Connector Index
Identification numbers have been assigned to in-line connectors, junction connectors, and terminals. The number is preceded by the letter "C" for connectors "G" for ground terminals or "T" for non-ground terminals.
| Harness | Location |
|---|
| Engine Compartment | Dashboard | Others (Floor, Door, Tailgate, and Roof) | Notes |
| A/C wire harness | | C502, C503 | | (see A/C WIRE HARNESS ) |
| Battery ground cable | (-),G1 | | | (see BATTERY GROUND CABLE ) |
| CKP sensor subharness | C151 | | | (see CKP SENSOR SUBHARNESS ) |
| Console subharness | | C901, C902 | | (see CONSOLE SUBHARNESS ) |
| Dashboard wire harness (View of driver's side) | | C304, C305, C504, C501, C510, through C518, C601, C501, C502 | | (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) |
| Dashboard wire harness (Center console) | | | C505 | C602, C603 G503 (see DASHBOARD WIRE HARNESS (CENTER CONSOLE BRANCH) ) |
| Dashboard wire harness (View of passenger's side) | | C201, C202, C203, C502, C503, C521, through C530, C604, C605, C606, C771, C901, C951 G504, G506, G507 | | (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) |
| Driver's door power mirror wire harness | | | C753 | (see DRIVER'S DOOR POWER MIRROR WIRE HARNESS ) |
| Driver's door subharness | | C751 | | (see DRIVER'S DOOR SUBHARNESS ) |
| Driver's door wire harness A | | | C752, C753 | (see DRIVER'S DOOR WIRE HARNESS A ) |
| Driver's door wire harness B | | C751 | C752 | (see DRIVER'S DOOR WIRE HARNESS B ) |
| Driver's seat subharness | | | C931 | (see DRIVER'S SEAT SUBHARNESS ) |
| Driver's seat wire harness | | | C609, C931 | (see DRIVER'S SEAT WIRE HARNESS ) |
| ECT sensor subharness | C205 | | | (see ECT SENSOR SUBHARNESS ) |
| Engine ground cable A | T2, G2 | | | (see ENGINE GROUND CABLE A ) |
| Engine ground cable B | T3, G3 | | | (see ENGINE GROUND CABLE B ) |
| Engine wire harness (Right side) | C101, C103, C104, C105, C151, C152, T101, T102 G101 | | | (see ENGINE WIRE HARNESS (RIGHT SIDE) ) |
| Engine wire harness (Left side) | C102, C153 T103, T104 | | | (see ENGINE WIRE HARNESS (LEFT SIDE) ) |
| Floor wire harness (Left branch) | | C303, C601 G601 | C602, C603, C609, C611, C612, C613, C781 G602, G603, G604 | (see FLOOR WIRE HARNESS (LEFT BRANCH) ) |
| Floor wire harness (Right branch) | | C204, C604, C605, C606 | C608, C610, C614, C615, C616, C791 G605, G606 | (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) |
| Front passenger's door power mirror wire harness | | | C773 | (see FRONT PASSENGER'S DOOR POWER MIRROR WIRE HARNESS ) |
| Front passenger's door subharness | | | C772, C773 | (see FRONT PASSENGER'S DOOR SUBHARNESS ) |
| Front passenger's door wire harness | | C771 | C772 | (see FRONT PASSENGER'S DOOR WIRE HARNESS ) |
| Front passenger's seat wire harness | | | C610 | (see FRONT PASSENGER'S POWER SEAT WIRE HARNESS ) |
| Knock sensor subharness | C152 | | | (see KNOCK SENSOR SUBHARNESS ) |
| Left engine compartment wire harness | C102, C301 G302, G303 | C206, C207, C303, C304, C305 | | (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) |
| Left rear door wire harness | C781 | | | (see LEFT REAR DOOR WIRE HARNESS ) |
| Left tailgate wire harness | C701, C702 | | | (see LEFT TAILGATE WIRE HARNESS ) |
| Middle tailgate wire harness | | | C702, C703 | (see MIDDLE TAILGATE WIRE HARNESS ) |
| ODS unit harness | | | C616 | (see ODS UNIT HARNESS ) |
| Rear wire harness | | | C611, C614, C701, C704, S701 G701 G702 | (see REAR WIRE HARNESS ) |
| Rear subframe wire harness | | | C613, G651 | (see REAR SUBFRAME WIRE HARNESS ) |
| RES wire harness | | C951 | | (see RES WIRE HARNESS (WITH REAR ENTERTAINMENT SYSTEM) ) |
| Right engine compartment wire harness (Front of engine compartment) | C101, C205, C212, C301, G201, G301 | | | (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (FRONT OF ENGINE COMPARTMENT) ) |
| Right engine compartment wire harness (Dash to rear of engine compartment) | G202 | C201 through C204, C206 through C211 G401 | | (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) |
| Right rear door wire harness | | | C791 | (see RIGHT REAR DOOR WIRE HARNESS ) |
| Right tailgate wire harness | | | C703, C704 | (see RIGHT TAILGATE WIRE HARNESS (WITH POWER TAILGATE) ) |
| Roof subharness | | | C851 | (see ROOF SUBHARNESS ) |
| Roof wire harness | | C501 | C851, C852, C853 | (see ROOF WIRE HARNESS ) |
| Shift solenoid subharness | C153 | | | (see SHIFT SOLENOID WIRE HARNESS ) |
| Starter cable | (+), T1, T4 | | | (see STARTER CABLE ) |
| Shift solenoid wire harness | C104 | | | (see SHIFT SOLENOID WIRE HARNESS ) |
CONNECTOR AND HARNESS REFERENCE CHART
Starter Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T1 | 6 | | Left side of engine compartment | Main under-hood fuse box | |
| T4 | 5 | | Left side of engine compartment | Starter motor | |
| (+) | 9 | | Battery | Battery positive terminal | |
CONNECTOR AND HARNESS REFERENCE CHART - STARTER CABLE
Battery Ground Cable
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| (-) | 1 | | Left side of engine compartment | Battery negative terminal | |
| G1 | 2 | | Left side of engine compartment | Body ground, via battery ground cable | |
CONNECTOR AND HARNESS REFERENCE CHART - BATTERY GROUND CABLE
Engine Ground Cable A
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T2 | 3 | | Left side of engine compartment | Transmission housing | |
| G2 | 4 | | Left side of engine compartment | Body ground, via battery ground cable A | |
CONNECTOR AND HARNESS REFERENCE CHART - ENGINE GROUND CABLE
Engine Ground Cable B
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| T3 | 8 | | Right side of engine compartment | Engine mount bracket | |
| G3 | 7 | | Right side of engine compartment | Body ground, via battery ground cable B | |
CONNECTOR AND HARNESS REFERENCE CHART - ENGINE GROUND CABLE
Scheme 4
Engine Wire Harness (Right Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C compressor clutch | 28 | 1 | Right side of engine compartment | | |
| Alternator | 27 | 4 | Middle of engine compartment | | |
| CMP sensor | 34 | 3 | Right side of engine | | |
| EGR valve and position sensor | 16 | 6 | Left side of engine compartment | | |
| ECT sensor 1 | 15 | 2 | Middle of engine | | |
| EVAP canister purge valve | 13 | 2 | Left side of engine compartment | | |
| Front A/F sensor (Bank 2, Sensor 1) | 19 | 6 | Exhaust manifold (front bank) | | |
| Front secondary heated oxygen sensor (secondary HO2S) (Bank 2, Sensor 2) | 18 | 4 | Exhaust manifold (front bank) | | |
| Ignition coil No. 1 | 3 | 3 | Middle of engine | | |
