Interior Trim (4-cyl) — Acura TSX II (2008-2014)

Scheme 160

Scheme 160: Component Location Index - Sedan

Scheme 161

Scheme 161: Component Location Index - Sport Wagon

Scheme 162

Trim Removal/Installation - Door Areas

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Front Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 163

Scheme 163: Front Door Sill Area

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Remove the front door sill trim (A). Release the hooks (B) and the tabs (C) from the kick panel (D) and the B-pillar lower trim (E). Pull up the trim by hand to detach the clips.
If necessary, pull up the front side outer trim (A) to release the hooks, then remove the trim.
Remove the kick panel (A). Pull out the front door opening seal (B) as needed from the kick panel hooks (C). Pull the kick panel back by hand to detach the clips (D, E). Driver's side Passenger's side
Pull out the front door opening seal (A) from the trim hooks (B) around the front door opening flange, then remove the seal.
Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tabs into place securely.

Rear Door Sill Area

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 168

Scheme 168: Rear Door Sill Area

Scheme 169

Scheme 170

Remove the rear seat cushion: Sedan (see «REAR SEAT REMOVAL/INSTALLATION - SEDAN»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Sport Wagon (see «REAR SEAT REMOVAL/INSTALLATION - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) )
Remove the rear door sill trim (A). Release the hooks (B) and the tab (C) from the B-pillar lower trim (D). Pull up the trim by hand to detach the clips (E, F).
If necessary, pull up the rear side outer trim (A) to release the hooks, then remove the trim.
Pull out the rear door opening seal (A) from the trim hooks (B) around the rear door opening flange, then remove the seal. NOTE: Sedan is shown; Sport Wagon is similar.
Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, the hooks, and the tab into place securely.

Trim Removal/Installation - Pillar Areas - Sedan

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

A-Pillar Trim

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to Component Replacement/Inspection After Deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the A-pillar trim (B) consists of a resin grommet (C) and a metal pin (D). The grommet expands when the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 171

Scheme 171: A-Pillar Trim

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Pull the front door opening seal away from the A-pillar as needed (see step 4 on ).
Hit the upper clip (A) in the A-pillar trim (B) with a rubber mallet. The clip is located under the point where the triangle mark (C) on the edge of the trim indicates. Hitting the clip breaks the projections (D) on the pin (E) and pushes it into the grommet (F) on the body (G). NOTE: The upper clip must be replaced with a new one when the A-pillar trim is reinstalled.
Pull back the top of the A-pillar trim (A) by hand to remove the upper clip (B) from the body (C).
Pull out the A-pillar trim (A) by hand to detach the clip. Pull up the trim from the dashboard (B), then remove the trim.
If the side curtain airbag has been deployed, replace the A-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ).
If the side curtain airbag has not deployed, check the A-pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the A-pillar trim, replace the upper clip (C) with a new one. If the clip (D) is damaged or stress-whitened, replace it with a new one.
Temporarily install the A-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
Carefully install the new upper clip (A) to the A-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown.
Reinstall the A-pillar trim (A). Insert the bottom of the trim into the dashboard (B). Place the trim over the A-pillar (C), and fit its upper clip (D), the clip, and the pin (E) into the holes (F) in the A-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked down under the clips or the trim. Do not push too hard on the A-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the A-pillar trim to verify that all clips are securely fastened.
Reinstall the door opening seal (see step 4 on ).

B-Pillar Upper/Lower Trim

Scheme 177

Scheme 177: B-Pillar Upper/Lower Trim

Scheme 178

Scheme 179

Scheme 180

Scheme 181

Remove these items: Front door sill trim (see «FRONT DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__front-door-sill-area) ) Rear door sill trim (see «CARGO AREA SIDE TRIM PANEL»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__cargo-area-side-trim-panel) ) Front door opening seal, as needed (see step 4 on ) Rear door opening seal, as needed (see step 4 on )
Slide the front seat forward fully.
Remove the B-pillar lower trim (A). While releasing the upper tabs (B), pull back the upper area of the trim to release the upper hooks (C). Detach the clips by pulling back the bottom of the trim by hand.
Remove the front seat belt lower anchor from the front seat (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl) ).
Remove the B-pillar upper trim (A). Pull back the bottom of the trim by hand to release the lower hooks (B). Pull back the bottom of the trim to release the upper pin (C) from the hole in the body and the slider (D) from the pin (E) on the front seat belt shoulder anchor adjuster. Pull down the trim to release the upper hooks (F) from the holes in the body.
Pass the front seat belt lower anchor (A) out through a hole in the slider (B), then remove the B-pillar upper trim (C).
Install the trim in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the B-pillar upper trim (A), the B-pillar lower trim (B), and all of the clips (C) on the trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it with a new one if it has any of the following damage: Any cracks or deformations in the B-pillar upper trim and the upper hooks (D), and any stress-whitened areas in the upper part of the trim Any cracks or deformations in the B-pillar lower trim, and any breakage in the area (E) that overlaps the B-pillar upper trim Any cracks or stress-whitening in the clip seating surface (F) If the clips are damaged or stress-whitened, replace them with new ones. Replace any damaged parts with new ones. Make sure the top of the B-pillar upper trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). Make sure the pin (G) on the front seat belt shoulder anchor adjuster (H) and the hole (I) on the back of the slider are engaged when installing the B-pillar upper trim. Make sure the upper hooks are installed into the holes in the body securely. Push the clips and the hooks into place securely. Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt. Trim inspection Slider engagement with shoulder anchor adjuster G

C-Pillar Trim

Note. If side airbags and/or side curtain airbags have deployed, the affected pillar area trim and attachment clips must be replaced. Refer to Component Replacement/Inspection After Deployment (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Put on gloves to protect your hands. Take care not to scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. The upper clip (A) in the C-pillar trim (B) consists of a resin grommet (C) and a metal pin (D). The grommet expands when the pin secures it to the body panel (E). The projections (F) on the pin break during removal, so the upper clip must be replaced with a new one when the trim is reinstalled.

