Front Door Panel Removal/Installation

Special Tools Required

1. KTC trim tool set SOJATP2014*
2. Trim pad remover, Snap-on A 177A or equivalent, commercially available

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 6

Scheme 7

Scheme 8

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

1. Lower the glass fully.
2. Using a trim tool, push on the rear hook (A) and pivot the cover (B) on the front hook (C), then remove the cover and the screws (D) securing the inner handle (E).
3. Remove the door panel (A) with as little bending as possible to avoid creasing or breaking it. -1 Remove the stopper (B) and screw (C) from the door panel. -2 Release the clips (D) that hold the door panel with a commercially available trim pad remover. -3 Starting at the rear, pull the door panel upward, then release the lock knob (E). NOTE: The inner handle cable (F) is connected to the door panel. Do not pull the door panel up too far, or the inner handle cable will be damaged.
4. While holding the door panel (A) away from the door, disconnect the inner handle cable (B), driving position memory switch connector (C) (driver's door), power door lock switch connector (D), power window switch connector (E, F), harness connector (G) (driver's door), door courtesy light harness clips (H) (passenger's door), and remove the door courtesy light (I) (passenger's door) by turning it counterclockwise one quarter turn.
5. If necessary, remove the door glass inner weatherstrip (A) from the door panel (B) by pulling it down.
6. Remove the screws (A), then remove the door grip (B).
7. Remove the power window switch panel (A). - Remove the screws (B), then remove the armrest (C). - Release the hooks (D) and clip (E), then remove the power window switch panel.
8. Remove the screws (A, B), then remove the door trim (C).
9. Remove the inner handle (A) by releasing the hook (B).
10. Install the door panel in the reverse order of removal, and note these items: Check for damaged or stress-whitened clips, and replace them with new ones. Make sure the connectors are plugged in properly, and the cable is connected properly. Make sure the window and power door lock operate properly. Reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tl/iii-2003-2006/remont/windows/#power-window-system__resetting-the-power-window-control-unit) ) on the door that the panel was removed from.

Front Door Outer Handle Replacement

Note. Put on gloves to protect your hands.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ) Plastic cover, as necessary (see «COMPONENT LOCATION INDEX - FRONT DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) )
2. Raise the glass fully.
3. Remove the bolt (A), then remove the center lower channel (B) by pulling it downward. NOTE: Be careful of sharp edges.
4. Disconnect the outer handle rod (A) from the bushing (B). NOTE: Check the bushing for damage and replace if necessary.
5. Remove the lock cylinder (A) (driver's door) or outer handle cover (B) (passenger's side). - Remove the maintenance hole seal (C). - Loosen the bolt securing the lock cylinder (driver's door), or outer handle cover (passenger's side). - Disconnect the cylinder rod (D) (driver's door) from the bushing (E). NOTE: Hold the lock cylinder (driver's door) or outer handle cover (passenger's side) with your hand to prevent it from falling when removing the bolt. Check the bushing for damage and replace if necessary.
6. Disconnect the cylinder switch connector (A), and detach the harness clip (B), then remove the cylinder switch (C) (driver's door).
7. Remove the screw, then separate the lock cylinder (A), cylinder switch (B) (driver's door). NOTE: Keep your hand over the outer handle cover to prevent it from falling during removal.
8. Release the hook (A), and then remove the outer handle cover (B).
9. Pull the pin (A) up while pinching its lower end.
10. Pull the outer handle (A) out, and then back as shown to remove it from the door panel. Take care not to scratch the door.
11. Release the hooks (A, B, C), then remove the outer handle front seat (D) and outer handle rear seat (E).
12. Remove the outer handle base (A). - Loosen the nut. - Release the tab (B) and slide the outer handle base forward.
13. Disconnect the outer handle rod (A) from outer handle base (B).
14. Install the handle in the reverse order of removal, and note these items: Reinstall the lock cylinder (driver's door) or the outer handle holder (passenger's door) before installing the outer handle cover. Make sure the cylinder switch harness is routed properly (driver's door). Make sure the cylinder switch connector is plugged in properly, and each rod is connected securely (driver's door). Make sure the door key cylinder/door locks operate properly (driver's door). Make sure the door handle works properly. When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to prevent water leaks.

