Note. Perform oil change at operating temperature.

Special tools and workshop equipment required
