Signal Specification, RTI
See Signal Specification, RTI.
Signal Specification, Rear Seat Entertainment Module (RSE), Generation 4.1
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse width modulated signal as a % |
Damaged rear seat entertainment module (RSE).
Scheme 7
Scheme 8
| Terminal | Signal Type | Ignition On | Miscellaneous |
|---|---|---|---|
| #A1 | |||
| #A2 | |||
| #A3 | |||
| #A4 | Power supply to control module | U=U high | Direct from battery via fuse. |
| #A5 | |||
| #A6 | Power supply to control module | U=U high | Via Central electronic module (CEM). For lighting in buttons. |
| #A7 | Power supply to control module | U=U high | Via Central electronic module (CEM). Indication of ignition on. |
| #A8 | Ground terminal | U=U low |
SIGNAL TABLE
Scheme 9
| Terminal | Signal Type | Ignition On | Miscellaneous |
|---|---|---|---|
| #D1 | |||
| #D2 | Direct current (DC) voltage (out) | 7-9 V at activation of rear audio separation module (RAS). | |
| #D3 | Ground terminal | U=U low | Ground for audio signal from rear audio separation module (RAS). |
| #D4 | Audio signal (in) | Left audio channel (+), RCA-switch. Alternating current (AC) voltage during signal. | |
| #D5 | |||
| #D6 | |||
| #D7 | Video signal (in) | Input signal from video terminal (+) on AUX panel. Analog signal. | |
| #D8 | |||
| #D9 | Internal CAN (+) | U= 2.5-2.8 V | Connected to terminal #D10. |
| #D10 | Internal CAN (+) | U= 2.5-2.8 V | Connected to terminal #D9. |
| #D11 | |||
| #D12 | Audio signal (out) | Signal to wire headsets via AUX panel. Left audio signal headset socket 1. | |
| #D13 | Audio signal (out) | Signal to wire headsets via AUX panel. Right audio signal headset socket 1. | |
| #D14 | Ground terminal | U=U low | Ground terminal wire headsets via AUX panel. Headset socket 1. |
| #D15 | |||
| #D16 | Audio signal. (out) | Output signal to rear audio separation (RAS). Right audio signal. | |
| #D17 | Audio signal (out) | Output signal to rear audio separation (RAS). Left audio signal. | |
| #D18 | Audio signal (in) | Input signal from AUX panel. Right audio channel (+), RCA switch. Alternating current (AC) voltage during signal. | |
| #D19 | Ground terminal | U=U low | Ground terminal for audio inputs on AUX panel. |
| #D20 | |||
| #D21 | Video signal. (in) | Input signal from video terminal (-) on AUX panel. Analog signal. | |
| #D22 | |||
| #D23 | Internal CAN (-) | U= 2.5-2.8 V | Connected to terminal #D24. |
| #D24 | Internal CAN (-) | U= 2.5-2.8 V | Connected to terminal #D23. |
| #D25 | |||
| #D26 | Ground terminal | U=U low | Ground terminal wire headsets via AUX panel. Headset socket 2. |
| #D27 | Audio signal (out) | Signal to wire headsets via AUX panel. Left audio signal headset socket 2. | |
| #D28 | Audio signal (out) | Signal to wire headsets via AUX panel. Right audio signal headset socket 2. |
SIGNAL TABLE
Scheme 10
| Terminal | Signal Type | Ignition On | Miscellaneous |
|---|---|---|---|
| #E1 | Power supply | 12 V | To left display screen terminal #2. |
| #E2 | Wake-up signal | Approximately 11-11.5 V | To left screen terminal #3. Upon start-up of the system and when there are communication faults with the screen, the voltages switches between 0 V and 11-11.5 V, 3 times. |
| #E3 | CAN signal (+) | U= 2.5-2.8 V | Internal CAN network between control module and display screens. Left display screen terminal #4. |
| #E4 | CAN signal (-) | U= 2.5-2.8 V | Internal CAN network between control module and display screens. Left display screen terminal #5. |
| #E5 | IR control signal for system (in) | U=approx. 4 V when no IR signal received | From left screen terminal #12. Lowers upon signal receipt. |
| #E6 | Ground terminal | U=U low | For audio signal to left display screen #11. |
| #E7 | Audio signal (out) | Analog signal | To left display screen terminal #9. Left audio channel. |
| #E8 | Audio signal (out) | Analog signal | To left display screen terminal #10. Right audio channel. |
| #E9 | |||
| #E10 | Video signal (out) | Analog signal | To left display screen terminal #8. Video (+). |
| #E11 | Video signal (out) | Analog signal | To left display screen terminal #7. Video (-). |
| #E12 | Ground terminal | U=U low | To left display screen terminal #1. |
| #E13 | Power supply. | 12 V | To right display screen terminal #2. |
| #E14 | Wake-up signal | Approximately 11-11.5 V | To right screen terminal #3. Upon start-up of the system and when there are communication faults with the screen, the voltages switches between 0 V and 11-11.5 V, 3 times. |
| #E15 | CAN signal (+) | U= 2.5-2.8 V | Internal CAN network between control module and display screens. Right display screen terminal #4. |
| #E16 | CAN signal (-) | U= 2.5-2.8 V | Internal CAN network between control module and display screens. Right display screen terminal #5. |
| #E17 | IR control signal for system (in) | U=approx. 4 V when no IR signal received | From right screen terminal #12. Lowers upon signal receipt. |
