SRS (supplemental Restraint System) - (v6) Acura TSX II

Scheme 1

Scheme 2

General Precautions

Note. Some systems store data in memory that is lost when the battery is disconnected. Before disconnecting the battery, refer to Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ).

Please read the following precautions carefully before servicing the SRS, or the airbags could accidentally deploy and cause damage or injuries.

Scheme 3

1. Except when doing electrical inspections that requires battery power, always turn the ignition switch to LOCK (0), disconnect the negative cable from the battery, then wait at least 3 minutes before starting work. NOTE: The SRS memory is not erased even if the ignition switch is turned to LOCK (0) or the battery cables are disconnected from the battery.
2. Use replacement parts which are manufactured to the same standards and quality as the original parts. Do not install used SRS parts. Use only new parts when making SRS repairs.
3. Carefully inspect any SRS part before you install it. Do not install any part that shows signs of being dropped or improperly handled, such as dents, cracks or deformation.
4. Before disconnecting the SRS unit connectors, always disconnect the appropriate SRS parts connectors.
5. Use only a digital multimeter to check the system. If it is not a Honda multimeter, make sure its output is 10 mA (0.01 A) or less when switched to the lowest value in the ohmmeter range. A tester with a higher output could cause accidental deployment and possible injury.
6. Do not put objects on the front passenger's airbag.

Cable Reel Alignment

1. Misalignment of the cable reel could cause an open in the wiring, making the SRS, remote steering wheel controls, or the horn inoperative. Center the cable reel whenever you do the following (see step 5 ). Installation of the steering wheel. Installation of the cable reel. Installation of the steering column. Other steering-related adjustment or installation.
2. Do not disassemble the cable reel.
3. Do not apply grease to the cable reel.
4. If the cable reel shows any signs of damage, replace it with a new one. For example, if the cable reel does not rotate smoothly, replace it.

Airbag Handling and Storage

Do not disassemble an airbag. It has no serviceable parts. Once an airbag has been deployed, it cannot be repaired or reused.

For temporary storage of an airbag during service, observe the following precautions.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

1. Store the removed airbag with the pad surface up. Never put anything on the airbag.
2. To prevent damage to the airbag, keep it away from any oil, grease, detergent, or water.
3. Store the removed airbag on a secure, flat surface away from any high heat source (exceeding 200 °F (93 °C)).
4. Never do electrical tests on the airbags, such as measuring resistance.
5. Do not position yourself in front of the airbag during removal, inspection, or replacement.
6. For proper disposal of a damaged airbag or tensioner, refer to «AIRBAG AND TENSIONER DISPOSAL»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__airbag-and-tensioner-disposal) .
7. The side curtain airbag module assembly is a long, jointed part containing an inflator (A), a flexible bag (B), and brackets (C). When removing or installing the side curtain airbag assembly, never do these things: Handle the flexible bag. Drop the airbag assembly. Cut, tear, or unwrap the tape strips.

SRS Unit, Front and Side Impact Sensors, Rear Safing Sensor, Driver's Seat Position Sensor, and Front Passenger's Weight Sensors

Note. Some systems store data in memory that is lost when the battery is disconnected. Before disconnecting the battery, refer to Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ).

Scheme 9

Scheme 10

1. Turn the ignition switch to LOCK (0), disconnect the negative cable from the battery, and wait at least 3 minutes before starting installation or replacement of the SRS unit or disconnecting the connectors from the SRS unit.
2. Be careful not to bump or impact the SRS unit, the front impact sensors, the side impact sensors, or the rear safing sensor when the ignition switch is in ON (II), or for at least 3 minutes after the ignition switch is turned to LOCK (0).
3. Do not reconnect any connectors to the SRS unit until it is fully installed, including torquing the TORX bolts.
4. During installation or replacement, be careful not to bump (by impact wrench, hammer, etc.) the area around the SRS unit, the front impact sensors, the side impact sensors, or the rear safing sensor. The airbags could accidentally deploy and cause damage or injury.
5. After a collision where the front airbags, the side airbags, the side curtain airbags, or the front seat belt tensioners deploys, go to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) . After a collision where the airbags or the side airbags does not deploy, inspect for any damage or any deformation on the SRS unit, the front impact sensors, the rear safing sensor, and the side impact sensors. If there is any damage, replace the SRS unit and/or the sensors. Also, do the front seat active head restraint inspection (see «FRONT SEAT ACTIVE HEAD RESTRAINT INSPECTION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-active-head-restraint-inspection) ). Replace all damaged parts.
6. Do not disassemble the SRS unit, the front impact sensors, the side impact sensors, the rear safing sensor, the driver's seat position sensor, and the front passenger's seat weight sensors.
7. Always install the SRS unit, driver's seat position sensor, all impact sensors, and the rear safing sensor with the new TORX bolts to the specified torque.
8. Do not spill water or oil on the SRS unit or any of the sensors.

Wiring Precautions

Some of the SRS wiring can be identified by a special yellow outer covering and the SRS connectors can be identified by their yellow color. Observe the following instructions.

Scheme 11

Scheme 12

1. Never attempt to modify, splice, or repair SRS wiring. If there is an open or damage to the SRS wiring, replace the harness.
2. Be sure to install the harness wires so they do not get pinched or interfere with other parts.
3. Make sure all SRS ground locations are clean, and the grounds are securely fastened for optimum metal-to-metal contact. Poor grounds can cause intermittent problems that are difficult to diagnose.
4. Do not use any silicone based cleaners or lubricants on any SRS connectors or terminals.

Precautions for Electrical Inspections

Special Tools Required

Back Probe Adapter, 17 mm 07TAZ-001020A

Scheme 13

Scheme 14

1. Make sure the battery is fully charged when doing electrical test. If the battery is not fully charged, the results of the tests may not be accurate.
2. When using electrical test equipment, insert the probe of the tester into the wire side of the connector (except SRS unit connectors and waterproof SRS connectors). Do not insert the probe of the tester into the terminal side of the connector, and do not tamper with the connector.
3. Use the back probe adapter, 17 mm. Do not insert the probe forcibly.
4. Use specified service connectors in troubleshooting. Using improper tools could cause a diagnostic error due to poor metal-to-metal contact.

SRS Unit Connectors

When diagnosing or troubleshooting at an SRS unit connector (A), use the terminal test port below the terminal you need to check. Gently insert the pin probes of the tester or jumper wire at the terminal test port from the terminal side.

Scheme 15

Note. Do not insert the pin probes of the tester or a jumper wire at the terminal port or the SRS short canceller terminal port. To prevent damage to the connector terminals, do not insert the test equipment probes, paper clips, or other substitutes as they can damage the terminals. Damaged terminals cause a poor connection and an incorrect measurement.

Waterproof SRS Connectors

When diagnosis or troubleshooting is done at waterproof SRS connector (A), use the terminal test port above the terminal you need to check. Gently insert the pin probe of the tester or jumper wire at the terminal test port from the terminal side.

Scheme 16

Note. Do not insert the pin probes of the tester or a jumper wire into the terminal port. To prevent damage to the connector terminals, do not insert the test equipment probes, paper clips, or other substitutes as they can damage the terminals. Damaged terminals can cause a poor connection and an incorrect measurement.

Lever-Locked Connector

The SRS unit connectors have a lever lock.

Disconnecting

To release the lock, pull the lever (A) while pushing the lock (B), on the outside of the connector, then pull out the connector (C).

Scheme 17

Connecting

To reconnect the connector, push in on the connector (A). As the connector is pressed in, the lever (B) moves to the locked position.

Scheme 18

Spring-Loaded Lock Connector

Some SRS connectors have a spring-loaded lock.

To release the lock, pull the spring-loaded sleeve (A) toward the stop (B) while holding the opposite half of the connector, then pull the connector halves apart. Be sure to pull on the sleeve and not on the connector.

Scheme 19

To reconnect, hold the pawl-side connector, and press on the back of the sleeve-side connector in the direction shown. As the two connector halves are pressed together, the sleeve (A) is pushed back by the pawl (B). Do not touch the sleeve.

Scheme 20

To release the lock, pull the spring-loaded sleeve (A) toward the stop (B) while holding the opposite half of the connector. Then pull the connector halves apart. Be sure to pull on the sleeve and not on the connector half.

Scheme 21

Hold both connector halves, and press them firmly together until the projection (A) of the sleeve-side connector clicks.

Scheme 22

Opening the SRS Unit Shorting Connectors for Diagnosis

Special Tools Required

SRS Short Canceller 070AZ-SAA0100

Note. To prevent damage to the connector cavity, insert an SRS short canceller straight into the cavity from the terminal side. Before installing an SRS short canceller, wash it with electrical contact cleaner, then dry it with compressed air. Do not use an SRS short canceller if it is damaged. Make sure to remove an SRS short canceller before reconnecting the SRS unit connector. Some systems store data in memory that is lost when the battery is disconnected. Before disconnecting the battery, refer to Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ).

When SRS unit connectors A (39P) and B (39P) are disconnected, short circuits are automatically created in the connector to prevent accidental deployment of an airbag or tensioner. The circuit may need to be opened sometimes when diagnosing the system. Insert an SRS short canceller in the specified cavities when necessary to keep the circuit open for diagnosis.

Scheme 23

Terminal numbers are shown from the wire side of the female terminals. Insert the SRS short canceller(s) into the cavities on the terminal side of the connector.

Scheme 24

Scheme 25

Front Seats With Side Airbags

Front seats with side airbags have a "SIDE AIRBAG" label on the seat-back.

Scheme 26

1. Clean the seats with a damp cloth. Do not soak the seats with liquid.
2. Do not spray steam on the seats. Do not repair a torn or frayed seat-back cover/pad. Replace the seat-back cover/pad. If it is damaged.
3. After a collision where the side airbag was deployed, replace the side airbag and the seat frame with new parts. If the seat-back cover is split, it must be replaced. Refer to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__component-replacementinspection-after-deployment) .
4. Never put aftermarket accessories on the seats (covers, pads, seat heaters, lights, etc.).

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

1. Turn the ignition switch to LOCK (0). Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work. Driver's Airbag
2. Remove the access panel (A) from the steering wheel, then disconnect the cable reel 4P connector (B) from the driver's airbag 4P connector. Front Passenger's Airbag
3. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
4. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector. Side Airbag
5. Disconnect the SRS floor wire harness 2P connectors (A) from the driver's and the front passenger's side airbag 2P connectors. Side Curtain Airbag
6. Remove the C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connectors (A) from the left and right side curtain airbag 2P connectors. Front Seat Belt Tensioner
8. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
9. Disconnect the SRS floor wire harness 4P connectors (A) from the driver's and the front passenger's seat belt tensioner 4P connectors. SRS Unit
10. With navigation: Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ).
11. Without navigation: Remove the dashboard center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-pocket-removalinstallation) ).
12. Disconnect SRS unit connectors A (39P) and B (39P) from the SRS unit. NOTE: The SRS unit connectors have lever locks. Release the locks before disconnecting the connectors.

DTC (Diagnostic Trouble Codes)

The self-diagnostic function of the SRS unit allows it to locate the causes of system problems and then store this information in memory. For easier troubleshooting, this data can be retrieved with the HDS, via the data link circuit.

1. When you turn the ignition switch to ON (II), the SRS indicator should come on. If it goes off after 6 seconds, the system is normal, and is not currently detecting any problems.
2. If there is a problem, the system locates and defines the problem, stores this information in memory, and turns the SRS indicator on. The data remains in the memory even when the ignition switch is turned to LOCK (0) or if the battery is disconnected.
3. The data is stored in memory as a diagnostic trouble code (DTC).
4. DTCs are either latching or resetting depending on the malfunction. With resetting DTCs, the SRS indicator goes off the next time the ignition switch is turned to ON (II) and the system is normal, but the DTC is still stored. With latching DTCs, the SRS indicator does not turn OFF until the malfunction is repaired and the DTC is cleared.
5. When you connect the HDS to the data link connector (DLC), you can retrieve a more detailed DTC in the HDS "SRS" menu. NOTE: Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).
6. After reading and recording the DTC, go to the troubleshooting procedure for that code.

Precautions

1. Make sure the battery is fully charged. If the battery is dead or low, measuring values may not be correct.
2. Use only a digital multimeter to check the system. Make sure its output is 10 mA (0.01 A) or less when switched to the smallest value in the ohmmeter range. A tester with a higher output could damage the airbag circuit or cause accidental airbag deployment and possible injury.
3. Whenever the ignition switch is in ON (II), or has been turned to LOCK (0) for less than 3 minutes, be careful not to bump the SRS unit; the airbags could accidentally deploy and cause damage or injuries.
4. Before removing the dashboard wire harness or SRS floor wire harness, disconnect the driver's airbag connector, the front passenger's airbag connector, both side airbag connectors, both side curtain airbag connectors, and both front seat belt tensioner connectors.
5. Do not touch a tester probe to the terminals in the SRS unit or harness connectors, and do not connect the SRS unit terminals or the sensor terminals with a jumper wire. Use only the back probe set and the multimeter. Back probe spring-loaded lock type connectors correctly.

How to Read DTCs

Note. Make sure the battery is fully charged before you begin.

Scheme 33

1. Turn the ignition switch to LOCK (0).
2. Connect the HDS to the data link connector (DLC) (A).
3. Turn the ignition switch to ON (II).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, inspect the power line of SRS unit, fuses, and ground, and if there is not any abnormality found, then go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
5. Use the HDS to check for SRS DTCs.
6. Read and record the DTCs. NOTE: Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0). Do not clear the DTCs until instructed by the troubleshooting procedure.
7. Turn the ignition switch to LOCK (0), then wait for 10 seconds.
8. Disconnect the HDS from the DLC.
9. Do the troubleshooting procedure for the DTC.

How to Clear DTCs

Note. Make sure the battery is fully charged before you begin.

Scheme 34

1. Turn the ignition switch to LOCK (0).
2. Connect the HDS to the data link connector (DLC) (A).
3. Turn the ignition switch to ON (II).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
5. In the SRS MENU of the HDS, select SRS, then DTC to clear DTCs.
6. Turn the ignition switch to LOCK (0), then wait for 10 seconds.
7. Disconnect the HDS from the DLC.

Troubleshooting Intermittent Failures

If there was a malfunction that sets a DTC, but it does not recur, a DTC will be stored in the memory, and the SRS indicator may come on depending on the malfunction detected.

Note. Check the condition of the battery (see BATTERY TEST ), and the charging system (see ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING ). Low battery voltage may cause some intermittent failures. A faulty or damaged cable reel can cause intermittent problems related to the driver's airbag inflator DTCs.

After checking the DTC, troubleshoot as follows

1. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ).
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Set the parking brake, then start the engine, and let it idle.
4. The SRS indicator comes on for about 6 seconds and then goes off.
5. Shake the related wire harnesses and the connectors, and look for loose connections, poor pin fits, and poor grounds.
6. Take a test-drive (quick acceleration, quick braking, and cornering), turn the steering wheel fully left and right, and hold it there for 5 to 10 seconds. If the problem recurs, the SRS indicator will come on.
7. If you cannot duplicate the concern, ask the client about the conditions when it occurred, or ask the client to demonstrate the concern.
8. If you cannot duplicate the intermittent failure, the system is OK at this time.

SRS Unit Update

Special Tools Required

1. Honda Diagnostic System (HDS) tablet tester
2. Honda Interface Module (HIM) and an iN workstation with the latest HDS software version
3. HDS pocket tester
4. GNA600 and an iN workstation with the latest HDS software version
5. MVCI unit with the latest control module (CM) update software installed

Any one of the above updating tools can be used.

Note. Make sure the HDS/iN workstation or the MVCI has latest HDS software version. Before you update the SRS unit, make sure the battery in the vehicle is fully charged. Never turn the ignition switch to LOCK (0) or ACC (I) during the update. If there is a problem with the update, leave the ignition switch in ON (II). To prevent SRS unit damage, do not operate anything electrical (headlights, audio system, brakes, A/C, power windows, moonroof (if equipped), door locks, etc.) during the update. To ensure the latest program is installed, do an SRS unit update whenever the SRS unit is substituted or replaced. You cannot update an SRS unit with a program it already has. It will only accept a new program. If you need to diagnose the HIM because the HIM's red (#3) light came on or was flashing during the update, leave the ignition switch in ON (II) when you disconnect the HIM from the data link connector (DLC). This will prevent SRS unit damage.

