Connector Index
Identification numbers have been assigned to in-line connectors. The number is preceded by the letter "C" for connectors, "G" for ground terminals or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Hatch, and Roof) | Notes |
| Battery ground cable | T3, (-) G1 | | | (see CONNECTOR TO HARNESS INDEX ) |
| Engine ground cable | T4 G2 | | | (see CONNECTOR TO HARNESS INDEX ) |
| Starter subharness | C102 and C103 T1, T2, and (+) T101 and T102 | | | (see STARTER SUBHARNESS ) |
| Engine wire harness | C102, C103, C105, and C108 G101 | C101, C104 | | (see ENGINE WIRE HARNESS ) |
| Transmission range switch subharness (A/T) | C105 | | | (see TRANSMISSION RANGE SWITCH SUBHARNESS (A/T) ) |
| Engine compartment wire harness (Right branch) (3) | G201 and G202 | | | (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ('02-04 MODELS) ) |
| Engine compartment wire harness (Right branch) (4) | G201 and G202 | | | (see ENGINE COMPARTMENT WIRE HARNESS (RIGHT BRANCH) ('05-06 MODELS) ) |
| Engine compartment wire harness (Left branch) (3) | G301 and G302 | | | (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ('02-04 MODELS) ) |
| Engine compartment wire harness (Left branch) (4) | G301 and G302 | | | (see ENGINE COMPARTMENT WIRE HARNESS (LEFT BRANCH) ('05-06 MODELS) ) |
| Engine compartment wire harness (Dashboard) | | C483 | C401, C402, C403, C501, C502 | (see ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD) ) |
| Dashboard wire harness (Left branch) | | C404, C451, C452, C551, C552 G401 | | (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) |
| Dashboard wire harness (Right branch) | | C101, C405, C481, C482, C571 G402, G403 | C401, C402, C403, C503, C504, C505 G404 | (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) |
| Wiper subharness | | C451 and C452 G451 | | (see WIPER SUBHARNESS ) |
| Floor wire harness (Front branch) | | | C501 through C505 C801 (1) , C851 (2) G501 | (see FLOOR WIRE HARNESS (FRONT BRANCH) ) |
| Floor wire harness (Rear branch) (3) | | | C601, C701, C702 G502 | (see FLOOR WIRE HARNESS (REAR BRANCH) ('02-04 MODELS) ) |
| Floor wire harness (Rear branch) (4) | | | C601, C651, C701, C702 G502 | (see FLOOR WIRE HARNESS (REAR BRANCH) ('05-06 MODELS) ) |
| Fuel subharness (4) | | | C651 | (see FLOOR WIRE HARNESS (REAR BRANCH) ('05-06 MODELS) ) |
| Rear wire harness (3) | | | C601, C602 G601 | (see REAR WIRE HARNESS ('02-04 MODELS) ) |
| Rear wire harness (4) | | | C601, C602 G601 | (see REAR WIRE HARNESS ('05-06 MODELS) ) |
| License plate light subharness (3) | | | C602 | (see REAR WIRE HARNESS ('02-04 MODELS) ) |
| License plate light subharness (4) | | | C602 | (see REAR WIRE HARNESS ('05-06 MODELS) ) |
| Rear window defogger wire harness (3) | | | C751 | (see REAR WIRE HARNESS ('02-04 MODELS) ) |
| Rear window defogger wire harness (4) | | | C751 | (see REAR WIRE HARNESS ('05-06 MODELS) ) |
| Hatch wire harness (3) | | | C701, C702, G701, G702 | (see HATCH WIRE HARNESS ('02-04 MODELS) ) |
| Hatch wire harness (4) | | | C701, C702, C703, G701 | (see HATCH WIRE HARNESS ('02-04 MODELS) ) |
| Roof wire harness | | C404 | | (see ROOF WIRE HARNESS ) |
| Front impact sensor harness (1) | | C405 | | (see FRONT IMPACT SENSOR HARNESS (WITH BOSE SOUND SYSTEM) ) |
| Front impact sensor harness (2) | | C405 | | (see FRONT IMPACT SENSOR HARNESS (WITHOUT BOSE SOUND SYSTEM) ) |
| OPDS unit harness (1) | | | C851 | (see FRONT IMPACT SENSOR HARNESS (WITH BOSE SOUND SYSTEM) ) |
| OPDS unit harness (2) | | | C851 | (see FRONT IMPACT SENSOR HARNESS (WITHOUT BOSE SOUND SYSTEM) ) |
| Driver's door wire harness | | C551, C552 | | (see DRIVER'S DOOR WIRE HARNESS ) |
| Passenger's door wire harness | | C571 | | (see PASSENGER'S DOOR WIRE HARNESS ) |
| A/C wire harness | | C481, C482, C483 | | (see A/C WIRE HARNESS ) |
| Passenger's seat subharness (1) | | | C801, C851 | (see PASSENGER'S SEAT SUBHARNESS (WITH BOSE SOUND SYSTEM) ) |
| (1) With BOSE Sound System (2) Without BOSE Sound System (3) '02-04 models (4) '05-06 models |
| (1) | With BOSE Sound System |
| (2) | Without BOSE Sound System |
HARNESS AND LOCATION REFERENCE CHART
Battery Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T3 | 3 | | Left side of engine compartment | | |
| G1 | 1 | | Left side of engine compartment | Body ground via battery ground cable | |
| (-) | 2 | | Battery | Battery negative terminal | |
CONNECTOR TERMINAL LOCATION REFERENCE
Engine Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T4 | 5 | | Right side of engine compartment | | |
| G2 | 4 | | Right side of engine compartment | Body ground via engine ground cable | |
CONNECTOR TERMINAL LOCATION REFERENCE
Scheme 20
Starter Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Alternator | 9 | 4 | Right side of engine compartment | | |
