Power Lumbar Support Acura RL II

Seats 6 illustrations ~151 words
Fig. 1: Identifying Power Lumbar Support Component Location
Scheme 1: Identifying Power Lumbar Support Component Location
Fig. 2: Power Lumbar Support - Circuit Diagram
Scheme 2: Power Lumbar Support - Circuit Diagram

Scheme 99

Scheme 99: Switch Test/Replacement
Scheme 99: Switch Test/Replacement

Scheme 100

Scheme 100
Scheme 100
  1. Separate the lumbar support switch cover (A) from the switch (B) to remove the switch. (Scheme 99): Identifying Lumbar Support Switch Cover And Switch
  2. Disconnect the 5P connector (C) from the switch.
  3. Check for continuity between the terminals in each switch position according to the table. (Scheme 100): Terminals Continuity Chart
  4. If the continuity is not as specified, replace the switch.

Scheme 101

Scheme 101: Motor Test
Scheme 101: Motor Test

Scheme 102

Scheme 102
Scheme 102
  1. Remove the front seat (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/rl/ii-2004-2008/remont/seats/#seats__front-seat-removalinstallation) ).
  2. Disconnect the 2P connector from the lumbar support motor (A). (Scheme 101): Identifying Lumbar Support Motor And 2P Connector
  3. Test each motor by applying battery voltage and body ground to the terminals. (Scheme 102): Terminals Voltage Reference Chart
  4. If the motor does not run or fails to run smoothly, replace it (see «FRONT SEAT LUMBAR SUPPORT REPLACEMENT»(/acura/rl/ii-2004-2008/remont/seats/#seats__front-seat-lumbar-support-replacement) ).