Scheme 35

1. Turn the ignition switch to LOCK (0).
2. Connect the HDS to the data link connector (DLC) (A).
3. Turn the ignition switch to ON (II), but do not start the engine.
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
5. Select the update program, and follow the screen prompts to update the SRS unit.
6. If the software in the SRS unit is the latest, disconnect the updating tool from the DLC, and go back to the procedure that you were doing. If the software in the SRS unit is not the latest, follow the instructions on the screen. NOTE: If you run into a problem during the update procedure (programming takes over 15 minutes, status bar goes over 100%, D position or immobilizer indicator flashes, HDS tablet freezes, etc.), follow these steps to minimize the chance of damaging the SRS unit: Leave the ignition switch in ON (II). Connect a jumper battery (do not connect a battery charger). Shutdown the updating tool. Disconnect the updating tool from the DLC. Reboot the updating tool. Reconnect the updating tool to the DLC, and try the update procedure again.
7. Turn the ignition switch to LOCK (0).
8. Disconnect the HDS from the DLC.

ODS Unit Initialization

Note. After SRS unit or ODS unit is replaced, do this procedure to initialize the ODS unit. ODS unit initialization will initialize both OPDS sensor and front passenger's weight sensor.

OPDS Sensor Initialization

When you replace a seat-back cover/pad, SRS unit, and/or ODS unit, initialize the OPDS sensor with the HDS.

Note. Before initializing the ODS unit, make sure the battery is fully charged. A new (uninitialized) ODS unit installed with a faulty OPDS sensor (DTC 86-1x or 86-2x) can cause DTCs 85-71 and 85-78. If the SRS has a hard DTC 86-1x or 86-2x, troubleshoot the DTCs completely before replacing the ODS unit. Before initializing the ODS unit, clear the DTCs. Make sure all components of the front passenger's seat are correctly installed. Make sure nothing is on the front passenger's seat, including after market seat covers or mats. Make sure there is nothing in the front passenger's seat-back pocket. Keep the A/C and the heater off.

Scheme 36

1. Turn the ignition switch to ON (II).
2. Set the seat-back in a normal position.
3. Turn the ignition switch to LOCK (0).
4. Connect the HDS to the data link connector (DLC) (A).
5. Turn the ignition switch to ON (II).
6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
7. From the HDS Main Menu, select SRS, then INITIALIZATION. In the INITIALIZATION Menu, select ODS Initialization. Follow the prompts until the OPDS sensor initialization has been completed.
8. Turn the ignition switch to LOCK (0), then wait for 10 seconds.
9. Disconnect the HDS from the DLC. NOTE: If the ODS unit fails to initialize after several attempts, replace the seat-back cover/pad with equipped OPDS sensor (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ), and retry. If the ODS unit continues to fail to initialize, replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).

Front Passenger's Weight Sensor Initialization

When you replace the SRS unit, the front passenger's weight sensor, the front passenger's seat frame, or the ODS unit, initialize the front passenger's weight sensor with the HDS.

Note. Before initializing the front passenger's weight sensor, make sure the battery is fully charged. Before initializing the ODS unit, clear the DTCs. Make sure all components of the front passenger's seat are correctly installed. Make sure nothing is on the front passenger's seat, including after market seat covers or mats. Make sure there is nothing in the front passenger's seat-back pocket. Keep the windows and the moonroof closed. Make sure the vehicle is on level ground. Keep the A/C and the heater off. Do not touch the front passenger's seat during the operation check. Do not expose the front passenger's seat to sudden temperature changes.

Scheme 37

1. Position the front passenger's seat all the way rearward, and adjust the seat-back to the forward most position. Do not move the seat from this position until the initialization is completed.
2. Turn the ignition switch to LOCK (0).
3. Connect the HDS to the data link connector (DLC) (A).
4. Turn the ignition switch to ON (II).
5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
6. Drive the vehicle, and accelerate to 22 mph (36 km/h), then stop on level ground.
7. From the HDS Main Menu, select SRS, then INITIALIZATION. In the INITIALIZATION Menu, select SWS Initialization. Follow the prompts until the front passenger's weight sensor initialization has been completed.
8. Turn the ignition switch to LOCK (0).
9. Disconnect the HDS from the DLC.

After Replacing Front Passenger's Seat Component(s)

Note. Check the ODS unit operation after any of these actions: Front passenger's seat component(s) replacement (except ODS unit and/or front passenger's weight sensor). SRS unit replacement. Remove the front passenger's weight sensor(s). After a vehicle collision (see FRONT PASSENGER'S WEIGHT SENSOR OUTPUT CHECK AFTER A VEHICLE COLLISION ).

Pre-Operation Check Set-Up

1. Make sure all the components of the front passenger's seat are correctly installed.
2. Position the front passenger's seat all the way rearward, and adjust the seat-back to the forward most position. Do not move the seat from this position until the output check is completed.
3. Make sure nothing is on the front passenger's seat, including after market seat covers or mats.
4. Make sure there is nothing in the front passenger's seat-back pocket.
5. Keep the windows and the moonroof closed.
6. Do all initialization procedures, except test-driving, in the service bay.
7. Make sure the vehicle is on level ground.
8. Turn the heater and the A/C off.
9. Do not touch the front passenger's seat during the operation check.
10. Do not expose the front passenger's seat to sudden temperature changes.
11. Make sure all aftermarket devices such as amplifiers, fluorescent light, air purifiers, CB or HAM radios, etc. are turned off.

Scheme 38

1. Drive the vehicle, accelerate to 22 mph (36 km/h), then stop on level ground.
2. Turn the ignition switch to LOCK (0).
3. Connect the HDS to the data link connector (DLC) (A).
4. Turn the ignition switch to ON (II).
5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
6. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select AFTER REPLACING FRONT PASSENGER'S SEAT COMPONENT(S). Follow the prompts until the ODS unit operation check has been completed.
7. Turn the ignition switch to LOCK (0).
8. Disconnect the HDS from the DLC.

Front Passenger's Weight Sensor Output Check After a Vehicle Collision

Note. Check the front passenger's weight sensor output after this action: After a vehicle collision.

1. Make sure all the components of the front passenger's seat are correctly installed.
2. Position the front passenger's seat all the way rearward, and adjust the seat-back to the forward most position. Do not move the seat from this position until the output check is completed.
3. Make sure nothing is on the front passenger's seat, including after market seat covers or mats.
4. Make sure there is nothing in the front passenger's seat-back pocket.
5. Keep the windows and the moonroof closed.
6. Do all initialization procedures, except test-driving, in the service bay.
7. Make sure the vehicle is on level ground.
8. Turn the heater and the A/C off.
9. Do not touch the front passenger's seat during the operation check.
10. Do not expose the front passenger's seat to sudden temperature changes.
11. Make sure all aftermarket devices such as amplifiers, fluorescent light, air purifiers, CB or HAM radios, etc. are turned off.

Scheme 39

1. Drive the vehicle, accelerate to 22 mph (36 km/h), then stop on level ground.
2. Turn the ignition switch to LOCK (0).
3. Connect the HDS to the data link connector (DLC) (A).
4. Turn the ignition switch to ON (II).
5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
6. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select AFTER A VEHICLE COLLISION. Follow the prompts until the front passenger's weight sensor output check has been completed.
7. Turn the ignition switch to LOCK (0).
8. Disconnect the HDS from the DLC.

Driver's Seat Position Sensor Operation Check

Check the driver's seat position sensor after the driver's seat position sensor replacement.

Scheme 40

Scheme 41

1. Make sure the driver's seat is all the way forward position.
2. Turn the ignition switch to LOCK (0).
3. Connect the HDS to the data link connector (DLC) (A).
4. Turn the ignition switch to ON (II).
5. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
6. '11 model: From the HDS Main Menu, select SRS, then PARAMETER INFORMATION. In the PARAMETER INFORMATION Menu, select Buckle Switch, Seat Position Sensor.
7. '12-13 models: From the HDS Main Menu, select SRS, then Data List.
8. Using a piece of tape (A), mark the location on the seat's outer cover (B) where the front riser cover meets the seat riser (C). The driver's seat position sensor should read NEAR.
9. Move the seat back in small increments (about 5 mm (0.2 in) until the driver's seat position sensor reads NOT NEAR. The seat should be about 55 mm (2.2 in) from the front. NOTE: It takes a few seconds for the HDS to display changes, so wait for about 5 seconds between each movement. If the driver's seat position sensor data does not work as described above, check the driver's seat position sensor for damage, and replace parts as needed.
10. Turn the ignition switch to LOCK (0).
11. Disconnect the HDS from the DLC.

DTC Troubleshooting Index

DTC TROUBLESHOOTING INDEX

Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

SWS DTC Index

SWS DTC INDEX

Symptom Troubleshooting Index

SYMPTOM TROUBLESHOOTING INDEX

Airbags

The SRS is a safety device which, when used with the front seat belts, is designed to help protect the driver and front passenger in a frontal impact exceeding a certain set limit. The system consists of the SRS unit (A) including safing sensor and impact sensor, the cable reel (B), the driver's airbag (C), the front passenger's airbag (D), the side airbags (E), the side curtain airbags (F), the front seat belt tensioners (G), the side impact sensors (first) (H), the front impact sensors (I), the rear safing sensor (J), and the side impact sensors (second) (K).

Since the driver's and the front passenger's airbags use the same sensors, both normally inflate at the same time. However, it is possible for only one airbag to inflate. This can occur when collision severity is near the threshold for airbag deployment. In such case, the SRS will only deploy airbags when the protection provided by the front seat belt is insufficient.

Front Passenger's Weight Sensors

The front passenger's weight sensors (L) are part of the front passenger's seat base. The front passenger's weight sensors detect the weight on the seat, and send the information to the ODS unit (M). If the total weight is about 65 lbs (30 kg) or less, the ODS unit sends a signal to the SRS unit to prevent the front passenger's airbag from deploying. When the front passenger's airbag is disabled, the passenger airbag cutoff indicator (N) on the center panel comes on to alert the driver that the front passenger's airbag will not deploy in a front-end collision.

Note. The sensors only detect the weight on the seat. The sensors do not detect the weight of the passenger's legs or arms that may be resting on the floor or armrests.

Driver's Seat Position Sensor

The driver's seat position sensor (0) is under the driver's seat on the left side. When the driver's seat is moved to forward most position, the deployment of the driver's airbag is moderated to decrease its force of impact during a front-end collision.

Scheme 42

Rear Safing Sensor

The rear safing sensor is located under the rear seat cushion. The rear safing sensor performs the same basic function as the safing sensor in the SRS unit. It measures sideways G force, such as the force the vehicle would receive in a side collision in the rear, and sends that information to the SRS unit. The SRS unit uses that information, and the information from the side impact sensors to determine the side that is impacted and the force. If the threshold is met, the SRS unit deploys the side airbag, the side curtain airbag, and the front seat belt tensioner on that side.

Side Airbag Cutoff indicator/OPDS Operation

The OPDS sensors (P) are located on the front passenger's seat-back foam pad. The ODS unit detects front passenger's position on the seat by using the OPDS sensors, then sends the signals to the SRS unit. The indicator comes on when the front passenger's seat is occupied by a small adult or child who is leaning into the deployment path, or when an object (grocery bag, briefcase, purse, etc.) is in the seat. This indicates the front passenger's side airbag is off and will not deploy; there is no problem with the side airbag. If the passenger sits upright or moves to another seat, or you remove the object from the seat, the indicator should go off. There will be some delay between the occupant's repositioning, and when the indicator will turn on or off.

Passenger's Airbag Cutoff Indicator/Front Passenger's Weight Sensor Operation

The indicator comes on if the weight on the front passenger's seat is about 65 lbs (30 kg) or less. This indicates the front passenger's airbag is off and will not deploy. The front airbag is shut off to reduce the chance of airbag-caused injuries.

SRS Operation

The main circuit in the SRS unit senses and analyzes the force of impact and, if necessary, ignites the inflator charges. If battery voltage is too low or power is disconnected due to the impact, the voltage regulator and the back-up power circuit will keep voltage at a constant level.

For the SRS to operate

Front Seat Belt Tensioners

1. The front impact sensor, the side impact sensor, or the rear safing sensor must activate and send electric signals to the microprocessor.
2. The microprocessor must compute the signals and trigger the tensioners.
3. The charges must ignite and deploy the tensioners.

Driver's and Front Passenger's Airbag(s)

1. The front impact sensor must activate and send electric signals to the microprocessor.
2. The microprocessor must compute the signals and trigger the front airbag inflators.
3. The triggered inflators must ignite and deploy the front airbags.

Side Airbag(s)

1. The side impact sensor must activate and send electric signals to the microprocessor.
2. The microprocessor must compute the signals and trigger the side airbag inflators. However, the microprocessor does not trigger the front passenger's side airbag if the SRS unit determines that the front passenger's head is in the deployment path of the side airbag.
3. The triggered inflators must ignite and deploy the side airbags.

Side Curtain Airbag(s)

1. The side impact sensor or the rear safing sensor must activate and send electrical signals to the microprocessor.
2. The microprocessor must compute the signals and trigger the side curtain airbag and the side airbag inflators.
3. The triggered inflators must ignite and deploy the side curtain airbag and the side airbag at the same time.

Scheme 43

Self-Diagnostic System

A self-diagnostic circuit is built into the SRS unit; when the ignition switch is turned to ON (II), the SRS indicator comes on and goes off after about 6 seconds if the system is operating normally. If the indicator does not come on, or does not go off after 6 seconds, or comes on while driving, it indicates a problem in the system. The system must be inspected and repaired as soon as possible.

For better serviceability, the SRS unit memory stores any DTCs related to the cause of the malfunction. The SRS unit is connected to the data link connector (DLC). This information can be read with the HDS when it is connected to the DLC (see DISCONNECTING SYSTEM CONNECTOR ).

Note. Before you disconnect the negative cable from the battery for troubleshooting, refer to Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ).

Scheme 44

SRS UNIT INPUTS AND OUTPUTS AT CONNECTOR A (39P) REFERENCE CHART

Scheme 45

SRS UNIT INPUTS AND OUTPUTS AT CONNECTOR B (39P) REFERENCE CHART

Scheme 46

Scheme 47

Scheme 48

Scheme 49

DTC 11-1x ("x" can be 0 thru 9 or A thru F): Open in the Driver's Airbag First Inflator; DTC 11-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Driver's Airbag First Inflator; DTC 11-4x ("x" can be 0 thru 9 or A thru F): Open in the Driver's Airbag Second Inflator; DTC 11-5x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Driver's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 50

Scheme 51

Scheme 52

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-1x, 11-2x, 11-4x, or 11-5x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the access panel from the steering wheel (see step 2 ), then disconnect the cable reel 4P connector (A) from the driver's airbag 4P connector.
7. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the cable reel 4P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ). Is DTC 11-1x, 11-2x, 11-4x, or 11-5x indicated? YES -Go to step 12 . NO -Open or increased resistance in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Remove the column cover (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
15. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector.
16. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the dashboard wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
19. Turn the ignition switch to ON (II), then wait for 10 seconds.
20. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ). Is DTC 11-1x, 11-2x, 11-4x, or 11-5x indicated? YES -Go to step 21 . NO -Open or increased resistance in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
21. Turn the ignition switch to LOCK (0).
22. Disconnect the negative cable from the battery, then wait at least 3 minutes.
23. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
24. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
25. Measure the resistance of the SRS simulator lead J black and red terminals respectively. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Open or increased resistance in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 11-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Driver's Airbag First Inflator; DTC 11-6x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Driver's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 53

Scheme 54

Scheme 55

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-3x or 11-6x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the access panel from the steering wheel (see step 2 ), then disconnect the cable reel 4P connector (A) from the driver's airbag 4P connector.
7. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the cable reel 4P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-3x or 11-6x indicated? YES -Go to step 12 . NO -Short to another wire in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Remove the column cover (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
15. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector.
16. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the dashboard wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
19. Turn the ignition switch to ON (II), then wait for 10 seconds.
20. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-3x or 11-6x indicated? YES -Go to step 21 . NO -Short to another wire in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
21. Turn the ignition switch to LOCK (0).
22. Disconnect the negative cable from the battery, then wait at least 3 minutes.
23. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
24. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
25. Connect the SRS short cancellers (070AZ-SAA0100) to SRS unit connector A (39P) terminals No. 3 and No. 4, and terminals No. 7 and No. 8 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
26. Measure the resistance of the SRS simulator lead J black and red terminals respectively. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Short to another wire in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 11-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Driver's Airbag First Inflator; DTC 11-Ax ("x" can be 0 thru 9 or A thru F): Short to Power in the Driver's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 56

Scheme 57

Scheme 58

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-8x or 11-Ax indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the access panel from the steering wheel (see step 2 ), then disconnect the cable reel 4P connector (A) from the driver's airbag 4P connector.
7. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the cable reel 4P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-8x or 11-Ax indicated? YES -Go to step 12 . NO -Short to power in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Remove the column cover (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
15. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector.
16. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the dashboard wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
19. Turn the ignition switch to ON (II), then wait for 10 seconds.
20. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-8x or 11-Ax indicated? YES -Go to step 21 . NO -Short to power in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
21. Turn the ignition switch to LOCK (0).
22. Disconnect the negative cable from the battery, then wait at least 3 minutes.
23. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
24. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
25. Reconnect the negative cable to the battery.
26. Turn the ignition switch to ON (II).
27. Measure the voltage between each terminal of SRS simulator lead J and body ground individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Short to power in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 11-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Driver's Airbag First Inflator; DTC 11-Bx("x" can be 0 thru 9 or A thru F): Short to Ground in the Driver's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 59

