BODY SIDE, ALIGNMENT CHART
Note. As the graphics in this service information are used for different model years and/or models, some variation may occur. However, the essential information in the graphics is always correct.
Scheme 1
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Scheme 2
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess as shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 3
D1 = 946 mm
Scheme 4
D2 = 918 mm
D3 = 1351 mm
Scheme 5
D4 = 1046 mm
D5 = 1150 mm
Scheme 6
E1 = 1446 mm
E2 = 1276 mm
E3 = 1546 mm
Scheme 7
E4 = 1570 mm
E5 = 1478 mm
E6 = 1478 mm
Scheme 8
E7 = 1307 mm
E8 = 1342 mm
E9 = 1490 mm
E10 = 1478 mm
SIDE MEMBERS/WHEEL ARCHES FRONT, ALIGNMENT CHART
Note. As the graphics in this service information are used for different model years and/or models, some variation may occur. However, the essential information in the graphics is always correct.
SIDE MEMBERS REAR, ALIGNMENT CHART
Note. As the graphics in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the graphics is always correct.
REAR END, ALIGNMENT CHART
Note. As the graphics in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the graphics is always correct.
ROOF, ALIGNMENT CHART
The dimensions in the table are listed as follows
Symbol number 1 means that the measurement is taken from the center.
Symbol number 2 means that the measurement is taken from one edge.
Symbol number 3 means that the measurement is taken from a cut mark. Measurements are taken from the bottom of the recess shown.
If only one measuring point symbol is displayed, the symbol applies to both measuring points. Otherwise the symbols are shown on each side of the dimension shown.
Scheme 9
M1 = 980 mm
M2 = 951 mm
M3 = 978 mm
M4 = 949 mm
Scheme 10
Scheme 11
Scheme 12
WINDSHIELD FRAME, ALIGNMENT CHART
Note. As the graphics in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the graphics is always correct.
