Interior Trim (v6) Acura TSX II

Scheme 25

Trim Removal/Installation - Door Areas

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Front Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. Remove the front door sill trim (A). Release the hooks (B) and the tabs (C) from the kick panel (D) and the B-pillar lower trim (E). Pull up the trim by hand to detach the clips.
2. If necessary, pull up the front side outer trim (A) to release the hooks, then remove the trim.
3. Remove the kick panel (A). Pull out the front door opening seal (B) as needed from the kick panel hooks (C). Pull the kick panel back by hand to detach the clips (D, E). Driver's side Driver's side Passenger's side
4. Pull out the front door opening seal (A) from the trim hooks (B) around the front door opening flange, then remove the seal.
5. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tabs into place securely.

Rear Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 31

Scheme 32

Scheme 33

1. Remove the rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-cushion) ).
2. Remove the rear door sill trim (A). Release the hooks (B) and the tab (C) from the B-pillar lower trim (D). Pull up the trim by hand to detach the clips (E, F).
3. If necessary, pull up the rear side outer trim (A) to release the hooks, then remove the trim.
4. Pull out the rear door opening seal (A) from the trim hooks (B) around the rear door opening flange, then remove the seal.
5. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tab into place securely.

Trim Removal/Installation - Pillar Areas

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

A-Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to Component Replacement/Inspection After Deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the A-pillar trim (B) consists of a resin grommet (C) and a metal pin (D). The grommet expands when the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

1. Pull the front door opening seal away from the A-pillar as needed (see step 4 ).
2. Hit the upper clip (A) in the A-pillar trim (B) with a rubber mallet. The clip is located under the point where the triangle mark (C) on the edge of the trim indicates. Hitting the clip breaks the projections (D) on the pin (E) and pushes it into the grommet (F) on the body (G). NOTE: The upper clip must be replaced with a new one when the A-pillar trim is reinstalled.
3. Pull back the top of the A-pillar trim (A) by hand to remove the upper clip (B) from the body (C).
4. Pull out the A-pillar trim (A) by hand to detach the clip. Pull up the trim from the dashboard (B), then remove the trim.
5. If the side curtain airbag has been deployed, replace the A-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) ).
6. If the side curtain airbag has not deployed, check the A-pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the A-pillar trim, replace the upper clip (C) with a new one. If the clip (D) is damaged or stress-whitened, replace it with a new one.
7. Temporarily install the A-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
8. Carefully install the new upper clip (A) to the A-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown.
9. Reinstall the A-pillar trim (A). Insert the bottom of the trim into the dashboard (B). Place the trim over the A-pillar (C), and fit its upper clip (D), the clip, and the pin (E) into the holes (F) in the A-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked down under the clips or the trim. Do not push too hard on the A-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the A-pillar trim to verify that all clips are securely fastened.
10. Reinstall the door opening seal (see step 4 ).

B-Pillar Upper/Lower Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to Component Replacement/Inspection After Deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Remove these items: Front door sill trim (see «FRONT DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__front-door-sill-area) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__rear-door-sill-area) ) Front door opening seal, as needed (see step 4 ) Rear door opening seal, as needed (see step 4 )
2. Slide the front seat forward fully.
3. Remove the B-pillar lower trim (A). While releasing the upper tabs (B), pull back the upper area of the trim to release the upper hooks (C). Detach the clips by pulling back the bottom of the trim by hand.
4. Remove the front seat belt lower anchor from the front seat (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ).
5. Remove the B-pillar upper trim (A). Pull back the bottom of the trim by hand to release the lower hooks (B). Pull back the bottom of the trim to release the upper pin (C) from the hole in the body and the slider (D) from the pin (E) on the front seat belt shoulder anchor adjuster. Pull down the trim to release the upper hooks (F) from the holes in the body.
6. Pass the front seat belt lower anchor (A) out through a hole in the slider (B), then remove the B-pillar upper trim (C).
7. Install the trim in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the B-pillar upper trim (A), the B-pillar lower trim (B), and all of the clips (C) on the trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it with a new one if it has any of the following damage: Any cracks or deformations in the B-pillar upper trim and the upper hooks (D), and any stress-whitened areas in the upper part of the trim Any cracks or deformations in the B-pillar lower trim, and any breakage in the area (E) that overlaps the B-pillar upper trim Any cracks or stress-whitening in the clip seating surface (F) If the clips are damaged or stress-whitened, replace them with new ones. Replace any damaged parts with new ones. Make sure the top of the B-pillar upper trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__checking-and-adjusting-the-headlinerpillar-trim) ). Make sure the pin (G) on the front seat belt shoulder anchor adjuster (H) and the hole (I) on the back of the slider are engaged when installing the B-pillar upper trim. Make sure the upper hooks are installed into the holes in the body securely. Push the clips and the hooks into place securely. Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt. Trim inspection Slider engagement with shoulder anchor adjuster

