Scheme 52
Trim Removal/Installation - Door Areas
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Front Door Sill Area
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 53
Scheme 54
Scheme 55
Scheme 56
- Detach the hooks (A) and tabs (B) from the kick panel (C) and B-pillar lower trim (D), and pull the front door sill trim (E) up by hand to detach the clips (F), then remove it from the front door opening seal (G).
- If necessary, pull the front side outer trim (H) up to detach the clips (I), then remove the trim.
- Remove the left kick panel (A) or the right kick panel (8). Pull out the door opening seal (C) as needed from the kick panel hooks (D) and the door opening flange. Remove the clip (E). Pull the kick panel back by hand to detach the clip (F), then remove it. Driver's Passenger's
- Pull out the front door opening seal (A) from the trim hooks (B) and around the front door opening flange, then remove the seal.
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and hooks into place securely.
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Rear Door Sill Area
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 57
Scheme 58
- Detach the hooks (A) and tabs (B) from the B-pillar lower trim (C) and rear side trim panel (D), and pull the rear door sill trim (E) up by hand to detach the clips (F, G), then remove it from the rear door opening seal (H).
- If necessary, pull the rear side outer trim (I) up to detach the clips (J), then remove the trim.
- Pull out the rear door opening seal (A) from the trim hooks (B) and around the rear door opening flange, then remove the seal.
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and hooks into place securely.
Trim Removal/Installation - Pillar Areas
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
A-Pillar Trim
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Follow the A-pillar trim installation procedure carefully; improper installation could cause the side curtain airbags to deploy improperly and possibly cause injury. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to scratch the trim and panels. The upper clip in the A-pillar trim (A) consists of a resin grommet (B) and a metal pin (C). The groove (D) in the grommet secures it to the body panel (E). The shoulder (F) on the grommet is broken during removal, so the clip must be replaced with a new one when the trim is reinstalled.
Scheme 59
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
- Pull the front door opening seal away from the A-pillar as needed (see step 4 on ).
- Hit the surface of the A-pillar trim (A) with a rubber mallet. The clip is located under the top of the A-pillar trim near the "SIDE CURTAIN AIRBAG" mark (B). Hitting the trim surface breaks the shoulder (C) on the grommet (D) and pushes the pin (E) and grommet against the body (F). NOTE: The clip must be replaced with a new one when the A-pillar trim is reinstalled.
- Pull the top of the A-pillar trim (A) back by hand to remove the pin (B) from the grommet (C) remaining in the body (D). NOTE: The edge of the headliner (E) lies between the A-pillar trim and the guide bracket (F) of the trim. The A-pillar trim shouldn't be pulled out too far at a time, or the guide bracket might catch the headliner and bend it.
- Remove the A-pillar trim (A) by hand to detach the remaining clips, then pull the trim up from the dashboard (B).
- Remove the grommet from the body. NOTE: The upper grommet must be replaced with a new one because the grommet is damaged during removal.
- If the side curtain airbag has been deployed, replace the A-pillar trim with a new one (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
- If the side curtain airbag has not been deployed, check the A-pillar trim (A) and note the following: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the A-pillar trim and replace it if it has any of these types of damage: Any cracks, deformations, or stress-whitened areas in the A-pillar trim Any cracks or stress-whitening in the clip and pin seating surfaces (B) Damaged guide bracket (C) Replace the upper grommet with a new one because it will be damaged during removal. If the clips (D) are damaged or stress-whitened, replace them with new ones.
- Before installing the A-pillar trim (A), carefully remove the grommet (B) from the pin (C) on the upper clip.
- Check the overlap between the headliner and A-pillar trim, and if necessary, adjust it (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ).
- Carefully reinstall the grommet (A) on the pin (B) and seat them on the A-pillar trim (C) as shown.
- Reinstall the A-pillar trim (A). Insert the bottom of the trim into the dashboard (B). Place the trim over the A-pillar (C), and fit its upper clip (D), the other clips (E) and the pin (F) into holes (G) in the A-pillar, then lightly push the trim into place. NOTE: Make sure that the side curtain airbag tether (H) is below the clip. Make sure the side curtain airbag isn't tucked down under the clips and ribs. Apply pressure to the areas of the trim on the upper clip until these clip fittings are felt. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Make sure the upper clip portions of the trim don't come off the body by tugging on the trim.
- Reinstall the front door opening seal.
