Front Suspension (4-cyl) Acura TSX II

Scheme 62

Special Tools Required

1. Ball Joint Thread Protector, 14 mm 07AAE-SJAA100
2. Ball Joint Thread Protector, 12 mm 07AAF-SDAA100
3. Ball Joint Thread Protector, 10 mm 07AAF-SECA120
4. Ball Joint Remover, 28 mm 07MAC-SL0A202
5. Hub Dis/Assembly Pin, 42mm 07GAF-SD4A100
6. Attachment, 72 x 75 mm 07746-0010600
7. Driver Handle, 15 x 135L 07749-0010000
8. Oil Seal Driver Attachment, 96 mm 07ZAD-PNA0100
9. Support Base 07965-SD90100

Note. Refer to the Exploded View as needed during the following procedure.

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the wheel nuts (A) and the front wheel.
3. Remove the brake hose bracket mounting bolt (A).
4. Remove the brake caliper bracket mounting bolts (B), then remove the caliper assembly (C) from the knuckle. To prevent damage to the caliper assembly or the brake hose, use a short piece of wire to hang the caliper assembly from the undercarriage. Do not twist the brake hose excessively.
5. Remove the wheel speed sensor harness bracket (A) and the wheel speed sensor (B) from the knuckle. Do not disconnect the wheel speed sensor connector.
6. Pry up the stake (A) on the spindle nut (B), then remove the nut.
7. Remove the front brake disc (see «FRONT BRAKE DISC REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-4-cyl__front-brake-disc-replacement) ).
8. Check the front hub for damage and cracks.
9. Remove the cotter pin (A) from the tie-rod end ball joint, then remove the nut (B). NOTE: During installation, install the new cotter pin after tightening the nut, and bend its end as shown.
10. Disconnect the tie-rod end ball joint from the knuckle using the ball joint thread protector and the ball joint remover (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__ball-joint-removal) ).
11. Remove the cotter pin (A) from the knuckle ball joint, then remove the castle nut (B). NOTE: During installation, insert the new cotter pin into the ball joint pin hole from the front to the rear of the vehicle, and bend its end as shown. Check the ball joint pin hole direction before connecting the ball joint.
12. Disconnect the knuckle ball joint from the lower arm using the ball joint thread protector and the ball joint remover (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__ball-joint-removal) ). NOTE: Be careful not to damage the ball joint boot when installing the remover. Do not force or hammer on the lower arm, or pry between the lower arm and the knuckle. You could damage the ball joint.
13. Remove the cotter pin (A) from the upper arm ball joint, then remove the castle nut (B). NOTE: During installation, insert the new cotter pin into the ball joint pin hole from the front to the rear of the vehicle, and bend its end as shown. Check the ball joint pin hole direction before connecting the ball joint.
14. Disconnect the upper arm ball joint from the knuckle using the ball joint thread protector and the ball joint remover (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__ball-joint-removal) ).
15. Pull the knuckle (A) outward, and separate the outboard joint (B) from the front hub using a soft face hammer outward, then remove the knuckle/hub. NOTE: Do not pull the driveshaft end outward. The driveshaft inboard joint may come apart. During installation, apply grease to the mating surfaces of the wheel bearing and the driveshaft outboard joint (see step 1 on «DRIVESHAFT INSTALLATION»(/acura/tsx/ii-2008-2014/remont/axle-shafts/#drivelineaxle-4-cyl__driveshaft-installation) ).
16. Install the knuckle/hub in the reverse order of removal, and note these items: Be careful not to damage the ball joint boot when connecting the knuckle. Before connecting the ball joint, degrease the threaded section and the tapered portion of the ball joint pin, the ball joint connecting hole, the threaded section, and the mating surfaces of the castle nut. Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it. Use a new spindle nut on reassembly. Before installing the spindle nut, apply a small amount of engine oil to the seating surface of the nut. After tightening, use a drift to stake the spindle nut shoulder against the driveshaft. Before installing the brake disc, clean the mating surfaces between the front hub and the inside of the brake disc. Before installing the wheel, clean the mating surfaces between the brake disc and the inside of the wheel.
17. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. Remove the knuckle/hub.
2. Separate the hub (A) from the knuckle (B) using the hub dis/assembly pin and a hydraulic press. Hold the knuckle with the attachment (C) of the hydraulic press or equivalent tool. Be careful not to damage or deform the splash guard (D). Hold onto the hub to keep it from falling when pressed clear.
3. Press out the wheel bearing inner race (A) of the hub (B) using the hub dis/assembly pin, a commercially available bearing separator (C), and a press.
4. Remove the snap ring (A) and the splash guard (B) from the knuckle (C).
5. Press the wheel bearing (A) out of the knuckle (B) using the attachment, the driver handle, and a press.
6. Wash the knuckle and the hub thoroughly in high flash point solvent before reassembly.
7. Press a new wheel bearing (A) into the knuckle (B) using the old bearing (C), a steel plate (D), the attachment, the support base, and a press. NOTE: Install the wheel bearing with the wheel speed sensor magnetic encoder (E) (brown color) toward the inside of the knuckle. Remove any oil, grease, dust, metal debris, and other foreign material from the magnetic encoder surface. Keep any magnetic tools away from the magnetic encoder surface. Be careful not to damage the magnetic encoder surface when you insert the wheel bearing.
8. Check the front knuckle ring (A) for damage or deformation, and replace it if necessary. NOTE: When installing the new front knuckle ring, position the knuckle ring notch portion (B) toward the cut out (C) near the ball joint in the knuckle, and align the center of the knuckle ring ledge portion (D) with the center of the wheel speed sensor hole (E) on the knuckle as shown.
9. Install the new snap ring (A) securely in the knuckle (B).
10. Install the splash guard (C), and tighten the screws (D) to the specified torque.
11. Install the hub (A) onto the knuckle (B) using the attachment, the driver handle, the support base, and a hydraulic press. Be careful not to damage the splash guard (C).
12. Install the knuckle/hub.

