Dashboard (v6) Acura TSX II

Driver's Dashboard Lower Cover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 33

Scheme 34

1. Adjust the steering column to the full tilt up position, and to the full telescopic out position.
2. Remove the driver's dashboard lower cover (A). Open the driver's pocket (B), and remove the screw (C). Pull out the bottom of the cover to detach the clips (D). Pull out along the edge of the cover to detach the clips (E, F). Disconnect the VSA OFF switch connector (G).
3. If necessary, push out the switch trim (A) to detach the clips and to release the tabs (B), then remove the trim from the driver's dashboard lower cover (C).
4. Install the cover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly. Push the clips and the tabs into place securely.

Scheme 35

1. Remove the driver's pocket (A). Release both pivots (B) by pulling back the bottom of the driver's pocket. Lower the pocket to pull the stop area (C) off the driver's dashboard lower cover (D).
2. Install the pocket in the reverse order of removal.

Driver's Dashboard Undercover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 36

1. Remove the driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-dashboard-lower-cover-removalinstallation) ).
2. Remove the driver's dashboard undercover (A). Gently pull down the rear edge to detach the clips. Pull the undercover rearward to release its holder (B) from the pin (C). Disconnect the footwell light connector (D).
3. Install the undercover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the footwell light connector is plugged in properly. Make sure the holder of the undercover is installed securely to the pin. Push the clips into place securely.

Driver's Outer Dashboard Trim Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 37

1. Remove the driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-dashboard-lower-cover-removalinstallation) ).
2. Detach the clips, then remove the driver's outer dashboard trim (A).
3. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Trim Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 38

Scheme 39

1. Remove these items: Center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-panel-removalinstallation) ) Passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-trim-removalinstallation) )
2. Remove the driver's center trim (A) or the passenger's center trim (B). Remove the screw(s) (C). Gently pull up the lower area of the trim to detach the clip (D) and to release the hook (E) from the edge of the center console (F). Pull out the trim to detach the clips (G, H). Driver's side Passenger's side
3. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Holder Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 40

Scheme 41

1. Remove the center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-trim-removalinstallation) ).
2. Remove the center pocket (A) by detaching the clip, then remove the screw.
3. Pull out the center holder (A) to detach the clips (B, C) and the harness clip (D). Disconnect the front accessory power socket connector (E), then remove the holder.
4. Install the holder in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the connector is plugged in properly. Push the clips into place securely.

Center Pocket Removal/Installation

Note. Take care not to scratch the dashboard or the related parts.

Scheme 42

1. Remove these items: Center holder (see «CENTER HOLDER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-holder-removalinstallation) ) Climate control unit (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) )
2. Move the shift lever to 1st.
3. Remove the bolts securing the center pocket (A). Pull out the center pocket, and disconnect the center pocket light connector (B), then remove the center pocket. NOTE: Take care not to scratch the A/T gear position indicator panel.
4. Install the pocket in the reverse order of removal.

Dashboard Center Lower Cover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 43

Scheme 44

Scheme 45

1. Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-panel-removalinstallation) ).
2. Detach the clips (A, B, C) by pulling out the front edges of the center console (D), then release both front areas of the console from the dashboard as needed.
3. Remove the driver's dashboard center lower cover (A). Gently pull the rear edge of the cover to detach the clips (B, C). Pull up the rear area of the cover to release the hook (D) from the rear heater duct (E). Pull the cover rearward to release the hook (F) from the heater unit (G).
4. Remove the passenger's dashboard center lower cover (A). Gently pull the edge of the cover to detach the clips (B, C). Pull up the cover to release the hook (D) from the rear heater duct (E).
5. Install the cover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Side Pocket Removal/Installation

Note. Take care not to scratch the dashboard or the related parts. The driver's side pocket is shown; the passenger's side pocket is similar.

Scheme 46

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-removalinstallation) ).
2. Remove the screws, and pull out the side pocket (A) to detach the clip, then remove it.
3. Install the side pocket in the reverse order of removal, and note these items: If the clip is damaged or stress-whitened, replace it with a new one. Push the clip into place securely.