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
B-Pillar Upper/Lower Trim
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
- Remove these items: Front door sill trim (see «FRONT DOOR SILL AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) Front door opening seal, as needed (see step 4 ) Rear door opening seal, as needed (see step 3 )
- Slide the front seat fully forward.
- Remove the B-pillar lower trim (A). Detach the lower clips by pulling the middle of the trim back by hand. While releasing the upper tabs (B), pull the upper portion of the trim back to release the upper hooks (C).
- Remove the front seat belt lower anchor (see «FRONT SEAT BELT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ).
- Pull the bottom of the B-pillar upper trim (A) back by hand to detach the lower hooks (B).
- Detach the upper clip by pulling the top of the B-pillar upper trim. Pull the trim down to release the upper hook (C) from the side curtain airbag B-pillar bracket (D).
- Pass the front seat belt (A) lower anchor out through a hole in the slider (B), then remove the B-pillar upper trim (C).
- Install the trim in the reverse order of removal, and note these items: If the clips (A) are damaged or stress-whitened, replace them with new ones. If the side curtain airbag has deployed, replace the B-pillar upper and lower trim and all clips on the trim with new ones (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the trim and replace it if it has any of these types of damage: Any cracks or deformations in the B-pillar upper trim (B) and the upper hook (C), and any stress-whitened areas in the upper part of the trim Any cracks or deformations in the B-pillar lower trim (D), and any breakages in the part (E) fitted with the B-pillar upper trim Any cracks or stress-whitened areas in the clips seating surfaces (F) Replace any damaged parts with new ones. Make sure the top of the trim overlaps with the headliner correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). Make sure the pin (G) on the front seat belt shoulder anchor adjuster (H) and the hole (I) on the back of the slider are engaged when installing the B-pillar upper trim. Make sure the trim hook is installed into the side curtain airbag B-pillar bracket securely. Push the clip and hooks into place securely. Before installing the anchor bolt, make sure there are no twists or kinks in the seat belt. Trim inspection Slider engagement with shoulder anchor adjuster
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Quarter Pillar Trim
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Follow the quarter pillar trim installation procedure carefully; improper installation could cause the side curtain airbag to deploy improperly and possibly cause injury. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to scratch the trim and panels. The upper clip in the quarter pillar trim (A) consists of a grommet (B) and a pin (C). The grommet expanded with the pin secures it to the body panel (D). The projections (E) on the pin is broken during removal, so the clip must be replaced with a new one when the trim is reinstalled.
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
Scheme 76
Scheme 77
Scheme 78
Scheme 79
Scheme 80
Scheme 81
Scheme 82
Scheme 83
- Remove these items: Rear door opening seal, as needed (see step 3 ) Tailgate weatherstrip, as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/exterior-body-panels/#tailgate) ) Second row seat belt lower anchor (see step 3 «SECOND ROW SEAT BELT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/restraints-control-systems/#seat-belts__second-row-seat-belt-replacement) ) Seat belt exit C-pillar cap (see step 4 «SECOND ROW SEAT BELT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/restraints-control-systems/#seat-belts__second-row-seat-belt-replacement) ) Seat belt exit D-pillar cap (see step 3 «THIRD ROW SEAT BELT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/restraints-control-systems/#seat-belts) ) With power tailgate: Left tailgate side trim (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-tailgate-area) )
- Remove the upper portion of the rear side trim panel, as needed (see «REAR SIDE TRIM PANEL REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__rear-side-trim-panel-removalinstallation) ).
- With power tailgate: Remove the pivot bracket mounting bolts, then push the power tailgate rod (A) in the quarter pillar trim (B).
- Hit the surface of the quarter pillar trim (A) with a rubber mallet. The clip is located in the top of the C-pillar near the "SIDE CURTAIN AIRBAG" mark (B). Hitting the trim surface breaks the projections (C) on the pin (D) and pushes it into the grommet (E) and against the body (F). NOTE: The clip must be replaced with a new one when the quarter pillar trim is reinstalled.
- Hit the surface of the quarter pillar trim (A) with a rubber mallet. The clip is located in the seat belt exit D-pillar cap opening. Hitting the trim surface breaks the projections (B) on the pin (C) and pushes it into the grommet (D) and against the body (E). NOTE: The clip must be replaced with a new one when the quarter pillar is reinstalled.
- While pulling the upper portion of the rear side trim panel (A) back, detach the clips (B, C), then release the lower portion of the quarter pillar trim (D) away from the body. NOTE: The quarter pillar is still fastened with two upper clips located in the middle of it.