C-Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to Component Replacement/Inspection After Deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the C-pillar trim (B) consists of a plastic grommet (C) and a metal pin (D). The grommet expands when the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

1. Remove these items: Rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-cushion) ) Rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-side-bolster) ) Rear door opening seal, as needed (see step 4 )
2. Fold down the seat-back.
3. Hit the upper clip (A) in the C-pillar trim (B) with a rubber mallet. The clip is located under the point where the triangle mark (C) on the edge of the trim indicates. Hitting the clip breaks the projections (D) on the pin (E) and pushes it into the grommet (F) and against the body (G). NOTE: The upper clip must be replaced with a new one when the C-pillar trim is reinstalled.
4. Pull back the top of the C-pillar trim (A) by hand to remove the upper clip (B) from the body (C).
5. Pull the C-pillar trim (A) by hand to detach the clips and to release the hook (B) and the tabs (C), then pull out the trim from the rear shelf (D).
6. If the side curtain airbag has deployed, replace the C-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) ).
7. If the side curtain airbag has not been deployed, check the C-pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the C-pillar trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the C-pillar trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the C-pillar trim, replace the upper clip (C) with a new one. If the clips (D) are damaged or stress-whitened, replace them with new ones.
8. Temporarily install the C-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
9. Carefully install a new upper clip (A) to the C-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown.
10. Reinstall the C-pillar trim (A). Insert the hook (B) and the tabs (C) of the trim in the rear shelf (D). Place the trim over the C-pillar (E), and fit the upper clip (F) and the clips into the holes (G) in the C-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked down under the clips or the trim. Do not push too hard on the C-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the C-pillar trim to verify that all clips are securely fastened.
11. Reinstall the rear door opening seal (see step 4 ).

Trim Removal/Installation - Rear Shelf Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Rear Shelf

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the rear shelf, rear bulkhead cover, or the trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. Remove these items: C-pillar trims, both sides (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ) Rear center seat belt lower anchor (see «CENTER SEAT BELT AND SEAT BELT BUCKLES»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6__rear-center-seat-belt-and-seat) )
2. Fold down the rear seat-backs.
3. If the rear bulkhead cover and the rear shelf are to be removed, turn the high mount brake light socket (A) 45° counterclockwise to remove the socket from the trunk compartment.
4. Remove the rear bulkhead cover (A). Remove the belt hole cover (B) by releasing the hooks (C). Gently pull back the front edge of the cover to detach the clips (D). Pull up the cover to detach the clips (E) fastening it to the body, and the clips (F) fastening it to the rear shelf (G). Lift the cover upward and forward to release each anchor rod (H) out through the holes in the cover. Pull out both rear seat belts (I) and rear center seat belt (J) through the slits (K) and the hole (L) in the cover. Carefully move the cover above the rear wheelhouse gussets (M), then remove it.
5. Remove the rear speaker grille (A). Pry up at the notch (B) with a flat-tip screwdriver, of the grille to release the hook (C). Pull up along the edge of the grille to detach the clips and release the hooks (D). Pull back the grille to release the hooks (E) from the rear shelf (F).
6. Remove the rear shelf (A). Detach the clips with a clip remover. Lift the rear shelf upward and forward to release the rear hook (B). Slightly warp the rear shelf to release both side edges from the side curtain airbag inflators, then pull it forward. NOTE: Be careful not to damage the speakers.
7. Install the shelf in the reverse order of removal, and note these items: Remove any clips left in the body with a clip remover, and install them on the shelf. If the clips are damaged or stress-whitened, replace them with new ones. When installing the rear bulkhead cover, slip the rear seat belt through the slits, and pass the rear center seat belt through the hole in the cover properly. Make sure the high mount brake light socket is connected securely. Push the clips and the hooks into place securely.

