Interior Trim Acura TL IV

Scheme 74

Trim Removal/Installation - Door Areas

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

Front Door Sill Area

Note. Put on gloves to protect your hands Take care not to bend or scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. Detach the hooks (A) from the kick panel (B) and the B-pillar lower trim (C), and pull the front door sill trim (D) up by hand to detach the clips (E), then remove it
2. If necessary, pull the front side outer trim (F) up to detach the clips (G), then remove the trim
3. Remove the driver's kick panel (A) or the passenger's kick panel (B) -1 Pull out the door opening seal (C) as needed from the kick panel hooks (D) -2 Pull the kick panel back by hand to detach the clips, then remove it Driver's side Passenger's side
4. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) )
5. Pull out the front door opening seal (A) from the trim hooks (B) around the front door opening flange, then remove the seal
6. Install the trim in the reverse order of removal, and note these items

1. If the clips are damaged or stress-whitened, replace them with new ones
2. Push the clips and the hooks into place securely

Rear Door Sill Area

Note. Put on gloves to protect your hands Take care not to bend or scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 79

Scheme 80

1. Remove the rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__rear-seat-removalinstallation) )
2. Detach the hooks (A) and the tab (B) from the B-pillar lower trim (C), and pull the rear door sill trim (D) up by hand to detach the clips (E, F), then remove the trim
3. If necessary, pull the rear side outer trim (G) up to detach the clips (H), then remove the trim
4. Remove the B-pillar lower trim (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) )
5. Pull out the rear door opening seal (A) from the trim hooks (B) around the rear door opening flange, then remove the seal
6. Install the trim in the reverse order of removal, and note these items

1. If the clips are damaged or stress-whitened, replace them with new ones
2. Push the clips, the hooks, and the tabs into place securely

Trim Removal/Installation - Pillar Areas

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

A-Pillar Trim

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Follow the A-pillar trim installation procedure carefully, improper installation could cause the side curtain airbags to deploy improperly and possibly cause injury Put on gloves to protect your hands Use the appropriate tool from the KTC trim tool set to avoid damage when removing components Take care not to scratch the trim or the panels The upper clip in the A-pillar trim (A) consists of a plastic grommet (B) and a metal pin (C) The grommet expanded by the pin secures it to the body panel (D) The projections (E) on the pin break during removal, so the clip must be replaced with a new one when the trim is reinstalled

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

1. Pull the door opening seal away from the A-pillar as needed (see step 5 )
2. Hit the upper clip in the A-pillar trim (A) with a rubber mallet The clip is located under the point where the index tab (B) on the edge of the trim indicates Hitting the clip breaks the projections (C) on the pin (D) and pushes it into the grommet (E) on the body (F) NOTE: The upper clip must be replaced with a new one when the A-pillar trim is reinstalled
3. Pull the top of the A-pillar trim (A) back by hand to remove the upper clip (B) from the body (C)
4. Pull the A-pillar trim (A) by hand to detach the clip Pull up the trim from the dashboard (B), and disconnect the tweeter connector (C), then remove the trim NOTE: Be careful not to damage the tweeter connector when removing the A-pillar trim
5. If the side curtain airbag has deployed, replace the A-pillar trim, along with other parts with a new ones. Refer to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) .
6. If the side curtain airbag has not deployed, check the A-pillar trim (A) and note the following items To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the A-pillar trim and replace it if it has any of the following damage Any cracks, deformations, or stress-whitened areas in the A-pillar trim Any cracks or stress-whitening in the clip seating surfaces (B) Replace the upper clip (C) with a new one If the clip (D) is damaged or stress-whitened, replace it with a new one
7. Temporarily install the A-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ) Remove the trim and, if necessary, adjust the overlap
8. Carefully install the new upper clip (A) to the A-pillar trim (B) Be sure that the grommet (C) is nearest to the top of the pin (D) as shown
9. Reinstall the A-pillar trim (A) Insert the bottom of the trim into the dashboard (B), then reconnect the tweeter connector (C) Place the trim over the A-pillar (D) and fit the upper clip (E) and the lower clip into the holes in the A-pillar, then lightly push the trim into place NOTE: Make sure the side curtain airbag is not tucked under the clips or trim ribs Do not push too hard on the A-pillar trim If you push too hard, the clip will be damaged, and it will not hold the trim properly Gently tug on the A-pillar trim to verify that all clips are securely fastened
10. Reinstall the door opening seal

