Audio Remote Switch Test
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ), and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Scheme 200
Scheme 201
- Remove the driver's airbag (see «DRIVER'S AIRBAG REPLACEMENT»(/acura/mdx/ii-2010-2013/remont/airbag/#srs-supplemental-restraint-system__drivers-airbag-replacement) ).
- Remove the 20P connector (A) from the cable reel.
- Measure the resistance between terminals No. 19 and No. 20 in each switch position according to the table. Position Resistance No button pressed About 10 kohms MODE About 3.7 kohms CH (+) About 1.7 kohms CH (-) About 775 ohms (VOL. UP)↑ About 357 ohms (VOL. DOWN)↓ About 100 ohms
- If the resistance is not as specified, replace the audio remote switch (see «AUDIO REMOTE SWITCH TEST»(/acura/mdx/ii-2010-2013/remont/entertainment-systems/#audio-system__audio-remote-switch-test) ).
- Use a diode tester between terminals in each switch position according to the table.
- If the diode test is not as specified, replace the audio remote switch (see «AUDIO REMOTE SWITCH TEST»(/acura/mdx/ii-2010-2013/remont/entertainment-systems/#audio-system__audio-remote-switch-test) ).
