GENERATOR SPECIFICATIONS
| Application | Specification | |
|---|---|---|
| Generator Type | ||
| Bosch NCB1 | 14V/120A | |
| Bosch E140/8 | 14V/140A | |
| Carbon Brush Minimum Length | 0.197" (5.0 mm) | |
| Current Strength During Charging Voltage Of 13.V (1) | ||
| Engine Speed @ 680 RPM | 70A | |
| Engine Speed @ 2300 RPM | 120A | |
| Direction Of Rotation | Counterclockwise | |
| Maximum Engine Speed | 6800 RPM | |
| Rotor Winding Resistance | 2.6 Ohms | |
| Stator Winding Resistance | .06 Ohms | |
| (1) Measured at 77°F (25°C) with stabilized output voltage. | ||
| (1) | Measured at 77°F (25°C) with stabilized output voltage. |
GENERATOR SPECIFICATIONS
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) | |
|---|---|---|
| Generator Belt Pulley | ||
| Fixed Pulley | 48 (65) | |
| Freewheel | 59 (80) | |
| Generator Mounting Bolt (M8) | 18 (24) | |
| INCH Lbs. (N.m) | ||
| B+ Terminal | 133 (15) | |
| Battery Connector | 22 (2.5) | |
TORQUE SPECIFICATIONS
Note. Charging voltage (Scheme 1)is with a 25-45 amp generator load at about 2300 RPM.