| IMT (IMRC) valve position sensor | 11 | 3 | Right side of engine | | Except Type-S |
| Knock sensor | 8 | 1 | Front of engine | | |
| Starter solenoid | 7 | 1 | Middle of engine compartment | | Type-S |
| C102 | 6 | 6 | Front of engine compartment | Engine wire harness (see ENGINE WIRE HARNESS ) | Type-S |
| C102 | 6 | 8 | Front of engine compartment | Engine wire harness (see ENGINE WIRE HARNESS ) | Except Type-S |
| C103 | 5 | 1 | Front of engine compartment | Engine wire harness (see ENGINE WIRE HARNESS ) | Type-S |
| T1 | 1 | | Left side of engine compartment | Underhood fuse/relay box | |
| T2 | 4 | | Middle of engine compartment | Starter motor | |
| T101 | 2 | | Underhood fuse/relay box | | |
| T102 | 10 | | Alternator | | |
| (+) | 3 | | Battery | Battery positive terminal | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 21
Engine Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T clutch pressure control solenoid valve A | 22 | 2 | Transmission housing | | A/T |
| A/T clutch pressure control solenoid valve B | 24 | 2 | Transmission housing | | A/T |
| A/T clutch pressure control solenoid valve C | 23 | 2 | Transmission housing | | A/T |
| Back-up light switch | 27 | 2 | Transmission housing | | M/T |
| Camshaft position (CMP) sensor A | 12 | 3 | Left side of engine | | |
| Camshaft position (CMP) sensor B | 11 | 3 | Left side of engine | | |
| CKP sensor | 42 | 3 | Right side of engine | | |
| ECM/PCM connector A | 7 | 31 | Under glove box | | |
| ECM/PCM connector B | 6 | 25 | Under glove box | | |
| Engine coolant temperature (ECT) sensor | 14 | 2 | Left side of engine | | |
| Engine oil pressure switch | 44 | 1 | Right side of engine | | |
| EVAP canister purge valve | 32 | 2 | Left side of intake manifold | | |
| Idle air control (IAC) valve | 30 | 3 | Left side of intake manifold | | |
| Ignition coil No. 1 | 3 | 3 | Middle of engine compartment | | |
| Ignition coil No. 2 | 8 | 3 | Middle of engine compartment | | |
| Ignition coil No. 3 | 9 | 3 | Middle of engine compartment | | |
| Ignition coil No. 4 | 10 | 3 | Middle of engine compartment | | |
| IMT (IMRC) solenoid valve | 41 | 2 | Right side of intake manifold | | Except Type-S |
| Injector No. 1 | 40 | 2 | Middle of engine compartment | | |
| Injector No. 2 | 39 | 2 | Middle of engine compartment | | |
| Injector No. 3 | 37 | 2 | Middle of engine compartment | | |
| Injector No. 4 | 36 | 2 | Middle of engine compartment | | |
| Input shaft (mainshaft) speed sensor | 18 | 3 | Transmission housing | | A/T |
| Intake air temperature (IAT) sensor | 29 | 2 | Intake air duct | | |
| MAP sensor | 33 | 3 | Left side of intake manifold | | |
| Output shaft (countershaft) speed sensor | 17 | 3 | Transmission housing | | A/T |
| Output shaft (countershaft) speed sensor | 17 | 3 | Transmission housing | | M/T (2) |
| PCM connector C | 5 | 22 | Under glove box | | A/T |
| Reverse lockout solenoid valve | 16 | 2 | Transmission housing | | Type-S |
| Starter solenoid | 31 | 1 | Under intake manifold | | Except Type-S |
| Throttle position (TP) sensor | 28 | 3 | Left side of intake manifold | | |
| Vehicle speed sensor (VSS) | 13 | 3 | Transmission housing | | M/T (1) |
| VTC oil control solenoid valve | 43 | 2 | Right side of engine | | |
| Rocker arm oil pressure switch (VTEC oil pressure switch) | 2 | 2 | Right side of engine | | |
| Rocker arm oil control solenoid (VTEC solenoid valve) | 1 | 2 | Right side of engine | | |
| 2 nd clutch transmission fluid pressure switch | 26 | 1 | Transmission housing | | A/T |
| 3 rd clutch transmission fluid pressure switch | 21 | 1 | Transmission housing | | A/T |
| (1) '02-04 models (2) '05-06 models |
CONNECTOR TERMINAL LOCATION CHART
Scheme 22
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C101 | 4 | 20 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
| C102 | 35 | 6 | Front of engine compartment | Starter subharness (see STARTER SUBHARNESS ) | Type-S |
| C102 | 35 | 8 | Front of engine compartment | Starter subharness (see STARTER SUBHARNESS ) | |
| C103 | 34 | 1 | Front of engine compartment | Starter subharness (see STARTER SUBHARNESS ) | Type-S |
| C104 (Junction connector) | 15 | 24 | Under right side of dash | Junction connector | |
| C105 | 19 | 10 | Transmission housing | Transmission range switch subharness | A/T |
| C108 | 25 | 8 | Transmission housing | ATF temperature sensor and shift solenoid valves | A/T |
| G101 | 38 | | Cylinder head cover | Engine ground, via engine wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Transmission Range Switch Subharness (A/T)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Transmission range switch | 20 | 10 | Transmission housing | | |