| Ignition coil No. 2 | 5 | 3 | Middle of engine | | |
| Ignition coil No. 3 | 7 | 3 | Middle of engine | | |
| Ignition coil No. 4 | 25 | 3 | Middle of engine | | |
| Ignition coil No. 5 | 23 | 3 | Middle of engine | | |
| Ignition coil No. 6 | 21 | 3 | Middle of engine | | |
| Injector No. 1 | 9 | 2 | Middle of engine | | |
| Injector No. 2 | 10 | 2 | Middle of engine | | |
| Injector No. 3 | 11 | 2 | Middle of engine | | |
| Injector No. 4 | 24 | 2 | Middle of engine | | |
| Injector No. 5 | 22 | 2 | Middle of engine | | |
| Injector No. 6 | 20 | 2 | Middle of engine | | |
| Intake manifold turning (IMT) actuator | 33 | 5 | Middle of engine compartment | | |
| Oil pressure switch | 29 | 1 | Middle of engine compartment | | |
| PCM connector B | 37 | 49 | Right side of engine compartment | | |
| PCM connector C | 36 | 49 | Right side of engine compartment | | |
| Rear A/F sensor (Bank 1, Sensor 1) | 12 | 6 | Exhaust manifold (rear bank) | | |
| Rear secondary heated oxygen sensor (secondary H02S) (Bank 1, Sensor 2) | 14 | 4 | Exhaust manifold (rear bank) | | |
| Rocker arm oil control solenoid | 1 | 1 | Right side of engine | | |
| Rocker arm oil pressure switch | 32 | 1 | Right side of engine | | |
| C101 | 35 | 12 | Right side of engine compartment | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (FRONT OF ENGINE COMPARTMENT) ) | |
| C103 (Junction connector) | 4 | 24 | Middle of engine compartment | | |
| C104 (Junction connector) | 6 | 24 | Middle of engine compartment | | |
| C105 (Junction connector) | 8 | 24 | Middle of engine compartment | | |
| C151 | 2 | 6 | Middle of engine compartment | CKP sensor subhamess | |
| C152 | 30 | 1 | Right side of engine compartment | Knock sensor subharness | |
| T101 | 17 | | Right side of engine compartment | Main under-hood fuse box | |
| T102 | 26 | | Right side of engine compartment | Alternator | |
| G101 | 39 | | Right side of engine | Body ground, via engine wire harness ground cable | |
ENGINE WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
CKP Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| CKP sensor A/B | 38 | 6 | Right side of engine compartment | | |
| C151 | 2 | 6 | Right side of engine compartment | Engine wire harness | |
CKP SENSOR SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Knock Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Knock sensor | 31 | 1 | Middle of engine compartment | | |
| C152 | 30 | 1 | Middle of engine compartment | Engine wire harness | |
KNOCK SENSOR SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 5
Engine Wire Harness (Left Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C clutch pressure control valve A | 12 | 2 | Transmission housing | | |
| A/C clutch pressure control valve B | 13 | 2 | Transmission housing | | |
| A/C clutch pressure control valve C | 10 | 2 | Transmission housing | | |
| ATF temperature sensor | 15 | 2 | Transmission housing | | |
| Engine mount control solenoid | 6 | 2 | Left side of engine compartment | | |
| Input shaft (mainshaft) speed sensor | 19 | 3 | Transmission housing | | |
| Manifold absolute pressure (MAP) sensor | 5 | 3 | Right side of engine compartment | | |
| Mass airflow (MAF)/Intake air temperature (IAT) sensor | 7 | 5 | Right side of engine compartment | | |
| Output shaft (countershaft) speed sensor | 17 | 3 | Transmission housing | | |
| Starter solenoid | 21 | 1 | Left side of engine compartment | | |
| Throttle actuator and throttle position sensor | 4 | 6 | Left side of engine compartment | | |
| Transmission range switch | 16 | 10 | Transmission housing | | |
| 2nd clutch transmission fluid pressure switch | 3 | 1 | Transmission housing | | |
| 3rd clutch transmission fluid pressure switch | 18 | 1 | Transmission housing | | |
| 4th clutch transmission fluid pressure switch | 9 | 1 | Transmission housing | | |
| C102 | 8 | 1 | Left side of engine compartment | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) | |
| C153 | 20 | 5 | On the transmission housing | Shift solenoid wire harness | |
| S1 (Thermal joint) (SG2) | 1 | | Left side of engine compartment | | |
| S2 (Thermal joint) (LG2) | 2 | | Left side of engine compartment | | |
ENGINE WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Shift Solenoid Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Shift solenoid valve A | 22 | 1 | In the transmission | | |
| Shift solenoid valve B | 14 | 1 | In the transmission | | |
| Shift solenoid valve C | 23 | 1 | In the transmission | | |
| Shift solenoid valve D | 11 | 1 | In the transmission | | |
| C153 | 20 | 5 | On the transmission housing | Engine wire harness | |
SHIFT SOLENOID WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 6
Right Engine Compartment Wire Harness (Front of Engine Compartment)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C condenser fan motor | 24 | 2 | Front of engine compartment | | |
| Headlight washer motor | 5 | 2 | Behind right side of front bumper | | Canada |
| Hood switch | 23 | 2 | Front of engine compartment | | |
| Horn (High) | 26 | 1 | Front of engine compartment | | |
| Horn (Low) | 31 | 1 | Front of engine compartment | | |
| Left daytime running light | 17 | 2 | Behind left side of front bumper | | |
| Left fog light | 16 | 2 | Behind left side of front bumper | | |
| Left front parking light | 10 | 2 | Behind left headlight | | |
| Left front side marker light | 9 | 2 | Behind left headlight | | |
| Left-front suspension stroke sensor | 14 | 3 | Left front suspension | | (1) |
| Left front turn signal light | 11 | 2 | Behind left headlight | | |
| Left headlight (high beam) | 13 | 2 | Behind left headlight | | |
| Left headlight leveling motor | 12 | 3 | Behind left headlight | | |
| Left HID unit | 8 | 2 | Under left headlight | | |
| Outside air temperature sensor | 20 | 2 | Front of engine compartment | | |
| PCM | 2 | 49 | Right side of engine compartment | | |
| Radiator fan motor | 21 | 2 | Front of engine compartment | | |
| Right daytime running light | 27 | 2 | Behind right side of front bumper | | |
| Right fog light | 28 | 2 | Behind right side of front bumper | | |
| Right front initiator | 30 | 3 | Behind right side of front bumper | | TPMS |
| Right front impact sensor | 29 | 2 | Behind right side of front bumper | | |
| Right front parking light | 34 | 2 | Behind right headlight | | |
| Right front side marker light | 36 | 2 | Behind right headlight | | |
| Right-front suspension stroke sensor | 38 | 3 | Right front suspension | | (1) |
| Right front turn signal light | 32 | 2 | Behind right headlight | | |
