Restraint System - Specifications, Electrical/electronic Volvo S60 I рестайлинг

Passive Restraints 2 illustrations ~313 words

Signal specification

General

All values specified below are between the relevant terminal and terminal #9 (power ground).

U=DC voltage in volts (V)
U bat =Battery voltage (V)
U low =Voltage approximately 0 V

Scheme 37

Scheme 37
Scheme 37
Terminal numberConnector markingSignal typeIgnition offIgnition onOther
#1F
#2GPower supply, occupant weight sensor (OWS)U bat for approximately 1 minute after the ignition key is moved to position 0 (applies only if the driver's door and front passenger door are closed). U bat for approximately 5 minutes (applies if the driver's or front passenger door are opened and left open). Otherwise U low .U bat
#3HSignal ground, pressure sensorU lowU low
#4JPower supply, pressure sensor4.8-5.2 V for approximately 1 minute after the ignition key is moved to position 0 (applies only if the driver's door and front passenger door are closed). 4.8-5.2 V for approximately 5 minutes (applies if the driver's or front passenger door are opened and left open). Otherwise U low .4.8-5.2 V
#5KSignal, pressure sensor
#6ASignal, seat belt force sensor
#7BVoltage supply, seat belt force sensor4.8-5.2 V for approximately 1 minute after the ignition key is moved to position 0 (applies only if the driver's door and front passenger door are closed). 4.8-5.2 V for approximately 5 minutes (applies if the driver's or front passenger door are opened and left open). Otherwise U low .4.8-5.2 V
#8CSignal ground, seat belt force sensorU lowU low
#9DPower ground, occupant weight sensor (OWS)U lowU low
#10ELIN busDuring communication the voltage is 0-U bat V.

Table of signals, 10-pin connector

Scheme 38

Scheme 38: Signal specification (S60, V70 2000-, V70 XC 2001-/XC70 -2004)
Scheme 38: Signal specification (S60, V70 2000-, V70 XC 2001-/XC70 -2004)

Note. It is important to connect the breakout box and check the ground terminals before taking readings.

Two breakout boxes are required to take readings from the SRS control module.

Note. The terminals for connector C are split between breakout boxes 1 and 2. From model year 2003, the connectors are numbered 1-84.