| C105 | 19 | 10 | Transmission housing | Engine wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 23
Engine Compartment Wire Harness (Right branch) ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ABS modulator-control unit | 1 | 25 | Right side of engine compartment | | |
| A/C compressor | 10 | 1 | Front of engine compartment | | |
| A/C condenser fan motor | 12 | 2 | Front of engine compartment | | |
| Hood switch (security) | 13 | 2 | Front of engine compartment | | |
| Horn (security) | 6 | 1 | Behind front bumper | | |
| Radiator fan switch | 11 | 2 | Front of engine compartment | | |
| Right front wheel sensor | 3 | 2 | Right side of engine compartment | | |
| Right front parking light | 2 | 2 | Behind right headlight | | |
| Right front turn signal light | 8 | 2 | Behind right headlight | | |
| Right headlight (high beam) | 9 | 3 | Behind right headlight | | |
| Right headlight (low beam) | 7 | 3 | Behind right headlight | | |
| G201 | 5 | | Behind right side of front bumper | Body ground via engine compartment wire harness | |
| G202 | 4 | | Behind right side of front bumper | Body ground via engine compartment wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 24
Engine Compartment Wire Harness (Right branch) ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ABS modulator-control unit | 1 | 25 | Right side of engine compartment | | |
| A/C compressor | 11 | 1 | Front of engine compartment | | |
| A/C condenser fan motor | 13 | 2 | Front of engine compartment | | |
| Hood switch (security) | 14 | 2 | Front of engine compartment | | |
| Horn (security) | 5 | 1 | Behind front bumper | | |
| Radiator fan switch | 12 | 2 | Front of engine compartment | | |
| Right front wheel sensor | 2 | 2 | Right side of engine compartment | | |
| Right front parking light | 9 | 2 | Behind right headlight | | |
| Right front side marker light | 7 | 2 | Behind right headlight | | |
| Right front turn signal light | 10 | 2 | Behind right headlight | | |
| Right headlight (high beam) | 8 | 2 | Behind right headlight | | |
| Right headlight (low beam) | 6 | 3 | Behind right headlight | | |
| G201 | 4 | | Behind right side of front bumper | Body ground via engine compartment wire harness | |
| G202 | 3 | | Behind right side of front bumper | Body ground via engine compartment wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 25
Engine Compartment Wire Harness (Left branch) ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C pressure switch | 3 | 2 | Front of engine compartment | | |
| A/F sensor | 16 | 4 | Below the backside of engine | | |
| ELD unit | 18 | 3 | Underhood fuse/relay box | | |
| Horn (Low) | 5 | 1 | Behind front bumper | | |
| Left front wheel sensor | 14 | 2 | Left side of engine compartment | | |
| Left front impact sensor | 10 | 2 | Left side of engine compartment | | |
| Left front parking light | 11 | 2 | Behind left headlight | | |
| Left front turn signal light | 24 | 2 | Behind left headlight | | |
| Left headlight (high beam) | 23 | 3 | Behind left headlight | | |
| Left headlight (low beam) | 25 | 3 | Behind left headlight | | |
| Optional connector (for fog light) | 12 | 1 | Left side of engine compartment | | |
| Outside air temperature sensor | 4 | 2 | Behind front bumper | | |
| Radiator fan motor | 1 | 2 | Front of engine compartment | | |
| Rear window washer motor | 9 | 2 | Behind left side of front bumper | | |
| Secondary heated oxygen sensor (SHO2S) | 15 | 4 | Left side of engine compartment | | |
| Test tachometer connector | 13 | 2 | Left side of engine compartment | | |
| Underhood fuse/relay box connector A (see UNDERHOOD FUSE/RELAY BOX ) | 20 | 2 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector B (see UNDERHOOD FUSE/RELAY BOX ) | 22 | 12 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector C (see UNDERHOOD FUSE/RELAY BOX ) | 17 | 7 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector D (see UNDERHOOD FUSE/RELAY BOX ) | 19 | 14 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector E (see UNDERHOOD FUSE/RELAY BOX ) | 21 | 5 | Underhood fuse/relay box | | |
| Washer fluid level switch | 6 | 2 | Behind left side of front bumper | | Canada |
| Windshield washer motor | 8 | 2 | Behind left side of front bumper | | |
| G301 | 7 | | Left side of engine compartment | Body ground via engine compartment wire harness | |
| G302 | 2 | | Under the radiator | Body ground via engine compartment wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 26
Engine Compartment Wire Harness (Left branch) ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C pressure switch | 3 | 2 | Front of engine compartment | | |
| A/F sensor | 18 | 4 | Below the backside of engine | | |
| ELD unit | 20 | 3 | Underhood fuse/relay box | | |
| Horn (Low) | 7 | 1 | Behind front bumper | | |