Scheme 60

Scheme 61

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-9x or 11-Bx indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the access panel from the steering wheel (see step 2 ), then disconnect the cable reel 4P connector (A) from the driver's airbag 4P connector.
7. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the cable reel 4P connector.
8. Reconnect the negative cable from the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-9x or 11-Bx indicated? YES -Go to step 12 . NO -Short to ground in the driver's airbag first or second inflator; replace the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Remove the column cover (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
15. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector.
16. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead J to the dashboard wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
19. Turn the ignition switch to ON (II), then wait for 10 seconds.
20. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 11-9x or 11-Bx indicated? YES -Go to step 21 . NO -Short to ground in the cable reel; replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
21. Turn the ignition switch to LOCK (0).
22. Disconnect the negative cable from the battery, then wait at least 3 minutes.
23. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
24. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
25. Measure the resistance between each terminal of SRS simulator lead J and body ground individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Short to ground in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 12-1x ("x" can be 0 thru 9 or A thru F): Open in the Front Passenger's Airbag First Inflator; DTC 12-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Front Passenger's Airbag First Inflator; DTC 12-4x ("x" can be 0 thru 9 or A thru F): Open in the Front Passenger's Airbag Second Inflator; DTC 12-5x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 62

Scheme 63

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-1x, 12-2x, 12-4x, or 12-5x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
7. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector.
8. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect the SRS simulator lead J to the dashboard wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-1x, 12-2x, 12-4x, or 12-5x indicated? YES -Go to step 13 . NO -Open in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-airbag-replacement) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
17. Measure the resistance of the SRS simulator lead J black and red terminals respectively. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Open in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 12-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Front Passenger's Airbag First Inflator; DTC 12-6x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 64

Scheme 65

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-3x or 12-6x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
7. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector.
8. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect the SRS simulator lead J to the dashboard wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-3x or 12-6x indicated? YES -Go to step 13 . NO -Short to another wire in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-airbag-replacement) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
17. Connect the SRS short cancellers (070AZ-SAA0100) to SRS unit connector A (39P) terminals No. 5 and No. 6, and terminals No. 9 and No. 10 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
18. Measure the resistance of the SRS simulator lead J black and red terminals respectively. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Short to another wire in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 12-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Front Passenger's Airbag First Inflator; DTC 12-Ax ("x" can be 0 thru 9 or A thru F): Short to Power in the Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 66

Scheme 67

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-8x or 12-Ax indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
7. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector.
8. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect the SRS simulator lead J to the dashboard wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-8x or 12-Ax indicated? YES -Go to step 13 . NO -Short to power in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-airbag-replacement) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Turn the ignition switch to ON (II).
19. Measure the voltage between each terminal of SRS simulator lead J and body ground individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Short to power in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 12-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Front Passenger's Airbag First Inflator; DTC 12-Bx ("x" can be 0 thru 9 or A thru F): Short to Ground in the Front Passenger's Airbag Second Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead J 070AZ-SNAA100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 68

Scheme 69

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-9x or 12-Bx indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
7. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector.
8. Connect the terminals of SRS simulator lead J to the SRS inflator simulator (2 ohms connectors), and then connect the SRS simulator lead J to the dashboard wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 12-9x or 12-Bx indicated? YES -Go to step 13 . NO -Short to ground in the front passenger's airbag first or second inflator; replace the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-airbag-replacement) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead J. Do not disconnect SRS simulator lead J from the dashboard wire harness 4P connector.
17. Measure the resistance between each terminal of SRS simulator lead J and body ground individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Short to ground in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC 21-1x ("x" can be 0 thru 9 or A thru F): Open in the Driver's Seat Belt Tensioner; DTC 21-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Driver's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 70

Scheme 71

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-1x or 21-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the driver's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-1x indicated? YES -Go to step 13 . NO -Open in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 12 and No. 13 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
17. Measure the resistance between SRS unit connector B(39P) terminals No. 12 and No. 13. There should be 2.0-3.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 21-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Driver's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 72

Scheme 73

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-3x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the driver's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-3x indicated? YES -Go to step 13 . NO -Short to another wire in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect SRS simulator lead K from the SRS floor wire harness 4P connector.
17. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 12 and No. 13 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
18. Measure the resistance between SRS unit connector B (39P) terminals No. 12 and No. 13. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 21-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Driver's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information,(see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 74

Scheme 75

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-8x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the driver's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-8x indicated? YES -Go to step 13 . NO -Short to power in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect SRS simulator lead K from the SRS floor wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Turn the ignition switch to ON (II).
19. Measure the voltage between body ground and SRS unit connector B (39P) terminals No. 12 and No. 13 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 21-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Driver's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 76

Scheme 77

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-9x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the driver's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 21-9x indicated? YES -Go to step 13 . NO -Short to ground in the driver's seat belt tensioner; replace the driver's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect SRS simulator lead K from the SRS floor wire harness 4P connector.
17. Measure the resistance between body ground and SRS unit connector B (39P) terminals No. 12 and No. 13 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 22-1x ("x" can be 0 thru 9 or A thru F): Open in the Front Passenger's Seat Belt Tensioner; DTC 22-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 78

Scheme 79

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-1x or 22-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the front passenger's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-1x or 22-2x indicated? YES -Go to step 13 . NO -Open in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 14 and No. 15 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
17. Measure the resistance between SRS unit connector B (39P) terminals No. 14 and No. 15. There should be 2.0-3.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 22-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 80

Scheme 81

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-3x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the front passenger's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-3x indicated? YES -Go to step 13 . NO -Short to another wire in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect SRS simulator lead K from the SRS floor wire harness 4P connector.
17. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 14 and No. 15 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
18. Measure the resistance between SRS unit connector B (39P) terminals No. 14 and No. 15. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 22-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 82

Scheme 83

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-8x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the front passenger's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-8x indicated? YES -Go to step 13 . NO -Short to power in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect SRS simulator lead K from the SRS floor wire harness 4P connector.
17. Reconnect the negative cable to the battery.
18. Turn the ignition switch to ON (II).
19. Measure the voltage between body ground and SRS unit connector B (39P) terminals No. 14 and No. 15 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 22-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Front Passenger's Seat Belt Tensioner

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead K 070AZ-SNAA200

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 84

Scheme 85

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-9x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
7. Disconnect the SRS floor wire harness 4P connector (A) from the front passenger's seat belt tensioner 4P connector.
8. Connect the terminals of SRS simulator lead K to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead K to the SRS floor wire harness 4P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 22-9x indicated? YES -Go to step 13 . NO -Short to ground in the front passenger's seat belt tensioner; replace the front passenger's seat belt (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect SRS simulator lead K from the SRS floor wire harness 4P connector.
17. Measure the resistance between body ground and SRS unit connector B (39P) terminals No. 14 and No. 15 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 31-1x ("x" can be 0 thru 9 or A thru F): Open in the Driver's Side Airbag Inflator; DTC 31-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Driver's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 86

Scheme 87

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-1x or 31-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the driver's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-1x or 31-2x indicated? YES -Go to step 12 . NO -Open in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Measure the resistance of the SRS simulator lead L black terminal (A). There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 31-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Driver's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 88

Scheme 89

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-3x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the driver's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-3x indicated? YES -Go to step 12 . NO -Short to another wire in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 6 and No. 7 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
17. Measure the resistance of the SRS simulator lead L black terminal (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 31-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Driver's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 90

Scheme 91

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-8x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the driver's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-8x indicated? YES -Go to step 12 . NO -Short to power in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Reconnect the negative cable to the battery.
17. Turn the ignition switch to ON (II).
18. Measure the voltage between black terminal of SRS simulator lead L (A) and body ground individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 31-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Driver's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 92

Scheme 93

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-9x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the driver's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 31-9x indicated? YES -Go to step 12 . NO -Short to ground in the driver's side airbag inflator; replace the driver's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Measure the resistance between black terminal of SRS simulator lead L (A) and body ground individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 32-1x ("x" can be 0 thru 9 or A thru F): Open in the Front Passenger's Side Airbag Inflator; DTC 32-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Front Passenger's Side Airbag Inflator

Special fools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 94

Scheme 95

1. Clear the DTCs With the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-1x or 32-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the front passenger's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-1x or 32-2x indicated? YES -Go to step 12 . NO -Open in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Measure the resistance of the SRS simulator lead L black terminal (A). There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 32-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, Verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 96

Scheme 97

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-3x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the front passenger's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-3x indicated? YES -Go to step 12 . NO -Short to another wire in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 8 and No. 9 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
17. Measure the resistance of the SRS simulator lead L black terminal (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 32-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 98

Scheme 99

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-8x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the front passenger's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-8x indicated? YES -Go to step 12 . NO -Short to power in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Reconnect the negative cable to the battery.
17. Turn the ignition switch to ON (II).
18. Measure the voltage between black terminal of SRS simulator lead L (A) and body ground individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 32-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Front Passenger's Side Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 100

Scheme 101

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-9x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector (A) from the front passenger's side airbag 2P connector.
7. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
8. Reconnect the negative cable to the battery.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 32-9x indicated? YES -Go to step 12 . NO -Short to ground in the front passenger's side airbag inflator; replace the front passenger's side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), then clear the DTC.
12. Turn the ignition switch to LOCK (0).
13. Disconnect the negative cable from the battery, then wait at least 3 minutes.
14. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
15. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
16. Measure the resistance between black terminal of SRS simulator lead L (A) and body ground individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 33-1x ("x" can be 0 thru 9 or A thru F): Open in the Left Side Curtain Airbag Inflator; DTC 33-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that ail the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 102

Scheme 103

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-1x or 33-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the left side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-1x or 33-2x indicated? YES -Go to step 13 . NO -Open in the left side curtain airbag Inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Measure the resistance of the SRS simulator lead L black terminal (A). There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 33-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 104

Scheme 105

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-3x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the left side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-3x indicated? YES -Go to step 13 . NO -Short to another wire in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 10 and No. 11 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
18. Measure the resistance of the SRS simulator lead L black terminal (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 33-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 106

Scheme 107

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-8x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the left side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-8x indicated? YES -Go to step 13 . NO -Short to power in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Reconnect the negative cable to the battery.
18. Turn the ignition switch to ON (II).
19. Measure the voltage between black terminal of SRS simulator lead L (A) and body ground individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 33-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Left Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 108

Scheme 109

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-9x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the left side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the left side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 33-9x indicated? YES -Go to step 13 . NO -Short to ground in the left side curtain airbag inflator; replace the left side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Measure the resistance between black terminal of SRS simulator lead L (A) and body ground individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 34-1x ("x" can be 0 thru 9 or A thru F): Open in the Right Side Curtain Airbag Inflator; DTC 34-2x ("x" can be 0 thru 9 or A thru F): Increased Resistance in the Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 110

Scheme 111

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-1x or 34-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the right side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-1x or 34-2x indicated? YES -Go to step 13 . NO -Open in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Measure the resistance of the SRS simulator lead L black terminal (A). There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 34-3x ("x" can be 0 thru 9 or A thru F): Short to Another Wire or Decreased Resistance in the Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300
3. SRS Short Canceller 070AZ-SAA0100

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 112

Scheme 113

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-3x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the right side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-3x indicated? YES -Go to step 13 . NO -Short to another wire in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Connect an SRS short canceller (070AZ-SAA0100) to SRS unit connector B (39P) terminals No. 24 and No. 25 (see «OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__opening-the-srs-unit-shorting-connectors) ).
18. Measure the resistance of the SRS simulator lead L black terminal (A). There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 34-8x ("x" can be 0 thru 9 or A thru F): Short to Power in the Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 114

Scheme 115

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-8x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the right side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-8x indicated? YES -Go to step 13 . NO -Short to power in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Reconnect the negative cable to the battery.
18. Turn the ignition switch to ON (II).
19. Measure the voltage between black terminal of SRS simulator lead L (A) and body ground individually. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 34-9x ("x" can be 0 thru 9 or A thru F): Short to Ground in the Right Side Curtain Airbag Inflator

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 116

Scheme 117

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-9x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Remove the right side C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
7. Disconnect the SRS floor wire harness 2P connector (A) from the right side curtain airbag 2P connector.
8. Connect the terminals of SRS simulator lead L to the SRS inflator simulator (2 ohms connectors), and then connect SRS simulator lead L to the SRS floor wire harness 2P connector.
9. Reconnect the negative cable to the battery.
10. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 34-9x indicated? YES -Go to step 13 . NO -Short to ground in the right side curtain airbag inflator; replace the right side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Disconnect the negative cable from the battery, then wait at least 3 minutes.
15. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Disconnect the SRS inflator simulator from SRS simulator lead L. Do not disconnect SRS simulator lead L from the SRS floor wire harness 2P connector.
17. Measure the resistance between black terminal of SRS simulator lead L (A) and body ground individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection; if the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness. NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 41-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Left Front Impact Sensor

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 118

Scheme 119

Scheme 120

Scheme 121

Scheme 122

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 41-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Check the connections between SRS unit connector A (39P) and the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), between the left engine compartment wire harness 2P connector and the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), and at connector C303 (see «LEFT ENGINE COMPARTMENT WIRE HARNESS DASHBOARD BRANCH)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__left-engine-compartment-wire-harness-dashboard) ). Are the connections OK? YES -Go to step 7 . NO -Repair the poor connections, then clear the DTC, and retest. If DTC 41-1x is still present, go to step 7 .
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Disconnect the left engine compartment wire harness 2P connector from the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Measure the resistance between SRS unit connector A (39P) terminals No. 36 and No. 37. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10 . NO -Short to another wire in the left engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.
10. Measure the resistance between body ground and SRS unit connector A (39P) terminals No. 36 and No. 37 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 11 . NO -Short to ground in the left engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.
11. Reconnect the negative cable to the battery.
12. Turn the ignition switch to ON (II).
13. Measure the voltage between body ground and SRS unit connector A (39P) terminals No. 36 and No. 37 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 14 . NO -Short to power in the left engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.
14. Turn the ignition switch to LOCK (0).
15. Connect the black terminal of SRS simulator lead L (A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the left engine compartment wire harness 2P connector (B).
16. Measure the resistance between SRS unit connector A (39P) terminals No. 36 and No. 37. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty left front impact sensor or SRS unit; replace the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the left engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.

DTC 42-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Right Front Impact Sensor

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 42-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Check the connections between SRS unit connector A (39P) and the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), between the right engine compartment wire harness 2P connector and the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), and at connector C206 (see «RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__right-engine-compartment-wire-harness-dashboard) ). Are the connections OK? YES -Go to step 7 . NO -Repair the poor connections, then clear the DTC, and retest. If DTC 42-1x is still present, go to step 7 .
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Disconnect the right engine compartment wire harness 2P connector from the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Measure the resistance between SRS unit connector A (39P) terminals No. 38 and No. 39. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10 . NO -Short to another wire in the right engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.
10. Measure the resistance between body ground and SRS unit connector A (39P) terminal No. 38 and No. 39 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 11 . NO -Short to ground in the right engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.
11. Reconnect the negative cable to the battery.
12. Turn the ignition switch to ON (II).
13. Measure the voltage between body ground and SRS unit connector A (39P) terminal No. 38 and No. 39 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 14 . NO -Short to power in the right engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.
14. Turn the ignition switch to LOCK (0).
15. Connect the black terminal of SRS simulator lead L (A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the right engine compartment wire harness 2P connector (B).
16. Measure the resistance between SRS unit connector A (39P) terminals No. 38 and No. 39. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty right front impact sensor or SRS unit; replace the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the right engine compartment wire harness or the dashboard wire harness; replace the faulty harness, then clear the DTC.