  1. Terminals #1A-#28A correspond to terminals #1-#28
  2. Terminals #1B-#28B correspond to terminals #29-#56
  3. #1C-#28C correspond to #57-#84
Breakout boxControl module terminal -02Control module terminal 03FunctionOther
1#1A#1Signal ground
2#2A#2Signal ground
3#3A#3Front left side impact protection (SIPS) bag (-)Monitoring signal at normal status. Ignition pulse on deployment.
4#4A#4Front left side impact protection (SIPS) bag (+)Monitoring signal at normal status. Ignition pulse on deployment.
5#5A#5Belt tensioner, front left (+)Monitoring signal at normal status. Ignition pulse on deployment.
6#6A#6Belt tensioner, front left (-)Monitoring signal at normal status. Ignition pulse on deployment.
7#7A#7
8#8A#8Side impact sensor, front left
9#9A#9Side impact sensor, front left
10#10A#10
11#11A#11
12#12A#12
13#13A#13
14#14A#14
15#15A#15Rear left seat belt tensioner (-)Monitoring signal at normal status. Ignition pulse on deployment.
16#16A#16Belt tensioner, rear left (+)Monitoring signal at normal status. Ignition pulse on deployment.
17#17A#17
18#18A#18
19#19A#19
20#20A#20
21#21A#21Left inflatable curtain (+)Monitoring signal at normal status. Ignition pulse on deployment.
22#22A#22Left inflatable curtain (-)Monitoring signal at normal status. Ignition pulse on deployment.
23#23A#23
24#24A#24
25#25A#25
26#26A#26
27#27A#27Side impact sensor, rear left
28#28A#28Side impact sensor, rear left
29#1B#29
30#2B#30Collision signalSignal to the central electronic module (CEM)
31#3B#31
32#4B#32SRS warning lampActivated
33#5B#33SRS warning lampDeactivated
34#6B#34Switch (+)
35#7B#35Driver airbag, stage 1 (-)Monitoring signal at normal status. Ignition pulse on deployment.
36#8B#36Driver airbag, stage 1 (+)Monitoring signal at normal status. Ignition pulse on deployment.
37#9B#37Driver's airbag stage 2 (+)Monitoring signal at normal status. Ignition pulse on deployment.
38#10B#38Driver airbag, stage 2 (-)Monitoring signal at normal status. Ignition pulse on deployment.
39#11B#39Passenger airbag, stage 1 (-)Monitoring signal at normal status. Ignition pulse on deployment.
40#12B#40Passenger airbag, stage 1 (+)Monitoring signal at normal status. Ignition pulse on deployment.
41#13B#41Passenger airbag, stage 2 (+)Monitoring signal at normal status. Ignition pulse on deployment.
42#14B#42Passenger airbag, stage 2 (-)Monitoring signal at normal status. Ignition pulse on deployment.
43#15B#43Switch (-)
44#16B#44
45#17B#45
46#18B#46
47#19B#47
48#20B#48
49#21B#49
50#22B#50
51#23B#51Control modules communication cable (CAN H)U=2.5-3.5 V
52#24B#52Control modules communication cable (CAN H)U=2.5-3.5 V
53#25B#53Communication cable, control modules (CAN L)U=1.5-2.5 V
54#26B#54Communication cable, control modules (CAN L)U=1.5-2.5 V
55#27B#55X-feed voltage from the ignition switch (ignition switch pos. I and II)Battery voltage approx. 12 V
56#28B#5615-supply voltage (ignition switch pos. II and III)Battery voltage approx. 12 V
57#1C#57
58#2C#58
59#3C#59Side airbag, front right (-)Monitoring signal at normal status. Ignition pulse on deployment.
60#4C#60Side airbag, front right (+)Monitoring signal at normal status. Ignition pulse on deployment.

Breakout box 1

Breakout boxControl module terminal -02Control module terminal 03FunctionOther
1#5C#61Belt tensioner, front right (+)Monitoring signal at normal status. Ignition pulse on deployment.
2#6C#62Front right seat belt tensioner (-)
3#7C#63
4#8C#64Side impact sensor, right front
5#9C#65Side impact sensor, right front
6#10C#66
7#11C#67
8#12C#68
9#13C#69
10#14C#70
11#15C#71Rear right seat belt tensioner (-)Monitoring signal at normal status. Ignition pulse on deployment.
12#16C#72Rear right seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
13#17C#73
14#18C#74
15#19C#75
16#20C#76
17#21C#77Right inflatable curtain (+)Monitoring signal at normal status. Ignition pulse on deployment.
18#22C#78Right inflatable curtain (-)Monitoring signal at normal status. Ignition pulse on deployment.
19#23C#79Belt tensioner, rear center (-)Monitoring signal at normal status. Ignition pulse on deployment.
20#24C#80Rear center seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
21#25C#81
22#26C#82
23#27C#83Side impact sensor, right rear
24#28C#84Side impact sensor, right rear

Breakout box 2

Signal specification (S60, S80, V70 2000-, V70 XC 2001-/XC70, XC90 2005-)

Note. It is important to connect the breakout box and check the ground terminals before taking readings.

Two breakout boxes are required to take readings from the SRS control module.

Note. The terminals for connector C are split between breakout boxes 1 and 2. From model year 2003, the connectors are numbered 1-84.