Scheme 182

Scheme 182: C-Pillar Trim

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Remove these items: Rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-cushion) ) Rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-side-bolster) ) Rear door opening seal, as needed (see step 4 on )
Fold down the seat-back.
Hit the upper clip (A) in the C-pillar trim (B) with a rubber mallet. The clip is located under the point where the triangle mark (C) on the edge of the trim indicates. Hitting the clip breaks the projections (D) on the pin (E) and pushes it into the grommet (F) and against the body (G). NOTE: The upper clip must be replaced with a new one when the C-pillar trim is reinstalled.
Pull back the top of the C-pillar trim (A) by hand to remove the upper clip (B) from the body (C).
Pull the C-pillar trim (A) by hand to detach the clips and to release the hook (B) and the tabs (C), then pull out the trim from the rear shelf (D).
If the side curtain airbag has deployed, replace the C-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ).
If the side curtain airbag has not been deployed, check the C-pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the C-pillar trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the C-pillar trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the C-pillar trim, replace the upper clip (C) with a new one. If the clips (D) are damaged or stress-whitened, replace them with new ones
Temporarily install the C-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
Carefully install a new upper clip (A) to the C-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown.
Reinstall the C-pillar trim (A). Insert the hook (B) and the tabs (C) of the trim in the rear shelf (D). Place the trim over the C-pillar (E), and fit the upper clip (F) and the clips into the holes (G) in the C-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked down under the clips or the trim. Do not push too hard on the C-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the C-pillar trim to verify that all clips are securely fastened.
Reinstall the rear door opening seal (see step 4 on ).

Trim Removal/Installation - Pillar Areas - Sport Wagon

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Scheme 188

Scheme 188: A-Pillar Trim

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Pull the front door opening seal away from the A-pillar as needed (see step 4 on ).
Hit the upper clip (A) in the A-pillar trim (B) with a rubber mallet. The clip is located under the point where the triangle mark (C) on the edge of the trim indicates. Hitting the clip breaks the projections (D) on the pin (E) and pushes it into the grommet (F) on the body (G). NOTE: The upper clip must be replaced with a new one when the A-pillar trim is reinstalled.
Pull back the top of the A-pillar trim (A) by hand to remove the upper clip (B) from the body (C).
Pull out the A-pillar trim (A) by hand to detach the clip. Pull up the trim from the dashboard (B), then remove the trim.
If the side curtain airbag has been deployed, replace the A-pillar trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ).
If the side curtain airbag has not deployed, check the A-pillar trim (A) and note the following items: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it with a new one if it has any of the following damage: Any cracks, deformations, or stress-whitened areas in the trim Any cracks or stress-whitening in the clip seating surfaces (B) After checking and adjusting the overlap between the headliner and the A-pillar trim, replace the upper clip (C) with a new one. If the clip (D) is damaged or stress-whitened, replace it with a new one.
Temporarily install the A-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). Remove the trim, and if necessary, adjust the overlap.
Carefully install the new upper clip (A) to the A-pillar trim (B). Be sure that the grommet (C) is nearest to the top of the pin (D) as shown.
Reinstall the A-pillar trim (A). Insert the bottom of the trim into the dashboard (B). Place the trim over the A-pillar (C), and fit its upper clip (D), the clip, and the pin (E) into the holes (F) in the A-pillar, then lightly push the trim into place. NOTE: Make sure the side curtain airbag is not tucked down under the clips or the trim. Do not push too hard on the A-pillar trim. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Gently tug on the A-pillar trim to verify that all clips are securely fastened.
Reinstall the door opening seal (see step 4 on ).

Scheme 194

Scheme 194: B-Pillar Upper/Lower Trim

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Remove these items: Front door sill trim (see «FRONT DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__front-door-sill-area) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-door-sill-area) ) Front door opening seal, as needed (see step 4 on ) Rear door opening seal, as needed (see step 4 on )
Slide the front seat forward fully.
Remove the B-pillar lower trim (A). While releasing the upper tabs (B), pull back the upper area of the trim to release the upper hooks (C). Detach the clips by pulling back the bottom of the trim by hand.
Remove the front seat belt lower anchor from the front seat (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl) ).
Remove the B-pillar upper trim (A). Pull back the bottom of the trim by hand to release the lower hooks (B). Pull back the bottom of the trim to release the upper pin (C) from the hole in the body and the slider (D) from the pin (E) on the front seat belt shoulder anchor adjuster. Pull down the trim to release the upper hooks (F) from the holes in the body.
Pass the front seat belt lower anchor (A) out through a hole in the slider (B), then remove the B-pillar upper trim (C).
Install the trim in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the B-pillar upper trim (A), the B-pillar lower trim (B), and all of the clips (C) on the trim, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it with a new one if it has any of the following damage: Any cracks or deformations in the B-pillar upper trim and the upper hooks (D), and any stress-whitened areas in the upper part of the trim Any cracks or deformations in the B-pillar lower trim, and any breakage in the area (E) that overlaps the B-pillar upper trim Any cracks or stress-whitening in the clip seating surface (F) If the clips are damaged or stress-whitened, replace them with new ones. Replace any damaged parts with new ones. Make sure the top of the B-pillar upper trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). Make sure the pin (G) on the front seat belt shoulder anchor adjuster (H) and the hole (I) on the back of the slider are engaged when installing the B-pillar upper trim. Make sure the upper hooks are installed into the holes in the body securely. Push the clips and the hooks into place securely. Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt. Trim inspection Slider engagement with shoulder anchor adjuster G

