Under-hood Fuse/Relay Box (Auxiliary Under-hood Relay Box part)
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| Fog light relay | 1 | 4 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) |
| Interior light relay | 2 | 4 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) |
UNDER-HOOD FUSE/RELAY BOX REFERENCE CHART
Scheme 37
Under-hood Fuse/Relay Box (Relay Control Module part)
UNDER-HOOD FUSE/RELAY BOX REFERENCE CHART
Scheme 38
Under-hood Fuse/Relay Box (Relay Block part)
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| A | 9 | 1 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) |
| A/C compressor clutch relay | 2 | 4 | |
| A/C condenser fan relay | 3 | 4 | |
| B | 8 | 1 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) |
| C | 5 | 1 | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) |
| Diode (for A/C condenser fan relay and fan control relay) | 11 | ||
| Diode (for radiator fan relay) | 10 | ||
| Fan control relay | 1 | 5 | |
| Front blower motor relay | 7 | 4 | |
| Headlight low beam relay | 6 | 4 | |
| Radiator fan relay | 4 | 4 |
UNDER-HOOD FUSE/RELAY BOX REFERENCE CHART
Scheme 39
Under-dash Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| A | 6 | 6 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| Accessory power socket relay | 8 | 4 | |
| B | 19 | 6 | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) |
| C | 18 | 12 | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) |
| D | 20 | 17 | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) |
| E | 25 | 16 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| F | 26 | 14 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| Front seat heater relay | 9 | 4 | |
| G | 21 | 6 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| H | 24 | 14 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| J | 16 | 21 | Driver's door subharness (see DRIVER'S DOOR WIRE HARNESS A ) |
| K | 15 | 12 | Driver's door subharness (see DRIVER'S DOOR WIRE HARNESS A ) |
| M | 14 | 3 | MICU service check connector |
| N | 2 | 45 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| P | 23 | 30 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| PGM-FI main relay 2 (FUEL PUMP) | 13 | 4 | |
| Power window relay | 11 | 4 | |
| Q | 22 | 14 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| R (for MES connector) | 3 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| S (for SRS) | 5 | 2 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| Short pin (for fuel pump) | 10 | ||
| Short pin (for lumbar support) | 12 | ||
| T | 7 | 6 | Not used |
| Turn signal/hazard relay | 4 | 6 | |
| W | 17 | 5 | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) |
| X | 1 | 39 | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
UNDER-DASH FUSE/RELAY BOX REFERENCE CHART
Scheme 40
Rear Fuse/Relay Box
| Socket | Ref | Terminal | Connects to |
|---|---|---|---|
| A | 6 | 2 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| B | 5 | 34 | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| C | 4 | 42 | Rear wire harness (see REAR WIRE HARNESS ) |
| Cargo area accessory power socket relay | 1 | 4 | Not used |
| D (for trailer) | 7 | 14 | |
| Rear window defogger relay | 3 | 4 | |
| SH-AWD relay | 2 | 4 |
REAR FUSE/RELAY BOX REFERENCE CHART