  1. Terminals #1A-#28A correspond to terminals #1-#28
  2. Terminals #1B-#28B correspond to terminals #29-#56
  3. #1C-#28C correspond to #57-#84
Breakout boxControl module terminal -02Control module terminal 03FunctionOther
1#1A#1Signal ground
2#2A#2Signal ground
3#3A#3Front left side impact protection (SIPS) bag (-)Monitoring signal at normal status. Ignition pulse on deployment.
4#4A#4Front left side impact protection (SIPS) bag (+)Monitoring signal at normal status. Ignition pulse on deployment.
5#5A#5Belt tensioner, front left (+)Monitoring signal at normal status. Ignition pulse on deployment.
6#6A#6Belt tensioner, front left (-)Monitoring signal at normal status. Ignition pulse on deployment.
7#7A#7
8#8A#8Side impact sensor, front left
9#9A#9Side impact sensor, front left
10#10A#10
11#11A#11
12#12A#12
13#13A#13
14#14A#14
15#15A#15Rear left seat belt tensioner (-)Monitoring signal at normal status. Ignition pulse on deployment.
16#16A#16Belt tensioner, rear left (+)Monitoring signal at normal status. Ignition pulse on deployment.
17#17A#17
18#18A#18
19#19A#19
20#20A#20
21#21A#21Left inflatable curtain (+)Monitoring signal at normal status. Ignition pulse on deployment.
22#22A#22Left inflatable curtain (-)Monitoring signal at normal status. Ignition pulse on deployment.
23#23A#23
24#24A#24
25#25A#25
26#26A#26
27#27A#27Side impact sensor, rear left
28#28A#28Side impact sensor, rear left
29#1B#29
30#2B#30Collision signalSignal to the central electronic module (CEM)
31#3B#31
32#4B#32SRS warning lampActivated
33#5B#33SRS warning lampDeactivated
34#6B#34Switch (+)
35#7B#35Driver airbag, stage 1 (-)Monitoring signal at normal status. Ignition pulse on deployment.
36#8B#36Driver airbag, stage 1 (+)Monitoring signal at normal status. Ignition pulse on deployment.
37#9B#37Driver's airbag stage 2 (+)Monitoring signal at normal status. Ignition pulse on deployment.
38#10B#38Driver airbag, stage 2 (-)Monitoring signal at normal status. Ignition pulse on deployment.
39#11B#39Passenger airbag, stage 1 (-)Monitoring signal at normal status. Ignition pulse on deployment.
40#12B#40Passenger airbag, stage 1 (+)Monitoring signal at normal status. Ignition pulse on deployment.
41#13B#41Passenger airbag, stage 2 (+)Monitoring signal at normal status. Ignition pulse on deployment.
42#14B#42Passenger airbag, stage 2 (-)Monitoring signal at normal status. Ignition pulse on deployment.
43#15B#43Switch (-)
44#16B#44
45#17B#45
46#18B#46
47#19B#47
48#20B#48
49#21B#49
50#22B#50
51#23B#51Control modules communication cable (CAN H)U=2.5-3.5 V
52#24B#52Control modules communication cable (CAN H)U=2.5-3.5 V
53#25B#53Communication cable, control modules (CAN L)U=1.5-2.5 V
54#26B#54Communication cable, control modules (CAN L)U=1.5-2.5 V
55#27B#55X-feed voltage from the ignition switch (ignition switch pos. I and II)Battery voltage approx. 12 V
56#28B#5615-supply voltage (ignition switch pos. II and III)Battery voltage approx. 12 V
57#1C#57
58#2C#58
59#3C#59Side airbag, front right (-)Monitoring signal at normal status. Ignition pulse on deployment.
60#4C#60Side airbag, front right (+)Monitoring signal at normal status. Ignition pulse on deployment.

Breakout box 1

Breakout boxControl module terminal -02Control module terminal 03FunctionOther
1#5C#61Belt tensioner, front right (+)Monitoring signal at normal status. Ignition pulse on deployment.
2#6C#62Front right seat belt tensioner (-)
3#7C#63
4#8C#64Side impact sensor, right front
5#9C#65Side impact sensor, right front
6#10C#66
7#11C#67
8#12C#68
9#13C#69
10#14C#70
11#15C#71Rear right seat belt tensioner (-)Monitoring signal at normal status. Ignition pulse on deployment.
12#16C#72Rear right seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
13#17C#73
14#18C#74
15#19C#75
16#20C#76
17#21C#77Right inflatable curtain (+)Monitoring signal at normal status. Ignition pulse on deployment.
18#22C#78Right inflatable curtain (-)Monitoring signal at normal status. Ignition pulse on deployment.
19#23C#79Belt tensioner, rear center (-)Monitoring signal at normal status. Ignition pulse on deployment.
20#24C#80Rear center seat belt tensioner (+)Monitoring signal at normal status. Ignition pulse on deployment.
21#25C#81
22#26C#82
23#27C#83Side impact sensor, right rear
24#28C#84Side impact sensor, right rear

Breakout box 2

General

All values given below are between the terminals stated in column 2 and the ground terminal on the body for the control module.