B-Pillar Upper/Lower Trim

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. If the side airbag and/or the side curtain airbag has deployed, replace the affected trim pieces and clips, along with other parts with a new ones. Refer to COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT . Put on gloves to protect your hands Take care not to bend or scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 88

Scheme 89

Scheme 90

1. Remove these items Front door sill trim (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) )
2. Slide the front seat forward fully
3. Remove the B-pillar lower trim (A) Pull the upper portion of the trim back to detach the upper hooks (B) Detach the lower clip by pulling the bottom of the trim back by hand
4. Remove these items Front seat belt lower anchor (see «FRONT SEAT BELT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/restraints-control-systems/#seat-belt-system) ) Front door opening seal, as needed (see step 5 ) Rear door opening seal, as needed (see step 5 )
5. Remove the B-pillar upper trim (A) Pull the bottom of the trim back by hand to detach the lower hooks (B) Pull the bottom of the trim back to release the clip Pull the trim down to release the upper hooks (C) from the holes in the body
6. Pass the front seat belt (A) lower anchor out through a hole in the slider (B), then remove the B-pillar upper trim (C)
7. Install the trim in the reverse order of removal, and note these items

1. If the clip (A) is damaged or stress-whitened, replace it with a new one
2. If the side curtain airbag has deployed, replace the B-pillar upper trim, the B-pillar lower trim and clips, along with other parts with a new ones. Refer to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) .
3. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it if it has any of the following damage Any cracks or deformations in the B-pillar upper trim (B) or the upper hooks (C), or any stress-whitened areas in the upper part of the trim Any cracks or deformations in the B-pillar lower trim (D), or any breakages in the part (E) that overlaps the B-pillar upper trim Any cracks or stress-whitened areas in the clip seating surface (F)
4. Replace any damaged parts with new ones
5. Make sure the top of the trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) )
6. Make sure the pin (G) on the front seat belt shoulder anchor adjuster (H) and the hole (I) on the back of the slider are engaged when installing the B-pillar upper trim
7. Make sure the upper hooks are installed into the holes in the body securely
8. Push the clips and the hooks into place securely
9. Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt

Trim inspection

Scheme 91

Slider engagement with shoulder anchor adjuster

Scheme 92

C-Pillar Trim

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Follow the C-pillartrim installation procedure carefully, improper installation could cause the side curtain airbag to deploy improperly and possibly cause injury Put on gloves to protect your hands Use the appropriate tool from the KTC trim tool set to avoid damage when removing components Take care not to scratch the trim or the panels The upper clip in the C-pillartrim (A) consists of a plastic grommet (B) and a metal pin (C) The grommet expanded by the pin secures it to the body panel (D) The upper clip must be replaced with a new one when the trim is reinstalled

Scheme 93

Scheme 94

Scheme 95

Scheme 96

Scheme 97

Scheme 98

Scheme 99

1. Remove these items Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__rear-seat-removalinstallation) ) Rear door opening seal, as needed (see step 5 )
2. Hit the upper clip in the C-pillar trim (A) with a rubber mallet Hitting the clip breaks the projections (B) on the pin (C) and pushes it into the grommet (D) on the body (E) NOTE: The upper clip must be replaced with a new one when the C-pillartrim is reinstalled
3. Pull the top of the C-pillar trim (A) back by hand to remove the upper clip (B) from the body (C)
4. Pull the C-pillar trim (A) by hand to detach the clips and to release the hooks (B), then pull the trim out from the rear shelf (C)
5. If the side curtain airbag has deployed, replace the C-pillar trim, along with other parts with a new ones. Refer to «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) .
6. If the side curtain airbag has not deployed, check the C-pillar trim (A) and note the following items To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the C-pillartrim and replace it if it has any of the following damage Any cracks, deformations, or stress-whitened areas in the C-pillar trim Any cracks or stress-whitened areas in the clip seating surfaces (B) Replace the upper clip (C) with a new one If the clips (D) are damaged or stress-whitened, replace them with new ones
7. Temporarily install the C-pillar trim (without the upper clip) to check the overlap between the trim and the headliner (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ) Remove the trim and, if necessary, adjust the overlap
8. Carefully install the new upper clip (A) to the C-pillar trim (B) Be sure that the grommet (C) is nearest to the top of the pin (D) as shown
9. Reinstall the C-pillar trim (A) Install the bottom hooks (B) of the trim in the rear shelf (C) Place the trim over the C-pillar (D), and fit the upper clip (E) and the lower clips into the holes (F) in the C-pillar, then lightly push the trim into place NOTE: Make sure the side curtain airbag is not tucked under the clips or the trim ribs Do not push too hard on the C-pillar trim If you push too hard, the clip is damaged, and it will not hold the trim properly Gently tug on the C-pillar trim to verify that all clips are securely fastened
10. Reinstall the rear door opening seal