- While pulling the lower portion of the quarter pillar trim (A) away from the body, hit the surface of the quarter pillar trim with a rubber mallet. The clip is located in the rear of the hollow (B) in the trim. Hitting the trim surface breaks the projections (C) on the pin (D) and pushes it into the grommet (E) and against the body (F). NOTE: The clip must be replaced with a new one when the quarter pillar trim is reinstalled.
- Slide the upper clip portion (A) of the quarter pillar trim (B) up at a 45° angle to remove the trim from the clip. The clip can be removed once the trim is clear.
- Remove the quarter pillar trim (A). If equipped with the premium sound system, disconnect the D-pillar speaker connector (B). If equipped with power tailgate, pull the power tailgate rod (C) out of the slit (D) in the quarter pillar trim.
- Hit the remaining upper clip (A) with a rubber mallet. Hitting the clip breaks the projections (B) on the pin (C) and pushes it into the grommet (D) and against the body (E). NOTE: The clip must be replaced with a new one when the quarter pillar trim is reinstalled.
- If the side curtain airbag has not deployed, remove the quarter pillar trim and all the clips on the trim with new ones (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
- If the side curtain airbag has not deployed, remove the upper clips (A) from the removed quarter pillar trim (B) and discard them. Then check the trim and note the following: To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect the quarter pillar trim and replace it if it has any of these types of damage: Any cracks, deformations, or stress-whitened areas in the quarter pillar trim Any cracks or stress-whitened areas in the clip seating surfaces (C, D) If any of the lower clips (E) are damaged or stress-whitened, replace them. Replace the upper clips with new ones.
- Before installing the quarter pillar trim (A), whether replaced or reinstalled, temporarily remove the new clips (B).
- Check the overlap between the headliner and quarter pillar trim, and if necessary, adjust it (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ).
- Carefully reinstall the clips (A) to the quarter pillar trim (B). Make sure that the grommet (C) is nearest to the top of the pin (D) as shown.
- Reinstall the quarter pillar trim (A). If equipped with the premium sound system, reconnect the D-pillar speaker connector (B). If equipped with power tailgate, pass the power tailgate rod (C) through the slit (D) in the quarter pillar trim. Place the trim over the C-pillar/D-pillar (E), and fit its upper clips (F), and all of the other clips (G, H) into holes (I) in the body, then lightly push the trim into place. NOTE: Make sure the side curtain airbag isn't tucked down under the clips and ribs. Apply pressure to the areas of the trim on the upper clips until these clip fittings are felt. If you push too hard, the clip will be damaged, and it will not hold the trim properly. Make sure the upper clip portions of the trim don't come off the body by tugging on the trim.
- With power tailgate: Fasten the pivot bracket (A) on the tailgate.
- Reinstall all of the removed parts.
Trim Removal/Installation - Cargo Area
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
- Remove the cargo floor lid (A). A
- Detach the hooks (A) from the rear side trim panel (B), and pull the rear trim panel (C) up by hand to detach the clips, then remove it.
- Turn the lock knobs (A) 90 °, then remove the tool set holder (B).
- Remove the screws, then remove the cargo lid hinges (A).
- Remove the cargo rear trim panel (A).
- Install the trim in the reverse order of removal, and note these items: If the clips are damaged or stress-whitened, replace them with new ones. Push the clips and hooks into place securely.
Trim Removal/Installation - Rear Side Area
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Rear Side Trim Panel Removal/Installation
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 89
Scheme 90
Scheme 91
Scheme 92
Scheme 93
Scheme 94
Scheme 95
Scheme 96
Scheme 97
Scheme 98
Scheme 99
- Remove these items: Rear door sill trim (see «REAR DOOR SILL AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) Rear door opening seal, as needed (see step 3 ) Tailgate weatherstrip, as needed (see «TAILGATE WEATHERSTRIP REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/exterior-body-panels/#tailgate) ) Cargo floor lid (see step 1 ) Rear trim panel (see step 2 ) Cargo lid hinges (see step 4 ) Cargo rear trim panel (see step 5 )
- Raise the third row seat up, and remove the clips from under the third row seat.
- Fold the third row seat-back forward.
- Pry out the cover (A) and remove the bolt (B), then remove the tie down hook (C) (two places).
- Right side: Pry out the lid (A) and remove the screw in the pull pocket.
- Open the cargo hook (A). Pry out the cover (B) and remove the screw.