| Right front wheel speed sensor | 37 | 2 | Right side of engine compartment | | |
| Right headlight (high beam) | 7 | 2 | Behind right headlight | | |
| Right headlight leveling motor | 6 | 3 | Behind right headlight | | |
| Right HID unit | 33 | 2 | Under right headlight | | |
| Washer fluid level switch | 4 | 2 | Behind right side of front bumper | | |
| Windshield washer motor | 35 | 2 | Behind right side of front bumper | | |
| C101 | 3 | 13 | Right side of engine compartment | Engine wire harness (see ENGINE WIRE HARNESS (RIGHT SIDE) ) | |
| C205 | 18 | 2 | Front of engine compartment | ECT sensor subharness | |
| C212 (Junction connector) | 1 | 24 | Right side of engine compartment | | |
| C301 | 15 | 3 | Left front of engine compartment | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) | |
| G201 | 25 | | Right side of engine compartment | Body ground, via right engine compartment wire harness | |
| G301 | 19 | | Left side of engine compartment | Body ground, via right engine compartment wire harness | |
| (1) With active damper system |
| (1) | With active damper system |
RIGHT ENGINE COMPARTMENT WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
ECT Sensor Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ECT sensor 2 | 22 | 2 | Left side of engine compartment | | |
| C205 | 18 | 2 | Left side of engine compartment | Right engine compartment wire harness | |
ECT SENSOR SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 7
Right Engine Compartment Wire Harness (Dash to Rear of Engine Compartment)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/C pressure sensor | 1 | 3 | Right side of engine compartment | | |
| APP sensor | 9 | 6 | Under left side of dash | | |
| Brake pedal position switch | 10 | 4 | Under left side of dash | | |
| Fog light relay | 22 | 4 | In the under-dash fuse/relay box | Under-hood auxiliary relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Front vertical acceleration sensor | 8 | 3 | Under left side of dash | | (1) |
| Headlight leveling control unit | 20 | 16 | Under right side of dash | | |
| Headlight washer relay | 21 | 4 | Under right side of dash | | Canada |
| Interior light relay | 22 | 4 | In the under-hood fuse/relay box | Under-hood auxiliary relay box (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Power steering pressure (PSP) switch | 2 | 2 | Right side of engine compartment | | |
| Under-hood fuse/relay box (Relay block) connector A | 22 | 1 | In the under-hood fuse/relay box | Relay block (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay block) connector B | 22 | 1 | In the under-hood fuse/relay box | Relay block (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay block) connector C | 22 | 1 | In the under-hood fuse/relay box | Relay block (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Right front damper coil | 3 | 2 | Right side of engine compartment | | (1) |
| TPMS control unit | 11 | 20 | Under left side of dash | | TPMS |
| Under-hood fuse/relay box (Relay control module) connector A | 22 | 4 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector B | 22 | 5 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector C | 22 | 2 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector D | 22 | 10 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector E | 22 | 14 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector F | 22 | 1 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector G | 22 | 4 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Under-hood fuse/relay box (Relay control module) connector H | 22 | 9 | In the under-hood fuse/relay box | Relay control module (see CONNECTOR TO FUSE/RELAY BOX INDEX ) | |
| Windshield wiper motor | 7 | 5 | Left side of engine compartment | | |
| C201 | 16 | 34 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C202 | 15 | 5 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C203 | 17 | 4 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C204 | 14 | 23 | Under right side of dash | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
| C206 | In | 14 | Under right side of dash | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) | |
| C207 | 6 | 20 | Under right side of dash | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) | |
| C208 (Junction connector) | 19 | 12 | Under right side of dash | | |
| C209 (Junction connector) | 13 | 12 | Under right side of dash | | |
| C210 (Junction connector) | 12 | 12 | Under right side of dash | | |
| C211 (Junction connector) | 4 | 12 | Under left side of dash | | |
| G202 | 23 | | Right side of engine compartment | Body ground, via right engine compartment wire harness | |
| G401 | 18 | | Under right side of dash | Body ground, via right engine compartment wire harness | |
| (1) With active damper system |
| (1) | With active damper system |
RIGHT ENGINE COMPARTMENT WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 8
Left Engine Compartment Wire Harness
| (1) | With active damper system |
LEFT ENGINE COMPARTMENT WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 9
Dashboard Wire Harness (View of Driver's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ACC cut relay | 44 | 5 | Under left side of dash | | |
| Auxiliary under-dash fuse holder 1 | 35 | 2 | Under left side of dash | | |
| Cable reel connector A | 14 | 4 | In steering column cover | | |
| Cable reel connector B | 16 | 20 | In steering column cover | | |
| Combination switch control unit | 15 | 8 | In steering column cover | | |
| Dash lights brightness controller | 17 | 6 | Under left side of dash | | |
| Driver's ambient light | 27 | 3 | Under left side of dash | | |
| Driver's footwell light | 26 | 2 | Under left side of dash | | |
| Gauge control module connector A | 2 | 12 | Behind gauge | | |
| Gauge control module connector B | 6 | 23 | Behind gauge | | |
| Headlight washer switch | 5 | 5 | Under left side of dash | | Canada |
| Ignition key switch/key light | 13 | 6 | In steering column cover | | |
| Ignition switch | 19 | 7 | In steering column cover | | |
| IG2 cut relay | 45 | 5 | Under left side of dash | | |
| Immobilizer-keyless control unit | 18 | 7 | In steering column cover | | |
| Left tweeter | 47 | 2 | Under left side of dash | | |
| Parking brake switch | 43 | 1 | Under left side of dash | | |
| Power mirror switch | 28 | 10 | Under left side of dash | | |
| Power telescopic motor/position sensor | 25 | 6 | In steering column cover | | |
| Power tilt motor/position sensor | 24 | 8 | In steering column cover | | |
