General Information - Design and Function: Component Locations Volvo S80 I

Location of components

The graphic shows the approximate location of the network modules. Modules A-E are slave modules while the others are master modules. The slave modules communicate through a master module using serial communication.

There may be more slave modules depending on the equipment level.

1. ABS: Anti-lock Braking System
2. AUM: Audio Module (Audio/radio module)
3. CCM: Climate Control Module
4. CEM: Central Electronic Module
5. DDM: Drivers Door Module
6. DIM: Driver Information Module
7. ECM: Engine Control Module
8. ETM: Electronic Throttle Module
9. PDM: Passenger Door Module
10. PHM: Phone Module
11. PSM: Power Seat Module
12. REM: Rear Electronic Module
13. RTI: Road Traffic Information
14. SRM: Sun Roof Module
15. SRS: Supplemental Restraint System
16. SWM: Steering Wheel Module
17. TCM: Transmission Control Module
18. UEM: Upper Electronic Module
19. A: Siren Control Module SCM
20. B: Inclination Sensor Module (ISM)
21. C: Light Switch Module
22. D: Roof Control Module (RCM)
23. E: Gear Selector Module (GSM)

Scheme 12

Previously each function had its own Control module, for example cruise control, alarm, turn signal lamps, rear demist and so on. On the P2X a function can be split between a number of modules, each of which has a particular task within the overall function. It is also possible to introduce more logic functions without needing more cables, connections and switches.

1. SRS
2. Door control
3. Light control
4. Control lever, left
5. Control lever, right
6. Combined instrument panel
7. Carphone panel
8. RTI unit
9. Roof lighting (upper electronic module)
10. Audio unit
11. Climate control
12. Button control (x7)
13. Geartronic gear selector lever housing