Quarter Pillar Trim

Scheme 199

Scheme 199: Quarter Pillar Trim

Scheme 200

Scheme 201

Remove the tailgate weatherstrip as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#tailgate-4-cyl) ).
Release the hooks (A) and the tabs (B) from the quarter pillar trim (C) on either side, and pull the roof end trim (D) down by hand to detach the clips (E, F, G), then remove it.
Remove the cargo area side trim panel (see «REAR PARCEL SHELF DYNAMIC DAMPER»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__rear-parcel-shelf-dynamic-damper) ).
Remove the quarter pillar trim (A). Pull the front area of the quarter pillar trim back by hand to detach the clip (B) and the pin (C). Pull the rear area of the quarter pillar trim back by hand to detach the clips (D). Pull down the trim to detach the clips (E), and to release the upper hooks (F, G) from the headliner (H) and the upper hook (I) from a body hole.
Install the trim in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the quarter pillar trim (A), along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it if it has any of the following damage: Any cracks or deformations in the quarter pillar trim and the upper hook (B), and any stress-whitened areas in the upper part of the trim Any cracks, or stress-whitening in the clip seating surfaces (C) If the clips (D) are damaged or stress-whitened, replace them with new ones. Replace any damaged parts with new ones. Make sure the top of the trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). Make sure the trim hook is installed into the hole in the body securely. Push the clips and the pin into place securely.

Trim Removal/Installation - Rear Shelf Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Rear Shelf

Note. Put on gloves to protect your hands. Take care not to bend or scratch the rear shelf, rear bulkhead cover, or the trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 202

Scheme 202: Rear Shelf

Scheme 203

Scheme 204

Scheme 205

Remove these items: C-pillar trims, both sides (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__c-pillar-trim) ) Rear center seat belt lower anchor (see «REAR CENTER SEAT BELT AND REAR SEAT BELT BUCKLES»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl__rear-center-seat-belt-and-rear) )
Fold down the rear seat-backs.
If the rear bulkhead cover and the rear shelf are to be removed, turn the high mount brake light socket (A) 45° counterclockwise to remove the socket from the trunk compartment.
Remove the rear bulkhead cover (A). Remove the belt hole cover (B) by releasing the hooks (C). Gently pull back the front edge of the cover to detach the clips (D). Pull up the cover to detach the clips (E) fastening it to the body, and the clips (F) fastening it to the rear shelf (G). Lift the cover upward and forward to release each anchor rod (H) out through the holes in the cover. Pull out both rear seat belts (I) and rear center seat belt (J) through the slits (K) and the hole (L) in the cover. Carefully move the cover above the rear wheel house gussets (M), then remove it.
Remove the rear speaker grille (A). Pry up at the notch (B) with a flat-tip screwdriver, of the grille to release the hook (C). Pull up along the edge of the grille to detach the clips and release the hooks (D). Pull back the grille to release the hooks (E) from the rear shelf (F).
Remove the rear shelf (A). Detach the clips with a clip remover. Lift the rear shelf upward and forward to release the rear hook (B). Slightly warp the rear shelf to release both side edges from the side curtain airbag inflators, then pull it forward. NOTE: Be careful not to damage the speakers.
Install the shelf in the reverse order of removal, and note these items: Remove any clips left in the body with a clip remover, and install them on the shelf. If the clips are damaged or stress-whitened, replace them with new ones. When, installing the rear bulkhead cover, slip the rear seat belt through the slits, and pass the rear center seat belt through the hole in the cover properly. Make sure the high mount brake light socket is connected securely. Push the clips and the hooks into place securely.

Rear Parcel Shelf Dynamic Damper

Note. Put on gloves to protect your hands. Take care not to scratch the body.

Scheme 206

Scheme 206: Rear Parcel Shelf Dynamic Damper

Remove the rear shelf.
Remove the bolts, then remove the rear parcel shelf dynamic damper (A). NOTE: Take care not to hit the rear window when removing the bolts.
Install the damper in the reverse order of removal.

Trim Removal/Installation - Rear Side Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Cargo Area Side Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 207

Scheme 207: Cargo Area Side Trim Panel

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Remove the tonneau cover (A).
Remove these items: Tailgate weatherstrip, as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#tailgate-4-cyl) ) Rear under floor cover (see «TRIM REMOVAL/INSTALLATION - CARGO AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-cargo-area) ) Rear seat cushion (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Rear seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Rear seat belt lower anchor (see step 2 on «REAR SEAT BELT REPLACEMENT - SPORT WAGON»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl) )
Pull up the damper maintenance lid (A) by hand to release the hooks (B), then remove the lid.
Remove the rear seat belt anchor wire (see step 6 on «REAR CENTER SEAT BELT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl__rear-center-seat-belt) ).
Remove the floor side lid (A).
Left side: Remove the cargo area side lid (A).
Pry out the cover (A) and remove the bolt (B), then remove the tie down hooks (C) and the convenience hook (D).
Remove the floor lid clip (A) by pinching its tabs (B).
Remove the cargo area side trim panel (A). Remove the clip (B) from the front area of the trim panel. Pull the upper edge of the trim panel back to release the upper hooks (C) and the tab (D) from the quarter pillar trim (E). Pull out the trim panel back by hand to detach the clips (F, G, H). Pull the front area of the trim panel inward to release it from the sear seat-back striker (I). Disconnect the cargo area light connector (J) and the cargo area accessory power socket connector (K) on the left side. Remove the front lower corner of the trim panel from under the rear seat-back. Carefully move the trim panel inward, and remove it.
If necessary, remove the bolts (A, B) and detach the connector clip (C), then remove the front lid support (D) and the rear lid support (E).
Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Make sure each connector is plugged in properly. Push the clips, the hooks, and the tabs into place securely.