Trim Removal/Installation - Rear Shelf Area

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

Rear Shelf

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Put on gloves to protect your hands Take care not to bend or scratch the rear shelf or the trim Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 100

1. Remove C-pillar trim, both sides (see «C-PILLAR TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) )
2. Remove the rear shelf (A) Pull up the entire rear shelf to detach the clips Pull both rear seat belts (B) and rear center seat belt (C) out through the slits (D) in the rear shelf
3. Install the shelf in the reverse order of removal, and note these items

1. Remove any clips left in the body with a clip remover, and reinstall them on the rear shelf
2. If the clips are damaged or stress-whitened, replace them with new ones
3. When installing the rear shelf, slip the rear seat belts and the rear center seat belt through the slits in the rear shelf properly
4. Push the clips and the hooks into place securely

Trim Removal/Installation - Trunk Area

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

Note. Put on gloves to protect your hands Take care not to bend or scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 101

Scheme 102

Scheme 103

Scheme 104

Scheme 105

Scheme 106

Scheme 107

1. Remove the trunk floor (A)
2. Remove the tool box spacer (A)
3. Remove the trunk lid weatherstrip near the trunk rear trim panel. See «TRUNK LID WEATHERSTRIP REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#trunk-lid) .
4. Detach the clips, and release the hooks (A) and the pins (B) by pulling up the trunk rear trim panel (C), then remove it
5. Release the clips and the Velcro fasteners (A), then remove the trunk front trim panel (B)
6. Release the clips (A, B) and the cargo hook buttons (C, D), then remove the trunk side trim panel (E)
7. Remove the rear seat-back (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__rear-seat-removalinstallation) )
8. Remove the clips
9. Lower the trunk upper trim panel (A) to detach the clips, then remove the panel from the trunk compartment
10. Install the trim in the reverse order of removal, and note these items

1. If the clips are damaged or stress-whitened, replace them with new ones
2. Push the clips and the hooks into place securely

Trim Removal/Installation - Trunk Lid

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

Trunk Lid Trim Panel

Note. Put on gloves to protect your hands Take care not to bend or scratch the panel Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 108

Scheme 109

Scheme 110

1. Remove the trunk lid cushion (see «TRUNK LID CUSHION REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#trunk-lid) )
2. Detach the clip, and remove trunk lid hinge trim A by detaching the hooks (C) from the trunk lid hinge B (on both sides
3. Remove the clips with a clip remover, then remove the trunk lid trim panel (A)
4. If necessary, release the hook (A), then remove the trunk lid handle (B)
5. Install the panel in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Push the clips and the hooks into place securely

Trunk Lid Hinge Trim

Note. Put on gloves to protect your hands Take care not to bend or scratch the panel Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 111

Scheme 112

1. Remove the trunk side trim panel, as needed (see «TRIM REMOVAL/INSTALLATION - TRUNK AREA»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-trunk-area) )
2. Detach the clips, and remove trunk lid hinge trim A by detaching the hooks (C) from the trunk lid hinge trim B
3. Remove the trunk lid hinge trim B from the trunk lid hinge (A)
4. Install the trim in the reverse order of removal, and note these items

1. If the clip is damaged or stress-whitened, replace it with a new one
2. Push the clip and the hooks into place securely

Sunvisor Removal/Installation

Note. Put on gloves to protect your hands Take care not to damage the sunvisor or the headliner