Knuckle Ball Joint Inspection

Note. When inspecting the ball joint, the vehicle will be shaken strongly. Make sure to support the front jacking bracket correctly with a suitable jack (see LIFT AND SUPPORT POINTS ).

Scheme 79

Scheme 80

Scheme 81

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Check all bolts, nuts, and bushings on the suspension components, and make sure that there is no looseness, deterioration, or damage.
3. Measure the gap between the lower arm (A) and the knuckle (B) using the vernier caliper with a dial or digital gauge (C). Record the measured gap.
4. Position a stand jack (A) about 305 mm (12.01 in) away from the front wheel.
5. Place a wood block (B) on top of the jack stand and under the front wheel.
6. Have an assistant apply downward pressure on the wood block to raise the wheel (You only have to raise the weight of the wheel and knuckle assembly to fully extend the ball joint).
7. Measure the gap between the lower arm (A) and the knuckle (B) using the vernier caliper with a dial or digital gauge (C) while the ball joint is being extended. Record the measured gap. NOTE: Measure the same point as step 3.
8. Compare gap measured in step 3 and step 7.

Maximum difference: 0.2 mm (0.008 in)

1. If the difference is more than 0.2 mm (0.008 in), replace the knuckle ball joint (see «KNUCKLE BALL JOINT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl__knuckle-ball-joint-replacement) ).
2. If the difference is less than 0.2 mm (0.008 in), the knuckle ball joint is OK.

Knuckle Ball Joint Replacement

Special Tools Required

1. Ball Joint Thread Protector, 14 mm 07AAE-SJAA100
2. Ball Joint Remover, 28 mm 07MAC-SL0A202
3. Ball Joint Tool Kit 07AAF-TL2A150
4. Adapter G 07XAF-001050A
5. C-Frame OTC7248, commercially available

Note. Paint mark (A) indicate the knuckle ball joint has been replaced. Do not replace the ball joint with the paint mark; you must replace the knuckle as an assembly (see KNUCKLE/HUB/WHEEL BEARING REPLACEMENT ).

