INSTALLATION
Install cylinder head. See CYLINDER HEAD
REMOVAL
Remove the cylinder head. See CYLINDER HEAD
Install cylinder head. See CYLINDER HEAD
Install timing belt. See TIMING BELT
Remove timing belt. See TIMING BELT
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Torque: M7
17 Nm
Scheme 179
Note. Make sure that the classification of the components correspond with each other.
See information about engine. See ENGINE
Scheme 180
Note. Make sure that the classification of the components correspond with each other.
See information about engine. See ENGINE
Scheme 181
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Scheme 182
| CAUTION | Take extra care when handling the components. |
| CAUTION | Make sure that the crankshaft is not rotated. |
Scheme 183
| CAUTION | Make sure that the area around the component is clean and free of foreign material. |
Scheme 184
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Scheme 185
Torque: Intermediate section for engine block step 1
20 Nm
Torque: Intermediate section for engine block step 2
40 Nm
Scheme 186
Torque: Intermediate section for engine block step 3
24 Nm
Scheme 187
Torque: Intermediate section for engine block step 4
17 Nm
Torque: Intermediate section for engine block step 5
90°
Scheme 188
Note. Make sure that the classification of the components correspond with each other.
See information about engine. See ENGINE
Scheme 189
Scheme 190
See information about engine. See ENGINE
Scheme 191
Scheme 192
Note. Make sure that the classification of the components correspond with each other.
Scheme 193
Scheme 194
see 9995746
Note. Make sure that the classification of the components correspond with each other.
Torque: Cap connecting rod
Stage 1: 30 Nm
Stage 2: 90°
Torque: M7
17 Nm
Scheme 195
see 9997273
Scheme 196
| CAUTION | Make sure that the gaskets are correctly located. |
Scheme 197
Note. Make sure that the component is clean, free of foreign material and lubricant.
Use: Cleaning agent, 1161721
see 9512767
Use: Chemical gasket, 1161059
Torque: M7
17 Nm
Torque: M7
17 Nm
Torque: M10
50 Nm
Scheme 198
see 9997174