Rear Parcel Shelf Dynamic Damper

Note. Put on gloves to protect your hands. Take care not to scratch the body.

Scheme 55

1. Remove the rear shelf.
2. Remove the bolts, then remove the rear parcel shelf dynamic damper (A). NOTE: Take care not to hit the rear window when removing the bolts.
3. Install the damper in the reverse order of removal.

Trim Removal/Installation - Trunk Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Trunk Side Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

1. Fold down the rear seat-backs.
2. Pull back the front area of the trunk floor (A), and detach the clips.
3. Remove the trunk floor (A).
4. Remove the trunk lid weatherstrip near the trunk rear trim panel (see «TRUNK LID WEATHERSTRIP REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#trunk-lid-v6) ).
5. Detach the clips (A, B), and release the hooks (C) and the tabs (D) by pulling up the trunk rear trim panel (E), then remove the panel.
6. Remove the tool box spacer (A).
7. Detach the clips (A, B), and release each tie down hook (C) out through the hole in the trunk side trim panel (D). Pull the panel out from under the rear bulkhead cover (E) and the rear seat-back (F), then remove the trim panel.
8. Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Scheme 61

Scheme 62

1. Remove the trunk side trim panel.
2. Remove the tie down hook (A).
3. Remove the spare tire.
4. Detach the clips, then remove the spare tire pan carpet (A).
5. Install the spare tire pan carpet in the reverse order of removal and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Scheme 63

Scheme 64

1. Lift the trunk floor, and unhook the hanger handle (A).
2. Lower the trunk floor, then remove the handle (A).
3. Install the handle in the reverse order of removal, and push the hooks into place securely.

Rear Wheelhouse Insulator

Note. Put on gloves to protect your hands.

Scheme 65

1. Remove the trunk side trim panel.
2. Detach the clips (A) and the harness holder (B) from the stud bolt, and detach the side wire harness clips (C), then remove the rear wheelhouse insulator (D).
3. Install the insulator in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the harness holders into place securely.

Trim Removal/Installation - Trunk Lid

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Trunk Lid Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 66

Scheme 67

Scheme 68

1. Remove the clips fastening trunk lid hinge trim A, B and the trunk lid trim panel (C), then separate the upper areas of trim A and B from the trunk hinge by releasing the hooks (D) on both sides.
2. Remove the trunk lid trim panel (A). Remove the clips (B, C, D). Remove both lower corner areas of the trim panel from under the trunk hinge trims (E). Pull the trunk lid handle (F) through the hole (G) in the trim panel, then remove the trim panel.
3. Pivot the trunk lid handle (A) down on the forward hooks (B) while prying the rear hook (C), then remove the handle.
4. Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Trunk Lid Hinge Trim

Note. Put on gloves to protect your hands. Take care not to bend or scratch the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 69

Scheme 70

1. Remove the trunk side trim panel as needed (see «TRUNK SIDE TRIM PANEL»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trunk-side-trim-panel) ).
2. Detach the clips (B, C), and remove trunk lid hinge trim A by releasing the hooks (D) from the trunk lid hinge.
3. Remove the clip, and remove trunk lid hinge trim B by releasing the hooks (A) from the trunk lid hinge (C).
4. Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Sunvisor Removal/Installation