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the front wheel.
3. Remove the wheel speed sensor harness bracket mounting bolt (A).
4. Pry up the stake (A) on the spindle nut (B), then remove the nut.
5. Remove the damper fork mounting nut (A) while holding the mounting bolt (B), then remove the mounting bolt. NOTE: Use the new damper fork mounting bolt and the new mounting nut, and torque the nut while holding the bolt during reassembly.
6. Remove the cotter pin (A) from the knuckle ball joint, then remove the castle nut (B). NOTE: During installation, insert the new cotter pin into the ball joint pin hole from the front to the rear of the vehicle, and bend its end as shown. Check the ball joint pin hole direction before connecting the ball joint.
7. Disconnect the knuckle ball joint from the lower arm using the ball joint thread protector and the ball joint remover (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__ball-joint-removal) ). NOTE: Be careful not to damage the ball joint boot when installing the remover. Do not force or hammer on the lower arm, or pry between the lower arm and the knuckle. You could damage the ball joint.
8. Pull the knuckle (A) outward, and separate the outboard joint (B) from the front hub using a soft face hammer outward, then move aside the knuckle/hub. NOTE: Do not pull the driveshaft end outward. The driveshaft inboard joint may come apart. During installation, apply grease to the mating surfaces of the wheel bearing and the driveshaft outboard joint (see step 1 on «DRIVESHAFT INSTALLATION»(/acura/tsx/ii-2008-2014/remont/axle-shafts/#drivelineaxle-4-cyl__driveshaft-installation) ).
9. Remove the front knuckle ring (A) from the knuckle. NOTE: During installation, make sure the position of the knuckle ring and the wheel speed sensor hole on the knuckle (see step 8 on «KNUCKLE BALL JOINT INSPECTION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl__knuckle-ball-joint-inspection) ).
10. Remove the boot clip (B) and the boot (C), then wipe grease off the exposed portion of the ball joint.
11. Install the attachments (07AAF-TL2A300-A and B) of the ball joint tool kit through the hub center. Position the projection of the attachment (07AAF-TL2A300-B) toward the lower side of the knuckle (A). Tighten it into place by hand. NOTE: Make sure that it is parallel between the top (B) of the knuckle ball joint and the flat aspect (C) of the attachment.
12. Position the ball joint tool kit, the adapter G, and the C-frame OTC7248, commercially available to knuckle ball joint (A) as shown. NOTE: Make sure the attachments are installed securely.
13. Tighten the pressure bolt (B) of the C-frame, and remove the knuckle ball joint. NOTE: When tightening the pressure bolt, fix the knuckle (C) and outboard joint (D) securely.
14. Clean the mating surfaces of the new knuckle ball joint (A) and the knuckle (B). Position the ball joint tool kit and the C-frame OTC7248, commercially available to ball joint as shown. NOTE: Make sure the attachments are installed securely.
15. Tighten the pressure bolt (C) of the C-frame until the knuckle ball joint shoulder is fully seated in the knuckle. NOTE: When tightening the pressure bolt, fix the knuckle and outboard joint (D) securely.
16. Using a yellow oil-based paint marker, paint a mark (A) to the top of the knuckle ball joint as shown. NOTE: The paint mark is used to identify a knuckle that has had the ball joint replaced. Replace the knuckle as an assembly if the knuckle ball joint has the paint mark.
17. Install all of the removed parts in the reverse order of removal, and note these items: First install all of the components, and lightly tighten the bolts and the nuts, then raise the suspension to load it with the vehicle's weight before fully tightening it to the specified torque. Do not place the jack against the ball joint pin of the knuckle. Be careful not to damage the ball joint boot when connecting the knuckle. Before connecting the ball joint, degrease the threaded section, the tapered portion of the ball joint pin, and the ball joint connecting hole, the threaded section, and the mating surfaces of the castle nut. Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it. Use a new spindle nut on reassembly. Before installing the spindle nut, apply a small amount of engine oil to the seating surface of the nut. After tightening, use a drift to stake the spindle nut shoulder against the driveshaft. Before installing the wheel, clean the mating surfaces between the brake disc and the inside of the wheel.
18. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).

