THREADS (2001-2007)

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 516

Scheme 516: Thread inserts, general

Damaged threads can in most cases be reconditioned using HELICOIL thread inserts.

Thread inserts are available in a variety of sizes, pitches and lengths. A correctly reconditioned thread will generally increase the strength of a joint.

Scheme 517

Scheme 517: Designation of thread insert

Measure the old threads and thread length in the hole.

A: Thread.

B: Thread length.

Scheme 518

Scheme 518: Drilling and tapping new thread in the hole

Drill out the old threads using the correct diameter drill bit. Blow the hole clean.

Tap the new thread using the correct tap.

Note. The thread taps referred to in the text are specially made for use with the HELI-COIL system.

Use methylated spirit or similar to lubricate the threading operation in aluminum. Thread longer threads in stages, backing out the tap and blowing the tap and the hole clean in between.

Thread the hole to the proper depth (or through if it is to be threaded throughout).

C: drill depth.

D: cutting phase.

Scheme 519

Scheme 519: Tools required for installation

The installation tool (illustrated) is used for threads M6 - M14 . During some operations the tool must be disassembled by removing the locking ring, for example with countersunk threads.

For threads M16 and larger the specific tool for each thread size must be used. The guide and mandrel are included.

Scheme 520

Scheme 520: Installing the thread insert in the installation tool

Locate the thread insert with the tang facing down in the tool.

Turn the spindle until the tang engages in the recess.

Screw the thread insert into the guide, do not apply pressure, until the first turn of the thread insert is flush with the guide opening.

A: Tang.

B: Guide.

C: Mandrel.

Scheme 521

Scheme 521: Installation of thread insert

Hold the installation tool straight above and centered over the hole. Screw in the insert without applying pressure on the spindle handle. Screw in until the end of the insert reaches at least half a thread revolution into the thread.

The insert must not touch the bottom of the hole or stick out of the other side if it is a through hole.

Break off the tang with the proper tang breaker. For M14 threads and coarser, use a pair of flat-nosed pliers or similar and break downwards.

Scheme 522

Scheme 522: Extraction of damaged thread insert

Alternative 1

File a notch in the thread insert, about a quarter turn in from the end. Do not file through the insert.

Note. Do not damage the thread in the material.

Use a triangular scraper or similar to extract the insert by rotating it.

Alternative 2

Carefully expose the end of the thread insert. Use flat-nose pliers to pull the thread insert out.

Clean out the threads in the hole using the thread tap and blow clean.

Install a new thread insert.

Reconditioning sparkplug threads

Note. Reconditioning of spark plug threads must be carried out with removed cylinder head.

Scheme 523

Scheme 523: Tapping thread in sparkplug hole

Use combination tap 998 5823-5 and thread repair inserts for spark plug thread M14x1,25 .

Note. Do not drill out spark plug threads.

Combined tap

A: Tap.

B: Reamer.

C: Steering.

Scheme 524

Scheme 524: Installation of thread insert

There are times when the cap nut cannot be used because of space restrictions. On these occasions the guide should be taped into place.

Note. As the thread insert for the spark plug thread is thinner (finer) than usual it is extra important to not pressure on the pin when inserting the thread insert (both in the nozzle and the material).

Twist the thread insert down and check that the upper thread is at least a half thread down into the thread and that none of the insert protrudes into the combustion chamber.

If the insert has been screwed in too far it must be turned until it is all the way through. If it is not deformed it can be inserted again.

Break off the tang with a pair of flat nose pliers. Check the thread. Install a sparkplug.

Thread table

Values in mm
Thread dimensionDrill - diameterExamples of areas of use
M6x16.3Oil pump
M7x17.3Sump to cylinder block, Intermediate section to cylinder block, Water pump to cylinder block
M8x1.258.4Studs at the exhaust ports
M10x1.510.5Intermediate section to cylinder block, Gearbox to engine
M12x1.512.5
M14x1.25Spark plugs
M14x1.514.2Oil pressure switch. Oil pressure outlet engine / turbocharger unit.
M18x1.518.5Oil drain plug in the sump.

Threads which must not be reconditioned

Coolant outlet for the drain nipple, heat exchanger / oil cooler.

Plug hole for crankshaft setting.

Screw holes for cylinder head screws.