Front Door Latch Replacement

Note. Put on gloves to protect your hands.

Scheme 25

Scheme 26

1. Raise the glass fully.
2. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ) Plastic cover, as necessary (see «COMPONENT LOCATION INDEX - FRONT DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) ) Center lower channel (see step 3 . )
3. Disconnect the cylinder rod from the lock cylinder, and disconnect the outer handle rod from the outer handle (see step 5 ).
4. Remove the screw securing the lock knob (A).
5. Detach the inner handle cable clip (A), and disconnect the actuator connectors (B). Remove the screws (C), then remove the latch (D) through the hole in the door. Take care not to bend the cylinder rod (E), inner handle cable (F), and lock cable (G).
6. Install the latch in the reverse order of removal, and note these items: Make sure the actuator connectors are plugged in properly, and each rod is connected securely. Make sure the door locks and opens properly. When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to prevent water leaks.

Front Door Glass and Regulator Replacement

Note. Put on gloves to protect your hands.

Scheme 27

Scheme 28

Scheme 29

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ) Plastic cover (see «COMPONENT LOCATION INDEX - FRONT DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) )
2. Carefully raise the glass (A) until you can see the bolts through the oval holes in the door, then remove them. Carefully pull the glass out through the window slot. Take care not to drop the glass inside the door.
3. Disconnect the connector (A) from the regulator (B).
4. Remove the bolts (C), and loosen the bolts (D), then remove the regulator through the hole in the door.
5. Apply multipurpose grease to the sliding surfaces of the regulator (A) where (Scheme 29)
6. Install the glass and regulator in the reverse order of removal, and note these items: Roll the glass up and down to see if it moves freely without binding. Make sure that there is no clearance between the glass and glass run channel when the glass is closed. Adjust the position of the glass as necessary (see «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ). Reset the power window control unit (see «RESETTING THE POWER WINDOW CONTROL UNIT»(/acura/tl/iii-2003-2006/remont/windows/#power-window-system__resetting-the-power-window-control-unit) ) on the door that the panel was removed from (driver's and/or passenger's). Check for water leaks (see step 7 in «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ). Test-drive and check for wind noise and rattles. When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to prevent water leaks. Make sure the power door locks, windows, and power mirror operate properly.

Front Door Sash Inner Trim Replacement

Note. Take care not to scratch the door.

Scheme 30

Scheme 31

1. Lower the glass fully.
2. Remove the door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ).
3. Detach the door sash inner trim and weatherstrip mounting clips.
4. Remove the door sash inner trim (A). - Detach the clips. - While removing the lower edge of the door sash inner trim from the edge of the sash, and release the hooks (B, C), then remove the trim.
5. Reinstall new door outer molding in the reverse order of removal, and note these items: Check for damaged or stress-whitened clips, and replace them with new ones. Push the clips into place securely.

Front Door Sash Outer Trim Replacement

Note. Take care not to scratch the door.

Scheme 32

1. Lower the glass fully.
2. Remove the door glass outer weatherstrip (see «FRONT DOOR SASH OUTER TRIM REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-sash-outer-trim-replacement) ).
3. Pull the glass run channel (A) away as needed, and remove the screws. Pull back the door sash outer trim (B) to release the hook (C) from the door rear edge of the door.
4. Install the trim in the reverse order of removal.

Front Door Glass Outer Weatherstrip Replacement

Special Tools Required

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. The door glass outer weatherstrip will need replacement because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 33

Scheme 34

1. Remove these items: Door panel (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ) Power mirror (see «POWER MIRROR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/mirrors/#mirrors) )
2. Remove lower portion of the weatherstrip (see «FRONT DOOR WEATHERSTRIP REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-weatherstrip-replacement) ).
3. Remove the screw from the rear edge of the door.
4. Starting at the rear, pull the door glass outer weatherstrip (A) up at each portion where the inner molding (B) catches the inside edge of the window slot, then remove the weatherstrip.
5. Install a new weatherstrip in the reverse order of removal.