Note. It is important to connect the breakout box and check the ground terminals before taking readings. The adapter has two terminals for the breakout box. The signals in the 84-pin connector are split between adapter terminals A and B. For some VIDA fault-tracing, the connectors are numbered #1A-#28A, #1B-#28B and #1C-#28C. This is because fault-tracing is used from previous model years. From and including model year 2003, the connectors are numbered #1-#84.

  1. Terminals #1A-#28A correspond to terminals #1-#28
  2. Terminals #1B-#28B correspond to terminals #29-#56
  3. Terminals #1C-#28C correspond to terminals #57-#84.
U=DC voltage in volts (V)
U bat =Battery voltage (V)
U low =Voltage approximately 0 V
Terminal control module -02Terminal control module 03Breakout box terminalSignal typeIgnition onOther
#1A#1#1
#2A#2#2
#3A#3#3Front left side impact protection (SIPS) bag (-)Monitoring signal at normal position. Ignition pulse on activation.
#4A#4#4Front left side impact protection (SIPS) bag (+)Monitoring signal at normal position. Ignition pulse on activation.
#5A#5#5Front left seat belt tensioner (+)Monitoring signal at normal position. Ignition pulse on activation.
#6A#6#6Front left seat belt tensioner (-)Monitoring signal at normal position. Ignition pulse on activation.
#7A#7#7Signal groundU low
#8A#8#8Side impact sensor, left front (-)
#9A#9#9Side impact sensor, left front (+)
#10A#10#10
#11A#11#11Seat belt tensioner 3rd row left (-) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#12A#12#12Seat belt tensioner 3rd row left (+) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#13A#13#13Inflatable curtain left rear (-) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#14A#14#14Inflatable curtain left rear (+) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#15A#15#15Rear left seat belt tensioner (-)Monitoring signal at normal position. Ignition pulse on activation.
#16A#16#16Rear left seat belt tensioner (+)Monitoring signal at normal position. Ignition pulse on activation.
#17A#17#17
#18A#18#18
#19A#19#19
#20A#20#20
#21A#21#21Left inflatable curtain (+)Monitoring signal at normal position. Ignition pulse on activation.
#22A#22#22Left inflatable curtain (-)Monitoring signal at normal position. Ignition pulse on activation.
#23A#23#23
#24A#24#24
#25A#25#25Seat belt buckle left front (+)
#26A#26#26Seat belt buckle left front (-)
#27A#27#27Side impact sensor, left rear (-)
#28A#28#28Side impact sensor, left rear (+)
#1B#29#29Passenger airbag, stage 3 (-) (Only XC90 USA/CDN)Monitoring signal at normal position. Ignition pulse on activation.
#2B#30#30CollisionSignal to CEM and PHM
#3B#31#31Diagnostic production
#4B#32#32Passenger airbag, stage 3 (+) (Only XC90 USA/CDN)Monitoring signal at normal position. Ignition pulse on activation.
#5B#33#33Driver airbag, stage 3 (+) (Only XC90 USA/CDN)Monitoring signal at normal position. Ignition pulse on activation.
#6B#34#34Driver airbag, stage 3 (-) (Only XC90 USA/CDN)Monitoring signal at normal position. Ignition pulse on activation.
#7B#35#35Driver airbag, stage 1 (-)Monitoring signal at normal position. Ignition pulse on activation.
#8B#36#36Driver airbag, stage 1 (+)Monitoring signal at normal position. Ignition pulse on activation.
#9B#37#37Driver airbag, stage 2 (+)Monitoring signal at normal position. Ignition pulse on activation.
#10B#38#38Driver airbag, stage 2 (-)Monitoring signal at normal position. Ignition pulse on activation.
#11B#39#39Passenger airbag, stage 1 (-)Monitoring signal at normal position. Ignition pulse on activation.
#12B#40#40Passenger airbag, stage 1 (+)Monitoring signal at normal position. Ignition pulse on activation.
#13B#41#41Passenger airbag, stage 2 (+)Monitoring signal at normal position. Ignition pulse on activation.
#14B#42#42Passenger airbag, stage 2 (-)Monitoring signal at normal position. Ignition pulse on activation.
#15B#43#43Adaptive steering column (-) (Only XC90 USA/CDN)Monitoring signal at normal position. Ignition pulse on activation.
#16B#44#44Adaptive steering column (+) (Only XC90 USA/CDN)Monitoring signal at normal position. Ignition pulse on activation.
#17B#45#45Switch for airbag, front passenger, sensor A (Not USA/CDN)
#18B#46#46Front impact sensor left front (-) (Only V70/XC70 USA/CDN and XC90)
#19B#47#47Front collision sensor left front (+) (Only V70/XC70 USA/CDN and XC90)
#20B#48#48Front impact sensor right front (+) (Only V70/XC70 USA/CDN and XC90)
#21B#49#49Front impact sensor right front (-) (Only V70/XC70 USA/CDN and XC90)
#22B#50#50Switch for airbag, front passenger, sensor B (Not USA/CDN)
#23B#51#51CAN HDuring communication the voltage is 2.5-4.0 V.
#24B#52#52CAN HDuring communication the voltage is 2.5-4.0 V.
#25B#53#53CAN LDuring communication the voltage is 1.0-2.5 V.
#26B#54#54CAN LDuring communication the voltage is 1.0-2.5 V.
#27B#55#55X-supplyU batIgnition position I and II.
#28B#56#5615 supplyU batIgnition position II and III.
#1C#57#57LIN bus. (Only V70/XC70/XC90 USA/CDN)During communication the voltage is 0-U bat V.
#2C#58#58
#3C#59#59Front right side impact protection (SIPS) bag (-)Monitoring signal at normal position. Ignition pulse on activation.
#4C#60#60Front right side impact protection (SIPS) bag (+)Monitoring signal at normal position. Ignition pulse on activation.