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. Insert a flat-tip screwdriver through the hole in the front side of the bracket cover (A), and push the hook (B). Make sure the hook is unlocked.
2. While pushing in the hook (A) with a flat-tip screwdriver, release the sunvisor (B) from the holder (C), and rotate the sunvisor backward 45°. Make sure the hook slides into the bracket cover as you rotate the sunvisor.
3. Pull down the sunvisor (A) to release the pin (B) and the bracket (C) from the holes in the body. Then pull out the vanity mirror light connector (D) and disconnect it. NOTE: If the sunvisor cannot be pulled down, the hook has not rotated into the bracket cover. Repeat step 2 to rotate the hook.
4. Turn the holder (A) 45° counterclockwise, and pull it down to remove it from the holder grommet (B).
5. Pry out the holder grommet (A) from the body by pinching its hooks (B).
6. If the side curtain airbag has deployed, replace the sunvisor, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) ).
7. If the side curtain airbag has not deployed, inspect the sunvisor for damage. A damaged sunvisor may cause the side curtain airbags to deploy improperly, possibly causing injury. Replace the sunvisor if it has any of the following damage: Any cracks in the sunvisor bracket (A) Any cracks in the sunvisor bracket cover (B) Any bends or cracks in the sunvisor stay shaft (C) Any cracks in the sunvisor base (D) Any cracks in the vanity mirror base (E)
8. If the holder grommet is damaged or stress-whitened, replace the holder grommet and the holder as an assembly.
9. Install the holder (A) into the holder grommet (B) by turning it 45° clockwise, and install them into the body as an assembly by pushing it until the hooks (C) snap into place securely.
10. Connect the vanity mirror light connector (A), and install the sunvisor (B) by inserting the bracket (C) and the pin (D) of the bracket cover (E) into the hole in the body.
11. While holding the bracket cover (A), rotate the sunvisor (B) forward until the hook (C) snaps into place. Gently pull down on the sunvisor to make sure it is properly secured in the body. Rotate the sunvisor into the holder (D).

Grab Handle Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape.

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

1. Lower the grab handle (A), then insert a small flat-tip screwdriver into the notch.
2. Pull a small flat-tip screwdriver with the appropriate trim tool (A), and remove the cap (B).
3. Pinch the clips (A) to release the hooks (B), then remove the grab handle (C).
4. Pinch the hooks on the clips (A) with a pair of pliers, and pull the clips.
5. If the side curtain airbag has deployed, replace the grab handle, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) ).
6. If the side curtain airbag has not deployed, inspect the grab handle for damage. A damaged grab handle may cause the side curtain airbag to deploy improperly, possibly causing injury. Replace the grab handle if it has any of the following damage: Any cracks or damage in the grab handle (A) Any cracks or stress-whitening in the caps (B)
7. Install the clips (A) on the grab handle (B), then insert the caps (C) fully into the clips.
8. Position the grab handle (A) on the mounting bracket (B), and push on the grab handle until the clips (C) snap into place securely.

Headliner Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner, the dashboard, or the other interior trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 87