DTC 41-2x, 41-3x, 41-9x, 41-Ax, 41-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Front Impact Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 41-2x, 41-3x, 41-9x, 41-Ax, or 41-Bx indicated? YES -Faulty left front impact sensor or SRS unit; replace the left front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 42-2x, 42-3x, 42-9x, 42-Ax, 42-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Front Impact Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 42-2x, 42-3x, 42-9x, 42-Ax, or 42-Bx indicated? YES -Faulty right front impact sensor or SRS unit; replace the right front impact sensor (see «FRONT IMPACT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 43-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Left Side Impact Sensor (first)

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 43-1x indicated? YES - If DTC 43-11 is indicated, go to step 4 . If DTC 43-1x except 43-11 is indicated alone or DTC 43-11 and 45-11 are indicated, faulty left side impact sensor (first); replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If DTC 43-12 and B2-11 are indicated, troubleshoot DTC B2-1x (see «DTC B2-1X ("X" CAN BE 0 THRU 9 OR A THRU F): NO SIGNAL FROM THE REAR SAFING SENSOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__dtc-b2-1x-x-can-be-0) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 4P connector from the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Measure the resistance between SRS unit connector B (39P) terminals No. 36 and No. 37. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 9 . NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
9. Measure the resistance between body ground and SRS unit connector B (39P) terminals No. 36 and No. 37 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10 . NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch to ON (II).
12. Measure the voltage between body ground and SRS unit connector B (39P) terminals No. 36 and No. 37 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 13 . NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Connect the black terminal of SRS simulator lead L(A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the SRS floor wire harness 4P connector (B).
15. Measure the resistance between SRS unit connector B (39P) terminals No. 36 and No. 37. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty left side impact sensor (first) or SRS unit; replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 44-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Right Side Impact Sensor (first)

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 44-1x indicated? YES - If DTC 44-11 is indicated, go to step 4 . If DTC 44-1x except 44-11 is indicated alone, or DTC 44-11 and 46-11 are indicated, faulty right side impact sensor (first); replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 4P connector from the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Measure the resistance between SRS unit connector B (39P) terminals No. 38 and No. 39. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 9 . NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
9. Measure the resistance between body ground and SRS unit connector B (39P) terminals No. 38 and No. 39 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10 . NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch to ON (II).
12. Measure the voltage between body ground and SRS Unit connector B (39P) terminals No. 38 and No. 39 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 13 . NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Connect the black terminal of SRS simulator lead L (A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the SRS floor wire harness 4P connector (B).
15. Measure the resistance between SRS unit connector B (39P) terminals No. 38 and No. 39. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty right side impact sensor (first) or SRS unit; replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 43-2x, 43-8x, 43-9x, 43-Ax, 43-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Side Impact Sensor (first)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 43-2x, 43-8x, 43-9x, 43-Ax, or 43-Bx indicated? YES -Faulty left side impact sensor (first) or SRS unit; replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 44-2x, 44-8x, 44-9x, 44-Ax, 44-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Side Impact Sensor (first)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 44-2x, 44-8x, 44-9x, 44-Ax, or 44-Bx indicated? YES -Faulty right side impact, sensor (first) or SRS unit; replace the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 45-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Left Side Impact Sensor (second)

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 45-1x indicated? YES - If DTC 45-11 is indicated alone or DTC, 45-11 and B2-12 is indicated, go to step 4 . If DTC 45-1x except 45-11 is indicated alone, faulty left side impact sensor (second); replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. If DTC 43-11 and 45-11 are indicated, faulty left side impact sensor (first); replace the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. If DTC 45-11 and B2-11 are indicated, faulty rear safing sensor; replace the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 2P connector from, the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Disconnect the SRS floor wire harness 4P connector from the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Measure the resistance between SRS floor wire harness 2P connector terminals No. 1 and No. 2. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 9 . NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
9. Measure the resistance between body ground and SRS floor wire harness 2P connector terminals No. 1 and No. 2 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10 . NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Measure the voltage between body ground and SRS floor wire harness 2P connector terminals No. 1 and No. 2 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 13 . NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Connect the red terminal of SRS simulator lead L (A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the SRS floor wire harness 4P connector (B).
15. Measure the resistance between SRS floor wire harness 2P connector terminals No. 1 and No. 2. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty left side impact sensor (second) or SRS unit; replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 46-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Right Side Impact Sensor (second)

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 46-1x indicated? YES - If DTC 46-11 is indicated, go to step 4 . If DTC 46-1x except 46-11 is indicated alone, faulty right side impact sensor (second); replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the SRS floor wire harness 4P connector from the right side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Disconnect the SRS floor wire harness 2P connector from the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Measure the resistance between SRS floor wire harness 2P connector terminals No. 1 and No. 2. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 9 . NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
9. Measure the resistance between body ground and SRS floor wire harness 2P connector terminals No. 1 and No. 2 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 10 . NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
10. Reconnect the negative cable to the battery.
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Measure the voltage between body ground and SRS floor wire harness 2P connector terminal No. 1 and No. 2 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 13 . NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
13. Turn the ignition switch to LOCK (0).
14. Connect the red terminal of SRS simulator lead L(A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the SRS floor wire harness 4P connector (B).
15. Measure the resistance between SRS floor wire harness 2P connector the terminals No. 1 and No. 2. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty right side impact sensor (second) or SRS unit; replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC 45-2x, 45-8x, 45-9x, 45-Ax, 45-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Left Side Impact Sensor (second)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES )and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 45-2x, 45-8x, 45-9x, 45-Ax, or 45-Bx indicated? YES -Faulty left side impact sensor (second) or SRS unit; replace the left side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 46-2x, 46-8x, 46-9x, 46-Ax, 46-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Right Side Impact Sensor (second)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 46-2x, 46-8x, 46-9x, 46-Ax, or 46-Bx indicated? YES -Faulty right side impact sensor (second) or SRS unit; replace the right side impact sensor (second) (see «SIDE IMPACT SENSOR (SECOND) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 51-xx, 52-xx, 53-xx, 54-xx, 55-xx, 57-xx, 58-xx ("x" can be 0 thru 9 or A thru F): Internal Failure of the SRS Unit

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before troubleshooting any of these DTCs, check the battery/system voltage and battery cable connections (see BATTERY TEST ). If the voltage is low, repair the charging system, test and charge the battery, or replace the battery before troubleshooting the SRS. If the battery/system voltage is now OK, ask the client if the battery ever went dead or if the engine was started and run with the battery in a low state of charge. A dead battery may trigger one or more of these DTCs. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 51-xx, 52-xx, 53-xx, 54-xx, 55-xx, 57-xx, or 58-xx indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 53-FF: SRS Unit Programming Error

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). This DTC is indicated when a SRS unit update is not completed properly. Do not turn the ignition switch to ACC (I) or LOCK (0) while updating the SRS unit. If you turn the ignition switch to ACC (I) or LOCK (0) before you complete the SRS unit update procedure, the SRS unit can be damaged. Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

1. Do the SRS unit update procedure (see «SRS UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__srs-unit-update) ).
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Turn the ignition switch to ON (II), then wait for 10 seconds.
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 53-FF indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Update is complete.

DTC 56-31: Lost Communication With the PCM (PGM-FI system); DTC 56-32, 56-33: Undefined Data Received From the PCM (PGM-FI system)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 148

1. Check for any F-CAN and B-CAN communication DTCs with the HDS. Are there any communication DTCs? YES -Go to the appropriate DTC troubleshooting. NO -Go to step 2 .
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Turn the ignition switch to ON (II), then wait for 10 seconds.
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 56-31, 56-32, or 56-33 indicated? YES -Go to step 5 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
5. Turn the ignition switch to LOCK (0).
6. Start the engine, and see if the malfunction indicator lamp (MIL) also stays on. Does the MIL stay on longer than 30 seconds? YES -Go to MIL Circuit Troubleshooting (see «MIL CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6) ). NO -Go to step 7 .
7. Turn the ignition switch to LOCK (0).
8. Jump the SCS line with the HDS (see «GENERAL TROUBLESHOOTING INFORMATION»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#fuel-and-emissions-systems-v6) ). NOTE: This step must be done to protect the PCM from damage.
9. Disconnect PCM connector A (49P) from the PCM (see «PCM REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__pcm-replacement) ).
10. Disconnect the negative cable from the battery, then wait at least 3 minutes.
11. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
12. Check for continuity between SRS unit connector A (39P) terminal No, 16 and PCM connector A (49P) terminal No. 49, and between SRS unit connector A (39P) terminal No. 17 and PCM connector A (49P) terminal No. 48. Is there continuity? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the left engine compartment wire harness or the dashboard wire harness. NO -Open in the harness between SRS unit connector A (39P) terminal No. 16 and PCM connector A (49P) terminal No. 49, or between SRS unit connector A (39P) terminal No. 17 and PCM connector A (49P) terminal No. 48 (left engine compartment wire harness or dashboard wire harness); replace the faulty harness, then clear the DTC.

DTC 61-1x ("x" can be 0 thru 9 or A thru F): Open in the Driver's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 149

Scheme 150

Scheme 151

Scheme 152

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds. Buckle and unbuckle the driver's seat belt several times.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 61-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Install a jumper wire between SRS unit connector B (39P) terminal No. 19 and body ground.
6. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
7. Turn the ignition switch to ON (II), then wait for 10 seconds.
8. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 61-2x indicated? YES -Go to step 9 . NO -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness or the driver's seat wire harness.
9. Turn the ignition switch to LOCK (0).
10. Remove the jumper wire from SRS unit connector B (39P).
11. Disconnect the driver's seat wire harness 2P connector (A) from the driver's seat belt buckle switch 2P connector.
12. Turn the ignition switch to ON (II), then wait for 10 seconds.
13. Measure the voltage between driver's seat wire harness 2P connector terminal No. 1 and body ground. There should be more than 10 V. Is the voltage as specified? YES -Go to step 14 . NO -Open in the SRS floor wire harness or the driver's seat wire harness; replace the faulty harness, then clear the DTC.
14. Turn the ignition switch to LOCK (0).
15. Measure the resistance between driver's seat wire harness 2P connector terminal No. 2 and body ground. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty driver's seat belt buckle switch; replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6__front-seat-belt-buckle) ), then clear the DTC. NO -Open in the SRS floor wire harness or the driver's seat wire harness; check for a poor ground at G701 (see «SRS FLOOR WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__srs-floor-wire-harness) ). If the ground is OK, replace the faulty harness, then clear the DTC.

DTC 61-2x ("x" can be 0 thru 9 or A thru F): Short in the Driver's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

Scheme 153

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds. Buckle and unbuckle the driver's seat belt several times.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 61-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the driver's seat wire harness 2P connector (A) from the driver's seat belt buckle switch 2P connector.
6. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
7. Turn the ignition switch to ON (II), then wait for 10 seconds.
8. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 61-2x indicated? YES -Short to ground in the SRS floor wire harness or the driver's seat wire harness; replace the faulty harness, then clear the DTC. NO -Faulty driver's seat belt buckle switch; replace the driver's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6__front-seat-belt-buckle) ), then clear the DTC.

DTC 62-1x ("x" can be 0 thru 9 or A thru F): Open in the Front Passenger's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 154

Scheme 155

Scheme 156

Scheme 157

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds. Buckle and unbuckle the front passenger's seat belt several times.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 62-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Install a jumper wire between SRS unit connector B (39P) terminal No. 21 and body ground.
6. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
7. Turn the ignition switch to ON (II), then wait for 10 seconds.
8. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 62-2x indicated? YES -Go to step 9 . NO -Faulty SRS unit or poor connection at SRS unit connector B (39P) and the SRS unit. Check the connection between the connector and the SRS unit. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the SRS floor wire harness or the front passenger's seat wire harness.
9. Turn the ignition switch to LOCK (0).
10. Remove the jumper wire from SRS unit connector B (39P).
11. Disconnect the front passenger's seat wire harness 2P connector (A) from the front passenger's seat belt buckle switch 2P connector.
12. Turn the ignition switch to ON (II), then wait for 10 seconds.
13. Measure the voltage between front passenger's seat wire harness 2P connector terminal No. 1 and body ground. There should be more than 10 V. Is the voltage as specified? YES -Go to step 14 . NO -Open in the SRS floor wire harness or the front passenger's seat wire harness; replace the faulty harness, then clear the DTC.
14. Turn the ignition switch to LOCK (0).
15. Measure the resistance between front passenger's seat wire harness 2P connector terminal No. 2 and body ground. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty front passenger's seat belt buckle switch; replace the front passenger's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6__front-seat-belt-buckle) ), then clear the DTC. NO -Open in the SRS floor wire harness or the front passenger's seat wire harness; check for a poor ground at G702 (see «SRS FLOOR WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__srs-floor-wire-harness) ). If the ground is OK, replace the faulty harness, then clear the DTC.

DTC 62-2x ("x" can be 0 thru 9 or A thru F): Short in the Front Passenger's Seat Belt Buckle Switch

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

Scheme 158

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds. Buckle and unbuckle the front passenger's seat belt several times.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 62-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the front passenger's seat wire harness 2P connector (A) from the front passenger's seat belt buckle switch 2P connector.
6. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
7. Turn the ignition switch to ON (II), then wait for 10 seconds.
8. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 62-2x indicated? YES -Short to ground in the SRS floor wire harness or the front passenger's seat wire harness; replace the faulty harness, then clear the DTC. NO -Faulty front passenger's seat belt buckle switch; replace the front passenger's seat belt buckle assembly (see «FRONT SEAT BELT BUCKLE»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6__front-seat-belt-buckle) ), then clear the DTC.

DTC 71-1x ("x" can be 0 thru 9 or A thru F): Open in the Driver's Seat Position Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 159

Scheme 160

Scheme 161

Scheme 162

1. Raise the driver's seat all the way up.
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Turn the ignition switch to ON (II), then wait for 10 seconds.
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 71-1x indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures). If another DTC is indicated, troubleshoot the DTC.
5. Turn the ignition switch to LOCK (0).
6. Check the connection between the driver's seat wire harness and the driver's seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), at connector C701 (see «SRS FLOOR WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__srs-floor-wire-harness) ), and ground connection at G701 (see «SRS FLOOR WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__srs-floor-wire-harness) ). Are the connections OK? YES -Go to step 7. NO -Repair the poor connections, then clear the DTC, and retest. If DTC 71-1x is still present, go to step 7.
7. Disconnect the driver's seat wire harness 2P connector (A) from the driver's seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Install a jumper wire between driver's seat wire harness 2P connector terminals No. 1 and No. 2.
9. Disconnect the negative cable from the battery, then wait at least 3 minutes.
10. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
11. Measure the resistance between SRS unit connector B (39P) terminal No. 23 ('11 model) or No. 28 ('12-13 models) and body ground. There should be less than 1.0 ohms. '11 model '12-13 models (Scheme 162): Measuring Resistance Between SRS Unit Connector B (39P) Terminal No. 28 And Body Ground Is the resistance as specified? YES -Faulty driver's seat position sensor or SRS unit; replace the driver's seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the SRS floor wire harness or the driver's seat wire harness; check for a poor ground at G701 (see «CONNECTORS AND HARNESSES (V6)»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6) ). If the ground is OK, replace the faulty harness, then clear the DTC.

DTC 71-2x ("x" can be 0 thru 9 or A thru F): Short in the Driver's Seat Position Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 163

Scheme 164

Scheme 165

1. Raise the driver's seat all the way up.
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Turn the ignition switch to ON (II), then wait for 10 seconds.
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 71-2x indicated? YES -Go to step 5. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures). If another DTC is indicated, troubleshoot the DTC.
5. Turn the ignition switch to LOCK (0).
6. Disconnect the driver's seat wire harness 2P connector (A) from the driver's seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
8. Turn the ignition switch to ON (II), then wait for 10 seconds.
9. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 71-2x indicated? YES -Go to step 10. NO -Faulty driver's seat position sensor; replace the driver's seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
10. Turn the ignition switch to LOCK (0).
11. Disconnect the negative cable from the battery, then wait at least 3 minutes.
12. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
13. Measure the resistance between SRS unit connector B (39P) terminal No. 23 ('11 model) or No. 28 ('12-13 models) and body ground. There should be an open circuit or at least 1 Mohms. '11 model '12-13 models (Scheme 165): Measuring Resistance Between SRS Unit Connector B (39P) Terminal No. 28 And Body Ground Is the resistance as specified? YES -Faulty driver's seat position sensor or SRS unit; replace the driver's seat position sensor (see «INSTALLATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Short to ground in the SRS floor wire harness or the driver's seat wire harness; replace the faulty harness, then clear the DTC.

DTC 81-4x, 81-5x ("x" can be 0 thru 9 or A thru F), 81-63, 81-64: Internal the Failure of the ODS Unit

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the front passenger's weight sensor operation.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-4x, 81-5x, 81-63, or 81-64 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Do the front passenger's weight sensor initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
6. Turn the ignition switch to ON (II), then wait for 10 seconds.
7. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-4x, 81-5x, 81-63, or 81-64 indicated? YES -Go to step 8 . NO -The system is OK at this time.
8. Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-4x, 81-5x, 81-63, or 81-64 indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 81-61: No Signal From the ODS Unit; DTC 81-62: Incorrect Data From the ODS Unit

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the front passenger's weight sensor operation.