Adapter terminal A

Terminal control module -02Terminal control module 03Breakout box terminalSignal typeIgnition onOther
#5C#61#1Front right seat belt tensioner (+)Monitoring signal at normal position. Ignition pulse on activation.
#6C#62#2Front right seat belt tensioner (-)Monitoring signal at normal position. Ignition pulse on activation.
#7C#63#3Signal groundU low
#8C#64#4Side impact sensor, right front (-)
#9C#65#5Side impact sensor, right front (+)
#10C#66#6
#11C#67#7Inflatable curtain right rear (+) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#12C#68#8Inflatable curtain right rear (-) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#13C#69#9Seat belt tensioner 3rd row right (+) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#14C#70#10Seat belt tensioner 3rd row right (-) (Only XC90 7 seater)Monitoring signal at normal position. Ignition pulse on activation.
#15C#71#11Rear right seat belt tensioner (-)Monitoring signal at normal position. Ignition pulse on activation.
#16C#72#12Rear right seat belt tensioner (+)Monitoring signal at normal position. Ignition pulse on activation.
#17C#73#13
#18C#74#14
#19C#75#15
#20C#76#16
#21C#77#17Right inflatable curtain (+)Monitoring signal at normal position. Ignition pulse on activation.
#22C#78#18Right inflatable curtain (-)Monitoring signal at normal position. Ignition pulse on activation.
#23C#79#19Rear center seat belt tensioner (-)Monitoring signal at normal position. Ignition pulse on activation.
#24C#80#20Rear center seat belt tensioner (+)Monitoring signal at normal position. Ignition pulse on activation.
#25C#81#21Seat belt buckle right front (+)
#26C#82#22Seat belt buckle right front (-)
#27C#83#23Side impact sensor, right rear (-)
#28C#84#24Side impact sensor, right rear (+)

Adapter terminal B
