FRONT SECTION, DIMENSIONS CHART
Note. The graphics in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the graphics is always correct.
EXPLANATION OF DIMENSIONS
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess as shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 13
A1 = 1282 mm
A2 = 791 mm
A3 = 954 mm
Scheme 14
Scheme 15
Scheme 16
A4 = 1616 mm
A5 = 1570 mm
Scheme 17
Scheme 18
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess as shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 19
A6 = 1266 mm
A7 = 1419 mm
A8 = 1409 mm
Scheme 20
A9 = 1314 mm
Weld join A10 = 1070 mm
A11 = 1119 mm
Scheme 21
B1 = 862 mm
B2 = 1066 mm
B3 = 1163 mm
Scheme 22
B4 = 889 mm
B5 = 1247 mm
Scheme 23
A12 = 50 mm
A13 = 18 mm
Scheme 24
A16 = 230 mm
A17 = 132 mm
Scheme 25
A18 = 10 mm
A19 = 150 mm
Scheme 26
A14 = 5 mm
A15 = 165 mm
Scheme 27
A20 = 102 mm
A21 = 31 mm
Scheme 28
A22 = 510 mm
A23 = 35 mm
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess as shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 29
J1 = 1068 mm
J2 = 1081 mm
Scheme 30
J3 = 1259 mm
J4 = 631 mm
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess as shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 31
H1 = 984 mm
H2 = 1046 mm
H3 = 1128 mm
Scheme 32
H4 = 692 mm
H5 = 620 mm
Scheme 33
H6 = 620 mm
H7 = 262 mm
Scheme 34
H8 = 650 mm
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess as shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 35
C1 = 1125 mm
C2 = 1445 mm
C3 = 1368 mm
C4 = 1479 mm