| Left front wheel sensor | 16 | 2 | Left side of engine compartment | | |
| Left front impact sensor | 12 | 2 | Left side of engine compartment | | |
| Left front parking light | 5 | 2 | Behind left headlight | | |
| Left front side marker light | 25 | 2 | Left headlight | | |
| Left front turn signal light | 4 | 2 | Behind left headlight | | |
| Left headlight (high beam) | 13 | 2 | Behind left headlight | | |
| Left headlight (low beam) | 26 | 3 | Behind left headlight | | |
| Optional connector (for fog light) | 14 | 1 | Left side of engine compartment | | |
| Outside air temperature sensor | 6 | 2 | Behind front bumper | | |
| Radiator fan motor | 1 | 2 | Front of engine compartment | | |
| Rear window washer motor | 11 | 2 | Behind left side of front bumper | | |
| Secondary heated oxygen sensor (SHO2S) | 17 | 4 | Left side of engine compartment | | |
| Test tachometer connector | 15 | 2 | Left side of engine compartment | | |
| Underhood fuse/relay box connector A (see UNDERHOOD FUSE/RELAY BOX ) | 22 | 2 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector B (see UNDERHOOD FUSE/RELAY BOX ) | 24 | 12 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector C (see UNDERHOOD FUSE/RELAY BOX ) | 19 | 7 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector D (see UNDERHOOD FUSE/RELAY BOX ) | 21 | 14 | Underhood fuse/relay box | | |
| Underhood fuse/relay box connector E (see UNDERHOOD FUSE/RELAY BOX ) | 23 | 5 | Underhood fuse/relay box | | |
| Washer fluid level switch | 8 | 2 | Behind left side of front bumper | | Canada |
| Windshield washer motor | 10 | 2 | Behind left side of front bumper | | |
| G301 | 9 | | Left side of engine compartment | Body ground via engine compartment wire harness | |
| G302 | 2 | | Under the radiator | Body ground via engine compartment wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 27
Engine Compartment Wire Harness (Dashboard)
CONNECTOR TERMINAL LOCATION CHART
Scheme 28
Dashboard Wire Harness (Left branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Beverage holder light | 16 | 2 | Under middle of dash | | |
| Brake pedal position switch | 37 | 4 | Under left side of dash | | |
| Cable reel connector A | 28 | 4 | In steering column cover | Driver's airbag first and second inflators | |
| Cable reel connector B | 13 | 5 | In steering column cover | | |
| Clutch pedal position switch | 38 | 2 | Under left side of dash | | Cruise |
| Clutch interlock switch | 39 | 2 | Under left side of dash | | |
| Combination light switch | 10 | 16 | In steering column cover | | |
| Cruise control unit | 4 | 14 | Under left side of dash | | |
| Cruise control main switch | 43 | 5 | Left side of dash | | |
| Data link connector (DLC) | 17 | 16 | Under middle of dash | | |
| Daytime running lights control unit | 1 | 14 | Under left side of dash | | |
| Daytime running lights relay | 56 | 4 | Under left side of dash | | Canada |
| Diode (for security system) | 5 | 2 | Under left side of dash | | Canada |
| Diode (for daytime running lights system) | 40 | 2 | Under left side of dash | | Canada |
| Diode (for key interlock) | 44 | 2 | Under left side of dash | | '05-06 models' |
| Front accessory power socket | 18 | 2 | Under middle of dash | | |
| Gauge assembly connector A | 7 | 22 | Behind gauge | | '02-04 models |
| Gauge assembly connector A | 7 | 20 | Behind gauge | | '05-06 models |
| Gauge assembly connector B | 9 | 18 | Behind gauge | | '02-04 models |
| Gauge assembly connector B | 9 | 16 | Behind gauge | | '05-06 models |
| Ignition key switch/key light | 26 | 6 | In steering column cover | | |
| Ignition switch | 27 | 7 | In steering column cover | | |
| In-car temperature sensor | 11 | 2 | Under middle of dash | | |
| Immobilizer control unit-receiver | 25 | 7 | In steering column cover | | |
| Key interlock relay | 53 | 5 | Under left side of dash | | '05-06 models (1) |
| Keyless receiver unit | 12 | 5 | Under middle of dash | | |
| Left tweeter | 51 | 2 | Left side of dash | | |
| Moonroof close relay | 52 | 5 | Under left side of dash | | |
| Moonroof open relay | 55 | 5 | Under left side of dash | | |
| Moonroof switch | 42 | 6 | Left side of dash | | |
| Optional rear accessory power socket connector | 45 | 2 | Under left side of dash | | Canada |
| Power mirror switch | 41 | 13 | Left side of dash | | |
| Rear accessory power socket relay | 56 | 4 | Under left side of dash | | USA |
| Seat heater switch | 15 | 10 | Under middle of dash | | Canada |
| Security control unit connector A | 2 | 20 | Middle of dash | | |
| Security control unit connector B | 3 | 16 | Under left side of dash | | |
| Security horn relay | 54 | 4 | Under left side of dash | | |
| Sunlight sensor | 8 | 2 | Under left side of dash | | |
| (1) A/T |