| Power tilt/telescopic steering control unit connector A | 22 | 16 | In steering column cover | | |
| Power tilt/telescopic steering control unit connector B | 21 | 8 | In steering column cover | | |
| Power tilt/telescopic steering switch | 23 | 13 | Left side of steering column | | |
| Steering angle sensor | 20 | 5 | In steering column cover | | |
DASHBOARD WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 10
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Under-dash fuse/relay box connector A (see UNDER-DASH FUSE/RELAY BOX ) | 38 | 6 | Left kick panel | | |
| Under-dash fuse/relay box connector N (see UNDER-DASH FUSE/RELAY BOX ) | 40 | 45 | Left kick panel | | |
| Under-dash fuse/relay box connector P (MICU) (see UNDER-DASH FUSE/RELAY BOX ) | 37 | 30 | Left kick panel | | |
| Under-dash fuse/relay box connector R (MES) (see UNDER-DASH FUSE/RELAY BOX ) | 42 | 2 | Left kick panel | | |
| Under-dash fuse/relay box connector S (see UNDER-DASH FUSE/RELAY BOX ) | 41 | 2 | Left kick panel | | |
| Under-dash fuse/relay box connector X (see UNDER-DASH FUSE/RELAY BOX ) | 39 | 39 | Left kick panel | | |
| VSA OFF switch | 4 | 5 | Under left side of dash | | |
| C304 | 31 | 14 | Under left side of dash | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) | |
| C305 | 30 | 4 | Under left side of dash | Left engine compartment wire harness (see LEFT ENGINE COMPARTMENT WIRE HARNESS ) | |
| C501 | 46 | 20 | Under left side of dash | Roof wire harness (see ROOF WIRE HARNESS ) | |
| C504 (Trailer electric brake connector) | 29 | 4 | Under left side of dash | | |
| C510 (Junction connector) | 32 | 20 | Under left side of dash | | |
| C511 (Junction connector) | 1 | 12 | Under left side of dash | | |
| C512 (Junction connector) | 2 | 12 | Under left side of dash | | |
| C513 (Junction connector) | 12 | 12 | Under left side of dash | | |
| C514 (Junction connector) | 11 | 12 | Under left side of dash | | |
| C515 (Junction connector) | 7 | 12 | Under left side of dash | | |
| C516 (Junction connector) | 8 | 12 | Under left side of dash | | |
| C517 (Junction connector) | 10 | 12 | Under left side of dash | | |
| C518 (Junction connector) | 9 | 12 | Under left side of dash | | |
| C601 | 36 | 20 | Under left side of dash | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| G501 | 34 | | Under left side of dash | Body ground, via dashboard wire harness | |
| G502 | 33 | | Under left side of dash | Body ground, via dashboard wire harness | |
DASHBOARD WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 11
Dashboard Wire Harness (Center Console Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| A/T shift lock solenoid | 6 | 2 | Under center console | | |
| A/T shift lever console light/park-pin switch | 7 | 8 | Under center console | | |
| Auxiliary jack assembly | 15 | 14 | Rear of center console | | (1) |
| Data link connector | 2 | 16 | Under middle of dash | | |
| HandsFreeLink control unit | 16 | 28 | Under rear of center console | | |
| In-car temperature sensor | 3 | 4 | Under middle of dash | | |
| Left second row seat heater switch | 14 | 6 | Rear of center console | | (3) |
| Rear accessory power socket | 15 | 2 | Rear of center console | | (2) |
| Rear air mix control motor | 11 | 7 | Under center console | | |
| Rear blower motor | 8 | 2 | Under center console | | |
| Rear blower motor relay | 10 | 4 | Under center console | | |
| Rear climate control panel | 13 | 10 | Rear of center console | | |
| Rear evaporator temperature sensor | 20 | 2 | Under center console | | |
| Rear mode control motor | 17 | 7 | Under center console | | |
| Rear power transistor | 9 | 4 | Under center console | | |
| Right second row seat heater switch | 12 | 6 | Rear of center console | | (3) |
| Second row seat heater relay | 22 | 5 | Under center console | | (3) |
| SRS unit connector A | 1 | 28 | Under middle of dash | | |
| Yaw rate-lateral/longitudinal acceleration sensor | 5 | 4 | Under middle of dash | | |
| C519 (Junction connector) | 24 | 12 | Under middle of dash | | |
| C520 (Junction connector) | 23 | 12 | Under middle of dash | | |
| C602 | 18 | 20 | Under center console | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| C603 | 19 | 5 | Under center console | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | (3) |
| G503 | 21 | | Under console panel | Body ground, via dashboard wire harness | |
| G505 | 4 | | Under middle of dash | Body ground, via dashboard wire harness | |
| (1) With rear entertainment system (2) Without rear entertainment system (3) With second row seat heaters |
| (1) | With rear entertainment system |
| (2) | Without rear entertainment system |
| (3) | With second row seat heaters |
DASHBOARD WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 12
Dashboard Wire Harness (View of Passenger's Side)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AC inverter unit | 36 | 12 | Under center console | | |
| Audio unit connector A | 39 | 17 | Middle of dash | | |
| Audio unit connector B | 40 | 32 | Middle of dash | | |
| Audio unit connector C | 41 | 24 | Middle of dash | | |
| Audio unit connector D (for XM receiver) | 42 | 14 | Middle of dash | | (4) |
| Audio unit connector E | 43 | 16 | Middle of dash | | (3) |
| Audio unit connector F | 45 | 2 | Middle of dash | Digital audio lead | (3) |
| Center information display | 11 | 12 | Middle of dash | | (2) |
| Climate control unit connector A | 1 | 40 | Middle of dash | | |
| Climate control unit connector B | 2 | 14 | Middle of dash | | |
| Digital audio lead connector | 19 | 2 | Under right side of dash | Digital audio lead | (3) |
| Front center speaker | 8 | 2 | Middle of dash | | |
| Front passenger's airbag first and second inflators | 17 | 4 | Under right side of dash | | |
| Glove box light | 20 | 2 | Under right side of dash | | |
| Hazard warning switch | 3 | 6 | Middle of dash | | |
| Interface dial | 44 | 5 | Middle of dash | | (1) |
| Navigation display unit | 6 | 20 | Middle of dash | | (1) |
| Right tweeter | 16 | 2 | Under right side of dash | | |
| Stereo amplifier connector A | 22 | 28 | Under right side of dash | | (1) |
| Stereo amplifier connector A | 22 | 20 | Under right side of dash | | (2) |
| Stereo amplifier connector B | 23 | 18 | Under right side of dash | | |
| Sunlight sensor/automatic lighting sensor | 9 | 5 | Middle of dash | | |
| C201 | 26 | 34 | Under right side of dash | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) | |
| C202 | 25 | 5 | Under right side of dash | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) | |