Speaker Cover Removal/Installation

Note. Take care not to scratch the dashboard or the related parts. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 47

1. Remove the speaker cover (A). Apply the protective tape (B) to the dashboard beside the side edge of the speaker cover. Pry upon the edge of the cover to detach the clips with a flat-tip screwdriver.
2. Install the cover in the reverse order of removal, and note these items: If the clips are damaged, replace them with new ones. Push the clips into place securely.

Passenger's Dashboard Trim Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 48

1. Remove the passenger's dashboard trim (A). Open the glove box. Pull out on the bottom edge of the trim by hand. Detach the clips along the trim.
2. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Glove Box Lock Cylinder Replacement

Note. Take care not to scratch the glove box.

Scheme 49

Scheme 50

Scheme 51

1. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-removalinstallation) ).
2. While lifting the glove box handle (A), pull out one end of the retainer (B) with a hook-shaped tool of its slot. NOTE: Do not remove the retainer entirely. Leave one end of the retainer in its original position when removing the lock cylinder.
3. Remove the glove box lock cylinder (A).
4. Reinstall the end of the retainer (A) in its slot, then install the lock cylinder (B). Push the cylinder into place securely until the retainer snaps into place

Glove Box Separator Removal/Installation

Note. Take care not to scratch the dashboard or the related parts.

Scheme 52

1. Open the glove box.
2. Pull the glove box separator (A) back to release the hooks (B) and the pins (C), then remove it.
3. Install the separator in the reverse order of removal, and push the hooks and the pins into place securely.

Glove Box Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 53

Scheme 54

Scheme 55

1. Remove the passenger's dashboard side panel (A). Open the front door. Open the glove box. Gently pull the rear edge of the lid outward by hand to release the hooks (B). Detach the clips and the hooks (C) by pulling the panel outward. Release the hooks (D).
2. Remove the passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-trim-removalinstallation) ).
3. Close the glove box.
4. Remove the bolts (A) and the screws (B).
5. Remove the glove box (A). Pull the glove box by hand to detach the clips. While holding the glove box, disconnect the glove box light connector (B) and the trunk lid opener main switch connector (C).
6. Install the glove box in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Push the clips and the hooks into place securely.

Glove Box Damper Replacement

Note. Take care not to scratch the glove box.

Scheme 56

1. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-removalinstallation) ).
2. Release the glove box damper wire (A). Remove the screws, then remove the glove box damper (B).
3. Install the damper in the reverse order of removal.

Passenger's Dashboard Undercover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 57

1. Remove the passenger's dashboard undercover (A). Gently pull down the rear edge to detach the clips. Pull the undercover away to release the pins (B) from the holders (C). Disconnect the footwell light connector (D) and the HandsFreeLink control unit connector (E).
2. Install the undercover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Make sure the pins of the undercover are installed securely to the holders. Push the clips into place securely.

Dashboard Side Vent Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The driver's side vent is shown; the passenger's side vent is similar.

Scheme 58

Scheme 59

Scheme 60

1. Driver's side: Remove the driver's dashboard side panel (A). Open the front door. Pull the lower edge of the panel by hand to detach the lower clip (B). Gently pull the rear edge of the panel outward by hand to detach the clips (C) and release the hooks (D). Release the hooks (E).
2. Passenger's side: Open the glove box, then remove the passenger's dashboard side panel (see step 1 ).
3. Detach the clips under the dashboard side vent (A). Insert a flat-tip screwdriver through a hole in the driver's dashboard side panel opening. While pushing on the inside clip (B) with a flat-tip screwdriver, carefully pull out the inside edge of the vent to release the upper tab (C). Repeat the preceding step at the outside clip (D) and the upper tab (E).
4. Remove the dashboard side vent (A).
5. Install the side vent in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Dashboard Center Vent Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The left dashboard center vent is shown; the right dashboard center vent is similar.

Scheme 61

1. Remove these items: Without navigation: Audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ) With navigation: Audio/navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) )
2. Remove the screws, then remove the dashboard center vent (A) from the center panel (B) while releasing upper tabs (C) with the appropriate trim tool.
3. Install the center vent in the reverse order of removal, and push the tabs into place securely.

Side Defogger Vent Trim Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The left side defogger vent trim is shown; the right side defogger vent trim is similar.