Rear Wheelhouse Insulator

Note. Put on gloves to protect your hands.

Scheme 215

Scheme 215: Rear Wheelhouse Insulator

Remove the cargo area side trim panel.
Detach the clips (A) and the harness holder (B) from the stud bolt, and detach the side wire harness clips (C), then remove the rear wheelhouse insulator (D).
Install the insulator in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the harness holder into place securely.

Trim Removal/Installation - Trunk Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Trunk Side Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim or the panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 216

Scheme 216: Trunk Side Trim Panel

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Fold down the rear seat-backs.
Pull back the front area of the trunk floor (A), and detach the clips.
Remove the trunk floor (A).
Remove the trunk lid weatherstrip near the trunk rear trim panel (see «TRUNK LID WEATHERSTRIP REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#trunk-lid-4-cyl) ).
Detach the clips (A, B), and release the hooks (C) and the tabs (D) by pulling up the trunk rear trim panel (E), then remove the panel.
Remove the tool box spacer (A).
Detach the clips (A, B), and release each tie down hook (C) out through the hole in the trunk side trim panel (D). Pull the panel out from under the rear bulkhead cover (E) and the rear seat-back (F), then remove the trim panel.
Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Scheme 221

Scheme 221: Spare Tire Pan Carpet

Scheme 222

Remove the trunk side trim panel.
Remove the tie down hook (A).
Remove the spare tire.
Detach the clips, then remove the spare tire pan carpet (A).
Install the spare tire pan carpet in the reverse order of removal and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Scheme 223

Scheme 223: Trunk Floor Hanger Handle

Scheme 224

Lift the trunk floor, and unhook the hanger handle (A).
Lower the trunk floor, then remove the handle {A).
Install the handle in the reverse order of removal, and push the hooks into place securely.

Note. Put on gloves to protect your hands.

Scheme 225

Scheme 225: Rear Wheelhouse Insulator

Remove the trunk side trim panel.
Detach the clips (A) and the harness holder (B) from the stud bolt, and detach the side wire harness clips (C), then remove the rear wheelhouse insulator (D).
Install the insulator in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the harness holders into place securely.

Trim Removal/Installation - Trunk Lid

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Trunk Lid Trim Panel

Note. Put on gloves to protect your hands, Take care not to bend or scratch the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 226

Scheme 226: Trunk Lid Trim Panel

Scheme 227

Scheme 228

Remove the clips fastening trunk lid hinge trim A, B and the trunk lid trim panel (C), then separate the upper areas of trim A and B from the trunk hinge by releasing the hooks (D) on both sides.
Remove the trunk lid trim panel (A). Remove the clips (B, C, D). Remove both lower corner areas of the trim panel from under the trunk hinge trims (E). Pull the trunk lid handle (F) through the hole (G) in the trim panel, then remove the trim panel.
Pivot the trunk lid handle (A) down on the forward hooks (B) while prying the rear hook (C), then remove the handle.
Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Trunk Lid Hinge Trim

Note. Put on gloves to protect your hands. Take care not to bend or scratch the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 229

Scheme 229: Trunk Lid Hinge Trim

Scheme 230

Remove the trunk side trim panel as needed (see «TRUNK SIDE TRIM PANEL»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trunk-side-trim-panel) ).
Detach the clips (B, C), and remove trunk lid hinge trim A by releasing the hooks (D) from the trunk lid hinge.
Remove the clip, and remove trunk lid hinge trim B by releasing the hooks (A) from the trunk lid hinge (C).
Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Trim Removal/Installation - Cargo Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 231

Scheme 231: Trim Removal/Installation - Cargo Area

Scheme 232

Scheme 233

Scheme 234

Scheme 235

Scheme 236

Remove the tonneau cover (see step 1 on ).
Fold down both rear seat-backs.
Release the Velcro fasteners (A) from both rear seat-backs (B). Pull back the Velcro fasteners, then attach them on the rear floor mat (C) as shown. Pull back the front area of the rear floor lid (D) to detach the clips, then turn the front section upside down to release the hooks (E) from both front lid supports (F).
Remove the rear floor lid (A).
Remove the rear floor bucket (A).
Remove the tool box spacer (A).
Remove the tailgate weatherstrip near the rear trim panel as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#tailgate-4-cyl) ).
Detach the clips (A, B), and release the hooks (C) and the tabs (D) from the cargo area side trim panels (E) by pulling the rear trim panel (F) up, then remove it.
If necessary, remove the clips, then remove the rear under floor cover (A).
Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely.

Scheme 237

Scheme 237: Rear Floor Lid Handle

Remove the rear floor lid.
Remove the screws, then remove the handle case (A) and the handle (B) from the rear floor lid.
Install the handle in the reverse order of removal.

Trim Removal/Installation - Tailgate Area

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Tailgate Trim Panel

Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 238

Scheme 238: Tailgate Trim Panel

Scheme 239

Scheme 240

Remove the tailgate upper trim (A). Release the hooks (B) and the tabs (C) from the left tailgate side trim (D) and the right tailgate side trim (E). Pull the upper trim back by hand to detach the clips, then remove it.
Remove the left tailgate side trim (A) and the right tailgate side trim (B). Pull out the top of the side trim to detach the clips. Release the hooks (C) and the tabs (D) from the tailgate lower trim panel (E).
With power tailgate: Remove the inside tailgate switch (see «DRIVER'S DOOR POWER TAILGATE SWITCH TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#power-tailgate-4-cyl) ).
Remove the tailgate lower trim panel (A). Remove the screws (B) from both pull pockets. Detach the clips (C) beside the tailgate latch. Pull down the trim panel to detach all of the clips (D). Release both upper corner areas of the trim panel from the edge of the tailgate flange.
Install the trim panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. With power tailgate: Make sure the inside tailgate switch connector is plugged in properly. Push the clips and the hooks into place securely.