CONNECTOR TERMINAL LOCATION CHART
Scheme 29
CONNECTOR TERMINAL LOCATION CHART
Scheme 30
Dashboard Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Airbag inflator (passenger's) | 24 | 4 | Under right side of dash | | |
| Antenna sublead connector | 35 | 1 | Behind audio unit | | '05-06 models |
| Audio unit | 1 | 20 | Behind audio unit | | |
| A/F sensor relay | 11 | 4 | Behind glove box | | |
| Climate control unit | 2 | 30 | Behind climate control unit | | |
| ECM/PCM connector E | 20 | 31 | Under glove box | | |
| Glove box light | 14 | 2 | Behind glove box | | |
| Hazard warning switch | 3 | 10 | Middle of dash | | |
| Ignition coil relay | 6 | 4 | Behind glove box | | '05-06 models |
| No. 31 (15 A) (IG COIL) fuse | 9 | | Behind glove box | | '05-06 models |
| No. 32 (15 A) (IGP) fuse | 10 | | Behind glove box | | '05-06 models |
| Park pin switch and transmission gear selection switch | 28 | 8 | Under shift lever console panel | | A/T |
| PCM connector D | 19 | 17 | Under glove box | | A/T |
| PGM-FI main relay 1 | 12 | 4 | Behind glove box | | |
| PGM-FI main relay 2 | 13 | 4 | Behind glove box | | |
| Reverse relay | 7 | 5 | Behind glove box | | A/T |
| Right tweeter | 15 | 2 | Right side of dash | | |
| Seat heater relay | 7 | 4 | Behind glove box | | Canada |
| Shift lock relay | 8 | 4 | Behind glove box | | A/T |
| Shift lock solenoid | 29 | 2 | Under shift lever console panel | | A/T |
| SRS unit connector A | 31 | 18 | Under middle of dash | | |
| C101 | 18 | 20 | Under middle of dash | Engine wire harness (see ENGINE WIRE HARNESS ) | |
| C401 | 32 | 24 | Under middle of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD) ) | |
| C402 | 33 | 12 | Under middle of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD) ) | |
| C403 | 34 | 4 | Under middle of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD) ) | |
| C405 | 17 | 4 | Under right side of dash | Front SRS sensor harness with BOSE (see FRONT IMPACT SENSOR HARNESS (WITH BOSE SOUND SYSTEM) ) without BOSE (see FRONT IMPACT SENSOR HARNESS (WITHOUT BOSE SOUND SYSTEM) ) | |
| C481 | 22 | 21 | Under right side of dash | A/C wire harness (see A/C WIRE HARNESS ) | |
| C482 | 23 | 1 | Under right side of dash | A/C wire harness (see A/C WIRE HARNESS ) | |
| C503 | 27 | 21 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (FRONT BRANCH) ) | '02-04 models |
| C503 | 27 | 20 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (FRONT BRANCH) ) | '05-06 models |
| C504 | 26 | 4 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (FRONT BRANCH) ) | |
| C505 | 25 | 14 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (FRONT BRANCH) ) | BOSE |
| C505 | 25 | 2 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (FRONT BRANCH) ) | '02-04 models (1) |
| C505 | 25 | 4 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (FRONT BRANCH) ) | '05-06 models (1) |
| C571 | 16 | 18 | Under right side of dash | Passenger's door wire harness (see PASSENGER'S DOOR WIRE HARNESS ) | '02-04 models |
| C571 | 16 | 20 | Under right side of dash | Passenger's door wire harness (see PASSENGER'S DOOR WIRE HARNESS ) | '05-06 models |
| G402 | 21 | | Under right side of dash | Body ground via dashboard wire harness | |
| G403 | 4 | | Behind auto unit | Body ground via dashboard wire harness | |
| G404 | 30 | | Under shift lever console panel | Body ground via dashboard wire harness | |
| (1) Without BOSE Stereo Sound System |
| (1) | Without BOSE Stereo Sound System |
CONNECTOR TERMINAL LOCATION CHART
Scheme 31
Wiper Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Brake fluid level switch | 6 | 2 | Left side of engine compartment | | |
| Cruise control actuator | 4 | 4 | Under right side of cowl cover | | |
| Power steering pressure (PSP) switch | 5 | 2 | Left side of engine compartment | | |
| Windshield wiper motor | 7 | 5 | Under left side of cowl cover | | |
| C451 | 2 | 6 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| C452 | 1 | 5 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| G451 | 3 | | Under left side of dash | Body ground via wiper subharness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 32
Floor Wire Harness (Front branch)
| (1) | Without BOSE Sound System |
CONNECTOR TERMINAL LOCATION CHART
Scheme 33
Floor Wire Harness (Rear branch) ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door switch | 18 | 1 | Left B-pillar | | |
| Driver's seat belt tensioner | 17 | 2 | Left B-pillar | | |
| Driver's side impact sensor | 16 | 2 | Left B-pillar | | |
| EVAP emission bypass solenoid valve | 11 | 2 | Fuel tank | | |
| EVAP emission control canister vent shut valve | 9 | 2 | Fuel tank | | |
| Fuel gauge sending unit/Fuel pump | 8 | 5 | Fuel tank | | |
| Fuel tank pressure sensor | 10 | 3 | Fuel tank | | |
