Cooling System - Draining, Charging & Bleeding: Removal & Installation Volvo V70 II рестайлинг

Cooling System (Mechanical) 8 illustrations ~187 words

Installation

Note. For tightening torques, see Tightening torque

Scheme 224

Scheme 224: Install The EGR Components
Scheme 224: Install The EGR Components

Install

  1. The EGR module using a new gasket at the connection pipe to the exhaust manifold.
  2. the 2 M10 screws. Tighten the screws until mating.
  3. the 1 M8 screw on the rear edge of the cylinder head. Tighten.
CAUTIONDo not tighten the screws so as to prevent tension in the rear mounting.

Tighten the M10 screws in the front edge of the cylinder head.

Scheme 225

Scheme 225
Scheme 225

Install

  1. the coolant hoses from the EGR cooler
  2. the 1 screw clamp. Tighten.
  3. the 1 disposable clamp

Scheme 226

Scheme 226
Scheme 226

Fit the clamp between the EGR cooler and the connection pipe to the exhaust manifold. Tighten.

Scheme 227

Scheme 227
Scheme 227

Insert the 1 M6 screw to the brace of the fuel rail.

Scheme 228

Scheme 228
Scheme 228

Install the intake manifold.

Tighten the hose clips.

Scheme 229

Scheme 229
Scheme 229

Install

  1. the throttle body using a new gasket
  2. the 4 M6 screws of the throttle body. Tighten.

Scheme 230

Scheme 230
Scheme 230

Plug in the connector of the throttle body and EGR mixer.

Plug in the connector of the EGR cooler's bypass valve.

Scheme 231

Scheme 231
Scheme 231

Install the hose on the throttle body and tighten the hose clip.