| C203 | 27 | 4 | Under right side of dash | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) | |
| C502 | 32 | 12 | Under middle of dash | A/C wire harness (see A/C WIRE HARNESS ) | |
| C503 | 33 | 16 | Under middle of dash | A/C wire harness (see A/C WIRE HARNESS ) | |
| C521 (Junction connector) | 7 | 12 | Under right side of dash | | |
| C522 (Junction connector) | 10 | 12 | Under right side of dash | | |
| C523 (Junction connector) | 14 | 12 | Under right side of dash | | |
| C524 (Junction connector) | 5 | 12 | Under right side of dash | | |
| C525 (Junction connector) | 4 | 12 | Under right side of dash | | |
| C526 (Junction connector) | 15 | 12 | Under right side of dash | | |
| C527 (Junction connector) | 12 | 12 | Under right side of dash | | |
| C528 (Junction connector) | 13 | 12 | Under right side of dash | | |
| C529 (Junction connector) | 21 | 20 | Under right side of dash | | |
| C530 (Junction connector) | 31 | 12 | Under right side of dash | | |
| C604 | 29 | 12 | Under right side of dash | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | (4) |
| C605 | 28 | 18 | Under right side of dash | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
| C606 | 35 | 24 | Under middle of dash | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | (1) |
| C771 | 24 | 23 | Under right side of dash | Front passenger's door wire harness (see FRONT PASSENGER'S DOOR WIRE HARNESS ) | |
| C901 | 34 | 23 | Under middle of dash | Console subhamess (see CONSOLE SUBHARNESS ) | |
| C951 | 18 | 24 | Under right side of dash | RES wire harness (see RES WIRE HARNESS (WITH REAR ENTERTAINMENT SYSTEM) ) | (3) |
| G504 | 37 | | Under middle of dash | Body ground, via dashboard wire harness | |
| G506 | 38 | | Under middle of dash | Body ground, via dashboard wire harness | |
| G507 | 30 | | Under right side of dash | Body ground, via dashboard wire harness | |
| (1) With navigation (2) Without navigation (3) With rear entertainment system (4) With XM receiver |
| (3) | With rear entertainment system |
DASHBOARD WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 13
Floor Wire Harness (Left Branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Active damper control unit connector A | 30 | 14 | Left side of cargo area | | (2) |
| Active damper control unit connector B | 31 | 20 | Left side of cargo area | | (2) |
| Cargo area accessory power socket | 23 | 2 | Left side of cargo area | | |
| Driver's door switch | 46 | 1 | Left B-pillar | | |
| Driver's seat belt tensioner | 43 | 4 | Left B-pillar | | |
| Driver's side airbag inflator | 9 | 2 | Under driver's seat | | |
| EVAP canister vent shut valve | 17 | 2 | Fuel tank | | |
| Fuel fill door opener solenoid | 24 | 2 | Left side of cargo area | | |
| Fuel pump control module | 35 | 10 | Left side cargo area | | |
| Fuel pump/fuel gauge sending unit | 41 | 4 | Fuel tank | | |
| Fuel tank pressure (FTP) sensor | 18 | 3 | Fuel tank | | |
| Left rear damper coil | 38 | 2 | Under left rear floor | | (2) |
| Left rear door switch | 40 | 1 | Left C-pillar | | |
| Left rear TPMS initiator | 36 | 3 | Under left rear floor | | TPMS |
| Left rear vertical acceleration sensor | 37 | 3 | Left side of cargo area | | (2) |
| Left side impact sensor (1st) | 45 | 4 | Left B-pillar | | |
| Left side impact sensor (2nd) | 39 | 2 | Left C-pillar | | |
| Left side curtain airbag inflator | 19 | 2 | Left C-pillar | | |
| Left second row seat heater | 21 | 3 | Under left second row seat | | (1) |
| Navigation service check connector | 42 | 2 | Under driver's seat | | Navigation |
| Navigation unit connector A | 10 | 20 | Under driver's seat | | Navigation |
| Navigation unit connector B | 11 | 7 | Under driver's seat | | Navigation |
| Navigation unit connector C | 12 | 8 | Under driver's seat | | Navigation |
| Navigation unit connector D | 13 | 14 | Under driver's seat | | Navigation |
| Navigation unit connector E | 14 | 5 | Under driver's seat | | Navigation |
| Rear fuse/relay box connector A (see REAR FUSE/RELAY BOX ) | 29 | 2 | Left side of cargo area | | |
| Rear fuse/relay box connector B (see REAR FUSE/RELAY BOX ) | 28 | 34 | Left side of cargo area | | |
| Rear safing sensor | 20 | 4 | Middle of floor | | |
| Reverse diode | 27 | 2 | Left side of cargo area | | '08 model |
| SH-AWD control unit connector A | 32 | 20 | Left side of cargo area | | |
| SH-AWD control unit connector B | 33 | 8 | Left side of cargo area | | |
| Under-dash fuse/relay box connector E (see UNDER-DASH FUSE/RELAY BOX ) | 3 | 16 | Left kick panel | | |
| Under-dash fuse/relay box connector F (see UNDER-DASH FUSE/RELAY BOX ) | 4 | 14 | Left kick panel | | |
| Under-dash fuse/relay box connector G (see UNDER-DASH FUSE/RELAY BOX ) | 5 | 6 | Left kick panel | | |
| Under-dash fuse/relay box connector H (see UNDER-DASH FUSE/RELAY BOX ) | 6 | 14 | Left kick panel | | |
| Under-dash fuse/relay box connector Q (see UNDER-DASH FUSE/RELAY BOX ) | 2 | 14 | Left kick panel | | |
| (1) With second row seat heaters |
| * 2: With navigation or electrical compass |
| * 3: Without navigation and electrical compass |
| (2) With active damper system |
| (1) | With second row seat heaters |
| (2) | With active damper system |
FLOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 14
| (1) | With second row seat heaters |
| (2) | With navigation or electrical compass |
| (3) | Without navigation and electrical compass |
FLOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 15
Floor Wire Harness (Right branch)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| AcuraLink connector (Male connector) | 23 | 5 | Right side of cargo area | | (3) |
| AcuraLink connector (Female connector) | 23 | 5 | Right side of cargo area | | (3) |
| AcuraLink control unit (XM receiver) connector A | 21 | 20 | Right side of cargo area | | USA |
| AcuraLink control unit (XM receiver) connector B | 22 | 16 | Right side of cargo area | | USA |
| Front passenger's door switch | 9 | 1 | Right B-pillar | | |
| Front passenger's seat belt tensioner | 11 | 4 | Right B-pillar | | |
| Front passenger's side airbag inflator | 29 | 2 | Right B-pillar | | |
| Right rear damper coil | 17 | 2 | Under right side of floor | | (2) |
| Right rear door switch | 14 | 1 | Right C-pillar | | |
| Right rear initiator | 16 | 3 | Under right side of floor | | TPMS |
| Right-rear vertical acceleration sensor | 20 | 3 | Right side of cargo area | | (2) |
| Right side curtain airbag inflator | 27 | 4 | Right C-pillar | | |
| Right second row seat cushion heater | 25 | 3 | Under right second row seat | | (1) |
