3.6L - Engine Assembly - Engine Code(s): Cgra: Overview Volkswagen Touareg II

Mechanical 1 illustration

Scheme 182

Scheme 182: ENGINE CARRIER, ENGINE MOUNT AND BRACKET OVERVIEW
Scheme 182: ENGINE CARRIER, ENGINE MOUNT AND BRACKET OVERVIEW
  1. Bolt 120 Nm + 180° (1/2) additional turn. Always replace
  2. Engine Mount, Right
  3. Bolt 60 Nm
  4. Bolt 40 Nm
  5. Wire Bracket
  6. Nut 75 Nm
  7. Engine Mount Bracket, Right
  8. Engine Mount Bracket, Left With the oil filter housing.
  9. Bolt 25 Nm
  10. Wire Bracket
  11. Wire Bracket
  12. Bolt 25 Nm
  13. Bolt 60 Nm
  14. Engine Mount, Left
  15. Engine Carrier