- Pull out the front upper edge of the rear side trim panel (A) by hand to release the tabs (B) and hooks (C) from the quarter pillar trim (D).
- Pull out the rear upper edge of the rear side trim panel (A) by hand to release the tabs (B) and hooks (C) from the quarter pillar trim (D).
- Pull the rear side trim panel (A) back by hand to detach the clips (B, C). Left side on the vehicle without power tailgate Left side on the vehicle with power tailgate Right side
- Pull the rear side trim panel (A) up, then remove it. On the left side, disconnect the rear accessory socket connector (C).
- If necessary, remove the bolt (A), and on the left side, remove the active damper unit mounting bolts (B), then remove the rear side trim panel support bracket (C).
- Install the trim in the reverse order of removal, and note these items: Make sure the accessory socket connector is plugged in properly. If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, hooks and tabs into place securely.
Scheme 100
Scheme 101
- Remove the rear side trim panel.
- Remove the screws and release the hooks (A), then remove the armrest (B). Left side Right side
- Install the armrest in the reverse order of removal.
Scheme 102
- Remove the rear side trim panel.
- Remove the screws and release the hooks (A), then remove the speaker grille (B).
- Install the grille in the reverse order of removal.
Trim Removal/Installation - Tailgate Area
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Note. Put on gloves to protect your hands. Take care not to bend or scratch the trim and panels. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 103
Scheme 104
Scheme 105
Scheme 106
- Remove the tailgate upper trim panel (A). Detach the hooks (B) and tabs (C) from the left tailgate side trim (D) and right tailgate side trim (E). Pull the tailgate upper trim panel back by hand to detach the clips, then remove it.
- Remove the left tailgate side trim (A) arid the right tailgate side trim (B). Pull out the top of the side trim to detach the clips. Detach the tabs (C) and hooks(D) from the tailgate lower trim panel (E).
- Remove the tailgate pull pocket (A). Pry the hooks (B) with a trim tool. Carefully pull the edge of the tailgate lower trim panel (C) just beside the tailgate pull pocket by hand, and push out the inside hooks (D). Pull down the upper edge of the pocket and release the lower tabs (E). With power tailgate: Disconnect the power tailgate close switch connector (F).
- Remove the tailgate lights (see «TAILGATE LIGHT TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/interiorillumination-lights/#interior-lights) ).
- Remove the tailgate lower trim panel (A). Detach the clips (B) beside the tailgate latch. Pull down the panel to detach all of the clips (C).
- Install the trim and panel in the reverse order of removal, and note these items: Make sure the power tailgate close switch connector is plugged in properly. If the clips are damaged or stress-whitened, replace them with new ones. Push the clips, hooks, and tubs into place securely.
Sunvisor Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Note. Take care not to scratch the headliner. Be careful not to damage the dashboard and other interior trim. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. When using a flat-tip screwdriver, wrap it with protective tape to prevent damage.
Scheme 107
Scheme 108
Scheme 109
Scheme 110
- Using a trim tool, release the tabs (A) of the sunvisor cap (B) from the bracket (C).
- Remove the sunvisor (A). Remove the screws. Remove the sunvisor from the body and holder (B). Disconnect the vanity mirror light connector (C).
- Using a flat-tip screwdriver, push the hook (A), and turn the holder (B) 90°, then pull it out.
- If the side curtain airbag has deployed (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ), replace the sunvisor with a new one.
- If the side curtain airbag has not deployed, to prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed sunvisor and replace it if it has any cracks or damage: Any cracks in the sunvisor stay base (A) Any bends or cracks in the sunvisor stay shaft (B) Any cracks in the sunvisor base (C) Any cracks in the vanity mirror base (D)
- Install the sunvisor in the reverse order of removal, and make sure the vanity mirror light connector is plugged in properly.
Grab Handle Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.
Scheme 111
Scheme 112
Scheme 113
Scheme 114
Scheme 115
Scheme 116
- Lower the grab handle (A), then pull out the caps (B) by prying up at the notches (C) with a small flat-tip screwdriver.
- While pinching the clips (A), release the hooks (B), then remove the grab handle (C).
- Using a pair of pliers, remove all of the clips (A) by pinching its hooks.
- If the side curtain airbag has deployed, replace the grab handle with a new one (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ).
- If the side curtain airbag has not deployed, to prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any cracks or damage in the grab handle (A) Any cracks or stress-whitening in the caps (B)
- Install the clips (A) to the grab handle (B), then install the caps (C) fully into the clips.