Scheme 166

Scheme 167

Scheme 168

Scheme 169

Scheme 170

Scheme 171

Scheme 172

1. Make sure nothing is on the front passenger's seat.
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Turn the ignition switch to ON (II), then wait for 10 seconds.
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-61 or 81-62 indicated? YES -Go to step 5 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
5. Turn the ignition switch to LOCK (0).
6. Check the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 7 . NO -Replace the fuse, then turn the ignition switch to ON (II). If the fuse blows again, check for a short to ground in the driver's under-dash fuse/relay box No. 12 (7.5 A) fuse circuit (dashboard wire harness, audio wire harness, SRS floor wire harness, or ODS unit harness); replace the faulty harness, then clear the DTC, and retest. If the DTC is still present, replace the driver's under-dash fuse/relay box, then clear the DTC. USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__drivers-under-dash-fuserelay-box-micu-removal) ) Canada models (see «CANADA MODELS»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__canada-models) )
7. Remove the back panel (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
8. Turn over the seat-back cover/pad to gain access to the ODS unit (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
9. Remove the cover from the ODS unit (see step 5 ).
10. Check the connection between the ODS unit 18P connector (A) and the ODS unit. Is the connection OK? YES -Go to step 11 . NO -Repair the poor connection, then clear the DTC, and retest. If DTC 81-61 or 81-62 is still present, go to step 11 .
11. Disconnect the ODS unit 18P connector (A) from the ODS unit.
12. Turn the ignition switch to ON (II), then wait for 10 seconds.
13. Measure the voltage between ODS unit 18P connector terminal No. 1 and body ground. There should be battery voltage. Is there battery voltage? YES -Go to step 14 . NO -Open in the dashboard wire harness, the audio wire harness, the SRS floor wire harness, or the ODS unit harness; replace the faulty harness, then clear the DTC.
14. Turn the ignition switch to LOCK (0).
15. Measure the resistance between ODS unit 18P connector terminals No. 12 and body ground. There should be less than 1.0 ohms. Is the resistance as specified? YES -Go to step 16 . NO -Open in the SRS floor wire harness, the ODS unit harness, poor connection at the ground G702 (see «SRS FLOOR WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__srs-floor-wire-harness) ), or poor connection at the ODS unit ISP connector and the ODS unit. Check the connectors; if the connection is OK, replace the faulty harness, then clear the DTC.
16. Disconnect the negative cable from the battery, then wait at least 3 minutes.
17. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
18. Measure the resistance between SRS unit connector B (39P) terminal No. 1 and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 19 . NO -Short to ground in the SRS floor wire harness or the ODS unit harness; replace the faulty harness, then clear the DTC.
19. Reconnect the negative cable to the battery.
20. Turn the ignition switch to ON (II).
21. Measure the voltage between SRS unit connector B (39P) terminal No. 1 and body ground. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 22 . NO -Short to power in the SRS floor wire harness or the ODS unit harness; replace the faulty harness, then clear the DTC.
22. Turn the ignition switch to LOCK (0).
23. Measure the resistance between SRS unit connector B (39P) terminal No. 1 and ODS unit 18P connector terminal No. 7. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty ODS unit or SRS unit; replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the harness between SRS unit connector B (39P) terminal No. 1 and ODS unit 18P connector terminal No. 7 (SRS floor wire harness or ODS unit harness); replace the faulty harness, then clear the DTC.

DTC 81-71, 81-78: ODS Unit Not Calibrated

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the front passenger's weight sensor operation.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-71 or 81-78 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Do the front passenger's weight sensor initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
6. Turn the ignition switch to ON (II), then wait for 10 seconds.
7. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-71 or 81-78 indicated? YES -Go to step 8 . NO -The system is OK at this time.
8. Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-71 or 81-78 indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 81-79: Front Passenger's Weight Sensors Initial Check Failure

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the front passenger's weight sensor operation.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-79 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Make sure nothing is on the front passenger's seat.
6. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
7. Turn the ignition switch to ON (II), then wait for 10 seconds.
8. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-79 indicated? YES -Go to step 9 . NO -The system is OK at this time.
9. Turn the ignition switch to LOCK (0).
10. Loosen the front passenger's seat mounting bolts, and shake the seat in all directions. Tighten the seat mounting bolts to the specified torque (see «FRONT SEAT RECLINE MOTOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-motor-replacement) ).
11. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
12. Do the front passenger's weight sensor initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
13. Turn the ignition switch to ON (II), then wait for 10 seconds.
14. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-79 indicated? YES -Go to step 15 . NO -The system is OK at this time.
15. Replace the front passenger's weight sensor assembly (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
16. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
17. Turn the ignition switch to ON (II), then wait for 10 seconds.
18. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 81-79 indicated? YES -Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 82-11: No Signal From the Inner Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). These SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Scheme 173

Scheme 174

Scheme 175

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 82-11 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select SWS DTC CHECK. Is an SWS DTC also indicated? YES - DTC 11-11: Short to power in the front passenger's weight sensor (inner side) power circuit; go to step 5 . DTC 11-12: Short to ground in the front passenger's weight sensor (inner side) power circuit; go to step 11 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) .
5. Turn the ignition switch to LOCK (0).
6. Disconnect the ODS unit harness 2P connector (A) from the front passenger's weight sensor (inner side).
7. Turn the ignition switch to ON (II).
8. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
9. Turn the ignition switch to ON (II), then wait for 10 seconds.
10. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select SWS DTC CHECK. Is SWS DTC 11-11 indicated? YES -Short to power in the ODS unit harness; replace the ODS unit harness, then clear the DTC, and retest. If the DTC is still present, replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Faulty front passenger's weight sensor (inner side); replace the inner side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
11. Turn the ignition switch to LOCK (0).
12. Disconnect the ODS unit harness 2P connector (A) from the front passenger's weight sensor (inner side).
13. Turn the ignition switch to ON (II).
14. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
15. Turn the ignition switch to ON (II), then wait for 10 seconds.
16. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select SWS DTC CHECK. Is SWS DTC 11-12 indicated? YES -Go to step 17 . NO -Faulty front passenger's weight sensor (inner side); replace the inner side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
17. Turn the ignition switch to LOCK (0).
18. Measure the resistance between ODS unit harness 2P connector terminal No. 2 and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty ODS unit; replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Short to ground in the ODS unit harness; replace the ODS unit harness, then clear the DTC.

DTC 82-12: No Signal From the Inner Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

Scheme 176

Scheme 177

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 82-12 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the ODS unit harness 2P connector (A) from the front passenger's weight sensor (inner side).
6. Turn the ignition switch to ON (II).
7. Measure the voltage between ODS unit harness 2P connector terminals No. 1 and No. 2. There should be more than 6 V. Is the voltage as specified? YES -Faulty front passenger's weight sensor (inner side); replace the inner side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Open in the ODS unit harness; replace the ODS unit harness, then clear the DTC, and retest. If the DTC is still present, replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).

DTC 82-13: No Signal From the Inner Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 82-13 indicated? YES -Faulty front passenger's weight sensor (inner side); replace the inner side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 83-21: No Signal From the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). These SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Scheme 178

Scheme 179

Scheme 180

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 83-21 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select SWS DTC CHECK. Is an SWS DTC also indicated? YES - DTC 21-11: Short to power in the front passenger's weight sensor (outer side) power circuit; go to step 5 . DTC 21-12: Short to ground in the front passenger's weight sensor (outer side) power circuit; go to step 11 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) .
5. Turn the ignition switch to LOCK (0).
6. Disconnect the ODS unit harness 3P connector (A) from the front passenger's weight sensor (outer side).
7. Turn the ignition switch to ON (II).
8. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
9. Turn the ignition switch to ON (II), then wait for 10 seconds.
10. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select SWS DTC CHECK. Is SWS DTC 21-11 indicated? YES -Short to power in the ODS unit harness; replace the ODS unit harness, then clear the DTC, and retest. If the DTC is still present, replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Faulty front passenger's weight sensor (outer side); replace the outer side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
11. Turn the ignition switch to LOCK (0).
12. Disconnect the ODS unit harness 3P connector (A) from the front passenger's weight sensor (outer side).
13. Turn the ignition switch to ON (II).
14. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
15. Turn the ignition switch to ON (II), then wait for 10 seconds.
16. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select SWS DTC CHECK. Is SWS DTC 21-12 indicated? YES -Go to step 17 . NO -Faulty front passenger's weight sensor (outer side); replace the outer side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
17. Turn the ignition switch to LOCK (0).
18. Measure the resistance between ODS unit harness 3P connector terminal No. 3 and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Faulty ODS unit; replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Short to ground in the ODS unit harness; replace the ODS unit harness, then clear the DTC.

DTC 83-22: No Signal From the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

Scheme 181

Scheme 182

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 83-22 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the ODS unit harness 3P connector (A) from the front passenger's weight sensor (outer side).
6. Turn the ignition switch to ON (II).
7. Measure the voltage between ODS unit harness 3P connector terminals No. 1 and No. 3. There should be more than 6 V. Is the voltage as specified? YES -Faulty front passenger's weight sensor (outer side); replace the outer side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Open in the ODS unit harness; replace the ODS unit harness, then clear the DTC, and retest: If the DTC is still present, replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).

DTC 83-23: No Signal From the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ).

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 83-23 indicated? YES -Faulty front passenger's weight sensor (outer side); replace the outer side front passenger's weight sensor (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC 85-4x, 85-5x ("x" can be 0 thru 9 or A thru F), 85-63, 85-64: Internal Failure of the ODS Unit

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the ODS unit operation.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-4x, 85-5x, 85-63, or 85-64 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Do the ODS unit initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
6. Turn the ignition switch to ON (II), then wait for 10 seconds.
7. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-4x, 85-5x, 85-63, or 85-64 indicated? YES -Go to step 8 . NO -The system is OK at this time.
8. Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-4x, 85-5x, 85-63, or 85-64 indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 85-61: No Signal From the ODS Unit; DTC 85-62: Incorrect Data From the ODS Unit

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the ODS unit operation.

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

Scheme 188

Scheme 189

1. Make sure nothing is on the front passenger's seat.
2. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
3. Turn the ignition switch to ON (II), then wait for 10 seconds.
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-61 or 85-62 indicated? YES -Go to step 5 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
5. Turn the ignition switch to LOCK (0).
6. Check the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 7 . NO -Replace the fuse, then turn the ignition switch to ON (II). If the fuse blows again, check for a short to ground in the driver's under-dash fuse/relay box No. 12 (7.5 A) fuse circuit (dashboard wire harness, audio wire harness, SRS floor wire harness, or ODS unit harness); replace the faulty harness, then clear the DTC, and retest. If the DTC is still present, replace the driver's under-dash fuse/relay box, then clear the DTC. USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__drivers-under-dash-fuserelay-box-micu-removal) ) Canada models (see «CANADA MODELS»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__canada-models) )
7. Remove the back panel (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
8. Turn over the seat-back cover/pad to gain access to the ODS unit (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
9. Remove the cover from the ODS unit (see step 5 ).
10. Check the connection between the ODS unit 18P connector (A) and the ODS unit. Is the connection OK? YES -Go to step 11 . NO -Repair the poor connection, then clear the DTC, and retest. If DTC 85-61 or 85-62 is still present, go to step 11 .
11. Disconnect the ODS unit 18P connector (A) from the ODS unit.
12. Turn the ignition switch to ON (II), then wait for 10 seconds.
13. Measure the voltage between ODS unit 18P connector terminal No. 1 and body ground. There should be battery voltage. Is there battery voltage? YES -Go to step 14 . NO -Open in the dashboard wire harness, the audio wire harness, the SRS floor wire harness, or the ODS unit harness; replace the faulty harness, then clear the DTC.
14. Turn the ignition switch to LOCK (0).
15. Measure the resistance between ODS unit 18P connector terminals No. 12 and body ground. There should be less than 1.0 ohms. Is the resistance as specified? YES -Go to step 16 . NO -Open in the SRS floor wire harness, the ODS unit harness, poor connection at the ground G702 (see «SRS FLOOR WIRE HARNESS»(/acura/tsx/ii-2008-2014/remont/body-electrical/#connectors-and-harnesses-v6__srs-floor-wire-harness) ), or poor connection at the ODS unit 18P connector and the ODS unit. Check the connectors; if the connection is OK, replace the faulty harness, then clear the DTC.
16. Disconnect the negative cable from the battery, then wait at least 3 minutes.
17. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
18. Measure the resistance between SRS unit connector B (39P) terminal No. 1 and body ground. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 19 . NO -Short to ground in the SRS floor wire harness or the ODS unit harness; replace the faulty harness, then clear the DTC.
19. Measure the resistance between SRS unit connector B (39P) terminal No. 1 and ODS unit 18P connector terminal No. 7. There should be less than 1.0 ohms. Is the resistance as specified? YES -Go to step 20 . NO -Open in the harness between SRS unit connector B (39P) terminal No. 1 and ODS unit 18P connector terminal No. 7 (SRS floor wire harness or ODS unit harness); replace the faulty harness, then clear the DTC.
20. Reconnect the negative cable to the battery.
21. Turn the ignition switch to ON (II).
22. Measure the voltage between SRS unit connector B (39P) terminal No. 1 and body ground. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 23 . NO -Short to power in the SRS floor wire harness or the ODS unit harness; replace the faulty harness, then clear the DTC.
23. Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
24. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
25. Turn the ignition switch to ON (II), then wait for 10 seconds.
26. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-61 or 85-62 indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 85-71, 85-78: ODS Unit Not Initialized

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the ODS unit operation.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-71 or 85-78 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Do the ODS unit initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
6. Turn the ignition switch to ON (II), then wait for 10 seconds.
7. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-71 or 85-78 indicated? YES -Go to step 8 . NO -The system is OK at this time.
8. Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Turn the ignition switch to ON (II), then wait for 10 seconds.
11. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-71 or 85-78 indicated? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 85-79: OPDS Sensor Initial Check Failure

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. These DTCs are codes that relate to the ODS unit operation.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-79 indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Make sure nothing is on the front passenger's seat.
6. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
7. Turn the ignition switch to ON (II), then wait for 10 seconds.
8. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-79 indicated? YES -Go to step 9 . NO -The system is OK at this time.
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Do the ODS unit initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 85-79 indicated? YES -Go to step 13. NO -The system is OK at this time.
13. Replace the ODS unit (see «ODS Unit Replacement»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
14. Clear the DTCs with the HDS (see «How to Clear DTCs»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
15. Turn the ignition switch to ON (II), then wait for 10 seconds.
16. Check for DTCs with the HDS. Is DTC 85-79 indicated? YES -Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the seat-back cover/pad with equipped OPDS sensor (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 86-1x ("x" can be 0 thru 9 or A thru F): Faulty OPDS Seat-Back Sensor; DTC 86-2x ("x" can be 0 thru 9 or A thru F): Faulty OPDS Seat Support Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 190

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 86-1x or 86-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Remove the back panel (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
6. Turn over the seat-back cover/pad to gain access to the ODS unit (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
7. Remove the cover (A), then check the connection between the ODS unit 18P connector (B) and the OPDS sensor connectors (C), and the ODS unit. Are the connections OK? YES -Go to step 8 . NO -Repair the poor connections, then clear the DTC, and retest. If DTC 86-1x or 86-2x is still present, go to step 8 .
8. Replace the seat-back cover/pad with equipped OPDS sensor (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
9. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
10. Do the ODS unit initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
11. Turn the ignition switch to ON (II), then wait for 10 seconds.
12. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 86-1x or 86-2x indicated? YES -Replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The system is OK at this time.

DTC 92-1x ("x" can be 0 thru 9 or A thru F): Short to Power in the Passenger's Airbag Cutoff Indicator

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. If there are other SRS DTCs stored with 92-1x; troubleshoot them first.

Scheme 191

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 92-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the passenger's airbag cutoff indicator 4P connector (see «PASSENGER'S AIRBAG CUTOFF INDICATOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Reconnect the negative cable to the battery.
9. Turn the ignition switch to ON (II).
10. Measure the voltage between SRS unit connector A (39P) terminal No. 20 and body ground. There should be less than 0.2 V. Is the voltage as specified? YES -Faulty passenger's airbag cutoff indicator or SRS unit; replace the passenger's airbag cutoff indicator (see «PASSENGER'S AIRBAG CUTOFF INDICATOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Short to power in the dashboard wire harness or the audio wire harness; replace the faulty harness, then clear the DTC.

DTC 92-2x ("x" can be 0 thru 9 or A thru F): Open or Short to Ground in the Passenger's Airbag Cutoff Indicator

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest. If there are other SRS DTCs stored with 92-2x; troubleshoot them first.