| #E18 | Ground terminal | U=U low | For audio signal to right display screen terminal #11. |
| #E19 | Audio signal (out) | Analog signal | To right display screen terminal #10. Left audio channel. |
| #E20 | Audio signal (out) | Analog signal | To right display screen terminal #9. Right audio channel. |
| #E21 | |||
| #E22 | Video signal (out) | Analog signal | To right display screen terminal #8. Video (+). |
| #E23 | Video signal (out) | Analog signal | To right display screen terminal #7. Video (-). |
| #E24 | Ground terminal | U=U low | To right display screen terminal #1. |
SIGNAL TABLE
Signal Specification, Rear Audio Separation
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse width modulated signal as a % |
Scheme 11
| Terminal | Signal type | Ignition On | Other |
|---|---|---|---|
| #A1 | Battery voltage supply | U bat | |
| #A2 | Switch signal for reverse warning | Connects audio from the reverse warning system to the rear speakers when reverse gear is engaged. | |
| #A3 | Left audio (in) | From DVD player. | |
| #A4 | Audio ground | For audio signal from DVD player. Internally connected to terminal #12 | |
| #A5 | Loudspeaker signal left-hand (L+) (out) | Rear speakers, high level audio. | |
| #A6 | Loudspeaker signal left-hand (L-) (out) | U=U low | Rear speakers, high level audio. |
| #A7 | Loudspeaker signal right-hand (R-) (out) | U=U low | Rear speakers, high level audio. |
| #A8 | Loudspeaker signal right-hand (R+-) (out) | Rear speakers, high level audio. | |
| #A9 | Ground terminal control module | U=U low | |
| #A10 | Activation signal for rear audio separation (RAS) | Approx. 7-9 V when function is activated. | Connecting function. From Rear seat entertainment module (RSE). |
| #A11 | Right audio (in) | From DVD player. | |
| #A12 | Audio ground | For audio signal from DVD player. Is internally connected to terminal #4. | |
| #A13 | Incoming loudspeaker sound (L+) | Input signal from the front audio system. | |
| #A14 | Incoming loudspeaker sound (L-) | Input signal from the front audio system. | |
| #A15 | Incoming loudspeaker sound (R-) | Input signal from the front audio system. | |
| #A16 | Incoming loudspeaker audio (R+) | Input signal from the front audio system. |
SIGNAL TABLE
Capacity of The Emergency Battery (Volvo On Call/Volvo On Call Plus)
This parameter indicates the remaining capacity of the internal emergency battery. The emergency battery is only available for phone modules (PHM) with Volvo On Call/Volvo On Call Plus functionality.
The emergency battery is only used when activating the Volvo On Call/Volvo On Call Plus service and if there is no power supply.
The remaining capacity is calculated by the phone module (PHM).
Measurement range 0-100%.
100% is full capacity.
The diagnostic trouble code (DTC) stores a diagnostic trouble code (DTC) when the capacity drops to 30%.
- 0% corresponds to 0 minutes call time
- 10% corresponds to approximately 5 minutes call time
- 20% corresponds to approximately 10 minutes call time
- 30% corresponds to approximately 15 minutes call time
- 40-50% corresponds to approximately 20 minutes call time
- 60% corresponds to approximately 30 minutes call time
- 70-100% corresponds to more than 30 minutes call time.
Signal Specification
General
All the values given below are between the terminals stated in column 1 and terminal #1 in column 2 (signal ground). This applies unless otherwise indicated in brackets.
Note. It is important to connect the breakout box and check the ground terminals before taking readings.
| U= | DC voltage in volts (V) | U AC = | AC voltage in volts (V) |
|---|---|---|---|
| U bat = | Battery voltage (V) | F = | Frequency in Hertz (Hz) |
| U low = | Voltage approximately 0 V | T = | Time in seconds |
| PWM = | Pulse width modulated signal as a % |
Scheme 12
| Control module terminal | Signal Type | Ignition On | Idle | Other |
|---|---|---|---|---|
| #1 | Ground | U low | ||
| #2 | 30 supply In the XC90 and S40 (04-) the handsfree box is powered via the infotainment relay. | U bat | ||
| #3 | ||||
| #4 | Loudspeaker signal (+) | Alternating current when there is sound in the loudspeaker | ||
| #5 | 15 supply | U=12 V | ||
| #6 | Radio mute signal | During a call U=U low U=12 V otherwise | ||
| #7 | Loudspeaker signal (-) | Alternating current when there is sound in the loudspeaker | ||
| #8 |
Connector Handsfree Box
Scheme 13
| Control module terminal | Signal Type | Ignition On | Idle | Other |
|---|---|---|---|---|
| #1 | Handsfree antenna | Handsfree antenna signal | ||
| #2 | Antenna ground | U low |
Antenna connector
Scheme 14
| Control module terminal | Signal type | Ignition on | Idle | Other |
|---|---|---|---|---|
| #1 | Microphone | Alternating current when there is sound in the microphone | ||
| #2 | Signal ground, microphone | U low |
Microphone connector
See also:
• Checking the ground terminals