Scheme 88

Scheme 89

Scheme 90

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

Scheme 100

Scheme 101

Scheme 102

Scheme 103

Scheme 104

1. Slide both front seats all the way back, and recline the seat-back fully.
2. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before beginning work.
3. Remove these items: Kick panel, driver's side (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-door-areas) ) Driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__drivers-dashboard-lower-cover-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6) ) Driver's dashboard side panel (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-undercover-removalinstallation) ) A-pillar trims, both sides (see «A-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__a-pillar-trim) ) B-pillar upper/lower trims, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ) C-pillar trims, both sides (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ) Ceiling light (see «FRONT INDIVIDUAL MAP LIGHT TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/interiorillumination-lights/#interior-lights-v6) ) Sunvisors and holders, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__sunvisor-removalinstallation) ) Grab handles, four places (see «GRAB HANDLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__grab-handle-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-removalinstallation) ) Center holder (see «CENTER HOLDER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-holder-removalinstallation) ) Center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-pocket-removalinstallation) ) Climate control unit (see «SUNLIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-v6__sunlight-sensor-replacement) ) Side pockets, both sides (see «SIDE POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-pocket-removalinstallation) ) Parking brake lever (see «PARKING BRAKE LEVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-v6) )
4. Remove the shift lever mounting bolts (see «SHIFT LEVER INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-v6) ), then lower the lever.
5. Remove the center pocket frame (see «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboardsteering-hanger-beam-removalinstallation) ).
6. Remove the roof console (A). Remove the lenses (B). Remove the screws (C), then pull out the front individual map light (D). Disconnect the front individual map light connector (E), the moonroof switch connector (F), the HomeLink unit connector (G), and the HFL microphone connector or the HFL-navigation microphone (H). Remove the screws (I). Pull down the front side of the console, and release the rear hooks (J).
7. Remove the rearview mirror harness cover. Disconnect the connector from the rearview mirror, and release the wire harness from the rearview mirror harness cover base (see «REARVIEW MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-v6) ).
8. If necessary, pinch the hooks (A) and remove the roof console screw grommets (B).
9. If necessary, detach the hooks (C) by prying out the map light clips (D), then remove the clips.
10. Remove the roof wire harness (A) by detaching the harness clips (B) from the driver's side A-pillar, and release the lowest clip (C) with a tube holder from the front moonroof drain tube (D).
11. Remove the antenna lead (A) by detaching the harness clips (B) from the passenger's side A-pillar, and disconnect the antenna lead connector (C).
12. From under the driver's dash, remove the bolt, and release the hook (A), then move the driver's under-dash fuse/relay box (B).
13. From under the driver's dash, disconnect the roof wire harness connectors (A), and detach the harness clip (B).
14. From outside of the driver's dash, carefully pry up on the roof wire harness holder (A) with a long-handled clip remover from the stud-bolt, then pull out the roof wire harness (B) from inside the dashboard.
15. From the right C-pillar area, disconnect the antenna lead connector (A) from the AM/FM antenna amplifier (B), and detach the harness clips (C).
16. From the roof console opening, disconnect the moonroof subharness connector (A), and detach the harness clip (B).
17. With the help of an assistant, lower the headliner(A). Remove the front door opening seals (B) and the rear door opening seals (C) from each roof area. Detach the rear clips (D) by pulling down the rear area of the headliner. Detach the front clips (E) and the Velcro fasteners (F) by lowering the moonroof opening edge of the headliner.
18. With the help of an assistant, remove the headliner (A) from the vehicle. Move the headliner rearward. Lower the front of the headliner below the steering wheel. Rotate the headliner to point the front corner outside of the passenger's front door opening and the rear corner outside of the driver's front door opening. Pull the headliner along with the roof wire harness (B) and the antenna lead (C) out through the passenger's front door. NOTE: Do not bend the headliner. Bending the headliner will crease and damage it.
19. If necessary, remove the roof wire harness (A) and the antenna lead (B) from the headliner (C). Remove the front ANC/active sound control microphone (see «WITH PREMIUM AUDIO»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ). Remove the cushion tape fastening the roof wire harnesses and the antenna lead to the headliner.
20. If necessary, remove the front grab handle bracket (A) and the rear grab handle bracket (B). Remove the bolts (C, D, E). Carefully pry up a gap between the front tab plate (F) and the bracket with a flat-tip screwdriver to detach the joint (G). Repeat the preceding step at the rear tab plate (H) area to detach the plate from the bracket. Detach the clips (I). NOTE: The grab handle bracket is attached to the tab plates of the side curtain airbag. Prying up the tab plates makes it possible to remove the bracket. Take care not to damage the side curtain airbag. Front Rear
21. Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the headliner and the removed trim pieces, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the headliner and all removed trim. Replace any pieces with the following damage: Any creases or tears in the headliner (A) Any cracks or breakage in the grab handle (B) Any damage around the grab handle holes (C) or the sunvisor holes (D) in the headliner Any cracks in the sunvisor stay base (E) Any cracks in the sunvisor bracket cover (F) Any bends or cracks in the sunvisor stay shaft (G) Any cracks in the sunvisor base (H) Any cracks or breakage in the vanity mirror base (I) Any fastener bases (J), the Velcro fasteners (K), or the clip bases (L) which have come off the headliner Replace the grab handle bracket mounting 6 mm bolt with a new one if it was removed. When installing a new grab handle bracket, tighten it and tab plates together with their mounting bolts securely. Install the grab handle by pushing on the handle against the bracket (M) until the clips (N) snap into place securely. If the clips are damaged or stress-whitened, replace them with new ones. Replace the removed cushion tapes with new pieces. Be careful not to crease or damage the headliner when reinstalling it through the front passenger's door opening. Also, be careful not to scratch the body. Check that both sides of the headliner are securely attached to the body. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__checking-and-adjusting-the-headlinerpillar-trim) ). If the map light clips are removed, replace them with new ones. If the roof console screw grommets are removed or if they are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely. Reinstall the roof console (0) as the following procedures: Install the roof console screw grommets (P) on the console with the screws (Q). Connect the HomeLink unit connector (R) and the HFL microphone connector or the HFL-navigation microphone (S). Set the rear hooks (T), and fit the grommets into the holes in the body, then push on the console until the grommets snap into place securely. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ). Check for any DTCs that may have been set during repairs, and clear them. Headliner Grab handle Sunvisor Roof console