Scheme 192

Scheme 193

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 92-2x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Disconnect the passenger's airbag cutoff indicator 4P connector (see «PASSENGER'S AIRBAG CUTOFF INDICATOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Measure the resistance between SRS unit connector A (39P) terminal No. 20 and passenger's airbag cutoff indicator 4P connector terminal No. 1. There should be less than 1.0 ohms. Is the resistance as specified? YES -Go to step 9 . NO -Open in the dashboard wire harness or the audio wire harness; replace the faulty harness, then clear the DTC.
9. Measure the resistance between SRS unit connector A (39P) terminal No. 20 and body ground. There should be an open circuit or more than 1 Mohms. Is the resistance as specified? YES -Faulty passenger's airbag cutoff indicator or SRS unit; replace the passenger's airbag cutoff indicator (see «PASSENGER'S AIRBAG CUTOFF INDICATOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Short to ground in the dashboard wire harness or the audio wire harness; replace the faulty harness, then clear the DTC.

DTC A1-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VA line)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 194

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC A1-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Check the No. 12 (7.5 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 6 . NO -Replace the fuse, then turn the ignition switch to ON (II). If the fuse blows again, check for a short to ground in the driver's under-dash fuse/relay box No. 12 (7.5 A) fuse circuit (dashboard wire harness, audio wire harness, SRS floor wire harness, or ODS unit harness); replace the faulty harness, then clear the DTC, and retest. If the DTC is still present, replace the driver's under-dash fuse/relay box, then clear the DTC. USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__drivers-under-dash-fuserelay-box-micu-removal) ) Canada models (see «CANADA MODELS»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__canada-models) )
6. Disconnect the negative cable from the battery, then wait at least 3 minutes.
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Reconnect the negative cable to the battery.
9. Turn the ignition switch to ON (II).
10. Measure the voltage between SRS unit connector A (39P) terminal No. 26 and body ground. There should be battery voltage. Is the battery voltage? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit; check the connection. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Open in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC A2-1x ("x" can be 0 thru 9 or A thru F): Faulty Power Supply (VB line)

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 195

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC A2-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Check the No. 11 (10 A) fuse in the driver's under-dash fuse/relay box. Is the fuse OK? YES -Go to step 6 . NO -Replace the fuse, then turn the ignition switch to ON (II). If the fuse blows again, check for a short to ground in the dashboard wire harness in the driver's under-dash fuse/relay box No. 11 (10 A) fuse circuit; replace the dashboard wire harness, then clear the DTC, and retest. If the DTC is still present, replace the driver's under-dash fuse/relay box, then clear the DTC. USA models (see «DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__drivers-under-dash-fuserelay-box-micu-removal) ) Canada models (see «CANADA MODELS»(/acura/tsx/ii-2008-2014/remont/fuses-circuit-breakers/#under-dash-fuserelay-box-v6__canada-models) )
6. Disconnect the negative cable from the battery, then wait at least 3 minutes.
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Reconnect the negative cable to the battery.
9. Turn the ignition switch to ON (II).
10. Measure the voltage between SRS unit connector A (39P) terminal No. 27 and body ground. There should be battery voltage. Is the battery voltage? YES -Faulty SRS unit or poor connection at SRS unit connector A (39P) and the SRS unit; check the connection. If the connection is OK, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). If the DTC does not clear, replace the dashboard wire harness. NO -Open in the dashboard wire harness; replace the dashboard wire harness, then clear the DTC.

DTC A3-1x ("x" can be 0 thru 9 or A thru F): SRS Unit Connector A Not Properly Installed

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC A3-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Check the connection between SRS unit connector A (39P) and the SRS unit. Is the connection OK? YES -Go to step 7 . NO -Repair the poor connection, then clear the DTC, and retest. If DTC A3-1x is still present, go to step 7 .
7. Disconnect SRS unit connector A (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Check for bent or damaged terminals on the SRS unit. Are any terminals bent or damaged? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Replace the dashboard wire harness, then clear the DTC.

DTC A4-1x ("x" can be 0 thru 9 or A thru F): SRS Unit Connector B Not Properly Installed

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC A4-1x indicated? YES -Go to step 4 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
4. Turn the ignition switch to LOCK (0).
5. Disconnect the negative cable from the battery, then wait at least 3 minutes.
6. Check the connection between SRS unit connector B (39P) and the SRS unit. Is the connection OK? YES -Go to step 7 . NO -Repair the poor connection, then clear the DTC, and retest. If DTC A4-1x is still present, go to step 7 .
7. Disconnect SRS unit connector B (39P) from the SRS unit (see «DISCONNECTING SYSTEM CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Check for bent or damaged terminals on the SRS unit. Are any terminals bent or damaged? YES -Replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Replace the SRS floor wire harness, then clear the DTC.

DTC B2-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Rear Safing Sensor

Special Tools Required

1. SRS Inflator Simulator 07SAZ-TB4011A
2. SRS Simulator Lead L 070AZ-SNAA300

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ), General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ), and Battery Terminal Disconnection and Reconnection (see USING THE GR8 BATTERY DIAGNOSTIC STATION ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

Scheme 196

Scheme 197

Scheme 198

Scheme 199

Scheme 200

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC B2-11 indicated? YES -Go to step 4 . NO -Go to step 5 .
4. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 45-11 also indicated? YES -Faulty rear safing sensor; replace the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC. NO -Go to step 7 .
5. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC B2-1x (except B2-11) also indicated? YES -Go to step 6 . NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.
6. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC 45-11 also indicated? YES -Troubleshoot DTC 45-1x (see «DTC 45-1X ("X" CAN BE 0 THRU 9 OR A THRU F): NO SIGNAL FROM THE LEFT SIDE IMPACT SENSOR (SECOND)»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__dtc-45-1x-x-can-be-0) ). NO -Faulty rear safing sensor; replace the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC.
7. Turn the ignition switch to LOCK (0).
8. Disconnect the negative cable from the battery, then wait at least 3 minutes.
9. Disconnect the SRS floor wire harness 4P connector from the left side impact sensor (first) (see «SIDE IMPACT SENSOR (FIRST) REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
10. Disconnect the SRS floor wire harness 4P connector from the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
11. Measure the resistance between SRS floor wire harness 4P connector (rear safing sensor) terminals No. 2 and No. 3. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 12 . NO -Short to another wire in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
12. Measure the resistance between body ground and SRS floor wire harness 4P connector (rear safing sensor) terminals No. 2 and No. 3 individually. There should be an open circuit or at least 1 Mohms. Is the resistance as specified? YES -Go to step 14 . NO -Short to ground in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
13. Reconnect the negative cable to the battery.
14. Turn the ignition switch to ON (II), then wait for 10 seconds.
15. Measure the voltage between body ground and SRS floor wire harness 4P connector (rear safing sensor) terminals No. 2 and No. 3 individually. There should be less than 0.2 V. Is the voltage as specified? YES -Go to step 16 . NO -Short to power in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.
16. Turn the ignition switch to LOCK (0).
17. Connect the red terminal of SRS simulator lead L (A) to the SRS inflator simulator (jumper connector), and then connect SRS simulator lead L to the SRS floor wire harness 4P connector (B).
18. Measure the resistance between SRS floor wire harness 4P connector (rear safing sensor) terminals No. 2 and No. 3. There should be less than 1.0 ohms. Is the resistance as specified? YES -Faulty rear safing sensor or SRS unit; replace the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Open in the SRS floor wire harness; replace the SRS floor wire harness, then clear the DTC.

DTC B2-2x, B2-8x, B2-9x, B2-Ax, B2-Bx ("x" can be 0 thru 9 or A thru F): Internal Failure of the Rear Safing Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC B2-2x, B2-8x, B2-9x, B2-Ax, or B2-Bx indicated? YES -Faulty rear safing sensor or SRS unit; replace the rear safing sensor (see «REAR SAFING SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), then clear the DTC, and retest. If the DTC is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC Ex-11 ("x" can be 0 thru 9 or A thru F): Control Operation Recorded

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Clear the DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
2. Turn the ignition switch to ON (II), then wait for 10 seconds.
3. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Is DTC Ex-11 indicated? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Intermittent failure, the system is OK at this time. Go to «TROUBLESHOOTING INTERMITTENT FAILURES»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__troubleshooting-intermittent-failures) . If another DTC is indicated, troubleshoot the DTC.

DTC Fx-11 ("x" can be 0 thru 9 or A thru F): Airbags and/or Tensioners Deployment Recorded

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, review SRS Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ) and General Troubleshooting Information (see DISCONNECTING SYSTEM CONNECTOR ). Refer to the DTCs shown: DTC F1-11: Driver's airbag and/or driver's seat belt tensioner deployed. DTC F2-11: Front passenger's airbag and/or front passenger's seat belt tensioner deployed. DTC F3-11: Driver's side airbag, left side curtain airbag, and/or driver's seat belt tensioner deployed. DTC F4-11: Front passenger's side airbag, right side curtain airbag, and/or front passenger's seat belt tensioner deployed. DTC F6-11: Left side curtain airbag or right side curtain airbag deployed.

When any airbags or tensioners have deployed, go to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT .

DTC 41-xx, 42-xx, 43-xx ("x" can be 0 thru 9 or A thru F): Internal Failure of the ODS Unit

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 81-4x (see DTC 81-4X, 81-5X ("X" CAN BE 0 THRU 9 OR A THRU F), 81-63, 81-64: INTERNAL THE FAILURE OF THE ODS UNIT ).

DTC 71-xx ("x" can be 0 thru 9 or A thru F): ODS Unit Not Calibrated

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 81-71 (see DTC 81-71, 81-78: ODS UNIT NOT CALIBRATED ).

DTC 11-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Inner Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 82-11 (see DTC 82-11: NO SIGNAL FROM THE INNER SIDE FRONT PASSENGER'S WEIGHT SENSOR ).

DTC 12-2x ("x" can be 0 thru 9 or A thru F): No Signal From the Inner Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 82-12 (see DTC 82-12: NO SIGNAL FROM THE INNER SIDE FRONT PASSENGER'S WEIGHT SENSOR ).

DTC 13-3x ("x" can be 0 thru 9 or A thru F): No Signal From the Inner Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 82-13 (see DTC 82-13: NO SIGNAL FROM THE INNER SIDE FRONT PASSENGER'S WEIGHT SENSOR ).

DTC 21-1x ("x" can be 0 thru 9 or A thru F): No Signal From the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 83-21 (see DTC 82-13: NO SIGNAL FROM THE INNER SIDE FRONT PASSENGER'S WEIGHT SENSOR ).

DTC 22-2x ("x" can be 0 thru 9 or A thru F): No Signal From the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 83-22 (see DTC 83-22: NO SIGNAL FROM THE OUTER SIDE FRONT PASSENGER'S WEIGHT SENSOR ).

DTC 23-3x ("x" can be 0 thru 9 or A thru F): No Signal From the Outer Side Front Passenger's Weight Sensor

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Only read DTCs from the SRS menu, not from SWS menus unless instructed to check SWS DTCs. SWS (ODS unit) DTCs are subcodes of SRS unit DTCs. Only troubleshoot the corresponding SRS DTCs. Also these SWS DTCs are cleared by turning the ignition switch to LOCK (0).

Do the troubleshooting for SRS DTC 83-23 (see DTC 83-23: NO SIGNAL FROM THE OUTER SIDE FRONT PASSENGER'S WEIGHT SENSOR ).

SRS indicator does not come on

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Turn the ignition switch to LOCK (0), then wait for 10 seconds.
2. Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Does the SRS indicator come on? YES -Intermittent failure, the system is OK at this time. NO -Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Connect the HDS to the data link connector (DLC) (see step 2 ).
5. Turn the ignition switch to ON (II).
6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
7. Do the gauge control module self-diagnostic function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__self-diagnostic-function) ). Does the SRS indicator blink? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Faulty gauge control module; replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__gauge-control-module-replacement) ).

SRS indicator stays on, but no DTCs are stored, or cannot be read

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before doing this troubleshooting procedure, make sure the battery is fully charged. If the battery voltage is low, SRS indicator may stays on. Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Start the engine, and see if the malfunction indicator lamp (MIL) also stays on. Does the MIL stay on longer than 30 seconds? YES -Go to MIL Circuit Troubleshooting (see «MIL CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6) ). NO -Go to step 2 .
2. Check for DTCs with the HDS (see «HOW TO READ DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-read-dtcs) ). Are any SRS DTCs indicated? YES -Do the SRS DTC troubleshooting. NO -Go to step 3 .
3. Check for body electrical DTCs with the HDS (see «WIRE COLOR CODES»(/acura/tsx/ii-2008-2014/remont/body-electrical/#body-electrical-special-tools-v6__wire-color-codes) ). Is DTC U0151 indicated? YES -Troubleshoot DTC U0151 (see «DTC U0151: GAUGE CONTROL MODULE LOST COMMUNICATION WITH SRS UNIT (SRS MESSAGE)»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__dtc-u0151-gauge-control-module-lost) ). NO -Go to step 4 .
4. Do the gauge control module self-diagnostic function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__self-diagnostic-function) ). Does the SRS indicator blink? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Faulty gauge control module; replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__gauge-control-module-replacement) ).

Side airbag cutoff indicator stays on

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Make sure nothing is on the front passenger's seat.
2. Make sure the seat-back is dry.
3. Turn the ignition switch to ON (II), and see if the SRS indicator comes on. Does the SRS indicator come on and stay on? YES -Go to the Symptom Troubleshooting " «SRS INDICATOR STAYS ON, BUT NO DTCS ARE STORED, OR CANNOT BE READ»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__srs-indicator-stays-on-but-no) ". NO -Go to step 4 .
4. Turn the ignition switch to LOCK (0).
5. Check for body electrical DTCs with the HDS (see «WIRE COLOR CODES»(/acura/tsx/ii-2008-2014/remont/body-electrical/#body-electrical-special-tools-v6__wire-color-codes) ). Is DTC U0151 indicated? YES -Troubleshoot DTC U0151 (see «DTC U0151: GAUGE CONTROL MODULE LOST COMMUNICATION WITH SRS UNIT (SRS MESSAGE)»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__dtc-u0151-gauge-control-module-lost) ). NO -Go to step 6 .
6. Do the gauge control module self-diagnostic function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__self-diagnostic-function) ). Does the side airbag cutoff indicator blink? YES -Go to step 7. NO -Faulty gauge control module; replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__gauge-control-module-replacement) ).
7. Do the ODS unit initialization (see «ODS Unit Initialization»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__ods-unit-initialization) ).
8. Turn the ignition switch to ON (II), and see if the side airbag cutoff indicator comes on. Does the side airbag cutoff indicator come on and stay on? YES -Replace the seat-back cover/pad equipped with an OPDS sensor (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ), and retest. If the problem is still present, replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The vehicle is OK at this time.

Side airbag cutoff indicator does not come on

Note. Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). If the SRS indicator also stays on, go to SRS INDICATOR STAYS ON, BUT NO DTCS ARE STORED, OR CANNOT BE READ . Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Turn the ignition to switch LOCK(0), then wait for 10 seconds.
2. Turn the ignition switch to ON (II), and check that the side airbag cutoff indicator comes on for about 6 seconds. Does the side airbag cutoff indicator come on? YES -Intermittent failure, the system is OK at this time. NO -Go to step 3 .
3. Turn the ignition switch to LOCK (0).
4. Connect the HDS to the data link connector (DLC) (see step 2 ).
5. Turn the ignition switch to ON (II).
6. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
7. Do the gauge control module self-diagnostic function (see «SELF-DIAGNOSTIC FUNCTION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__self-diagnostic-function) ). Does the side airbag cutoff indicator blink? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Faulty gauge control module; replace the gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#gauges-v6__gauge-control-module-replacement) ).

Passenger's airbag cutoff indicator stays on or comes on suddenly

Note. Under the following conditions, the passenger's airbag cutoff indicator stays on or comes on suddenly: Before doing this troubleshooting procedure, find out if the vehicle was in a collision. If so, verify that all the required components were replaced with new components, of the correct part number, and that they were properly installed (see COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT ). When no one is sitting on the front passenger's seat, but there is an object on the seat more than 11 lbs (5 kg). The front seat belt is buckled, but no one is sitting on the front passenger's seat. Someone who is less than about 65 lbs (30 kg) is sitting on the front passenger's seat. Before replacing the SRS unit, check the SRS unit software version with the HDS. If the software version is not the latest, update the SRS unit software (see SRS UNIT UPDATE ), and retest.

