Maintenance, Diagnosis - Maintenance Procedures: NVH Audi A3 8P facelift

ENGINE COMPARTMENT FRONT NOISE INSULATION COVER, REMOVING AND INSTALLING

Noise Insulation, Audi A3 Cabriolet, Removing and Installing ENGINE COMPARTMENT FRONT NOISE INSULATION COVER, REMOVING AND INSTALLING

Scheme 33

1. 1 - Noise insulation Remove the bolts -2- from the subframe and the bolts -3- from the wheel housing liner and pull the noise insulation to the rear. When installing, ensure noise insulation slides in as shown in the detailed illustration see scheme 1
2. 2 - Combi-bolt 6 NM
3. 3 - Self-tapping screw 2 NM
4. 4 - Wheel housing liner
5. 5 - Subframe
6. 6 - Lock carrier

Scheme 34

Slide noise insulation -3- as shown into lower lock carrier -2-.

The narrow latches -arrow a- must be slid below or wide latches -arrow b- slid above the lock carrier edge -2-.

Retaining tabs must engage over wide tabs in lock carrier holes when doing so.

Scheme 35

1. Remove the screws -1-, -2- and -6- from the frame and remove the noise insulation toward the rear.
2. Installation is the reverse of removal.

Note. Make sure the noise insulation is pushed in from the front when installing.