| Right side impact sensor (1st) | 10 | 4 | Right B-pillar | | |
| Right side impact sensor (2nd) | 15 | 2 | Right C-pillar | | |
| Roll rate sensor | 26 | 2 | Middle of floor | | |
| SRS unit connector B | 2 | 16 | Under middle of dash | | |
| SRS unit connector C | 1 | 28 | Under middle of dash | | |
| Subwoofer | 19 | 8 | Under front passenger's seat | | |
| XM receiver | 21 | 14 | Right side of cargo area | | (4) |
| C204 | 6 | 23 | Right kick panel | Right engine compartment wire harness (see RIGHT ENGINE COMPARTMENT WIRE HARNESS (DASH TO REAR OF ENGINE COMPARTMENT) ) | |
| C604 | 4 | 12 | Right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | (5) |
| C605 | 5 | 18 | Right kick panel | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C606 | 3 | 24 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | Navigation |
| C608 (Junction connector) | 28 | | Under middle of dash | | |
| C610 | 8 | 14 | Under front passenger's seat | Front passenger's power seat wire harness (see FRONT PASSENGER'S POWER SEAT WIRE HARNESS ) | |
| C614 | 24 | 13 | Right side of cargo area | Rear wire harness (see REAR WIRE HARNESS ) | Navigation |
| C614 | 24 | 2 | Right side of cargo area | Rear wire harness (see REAR WIRE HARNESS ) | Without Navigation |
| C615 (Junction connector) | 18 | 12 | Right side of floor | | |
| C616 | 30 | 4 | Under front passenger's seat | ODS wire harness (see ODS UNIT HARNESS ) | |
| C791 | 12 | 18 | Right B-pillar | Right rear door wire harness (see RIGHT REAR DOOR WIRE HARNESS ) | |
| G605 | 7 | | Under front passenger's seat | Body ground, via floor wire harness | |
| G606 | 13 | | Mounted on B-pillar | Body ground, via floor wire harness | |
| (1) With second row seat heaters (2) With active damper system (3) USA models with AcuraLink (4) Without AcuraLink (5) With XM receiver |
| (1) | With second row seat heaters |
| (2) | With active damper system |
| (3) | USA models with AcuraLink |
FLOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 16
Rear Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Condenser (for high mount brake light) | 22 | 2 | Left D-pillar | | '08 model |
| Condenser (for rear window defogger) | 19 | 2 | Left D-pillar | | '08 model |
| Electrical compass unit | 2 | 6 | Left D-pillar | | (4) |
| Keyless buzzer/power tailgate buzzer | 13 | 2 | Behind rear bumper | | |
| Left brake light/taillight | 15 | 3 | Left taillight assembly | | |
| Left rear side marker light | 17 | 2 | Left taillight assembly | | |
| Left rear turn signal light | 16 | 2 | Left taillight assembly | | |
| Left surround speaker | 6 | 2 | Left D-pillar | | Navigation |
| Power tailgate control unit connector A | 26 | 5 | Left D-pillar | | (1) |
| Power tailgate control unit connector B | 24 | 20 | Left D-pillar | | (1) |
| Power tailgate control unit connector C | 25 | 14 | Left D-pillar | | (1) |
| Power tailgate driver unit connector A | 4 | 2 | Left D-pillar | | (1) |
| Power tailgate driver unit connector B | 5 | 8 | Left D-pillar | | (1) |
| Rear fuse/relay box connector C (see REAR FUSE/RELAY BOX ) | 20 | 42 | Left side of cargo area | | |
| Right brake light/taillight | 11 | 3 | Right taillight assembly | | |
| Right rear side marker light | 10 | 2 | Right taillight assembly | | |
| Right rear turn signal light | 12 | 2 | Right taillight assembly | | |
| Right surround speaker | 9 | 2 | Right D-pillar | | Navigation |
| C611 | 21 | 12 | Left side of cargo area | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | (2) |
| C611 | 21 | 4 | Left side of cargo area | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | (3) |
| C614 | 7 | 13 | Right side of cargo area | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | Navigation |
| C614 | 7 | 2 | Right side of cargo area | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | Without Navigation |
| C701 | 3 | 23 | Left D-pillar | Left tailgate wire harness (see LEFT TAILGATE WIRE HARNESS ) | |
| C704 | 8 | 12 | Right D-pillar | Right tailgate wire harness (see RIGHT TAILGATE WIRE HARNESS (WITH POWER TAILGATE) ) | (1) |
| C705 (female connector) | 23 | 2 | Left D-pillar | | '08 model (1) |
| C705 (male connector) | 23 | 2 | Left D-pillar | | '08 model (1) |
| S701 (Thermal joint) | 18 | | Left D-pillar | | (1) |
| G701 | 1 | | Left D-pillar | Body ground, via rear wire harness | |
| G702 | 14 | | Center of cargo area | Body ground, via rear wire harness | |
| (1) With power tailgate (2) With navigation or compass (3) Without navigation and compass (4) Canada models without navigation |
| (2) | With navigation or compass |
| (3) | Without navigation and compass |
| (4) | Canada models without navigation |
REAR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 17
Left Tailgate Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| High mount brake light | 1 | 2 | Roof spoiler | | |
| Rear window defogger connector A (+) | 22 | 1 | Left side of rear window | | |
| C701 | 23 | 23 | Left D-pillar | Rear wire harness (see REAR WIRE HARNESS ) | |
| C702 | 2 | 18 | Left side of tailgate | Middle tailgate wire harness | |
LEFT TAILGATE WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Middle Tailgate Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left tailgate light | 19 | 2 | Left side of tailgate | | |
| Left back-up light | 3 | 2 | Left side of tailgate | | |
| Left license plate light | 14 | 2 | Center of tailgate | | |
| Left power tailgate pinch sensor | 20 | 2 | Left side of tailgate | | (1) |
| Power tailgate closer motor | 17 | 2 | Center of tailgate | | (1) |
| Power tailgate closer unit/latch and ratchet switch | 18 | 6 | Center of tailgate | | (1) |
| Power tailgate inside switch | 12 | 5 | Center of tailgate | | (1) |
| Rearview camera | 9 | 6 | Center of tailgate | | Navigation |
| Rear window defogger connector B | 5 | 1 | Right side of rear window | | (2) |
| Rear window wiper motor | 4 | 4 | Center of tailgate | | |
| Right tailgate light | 11 | 2 | Right side of rear window | | |
| Right back-up light | 7 | 2 | Right side of tailgate | | |
| Right license plate light | 10 | 2 | Center of tailgate | | |
| Right power tailgate pinch sensor | 8 | 2 | Right side of tailgate | | (1) |
| Tailgate latch switch | 15 | 2 | Center of tailgate | | (2) |
| Tailgate outer handle switch | 13 | 3 | Center of tailgate | | |
| Tailgate release actuator | 16 | 2 | Center of tailgate | | (2) |
| C702 | 2 | 18 | Left side of tailgate | Left tailgate wire harness | |
| C703 | 6 | 18 | Right side of tailgate | Right tailgate wire harness (see RIGHT TAILGATE WIRE HARNESS (WITH POWER TAILGATE) ) | (1) |