Upper Arm Replacement

Special Tools Required

1. Ball Joint Thread Protector, 10 mm 07AAF-SECA120
2. Ball Joint Remover, 28 mm 07MAC-SL0A202

Scheme 93

Scheme 94

Scheme 95

Scheme 96

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the front wheel.
3. Remove the front damper/spring (see «STABILIZER BAR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
4. Remove the cotter pin (A) from the upper arm ball joint, then remove the castle nut (B).
5. Disconnect the upper arm ball joint from the knuckle using the ball joint thread protector and the ball joint remover (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__ball-joint-removal) ).
6. Remove the upper arm mounting bolts (A), then remove the upper arm (B).
7. Install the upper arm (A), and lightly tighten the new upper arm mounting bolts (B), then connect the knuckle, and lightly tighten the castle nut (C). NOTE: Be careful not to damage the ball joint boot when connecting the knuckle. Before connecting the ball joint, degrease the threaded section and the tapered portion of the ball joint pin, the ball joint connecting hole, the threaded section and the mating surfaces of the castle nut.
8. Place a floor jack under the lower arm, and raise the suspension until the clearance between the top (D) of the upper arm ball joint and the backside of the fender cut out point (E) is 40 mm (1.6 in), then tighten the upper arm mounting bolts to the specified torque. NOTE: To measure the specified clearance, temporarily remove the front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-inner-fender-replacement) ). Do not place the jack directly on the ball joint pin to load the suspension.
9. Lower the floor jack
10. Install the front damper/spring (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
11. Tighten the castle nut (A) on the upper arm ball joint to the specified torque. NOTE: Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it. Insert the new cotter pin (B) into the ball joint pin hole from the front to the rear of the vehicle, and bend its end as shown. Check the ball joint pin hole direction before connecting the ball joint.
12. Clean the mating surfaces between the brake disc and the inside of the wheel, then install the front wheel.
13. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).

Lower Arm Removal/Installation

Special Tools Required

1. Ball Joint Thread Protector, 14 mm 07AAE-SJAA100
2. Ball Joint Remover, 28 mm 07MAC-SL0A202
3. Bushing Driver 070AF-TA0A100
4. Bushing Receiver Set 070AF-TA0A220

Scheme 97

Scheme 98

Scheme 99

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the front wheel.
3. Remove the front splash shield (see «FRONT SPLASH SHIELD REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#fenderwell-4-cyl__front-splash-shield-replacement) ).
4. Remove the damper pinch bolt (A) and the damper fork mounting nut (B) while holding the mounting bolt (C), then remove the damper fork (D) from the damper and the lower arm. NOTE: During installation, insert the aligning tab (E) on the damper unit into the slot (F) of the damper fork. Use the new damper fork mounting bolt and the new mounting nut, and torque the nut while holding the bolt during reassembly.
5. Disconnect the stabilizer link from the lower arm (see «STABILIZER LINK REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
6. Remove the cotter pin (A) from the knuckle ball joint, then remove the castle nut (B). NOTE: During installation, insert the new cotter pin into the ball joint pin hole from the front to the rear of the vehicle, and bend its end as shown. Check the ball joint pin hole direction before connecting the ball joint.
7. Disconnect the knuckle ball joint from the lower arm using the ball joint thread protector and the ball joint remover (see «BALL JOINT REMOVAL»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__ball-joint-removal) ). NOTE: Be careful not to damage the ball joint boot when installing the remover. Do not force or hammer on the lower arm, or pry between the lower arm and the knuckle. You could damage the ball joint.
8. Remove the lower arm mounting bolts, and remove the lower arm (A). NOTE: Use new lower arm mounting bolts during reassembly.
9. Install the lower arm in the reverse order of removal, and note these items: First install all of the components, and lightly tighten the bolts and the nuts, then raise the suspension to load it with the vehicle's weight before fully tightening it to the specified torque. Do not place the jack against the ball joint pin of the knuckle. Be careful not to damage the ball joint boot when connecting the knuckle. Before connecting the ball joint, degrease the threaded section and the tapered portion of the ball joint pin, the ball joint connecting hole, the threaded section, and the mating surfaces of the castle nut. Torque the castle nut to the lower torque specification, then tighten it only far enough to align the slot with the ball joint pin hole. Do not align the castle nut by loosening it. Before installing the wheel, clean the mating surfaces between the brake disc and the inside of the wheel.
10. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).