Tailgate Hinge Trim

Note. Put on gloves to protect your hands. Take care not to bend or scratch the panel. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 241

Scheme 241: Tailgate Hinge Trim

Scheme 242

Remove these items: Tonneau cover (see step 1 on ) Tailgate weatherstrip (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#tailgate-4-cyl) ) Quarter pillar trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__b-pillar-upperlower-trim) ) Tailgate side trim
Remove the tailgate hinge trim (A). Lower the trim to release three hooks (B) from convex areas (C) in the tailgate hinge arm (D). Right side: Release the rear window washer tube (E) from the hooks (F) and the ribs (G). NOTE: The right tailgate hinge trim is shown; the left tailgate hinge trim is similar, however, the rear window washer tube is routed on only right side.
Install the trim in the reverse order of removal, and note these items: Right side: Align the tube joint (A) and the mark (B) on the rear window washer tube (C) with the hooks (D) as shown. Make sure the washer tube is routed in the trim properly without being pinched. When installing the trim, fit the three inside hooks to concaved areas in the hinge arm, then gradually slide the hinge trim up to fit the hooks to the convex areas in the hinge arm. Make sure the tailgate wire harness is routed in the trim properly.

Sunvisor Removal/Installation

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 243

Scheme 243: Sunvisor Removal/Installation

Scheme 244

Scheme 245

Scheme 246

Scheme 247

Scheme 248

Scheme 249

Scheme 250

Scheme 251

Insert a flat-tip screwdriver through the hole in the front side of the bracket cover (A), and push the hook (B). Make sure the hook is unlocked.
While pushing in the hook (A) with a flat-tip screwdriver, release the sunvisor (B) from the holder (C), and rotate the sunvisor backward 45°. Make sure the hook slides into the bracket cover as you rotate the sunvisor.
Pull down the sunvisor (A) to release the pin (B) and the bracket (C) from the holes in the body. Then pull out the vanity mirror light connector (D) and disconnect it. NOTE: If the sunvisor cannot be pulled down, the hook has not rotated into the bracket cover. Repeat step 2 to rotate the hook.
Turn the holder (A) 45° counterclockwise, and pull it down to remove it from the holder grommet (B).
Pry out the holder grommet (A) from the body by pinching its hooks (B).
If the side curtain airbag has deployed, replace the sunvisor, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ).
If the side curtain airbag has not deployed, inspect the sunvisor for damage. A damaged sunvisor may cause the side curtain airbags to deploy improperly, possibly causing injury. Replace the sunvisor if it has any of the following damage: Any cracks in the sunvisor bracket (A) Any cracks in the sunvisor bracket cover (B) Any bends or cracks in the sunvisor stay shaft (C) Any cracks in the sunvisor base (D) Any cracks in the vanity mirror base (E)
If the holder grommet is damaged or stress-whitened, replace the holder grommet and the holder as an assembly.
Install the holder (A) into the holder grommet (B) by turning it 45° clockwise, and install them into the body as an assembly by pushing it until the hooks (C) snap into place securely.
Connect the vanity mirror light connector (A), and install the sunvisor (B) by inserting the bracket (C) and the pin (D) of the bracket cover (E) into the hole in the body.
While holding the bracket cover (A), rotate the sunvisor (B) forward until the hook (C) snaps into place. Gently pull down on the sunvisor to make sure it is properly secured in the body. Rotate the sunvisor into the holder (D).

Grab Handle Removal/Installation

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 252

Scheme 252: Grab Handle Removal/Installation

Scheme 253

Scheme 254

Scheme 255

Scheme 256

Scheme 257

Scheme 258

Lower the grab handle (A), then insert a small flat-tip screwdriver into the notch.
Pull a small flat-tip screwdriver with the appropriate trim tool (A), and remove the cap (B).
Pinch the clips (A) to release the hooks (B), then remove the grab handle (C).
Pinch the hooks on the clips (A) with a pair of pliers, and pull the clips.
If the side curtain airbag has deployed, replace the grab handle, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ).
If the side curtain airbag has not deployed, inspect the grab handle for damage. A damaged grab handle may cause the side curtain airbag to deploy improperly, possibly causing injury. Replace the grab handle if it has any of the following damage: Any cracks or damage in the grab handle (A) Any cracks or stress-whitening in the caps (B)
Install the clips (A) on the grab handle (B), then insert the caps (C) fully into the clips.
Position the grab handle (A) on the mounting bracket (B), and push on the grab handle until the clips (C) snap into place securely.

Headliner Removal/Installation - Sedan

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend or scratch the headliner. Be careful not to damage the dashboard or the other interior trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 259