Scheme 62

1. Insert the appropriate trim tool into a gap between the side defogger vent trim (A) and the dashboard, and push in the hook (B).
2. Pry up the vent trim to release the hook (C), then remove the vent trim.
3. Install the tab area of the trim first, then push down on the trim until the hook securely engages the dashboard.

Column Cover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to scratch or damage the column covers. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Do not pry on the column cover surface with any tools.

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. Adjust the steering column to the full tilt down position, and to the full telescopic out position.
2. Release the column blind cover (A) from the column covers. Carefully pry up the edge of the column blind cover with the appropriate trim tool to release the pin (B) from the lower column cover (C). Detach the clips fastening the column blind cover from the upper column cover (D) by hand. Pull the other pin (E) off the lower column cover.
3. Turn the steering wheel to the left, and release the left tab (A) of the upper column cover (B) while pushing on the lower column cover (C) from the front. NOTE: Carefully release the tabs, and do not pull up too hard on the upper column cover, or the hooks (D) may break.
4. Turn the steering wheel to the right, and release the right tab of the upper column cover the same as step 3 .
5. Remove the upper column cover (A) by lightly pulling it up to release both side hooks (B) of the cover.
6. Remove the screws (A, B), then remove the lower column cover (C).
7. Install the upper and lower column covers in the reverse order of removal, and push the hooks into place securely.

Column Blind Cover Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the dashboard or the related parts. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 67

1. Adjust the steering column to the full tilt down position, and to the full telescopic out position.
2. Remove these items: Driver's outer dashboard trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-outer-dashboard-trim-removalinstallation) ) Driver's center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-trim-removalinstallation) )
3. Remove the column blind cover (A). Remove the screws. Carefully pry up the edge of the column blind cover with the appropriate trim tool to release the pin (B) from the lower column cover (C). Detach the clips fastening the column blind cover from the upper column cover (D) by hand, and pull the pin (E) off the lower column cover. Release the hooks (F) (five places) from the dashboard. Remove both ends of the column blind cover from the hooks (G) of the dashboard.
4. Install the cover in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Slip both ends of the blind cover under the hooks of the dashboard properly. Push the clips and the hooks into place securely.

Dashboard Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Have an assistant help you when removing and installing the dashboard. Put on gloves to protect your hands. Take care not to scratch the dashboard, the body, or the related parts. Take care not to bend the brackets. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before beginning work.
2. Remove these items from the dashboard: A-pillar trims, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-pillar-areas) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-removalinstallation) ) Dashboard center lower covers, both sides (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-dashboard-lower-cover-removalinstallation) ) Side defogger vent trims, both sides (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ) Driver's outer dashboard trim (see «DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-outer-dashboard-trim-removalinstallation) ) Dashboard side vents, both sides (see «DASHBOARD SIDE VENT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-side-vent-removalinstallation) ) Side pockets, both sides (see «SIDE POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-pocket-removalinstallation) ) Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-removalinstallation) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-undercover-removalinstallation) ) Gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__gauge-control-module-replacement) ) Speaker cover (see «SPEAKER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__speaker-cover-removalinstallation) ) Without navigation: Center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-pocket-removalinstallation) ) Audio unit: Without navigation: Audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ) With navigation: Audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ) With navigation: Audio/navigation switch panel (see «AUDIO-NAVIGATION SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ) Display unit: Without navigation: Audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ) With navigation: Navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__navigation-display-unit-removalinstallation) ) Sunlight sensor (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) ) With navigation: Front center speaker (see «FRONT CENTER SPEAKER (WITH ELS AUDIO)»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ) In-car temperature sensor (see «IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ) Shift lever (see «SHIFT LEVER REMOVAL»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-v6) ) Driver's Side
3. Detach the harness clips (A, B) from the dashboard. Middle Area
4. Detach the dashboard wire harness clip (A) and the harness clips (B) from the center pocket frame (C).
5. Remove the bolts (A) and the screws (B), then remove the center pocket frame (C) from the dashboard.
6. Detach the audio wire harness clips (A) from the dashboard center stay, and detach the antenna lead clip (B) from the center frame. Passenger's Side
7. Disconnect the antenna lead connector (A).
8. Detach the audio wire harness clips (A), the dashboard wire harness connector clip (B), and the audio wire harness connector clip (C) from the dashboard.
9. Remove the screw, then remove passenger's dashboard duct B.
10. Pull out the audio wire harness (A) from the display unit opening.
11. Disconnect the passenger's airbag connector (A), and detach the dashboard wire harness clips (B). Remove the passenger's airbag mounting bolts.
12. Remove the bolts securing the dashboard (A).
13. Lift up on the dashboard to release it from the guide pins (B) and the center pin (C) on the dashboard from the grommet (D). Carefully remove the dashboard through the front door opening.
14. While holding the dashboard (A) away from the body, detach the antenna lead clip (B) from the passenger's side bracket (C).
15. Carefully remove the dashboard through the front door opening. NOTE: Do not rest the dashboard on its lower center cover opening, or it may be damaged. Lay it on its front or back.
16. Remove the screws, then remove the front defogger duct (A) and both front dashboard stays (B) from the dashboard (C).
17. Remove the screws, then remove the dashboard duct (A) from the dashboard (B).
18. Remove the screws, then remove passenger's dashboard duct A from the dashboard (B).
19. Remove the screws, then remove the dashboard center stay (A) from the dashboard (B).
20. Remove the passenger's airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ).
21. Assemble the dashboard and the steering hanger beam in the reverse order of removal, and note these items: Replace the passenger's airbag mounting bolts with new ones. If the clips are damaged or stress-whitened, replace them with new ones. Make sure the dashboard fits onto the guide pins correctly. Make sure the dashboard wire harness, the audio wire harness, and the antenna lead are routed properly and not pinched. Make sure each connector is plugged in properly. Push the harness clips and the connector clips into place securely. Do the battery terminal reconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ). If necessary, adjust the shift cable (see «SHIFT CABLE ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-v6) ). Check for any DTCs that may have been set during repairs, and clear them.

