GEAR SELECTOR ASSEMBLY

Gear selector assembly with Geartronic function

Scheme 115

Scheme 115: GEAR SELECTOR ASSEMBLY
Scheme 115: GEAR SELECTOR ASSEMBLY

Gear selector assemblies with Geartronic are unique in appearance and function. In addition to modes they also have a "manual" shifting mode.

The gear selector for Geartronic has the following functions

  1. Park position
  2. Back-up.
  3. Neutral.
  4. Automatic shifting between all gears. (Does not apply when the mode selector is in winter mode)
  5. Manual shifting. There are three Hall sensors on the gear selector module (GSM). A permanent magnet on the cover in the gear selector lever affects the output signals of the Hall sensors to the gear selector module (GSM).