Scheme 259: Headliner Removal/Installation - Sedan

Scheme 260

Scheme 261

Scheme 262

Scheme 263

Scheme 264

Scheme 265

Scheme 266

Scheme 267

Scheme 268

Scheme 269

Scheme 270

Scheme 271

Scheme 272

Scheme 273

Scheme 274

Scheme 275

Scheme 276

Slide both front seats all the way back, and recline the seat-back fully.
Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl) ), then wait at least 3 minutes before beginning work.
Remove these items: Kick panel, driver's side (see «FRONT DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__front-door-sill-area) ) Driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-lower-cover-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-undercover-removalinstallation) ) Driver's dashboard side panel (see step 1 on «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__passengers-dashboard-undercover-removalinstallation) ) A-pillar trims, both sides (see «A-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__a-pillar-trim) ) B-pillar upper/lower trims, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__b-pillar-upperlower-trim) ) C-pillar trims, both sides (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__c-pillar-trim) ) Ceiling light (see «FRONT INDIVIDUAL MAP LIGHT TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/interiorillumination-lights/#interior-lights-4-cyl) ) Sunvisors and holders, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__sunvisor-removalinstallation) ) Grab handles, four places (see «GRAB HANDLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__grab-handle-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-removalinstallation) ) Center holder (see «CENTER HOLDER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-holder-removalinstallation) ) Center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__center-pocket-removalinstallation) ) Climate control unit (see «CLIMATE CONTROL UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-hvac-system/#climate-control-4-cyl) ) Side pockets, both sides (see «SIDE POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__side-pocket-removalinstallation) ) Parking brake lever (see «PARKING BRAKE LEVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-4-cyl) )
A/T: Remove the shift lever mounting bolts (see step 8 on «SHIFT LEVER INSTALLATION»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-4-cyl) ), then lower the lever.
Remove the center pocket frame (see step 5 on «DASHBOARD/STEERING HANGER BEAM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__dashboardsteering-hanger-beam-removalinstallation) ).
Remove the roof console (A). Remove the lenses (B). Remove the screws (C), then pull out the front individual map light (D). Disconnect the front individual map light connector (E), the moonroof switch connector (F), the HomeLink unit connector (G), and the HFL microphone connector or the HFL-navigation microphone (H). Remove the screws (I). Pull down the front side of the console, and release the rear hooks (J).
Remove the rearview mirror harness cover; Disconnect the connector from the rearview mirror, and release the wire harness from the rearview mirror harness cover base (see «REARVIEW MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-4-cyl) ).
If necessary, pinch the hooks (A) and remove the roof console screw grommets (B).
If necessary, release the hooks (C) by prying out the map light clips (D), then remove the clips.
Remove the roof wire harness (A) by detaching the harness clips (B) from the driver's side A-pillar, and release the lowest clip (C) with a tube holder from the front moonroof drain tube (D).
Remove the antenna lead (A) by detaching the harness clips (B) from the passenger's side A-pillar, and disconnect the antenna lead connector (C).
From under the driver's dash, remove the bolt, and release the hook (A), then move the driver's under-dash fuse/relay box (B).
From under the driver's dash, disconnect the roof wire harness connectors (A), and detach the harness clip (B).
From outside of the driver's dash, carefully pry up on the roof wire harness holder (A) with a long-handled clip remover from the stud-bolt, then pull out the roof wire harness (B) from inside the dashboard.
From the right C-pillar area, disconnect the antenna lead connector (A) from the AM/FM antenna amplifier (B), and detach the harness clips (C).
From the roof console opening, disconnect the moonroof subharness connector (A), and detach the harness clip (B).
With the help of an assistant, lower the headliner (A). Remove the front door opening seals (B) and the rear door opening seals (C) from each roof area. Detach the rear clips (D) by pulling down the rear area of the headliner. Detach the front clips (E) and the Velcro fasteners (F) by lowering the moonroof opening edge of the headliner.
With the help of an assistant, remove the headliner (A) from the vehicle. Move the headliner rearward. Lower the front of the headliner below the steering wheel. Rotate the headliner to point the front corner outside of the passenger's front door opening and the rear corner outside of the driver's front door opening. Pull the headliner along with the roof wire harness (B) and the antenna lead (C) out through the passenger's front door. NOTE: Do not bend the headliner. Bending the headliner will crease and damage it.
If necessary, remove the cushion tape fastening the roof wire harness (A) and the antenna lead (B) to the headliner (C), then remove them from the headliner.
If necessary, remove the front grab handle bracket (A) and the rear grab handle bracket (B). Remove the bolts (C, D, E). Carefully pry up a gap between the front tab plate (F) and the bracket with a flat-tip screwdriver to detach the joint (G). Repeat the preceding step at the rear tab plate (H) area to detach the plate from the bracket. Detach the clips (I). NOTE: The grab handle bracket is attached to the tab plates of the side curtain airbag. Prying up the tab plates makes it possible to remove the bracket. Take care not to damage the side curtain airbag. Front Rear
Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the headliner and the removed trim pieces, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the headliner and all removed trim. Replace any pieces with the following damage: Any creases or tears in the headliner (A) Any cracks or breakage in the grab handle (B) Any damages around the grab handle holes (C) or the sunvisor holes (D) in the headliner Any cracks in the sunvisor stay base (E) Any cracks in the sunvisor bracket cover (F) Any bends or cracks in the sunvisor stay shaft (G) Any cracks in the sunvisor base (H) Any cracks or breakage in the vanity mirror base (I) Any fastener bases (J), the Velcro fasteners (K), or the clip bases (L) which have come off the headliner Replace the grab handle bracket mounting 6 mm bolt with a new one if it was removed. When installing a new grab handle bracket, tighten it and tab plates together with their mounting bolts securely. Install the grab handle by pushing on the handle against the bracket (M) until the clips (N) snap into place securely. If the clips are damaged or stress-whitened, replace them with new ones. Replace the removed cushion tapes with new pieces. Be careful not to crease or damage the headliner when reinstalling it through the front passenger's door opening. Also, be careful not to scratch the body. Check that both sides of the headliner are securely attached to the body. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). If the map light clips are removed, replace them with new ones. If the roof console screw grommets are removed or if they are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely. Reinstall the roof console (0) as the following procedures: Install the roof console screw grommets (P) on the console with the screws (Q). Connect the HomeLink unit connector (R) and the HFL microphone connector or the HFL-navigation microphone(s). Set the rear hooks (T), and fit the grommets into the holes in the body, then push on the console until the grommets snap into place securely. Do the battery terminal reconnection procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl__battery-removal-and-installation) ). Check for any DTCs that may have been set during repairs, and clear them. Headliner Grab handle Sunvisor Roof console