Scheme 113

Scheme 114

Scheme 115

Scheme 116

Scheme 117

Scheme 118

Scheme 119

Scheme 120

Scheme 121

1. Insert a flat-tip screwdriver wrapped with protective tape through the hole in the front side of the bracket cover (A), and push in on the hook (B)
2. While pushing in on the hook (A), release the sunvisor (B) from the holder (C), and rotate the sunvisor backward about 45°. Make sure the hook slides into the bracket cover as you rotate the sunvisor
3. Pull down the sunvisor (A) to release the pin (B) and the bracket (C) from the holes in the body Then pull out the vanity mirror light connector (D), and disconnect it NOTE: If the sunvisor cannot be pulled down, the hook has not rotated into the bracket cover Repeat step 2 to rotate the hook
4. Turn the holder (A) 45° counterclockwise, and pull it down to remove it from the holder grommet (B)
5. Pry out the holder grommet (A) from the body by pinching its hooks (B)
6. If the side curtain airbag has deployed, replace the sunvisor with a new one
7. If the side curtain airbag has not deployed, inspect the sunvisor for damage A damaged sunvisor may cause the side curtain airbags to deploy improperly, possibly causing injury Replace the sunvisor if it has any of the following damage Any cracks in the sunvisor bracket (A) Any cracks in the sunvisor bracket cover (B) Any bends or cracks in the sunvisor stay shaft (C) Any cracks in the sunvisor base (D) Any cracks in the vanity mirror base (E)
8. If the holder grommet is damaged or stress-whitened, replace it with a new one
9. Install the holder (A) in the holder grommet (B) by turning it 45° clockwise, and install them in the body as an assembly by pushing it until the hooks (C) snap into place securely
10. Connect the vanity mirror light connector (A), and install the sunvisor (B) by inserting the bracket (C) and the pin (D) of the bracket cover (E) into the holes in the body
11. While holding the bracket cover (A), rotate the sunvisor (B) forward until the hook (C) snaps into place Gently pull down on the sunvisor to make sure it is properly secured in the body Rotate the sunvisor into the holder (D)

Grab Handle Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 122

Scheme 123

Scheme 124

Scheme 125

Scheme 126

Scheme 127

1. Lower the grab handle (A), then insert a small flat-tip screwdriver wrapped in protective tape into the notch
2. Use a KTC trim tool (A) to pull on the small flat-tip screwdriver, and remove the cap (B)
3. Pinch the clips (A) to release the hooks (B), then remove the grab handle (C)
4. Remove the clips (A) by pinching the hooks with a pair of pliers
5. If the side curtain airbag has deployed, replace the grab handle with a new one
6. If the side curtain airbag has not deployed, inspect the grab handle for damage A damaged grab handle may cause the side curtain airbag to deploy improperly, possibly causing injury Replace the grab handle if it has any of the following damage Any cracks or damage in the grab handle (A) Any cracks or stress-whitening in the caps (B)
7. Install the clips (A) on the grab handle (B), then insert the caps (C) fully into the clips
8. Position the grab handle (A) on the mounting bracket (B), and push on the grab handle until the clips (C) snap into place securely

Headliner Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Put on gloves to protect your hands Take care not to bend or scratch the headliner Be careful not to damage the dashboard or other interior trim Use the appropriate tool from the KTC trim tool set to avoid damage when removing components

