Automatic Transmission - External Controls: Overhaul Volvo V70 II рестайлинг

Gear selector lever assembly, reconditioning

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Removing the gear selector assembly and cables

Remove the gear selector assembly and mechanical cables. See Removing the gear selector assembly and cables .

Scheme 1550

Lubricating and installing components in the gear selector assembly

Lubricate the gear selector lever ball joints and bevel arm bushings using grease, P/N 1161241-3.

Installing cables and gear selector assembly

Install the mechanical cables and the gear selector assembly. See Installing the cables and gear selector assembly .

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Remove the gear selector assembly and cables from the XC90. See: Gearbox cables, replacing and on the S60 and V70. See: Transmission cables, replacing .

Scheme 1551

Remove

1. the catch for the bevel arm
2. bevel arm with bushing and spring
3. the cover for the gear selector lever ball joint. Pull up the ball joint, gear selector lever and rubber sleeve from the gear selector assembly
4. the solenoid.

Scheme 1552

Install a new link cap.

Lubricate the new link cap. Use grease, P/N 116 1241-3.

Lubricate the gear selector lever ball joints and bevel arm bushings. Use grease, P/N 116 1241-3.

Install

1. the rubber sleeve
2. the gear selector lever with ball joints and cover
3. the bevel arm with bushings, spring and retaining clip
4. the solenoid.

See Gear selector lever assembly, reconditioning

Note. As the illustrations in this service information are used for different model years and / or models, some variation may occur. However, the essential information in the illustrations is always correct.

Remove the gear selector assembly and mechanical cables. See Gear selector lever assembly, replacing .

Lubricate the gear selector lever ball joints and bevel arm bushings using grease, P/N 1161241-3.

Installing the cables and gear selector assembly

Install the mechanical cables and the gear selector assembly. See Gear selector lever assembly, replacing .