Dashboard/Steering Hanger Beam Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Have an assistant help you when removing and installing the dashboard/steering hanger beam. Put on gloves to protect your hands. Take care not to scratch the dashboard, the body, or the related parts. Take care not to bend the brackets. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before beginning work.
2. Remove these items: A-pillar trims, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-pillar-areas) ) Driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-dashboard-lower-cover-removalinstallation) ) Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-door-areas) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-dashboard-undercover-removalinstallation) ) Dashboard center lower covers, both sides (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-removalinstallation) ) Side pockets, both sides (see «SIDE POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-pocket-removalinstallation) ) Without navigation: Center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-pocket-removalinstallation) ) With navigation: Audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ) Center pocket frame (see step 5 ) Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-removalinstallation) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-undercover-removalinstallation) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ) Shift lever (see «SHIFT LEVER REMOVAL»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-v6) ) Driver's Side
3. From under the dash, disconnect the left engine compartment wire harness connectors (A), the driver's door wire harness connector (B), the roof wire harness connectors (C), and the left side wire harness connectors (D). Disconnect the left engine compartment wire harness connectors (E) and the left side wire harness connectors (F) from the driver's under-dash fuse/relay box (G).
4. From under the dash, disconnect the air hose (A), then remove it. Middle Area (Shift Lever Area)
5. Disconnect the SRS unit connector A, the parking brake switch connector (B), the yaw rate-lateral acceleration sensor connector (C), and the USB adapter unit connector (D) (without navigation), and detach the wire harness clips (E). Remove the ground bolt (F) with a TORX T30 bit.
6. Remove the bolts, then remove the shift lever mount bracket (A). Middle Area (Passenger's Side)
7. From under the dash, disconnect the A/C wire harness connector (A), and the floor wire harness connector (B). Detach the wire harness clip (C). Passenger's Side
8. Disconnect the antenna lead connector (A).
9. From under the dash, disconnect the passenger's door wire harness connector (A), the right side wire harness connectors (B), and the right engine compartment wire harness connectors (C). Disconnect the dashboard wire harness connectors (D) and the audio wire harness connector (E) from the passenger's under-dash fuse/relay box (F).
10. Detach all of the harness and connector clips.
11. Detach the harness clip (A) and the clip fastening the relay (B) from the brake pedal support member (C). Remove the bolts (D, E), then remove the member, and disconnect the TPMS control unit connector (F).
12. Remove the center frame mounting bolts (A) and the center joint mounting bolts (B), then remove the center joint bracket (C).
13. Remove the special bolts (A) from outside the passenger's door. Remove the caps (B). Loosen the special bolts until they disengage from the threads on the hanger beam side bracket (C), and engage the inside threads of the collar bolts (D). The thread lock on the special bolts makes the special bolts and collar bolts turn together. Continue loosening the special bolts to turn the collar bolts into the fixed space adjusters (E) until the collar bolts engage the stoppers (F). This creates a gap (G) between the collar bolts and the body. Loosen the special bolts to disengage them from the collar bolts, then remove them.
14. Check that the collar bolts (A) are seated in the space adjusters (B). Insert an 8 mm hex wrench in the collar bolt. Gently turn the wrench counterclockwise. If the wrench turns easily, continue turning until the collar bolt seats and engages the stopper (C). If the wrench does not turn easily, the collar bolt is seated. NOTE: If either collar bolt was not seated, replace the special bolts.
15. From outside the driver's door, remove the caps (A), then remove the dashboard mounting bolts (B, C) from outside the driver's door.
16. Lift up on the dashboard (A) to release it from the guide pins (B) and the center pin (C) on the dashboard from the grommet (D). Carefully remove the dashboard through the front door opening. NOTE: Take care not to scratch the body with the collar nuts on the passenger's side. Do not rest the dashboard on its center lower cover opening, or it may be damaged. Lay it on its front or back.
17. Install the dashboard in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure the dashboard fits onto the guide pins correctly. Before tightening the bolts, make sure the wire harnesses are not pinched. Make sure each connector is plugged in properly. Make sure the collar bolts (A) turn easily by hand in the fixed space adjusters (B). Tighten the collar bolts by hand until they engage the stoppers (C) before reinstalling the dashboard. Before reinstalling the dashboard, screw the special bolts (D) into the collar bolts and check that they turn together. If they do not turn together, replace the special bolts. After setting the dashboard in the body, reinstall all of the mounting bolts but do not tighten them. First tighten the driver's side bracket bolts to the specified torque. Next, tighten the special bolts to turn the collar bolts out of the space adjusters until the collar bolts contact the body. Continue tightening the special bolts to the specified torque. Apply medium strength liquid thread lock to the bolts securing the center joint bracket and the dashboard before reinstallation. After tightening the dashboard mounting bolts, tighten the center joint bracket mounting bolts, and then tighten the center frame mounting bolts. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ). If necessary, adjust the shift cable (see «SHIFT CABLE ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-v6) ). Check for any DTCs that may have been set during repairs, and clear them. Special bolt tightening on passenger's side

