Scheme 28
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or related parts Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 29
Scheme 30
- Open the front door, pry out the rear edge of the driver's dashboard side panel (A) with the appropriate trim tool to detach the clips and the hooks (B), and remove the panel
- Detach the clips Disconnect the dash lights brightness controller connector (A), then remove the driver's dashboard trim (B)
- Install the driver's dashboard trim in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Make sure the connector is plugged in properly Push the clips and the hooks into place securely
Driver's Switch Panel Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components When prying with a flat-tip screwdriver, wrap it with protective tape to prevent damage
Scheme 31
- Remove the driver's switch panel (A) -1 Apply protective tape (B) to the dashboard under the edge of the driver's switch panel -2 Pry up on the edge of the panel with a flat-tipped screwdriver wrapped with protective tape to release the hooks (C) -3 Disconnect the VSA OFF switch connector (D) and the headlight washer connector (E) (for some models)
- Install the panel in the reverse order of removal, and note these items Make sure the each connector is plugged in properly Push the hooks into place securely
Instrument Fascia Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 32
Scheme 33
- Remove these items Driver's dashboard trim (see «DRIVER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Driver's center trim (see step 1 on «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
- Tilt the steering column fully down, and move the steering wheel all the way out
- Detach the clips and the hooks (A) fastening the instrument fascia (B) from the upper column cover (C)
- Gently pull out the bottom to release the clips, and remove the instrument fascia (A)
- Install the instrument fascia in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Push the clips and the hooks into place securely
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the related parts Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 34
- Remove the driver's dashboard undercover (A) -1 Turn the lock knob (B) 90° -2 Gently pull down the rear edge to detach the clip -3 Disconnect the footwell light connector (C) and the harness clip (D) -4 Pull the undercover rearward to release the brackets (E) from the pins (F)
- Install the undercover in the reverse order of removal, and note these items If the clip is damaged or stress-whitened, replace it with a new one Push the clip into place securely Make sure the footwell light connector is plugged in properly Make sure the brackets are installed securely on the pins
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the trim or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 35
Scheme 36
- Remove the driver's center trim (A) or the passenger's center trim (B) -1 Gently pull the lower portion of the trim up to detach the clips from the edge of the center console (C) -2 Disconnect the engine start/stop switch connector (D) (for some models) Driver's side Passenger's side
- Install the trim in the reverse order of removal, and note these items Make sure the engine start/stop switch connector is plugged in properly (for some models) If the clips are damaged or stress-whitened, replace them with new ones Push the clips into place securely
Driver's Side Vent Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 37
- Remove the driver's dashboard trim (see «DRIVER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
- Remove the screw, and release the clip securing the driver's side vent (A), then remove the vent
- Install the vent in the reverse order of removal, and note these items If the clip is damaged or stress-whitened, replace it with a new one Push the clip into place securely
Passenger's Side Vent Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 38
Scheme 39
- Remove the Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) )
- Remove the screw (A) securing the duct (B) from glove box opening Remove the screws (C) securing the passenger's side vent (D)
- Pull out passenger's side vent (A) to detach the clip, then remove the side vent
- Install the vent in the reverse order of removal, and note these items If the clip is damaged or stress-whitened, replace it with a new one Push the clip into place securely
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 40
- Remove the dashboard center vent (A) NOTE: Do not pull on the vent louvers or the edge of the vent, or you may damage them -1 Insert a hook-shaped tool into one side of the center vent until it hooks on to the back edge of the duct (B) -2 Carefully pull one side of the dashboard center vent partially out to release the clips (C, D) and the hooks (E), then do the same on the other side -3 Disconnect the hazard warning switch/passenger's airbag cutoff indicator connector (F) NOTE: Do not pull on the vent louvers or the edge of the vent, or you may damage them.