| C706 (female connector) | 21 | 2 | Center of tailgate | | '08 model (1) |
| C706 (male connector) | 21 | 2 | Center of tailgate | | '08 model (1) |
| (1) With power tailgate (2) Without power tailgate |
| (2) | Without power tailgate |
MIDDLE TAILGATE WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 18
Right Tailgate Wire Harness (With Power Tailgate)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear window defogger connector B (-) | 3 | 1 | Right side of rear window | | |
| C703 | 2 | 18 | Right side of tailgate | Middle tailgate wire harness (see MIDDLE TAILGATE WIRE HARNESS ) | |
| C704 | 1 | 12 | Right side of cargo area | Rear wire harness (see REAR WIRE HARNESS ) | |
RIGHT TAILGATE WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 19
Rear Subframe Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Differential temperature sensor | 4 | 2 | Rear differential | | |
| Left clutch electromagnetic coil | 5 | 4 | Rear differential | | |
| Left rear wheel speed sensor | 7 | 2 | Rear differential | | |
| Left rear suspension stroke sensor | 9 | 3 | Rear differential | | |
| Right clutch electromagnetic coil | 3 | 4 | Rear differential | | |
| Right rear suspension stroke sensor | 2 | 3 | Rear differential | | |
| Right rear wheel speed sensor | 1 | 2 | Rear differential | | |
| C613 | 8 | 23 | Under rear of floor | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| G651 | 6 | | Subframe | Body ground, via rear subframe wire harness | |
REAR SUBFRAME WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 20
Roof Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Automatic dimming inside mirror | 2 | 7 | Front of roof | | (1) |
| Driver's vanity mirror light | 12 | 2 | Left front side of roof | | |
| Moonroof control unit/motor | 5 | 10 | Middle of roof | | |
| Moonroof switch | 7 | 7 | Front center of roof | | |
| Optional connector | 1 | 4 | Front center of roof | | |
| Passenger's vanity mirror light | 3 | 2 | Right front side of roof | | |
| Roof console | 6 | 20 | Front center of roof | | |
| C501 | 13 | 20 | Under left side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF DRIVER'S SIDE) ) | |
| C851 | 8 | 4 | Front center of roof | Roof subhamess | |
| C852 (Junction connector) | 9 | 12 | Left front side of roof | | |
| C853 (Junction connector) | 4 | 12 | Right front side of roof | | |
| (1) Canada models |
ROOF WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Roof Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Rear individual map light (2nd) | 10 | 3 | Middle of roof | | |
| Rear individual map light (3rd) | 11 | 3 | Rear of roof | | |
| C851 | 8 | 4 | Front center of roof | Roof wire harness | |
ROOF SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 21
RES Wire Harness (With Rear Entertainment System)
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Digital audio sublead connector | 1 | 3 | Under right side of dash | | |
| Rear controller and screen connector A | 3 | 24 | Roof | | |
| Rear controller and screen connector B | 4 | 2 | Roof | | |
| C951 | 2 | 24 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
RES WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 22
Console Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Active damper system switch | 5 | 5 | Center console | | |
| Driver's seat heater switch | 7 | 6 | Center console | | |
| Front accessory power socket | 6 | 2 | Center console | | |
| Front passenger's seat heater switch | 3 | 6 | Center console | | |
| Power outlet | 4 | 3 | Console box | | (1) |
| C901 | 1 | 23 | Under middle of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C902 (junction connector) | 2 | 12 | Under middle of dash | | |
| (1) With power outlet |
CONSOLE SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 23
Driver's Door Wire Harness A
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door courtesy light | 18 | 2 | Driver's door | | |
| Driver's door lock switch | 2 | 5 | Driver's door | | |
| Driver's MPCS unit connector A | 11 | 40 | Driver's door | | |
| Driver's MPCS unit connector B | 10 | 14 | Driver's door | | |
| Driver's power tailgate switch/fuel fill door opener switch | 17 | 7 | Driver's door | | (1) |
| Driving position memory switch | 9 | 10 | Driver's door | | |
| Fuel fill door opener switch | 17 | 5 | Driver's door | | (2) |
| Power window master switch | 1 | 14 | Driver's door | | |
| C752 | 15 | 28 | Driver's door | Driver's door wire harness B | |
| C753 | 8 | 16 | Driver's door | Driver's door power mirror wire harness | |
| (1) With power tailgate (2) Without power tailgate |
| (2) | Without power tailgate |
DRIVER'S DOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Driver's Door Wire Harness B
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's door lock actuator/knob switch/key cylinder switch | 28 | 10 | Driver's door | | |
| Driver's power window motor | 19 | 6 | Driver's door | | |
| Left front speaker | 16 | 2 | Driver's door | | |
| C751 | 14 | 37 | Driver's door | Driver's door subharness | |
| C752 | 15 | 28 | Driver's door | Driver's door wire harness A | |
DRIVER'S DOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Driver's Door Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Under-dash fuse/relay box connector K (see UNDER-DASH FUSE/RELAY BOX ) | 12 | 12 | Left kick panel | | |
| Under-dash fuse/relay box connector J (see UNDER-DASH FUSE/RELAY BOX ) | 13 | 21 | Left kick panel | | |
| C751 | 14 | 20 | Driver's door | Driver's door wire harness B | |
DRIVER'S DOOR SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Driver's Door Power Mirror Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left power mirror actuator | 3 | 4 | Driver's door mirror | | |
| Left power mirror defogger connector A | 6 | 1 | Driver's door mirror | | |
| Left power mirror defogger connector | 7 | 1 | Driver's door mirror | | |
| Left power mirror position sensor | 4 | 4 | Driver's door mirror | | |
| Left side turn signal light | 5 | 2 | Driver's door mirror | | |
| C753 | 8 | 16 | Driver's door | Driver's door wire harness A | |
DRIVER'S DOOR POWER MIRROR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 24
Front Passenger's Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door lock actuator/knob switch | 9 | 10 | Front passenger's door | | |
| Front passenger's power window motor | 10 | 6 | Front passenger's door | | |
| Right front speaker | 12 | 2 | Front passenger's door | | |
