Seat Heaters Acura RL II

Scheme 93

Scheme 94

Scheme 95

1. Remove the driver's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/seats/#seats__front-seat-removalinstallation) ).
2. Disconnect the 4P connector (A) and 2P connector (B) from the seat heater. Seat-back
3. Check for continuity between the B1 and B2 terminals of the seat-back heater 2P connector. There should be continuity. Seat Cushion
4. Check for continuity between the A3 and B1 terminals, the A1 and B2 terminals, and the A2 and B2 terminals. There should be continuity.
5. If the continuity is not as specified, replace the appropriate seat heater.

Scheme 96

1. Remove the passenger's seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/seats/#seats__front-seat-removalinstallation) ).
2. Disconnect the 4P connector (A) from the seat heater.
3. Check for continuity between the No. 1 and No. 2 terminals, and No. 1 and No. 3 terminals of the 4P connector. There should be continuity.
4. If the continuity is not as specified, replace the seat heater.

Scheme 97

Scheme 98

1. Remove the center console panel (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Disconnect the 6P connector from the seat heater switch (A).
3. Remove the two screws and the switch.
4. Check for continuity between the terminals in each switch position (Scheme 98)
5. If the continuity is not as specified, replace the illumination bulbs (B) or the switch.
