Ignition and Control Systems - Component Location: Component Locations Volvo V70 II

Fuel System 1 illustration

Location of components

See Location of components

Location of components, engine compartment

See Location of components, engine compartment

Scheme 203

Scheme 203: Location of components, engine compartment

Not all the following components are necessarily in the car. The components vary between engine types.

ComponentRemarks
1Engine coolant temperature (ECT) sensor
2Ground terminal
3Coolant level sensor
4Reset valve, camshaftExhaust and intake camshafts.
5Turbocharger (TC) control valveOnly turbocharged (TC) engines
6Camshaft sensorExhaust and intake camshafts.
7Brake pedal sensor
8Engine speed (RPM) sensor
9Outer temperature sensor
10Power supply terminal
11Fusebox
12Relay box
13Mass air flow (MAF) sensor
14Ignition coil
15Canister purge (CP) valve
16Boost pressure sensorThe intake air temperature (IAT) sensor is integrated in the boost pressure sensor
17Fuel pressure sensorThe fuel temperature sensor is integrated in the fuel pressure sensor
18Injector
19Oil level sensorLocated in the oil trough
20Engine cooling fan (FC) control module
21Throttle unitAlso includes the throttle position (TP) sensor
22A/C pressure sensor
23Knock sensor (KS)
24Engine control unit
25Engine cooling fan (FC) control modules