| Left rear wheel sensor | 13 | 2 | Left rear of floor | | |
| Left rear speaker | 15 | 2 | Left quarter panel | | |
| Passenger's door switch | 2 | 1 | Right B-pillar | | |
| Passenger's seat belt tensioner | 3 | 2 | Right B-pillar | | |
| Passenger's side impact sensor | 1 | 2 | Right B-pillar | | |
| Rear BOSE stereo amplifier/woofer | 12 | 6 | At spare tire | | |
| Right rear speaker | 4 | 2 | Right quarter panel | | |
| C601 | 5 | 10 | Right quarter panel | Rear wire harness (see REAR WIRE HARNESS ('02-04 MODELS) ) | |
| C701 | 7 | 8 | Right quarter panel | Hatch wire harness (see HATCH WIRE HARNESS ('02-04 MODELS) ) | |
| C702 | 6 | 2 | Right quarter panel | Hatch wire harness (see HATCH WIRE HARNESS ('02-04 MODELS) ) | |
| G502 | 14 | | Behind left rear seat-back | Body ground via floor wire | BOSE |
CONNECTOR TERMINAL LOCATION CHART
Scheme 34
Floor Wire Harness (Rear branch) ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door switch | 18 | 1 | Left B-pillar | | |
| Driver's seat belt tensioner | 17 | 2 | Left B-pillar | | |
| Driver's side impact sensor | 16 | 2 | Left B-pillar | | |
| EVAP emission bypass solenoid valve | 11 | 2 | Fuel tank | | |
| Fuel gauge sending unit/Fuel pump | 8 | 5 | Fuel tank | | |
| Left rear wheel sensor | 13 | 2 | Left rear of floor | | |
| Left rear speaker | 15 | 2 | Left quarter panel | | |
| Passenger's door switch | 2 | 1 | Right B-pillar | | |
| Passenger's seat belt tensioner | 3 | 2 | Right B-pillar | | |
| Passenger's side impact sensor | 1 | 2 | Right B-pillar | | |
| Rear BOSE stereo amplifier/woofer | 12 | 6 | At spare tire | | |
| Right rear speaker | 4 | 2 | Right quarter panel | | |
| C601 | 5 | 20 | Right quarter panel | Rear wire harness (see REAR WIRE HARNESS ('05-06 MODELS) ) | |
| C651 | 9 | 6 | Fuel tank | Fuel subharness | |
| C701 | 7 | 8 | Right quarter panel | Hatch wire harness (see HATCH WIRE HARNESS ('05-06 MODELS) ) | |
| C702 | 6 | 2 | Right quarter panel | Hatch wire harness (see HATCH WIRE HARNESS ('05-06 MODELS) ) | |
| G502 | 14 | | Behind left rear seat-back | Body ground via floor wire harness | BOSE |
CONNECTOR TERMINAL LOCATION CHART
Fuel Subharness ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| EVAP emission control canister vent shut valve | 10 | 2 | Fuel tank | | |
| Fuel tank pressure sensor | 11 | 3 | Fuel tank | | |
| C651 | 9 | 6 | Fuel tank | Floor wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 35
Rear Wire Harness ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Cargo area light | 3 | 2 | Right side of cargo area | | |
| Left back-up light | 13 | 2 | Left taillights | | |
| Left rear side marker light | 17 | 2 | Left taillights | | |
| Left rear turn signal light | 16 | 2 | Left taillights | | |
| Left taillight/brake light connector A | 15 | 3 | Left taillights | | |
| Left taillight/brake light connector B | 14 | 3 | Left taillights | | |
| Right back-up light | 9 | 2 | Right taillights | | |
| Right rear wheel sensor | 2 | 2 | Under right rear of floor | | |
| Right rear side marker light | 4 | 2 | Right taillights | | |
| Right rear turn signal light | 5 | 2 | Right taillights | | |
| Right taillight/brake light connector A | 6 | 3 | Right taillights | | |
| Right taillight/brake light connector B | 7 | 3 | Right taillights | | |
| Trailer lighting connector | 8 | 6 | Middle of cargo area | | |
| C601 | 1 | 10 | Right rear side of floor | Floor wire harness (see FLOOR WIRE HARNESS (REAR BRANCH) ('02-04 MODELS) ) | |
| C602 | 10 | 2 | Middle of cargo area | License plate light subharness | |
| G601 | 12 | | Middle of cargo area | Body ground via rear wire harness | |
CONNECTOR TERMINAL LOCATION CHART
License Plate Light Subharness ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| License plate light connector | 11 | 2 | Behind rear bumper | | |
| C602 | 10 | 2 | Middle of cargo area | Rear wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Rear Window Defogger Wire Harness ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector A (+) | 19 | 1 | Left C-pillar | | |
| Rear window defogger connector B (-) | 20 | 1 | Right C-pillar | | |
| Window antenna coil connector B | 18 | 2 | Middle of hatch | | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 36
Rear Wire Harness ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Cargo area light | 3 | 2 | Right side of cargo area | | |
| Left back-up light | 12 | 2 | Left taillights | | |
| Left rear side marker light | 15 | 2 | Left taillights | | |
| Left rear turn signal light | 14 | 3 | Left taillights | | |
| Left taillight/brake light connector B | 13 | 3 | Left taillights | | |
| Right back-up light | 9 | 2 | Right taillights | | |
| Right rear wheel sensor | 2 | 2 | Under right rear of floor | | |
