Consoles Acura MDX II

Center Console Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to scratch the front seat, dashboard, and related parts.

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

1. Do the battery terminal disconnection procedure, and wait at least 3 minutes before beginning work.
2. Remove these items: Driver's inner dashboard trim (see «DRIVER'S INNER DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#dashboard) ) Passenger's dashboard trim (see «PASSENGER'S DASHBOARD TRIM REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#dashboard) ) Console rear trim (see «CENTER CONSOLE REAR TRIM REMOVAL/ INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-rear-trim-removal-installation) ) Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/seats/#seats__front-seat-removalinstallation) )
3. Detach the clips by pulling the console lower trim (A) back by hand, then remove it.
4. Detach the clips (A, B) by pulling the driver's center console trim (C), then remove it.
5. Detach the clips (A, B) by pulling the passenger's center console trim (C) out, and pull it forward to release its pin (D) from the center console, then remove it.
6. From driver's side, disconnect the parking pin shift connector (A) and shift lock solenoid connector (B). Remove the rear blower motor relay mounting bolt (C), second row seat heater relay mounting bolt (D) (for some models), and ground bolt (E).
7. From passenger's side, disconnect the console subharness connector (A).
8. Disconnect the HandsFreeLink control unit connector (A), and detach the harness clips (B).
9. Open the beverage holder lid. Pull the beverage holder inner case (A) up by hand to detach the clips, then remove it.
10. Shift the shift lever into the R position, then disconnect the A/T shift cable (see step 5 on «SHIFT CABLE REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/automatic-trans/#automatic-transmission) ).
11. Pull back the carpet (A) as needed, then remove the bolts (B, C) securing the center console (D).
12. Pull back the carpet (A) as needed. Slide the center console (B) backward to detach the clips and pins (C) from the dashboard, lift the console up, then carefully remove it.
13. Install the console in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely. Before tightening the bolts, make sure the dashboard wire harness is not pinched. Make sure the connectors are plugged in properly. DO the battery terminal reconnection procedure(see «BATTERY TERMINAL DISCONNECTION AND RECONNECTION»(/acura/mdx/ii-2006-2010/remont/body-electrical/#battery) Check for any DTCs that may have been set during repairs, and clear them. If necessary, adjust the shift cable (see «SHIFT CABLE ADJUSTMENT»(/acura/mdx/ii-2006-2010/remont/automatic-trans/#automatic-transmission) ).

Center Console Rear Trim Removal/ Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to scratch the center console and related parts.

Scheme 146

1. Starting at the top, gently pull out the console rear trim (A) to detach the clips (B), then pullout the trim to detach the remaining clips (C), and to release the lower tabs (D), disconnect the connectors, then remove the trim: Rear heater-A/C passenger's control panel-unit connector (E) With second row seat heater: Second row seat heater switch connectors (F) Without rear entertainment system: Accessory power socket connector (G) With rear entertainment system: Auxiliary jack connector (G)
2. Install the trim in the reverse order of removal, and note these items: Make sure all connectors are plugged in properly. If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Console Rear Trim Disassembly/Reassembly

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to scratch the trim.

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Scheme 151

Scheme 152

1. Remove the center console rear trim (see «CENTER CONSOLE REAR TRIM DISASSEMBLY/REASSEMBLY»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-rear-trim-disassemblyreassembly) ).
2. Remove the screws, then remove the center console duct (A).
3. Remove the. screws and release the hooks (A), then remove the HVAC trim (B).
4. Remove the screws, then remove the rear upper lid (A).
5. Remove the screws (A) and detach the clips (B, C), then remove the rear console vent/vent trim (D).
6. Remove the screws, then remove the rear console vent (A) from the rear console vent trim (B).
7. Without rear entertainment system: Remove the screws and release the hooks (A), then remove the accessory power socket panel (B).
8. Reassemble the rear trim in the reverse order of disassembly, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and hooks into place securely.