- Install the dashboard center vent in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Push the clips and the hooks into place securely Make sure the connector is plugged in properly
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 41
Scheme 42
- Open the front door, pry out the bottom edge of the passenger's dashboard side panel with the appropriate trim tool to detach the clips and the hooks (A), and remove the panel (B)
- Remove the passenger's side center trim (see «CENTER TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
- Remove the passenger's dashboard trim (A) -1 Pull out on the side edge of the trim by hand -2 Detach the clips along the trim
- Install the passenger's dashboard trim in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Push the clips into place securely
Glove Box Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 43
Scheme 44
- Remove these items Passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Passenger's dashboard undercover (see «Passenger's Dashboard Undercover Removal/Installation»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) )
- Remove the bolts (A) and the screws (B)
- Remove the glove box (A). Pull the glove box (A) by hand to detach the clips Disconnect the glove box light bulb (B), the trunk lid opener main switch connector (C), and the keyless access system mode switch connector (D) (for some models
- Install the glove box in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Make sure each connector is plugged in properly Push the clips into place securely
Glove Box Lock Cylinder Replacement
Note. Take care not to scratch the glove box
Scheme 45
Scheme 46
Scheme 47
- Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) )
- While lifting the glove box handle (A), use a hook-shaped tool to pull one end of the retainer (B) out of its slot NOTE: Do not remove the retainer entirely Leave one end of the retainer in its original position when removing the lock cylinder
- Remove the glove box lock cylinder (A)
- Reinstall the end of the retainer (A) in its slot, then install the lock cylinder (B) Push the cylinder into place securely until the retainer snaps into place
Glove Box Damper Replacement
Note. Take care not to scratch the glove box
Scheme 48
- Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) )
- Release the glove box damper string (A), remove the screws, then remove glove box damper (B)
- Install the damper in the reverse order of removal
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or its related parts Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 49
- Remove the passenger's dashboard undercover (A) -1 Gently pull down the rear edge to detach the clips -2 Pull the undercover away to release the pins (B) from the brackets (C) -3 Disconnect the front passenger's footwell light connector (D)
- Install the undercover in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Push the clips into place securely Make sure footwell light connector is plugged in properly Make sure the pins are installed securely in the brackets
Side Defogger Vent Trim Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components The left side defogger vent trim is shown, the right side defogger vent trim is similar
Scheme 50
- Insert the appropriate trim tool into a gap between the side defogger vent trim (A) and the dashboard, and pry on the hook (B), then remove the vent trim
- Install the side defogger vent trim in the reverse order of removal, and push the hooks into place securely
Steering Column Cover Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
Note. Put on gloves to protect your hands Take care not to scratch the dashboard or the panels Use the appropriate tool from the KTC trim tool set to avoid damage when removing components Do not pry the column cover surface with any tools
Scheme 51
Scheme 52
Scheme 53
- Remove the instrument fascia (see «Instrument Fascia Removal/Installation»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__instrument-fascia-removalinstallation) )
- Turn the steering wheel to access the mounting screws, then remove the screws from front side of the column cover (A)
- Insert a small screwdriver or similar tool into the holes (A) in the lower column cover (B) Gently push to release the hooks (C), and pull up the upper column cover (D) to remove it
- Remove the three screws (A, B), then remove the lower column cover (C)
- Install the upper and lower column cover in the reverse order of removal Make sure the wire harnesses are not pinched before tightening the screws. Push the hooks into place securely.