| Right rear side marker light | 4 | 2 | Right taillights | | |
| Right rear turn signal light | 5 | 3 | Right taillights | | |
| Right taillight/brake light connector | 6 | 3 | Right taillights | | |
| Trailer lighting connector | 7 | 6 | Middle of cargo area | | |
| C601 | 1 | 20 | Right rear side of floor | Floor wire harness (see FLOOR WIRE HARNESS (REAR BRANCH) ('05-06 MODELS) ) | |
| C602 | 10 | 2 | Middle of cargo area | License plate light subharness | |
| G601 | 8 | | Middle of cargo area | Body ground via rear wire harness | |
CONNECTOR TERMINAL LOCATION CHART
License Plate Light Subharness ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| License plate light connector | 11 | 2 | Behind rear bumper | | |
| C602 | 10 | 2 | Middle of cargo area | Rear wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Rear Window Defogger Wire Harness ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector A (+) | 16 | 1 | Left C-pillar | | |
| Rear window defogger connector B (-) | 18 | 1 | Right C-pillar | | |
| Rear window defogger noise condenser | 17 | 2 | Middle of hatch | | |
| C751 | 19 | 2 | Middle of hatch | Hatch wire harness (see HATCH WIRE HARNESS ('05-06 MODELS) ) | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 37
Hatch Wire Harness ('02-04 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Hatch latch switch | 11 | 2 | Middle of hatch | | |
| Hatch lock actuator | 1 | 2 | Middle of hatch | | |
| High mount brake light | 9 | 2 | Middle of hatch | | |
| Noise condenser | 6 | 3 | Right C-pillar | | |
| Rear window wiper motor | 7 | 4 | Right side of hatch | | |
| Security hatch lock knob switch | 10 | 3 | Middle of hatch | | |
| Window antenna coil connector A | 2 | 1 | Middle of hatch | | |
| C701 | 5 | 8 | Right quarter panel | Floor wire harness (see FLOOR WIRE HARNESS (REAR BRANCH) ('02-04 MODELS) ) | |
| C702 | 4 | 2 | Right quarter panel | Floor wire harness (see FLOOR WIRE HARNESS (REAR BRANCH) ('02-04 MODELS) ) | |
| G701 | 3 | | Right C-pillar | Body ground via hatch wire harness | |
| G702 | 8 | | Middle of hatch | Body ground via hatch wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 38
Hatch Wire Harness ('05-06 models)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Hatch latch switch | 9 | 2 | Middle of hatch | | |
| Hatch lock actuator | 10 | 2 | Middle of hatch | | |
| High mount brake light | 7 | 2 | Middle of hatch | | |
| Noise condenser | 4 | 3 | Right C-pillar | | |
| Rear window wiper motor | 5 | 4 | Right side of hatch | | |
| Security hatch lock knob switch | 8 | 3 | Middle of hatch | | |
| C701 | 3 | 8 | Right quarter panel | Floor wire harness (see FLOOR WIRE HARNESS (REAR BRANCH) ('05-06 MODELS) ) | |
| C702 | 2 | 2 | Right quarter panel | Floor wire harness (see FLOOR WIRE HARNESS (REAR BRANCH) ('05-06 MODELS) ) | |
| C703 | 11 | 2 | Middle of hatch | | |
| C751 | 6 | 2 | Middle of hatch | Rear window defogger wire harness (see REAR WIRE HARNESS ('05-06 MODELS) ) | |
| G701 | 1 | | Right C-pillar | Body ground via hatch wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 39
Roof Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Ceiling light | 3 | 3 | Middle of roof | | Moonroof |
| Ceiling light | 5 | 3 | Front of roof | | Without moonroof |
| Moonroof motor | 4 | 2 | Middle of roof | | Moonroof |
| Spotlight | 2 | 2 | Front of roof | | Moonroof |
| C404 | 1 | 6 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | Moonroof |
| C4043 | 6 | 6 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | Without moonroof |
CONNECTOR TERMINAL LOCATION CHART
Scheme 40
Front Impact Sensor Harness (With BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right front impact sensor | 3 | 2 | Behind right side of front bumper | | |
| C4053 | 4 | 4 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
CONNECTOR TERMINAL LOCATION CHART
Floor Wire Harness (SRS branch) (With BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt buckle tensioner | 11 | 2 | Under driver's seat | | |
| Driver's seat belt tensioner | 9 | 2 | Left B-pillar | | |
| Driver's side airbag inflator | 12 | 2 | Under driver's seat | | |
| Driver's side impact sensor | 10 | 2 | Left side of floor | | |
| Passenger's seat belt buckle tensioner | 13 | 2 | Under passenger's seat | | |
| Passenger's seat belt tensioner | 7 | 2 | Right B-pillar | | |
| Passenger's side airbag inflator | 5 | 2 | Under passenger's seat | | |
| Passenger's side impact sensor | 8 | 2 | Right side of floor | | |
| SRS unit connector B | 1 | 18 | Under middle of dash | | |
| SRS unit connector C | 2 | 8 | Under middle of dash | | |
| C801 | 15 | 10 | Under passenger's seat | Passenger's seat subharness | |
CONNECTOR TERMINAL LOCATION CHART