Front Door Outer Molding Replacement

Special Tools Required

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. The door outer molding will need replacement because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 35

1. Remove the power mirror (see «POWER MIRROR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/mirrors/#mirrors) ). To prevent scratching the power mirror and door, wrap the power mirror with a shop towel. Disconnecting the power mirror connector is not required.
2. Remove the door outer molding (A). - Pry out the rear clip with a trim tool. - While removing the upper edge of the door outer molding from the edge of the sash, cut the double-sided adhesive tapes (B) with a utility knife, then remove the molding.
3. Scrape off the remaining double-sided adhesive tape from the sash, then clean the sash surface with a sponge dampened in alcohol.
4. Install a new door outer molding in the reverse order of removal, and note these items: Clean all adhesive contact areas with alcohol. Push the clip and the adhesive portions into place securely. Make sure the upper and lower sides of the molding are catching the edges of the sash properly.

Front Door Weatherstrip Replacement

Note. Take care not to scratch the door. Use a clip remover to remove the clips.

Scheme 36

1. Remove the door checker mounting bolt (A).
2. Detach the clips (B, C, D, E), then remove the door weatherstrip (F).
3. Install the weatherstrip in the reverse order of removal, and note these items: Check for damaged or stress-whitened clips, and replace them with new ones. Make sure the weatherstrip is installed in the holder (G) securely. Apply liquid thread lock to the door checker mounting bolt before installation. Check for water leaks (see step 7 in «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ).

Rear Door Panel Removal/Installation

Special Tools Required

1. KTC trim tool set SOJATP2014*
2. Trim pad remover, Snap-on A 177A or equivalent, commercially available

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. Lower the glass fully.
2. Using a trim tool, push on the rear hook (A) and pivot the cover (B) on the front hook (C), then remove the cover and the screws (D) securing the inner handle (E).
3. Remove the door panel (A) with as little bending as possible to avoid creasing or breaking it. -1 Remove the stopper (B) and screw (C) from the door panel. -2 Release the clips (D) that hold the door panel with a commercially available trim pad remover. -3 Starting at the rear, pull the door panel upward, then release the lock knob (E). NOTE: The inner handle cable (F) is connected to the door panel. Do not pull the door panel up too far, or the inner handle cable will be damaged.
4. While holding the door panel (A) away from the door, disconnect the inner handle cable (B) and power window switch connector (C).
5. If necessary, remove the door glass inner weatherstrip (A) from the door panel (B).
6. Remove the screws (A), then remove the door grip (B).
7. Remove the power window switch panel (A). - Remove the screws (B), then remove the armrest (C). - Replace the hooks (D) and clip (E), then remove the power window switch panel.
8. Remove the screws (A, B), then remove the door trim (C).
9. Remove the inner handle (A) by releasing the hook (B).
10. Install the door panel in the reverse order of removal, and note these items: Check for damaged or stress-whitened clips, and replace them with new ones. Make sure the connectors are plugged in properly, and the cable is connected properly. Make sure the window and power door lock operate properly.

Rear Door Outer Handle Replacement

Note. Put on gloves to protect your hands.

Scheme 45

Scheme 46

Scheme 47

Scheme 48

Scheme 49

Scheme 50

Scheme 51

Scheme 52

Scheme 53

Scheme 54

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-panel-removalinstallation) ) Plastic cover, as necessary (see «COMPONENT LOCATION INDEX - REAR DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) ) Glass (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-glass-and-regulator-replacement) )
2. Disconnect the outer handle rod (A) from the bushing (B). NOTE: Check the bushing for damage and replace if necessary.
3. Remove the screws (A, B). Disconnect the lock knob and door lock actuator connectors (C), release the hook (D), and remove the latch (E), through the hole in the door.
4. Remove the child lock cap (A), and loosen the bolt securing the outer handle holder (B) completely.
5. Release the hook (A), and then remove the outer handle cover (B).
6. Pull the pin (A) up while pinching its lower end.
7. Pull the outer handle (A) out, and then back as shown to remove it from the door panel. Take care not to scratch the door.
8. Using a long, thin screwdriver through the child lock cap hole, release the tab hooks (A), and remove the outer handle rear seat (B). Release the tab hooks (C), and remove the outer handle front seat (D).
9. Detach the shoulder pad mounting clips.
10. Remove the outer handle base (A). - Loosen the nut. - Release the tab (B) and slide the outer handle base forward.
11. Detach the clip, then remove the shoulder pad (A) from the outer handle base (B).
12. Disconnect the outer handle rod (A) from the outer handle base (B).
13. Install the handle in the reverse order of removal, and note these items: Make sure the door locks and opens properly. When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to prevent water leaks.

Rear Door Latch Replacement

Note. Put on gloves to protect your hands.

Scheme 55

Scheme 56

1. Remove these items: Door panel (see «FRONT DOOR WEATHERSTRIP REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-weatherstrip-replacement) ) Plastic cover, as necessary (see «COMPONENT LOCATION INDEX - REAR DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) ) Rear door glass (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-glass-and-regulator-replacement) )
2. Disconnect the outer handle rod from the latch (see step 2 in «REAR DOOR OUTER HANDLE REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-outer-handle-replacement) ).
3. Disconnect the actuator connectors (A). Remove the screws (B, C) securing the latch.
4. Detach the cable clip (D), and release the hook (E), then remove the latch (F) through the hole in the door. Take care not to bend the inner handle cable (G).
5. Remove the lock rod protector (A) from the latch protector (B) by releasing the hook (C).
6. Install the latch in the reverse order of removal, and note these items: Make sure the actuator connectors are plugged in properly. Make sure the door locks and the window operates properly. When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to prevent water leaks.

Rear Door Glass and Regulator Replacement

Note. Put on gloves to protect your hands. Be careful of sharp edges.

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

1. Remove these items: Door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-panel-removalinstallation) ) Plastic cover, as necessary (see «COMPONENT LOCATION INDEX - REAR DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) )
2. Carefully move the glass (A) until you can see the bolts, through the holes in the door frame, then remove them. Remove the glass from the regulator (B), and carefully lower the glass. Take care not to drop the glass inside the door.
3. Pull the glass run channel (A) away as needed. Pull the door weatherstrip (B) away as needed, then remove the screw (C) with a T15 Torx bit. Remove the bolts (D, E) securing the center channel (F), then remove the collar (G).
4. Pull the upper portion of the center channel (A) forward to remove it from the door quarter glass seal (B), then pull up and remove the center channel through the window slot. Take care not to damage the outer weatherstrip (C).
5. Remove the quarter glass (A). Take care not to damage the outer weatherstrip (B).
6. Carefully remove the glass (A) through the window slot. Take care not to drop the glass inside the door.
7. Disconnect the connector (A) from the regulator (B).
8. Remove the bolts (C), and loosen the bolts (D), then remove the regulator through the hole in the door.
9. Apply multipurpose grease to all the sliding surfaces of the regulator (A) where (Scheme 64)
10. Install the glass and regulator in the reverse order of removal, and note these items: Special corrosion-resistant bolts are used in this area. The use of any other type of hardware may result in accelerated corrosion. Roll the glass up and down to see if it moves freely without binding. Make sure that there is no clearance between the glass and glass run channel when the glass is closed. Adjust the position of the glass as necessary (see «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ). Check for water leaks (see step 7 in «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ). Test-drive and check for wind noise and rattles. When reinstalling the door panel, make sure the plastic cover is installed properly and sealed around its outside perimeter to prevent water leaks.

Rear Door Sash Inner Trim Replacement

Note. Take care not to scratch the door.

Scheme 64

Scheme 65

1. Lower the glass fully.
2. Remove the door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-panel-removalinstallation) ).
3. Detach the door sash inner trim and weatherstrip mounting clips.
4. Remove the door sash inner trim (A). - Detach the clips. - While removing the lower edge of the door sash inner trim from the edge of the sash, and release the hook (B), then remove the door sash inner trim.
5. Reinstall new door outer molding in the reverse order of removal, and push the clips into place securely.

Rear Door Sash Outer Trim Replacement

Note. Take care not to scratch the door.

Scheme 66

1. Lower the glass fully.
2. Remove the door glass outer weatherstrip (see «REAR DOOR GLASS OUTER WEATHERSTRIP REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-glass-outer-weatherstrip-replacement) ).
3. Pull the glass run channel (A) away as needed, and remove the screws (B), pull back the door sash outer trim (C) to release the hook (D) from the door rear edge of the door.
4. Install the trim in the reverse order of removal.

Rear Door Glass Outer Weatherstrip Replacement

Note. Once you remove the door glass outer weatherstrip, replace it with a new one because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door.

Scheme 67

Scheme 68

Scheme 69

1. Remove the door panel (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-panel-removalinstallation) ).
2. Remove corner portion of the weatherstrip (see «REAR DOOR WEATHERSTRIP REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-weatherstrip-replacement) ).
3. Remove the screw and sealing washer from the front edge of the door.
4. Starting at the front, pull the door glass outer weatherstrip (A) up at each portion where the inner molding (B) catches the inside edge of the window slot. Take care not to bend the door outer molding (C).
5. First slide the door glass outer weatherstrip (A) forward slightly, detach the rear clip (B) by pulling the front of the weatherstrip up, then slide the weatherstrip forward to remove it.
6. Install a new weatherstrip in the reverse order of removal.

Rear Door Outer Molding Replacement

Special Tools Required

KTC trim tool set SOJATP2014*

*Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Once you remove the door outer molding, replace it with a new one because it will bend during removal. Put on gloves to protect your hands. Take care not to scratch the door. Use the appropriate tool from the KTC trim tool set to avoid damage when prying components.

Scheme 70

Scheme 71

1. Remove the quarter glass (see «REAR DOOR GLASS AND REGULATOR REPLACEMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-glass-and-regulator-replacement) ).
2. Remove the screws.
3. Pry the front clips with the appropriate tool from the KTC trim tool set.
4. While removing the upper edge of the door outer molding (A) from the edge of the sash, cut the double-sided adhesive tape (B) with a utility knife, then remove the molding.
5. Scrape the remaining double-sided adhesive tape from the sash, then clean the sash surface with a sponge dampened in alcohol.
6. Install a new door outer molding in the reverse order of removal, and note these items: Push the clips and the adhesive portions into place securely. Make sure the upper and lower sides of the molding are catching the edges of the sash properly. Make sure the lower end of the door outer molding is under the door glass outer weatherstrips (C).

Rear Door Weatherstrip Replacement

Note. Take care not to scratch the door. Use a clip remover to remove the clips.

Scheme 72

1. Remove the door checker mounting bolt (A).
2. Detach the clips (B, C, D, E), then remove the door weatherstrip (F).
3. Install the weatherstrip in the reverse order of removal, and note these items: Check for damaged or stress-whitened clips, and replace them with new ones. Make sure the weatherstrip is installed in the holder (G) securely. Apply liquid thread lock to the door checker mounting bolt before installation. Check for water leaks (see step 7 in «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ).

Scheme 73

Scheme 74

1. With a T40 Torx bit, remove the door hook pin (A) from the door.
2. With a T40 Torx bit, remove the bolts, then remove the door catch (A) from the body.
3. Install the hook pin and catch in the reverse order of removal, and apply liquid thread lock to the threads of the door hook pin.

Front and Rear Door Glass Adjustment

Note. Check the weatherstrips and glass run channel for damage or deterioration, and replace them if necessary. Wipe the run channel clean with a shop towel. Lubricate the run channel with Shin-Etsu silicone grease P/N 08798-9013.

Scheme 75

Scheme 76

Scheme 77

Scheme 78

1. Place the vehicle on a firm, level surface.
2. Remove these items: Door panel, front door (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ), rear door (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-panel-removalinstallation) ) Plastic cover, front door (see «COMPONENT LOCATION INDEX - FRONT DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) ), rear door (see «COMPONENT LOCATION INDEX - REAR DOOR»(/acura/tl/iii-2003-2006/remont/windows/#door-system) )
3. Carefully move the glass (A) until you can see the glass mounting bolts (B), then loosen them.
4. Push the glass against the channel (C), then tighten the glass mounting bolts.
5. Make sure that the glass moves smoothly.
6. Raise the glass fully, and check for gaps. Also check that the glass (A) contacts the glass run channel (B) evenly.
7. Check for water leaks. Run water over the roof and on the sealing area as shown, and note these items: Use a 12 mm (1/2 in.) diameter hose (A). Adjust the rate of water flow as shown (B) in (Scheme 79). Do not use a nozzle. Hold the hose about 300 mm (12 in.) away from the door (C).
8. Attach the plastic cover, and install the door panel, front door (see «FRONT DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-door-panel-removalinstallation) ), rear door (see «REAR DOOR PANEL REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/windows/#door-system__rear-door-panel-removalinstallation) ).

Front and Rear Door Position Adjustment

SRS components are located in the lower B-pillar area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before performing repairs or service.

Note. Check for a flush fit with the body, then check for equal gaps between the front, rear, and bottom door edges and the body. Check that the door and body edges are parallel.

Scheme 79

Scheme 80

Scheme 81

1. Place the vehicle on a firm, level surface when adjusting the doors.
2. Adjust at the hinges (A): Place a shop towel (B) on the jack (C) to prevent damage to the door when adjusting it. On the front door: Remove the front inner fender (see «FRONT INNER FENDER REPLACEMENT»(/acura/tl/iii-2003-2006/remont/exterior-body-panels/#fenderwell__front-inner-fender-replacement) ) and front fender fairing (see «FRONT FENDER FAIRING REPLACEMENT»(/acura/tl/iii-2003-2006/remont/exterior-body-panels/#fenderwell) ). Loosen the hinge mounting bolts (D) slightly, and move the door backward or forward. On the rear door: Remove the B-pillar lower trim (see «B-PILLAR»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#interior-trim) ) and remove the front seat belt and retractor (see «FRONT SEAT BELT REPLACEMENT»(/acura/tl/iii-2003-2006/remont/restraints-control-systems/#seat-belt-system__front-seat-belt-replacement) ), and the plug seal from the body. Loosen the hinge mounting nuts (E) slightly, and move the door backward or forward, up or down as necessary to equalize the gaps.
3. If necessary, replace the door mounting bolts with the adjusting bolts (P/N 90102-SFA-305) made specifically for door adjustment, then adjust at the door: Loosen the door mounting bolts (F) slightly, and move the door up or down as necessary to equalize the gaps, and in or out until it's flush with the body.
4. Make sure that the door and body edges are parallel. If necessary, adjust the door cushion (A) to make the rear of the doors flush with the body.
5. Apply touch-up paint to the hinge mounting bolts, and around the hinges.
6. Check for water leaks (see step 7 in «FRONT AND REAR DOOR GLASS ADJUSTMENT»(/acura/tl/iii-2003-2006/remont/windows/#door-system__front-and-rear-door-glass-adjustment) ).

Front and Rear Door Striker Adjustment

Make sure the door latches securely without slamming it. If necessary, adjust the striker (A). The striker can be adjusted slightly up or down, and in or out.

Scheme 82

Scheme 83

1. Release the hooks (B), then remove the striker trim (C).
2. Loosen but do not remove the screws (A), then insert a shop towel (B) between the body and striker (C).
3. Lightly tighten the screws.
4. Wrap the striker with a shop towel, then adjust the striker by tapping it with a plastic hammer (D). Do not hit the striker too hard.
5. Loosen the screws, and remove the shop towel.
6. Lightly tighten the screws.
7. Hold the outer handle out, and push the door against the body to be sure the striker allows a flush fit. If the door latches properly, tighten the screws and recheck.

See also:
• RESETTING THE POWER WINDOW CONTROL UNIT
• POWER MIRROR REPLACEMENT
• COMPONENT LOCATION INDEX
• FRONT INNER FENDER REPLACEMENT
• FRONT FENDER FAIRING REPLACEMENT
• B-PILLAR
• FRONT SEAT BELT REPLACEMENT
• FRONT DOOR PANEL REMOVAL/INSTALLATION
• COMPONENT LOCATION INDEX - FRONT DOOR
• FRONT AND REAR DOOR GLASS ADJUSTMENT
• FRONT DOOR SASH OUTER TRIM REPLACEMENT
• FRONT DOOR WEATHERSTRIP REPLACEMENT
• REAR DOOR PANEL REMOVAL/INSTALLATION
• REAR DOOR GLASS AND REGULATOR REPLACEMENT
• REAR DOOR OUTER HANDLE REPLACEMENT
• REAR DOOR GLASS OUTER WEATHERSTRIP REPLACEMENT
• REAR DOOR WEATHERSTRIP REPLACEMENT