Scheme 100

Scheme 101

Scheme 102

Scheme 103

1. Remove the lower arm.
2. Mark alignment marks (A) on the bottom of the lower arm next to the aligning marks (B) on the compliance bushing. NOTE: The compliance bushing has a specific installation position. Turn the lower arm so that its bottom side is up. Position the bushing identifying mark (C) face up and near the tab (D) on the lower arm. Then align the bushing aligning marks on the bushing and the lower arm. If the alignment marks are gone, align the angle (E) between the lower arm and the bushing as shown.
3. Press out the compliance bushing (A) with the bushing driver, the bushing receiver set (attachment A), and a hydraulic press, and remove the bushing from the lower arm (B). NOTE: Be careful not to damage the inside of the bushing hole on the lower arm.
4. Clean the mating surfaces of the new compliance bushing (A) and the lower arm (B).
5. Make sure of the compliance bushing installation direction, align the bushing aligning marks with the lower arm, then press in the bushing into the lower arm using the bushing driver, the bushing receiver set (attachments A and B), and a hydraulic press. NOTE: Press in the bushing from the bottom side of the lower arm. After installation, check the protrusion (C) of the bushing outer sleeve (D) through the lower arm bushing hole (E).
6. Install the lower arm.

Scheme 104

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the front wheel.
3. Remove the self-locking nut (A) and the flange nut (B) while holding the respective joint pin (C) with a hex wrench (D), then remove the stabilizer link (E).
4. Install the stabilizer link on the stabilizer bar (F) and the lower arm (G) with the joint pins set at the center of their range of movement. NOTE: The stabilizer link has a paint mark (H). The left stabilizer link is marked with yellow paint, and the right stabilizer link is marked with white paint.
5. Install the new self-locking nut and the new flange nut, and tighten them to the specified torque while holding the respective joint pin with a hex wrench.
6. Clean the mating surfaces between the brake disc and the inside of the wheel, then install the front wheel.
7. Test-drive the vehicle.
8. After 5 minutes of driving, tighten the self-locking nut again to the specified torque.

Scheme 105

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the front wheels.
3. Disconnect both tie-rod ball joints from the knuckle (see step 9 on «WHEEL BEARING REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
4. Disconnect both stabilizer links from the stabilizer bar (see «STABILIZER LINK REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ).
5. Remove the flange bolts (A) and the bushing holders (B), then remove the bushings (C) and the stabilizer bar (D). NOTE: During installation, align the paint marks (E) on the stabilizer bar with the side of the bushings.
6. Install the stabilizer bar in the reverse order of removal, and note these items: Note the right and left direction of the stabilizer bar. Note the direction of installation for the bushings. Refer to stabilizer link removal/installation to connect the stabilizer bar to the links (see «STABILIZER LINK REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/suspension-front/#front-suspension-4-cyl) ). Before installing the wheel, clean the mating surfaces between the brake disc and the inside of the wheel.
7. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).

