Climate control module (CCM), replacing
The illustrations in this service information are used for different model years and/or models. Some variation may occur. However, the essential information is always correct.
Scheme 777
Note. Read off the programmed data from the climate control module (CCM) before it is replaced. This is carried out via VIDA vehicle communication. The parameters for the climate control module (CCM) must be programmed after the module is replaced.
Move the gear selector / gear selector lever as far back as possible.
Ignition off.
Remove the key. The key must be removed to ensure that the ignition is not switched on by mistake.
| WARNING | After the key has been removed wait three minutes before starting work. |
Scheme 778
Detach the panel at the gear selector lever as illustrated.
Turn the panel so that it is as far away from the center console as possible.
Scheme 779
Remove the frame by pressing in the 4 catches. See the illustration.
Scheme 780
Remove the 2 x lower screws from the bracket.
Angle out the entire infotainment control module (ICM) and the dashboard environment panel as illustrated.
| CAUTION | Do not damage any surfaces. |
Disconnect the connectors.
Scheme 781
Turn the infotainment control module (ICM) and dashboard environment panel upside down.
Remove the 3 x screws on the top. See the illustration.
Scheme 782
Remove the trim panel by releasing the 6 x catches. See the illustration. Pry the catches outwards to release them.
Scheme 783
Remove
the 4 x screws
the climate control module (CCM).
