Tailgate Acura MDX II

Exterior Body Panels 10 illustrations ~566 words

Special Tools Required

KTC trim tool set SOJATP2014 *

* Available through the American Honda Tool and Equipment Program; call 888-424-6857

Note. Put on gloves to protect your hands. Use the appropriate tool from the KTC trim tool set to avoid damage when removing components.

Scheme 122

Scheme 122: Tailgate Adjustment
Scheme 122: Tailgate Adjustment

Scheme 123

Scheme 123
Scheme 123

Scheme 124

Scheme 124
Scheme 124
  1. With power tailgate: Do the battery terminal disconnection procedure (See «DISCONNECTION»(/acura/mdx/ii-2006-2010/remont/body-electrical/#battery__disconnection) . NOTE: Open the tailgate by using the emergency lever while adjusting the tailgate: Without power tailgate (see «WITHOUT POWER TAILGATE»(/acura/mdx/ii-2006-2010/remont/door-locks-anti-theft-systems/#openers) ) With power tailgate (see «WITH POWER TAILGATE»(/acura/mdx/ii-2006-2010/remont/door-locks-anti-theft-systems/#openers) )
  2. Remove the Support strut from each side (see «TAILGATE SUPPORT STRUT REPLACEMENT»(/acura/mdx/ii-2006-2010/remont/exterior-body-panels/#tailgate) ).
  3. Remove the striker cap (A) from the rear trim panel (B).
  4. Slightly loosen each bolt (A).
  5. Adjust the tailgate (B) alignment in the following sequence: Adjust the tailgate right and left, using the elongated holes in the tailgate hinges (C). Turn the tailgate edge cushions (D), in or out as necessary, to make the tailgate fit flush with the body at the side edges. Adjust the fit between the tailgate and tailgate opening by moving the striker (E), and adjust the striker right or left until it is centered in the tailgate latch (F).
  6. Tighten each bolt securely.
  7. Check that the tailgate opens properly and locks securely.
  8. Reinstall the support struts securely.
  9. Apply touch-up paint to the hinge mounting bolts and around the hinges, and let the paint dry.
  10. Apply multipurpose grease to the pivot portion of the tailgate hinges (A) as indicated by the arrows.
  11. Reinstall all of the removed parts.
  12. With power tailgate: Do the battery terminal reconnection procedure (See «RECONNECTION»(/acura/mdx/ii-2006-2010/remont/body-electrical/#battery__reconnection) ). NOTE: Check for any DTCs that may have been set during repairs, and clear them.

Note. Use eye protection when prying the support strut clips.

Scheme 125

Scheme 125: Tailgate Support Strut Replacement
Scheme 125: Tailgate Support Strut Replacement

Scheme 126

Scheme 126
Scheme 126

Scheme 127

Scheme 127
Scheme 127
  1. With the help of an assistant, use a flat-tip screwdriver (A) to pry the support strut clips (B) from each end of the support strut (C) at the tailgate and body, then release the support strut from the pivot bolt (D) and from the pivot bracket (E). Do not remove the clips from the support strut.
  2. Remove the bolts, then remove the pivot bracket (A).
  3. Reinstall the pivot bracket.
  4. Set the clips (A) on the original position, then reattach the support strut (B) on the pivot bolt (C) and pivot bracket (D) by pushing the support strut onto the pivot.

Scheme 128

Scheme 128: Tailgate Weatherstrip Replacement
Scheme 128: Tailgate Weatherstrip Replacement

Scheme 129

Scheme 129
Scheme 129

Scheme 130

Scheme 130
Scheme 130

Scheme 131

Scheme 131
Scheme 131
  1. With power tailgate: Remove the left tailgate side trim (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-tailgate-area) ).
  2. With power tailgate: Remove the pivot bracket mounting bolts, then push the power tailgate rod (A) in the quarter pillar trim (B).
  3. Remove the tailgate weatherstrip (A) by pulling it out.
  4. Locate the painted alignment mark (A) on the tailgate weatherstrip (B). Align the painted mark with the alignment notch in the center of the tailgate opening, and install the tailgate weatherstrip all the way around. Slip the weatherstrip in under the lips (C) of both rear gutter covers (D). Make sure there are no wrinkles in the weatherstrip.
  5. With power tailgate: Fasten the pivot bracket (A) on the tailgate.
  6. With power tailgate: Reinstall the left tailgate side trim (see «TRIM REMOVAL/INSTALLATION - TAILGATE AREA»(/acura/mdx/ii-2006-2010/remont/exteriorinterior-trim/#interior-trim__trim-removalinstallation-tailgate-area) ).
  7. Check for water leaks.