1. Check for these items, then recheck the passenger's airbag cutoff indicator. The front passenger's seat is installed correctly. Nothing is/was on the front passenger's seat. Nothing is/was under the front passenger's seat. Nothing is/was in the front passenger's seat-back pocket. Whoever was sitting on the front passenger's seat was sitting in the proper sitting position. The seat weight sensors may not measure the correct weight of the front passenger. If the front passenger's weight is more than 65 lbs (30 kg) but is supporting some of their body weight with their feet on the floor, or with their hands and arms on an arm rest, the actual weight of the passenger is not measured. Does the passenger's airbag cutoff indicator stay on? YES -Go to step 2 . NO -The vehicle is OK at this time.
2. Turn the ignition switch to LOCK (0).
3. Connect the HDS to the data link connector (DLC) (see step 2 ).
4. Make sure the HDS communicates with the vehicle and the SRS unit. If it does not communicate, go to the DLC circuit troubleshooting (see «DLC CIRCUIT TROUBLESHOOTING»(/acura/tsx/ii-2008-2014/remont/testing-diagnostics/#pgm-fi-system-v6__dlc-circuit-troubleshooting) ).
5. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select AFTER REPLACING FRONT PASSENGER'S SEAT COMPONENT(S), and follows the prompts. Does the passenger's airbag cutoff indicator stay on? YES -Go to step 6 . NO -The vehicle is OK at this time.
6. From the HDS Main Menu, select SRS, then Inspection. In the Inspection Menu, select AFTER A VEHICLE COLLISION, and follows the prompts. Does the passenger's airbag cutoff indicator stay on? YES -Faulty SRS unit; replace the SRS unit (see «SRS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), and retest. If the problem is still present, replace the ODS unit (see «ODS UNIT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), and retest. If the problem is still present, replace the front passenger's weight sensors as an assembly (see «FRONT PASSENGER'S WEIGHT SENSOR REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -Troubleshooting is complete.
7. Replace the SRS unit (see «SRS Unit Replacement»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
8. Turn the ignition switch to ON (II), and see if the side airbag cutoff indicator comes on. Does the side airbag cutoff indicator come on and stay on? YES -Replace the seat-back cover/pad equipped with an OPDS sensor (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ), and retest. If the problem is still present, replace the SRS unit (see «SRS Unit Replacement»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ). NO -The vehicle is OK at this time.

Component Replacement/Inspection After Deployment

Note. If there is a breaking or damage found in harness relevant to the replacement parts shown below, replace it, do not repair. Before doing any SRS repairs, check for DTCs with the HDS (see HOW TO READ DTCS ) for the less obvious deployed components (front seat belt tensioners, front impact sensors, side impact sensors, rear safing sensor, etc). Do not replace the ODS unit unless it is physically damaged or a specific fault was found during DTC troubleshooting. Because it could complicate troubleshooting other DTCs. After a vehicle collision, do the ODS UNIT OPERATION CHECK . After a vehicle collision, inspect the front seat active head restraints (see FRONT SEAT ACTIVE HEAD RESTRAINT INSPECTION ).

After a collision where the front seat belt tensioners deployed, replace these items

1. SRS unit
2. Front seat belt(s)
3. Front impact sensor(s)

After a collision where the front airbag(s) deployed, replace these items

1. SRS unit
2. Deployed front airbag(s)
3. Front seat belt(s)
4. Front impact sensor(s)
5. Dashboard

After a collision where the side airbag has deployed, replace the items for the side(s) that deployed

1. SRS unit
2. Deployed side airbag(s)
3. Side impact sensor(s) (first)
4. Side impact sensor(s) (second)
5. B-pillar lower trim
6. Seat frame and related parts
7. Front seat belt(s)

After a collision where the side curtain airbag has deployed, replace the items for the side(s) that deployed

1. SRS unit
2. Deployed side curtain airbag(s)
3. Front seat belt(s)
4. Side impact sensor(s) (first)
5. Side impact sensor(s) (second)
6. Rear safing sensor
7. Roof trim
8. A-pillar trim
9. B-pillar upper trim
10. C-pillar trim
11. Front grab handle
12. Rear grab handle
13. All related trim clips
14. Sunvisor

After a moderate to severe side or rear collision, inspect for any damage on the side curtain airbag or other related components. Replace the components as needed.

A-Pillar Trim

Scheme 201

B-Pillar Upper/Lower Trim

Scheme 202

C-Pillar Trim

Scheme 203

During the repair process, inspect these areas

1. Inspect all the SRS wire harnesses. Replace, do not repair, any damaged harnesses.
2. Inspect the cable reel for heat damage. If there is any damage, replace the cable reel (see «CABLE REEL REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).

After the vehicle is completely repaired, turn the ignition switch to ON (II). If the SRS indicator comes on for about 6 seconds and then goes off, the SRS is OK. If the indicator does not function properly, use the HDS to check for the DTCs (see HOW TO READ DTCS ). If you cannot retrieve a code, do the SRS Symptom Troubleshooting.

Checking and Adjusting the Headliner/Pillar Trim Overlap

To prevent the side curtain airbag from deploying and damaging the pillar trim (A-pillar trim, B-pillar trim, C-pillar trim, or quarter pillar trim), the overlap between the headliner and pillar trim must be less then 8 mm (0.3 in). To check the overlap, do this

Scheme 204

Scheme 205

Scheme 206

Scheme 207

1. Install the headliner (A) and the pillar trim (B). This illustration shows the A-pillar.
2. Apply masking tape (A) to the headliner (B) to mark the upper edge of the pillar trim (C). This illustration shows the A-pillar.
3. Remove the pillar trim, and measure the headliner overlap. If the overlap is less than 8 mm (0.3 in), remove the tape, and install the pillar trim. If the overlap is more than 8 mm (0.3 in), go to step 4 . This illustration shows the A-pillar.
4. Carefully trim the headliner with a utility knife, reducing the overlap to less than 8 mm (0.3 in). This illustration shows the A-pillar.
5. Remove the tape, and install the pillar trim.

Driver's Airbag Replacement

Note. If replacing the driver's airbag after deployment, refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT for a complete list of other parts that must also be replaced.

Scheme 208

Scheme 209

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the access panel (A) from the steering wheel, then disconnect the cable reel 4P connector (B) from the driver's airbag 4P connector.
3. Remove the two TORX bolts (A) using a TORX T30 bit.
4. Remove the driver's airbag (B).

Installation

Note. If you are replacing a deployed driver's airbag, inspect the cable reel for heat damage. If there is any damage, replace the cable reel (see CABLE REEL REPLACEMENT ).

Scheme 210

Scheme 211

1. Place the driver's airbag (A) in the steering wheel, and tighten the new TORX bolts (B) to the specified torque, using a TORX T30 bit. NOTE: Make sure the clearance (C) between the steering wheel and horn pad is the specified value.
2. Connect the driver's airbag 4P connector (A) to the cable reel 4P connector, then install the access panel (B) on the steering wheel.
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. After installing the driver's airbag, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Make sure the horn works properly.

Front Passenger's Airbag Replacement

Note. If replacing the front passenger's airbag after deployment, refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT for a complete list of other parts that must also be replaced.

Scheme 212

Scheme 213

Scheme 214

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
3. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector.
4. Remove the passenger's dashboard duct (A), then detach the harness clips (B).
5. Remove the front passenger's airbag mounting nuts (A) and the bolts (B). Release the hooks of the hook plate (C), then remove it.
6. Remove the front passenger's airbag (D) from the dashboard panel.

Scheme 215

Scheme 216

Scheme 217

1. Place the front passenger's airbag (A) into the dashboard panel, then install the hook plate (B). NOTE: Make sure the hooks are set properly.
2. Tighten the front passenger's airbag mounting nuts (C) and the bolts (D) to the specified torque.
3. Install the harness clips (A), then reinstall the passenger's dashboard duct (B).
4. Connect the dashboard wire harness 4P connector (A) to the front passenger's airbag 4P connector.
5. Install the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
6. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
7. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
8. After installing the front passenger's airbag, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.

Side Airbag Replacement

Note. If replacing the side airbag after deployment, refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT for a complete list of other parts that must also be replaced.

Scheme 218

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
3. Remove the seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
4. Detach the harness clip (A) from the seat frame. Remove the two mounting nuts (B), then remove the side airbag (C).

Note. If the side airbag lid is secured with tape, remove the tape. Do not open the lid on the side airbag cover. If you are replacing a deployed airbag, replace the attachment wire A, B, and C. Make sure that the seat-back cover/pad is installed properly. Improper installation may prevent proper deployment. Be sure to install the harness so that they are not pinched or interfering with other parts.

Scheme 219

1. Place the side airbag (A) on the seat-back frame. Tighten the new mounting nuts (B) to the specified torque.
2. Install the harness clip (C).
3. Install the seat-back cover/pad (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
4. Install the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
5. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
6. Move the front seat and the seat-back through their full ranges of movement, making sure the harness wires are not pinched or interfering with other parts.
7. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
8. After installing the side airbag, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.

Removal

Note. If replacing the side curtain airbag after deployment, refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT for a complete list of other parts that must also be replaced. Review the interior trim replacement procedure before doing repair or service (see COMPONENT LOCATION INDEX ). Removal of the side curtain airbag must be done according to Precaution and Procedures (see PRECAUTIONS AND PROCEDURES ).

Scheme 220

Scheme 221

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the headliner (see «HANDLINER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__headliner-removalinstallation) ).
3. Disconnect the SRS floor wire harness 2P connectors (A) from the side curtain airbag 2P connectors, then detach the connector clip (B). Left side is shown; right side is similar.
4. Remove the side curtain airbag mounting bolts (A) and the mounting bolts (B) from the bracket. Detach the clips (C), then remove the side curtain airbag (D). Left side is shown; right side is similar.

Note. If replacing the side curtain airbag after deployment, refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT for a complete list of other parts that must also be replaced. Installation of the side curtain airbag must be done according to the Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). If the side curtain airbag is frayed, or has any other visible damage, replace it. Do not attempt to repair an airbag. When you install the side curtain airbag, make sure it is not twisted, and that it is not caught between the inflator bracket by the bracket bolts. Make sure that the side curtain airbag inflator retainer is installed properly. Otherwise the airbag could incorrectly deploy and cause damage or injuries. If there is any damage to the side curtain airbag, do not try to repair it. Replace any damaged side curtain airbag.

Scheme 222

Scheme 223

1. Place the side curtain airbag assembly (A) on the side of the roof, and fit its clips (B) into the holes in the body. Tighten the side curtain airbag mounting bolts (C) and the mounting bolts (D) to the specified torque. Left side is shown; right side is similar.
2. Connect the SRS floor wire harness 2P connectors (A) from the side curtain airbag 2P connectors, then install the connector clip (B). Left side is shown; right side is similar.
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. After installing the side curtain airbag, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
6. Install all removed parts in reverse order of removal. If the clips are stress-whitened, replace them with new ones.
7. Confirm proper headliner/pillar trim overlap (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__checking-and-adjusting-the-headlinerpillar-trim) ).

Airbag and Tensioner Disposal

Special Tools Required

Deployment Tool 07AAZ-000A100

Before scrapping any front airbags, side airbags, side curtain airbags, or front seat belt tensioners (including those in a whole vehicle to be scrapped), the part(s) must be deployed. If the vehicle is still within the warranty period, the Acura District Parts and Service Manager must give approval and/or special instruction before deploying the part(s). Only after the part(s) have been deployed (as the result of vehicle collision, for example), can they be scrapped. If the parts appear intact (not deployed), treat them with extreme caution. Follow this procedure.

Deploying Airbags in the Vehicle

If an SRS equipped vehicle is to be entirely scrapped, its front airbags, side airbags, side curtain airbags, and front seat belt tensioners, should be deployed while still in the vehicle. These parts should not be considered as salvageable parts and should never be installed in another vehicle.

Scheme 224

Scheme 225

Scheme 226

Scheme 227

Scheme 228

Scheme 229

Scheme 230

Scheme 231

1. Turn the ignition switch to LOCK (0). Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Confirm that each front airbag, side airbag, side curtain airbag, or front seat belt tensioner is securely mounted.
3. Confirm that the deployment tool is functioning properly by following the check procedure on the tool label. Driver's Airbag
4. Remove the access panel (A) from the steering wheel, then disconnect the cable reel 4P connector (B) from the driver's airbag 4P connector. Front Passenger's Airbag
5. Remove the glove box (see «GLOVE BOX SEPARATOR REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__glove-box-separator-removalinstallation) ).
6. Disconnect the dashboard wire harness 4P connector (A) from the front passenger's airbag 4P connector. Side Airbag
7. Disconnect the SRS floor wire harness 2P connectors (A) from the driver's and the front passenger's side airbag 2P connectors. Side Curtain Airbag
8. Remove the C-pillar trim (see «C-PILLAR TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__c-pillar-trim) ).
9. Disconnect the SRS floor wire harness 2P connectors (A) from the left and right side curtain airbag 2P connectors. Front Seat Belt Tensioner
10. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
11. Disconnect the SRS floor wire harness 4P connectors (A) from the driver's and the front passenger's seat belt tensioner 4P connectors. Pull the front seat belt out all the way and cut it.
12. Cut off each connector, and strip the ends of the wires. Twist each pair of unlike colored wires together, and clip an alligator clip (A) from the deployment tool to each pair. NOTE: Place the deployment tool at lease 10 m (33 ft) away from the vehicle. The driver's and front passenger's airbags have dual inflators. Twist each pair of unlike colored wires together, and clip an alligator clip to each pair.
13. Connect a 12 V battery to the tool. If the green light on the tool comes on, the igniter circuit is defective and cannot deploy the component. Go to «DISPOSAL OF DAMAGED COMPONENTS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__disposal-of-damaged-components) . If the red light on the tool comes on, the component is ready to be deployed.
14. Push the tool's deployment switch. The airbags and tensioners should deploy (deployment is both highly audible and visible: A loud noise and rapid inflation of the bag, followed by slow deflation). If the components deploy and the green light on the tool comes on, continue with this procedure. If a component does not deploy, and the green light comes ON, its igniter is defective. Go to «DISPOSAL OF DAMAGED COMPONENTS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__disposal-of-damaged-components) . During deployment, the airbags can become hot enough to burn you. Wait for 30 minutes after deployment before touching the airbags.
15. Dispose of the complete airbag or tensioner. No part of it can be reused. Place it in a sturdy plastic bag (A), and seal it securely. Dispose of the deployed airbag according to your local regulations.

Deploying Components Out of the Vehicle

If an intact airbag or tensioner has been removed from a scrapped vehicle, or has been found defective or damaged during transit, storage, or service, it should be deployed as follows

Scheme 232

1. Confirm that the deployment tool is functioning properly by following the check procedure Deploying Airbags in the Vehicle on the tool label.
2. Position the airbag face up, outdoors, on flat ground, at least 10 m (33 ft) from any obstacles or people.
3. Follow steps 12 through 15 of the in-vehicle deployment procedure. NOTE: The driver's and front passenger's airbags have dual inflators. Twist each pair of unlike colored wires together, and clip an alligator clip to each pair.

Disposal of Damaged Components

1. If installed in a vehicle, follow the removal procedure for the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ), the front passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-airbag-replacement) ), the side airbag (see «SIDE AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__side-airbag-replacement) ), the side curtain airbag (see «SIDE CURTAIN AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ), and the front seat belt tensioner (see «FRONT SEAT BELT REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/restraints-control-systems/#seat-belts-v6) ).
2. In all cases, make a short circuit by cutting, stripping, and twisting together the two inflator wires. NOTE: The driver's and front passenger's airbags have dual inflators. The like color wires go to the individual inflators. Twist the like colored wires together.
3. Package the component in exactly the same packaging that the new replacement part came in.
4. Mark the outside of the box DAMAGED AIRBAG NOT DEPLOYED, DAMAGED SIDE AIRBAG NOT DEPLOYED, DAMAGED SIDE CURTAIN AIRBAG NOT DEPLOYED or, DAMAGED SEAT BELT TENSIONER NOT DEPLOYED so it does not get confused with your parts stock.
5. Contact your Acura District Parts and Service Manager for instructions on how and where to return it for disposal.

Deployment Tool Check

1. Connect the yellow clips to both switch protector handles on the tool.
2. Then connect the red lead to the positive battery post and the black lead to the negative battery post.
3. Push the operation switch: The green light should come on, indicating that the tool is operating properly and is ready for use. If the red light stays on, the tool is faulty, and another one must be used for the procedure.
4. Disconnect the tool clips and connectors from the protector handles and the battery.

Scheme 233

Scheme 234

Scheme 235

1. Set the front wheels in the straight ahead position.
2. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
3. Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ).
4. Disconnect the cable reel subharness 20P connector (A) from the cable reel.
5. Loosen the steering wheel bolt (B) three turns.
6. Install a commercially available steering wheel puller on the steering wheel (see «STEERING WHEEL REMOVAL»(/acura/tsx/ii-2008-2014/remont/manual-power-steering/#steering-v6__steering-wheel-removal) ).
7. Remove the steering wheel puller, then remove the steering wheel bolt and steering wheel from the steering column.
8. Remove the upper and lower column covers (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
9. Disconnect the dashboard wire harness 4P connector (A) from the cable reel 4P connector (B), then disconnect the dashboard wire harness 20P connector (C) from the cable reel (D).
10. Release the upper lock tab (A) under the cable reel connector with a 90 ° hook shaped tool (B). Slide the tool below the cable reel connector just above the lock tab. Release the lower lock tab (C), and slide the cable reel off the column.