- Position the grab handle (A) on the bracket (B), and push on the grab handle until the clips (C) snap into place securely.
Headliner Removal/Installation
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to bend and scratch the headliner. Be careful not to damage the dashboard and other interior trim.
Scheme 117
Scheme 118
Scheme 119
Scheme 120
Scheme 121
Scheme 122
Scheme 123
Scheme 124
Scheme 125
Scheme 126
Scheme 127
Scheme 128
Scheme 129
- Remove these items: A-pillar trim, both sides (see «A-PILLAR TRIM»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__a-pillar-trim) ) Front seat belt upper anchor, both sides (see step 7 «FRONT SEAT BELT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/restraints-control-systems/#seat-belts__front-seat-belt-replacement) ) B-pillar lower trim, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) B-pillar upper trim, both sides (see «B-PILLAR UPPER/LOWER TRIM»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__b-pillar-upperlower-trim) ) Quarter pillar trim, both sides (see «QUARTER PILLAR TRIM»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__quarter-pillar-trim) ) Sunvisors, both sides (see «SUNVISOR REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__sunvisor-removalinstallation) ) Grab handles, four places (see «GRAB HANDLE REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__grab-handle-removalinstallation) ) Rear individual map light (see «REAR INDIVIDUAL MAP LIGHT TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/interiorillumination-lights/#interior-lights) ) Cargo area light (see «TAILGATE LIGHT TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/interiorillumination-lights/#interior-lights) ) Center second row seat belt cover (see step 1 on «SECOND ROW SEAT BELT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/restraints-control-systems/#seat-belts__second-row-seat-belt-replacement) ) RES display cover (for some models) (see «REAR CONTROLLER AND SCREEN REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/entertainment-systems/#rear-entertainment-system__rear-controller-and-screen-removalinstallation) ) Roof console (see «INTERIOR LIGHT SWITCH TEST/REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/interiorillumination-lights/#interior-lights) )
- Remove the screws, then remove the roof console bezel (A).
- If necessary, remove the remaining roof console clips (A) from the body and the moonroof frame (B).
- Disconnect the roof wire harness connector (A).
- With rear entertainment system: Disconnect the RES wire harness connectors (A) and detach the harness clips (B) from the left A-pillar (C).
- With rear entertainment system: Disconnect the RES wire harness connectors (A) from the rear controller and screen (B).
- Lower the headliner (A). The vehicle with rear entertainment system is shown; and without rear entertainment system is similar. Remove the front door opening seals (B), rear door opening seals (C), and tailgate weatherstrip (D) from each roof portion. With the help of an assistant, detach the rear clips by pulling the rear portion of the headliner down. With the help of an assistant, release the fasteners (E) by lowering the headliner.
- With the help of an assistant, pull the headliner (A) along with the roof wire harness and rear entertainment system wire harness (for some models) out through the tailgate opening. Do not bend the liner. Bending the liner will crease and damage it.
- If necessary, detach the hooks, then remove the roof side pad (A).
- If necessary, remove the cushion tapes (A) fastening the roof subharness (B) to the headliner (C), detach the harness clips (D) and release the harness from the harness protector base (E), then remove them from the headliner.
- With rear entertainment system: If necessary, remove the cushion tape (A) fastening the RES wire harness (B) to the headliner (C), detach the harness clips (D) and release the harness from the harness protector base (E), then remove them from the headliner.
- Install the headliner in the reverse order of removal, and note these items: If the side curtain airbag has deployed, replace the headliner and removed trim pieces with new ones (see «COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__component-replacementinspection-after-deployment) ). To prevent the side curtain airbags from deploying improperly and possibly causing injury, inspect removed pieces and replace them if they have any of these types of damage: Any crease or tears in the headliner (A) Any cracks or breakages in the grab handle (B) Any damages around the grab handle holes (C) or sunvisor holes in the headliner Any cracks in the sunvisor stay base (D) Any bends or cracks in the sunvisor stay shaft (E) Any cracks in the sunvisor base (F) Any cracks or breakages in the vanity mirror base(G) Any fasteners (H) and clip bases (I) which have come off the headliner When installing the grab handle, push on the handle against the bracket (J) until the clips (K) snap into place securely. Check if the clips are damaged or stress-whitened, and if necessary, replace them with new ones. Replace the removed cushion tape with new ones. Check that both sides of the headliner are securely attached to the trim. Make sure the headliner overlaps the trim pieces correctly (see «CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP»(/acura/mdx/ii-2006-2010/remont/airbag/#srs-supplemental-restraint-system__checking-and-adjusting-the-headlinerpillar-trim) ). When reinstalling the headliner through the tailgate opening, be careful not to fold or bend it. Also, be careful not to scratch the body. Headliner Grab handle Sunvisor
Carpet Replacement
Special Tools Required
KTC trim tool set SOJATP2014 *
* Available through the American Honda Tool and Equipment Program; call 888-424-6857
SRS components are located in this area. Review the SRS component locations (see COMPONENT LOCATION INDEX ) and the precautions and procedures (see PRECAUTIONS AND PROCEDURES ) before doing repairs or service.
Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components. Take care not to damage, wrinkle or twist the carpet. Be careful not to damage the dashboard and other interior trim pieces.
Scheme 130
Scheme 131
Scheme 132
Scheme 133
Scheme 134
Scheme 135
Scheme 136
- Remove these items: Front seats, both sides (see «FRONT SEAT REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/seats/#seats__front-seat-removalinstallation) ) Second row seats, both sides (see «SECOND ROW SEAT REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/seats/#seats__second-row-seat-removalinstallation) ) Third row seats, both sides (see «THIRD ROW SEAT REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/seats/#seats__third-row-seat-removalinstallation) ) Front door sill trim, both sides (see «FRONT DOOR SILL AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__front-door-sill-area) ) Rear door sill trim, both sides (see «REAR DOOR SILL AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__rear-door-sill-area) ) Kick panels, both sides (see step 3 ) Driver's dashboard undercover (see «DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#dashboard) ) Passenger's dashboard undercover (see «PASSENGER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#dashboard) ) Steering joint cover (see «STEERING COLUMN REMOVAL AND INSTALLATION»(/acura/mdx/ii-2006-2010/remont/manual-power-steering/#power-steering-system__steering-column-removal-and-installation) )
- Detach the hooks (A), then remove the footrest plate (B).
- Remove the nut (A). Using a 6 mm socket wrench, release the clip (B), then remove the footrest (C).
- Remove the clips fastening both rear side trim panels (A). Pull out the edge of the carpet (B) from under the panels.
- Remove the clips fastening the edge of the carpet (A) from both front door sill areas and both rear door sill areas. Pull out the edge of the carpet from under the B-pillar lower trim (B).
- Pull out the middle edge of the carpet (A) from under the center console (B), driver's/passenger's console trim (C), and console rear trim (D).
- Release the fastener (A) on the front edge of the carpet (B), then pull back the carpet from under the dashboard.
- Remove the carpet.
- Install the carpet in the reverse order of removal, and note these items: Take care not to damage, wrinkle or twist the carpet. Make sure the seat harnesses (A) are routed correctly. Slip the slits (B) in the carpet over the rear heater duct (C) and the third row seat heater duct (D). Slip the carpet under the center console, both B-pillar lower trim, and both rear side trim panels properly.
See also:
• COMPONENT LOCATION INDEX
• COMPONENT REPLACEMENT/INSPECTION AFTER DEPLOYMENT
• CHECKING AND ADJUSTING THE HEADLINER/PILLAR TRIM OVERLAP
• FRONT SEAT BELT REPLACEMENT
• TAILGATE WEATHERSTRIP REPLACEMENT
• SECOND ROW SEAT BELT REPLACEMENT
• THIRD ROW SEAT BELT REPLACEMENT
• TAILGATE LIGHT TEST/REPLACEMENT
• REAR CONTROLLER AND SCREEN REMOVAL/INSTALLATION
• FRONT SEAT REMOVAL/INSTALLATION
• SECOND ROW SEAT REMOVAL/INSTALLATION
• THIRD ROW SEAT REMOVAL/INSTALLATION
• DRIVER'S DASHBOARD UNDERCOVER REMOVAL/INSTALLATION
• STEERING COLUMN REMOVAL AND INSTALLATION
• FRONT DOOR SILL AREA
• REAR DOOR SILL AREA
• TRIM REMOVAL/INSTALLATION - TAILGATE AREA
• REAR SIDE TRIM PANEL REMOVAL/INSTALLATION
• A-PILLAR TRIM
• B-PILLAR UPPER/LOWER TRIM
• QUARTER PILLAR TRIM
• SUNVISOR REMOVAL/INSTALLATION
• GRAB HANDLE REMOVAL/INSTALLATION