| C771 | 14 | 23 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C772 | 13 | 20 | Front passenger's door | Front passenger's door subhamess | |
FRONT PASSENGER'S DOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Front Passenger's Door Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's door courtesy light | 11 | 2 | Front passenger's door | | |
| Front passenger's door lock switch | 7 | 5 | Front passenger's door | | |
| Front passenger's power window switch | 8 | 14 | Front passenger's door | | |
| Front passenger's MPCS unit connector A | 15 | 28 | Front passenger's door | | |
| Front passenger's MPCS unit connector B | 16 | 15 | Front passenger's door | | |
| C772 | 13 | 20 | Front passenger's door | Front passenger's door wire harness | |
| C773 | 1 | 16 | Front passenger's door | Front passenger's door power mirror wire harness | |
FRONT PASSENGER'S DOOR SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Front Passenger's Door Power Mirror Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right power mirror actuator | 6 | 4 | Front passenger's door mirror | | |
| Right power mirror defogger connector A | 3 | 1 | Front passenger's door mirror | | |
| Right power mirror defogger connector B | 2 | 1 | Front passenger's door mirror | | |
| Right power mirror position sensor | 5 | 4 | Front passenger's door mirror | | |
| Right side turn signal light | 4 | 2 | Front passenger's door mirror | | |
| C773 | 1 | 16 | Front passenger's door | Front passenger's door subharness | |
FRONT PASSENGER'S DOOR POWER MIRROR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 25
Left Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Left rear courtesy light | 5 | 2 | Left rear door | | |
| Left rear door lock actuator/knob switch | 6 | 10 | Left rear door | | |
| Left rear door speaker | 3 | 2 | Left rear door | | |
| Left rear power window motor | 4 | 6 | Left rear door | | |
| Left rear power window switch | 1 | 14 | Left rear door | | |
| C781 | 2 | 18 | Left B-pillar | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
LEFT REAR DOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 26
Right Rear Door Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Right rear courtesy light | 4 | 2 | Right rear door | | |
| Right rear door lock actuator/knob switch | 2 | 10 | Right rear door | | |
| Right rear door speaker | 5 | 2 | Right rear door | | |
| Right rear power window motor | 3 | 6 | Right rear door | | |
| Right rear power window switch | 1 | 14 | Right rear door | | |
| C791 | 6 | 18 | Right B-pillar | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
RIGHT REAR DOOR WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 27
Driver's Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's power seat adjustment switch | 4 | 12 | Under driver's seat | | |
| Driver's power seat control unit connector A | 14 | 40 | Under driver's seat | | |
| Driver's power seat control unit connector B | 6 | 18 | Under driver's seat | | |
| Driver's power seat front up-down motor | 13 | 2 | Under driver's seat | | |
| Driver's power seat front up-down position sensor | 12 | 4 | Under driver's seat | | |
| Driver's power seat rear up-down motor | 9 | 2 | Under driver's seat | | |
| Driver's power seat rear up-down position sensor | 10 | 4 | Under driver's seat | | |
| Driver's power seat slide motor | 7 | 2 | Under driver's seat | | |
| Driver's power seat slide position sensor | 8 | 4 | Under driver's seat | | |
| Driver's seat-back heater | 16 | 2 | Under driver's seat | | |
| Driver's seat belt buckle switch | 17 | 3 | Under driver's seat | | |
| Driver's seat cushion heater | 11 | 4 | Under driver's seat | | |
| Driver's seat position sensor | 15 | 2 | Under driver's seat | | |
| Lumbar support switch | 2 | 5 | Under driver's seat | | |
| C609 | 5 | 23 | Under driver's seat | Floor wire harness (see FLOOR WIRE HARNESS (LEFT BRANCH) ) | |
| C931 | 3 | 8 | Under driver's seat | Driver's seat subharness | |
DRIVER'S SEAT WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Driver's Seat Subharness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's seat power recline motor/power sensor | 1 | 5 | Left side of driver's seat-back | | |
| Lumbar support motor | 18 | 2 | Right side of driver's seat-back | | |
| C931 | 3 | 8 | Under driver's seat | Driver's seat wire harness | |
DRIVER'S SEAT SUBHARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 28
Front Passenger's Power Seat Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Front passenger's power seat adjustment switch | 8 | 12 | Under front passenger's seat | | |
| Front passenger's power seat front up-down motor | 2 | 2 | Under front passenger's seat | | |
| Front passenger's power seat rear up-down motor | 4 | 2 | Under front passenger's seat | | |
| Front passenger's power seat recline motor | 9 | 4 | Under front passenger's seat | | |
| Front passenger's power seat slide motor | 5 | 2 | Under front passenger's seat | | |
| Front passenger's seat belt buckle switch | 1 | 3 | Under front passenger's seat | | |
| Front passenger's seat cushion heater | 3 | 4 | Under front passenger's seat | | |
| C610 | 7 | 14 | Under front passenger's seat | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
FRONT PASSENGER'S POWER SEAT WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
ODS Unit Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| ODS unit | 10 | 18 | Left side of front passenger's seat | | |
| C616 | 6 | 4 | Under front passenger's seat | Floor wire harness (see FLOOR WIRE HARNESS (RIGHT BRANCH) ) | |
ODS UNIT HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 29
A/C Wire Harness
| Connector or Terminal | Ref | Cavities | Location | Connects to | Notes |
|---|
| Driver's air mix control motor | 11 | 7 | Under middle of dash | | |
| Front blower motor | 3 | 2 | Under right side of dash | | |
| Front evaporator temperature sensor | 10 | 2 | Under middle of dash | | |
| Front mode control motor | 1 | 7 | Under middle of dash | | |
| Front passenger's ambient light | 5 | 3 | Under right side of dash | | |
| Front passenger's footwell light | 4 | 2 | Under right side of dash | | |
| Front power transistor | 7 | 4 | Under middle of dash | | |
| Front recirculation control motor | 2 | 7 | Under middle of dash | | |
| Passenger's air mix control motor | 6 | 7 | Under middle of dash | | |
| C502 | 9 | 12 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
| C503 | 8 | 16 | Under right side of dash | Dashboard wire harness (see DASHBOARD WIRE HARNESS (VIEW OF PASSENGER'S SIDE) ) | |
A/C WIRE HARNESS CONNECTOR OR TERMINAL REFERENCE CHART
Scheme 30
