Engine - Engine Torque Control Arm: Overview Volvo V70 II рестайлинг

Scheme 530

Remove

1. the connector from the mass air flow (MAF) sensor and the turbocharger (TC) control valve.
2. the turbocharger (TC) control valve from the air cleaner (ACL) cover. Move it to one side.
3. the inlet hose between the turbocharger (TC) and the air cleaner (ACL) cover. Warm the connections to the air cleaner (ACL) cover with a hot-air gun. This will make removal easier.
4. the inlet hose between the air cleaner (ACL) housing and the front panel.
5. the air cleaner (ACL) cover from the air cleaner (ACL) housing.
6. the air cleaner (ACL) housing.

Scheme 531

Remove

1. the screw for the torque rod mounting in the torque control arm on the engine.
2. the screws at the suspension turrets.
3. the torque rod.

Scheme 532

Remove the 6 screws retaining the torque control arm.

Scheme 533

Install the new torque control arm and tighten as shown in the illustration.

Install

1. the torque rod.
2. the screws for the brackets at the suspension turrets. Tighten to 50 Nm .
3. the screw for the torque rod mounting in the bracket on the engine. Tighten to 80 Nm .