Scheme 128

Scheme 129

Scheme 130

Scheme 131

Scheme 132

Scheme 133

Scheme 134

Scheme 135

1. Remove the front seat head restraints, and hold down the rear seat head restraints Slide both the front seats all the way back, and fully recline the seat-back
2. Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work
3. Remove these items A-pillartrim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) B-pillar upper/lower trim, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) C-pillar trim, both sides (see «C-PILLAR TRIM»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__c-pillar-trim) ) Sunvisors and holders, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__sunvisor-removalinstallation) ) Grab handles, four places (see «GRAB HANDLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__grab-handle-removalinstallation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Rear individual map light (see «REAR INDIVIDUAL MAP LIGHT INPUT TEST/REPLACEMENT»(/acura/tl/iv-2008-2011/remont/interiorillumination-lights/#interior-lights) ) High mount brake light cover (see «HIGH MOUNT BRAKE LIGHT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exterior-lights/#exterior-lights) ) Shift cable (see «SHIFT CABLE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/automatic-trans/#automatic-transmission) ) Shift lever bracket base (see «SHIFT LEVER REMOVAL»(/acura/tl/iv-2008-2011/remont/automatic-trans/#automatic-transmission) )
4. Remove the roof console (A) Remove the screws, then pull out the roof console by detaching the clips Disconnect the roof console connector (B), the moonroof switch connector (C), and the HFL microphone connector (D) (for some models), then remove the roof console
5. Remove the rearview mirror harness cover Disconnect the connector from the rearview mirror, and release the wire harness from the rearview mirror harness cover base (see «REARVIEW MIRROR HARNESS COVER BASE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/windows/#windows-and-glass__rearview-mirror-harness-cover-base-replacement) )
6. Driver's side Disconnect the roof wire harness connector (A), and remove the roof wire harness (B) from the A-pillar by detaching the harness clips (C)
7. Disconnect the moonroof subharness connector (A), and detach the harness clip (B) as shown
8. Lower the headliner (A) Remove the front door opening seals (B) and rear door opening seals (C) from each roof portion With the help of an assistant, detach the rear clips (D) by pulling the rear portion of the headliner down Detach the front clips (E), the magnet (F), and the Velcro fasteners (G) by pulling the headliner down at the moonroof opening
9. Remove the headliner (A) from the vehicle NOTE: Do not bend the headliner Bending the headliner will crease and damage it Lower the headliner -2 Move the headliner rearward -3 Lower the front of the headliner below the dashboard -4 Rotate the headliner to point the front corner outside of the passenger's front door opening and the rear corner outside of the driver's front door opening -5 Pull the headliner and the roof wire harness (B) out through the passenger's front door
10. If necessary, remove the cushion tape fastening the roof wire harness (A) to the headliner (B), then remove the harness from the headliner
11. If necessary, remove the front grab handle bracket (A) and the rear grab handle bracket (B) Take care not to damage the side curtain airbag -1 Remove the side curtain airbag mounting bolts (C, D) -2 Release the tabs (E) holding the grab handle bracket to the side curtain airbag, and remove the bracket Front Rear
12. Install the headliner in the reverse order of removal, and note these items

1. If the side curtain airbag has deployed, replace the headliner and the removed trim pieces with new ones (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) )
2. To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the headliner and all removed trim Replace any pieces with the following damage Any creases or tears in the headliner (A) Any cracks or breakage in the grab handle (B) Any damage around the grab handle holes (C) or sunvisor holes (D) in the headliner Any cracks in the sunvisor stay base (E) Any cracks in the sunvisor bracket cover (F) Any bends or cracks in the sunvisor stay shaft (G) Any cracks in the sunvisor base (H) Any cracks or breakage in the vanity mirror base (I) Any fastener bases (J), stiffeners (K), magnet (L), or clip bases (M) which have come off the headliner
3. When installing the grab handle, push on the handle against the bracket (N) until the clips (0) snap into place securely
4. If the clips are damaged or stress-whitened, replace them with new ones
5. Replace the removed cushion tape with new pieces
6. Check that both sides of the headliner are securely attached to the body
7. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) )
8. Be careful not to crease or damage the headliner when reinstalling it through the front passenger's door opening Also be careful not to scratch the body
9. Push the clips and hooks into place securely

Headliner

Scheme 136

Grab handle

Scheme 137

Sunvisor

Scheme 138

Front Carpet Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Put on gloves to protect your hands Take care not to damage, wrinkle or twist the carpet Be careful not to damage the dashboard or other interior trim pieces Use the appropriate tool from the KTC trim tool set to avoid damage when removing components When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

