Aem, Auu, and Cem Module - Component Location: Overview Volvo V50 I рестайлинг

Body Electrical 11 illustrations ~305 words

Scheme 406

Scheme 406: LOCATION OF COMPONENTS
Scheme 406: LOCATION OF COMPONENTS
  1. Accessory electronic module (AEM).

Scheme 407

Scheme 407: COMPONENT LOCATION
Scheme 407: COMPONENT LOCATION

Overview

  1. Accessory USB unit (AUU)

Scheme 408

Scheme 408: LOCATION OF COMPONENTS
Scheme 408: LOCATION OF COMPONENTS

central electronic module (CEM)

  1. central electronic module (CEM)

Scheme 409

Scheme 409
Scheme 409

Secondary Battery

  1. Secondary battery (only on vehicles with the function Automatic start/stop of engine).

Scheme 410

Scheme 410
Scheme 410

Lighting exterior, front

  1. Low beam
  2. High beam
  3. Parking lamps
  4. Turn signal lamps
  5. Side marking
  6. Turn signal lamp door mirror
  7. Local lighting
  8. Fog lamps

Scheme 411

Scheme 411
Scheme 411

Lighting exterior, rear

  1. Stop lamps
  2. Tail lamps
  3. Turn signal lamps
  4. Back-up (reversing) lamps
  5. Fog tail lamps
  6. License plate lighting
  7. High level stop lamp.

Scheme 412

Scheme 412
Scheme 412

Inner lighting

  1. Front interior lighting
  2. Rear interior lighting
  3. Lighting glove compartment
  4. Courtesy lighting left
  5. Courtesy lighting right.

Scheme 413

Scheme 413
Scheme 413

Warning and indicator lamps

  1. Seat belt reminder
  2. PAD lamp
  3. PAE lamp (2008-)
  4. MIL lamp
  5. Alarm diode
  6. Indication reduced alarm
  7. Indicator lamp hazard warning signal flashers
  8. Indicator lamp fog lamp front
  9. Indicator lamp fog lamp rear.

Scheme 414

Scheme 414
Scheme 414

Sensors

  1. Battery temperature (removed from and including structure week 200605)
  2. Outside temperature
  3. Fuel level
  4. Clutch pedal
  5. Accelerator pedal (AP) position sensor
  6. Twilight sensor
  7. Sun sensor
  8. Position sensor GDL front
  9. Position sensor GDL rear.
  10. Humidity sensor (HUS) (2008-)

Scheme 415

Scheme 415
Scheme 415

LIN nodes

  1. Wiper motor module (WMM)
  2. Rain sensor module (RSM)
  3. Gas discharge lamp module (GDL), left (does not apply to V50, 2008-)
  4. Gas discharge lamp module (GDL), right (does not apply to V50, 2008-)
  5. Siren control module (SCM)
  6. Remote Receiver Module (RRX)
  7. Remote Keyless Entry (RKE)
  8. Steering column lock module (SCL)
  9. Start control module (SCU)
  10. Battery monitoring sensor (only on vehicles with the function brake energy regeneration)

Scheme 416

Scheme 416
Scheme 416

Alarm components

  1. Siren control module (SCM)
  2. Alarm diode
  3. Mass movement sensor module (MMS)
  4. Ajar position sensor, left front
  5. Ajar position sensor, right front
  6. Ajar position sensor, left rear
  7. Ajar position sensor, right rear
  8. Switch hood
  9. Switch trunk lid/tailgate
  10. Switch reduced alarm.
