Under-hood Fuse/Relay Box
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 1 | 30 A | BLU/YEL | A/C condenser fan motor |
| BLU/RED | A/C compressor clutch | ||
| 2 | 15 A (3) | WHT/GRN | Dash lights, Front parking lights, Front side marker lights (4) , License plate lights, Taillights, Trailer lighting connector, Rear side marker lights |
| 10 A (4) | |||
| 3 | 7.5 A | WHT/BLU | Cargo area light, Ceiling light, Ignition key light, Spotlights (with moonroof) |
| 4 | 20 A | BLU/BLK | Radiator fan motor |
| 5 | 15 A (3) | WHT/BLK | Turn signal/hazard relay, Turn signal lights |
| 10 A (4) | |||
| 6 | 15 A (3) | WHT/BLK | CKP sensor, ECM/PCM, IAC valve, Immobilizer control unit-receiver, Injectors, PGM-FI main relay 1 and 2, Camshaft position (CMP) sensor B |
| 20 A (4) | RED/YEL | No. 31 and No. 32 fuses (in the auxiliary under-dash fuse/relay box) | |
| 7 | 15 A | WHT/GRN | Brake lights, Brake signals to ABS modulator-control unit, Cruise control unit, ECM/PCM, Trailer lighting connector. Security horn relay, Security horn |
| BLU/RED | Horn | ||
| 8 | 20 A | WHT/GRN | ABS modulator-control unit |
| 9 | 7.5 A | WHT/RED | Audio unit, Data link connector (DLC), Gauge assembly, Immobilizer control unit-receiver, Immobilizer indicator, Keyless receiver unit, Multiplex control unit, Security control unit |
| 10 | 30 A | WHT/RED | ABS modulator-control unit |
| 11 | 40 A | BLK/YEL | Rear window defogger, Noise condenser |
| 12 | 40 A | BLU/WHT | Blower motor |
| 13 | 40 A | WHT/BLK | No. 7 and 21 fuses (in the under-dash fuse/relay box), Power window relay |
| 14 | 30 A | WHT/RED | No. 2, 3, 15 and 16 fuses (in the under-dash fuse/relay box) |
| 15 | 20 A | RED/YEL | Daytime running lights relay (Canada), Daytime running lights control unit (Canada), High beam indicator light (USA), Left headlight |
| 16 | 15 A | WHT | Multiplex control unit |
| 17 | 20 A | RED | Daytime running lights control unit (Canada), Right headlight |
| 18 | WHT/BLU | Optional connector (Canada) | |
| 19 | 100 A | Battery, Power distribution | |
| 20 | 40 A (1) | WHT | Ignition switch (BAT) |
| 50 A (2) | |||
| (1) USA (2) Canada (3) '02-04 models (4) '05-06 models | |||
| (1) | USA |
| (2) | Canada |
| (3) | '02-04 models |
| (4) | '05-06 models |
FUSE NUMBER AND AMPERE REFERENCE CHART
Scheme 49
Under-dash Fuse/Relay Box
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 1 | 15 A | BLK/WHT | Ignition coils |
| 2 | 20 A | WHT/RED | A/F sensor, ECM/PCM |
| 3 | 10 A | RED/BLU | Daytime running lights control unit (Canada), Rear accessory power socket (USA) |
| 4 | 10 A | BLK/ORN | Alternator, A/F sensor relay, CMP sensor, Cruise control unit, ELD unit, Evaporative emission (EVAP) bypass solenoid valve, Evaporative emission (EVAP) canister vent shut valve, Evaporative emission (EVAP) canister purge valve, IMT (IMRC) solenoid valve, Reverse lock solenoid (Type S), Secondary HO2S, Vehicle speed sensor (M/T) |
| 5 | Not used | ||
| 6 | 7.5 A | YEL/GRN | Moonroof open and close relay, Power window control unit (in the power window master switch), Power window relay |
| 7 | 20 A | GRN | Moonroof motor |
| 8 | 7.5 A | YEL/RED | Audio unit, Shift lock solenoid |
| 9 | 10 A | GRN | OPDS unit, Rear window wiper motor, Rear window washer motor |
| 10 | 7.5 A | YEL | A/T reverse relay, Back-up lights, Gauge assembly, Keyless receiver unit, Multiplex control unit, Security control unit, Shift lock relay |
| 11 | 7.5 A | BLK/ORN | ABS modulator-control unit |
| 12 | 7.5 A | YEL/RED | Daytime running lights control unit (Canada) |
| 13 | 10 A | PNK | SRS unit |
| 14 | 10 A | BLK/YEL | A/C compressor clutch relay, Climate control unit, A/C condenser fan relay, Blower motor relay, Power mirror actuator, Power mirror defogger (Canada), Radiator fan relay, Recirculation control motor, Rear window defogger relay, Seat heater relay (Canada) |
| 15 | 20 A | BLU/RED | Front stereo amplifier (with BOSE sound system), Rear stereo amplifier (with BOSE sound system) |
| 16 | 20 A | RED/BLK | Seat heater (Canada) |
| 17 | 15 A | BLK/YEL | ECM/PCM, Fuel pump, SRS unit |
| 18 | 15 A | YEL/GRN | Front accessory power socket, Rear accessory power socket relay (USA) |
| 19 | 7.5 A | YEL/BLK | Turn signal/hazard relay, Turn signal lights |
| 20 | 20 A | GRN/BLK | Multiplex control unit, Windshield wiper motor, Windshield washer motor |
| 21 | Not used | ||
| 22 | 20 A | GRN/BLK | Passenger's window motor |
| 23 | 20 A | GRN/WHT | Driver's window motor |
| 24 | Not used | ||
| 25 | Not used |
SOCKET AND TERMINAL REFERENCE CHART
Scheme 50
Auxiliary Under-dash Fuse/Relay Box ('05-06 models)
| Fuse Number | Amps | Wire Color | Component(s) or Circuit(s) Protected |
|---|---|---|---|
| 31 | 15 A | BLU | Ignition coil relay |
| 32 | 15 A | WHT/BLK | PGM-FI main relay |
FUSE NUMBER AND AMPERE REFERENCE CHART
