3.0L - Engine Assembly - Engine Code(s): Cata: Component Locations Volkswagen Touareg II

SPECIAL TOOLS

Special tools and workshop equipment required

Scheme 305

Scheme 306

Scheme 307

Scheme 308

1. Support Set VAS 6131/10
2. Supplementary Set VAS 6131/12
3. Supplementary Set VAS 6131/11
4. Supplementary Set VAS 6131/13
5. Tapered Mounting Pin VAS 6131/10-2 (Qty: 3)
6. Engine and Transmission Holder VAS 6095
7. Universal Mounting VAS 6095/1
8. Bracket for V6 TDI Engine VAS 6095/1-4
9. Lifting Tackle 3033
10. Shop Crane - Load Cap = 700-1200 KG VAS 6100
11. Lift Arm Ext./Workshop Hoist VAS 6101
12. Tensioning Strap T10038
13. Ball Joint Puller T10187
14. Bracket 30-211 A
15. Socket T40058
16. TORX® Socket T60 T40087

Scheme 309

Special tools and workshop equipment required

1. Engine Support Bridge 10-222 A
2. Bracket with Hook and Spindle 10-222 A/10
3. Adapter 10-222 A/28
4. Adapters 10-222 A/29
5. Engine Support Basic Set T40091
6. Engine Support Supplement Set T40093

Scheme 310

Special tools and workshop equipment required

1. Used oil Collecting and Extracting Device V.A.G 1782
2. Step Ladder VAS 5085
3. Engine Bung Set VAS 6122
4. Scissor Type Assembly Platform (US) VAS 6131 A
5. Drip Tray for VAS 6100 VAS 6208
6. Hose Clip Pliers VAS 6362