Headliner Removal/Installation - Sport Wagon

Special Tools Required

KTC Trim Tool Set SOJATP2014*

* Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to bend and scratch the headliner. Be careful not to damage the dashboard and other interior trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 277

Scheme 277: Headliner Removal/Installation - Sport Wagon

Scheme 278

Scheme 279

Scheme 280

Scheme 281

Scheme 282

Scheme 283

Scheme 284

Scheme 285

Scheme 286

Scheme 287

Scheme 288

Scheme 289

Scheme 290

Scheme 291

Scheme 292

Scheme 293

Scheme 294

Scheme 295

Slide both front seats all the way back, and recline the seat-back fully.
Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl) ), then wait at least 3 minutes before beginning work.
Remove these items: Kick panel, driver's side (see «FRONT DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__front-door-sill-area) ) Driver's dashboard lower cover (see «DRIVER'S DASHBOARD LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-lower-cover-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-undercover-removalinstallation) ) Driver's dashboard side panel (see step 1 on «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__passengers-dashboard-undercover-removalinstallation) ) A-pillar trims, both sides (see «A-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl) ) B-pillar upper/lower trims, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl) ) Quarter pillar trims, both sides (see «QUARTER PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__quarter-pillar-trim) ) Ceiling light (see «FRONT INDIVIDUAL MAP LIGHT TEST/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/interiorillumination-lights/#interior-lights-4-cyl) ) Rear center seat belt cover (see step 1 on «REAR CENTER SEAT BELT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-4-cyl__rear-center-seat-belt) ) Sunvisors and holders, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__sunvisor-removalinstallation) ) Grab handles, four places (see «FRONT DOOR SILL AREA»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__front-door-sill-area) )
Remove the roof console (A). Remove the lenses (B). Remove the screws (C), then pull out the front individual map light (D). Disconnect the front individual map light connector (E), the moonroof switch connector (F), the HomeLink unit connector (G), and the HFL microphone connector or the HFL-navigation microphone (H). Remove the screws (I). Pull down the front side of the console, and release the rear hooks (J).
Remove the rearview mirror harness cover. Disconnect the connector from the rearview mirror, and release the wire harness from the rearview mirror harness cover base (see «REARVIEW MIRROR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mirrors/#mirrors-4-cyl) ).
If necessary, pinch the hooks (A) and remove the roof console screw grommets (B).
If necessary, release the hooks (C) by prying out the map light clips (D), then remove the clips.
Remove the roof wire harness (A) by detaching the harness clips (B) from the driver's side A-pillar, and release the lowest clip (C) with a tube holder from the front moonroof drain tube (D).
Remove the antenna lead (A) by detaching the harness clips (B) from the passenger's side A-pillar, and disconnect the antenna lead connector (C).
From under the driver's dash, remove the bolt, and release the hook (A), then move the driver's under-dash fuse/relay box (B).
From under the driver's dash, disconnect the roof wire harness connectors (A), and detach the harness clip (B).
From outside of the driver's dash, carefully pry up on the roof wire harness holder (A) with a long-handled clip remover from the stud-bolt, then pull out the roof wire harness (B) from inside the dashboard.
From the left rear corner area, disconnect and detach the antenna lead connector (A).
From the right rear corner area, disconnect and detach the antenna lead connector (A).
From the roof console opening, disconnect the moonroof subharness connector (A), and detach the harness clip (B).
With the help of an assistant, lower the headliner (A). Remove the front door opening seals (B) and the rear door opening seals (C) from each roof area. Detach the rear clips (D) by pulling down the rear area of the headliner. Detach the front clips (E) and the Velcro fasteners (F) by lowering the moonroof opening edge of the headliner.
With the help of an assistant, remove the headliner (A) along with the roof wire harness (B) and the antenna lead (C) out through the tailgate opening. NOTE: Do not bend the headliner. Bending the headliner will crease and damage it.
If necessary, remove the cushion tape fastening the roof wire harness (A) and the antenna lead (B) to the headliner (C), then remove them from the headliner.
If necessary, remove the front grab handle bracket (A) and the rear grab handle bracket (B). Remove the bolts (C, D, E). Carefully pry up a gap between the front tab plate (F) and the bracket with a flat-tip screwdriver to detach the joint (G). Front grab handle bracket: Repeat preceding step at the rear tab plate (H) area to detach the plate from the bracket. Detach the clips (I). NOTE: The grab handle bracket is attached to the tab plates of the side curtain airbag. Prying up the tab plates makes it possible to remove the bracket. Take care not to damage the side curtain airbag. Front Rear
Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the headliner and the removed trim pieces, along with the other parts listed for side curtain airbag deployment (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the headliner and all removed trim. Replace any pieces with the following damage: Any crease or tears in the headliner (A) Any cracks or breakage in the grab handle (B) Any damages around the grab handle holes (C) or the sunvisor holes (D) in the headliner Any cracks in the sunvisor stay base (E) Any cracks in the sunvisor bracket cover (F) Any bends or cracks in the sunvisor stay shaft (G) Any cracks in the sunvisor base (H) Any cracks or breakage in the vanity mirror base (I) Any fastener bases (J), the Velcro fasteners (K), or the clip bases (L) which have come off the headliner Replace the grab handle bracket mounting 6 mm bolt with a new one if it was removed. When installing a new grab handle bracket, tighten it and tab plates together with their mounting bolts securely. Install the grab handle by pushing on the handle against the bracket (M) until the clips (N) snap into place securely. If the clips are damaged or stress-whitened, replace them with new ones. Replace the removed cushion tapes with new pieces. Be careful not to crease or damage the headliner when reinstalling it through the tailgate opening. Also, be careful not to scratch the body. Check that both sides of the headliner are securely attached to the trim. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-4-cyl__checking-and-adjusting-the-headlinerpillar-trim) ). If the map light clips are removed, replace them with new ones. If the roof console screw grommets are removed or if they are damaged or stress-whitened, replace them with new ones. Push the clips and the hooks into place securely. Reinstall the roof console (O) as the following procedures: Install the roof console screw grommets (P) on the console with the screws (Q). Connect the HomeLink unit connector (R) and the HFL microphone connector or the HFL-navigation microphone(s). Set the rear hooks (T), and fit the grommets into the holes in the body, then push on the console until the grommets snap into place securely. Do the battery terminal reconnection procedure (see «BATTERY REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl__battery-removal-and-installation) ). Check for any DTCs that may have been set during repairs, and clear them. Interior Trim Grab handle Sunvisor Roof console