1. Remove these items Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-removalinstallation) ) Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Passenger's dashboard undercover (see «GLOVE BOX DAMPER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__glove-box-damper-replacement) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Steering joint cover (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tl/iv-2008-2011/remont/electronic-steering/#power-steering-system__steering-column-removal-and-installation) ) Shift cable (see «SHIFT CABLE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/automatic-trans/#automatic-transmission) ) Shift lever bracket base (see «SHIFT LEVER REMOVAL»(/acura/tl/iv-2008-2011/remont/automatic-trans/#automatic-transmission) )
2. Release the hooks (A), then remove the accelerator pedal clip (B)
3. While pushing down the return spring (A), pull back the accelerator pedal (B) to release the hook (C)
4. Remove the footrest (A) by pulling it to detach the clips
5. Remove the bolts, then remove the yaw rate-lateral acceleration sensor mounting bracket (A) Detach the harness clips (C), and remove the ground bolt (D) with a TORX T30 bit Disconnect the SRS unit connector B Bolt specification: 6 x 1.0 mm, 9.8 N.m (1.0kgf-m, 7.2 lbf.ft)
6. Remove the clips (A) Detach the clips (B) fastening the carpet to both door sill areas
7. Pull the front carpet (C) out from under the dashboard, then remove the carpet
8. If necessary, release the hook (A) that is just under the arrow mark (B) on the floor mat holder (C) by prying up on the holder with a flat-tip screwdriver, and remove the holder through the slit (D) in the carpet (E).
9. Install the front carpet in the reverse order of removal, and note these items

1. If the clips fastening the carpet to the floor are damaged or stress-whitened, replace them with new ones.
2. if you remove the accelerator pedal clip, replace it with a new one (clip).
3. If necessary, adjust the parking brake cable (see «PARKING BRAKE INSPECTION AND ADJUSTMENT»(/acura/tl/iv-2008-2011/remont/mechanical-hydraulic/#conventional-brake-components) ).
4. Push the clips into place securely

Rear Carpet Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the Acura Tool and Equipment Program, call 888-424-6857

SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service

Note. Put on gloves to protect your hands Take care not to damage, wrinkle or twist the carpet Use the appropriate tool from the KTC trim tool set to avoid damage when removing components When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage

Scheme 145

Scheme 146

1. Remove these items Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__front-seat-removalinstallation) ) Front door sill trim, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Rear door sill trim, both sides (see «REAR DOOR SILL AREA»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Rear seat cushion (see «REAR SEAT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/seats/#seats__rear-seat-removalinstallation) ) Shift cable (see «SHIFT CABLE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/automatic-trans/#automatic-transmission) ) Shift lever bracket base (see «SHIFT LEVER REMOVAL»(/acura/tl/iv-2008-2011/remont/automatic-trans/#automatic-transmission) )
2. Remove the bolts, then remove the yaw rate-lateral acceleration sensor mounting bracket (A) Detach the harness clips (C), and remove the ground bolt (D) with a TORX T30 bit Disconnect the SRS unit connector B Bolt specification: 6 x 1.0 mm, 9.8 N.m (1.0kgf-m, 7.2 lbf.ft)
3. Remove the clips (A) securing the front carpet (B) and the rear carpet (C)
4. Pull the rear carpet out by detaching the clips (D), cut the carpet in the areas (E) shown, then remove the carpet
5. Install the rear carpet in the reverse order of removal, and note these items

1. If the clips fastening the carpet to the floor are damaged or stress-whitened, replace them with new ones
2. Push the clips into place securely

See also:
• REAR SEAT REMOVAL/INSTALLATION
• COMPONENT LOCATION INDEX
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• FRONT SEAT BELT REPLACEMENT
• TRUNK LID WEATHERSTRIP REPLACEMENT
• BATTERY TERMINAL DISCONNECTION AND RECONNECTION
• CENTER CONSOLE REMOVAL/INSTALLATION
• REAR INDIVIDUAL MAP LIGHT INPUT TEST/REPLACEMENT
• HIGH MOUNT BRAKE LIGHT REPLACEMENT
• SHIFT CABLE REPLACEMENT
• REARVIEW MIRROR HARNESS COVER BASE REPLACEMENT
• FRONT SEAT REMOVAL/INSTALLATION
• DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• GLOVE BOX DAMPER REPLACEMENT
• STEERING COLUMN REMOVAL AND INSTALLATION
• PARKING BRAKE INSPECTION AND ADJUSTMENT
• B-PILLAR UPPER/LOWER TRIM
• TRIM REMOVAL/INSTALLATION - DOOR AREAS
• REAR DOOR SILL AREA
• C-PILLAR TRIM
• TRIM REMOVAL/INSTALLATION - TRUNK AREA
• TRIM REMOVAL/INSTALLATION - PILLAR AREAS
• SUNVISOR REMOVAL/INSTALLATION
• GRAB HANDLE REMOVAL/INSTALLATION
