Headlights - Adjustment, Washers: Other Volvo V70 II

Wiper/washer Systems 8 illustrations ~296 words

Information

The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 45

Scheme 45: Information
Scheme 45: Information

Scheme 46

Scheme 46: Removing the handset
Scheme 46: Removing the handset

Remove

  1. two screws (1)
  2. the ashtray. See «Replacing the rear ashtray»(ref-406929-S21607156532011070100000) .

Disconnect the connector.

Remove the rubber grommet.

Installing the handset

Install

  1. the rubber grommet
  2. the connector
  3. the ashtray
  4. the two screws.

Note. Ensure that the rubber grommet is in the correct position.

Handset, replacing (2005-)

Note. The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information in the illustrations is always correct.

Scheme 47

Scheme 47: Removing the ashtray
Scheme 47: Removing the ashtray

Open the ashtray so that it passes the hooks. Remove the holder for the ashtray. Press the catches down and remove the holder.

Scheme 48

Scheme 48: Removing the handset
Scheme 48: Removing the handset

Scheme 49

Scheme 49
Scheme 49

Disconnect the connector. Remove the rubber grommet.

Installing the handset and ashtray

Note. Ensure that the rubber grommet is correctly positioned.

Install

  1. the rubber grommet
  2. the connector
  3. the ashtray.

Headlamps, adjusting

Operation Number(s): 35202-2

Vehicles with high intensity discharge headlamps

Scheme 50

Scheme 50: Ensuring the vehicle is parked on a flat surface
Scheme 50: Ensuring the vehicle is parked on a flat surface

Headlight washers, replacing

Operation Number(s): 36323-2

HINT: For replacing washer motor and level sensor, see: B5244Sx / B5254Tx or Other.

Removing the headlamp and bumper cover

Remove

  1. the headlamp. See
  2. the bumper cover. See

Scheme 51

Scheme 51: Removing high-pressure washer headlamp
Scheme 51: Removing high-pressure washer headlamp

Remove

  1. the 2 screws
  2. the high-pressure washer
  3. the clips on the hose connector
  4. the hose.

Installing the high-pressure washer headlamp

Install

  1. the clips on the hose connector
  2. the hose
  3. the high-pressure washer
  4. the 2 screws.

Installing headlamp and bumper cover

Install

  1. the bumper cover. See
  2. the headlamp. See

Scheme 52

Scheme 52: Adjusting nozzle
Scheme 52: Adjusting nozzle

Test the function.

Adjust the alignment of the nozzle as necessary as illustrated above. The cover must be against the bumper cover without any play.
