Power Relay Test
Use this chart to identify the type of relay, then do the test listed for it.
Note. For the turn signal/hazard relay input test (see TURN SIGNAL/HAZARD RELAY INPUT TEST ).
| Relay | Test |
|---|---|
| A/C compressor clutch relay | Normally-open type A |
| Air fuel ratio sensor relay | |
| A/C condenser fan relay | |
| Headlight relay 1 | |
| Headlight relay 2 | |
| Horn relay | |
| Ignition coil relay (1) | |
| Power window relay | |
| Radiator fan relay | |
| Reverse relay (A/T) | |
| Rear accessory power socket relay (USA) | |
| Seat heater relay (Canada) | |
| Security horn relay | |
| Starter cut relay | |
| Taillight relay | |
| Daytime running lights relay (Canada) | |
| PGM-FI main relay 1 | |
| PGM-FI main relay 2 | |
| Blower motor relay | Normally-open type B |
| Rear BOSE stereo amplifier relay | |
| Rear window defogger relay | |
| Key interlock relay | Five terminal type |
| Moonroof close relay | |
| Moonroof open relay | |
| Shift lock relay (A/T) | |
| (1) '05-06 models | |
| (1) | '05-06 models |
RELAYS TEST REFERENCE CHART
Normally-open type A
Check for continuity between the terminals.
Scheme 53
- There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 4 terminals.
- There should be no continuity between the No. 1 and No. 2 terminals when power is disconnected.
type 1
Scheme 54
type 2
Scheme 55
PGM-FI main relay 1
PCM-FI main relay 2
type 1
Scheme 56
type 2
Scheme 57
Normally-open type B
Check for continuity between the terminals.
Scheme 58
- There should be continuity between the No. 1 and No. 3 terminals when power and ground are connected to the No. 2 and No. 4 terminals.
- There should be no continuity between the No. 1 and No. 3 terminals when power is disconnected.
Blower motor relay
type 1
Scheme 59
type 2
Scheme 60
Scheme 61
Scheme 62
Five-terminal type
Check for continuity between the terminals.
Scheme 63
Scheme 64
- There should be continuity between the No. 1 and No. 2 terminals when power and ground are connected to the No. 3 and No. 5 terminals.
- There should be continuity between the No. 1 and No. 4 terminals when power is disconnected.
See also:
• TURN SIGNAL/HAZARD RELAY INPUT TEST