Scheme 236

Scheme 237

Scheme 238

Scheme 239

Scheme 240

1. Before installing the steering wheel, make sure the front wheels are aligned straight ahead.
2. Set the turn signal canceling sleeve (A) so that the projections (B) are aligned vertically.
3. Carefully install the cable reel (A) on the steering column shaft. Then connect the dashboard wire harness 20P connector (B) to the cable reel, and connect the 4P connector (C) to the dashboard wire harness 4P connector (D).
4. Install the upper and lower column covers (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__side-defogger-vent-trim-removalinstallation) ).
5. Before installing the steering wheel, make sure the front wheels are pointing straight ahead, then center the cable reel (A). Do this by first rotating the cable reel clockwise until it stops. Then rotate it counterclockwise about three full turns. The arrow mark (B) on the cable reel label should point straight up.
6. Position the two tabs (A) of the turn signal canceling sleeve (B) as shown. Install the steering wheel on to the steering column shaft, making sure the steering wheel hub (C) engages the pins (D) of the cable reel and tabs of the turn signal canceling sleeve. Do not tap on the steering wheel or steering column shaft when installing the steering wheel.
7. Install the steering wheel bolt (A), and tighten it to the specified torque. Connect the cable reel subharness 20P connector (B). Make sure the wire harness is routed and fastened properly.
8. Install the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-airbag-replacement) ).
9. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
10. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
11. After installing the cable reel, confirm proper system operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off. Make sure the horn and turn signal switches works properly. Make sure the steering wheel switches works properly. Make sure the horn works properly.
12. After installation, check the steering wheel spoke angle. If the steering spoke angles to the right and left are not equal (steering wheel is not centered), correct the engagement of the wheel/column shaft splines.

Scheme 241

Scheme 242

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the driver's dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ) and passenger's dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ).
3. Remove the TORX bolt (A) using a TORX T30 bit.
4. With navigation: Remove the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ).
5. Without navigation: Remove the dashboard center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-pocket-removalinstallation) ).
6. Disconnect SRS unit connectors A (39P) and B (39P) from the SRS unit (C). NOTE: The SRS unit connectors have lever locks. Release the locks before disconnecting the connectors (see «SRS UNIT CONNECTORS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__srs-unit-connectors) ).
7. Remove the TORX bolts (D) using a TORX T30 bit, then pull out the SRS unit.

Scheme 243

Scheme 244

1. Install the SRS unit (A) with the new TORX bolt (B), using a TORX T30 bit.
2. Install the new TORX bolts (C) using a TORX T30 bit.
3. Connect SRS connectors A (39P) and B (39P) to the SRS unit; push them into position until they click and the lever locks are fully secured (see «LEVER-LOCKED CONNECTOR»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__lever-locked-connector) ).
4. Tighten the three installed TORX bolts to the specified torque.
5. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
6. Make sure the SRS unit has the latest software. If it dose not have the latest, update the software in the SRS unit (see «SRS UNIT UPDATE»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__srs-unit-update) ).
7. Do the ODS unit initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
8. Check the operation of the ODS unit with the HDS (see «ODS UNIT OPERATION CHECK»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6) ).
9. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
10. With navigation: Install the audio-navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__audio-navigation-unit-removalinstallation) ).
11. Without navigation: Install the dashboard center pocket (see «CENTER POCKET REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__center-pocket-removalinstallation) ).
12. Install the driver's dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ) and passenger's dashboard center lower cover (see «DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/gauges-instrument-panels/#dashboard-v6__dashboard-center-lower-cover-removalinstallation) ).

Scheme 245

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) ).
3. Disconnect the SRS floor wire harness 4P connector (A) from the side impact sensor (first) (B).
4. Remove the TORX bolt (C) using a TORX T30 bit, then remove the side impact sensor (first).

Scheme 246

1. Install the side impact sensor (first) (A) with the new TORX bolt (B) using a TORX T30 bit, and tighten the TORX bolt to the specified torque.
2. Connect the SRS floor wire harness 4P connector (C) to the side impact sensor (first).
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
6. Install the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tsx/ii-2008-2014/remont/exteriorinterior-trim/#interior-trim-v6__b-pillar-upperlower-trim) )

Scheme 247

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-side-bolster) ).
3. Disconnect the SRS floor wire harness 2P connector (A) from the side impact sensor (second) (B).
4. Remove the TORX bolt (C) using a TORX T30 bit, then remove the side impact sensor (second).

Scheme 248

1. Install the side impact sensor (second) (A) with the new TORX bolt (B) using a TORX T30 bit, and tighten the TORX bolt to the specified torque.
2. Connect the SRS floor wire harness 2P connector (C) to the side impact sensor (second).
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
6. Install the seat side bolster (see «SEAT SIDE BOLSTER»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__seat-side-bolster) ).

Scheme 249

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the rear seat cushion (see «REAR SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__rear-seat-cushion-cover-replacement) ), then pull out the carpet as needed.
3. Disconnect the SRS floor wire harness 4P connector (A) from the rear safing sensor (B).
4. Remove the TORX bolt (C) using a TORX T30 bit, then remove the rear safing sensor.

Scheme 250

1. Install the rear safing sensor (A) with the new TORX bolt (B) using a TORX T30 bit, and tighten the TORX bolt to the specified torque.
2. Connect the SRS floor wire harness 4P connector (C) to the rear safing sensor.
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
6. Install the rear seat cushion (see «REAR SEAT CUSHION COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__rear-seat-cushion-cover-replacement) ).

Note. Removal of the front passenger's weight sensors must be done according to Precautions and Procedures (see PRECAUTIONS AND PROCEDURES ). The front passenger's weight sensor are part of the seat rail and must be replaced as an assembly.

Scheme 251

1. Move the front passenger's seat all the way forward.
2. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
3. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
4. Remove the upper rail outer cover and upper rail inner cover (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-frame-replacement) ).
5. Remove the bolts (A), then remove the front seat frame (B) from the front passenger's weight sensors (C).
6. Remove the mounting bolts (D) from the front passenger's weight sensors.
7. Move the seat rail all the way rearward, disconnect the front passenger's weight sensor connectors (E) from the ODS unit harness, then remove the nuts (F) and the front seat rear foot (G).
8. Remove the mounting bolts (H), then remove the front passenger's weight sensors.

Note. Be sure to install the harness wires so they are not pinched or interfere with other parts. Make sure both of the hooks (A) on the seat track are properly secured to the front bracket (B). If the hooks are not properly secured, the front passenger's weight sensors will not perform properly.

Scheme 252

1. Install and torque the front passenger's weight sensors with new mounting bolts (C) and the new nuts (D) under the seat cushion.
2. Connect the front passenger's weight sensors connectors (E) to the ODS unit harness.
3. Install the new nuts (F), and tighten the nuts to the specified torque.
4. Install the new bolts (G), and tighten the bolts to the specified torque.
5. Install the upper rail outer cover and upper rail inner cover (see «FRONT SEAT FRAME REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-frame-replacement) ).
6. Install the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
7. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
8. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
9. Do the front passenger's weight sensor initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
10. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.

Scheme 253

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
3. Remove the back panel (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
4. Turn over the seat-back cover/pad to gain access to the ODS unit (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
5. Remove the cover (A), then disconnect the ODS unit 18P connector (B) and the OPDS sensor connectors (C) from the ODS unit (D).
6. Remove the two screws (E) and the ODS unit.

Note. Be sure to install the harness so that they are not pinched or interfering with other parts. Make sure that the seat-back cover/pad is installed properly. Improper installation may prevent proper deployment.

Scheme 254

1. Place the ODS unit (A) on the seat-back frame. Tighten the new two screws (B) to the specified torque.
2. Connect the ODS unit 18P connector (C) and OPDS sensor connectors (D) to the ODS unit. Install the cover (E).
3. Install the seat-back cover/pad in the reverse order of removal (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
4. Install the back panel (see «FRONT SEAT-BACK COVER REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-back-cover-replacement) ).
5. Install the front passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
6. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
7. Set the seat-back in the normal position, and make sure there is nothing on the front passenger's seat.
8. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
9. Do the ODS unit initialization (see «FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__front-passengers-weight-sensor-initialization) ).
10. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.

Scheme 255

1. Do the battery terminal disconnection procedure (see «USING THE GR8 BATTERY DIAGNOSTIC STATION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__using-the-gr8-battery-diagnostic-station) ), then wait at least 3 minutes before starting work.
2. Remove the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#bumpers-v6__front-bumper-removalinstallation) ).
3. Left side: Removal the intake air resonator (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#intake-air-system-v6) ).
4. Disconnect the left or right engine compartment wire harness 2P connector (A) from the front impact sensor (B).
5. Remove the TORX bolts (C) using a TORX T30 bit, then remove the front impact sensor.

Scheme 256

1. Install the front impact sensor (A) with the new TORX bolt (B) using a TORX T30 bit, and tighten the TORX bolt to the specified torque.
2. Connect the left or right engine compartment wire harness 2P connector (C) to the front impact sensor.
3. Do the battery terminal reconnection procedure (see «RECONNECTION»(/acura/tsx/ii-2008-2014/remont/body-electrical/#battery-v6__reconnection) ).
4. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
5. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.
6. Left side: Install the intake air resonator (see «AIR CLEANER ELEMENT INSPECTION/REPLACEMENT»(/acura/tsx/ii-2008-2014/remont/mechanical/#intake-air-system-v6) ).
7. Install the front bumper (see «FRONT BUMPER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/exterior-body-panels/#bumpers-v6__front-bumper-removalinstallation) ).

Note. Do not turn the ignition switch to ON (II) while removing the driver's seat position sensor.

Scheme 257

1. Raise the driver's seat all the way up.
2. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
3. Remove the recline cover (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
4. Disconnect the driver's seat position sensor harness 2P connector (A) from the driver's seat position sensor (B).
5. Remove the TORX bolt (C) while holding the nut (D) using a TORX T30 bit, then remove the driver's seat position sensor.

Note. Be sure to install the harness so it does not pinched or interfere with other parts. Do not turn the ignition switch to ON (II) while installing the driver's seat position sensor.

Scheme 258

1. Install the driver's seat position sensor (A) with the new TORX bolt (B) and the new nut (C) using a TORX T30 bit, and tighten the TORX bolt while holding the nut to the specified torque.
2. Connect the driver's seat position sensor harness 2P connector (D) to the driver's seat position sensor.
3. Install the recline cover (see «FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-recline-cover-removalinstallation) ).
4. Install the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/seats/#seats-v6__front-seat-removalinstallation) ).
5. Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ).
6. Check the operation of the driver's seat position sensor with the HDS (see «DRIVER'S SEAT POSITION SENSOR OPERATION CHECK»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__drivers-seat-position-sensor-operation-check) ).
7. Confirm proper SRS operation: Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.

Scheme 259

1. With navigation: Remove the navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#navigation-system-v6__navigation-display-unit-removalinstallation) ).
2. Without navigation: Remove the audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tsx/ii-2008-2014/remont/entertainment-systems/#audio-system-v6) ).
3. Disconnect the 4P connector (A) from the passenger's airbag cutoff indicator (B).
4. Remove the screws (C), then pull out the passenger's airbag cutoff indicator from the navigation display unit (with navigation) or the audio-HVAC display unit (without navigation).
5. Reinstall the parts in the reverse order of removal.
6. After installing the passenger's airbag cutoff indicator, confirm proper system operation: Clear any DTCs with the HDS (see «HOW TO CLEAR DTCS»(/acura/tsx/ii-2008-2014/remont/airbag/#srs-supplemental-restraint-system-v6__how-to-clear-dtcs) ). Turn the ignition switch to ON (II), and check that the SRS indicator comes on for about 6 seconds and then goes off.

See also:
• USING THE GR8 BATTERY DIAGNOSTIC STATION
• FRONT SEAT ACTIVE HEAD RESTRAINT INSPECTION
• GLOVE BOX SEPARATOR REMOVAL/INSTALLATION
• C-PILLAR TRIM
• B-PILLAR UPPER/LOWER TRIM
• AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION
• CENTER POCKET REMOVAL/INSTALLATION
• DLC CIRCUIT TROUBLESHOOTING
• BATTERY TEST
• ALTERNATOR AND REGULATOR CIRCUIT TROUBLESHOOTING
• FRONT SEAT-BACK COVER REPLACEMENT
• SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION
• FRONT SEAT BELT REPLACEMENT
• LEFT ENGINE COMPARTMENT WIRE HARNESS DASHBOARD BRANCH)
• RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD BRANCH)
• MIL CIRCUIT TROUBLESHOOTING
• GENERAL TROUBLESHOOTING INFORMATION
• PCM REPLACEMENT
• FRONT SEAT BELT BUCKLE
• SRS FLOOR WIRE HARNESS
• CONNECTORS AND HARNESSES (V6)
• DRIVER'S UNDER-DASH FUSE/RELAY BOX (MICU) REMOVAL AND INSTALLATION
• CANADA MODELS
• FRONT SEAT RECLINE COVER REMOVAL/INSTALLATION
• FRONT SEAT RECLINE MOTOR REPLACEMENT
• SELF-DIAGNOSTIC FUNCTION
• GAUGE CONTROL MODULE REPLACEMENT
• WIRE COLOR CODES
• DTC U0151: GAUGE CONTROL MODULE LOST COMMUNICATION WITH SRS UNIT (SRS MESSAGE)
• RECONNECTION
• FRONT SEAT REMOVAL/INSTALLATION
• COMPONENT LOCATION INDEX
• HANDLINER REMOVAL/INSTALLATION
• STEERING WHEEL REMOVAL
• DASHBOARD CENTER LOWER COVER REMOVAL/INSTALLATION
• SEAT SIDE BOLSTER
• REAR SEAT CUSHION COVER REPLACEMENT
• FRONT SEAT FRAME REPLACEMENT
• FRONT BUMPER REMOVAL/INSTALLATION
• AIR CLEANER ELEMENT INSPECTION/REPLACEMENT
• NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION
• AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION
• AIRBAG AND TENSIONER DISPOSAL
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• HOW TO READ DTCS
• HOW TO CLEAR DTCS
• ODS UNIT REPLACEMENT
• FRONT PASSENGER'S WEIGHT SENSOR OUTPUT CHECK AFTER A VEHICLE COLLISION
• 11-1X
• 11-3X
• 11-8X
• 11-9X
• 12-1X
• 12-3X
• 12-8X
• 12-9X
• 21-1X
• 21-3X
• 21-8X
• 21-9X
• 22-1X
• 22-3X
• 22-8X
• 22-9X
• 31-1X
• 31-3X
• 31-8X
• 31-9X
• 32-1X
• 32-3X
• 32-8X
• 32-9X
• 33-1X
• 33-3X
• 33-8X
• 33-9X
• 34-1X
• 34-3X
• 34-8X
• 34-9X
• 41-1X
• 41-2X
• 42-1X
• 42-2X
• 43-1X
• 43-2X
• 44-1X
• 44-2X
• 45-1X
• 45-2X
• 46-1X
• 46-2X
• 51-xX
• 53-FF
• 56-31
• 61-1X
• 61-2X
• 62-1X
• 62-2X
• 71-1X
• 71-2X
• 81-4X
• 81-61
• 81-71
• 81-79
• 82-11
• 82-12
• 82-13
• 82-21
• 82-22
• 83-23
• 85-4X
• 85-61
• 85-71
• 85-79
• 86-1X
• 92-1X
• 92-2X
• A1-1X
• A2-1X
• A3-1X
• A4-1X
• B2-1X
• B2-2X
• EX-11
• FX-11
• SRS INDICATOR DOES NOT COME ON
• SRS INDICATOR STAYS ON, BUT NO DTCS ARE STORED, OR CANNOT BE READ
• SIDE AIRBAG CUTOFF INDICATOR STAYS ON
• PASSENGER'S AIRBAG CUTOFF INDICATOR STAYS ON OR COMES ON SUDDENLY
• SRS UNIT UPDATE
• TROUBLESHOOTING INTERMITTENT FAILURES
• DRIVER'S AIRBAG REPLACEMENT
• OPENING THE SRS UNIT SHORTING CONNECTORS FOR DIAGNOSIS
• FRONT PASSENGER'S AIRBAG REPLACEMENT
• SIDE AIRBAG REPLACEMENT
• FRONT PASSENGER'S WEIGHT SENSOR INITIALIZATION
• ODS Unit Initialization
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• DISPOSAL OF DAMAGED COMPONENTS
• SRS UNIT CONNECTORS
• LEVER-LOCKED CONNECTOR
• DRIVER'S SEAT POSITION SENSOR OPERATION CHECK