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service
Note. Put on gloves to protect your hands Have an assistant help you when removing and installing the dashboard Take care not to scratch the dashboard, the body or the other related parts Take care not to bend the brackets Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
- Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work
- Remove these items from the dashboard area A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Instrument fascia (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__drivers-switch-panel-removalinstallation) ) Driver's switch panel (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__drivers-switch-panel-removalinstallation) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Hood release handle (see «HOOD RELEASE HANDLE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#hood) ) Dashboard center vent (see «DASHBOARD CENTER VENT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__glove-box-removalinstallation) ) Driver's side vent (see «DRIVER'S SIDE VENT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__drivers-side-vent-removalinstallation) ) Passenger's side vent (see «DRIVER'S SIDE VENT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__drivers-side-vent-removalinstallation) ) Side defogger vent trim, both sides (see «SIDE DEFOGGER VENT TRIM REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__side-defogger-vent-trim-removalinstallation) ) Gauge control module (see «GAUGE CONTROL MODULE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#display-and-gauge-system__gauge-control-module-replacement) ) Center speaker (see «USB ADAPTER UNIT REPLACEMENT»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) With navigation system Navigation display unit (see «NAVIGATION DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__navigation-display-unit-removalinstallation) ) Without navigation system Audio-HVAC display unit (see «AUDIO-HVAC DISPLAY UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) With navigation system Audio-Navigation unit (see «AUDIO-NAVIGATION UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__audio-navigation-unit-removalinstallation) ) Without navigation system Audio unit (see «AUDIO UNIT REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/entertainment-systems/#audio-system) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tl/iv-2008-2011/remont/electronic-steering/#power-steering-system__steering-column-removal-and-installation) ) Humidity/In-car temperature sensor (see «HUMIDITY/IN-CAR TEMPERATURE SENSOR REPLACEMENT»(/acura/tl/iv-2008-2011/remont/automatic-hvac-system/#climate-control-system) ) Sunlight sensor (see «SUNLIGHT SENSOR TEST»(/acura/tl/iv-2008-2011/remont/automatic-hvac-system/#climate-control-system__sunlight-sensor-test) ) With navigation system GPS antenna (see «GPS ANTENNA REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/navigation-system/#navigation-system__gps-antenna-removalinstallation) ) Passenger's airbag (see «FRONT PASSENGER'S AIRBAG REPLACEMENT»(/acura/tl/iv-2008-2011/remont/airbag/#srs-supplemental-restraint-system__front-passengers-airbag-replacement) ) With keyless access system Front interior LF antenna (see «FRONT INTERIOR LF ANTENNA REPLACEMENT»(/acura/tl/iv-2008-2011/remont/door-locks-anti-theft-systems/#keyless-access-system) ) With keyless access system Remote slot (see «REMOTE SLOT CONTROL UNIT»(/acura/tl/iv-2008-2011/remont/door-locks-anti-theft-systems/#keyless-access-system) ) Driver's side
- Remove the harness clip (A) from between the A-pillar (B) and the dashboard (C) Center
- Remove the clip, then remove the center joint duct (A)
- Release the harness clips (A, B) from below the display unit opening Passenger's side
- Remove the harness clip (A) from between the A-pillar (B) and the dashboard (C)
- Remove the bolts securing the dashboard (A) Bolt specification: 5 x 0.8 mm, 5 N.m (0.5 kgf.m, 4 lbf.ft)
- Lift up on the dashboard (A) to release it from the guide pins (B), then carefully remove the dashboard through the front door opening NOTE: Lay the dashboard on its front or back Do not rest it on the lower console opening or you may damage it
- Install the dashboard in the reverse order of removal, and note these items Make sure the dashboard fits onto the guide pins correctly Make sure the wire harnesses are not pinched before tightening the bolts Make sure the connectors are plugged in properly Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) ) Check for any DTCs that may have been set during repairs, and clear them
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the Acura Tool and Equipment Program, call 888-424-6857
SRS components are located in this area Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service
Note. Put on gloves to protect your hands Have an assistant help you when removing and installing the dashboard Take care not to scratch the dashboard, the body or the other related parts Take care not to bend the brackets Use the appropriate tool from the KTC trim tool set to avoid damage when removing components
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
- Do the battery terminal disconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) ), then wait at least 3 minutes before beginning work