See also:
• CENTER CONSOLE PANEL REMOVAL/INSTALLATION
• SUNLIGHT SENSOR REPLACEMENT
• COMPONENT LOCATION INDEX
• CENTER CONSOLE REMOVAL/INSTALLATION
• AUDIO UNIT REMOVAL/INSTALLATION
• USING THE GR8 BATTERY DIAGNOSTIC STATION
• TRIM REMOVAL/INSTALLATION - PILLAR AREAS
• GAUGE CONTROL MODULE REPLACEMENT
• AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
• NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION
• IN-CAR TEMPERATURE SENSOR REPLACEMENT
• STEERING COLUMN REMOVAL AND INSTALLATION
• SHIFT LEVER REMOVAL
• SIDE AIRBAG REPLACEMENT
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• RECONNECTION
• DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION
• PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION
• CENTER TRIM REMOVAL/INSTALLATION
• CENTER HOLDER REMOVAL/INSTALLATION
• GLOVE BOX REMOVAL/INSTALLATION
• DRIVER'S OUTER DASHBOARD TRIM REMOVAL/INSTALLATION
• SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION
• DASHBOARD SIDE VENT REMOVAL/INSTALLATION
• SIDE POCKET REMOVAL/INSTALLATION
• PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• SPEAKER COVER REMOVAL/INSTALLATION
• CENTER POCKET REMOVAL/INSTALLATION
• DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION
