Clock Acura TL III

Gauges & Instrument Panels 2 illustrations ~101 words

Scheme 47

Scheme 47: Without Navigation
Scheme 47: Without Navigation

Without Navigation

Note. Vehicles with navigation; refer to audio-HVAC sub display unit removal/installation (see AUDIO UNIT REMOVAL/INSTALLATION ).

Scheme 48

Scheme 48: Without Navigation
Scheme 48: Without Navigation
  1. Remove the upper panel (see «DRIVER'S DASHBOARD UNDER COVER REMOVAL/INSTALLATION»(/acura/tl/iii-2003-2006/remont/exteriorinterior-trim/#dashboard) ).
  2. Disconnect the 5P connector (A) from the clock.
  3. Remove the two mounting screws, and remove the clock (B). TERMINALS Cavity Wire Connect to 1 WHT/RED Constant power 2 YEL IG1 (Main clock power supply) 3 - Not used 4 BLK Ground (G503, G601) 5 RED/BLU Lights-on signal (-)
  4. Install in the reverse order of removal.