Scheme 106

Scheme 107

Scheme 108

1. Raise and support the vehicle (see «LIFT AND SUPPORT POINTS»(/acura/tsx/ii-2008-2014/remont/oem-general-information/#general-information-4-cyl__lift-and-support-points) ).
2. Remove the front wheel.
3. Remove the wheel speed sensor harness bracket mounting bolt (A).
4. Remove the damper pinch bolt (A) and the damper fork mounting nut (B) while holding the mounting bolt (C), then remove the damper fork (D) from the damper and the lower arm.
5. Remove the front strut brace mounting nuts (A).
6. Remove the damper mounting nuts (B) from the top of the damper. Do not let the damper/spring drop down under its own weight.
7. Remove the damper/spring (A). NOTE: Be careful not to damage the body.

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

1. Position the damper/spring (A) in the body with the aligning tab (B) facing inside. NOTE: Be careful not to damage the body.
2. Loosely install the new damper mounting nuts (A) to the top of the damper.
3. Loosely install the front strut brace mounting nuts (B).
4. Install the clamper fork (A) over the driveshaft and onto the lower arm (B). Install the aligning tab (C) on the damper unit into the slot (D) of the damper fork.
5. Loosely install the damper pinch bolt (E) into the damper fork.
6. Connect the damper fork and the lower arm with the new damper fork mounting bolt (F), then lightly tighten the new mounting nut (G).
7. Place a floor jack under the lower arm, and raise the suspension to load it with the vehicle's weight. NOTE: Do not place the jack directly on the ball joint pin to load the suspension.
8. Tighten the damper pinch bolt and the damper fork mounting nut while holding the mounting bolt to the specified torque.
9. Tighten the damper mounting nuts and front strut brace mounting nuts on top of the damper to the specified torque.
10. Install the wheel speed sensor harness bracket (A).
11. Clean the mating surfaces between the brake disc and the inside of the wheel, then install the front wheel.
12. Check the wheel alignment, and adjust it if necessary (see «WHEEL ALIGNMENT»(/acura/tsx/ii-2008-2014/remont/wheel-alignment/#front-and-rear-suspension-inspection-4-cyl__wheel-alignment) ).

Scheme 114

Note. When compressing the damper spring, use a commercially available strut spring compressor (Branick MST-580A or Model 7200, or equivalent) according to the manufacturer's instructions. Refer to the Exploded View as needed during the following procedure.

Scheme 115

1. Compress the damper spring, then remove the self-locking nut (A) while holding the damper shaft with a hex wrench (B). Do not compress the damper spring more than necessary to remove the self-locking nut.
2. Release the pressure from the strut spring compressor, then disassemble the damper as shown in the Exploded View.

Scheme 116

1. Reassemble all the parts, except for the damper spring.
2. Compress the damper assembly by hand, and check for smooth operation through a full stroke, both compression and extension. The damper should extend smoothly and constantly when compression is released. If it does not, the gas is leaking and the damper should be replaced.
3. Check for oil leaks, abnormal noises, and binding during these tests.

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

1. Install the spring mounting cushion (A) on the damper mounting base (B) by aligning the tab (C) and the notch (D).
2. Install all the parts except the damper mounting washer and the self-locking nut onto the damper unit by referring to the Exploded View.
3. Compress the damper spring using a strut spring compressor. Do not compress the spring excessively.
4. Align the lower end (A) of the damper spring with the stepped part (B) of the dust cover lower mount and the lower spring seat on damper unit.
5. Position the tab (A) on the spring mounting cushion facing forward but toward the inside of the vehicle. Left Right
6. Align the angle of the stud (B) on the damper mounting base (C) with the aligning tab (D) on the bottom of the damper unit as shown.
7. Install the damper mounting washer (A) and the new self-locking nut (B).
8. Hold the damper shaft with a hex wrench (C), and tighten the self-locking nut to the specified torque.
9. Remove the damper/spring from the strut spring compressor.