- Remove these items from the dashboard A-pillar trim, both sides (see «TRIM REMOVAL/INSTALLATION - PILLAR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-pillar-areas) ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Kick panels, both sides (see «TRIM REMOVAL/INSTALLATION - DOOR AREAS»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-door-areas) ) Hood release handle (see «HOOD RELEASE HANDLE REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exterior-body-panels/#hood) ) Instrument fascia (see «DRIVER'S SWITCH PANEL REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard__drivers-switch-panel-removalinstallation) ) Steering column (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/tl/iv-2008-2011/remont/electronic-steering/#power-steering-system__steering-column-removal-and-installation) ) Center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/tl/iv-2008-2011/remont/gauges-instrument-panels/#consoles__center-console-removalinstallation) ) Passenger's dashboard undercover (see «Passenger's Dashboard Undercover Removal/Installation»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#dashboard) ) Driver's side
- Disconnect the roof wire harness connector (A)
- Disconnect the left side wire harness connectors (A), the left engine compartment wire harness connectors (B), and the driver's door wire harness connector (C) from the driver's under-dash fuse/relay box (D)
- Detach the harness clip (A) fastening the relay (B) from the brake pedal support member (C) Remove the bolts (D, E), then remove the member, and disconnect the TPMS control unit connector (F) Center dashboard/console
- Remove the clip, then remove the center joint duct (A)
- Detach the clip securing the center side duct (B). Disconnect SRS unit connector A, the A/C wire harness connector (C), and the yaw rate-lateral/(longitudinal) acceleration sensor connector (D), the A/T shift solenoid /park-pin switch connector (E), the center console subharness connector (F), then detach the wire harness clips (G). Remove the TORX ground bolt (H) with a TORX T30 bit. Center dashboard (passenger's side)
- Disconnect the A/C wire harness connector (A), and detach the clip securing the center side duct (B) Passenger's side
- Disconnect the antenna sublead connectors (A)
- Disconnect the passenger's door wire harness connector (A), the right side wire harness connectors (B), and the right engine compartment wire harness connectors (C) Disconnect the dashboard wire harness connector (D) and the audio wire harness connectors (E) from the passenger's under-dash fuse/relay box (F) Detach the harness clip (G)
- Remove bolts (A, B), then remove the center joint bracket (C)
- Remove the cowl cover (see «COWL COVER REPLACEMENT»(/acura/tl/iv-2008-2011/remont/exteriorinterior-trim/#exterior-trim__cowl-cover-replacement) )
- Remove the bolts securing the steering hanger beam
- Remove the special bolts (A) from outside the passenger's door -1 Remove the caps (B) -2 Loosen the special bolts until they disengage from the threads on the hanger beam side bracket (C), and engage the inside threads of the collar bolts (D) The thread lock on the special bolts makes the special bolts and collar bolts turn together -3 Continue loosening the special bolts to turn the collar bolts into the fixed space adjusters (E) until the collar bolts engage the stops (F) This creates a gap (G) between the collar bolts and the body -4 Loosen the special bolts to disengage them from the collar bolts, then remove them
- Check that the collar bolts (A) are seated in the space adjusters (B) -1 Insert an 8 mm hex wrench in the collar bolt -2 Gently turn the wrench counterclockwise -3 If the wrench turns easily, continue turning until the collar bolt seats and engages the stop (C) -4 If the wrench does not turn easily, the collar bolt is seated NOTE: If either collar bolt was not seated, replace the special bolts
- From outside the driver's door, remove the caps (A), then remove the bolts from outside the driver's door
- Lift up on the dashboard (A) to release it from the guide pins (B) on the body Carefully remove the dashboard through the front door opening Take care not to scratch the body with the collar nuts on the passenger's side NOTE: Do not rest the dashboard on its lower center cover opening, or it may be damaged Lay it on its front or back
- Install the dashboard in the reverse order of removal, and note these items If the clips are damaged or stress-whitened, replace them with new ones Make sure the dashboard fits onto the guide pins correctly Before tightening the bolts, make sure the wire harnesses are not pinched Make sure the connectors are plugged in properly Push the clips and hooks into place securely Make sure the collar bolts (A) turn easily by hand in the fixed space adjusters (B) Tighten the collar bolts by hand until they engage the stops (C) before reinstalling the dashboard Before reinstalling the dashboard, screw the special bolts (D) into the collar bolts, and check that they turn together If they do not turn together, replace the special bolts After setting the dashboard in the body, reinstall all of the mounting bolts but do not tighten them First tighten the driver's side bracket bolts to the specified torque Next, tighten the special bolts As you tighten the bolts, the collar bolts screw out of the sleeve until they contact the body Continue tightening the special bolts to the specified torque Apply medium strength liquid thread lock to the bolts securing the center joint bracket and the dashboard before reinstallation After tightening the dashboard mounting bolts, tighten the center joint bracket mounting bolts, and then tighten the center frame mounting bolts Tighten all remaining mounting bolts to the specified torque Do the battery terminal reconnection procedure (see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/tl/iv-2008-2011/remont/body-electrical/#battery) ) Check for any DTCs that may have been set during repairs, and clear them Special bolt tightening on passenger's side
