HEADLAMPS, CHECKING ADJUSTMENT WITH NEW TEST SCREEN WITHOUT 15° SETTING LINE
Observe the following
Scheme 5
- With dipped beam switched on, horizontal light-dark border must contact hyphenated line -1- of test surface
- Break-away point -2- between left horizontal part and rising part on right of light-dark border must run vertically through central point -3-. Bright core of light beam must be right of vertical line
Note. To make it easier to find break-away point -2- cover and uncover left half of headlamp (as viewed when looking forward) a few times. Check the low beam one more time. After correct adjustment of dipped beams the center point of the main beam must lie on the center mark -3-. For the previous test screens with 15 ° setting line, adjust for new test screen. To avoid incorrect settings, ignore "15 ° setting line."