Carpet Replacement

Special Tools Required

KTC Trim Tool Set SOJATP2014*

*Available through the Acura Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Take care not to damage, wrinkle or twist the carpet. Be careful not to damage the dashboard or other interior trim pieces. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage.

Scheme 296

Scheme 296: Carpet Replacement

Scheme 297

Scheme 298

Scheme 299

Scheme 300

Scheme 301

Scheme 302

Scheme 303

Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-4-cyl) ), then wait at least 3 minutes before beginning work.
Remove these items: Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-4-cyl__trim-removalinstallation-door-areas) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__drivers-dashboard-undercover-removalinstallation) ) Dashboard center lower covers, both sides (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__dashboard-center-lower-cover-removalinstallation) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-4-cyl__passengers-dashboard-undercover-removalinstallation) ) B-pillar lower trims, both sides: Sedan (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-cushion) ) Sport Wagon (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) ) Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__front-seat-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#consoles-4-cyl__center-console-removalinstallation) ) Steering joint cover (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-4-cyl__steering-column-removal-and-installation) ) Parking brake lever (see «PARKING BRAKE LEVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-4-cyl) ) M/T: Shift lever housing (see «SHIFT LEVER HOUSING REPLACEMENT»(ref-475400-S32969248762012052300000) ) A/T: Shift lever (see «SHIFT LEVER REMOVAL»(/acura/tsx/ii-2008-2014/remont/automatic-trans/#automatic-transmission-4-cyl) ) Rear seat cushion: Sedan (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl__seat-cushion) ) Sport Wagon (see «SEAT CUSHION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-4-cyl) )
Release the hooks (A), then remove the accelerator pedal clip (B).
While pushing down the back-up spring (A), pull back the accelerator pedal (B) to release the hook (C).
Remove the footrest (A) by pulling it to detach the clips.
Disconnect the yaw rate-lateral acceleration sensor connector (A) and the USB adapter unit connector (B), and detach the wire harness clips (C). Remove the ground bolt with a TORX T30 bit.
A/T: Remove the bolts, then remove the shift lever mount bracket (A).
Disconnect the SRS unit connector B, and detach the harness clips (A) fastening the floor wire harness (C).
Remove the carpet (A). Release the Velcro fastener (B), and release the carpet from the hooks (C) of both rear heater ducts. Detach the clips (D). Detach the clips (E) fastening the carpet to both door sill areas. Pull the seat harnesses (F) out through the holes in the carpet.
If necessary, release the hook (A) that is just under the arrow mark (B) on the floor mat holder (C) by prying the holder with a flat-tip screwdriver, and remove the holder through the slit (D) in the carpet (E).
Install the carpet in the reverse order of removal, and note these items: If the clips fastening the carpet to the floor are damaged or stress-whitened, replace them with new ones. Take care not to damage, wrinkle or twist the carpet. Make sure the floor wire harnesses are routed correctly. Slip the holes in the carpet over the rear heater ducts. Make sure each connector is plugged in properly. Replace the clips fastening the carpet to both door sill areas with new ones. Push the Velcro fastener, the hooks, and the clips into place securely. Push the accelerator pedal clip into place securely, and verify that the pedal is properly fastened to the floor. If necessary, adjust the parking brake cable (see «PARKING BRAKE INSPECTION AND ADJUSTMENT»(/acura/tsx/ii-2008-2014/remont/mechanical-hydraulic/#conventional-brake-components-4-cyl) ).

Interior Trim (4-cyl) Acura TSX II

Scheme 160

Scheme 161

Scheme 162

Trim Removal/Installation - Door Areas

Front Door Sill Area

Scheme 163

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Rear Door Sill Area

Scheme 168

Scheme 169

Scheme 170

Trim Removal/Installation - Pillar Areas - Sedan

A-Pillar Trim

Scheme 171

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

B-Pillar Upper/Lower Trim

Scheme 177

Scheme 178

Scheme 179

Scheme 180

Scheme 181

C-Pillar Trim

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Trim Removal/Installation - Pillar Areas - Sport Wagon

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

Scheme 193

Scheme 194

Scheme 195

Scheme 196

Scheme 197

Scheme 198

Quarter Pillar Trim

Scheme 199

Scheme 200

Scheme 201

Trim Removal/Installation - Rear Shelf Area

Rear Shelf

Scheme 202

Scheme 203

Scheme 204

Scheme 205

Rear Parcel Shelf Dynamic Damper

Scheme 206

Trim Removal/Installation - Rear Side Area

Cargo Area Side Trim Panel

Scheme 207

Scheme 208

Scheme 209

Scheme 210

Scheme 211

Scheme 212

Scheme 213

Scheme 214

Rear Wheelhouse Insulator

Scheme 215

Trim Removal/Installation - Trunk Area

Trunk Side Trim Panel

Scheme 216

Scheme 217

Scheme 218

Scheme 219

Scheme 220

Scheme 221