Console Armrest Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the console. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 153

Scheme 154

1. Remove the center console rear trim (see «CENTER CONSOLE REAR TRIM DISASSEMBLY/REASSEMBLY»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-rear-trim-disassemblyreassembly) ).
2. Starting at the rear, pull out the wood panel (A) to detach the clips, then remove it.
3. Remove the screws, then remove the armrest (A) from the space between the console frame (B) and the console latch trim (C).
4. Install the armrest in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Console Latch Panel Removal/Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the console. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 155

1. Remove the center console armrests from both sides (see «CONSOLE ARMREST REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__console-armrest-removalinstallation) ).
2. Remove the screws (A), and starting at the rear, pull out the center console latch panel (B) to detach the clips (C), then remove it.
3. Install the panel in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Console Panel Removal/ Installation

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the console. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 156

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Remove the center console latch panel (see «CENTER CONSOLE LATCH PANEL REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-latch-panel-removalinstallation) ).
3. Pull the center console panel (A) out to detach the clips (B, C). Disconnect the accessory power socket connector (D) and seat heater switch connectors (E), detach the harness clip (F), then remove the panel.
4. Install the panel in the reverse order of removal, and note these items: Make sure each connector is plugged in properly. If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Console Panel Pocket Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the pocket. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 157

Scheme 158

Scheme 159

Scheme 160

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Remove the center console panel (see «CENTER CONSOLE PANEL REMOVAL/ INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-panel-removal-installation) ).
3. Remove the screws, then remove the console pocket (A) from the console panel (B).
4. Remove the screws and release the tabs (A), then remove the upper lid (B).
5. Remove the arm (A) and the spring (B).
6. Remove the console pocket lid (A) from the console pocket (B).
7. Install the pocket in the reverse order of removal, and apply oil to entire rail area of the arm.

Center Console Beverage Holder Replacement

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the console. Use the appropriate tool from the KTC trim toll set to avoid damage when removing components.

Scheme 161

Scheme 162

Scheme 163

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Remove the console panel (see «CENTER CONSOLE PANEL REMOVAL/ INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-panel-removal-installation) ).
3. Remove the console beverage holder (A) and passenger's console panel (B) as an assembly: Detach the console subhamess connector (C). Remove the screws (D) securing the console beverage holder to the A/T gear position indicator panel (E) and console frame (F). Remove the screws (G) securing the passenger's console panel to the console frame. Pull out the passenger's console panel to detach the clips (H).
4. Remove the screws, then remove the center console beverage holder (A).
5. If necessary, separate both rails (A) from the outer case (B), then remove the shutter (C).
6. Install the beverage holder in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Center Console Box Replacement

Special Tools Required

KTC trim tool set SOJATP20T4

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Take care not to scratch the center console. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 164

Scheme 165

1. Remove the center console (see «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Remove the beverage holder and passenger's console panel as an assembly (see «CENTER CONSOLE BEVERAGE HOLDER REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-beverage-holder-replacement) ).
3. Remove the screw (A), and detach the clips (B, C) by pulling the driver's console panel (D) back, then remove if from the console frame (E).
4. Remove the HandsFreeLink control unit (see «CONTROL UNIT INPUT TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/entertainment-systems/#handsfreelink-system) ).
5. Remove the screws, disconnect the auxiliary jack connector (without rear entertainment system) or the AC power outlet connector (with rear entertainment System) (A), then remove the center console box (B) from the console frame (C).
6. Install the box in the reverse order of removal, and note these items: Make sure the auxiliary jack connector or the AC power outlet connector is plugged in properly. If the clips are damaged or stress-whitened, replace them with new ones. Push the clips into place securely.

Scheme 166

Scheme 167

1. Remove the passenger's center console trim (see step 6 on «CENTER CONSOLE REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#consoles__center-console-removalinstallation) ).
2. Remove the screws, then remove the console side pocket (A) from the passenger's center console trim (B).
3. Separate the box (A) and rail (B), then slide the console side lid (C) out.
4. Install the pocket in the reverse order of removal.