Passenger's Seat Subharness (SRS branch) (With BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| C801 | 15 | 10 | Under front passenger's seat | Floor wire harness | |
| C851 | 14 | 4 | Under front passenger's seat | OPDS unit harness | |
CONNECTOR TERMINAL LOCATION CHART
OPDS Unit Harness (With BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| OPDS unit connector D | 6 | 4 | In passenger's seat | | |
| C851 | 14 | 4 | Under passenger's seat | Passenger's seat subharness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 41
Front Impact Sensor Harness (Without BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right front impact sensor | 3 | 2 | Behind right side of front bumper | | |
| C405 | 4 | 2 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
CONNECTOR TERMINAL LOCATION CHART
Floor Wire Harness (SRS branch) (Without BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat belt buckle tensioner | 13 | 2 | Under driver's seat | | |
| Driver's seat belt tensioner | 11 | 2 | Left B-pillar | | |
| Driver's side airbag inflator | 14 | 2 | Under driver's seat | | |
| Driver's side impact sensor | 12 | 2 | Left side of floor | | |
| Passenger's seat belt buckle tensioner | 5 | 2 | Under passenger's seat | | |
| Passenger's seat belt tensioner | 9 | 2 | Right B-pillar | | |
| Passenger's side airbag inflator | 7 | 2 | Under passenger's seat | | |
| Passenger's side impact sensor | 10 | 2 | Right side of floor | | |
| SRS unit connector B | 1 | 18 | Under middle of dash | | |
| SRS unit connector C | 2 | 8 | Under middle of dash | | |
| C851 | 6 | 4 | Under passenger's seat | OPDS unit harness | |
CONNECTOR TERMINAL LOCATION CHART
OPDS Unit Harness (Without BOSE Sound System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| OPDS unit connector D | 8 | 4 | In passenger's seat | | |
| C851 | 6 | 4 | Under passenger's seat | Floor wire harness | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 42
Driver's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door key cylinder switch | 1 | 3 | Driver's door | | |
| Driver's door lock actuator | 9 | 2 | Driver's door | | |
| Driver's door lock knob switch | 10 | 3 | Driver's door | | |
| Driver's door lock switch | 2 | 3 | Driver's door | | |
| Driver's power window motor | 7 | 6 | Driver's door | | |
| Left front speaker | 6 | 2 | Driver's door | | |
| Left power mirror | 3 | 3 | Driver's door | | (1) |
| Left power mirror | 3 | 6 | Driver's door | | (2) |
| Power window master switch | 8 | 14 | Driver's door | | |
| C551 | 4 | 16 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | '02-04 models |
| C551 | 4 | 20 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | '05-06 models |
| C552 | 5 | 6 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (LEFT BRANCH) ) | |
| (1) '02-04 USA models (2) '02-04 Canada models and '05-06 models |
| (2) | '02-04 Canada models and '05-06 models |
CONNECTOR TERMINAL LOCATION CHART
Scheme 43
Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Passenger's door key cylinder switch | 4 | 3 | Passenger's door | | |
| Passenger's door lock actuator | 6 | 2 | Passenger's door | | |
| Passenger's door lock knob switch | 5 | 3 | Passenger's door | | |
| Passenger's door lock switch | 3 | 3 | Passenger's door | | |
| Passenger's power window motor | 8 | 2 | Passenger's door | | |
| Passenger's power window switch | 7 | 5 | Passenger's door | | |
| Right front speaker | 9 | 2 | Passenger's door | | |
| Right power mirror | 2 | 3 | Passenger's door | | (1) |
| Right power mirror | 2 | 6 | Passenger's door | | (2) |
| C571 | 1 | 18 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '02-04 models |
| C571 | 1 | 20 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | '05-06 models |
| (1) '02-04 USA models (2) '02-04 Canada models and '05-06 models |
| (2) | '02-04 Canada models and '05-06 models |
CONNECTOR TERMINAL LOCATION CHART
Scheme 44
A/C Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Air mix control motor | 1 | 5 | Under middle of dash | | |
| Blower motor | 5 | 2 | Under right side of dash | | |
| Evaporator temperature sensor | 2 | 2 | Under middle of dash | | |
| Mode control motor | 8 | 10 | Under right side of dash | | |
| Power transistor | 4 | 4 | Under right side of dash | | |
| Recirculation control motor | 9 | 5 | Under right side of dash | | |
| C481 | 7 | 21 | Behind glove box | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
| C482 | 6 | 1 | Behind glove box | Dashboard wire harness (see DASHBOARD WIRE HARNESS (RIGHT BRANCH) ) | |
| C483 | 3 | 1 | Under middle of dash | Engine compartment wire harness (see ENGINE COMPARTMENT WIRE HARNESS (DASHBOARD) ) | |
CONNECTOR TERMINAL LOCATION CHART
Scheme 45
Passenger's Seat Subharness (With BOSE Sound System)
CONNECTOR TERMINAL LOCATION CHART
Scheme 46