Carpet Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Take care not to damage the dashboard or other interior trim pieces. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 105

Scheme 106

Scheme 107

Scheme 108

Scheme 109

Scheme 110

Scheme 111

Scheme 112

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before beginning work.
2. Remove these items: Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__trim-removalinstallation-door-areas) ) Driver's dashboard undercover (see «DRIVER'S POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6) ) Dashboard center lower covers, both sides (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__passengers-dashboard-undercover-removalinstallation) ) B-pillar lower trims, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ) Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-v6__center-console-removalinstallation) ) Steering joint cover (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-column-removal-and-installation) ) Parking brake lever (see «PARKING BRAKE LEVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-v6) ) Shift lever (see «SHIFT LEVER REMOVAL»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-v6) ) Rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-cushion) )
3. Release the hooks (A), then remove the accelerator pedal clip (B).
4. While pushing down the back-up spring (A), pull back the accelerator pedal (B) to release the hook (C).
5. Remove the footrest (A) by pulling it to detach the clips.
6. Disconnect the yaw rate-lateral acceleration sensor connector (A) and the USB adapter unit connector (B), and detach the wire harness clips (C). Remove the ground bolt with a TORX T30 bit.
7. Remove the bolts, then remove the shift lever mount bracket (A).
8. Disconnect the SRS unit connector B, and detach the harness clips (A) fastening the floor wire harness (C).
9. Remove the carpet (A). Release the Velcro fastener (B), and release the carpet from the hooks (C) of both rear heater ducts. Detach the clips (D). Detach the clips (E) fastening the carpet to both door sill areas. Pull the seat harnesses (F) out through the holes in the carpet.
10. If necessary, release the hook (A) that is just under the arrow mark (B) on the floor mat holder (C) by prying the holder with a flat-tip screwdriver, and remove the holder through the slit (D) in the carpet (E).
11. Install the carpet in the reverse order of removal, and note these items: If the clips fastening the carpet to the floor are damaged or stress-whitened, replace them with new ones. Take care not to damage, wrinkle or twist the carpet. Make sure the floor wire harnesses are routed correctly. Slip the holes in the carpet over the rear heater ducts. Make sure each connector is plugged in properly. Replace the clips fastening the carpet to both door sill areas with new ones. Push the Velcro fastener, the hooks, and the clips into place securely. Push the accelerator pedal clip into place securely, and verify that the pedal is properly fastened to the floor. If necessary, adjust the parking brake cable (see «PARKING BRAKE INSPECTION AND ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-v6) ).

See also:
• SEAT CUSHION
• COMPONENT LOCATION INDEX
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• FRONT SEAT BELT REPLACEMENT
• SEAT SIDE BOLSTER
• CENTER SEAT BELT AND SEAT BELT BUCKLES
• TRUNK LID WEATHERSTRIP REPLACEMENT
• USING THE GR8 BATTERY DIAGNOSTIC STATION
• DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION
• DRIVER'S POCKET REMOVAL/INSTALLATION
• PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• FRONT INDIVIDUAL MAP LIGHT TEST/REPLACEMENT
• CENTER CONSOLE REMOVAL/INSTALLATION
• CENTER HOLDER REMOVAL/INSTALLATION
• CENTER POCKET REMOVAL/INSTALLATION
• SUNLIGHT SENSOR REPLACEMENT
• SIDE POCKET REMOVAL/INSTALLATION
• PARKING BRAKE LEVER REPLACEMENT
• SHIFT LEVER INSTALLATION
• DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION
• REARVIEW MIRROR REPLACEMENT
• WITH PREMIUM AUDIO
• RECONNECTION
• DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION
• FRONT SEAT REMOVAL/INSTALLATION
• STEERING COLUMN REMOVAL AND INSTALLATION
• FRONT DOOR SILL AREA
• REAR DOOR SILL AREA
• C-PILLAR TRIM
• TRUNK SIDE TRIM PANEL
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• A-PILLAR TRIM
• B-PILLAR UPPER/LOWER TRIM
• SUNVISOR REMOVAL/INSTALLATION
• GRAB HANDLE REMOVAL/INSTALLATION
